Oreck U2250, XL CLASSIC User Guide
76009-01 REV C
Powerful, Lightweight
Upright Vacuum
XL®Classic Series
User’s
Guide
Important!
Read all instructions carefully, and keep for future reference.
Safety.
ENGLISH
General Warnings
IMPORTANT SAFETY INSTRUCTIONS!
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
ARNING To reduce the risk of fire, electric shock, or injury:
W
Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing.
•
Do not use outdoors or on wet surfaces.
•
• Do not operate the unit while in the upright and locked position.
• Do not let the unit run while in any one stationary position for any period of time. Keep the unit moving while
in operation.
• Do not allow to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged,
left outdoors, or dropped into water, return it to a service center or call customer service at:
US: 1-800-989-3535 Canada: 1-888-676-7325
• Do not pull or carry by cord, use cord as a handle, close door on cord, or pull cord around sharp edges
or corners.
Keep cord away from heated surfaces.
•
• Do not run appliance over cord.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair
and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
• Do not use to pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not use without filter bag assembly in place.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids, such as gasoline or lighter fluid, or use in areas where
they may be present.
• Do not use appliance in an enclosed space where flammable, explosive or toxic vapors are given off by oil base
paint, paint thinner, some mothproofing substances, or in an area where flammable dust is present.
• Do not pick up toxic material such as chlorine bleach, drain cleaner, gasoline, etc. with this appliance.
• Use caution when vacuuming over area rug edges and fringe.
Enjoy.
Call.
Click.
Visit.
SAVE THESE INSTRUCTIONS
Household Use Only
A polarized plug has one rounded prong and one straight prong.
The rounded end goes into the longest socket slot.
To reduce the risk of electric shock, this equipment has a polarized plug
lade is wider than the other).
(one b
only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not f
Do not alter the plug in any w
Thank you for purchasing our Oreck XL
erful upright Oreck has ev
w
po
than 99.99% of all particles including pollen, mold spores and pet dander
the nap of your carpet the very first time you use it.
To speak with an Oreck representative call:
USA:
On the web, point and click at: www.oreck.com
Visit us in person at one of over 450 store locations. To find the nearest store, please call
888-oreckstore (888-673-2578) or visit www.oreckstore.com.
it, contact qualif
1-800-989-3535 Canada: 1-888-676-7325
This plug will fit in a polarized outlet
ied personnel to install the proper outlet.
y.
a
®
er developed. The U2250 features a 1-year warranty. The Celoc
U2250 Classic Series upright vacuum cleaner. It is the quietest, most
. And because it's an Oreck, it can restore
®
iltration traps more
f
2
Contents.
Total Cleaning System
ENGLISH
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
eneral Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
G
peration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
O
arts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
P
Assembling the Handle Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operating the U2250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operating Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposable Filter Dust Bags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
®
Celoc
Filtration System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
he Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
T
ubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
L
aintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
M
Replacing Disposable Filter Dust Bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Replacing Worn Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting or Replacing Brushroll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Replacing Edge Brush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using an Oreck Fresh Air
Stuffing or Blockage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Accessories & Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Español Guía Del Usuario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Guide D’utilisation Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
®
Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operation.
To assist you in
identifying your
vacuum’s components,
the parts ha
numbered as follows.
ve been
Parts List
1 Handle
2 On/Off Switch
3 Cord Hook
4 Handle Tube
5 Zipper
6 Bumper
Edge Brush
7
8 Belt Door
9 Power Cord
10 Connector Deflector Assembly
11 Collars
Lower Tube
12
13 Fan Housing
14 Bag Spring
15 Outer Bag
16 Power Head
Disposable Filter Dust Bag
17
18 Housing
17
1
5
3
10
4
15
11
12
9
2
13
14
18
6
16
8
7
3
Operation.
ENGLISH
Assembling the Handle Tube
Before assembling appliance, remove two screw from the connector assembly. Remove cardboard insert by
1
pulling upward.
2
lide upper handle section over the matching section of the connector assembly. Insert short screw into top
S
hole and long screw into the bottom hole then tighten firmly until handle is no longer loose.
Upper
Handle
1
Connector
Assembly
2
Operating the U2250
Make sure disposable filter dust bag is in place. DO NOT operate the cleaner without a filter dust bag. Plug the
power cord into an electrical outlet and press the
Up-Position Lock - Place foot on power head and lean handle back gently to release lock for vacuum use.
3
Return handle to the full upright position to engage lock.
locked position. Do not let the unit run while in any one stationary position for any period of time. Keep the
unit moving while in operation.
4
Easy Power Cord Storage - Wrap power cord around cord hook on handle and cord hook on connector.
Secure to “U” shaped part on plug.
On ( l ) - OFF ( O ) switch on top of base when ready to operate.
Note: Do not operate the unit while in the upright and
3
4
Operating Instructions
This new ORECK Upright is one of the finest, fastest, and strongest units in its class. You’ll love the way it cleans,
gets under things, and it’s SO lightweight and easy to use.
The following are a few simple suggestions regarding its operation:
1. When inserting a new disposable filter dust bag -FIRST PUFF OUT and OPEN THE BAG.
2. When the disposable filter dust bag is full, REPLACE IT.
y time the machine does not pick up properly or makes an unusual noise, STOP OPERATION and service.
If at an
3.
4. Although your upright will pick up pins, paper clips, and other small objects, it is recommended that these be
removed from the floor before you vacuum. Failure to do so may result in permanent damage to the motor
an and its housing.
suction f
5. WARNING: Do not use your vacuum cleaner on damp or wet surfaces. This will cause damage to the vacuum
cleaner and is dangerous to the user. Damage caused by use on wet or damp surfaces is not covered under warranty.
or optimal performance, replace the belt every 6 months.
F
6.
7. Check the disposable filter dust bag at least once a month.
acuum cleaner over the cord. The revolving brush could damage the cord.
un the v
T r
DO NO
8.
9. Use caution when vacuuming over area rug edges and fringe.
4
General
ENGLISH
The performance of your new cleaner greatly depends upon care and maintenance. The instructions in this manual
will guide you in performing basic care and maintenance. To obtain the most satisfying years of service read the
instructions and keep them handy for future reference.
Information
.
Disposable Filter Dust Bags
Disposable filter dust bags play a very important role in the efficiency of your ORECK vacuum cleaner. The
purpose of the filter bag is to trap dirt, but at the same time it must be porous enough to allow air to pass through.
f the filter bag becomes clogged, no air can pass through the cleaner and cleaning cannot take place, regardless of
I
he cleaner’s power.
t
To keep your cleaner operating at maximum efficiency, change the dust bag frequently.
DO NOT FILL ABOVE THE LINE INDICATED ON THE DUST BAG.
Be sure the disposable filter dust bag is installed properly. Note: All disposable filter dust bags are not the same.
Your ORECK disposable dust bags have been designed to be used with the ORECK cleaner. Using bags other than
genuine ORECK TYPE CC disposable bags will affect the cleaning ability of your cleaner and could cause damage
to it.
Celoc®Filtration System
The Celoc outer bag of y
of dust particles. It is important the inside of the outer bag be cleaned. Vacuum the inside of the outer bag or hand
wash, turned inside out, with warm water, and air dry. If desired, the Celoc outer bag can be replaced for renewed
efficiency. The Celoc layered disposable inner dust bag must be replaced once a month even if it is not full. Change
it more often if it is used in extremely dirty areas. Increase the cleaning power of your vacuum by changing the bag
often.
our vacuum cleaner is high filtration medical material designed to filter the smallest
The Belt
The belt on your vacuum cleaner controls the speed of the revolving brush and is very important for the effective
operation of the cleaner. If the belt becomes stretched or cut, it will cause the revolving brush to stop completely or
slow down. See instructions in the manual for replacing belt.
Note: An extra belt is stored in the baseplate of your cleaner. When buying replacement belts, use ONLY ORECK
genuine belts. Belts other than Oreck belts will not operate the revolving brush correctly and may create undue
stress which will cause damage to the motor and brush bearings. Using belts other than ORECK belts will void the
warranty.
Lubrication
The vacuum cleaner motor bearings are factory lubricated and sealed. Further lubrication is not required.
CAUTION
Wood Floors, Soft (Vinyl, Asphalt Tile, etc.) Floor Surfaces and Polished Floor Finishes
Use floor and floor finish manufacturer’s recommended methods of cleaning. The roller
brush may also scuff very soft finishes. Do not operate the unit while in the upright and locked position. Do not let
the unit run while in any one stationary position for any period of time. Keep the unit moving while in operation.
Note: At least once a month, check for and remove excessive lint, string or hair from
revolving brush. Patented cleaning grooves on brush roll will allow easier cleaning.
Wipe the outside of the cleaner with a damp cloth. Also clean the connector deflector
assembly area, base of cleaner and fan housing area. If there is dust in the outer bag,
acuum it or shake it out.
v
A little preventative maintenance will keep your cleaner looking new and will ensure
continued cleaning ef
fectiv
eness.
5
ENGLISH
ENFONCEZ JUSQUENFONCEZ JUSQU’À’À
ENTENDRE UN BRUITENTENDRE UN BRUIT
P
RESIONE HASTPRESIONE
H
ASTAA
ESCUCHAR UN ESCUCHAR UN
CHASQUIDO DE SUJECICHASQUIDO DE SUJECIÓÓNN
ENFONCEZ JUSQU’À
ENTENDRE UN BRUIT
P
RESIONE HASTA
ESCUCHAR UN
CHASQUIDO DE SUJECIÓN
Replacing Disposable Filter Dust Bag
WARNING: Unplug cord from electrical outlet before servicing.
AG REMOVAL:
B
5
Unzip outer bag completely.
Pull bag cardboard collar to release bag dock door from connector. Bag dock door will hinge downward.
6
Gently pull bag cardboard collar upward out of the bag dock. Saniseal
7
BAG INSTALLATION:
8
lide the cardboard collar completely onto bag dock door.
S
9
Firmly push bag dock door with both thumbs on indication point until it snaps.
5 6 7 8 9
®
dust seal will close automatically.
Maintenance.
Replacing Wor
n Belt
WARNING: Unplug cord from electrical outlet before servicing.
10
Remove the replacement belt from the storage channel.
Remove the door by removing the hold down screw located on side of power head.
11
Fold door away from the power head and lift it away.
12
Remove the belt from the motor drive shaft and brush roll pulley.
13
Loop the new belt over the brush roll pulley. Place the opposite end of the belt on the motor drive shaft.
14
Replace the door by placing the bottom tab on door into slots located inside power head and pressing the
12
door closed.
Replace the hold down screw and tighten.
11
10
11
12
13 14
Adjusting or Replacing Brushroll
ARNING:
W
To determine if the brushroll is worn, place a firm straight edge across the nozzle opening. If brushroll bristles do
not extend be
Remove the baseplate by removing 5 screws. Then, remove the belt and brushroll from the housing.
15
Rotate both bearing assemblies at ends or brushroll to sho
16
Note: The bearing assembly setting marked “OLD” has no ribs on the top of the assembly.
17
The one marked “NEW” has several ribs. When rotating bearings, make sure both bearing assembly settings are
18
the same and f
Reassemble the belt.
14
Reassemb
15
Unplug cord from electrical outlet before servicing.
ond baseplate, brushroll should be adjusted.
y
w “OLD” and replace in the holding channels in the housing.
ace up w
hen replacing the br
ushroll.
le the baseplate.
6
ENGLISH
If a previous adjustment has already been made and bristle height does not extend above the baseplate, a new brush assembly should be ordered.
IMPORTANT: Unless the brush is worn as indicated above, both bearings must be in the “NEW” position.When rotating, both
bearings must be in the “OLD” position. Unmatched settings can cause damage to the unit.
OLD
5
1
16
7
1
NEW
18
Replacing Edge Brush
WARNING: Unplug cord from electrical outlet before servicing.
Turn the power head over. With baseplate facing up, remove the screw located in the center of each edge brush.
Remove both edge brushes and replace with new ones. Replace both screws and tighten.
Using an Oreck Fresh Air®Tab
Your ORECK U2250 vacuum cleaner has a special ORECK FRESH AIR®tab pocket.
This pocket is located inside the outer cloth bag in the area where the disposable filter
dust bag attaches to the intake tube. Insert tablet in pocket if desired.
Stuffing or Blockage
IMPORTANT: On plush and new carpets, stuffing may occur inside the the intake tube and the lower tube assembly. This is due to excessive
fuzz and loose cuttings in the carpet. Stuffing could occur for the first few cleanings until all the loose material is removed. Due to the high
efficiency of the cleaner, many older carpets will cause stuffing when the cleaner is first used on them. If your vacuum cleaner does not pick
up properly, or makes unusual noise and the outer bag does not fluff up or balloon open, follow these steps:
WARNING: Unplug cord from electrical outlet before servicing.
Check for blockage at the mouth of the intake opening. If there is blockage, remove it with long-nose pliers,
19
a screwdriver or coat hanger. If you can not reach the blockage, remove baseplate. Remove the baseplate by removing 5 screws (see “Adjusting
or Replacing Brushroll”).
If the blockage is not at the base, remove lower tube. Unhook bag spring, releasing bottom of bag.
20
Twist lower collar counterclockwise to slide up. Pull tube out of base.
21
Check for blockage. If blockage is in the tube, remove with a coat hanger.
22
If tube is not blocked, look into fan housing. Remove debris with long-nose pliers, a screwdriver or coat hanger.
23
To reassemble, check O-ring on tube, and replace if damaged. Replace tube by first lining up slot at base of tube with tab inside fan housing.
21
Insert tube and push down until the tube is seated. Make sure O-ring is in place against fan housing opening. Replace and tighten collar until
collar locking tabs are locked in place. Reattach bag spring.
Many times blockage occurs due to a full dust bag causing dirt to back down the air flow system. When that happens, the blockage will be at
24
the top of the system, starting in the area where the dust bag connects to the connector assembly.
Note: If the above actions do not correct the problem, contact an Oreck authorized service center or call the customer service center.
1-800-989-3535 Canada:
US:
1-888-676-7325
19
20 21 22
7
23
24
ENGLISH
Trouble-
shooting.
Service problems that
appear to be major can
often be solved easily.
You can be your own
troubleshooter by
reviewing this guide.
All other servicing
should be done by an
eck authorized
Or
service center.
Parts.
PPrroobblleemm CChheecckk WWhhaatt ttoo ddoo
leaner will not run.
C
Cleaner does not pick up. •Filter Bag is full. • Replace filter bag. See “Replacing Disposable
Unit still does not •Check all the • Contact Oreck for service.
operate properly. above points.
All accessories and replacement parts are sold separately. To order, call our customer service group or visit our
website. Please have your model number from the data label on the bottom of the unit.
Not plugged in properly. • Be sure cleaner is firmly plugged into wall outlet.
•
•No electricity in wall outlet. • Check electrical source – fuse or circuit breaker.
Filter Dust Bag”.
Nozzle or intake pivot • Clear obstruction.
•
logged.
c
•Belt is broken or stretched. • Replace belt.
Brush is worn. • See “Adjusting or Replacing Brushroll”.
•
•Bag tube clogged. • Clear obstruction.
Bag pores are clogged •Change bag.
•
ith fine dust.
w
•Impeller fan is broken. • Return to Service Center for repair.
•Revolving brush is not • Check bearing seal. Make sure words “OLD”
even at both ends. or “NEW” at each end.
Accessories
IItteemm PPaarrtt NNuummbbeerr
Crystal Aroma®Carpet and Room Freshener AROMAII
Oreck Dry Carpet
®
Cleaning System 303088
Replacement Parts
IItteemm PPaarrtt NNuummbbeerr
Dust Bag, 8 Pack, Saniseal® Odor Fighting Hypo-Allergenic CCPK8OF
Dust Bag, 8 Pack, Saniseal
Belts, 3 P
ack 0300604
®
Hypo-Allergenic CCPK8DW
Customer Service Hotline
USA: 1-800-989-3535 Canada: 1-888-676-7325
website: www.oreck.com
8
Warranty.
Total Cleaning System
ENGLISH
ORECK MANUFACTURING COMPANY: (Oreck Manufacturing Company gives you the following limited
arranty for this product only if it was originally purchased for residential use, not resale, from Oreck or an Oreck
w
uthorized Retail Dealer.)
A
reck will repair or replace, free of charge, to the original purchaser, any part that is found to be defective in
O
aterial or workmanship within one (1) year of the date of purchase; ten (10) years on housing. This limited war-
m
ranty applies to normal domestic use. Any commercial use of this product will void this limited warranty. This limited warranty covers the revolving roller brush for one (1) year for residential use only.
This limited warranty does not cover the replacement of expendable or consumable parts such as carbon motor
brushes, edge brushes, drive belts, brushes, bulbs, disposable bags and other parts subject to normal wear unless
they are defective in material or workmanship.
This limited warranty does not apply to any part subjected to accident, abuse, commercial use, alteration, misuse,
damage caused by act of God, the use of voltages other than indicated on the serial number displayed on this
roduct or service of this product by other than Oreck or a participating Factory Authorized Service Center. Oreck
p
does not authorize any person or representative to assume or grant any other warranty obligation with the sale of
this product.
Oreck’s limited warranty is valid only if you retain proof of purchase from Oreck or an Oreck Authorized Retail
Dealer for this product. If you purchase this product from any other source, your purchase is “AS IS,” which means
Oreck grants you no warranty, and that you, not Oreck, assume the entire risk of the quality and performance of
this product, including the entire cost of any necessary servicing or repairs of any defects.
Oreck’s liability for damages to you for any costs whatsoever arising out of this statement of limited warranty shall
be limited to the amount paid for this product at the time of original purchase, and Oreck shall not be liable for any
direct, indirect, consequential or incidental damages arising out of the use or inability to use this product.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE WARRANTY PERIOD, AND NO WARRANTIES, WHETHER EXPRESS OR
IMPLIED, WILL APPLY AFTER THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties, so the above limitation may not apply
to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
If appropriate, see additional information for extended warranty.
Loading...
