Oreck 21057-03 User Manual

21057-03 Rev A

Professional Air Purifier

AIRP Series

User’s Guide

Important!

Read all instructions carefully, and keep for future reference.

Enjoy

Total Cleaning System

E N G L I S H

Thank you for purchasing an Oreck Professional Air Purifier! You will enjoy years of cleaner, fresher air with the Oreck air purifier in your

home. It includes six different air purification technologies to provide unique protection against airborne pollutants and allergens: Stage 1. The pre-filter removes large particles, including dust, lint,

and hair. Stages 2 and 3 are part of the Truman Cell Stage 2. Positive charging wires electrostatically charge smaller particles

such as dust, smoke, pollen, bacteria, molds, viruses, and fungi. Stage 3. The electronic Truman Cell

particles and destroys the bacteria, molds, viruses and fungi. Stage 4. The optional odor absorber removes common household odors

and chemical fumes. Stage 5. The oxygenator changes atmospheric ozone to harmless oxygen. Stage 6. The optional air revitalizer negative ion generator provides

additional air freshness and a pleasant, clean scent through

the release of negative ions. This combination of technologies provides broad protection against a wide range of contaminants to make your home healthier, cleaner, and more livable. Enjoy!

™

proprietary technology.

™

collects the electrostatically charged

Call.

Click.

Visit.

At Oreck we understand that our customers are unique and expect superior service. To meet your needs, we offer different customer service options to work with your lifestyle and preferences.

Welcome to our Call. Click. Visit. customer service program.

To speak with an Oreck representative call: USA: 1-800-989-3535

Canada: 1-888-676-7325

On the web, point and click at: www.oreck.com

Visit us in person at one of over 450 store locations. To find the nearest store, please call 888-oreckstore (888-673-2578) or visit www.oreckstore.com.

E N G L I S H

Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cleaning Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cleaning the Pre-Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

™

Cleaning the Truman Cell

Cleaning the Air Direction Grill . . . . . . . . . . . . . . . . . . . 10

Cleaning the Oxygenator . . . . . . . . . . . . . . . . . . . . . . . . . 10

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Replacing the Odor Absorber . . . . . . . . . . . . . . . . . . . . . 10

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Español Guía del usuario . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

. . . . . . . . . . . . . . . . . . . . . . . 9

E N G L I S H

Safety

General Warnings

IMPORTANTSAFETYINSTRUCTIONS!

When using an electrical appliance, basic precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS AIR PURIFIER WARNING To reduce the risk of fire, electric shock, or injury:

• Do not use outdoors or on wet surfaces.

• Use only as described in this manual.

• Do not use with damaged cord or plug. If appliance is not working as it

should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center or call customer service at:

USA: 1-800-989-3535 Canada: 1-888-676-7325

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Do not handle plug or appliance with wet hands.

• Do not put any object into openings. Do not use with any opening blocked;

keep free of dust, lint, hair and anything that may reduce air flow.

• Keep hair, loose clothing, fingers and all parts of body away from openings

and moving parts.

• Turn off all controls before unplugging.

• Do not use appliance in an enclosed space where oxygen, flammable, explosive or

toxic vapors are given off or in an area where flammable dust is present.

• You should consult your oxygen and medical equipment providers before

using the air purifier around oxygen tanks, hoods, or other medical devices using concentrated oxygen. Using electronic devices, including an air purifier, in the presence of oxygen and other combustible gases could result in fires or

explosions, potentially causing serious injury or even death.



SAVETHESEINSTRUCTIONS

CAUTION!

Installing a wet or even damp Truman Cell™into the air purifier may cause melting of internal components during use.

• DO NOT place a wet or damp Truman Cell

• DO NOT wash the odor absorber. Replace, if necessary.

• Dry the Truman Cell

it into the air purifier. Ensure that all areas including corners and areas that may trap water are dry before reinstalling into the air purifier.

™

thoroughly outside of the air purifier before reinstalling

FOR COMMERCIAL USE:

High voltage from Truman Cell™may cause ignition of flammable or explosive gases/particles in the circulating air.

• DO NOT use in an area that contains flammable or explosive gases/particles in

the circulating air.

™

in the air purifier.

Use

ONLY Oreck

certifi ed parts and

accessories.

E N G L I S H

• Do not place open flames, including candles, directly in front of the air purifier.

Doing so may result in minor or moderate injury.

• Keep objects away from the front grill. It is important to consider the following when deciding on where to locate the air

purifier:

• Position the air purifier on a flat, solid, stable surface.

• Position the air purifier where the dirty air is not drawn across your head or body

while sitting or sleeping.

• Position the air purifier so the plug on the power cord easily reaches a standard

electrical outlet for a polarized plug.

• Do not use an extension cord.

• Do not place the air purifier near sources of heat, such as stove tops, ovens,

radiators or computers.

A polarized plug has one rounded prong and one straight prong. The rounded end goes into the longest socket slot.

To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact qualified personnel to install the proper outlet. Do not alter the plug in any way.

Parts

All accessories and replacement parts are sold separately. To order, call our

customer service group or visit our website. Please have your model number from the data label on the bottom of the unit.

Accessories

Item Part Number

Assail-a-Cell®Collector Cell Cleaner, 20 oz. 32358 Spring Mulberry Blooming Jasmine Odor Absorber AP1PKP

Scent Cartridges, 8 pack FA2PK

Scent Cartridges, 8 pack FA3PK

Replacement Parts

Item Part Number

Pre-Filter 21024-01 Truman Cell

Customer Service Hotline USA: 1-800-989-3535 Canada: 1-888-676-7325

™

09-21058-01

website: www.oreck.com

E N G L I S H

Operation

Simply follow the numbered steps to use your Air Purifier. Each call out describes the features of the Air Purifier and how it functions.

Top Cover - Easily removed by sliding forward

and lifting off.

Oxygenator - Permanent cartridge converts ozone into oxygen. Odor Absorber - Optional feature that removes odors

and chemical fumes from glue, solvents and synthetic materials. The purifier continues to clean the air with or

without the odor absorber.

Truman Cell™- Electrostatically charges and

collects small particles such as dust, smoke, pollen, bacteria, molds, viruses, and fungi.

Pre-Filter - Removes large particles

such as dust, hair and lint.

Front Grill - Slides off for easy cleaning. Slide to

the left to remove. The grill must be closed securely for the unit to operate.

Cleaning Brush - (not shown)

Included to clean air direction grill and areas around the air purifier.

Turns red when the Truman Cell™needs cleaning.

Hold down the Air Revitalizer button until the light blinks

Turns red when the optional odor absorber has been in

use 12 months. Hold down the Night Light button until

the light blinks three times to reset the timer after

Collector Cell Light

three times to reset the timer after cleaning.

Odor Absorber Light

replacing the odor absorber

Air Revitalizer Light

Indicates when the Air Revitalizer is ON.

Air Revitalizer

Button

2 3

Position the air

purifier so dirty air is

not drawn across your

head or body.

E N G L I S H

Air Direction Grill - Directs the flow of air. Air Direction Control - Slide the button in the direction

that you would like the air to flow.

Night Light - Conveniently lights your room if desired.

Fragrance Tray - Holds the scent

cartridge to provide optional fragrances to the air returned to the room.

Fragrance Tray Button - Push to open

the fragrance tray.

Power Button

Night Light

Button

Place.

Locate the air purifier on a hard surface such as a table or desk. Be sure the grill is not blocked by other objects, there are no candles or flames near

the unit.

Plug In.

Plug into nearest standard electrical outlet that accepts a polarized plug.

Select the air cleaning speed.

Press the power button for the desired speed.

• High for maximum cleaning.

• Mediumfor normal use.

• Silencefor Silence Technology

The quietest setting, cleaning the air as effectively but more slowly than the higher settings.

Turn on the Air Revitalizer.

Provides additional air freshness and a pleasant, clean scent through the release of negative ions. Negative ions may cause dust to settle from the air onto the air purifier and surrounding furnishings. Designed to run continually, but may be turned off if desired.

Cleaning

The

Air Purifier

will not run if the

top cover and grill are

not closed securely.

E N G L I S H

Cleaning Times

Proper care and cleaning of the air purifier is critical to performance. The following

chart shows the cleaning intervals and methods.

Part Cleaning Time Method

Cabinet As needed Wipe with damp cloth first. If required,

™

Truman Cell

2 to 4 weeks, Spray Oreck Assail-a-Cell® cleaner or as needed or soak in warm water with mild

™

Truman Cell

If arcing occurs* Gently wipe cell wires with a dry

Pre-filter 2 to 4 weeks, Rinse thoroughly in warm water.

or as needed

Odor 12 months, Replace (optional for odor removal). Absorber or as needed Do not wash or get wet.

Air Direction As needed Use the brush provided with the Grill air purifier to brush away debris

Oxygenator As needed Vacuum the front with a soft

*Arcing is a sharp snapping sound that can occur when dust particles build up in the Truman Cell™.

follow with mild non-abrasive cleaner.

detergent.Rinse and dry thoroughly.

cotton swab, Spray Oreck Assail-a-Cell cleaner or soak in warm water with mild liquid detergent. Rinse and dry thoroughly.

Vacuum to clean, if necessary.

in between the slots.

brush attachment. Do not use any liquids for cleaning.

WARNING!

Cleaning the unit while it is plugged in may result in electric shock, electric spark and serious injury. Unplug the unit before cleaning or maintenance. Remove the

unit from the wall if it is wall mounted.

Cleaning the Pre-Filter

Unplug the air purifier. Remove the top cover by sliding forward and lifting off.

Pull the pre-filter straight up and out of the cabinet.

Thoroughly rinse the pre-filter and let it air dry before placing it back in the

cabinet. Do not use heated or compressed air as part of the drying process. Place the pre-filter back into the unit by sliding it straight down into the slots.

Place the top cover back on the cabinet, sliding back to lock into place.

E N G L I S H

Cleaning the Truman Cell

Note: The Truman Cell™may require more frequent cleaning if “arcing” occurs. Arcing is a sharp snapping sound that occurs when large particles of dust are collected in the Truman Cell

™

. If prolonged

or continuous arcing occurs the Truman Cell™should be cleaned.

IMPORTANT: Do not try to clean the Truman Cell™by inserting a cloth, brush, or other object between the cell plates.

Unplug the air purifier. Remove the top cover by sliding forward and lifting off.

Pull the Truman Cell

of the Truman Cell

Based on the frequency of arcing or how dirty the cell has become, perform one or both of the following steps: If the cell is arcing frequently a “quick clean” can be performed by gently wiping a dry cotton swab

™

straight up and out of the cabinet by using the two small handles on each side

™

along the length of each of the four wires near the front of the cell to remove any built-up particles from the wires. Go to Step 9.

For a more complete cleaning, place the Truman Cell

™

in a sink, bathtub, dishwasher or other loca-

tion where cleaner and contaminants will rinse away without damaging surfaces and proceed to Step 7. Note: If placed in dishwasher, do not insert dishwasher tongs directly into the collector cell as this may cuase damage to the wires or cell plates.

Spray Oreck Assail-a-Cell

surface. Allow the cleaner to soak for a few minutes and rinse with clean water. Do not let the cleaner dry on the Truman Cell

An alternative method to clean the Truman Cell Mild liquid dish detergent may be used to help break down dirt. Rinse thoroughly with clean water. Note: Do not insert objects to clean the Truman Cell

cleaner thoroughly between each cell plate and cover each

™

is to soak it in warm water for two to three hours.

™

. Tough residue such as tar from tobacco smoke may need additional applications or longer soaking. Allow to dry completely outside of the air purifier. Do not use heated or compressed air to dry.

IMPORTANT: Do not reinsert the Truman Cell Cell” light blinks red after replacing the Truman Cell™, then the Truman Cell™may still be wet. Remove the Truman Cell

Place the Truman Cell

™

and allow it to finish drying.

™

back into the unit by sliding it straight down into the slots. The Truman Cell

™

until it is completely dry. If the “Check Collector

is specially designed so that it can be inserted only in one direction.

Replace the top cover, sliding back to lock into place. Be sure the top cover and front grill are securely closed or the unit will not operate.

Reset the “Check Collector Cell” timer by holding down the Air Revitalizer button until the “Check

Collector Cell” light blinks three times.

™

CHANGE ODOR ABSORBER

HOLD TO RESET

HIGH

MEDIUM

SILENCE

NIGHT

LIGHT

CHECK

COLLECTOR CELL

HOLD TO RESET

AIR

REVITALIZER

Maintenance

CHANGE ODOR ABSORBER

HOLD TO RESET

HIGH

MEDIUM

SILENCE

NIGHT

LIGHT

CHECK COLLECTOR CELL

HOLD TO RESET

AIR

REVITALIZER

E N G L I S H

Cleaning the Air Direction Grill

Using the cleaning brush (located on the bottom of the top cover), brush away any debris that may have collected between the grill slots.

Cleaning the Oxygenator

Unplug the air purifier.

Remove the top cover

odor absorber, pre-filter, and Truman Cell

Lightly vacuum the front

™

only with a soft-brush attachment. Do not use liquids to clean. Liquids will damage the oxygenator.

Replace all parts in step 2.

Cleaning the Oxygenator

Oreck Cleaning Brush

Unplug the air purifier.

Remove the top cover by sliding forward and lifting off.

Pull the odor absorber straight up and out of the cabinet.

Replace with a new odor absorber. The handles on the odor absorber

should point up. Do not force the odor absorber into the slot. Replace the top cover, sliding back to lock into place.

Reset the “Check Odor Absorber” timer by holding down the Night Light button until the “Check Odor Absorber” light blinks three times.

E N G L I S H

Troubleshooting

Service problems that appear to be major can often be solved easily. You can be your own troubleshooter by reviewing this guide. All other servicing should be done by an Oreck authorized service center.

Problem Check What to do

Unit does not turn on. • Power Cord • Plug in the power cord.

• Power Button • Set power button for desired blower speed.

• Front Grill • Reinsert front grill, sliding right until it locks

• Top Cover • Top cover should be replaced and slid back to lock.

“Check Collector Cell” • Truman Cell has turned red. thoroughly clean and dry before reinstalling.

“Check Collector Cell” • Truman Cell light is flashing red. Clean Truman Cell™.

Unit does not • Truman Cell remove pollutants. thoroughly clean and dry before reinstalling.

Unit sparks, crackles • Truman Cell and pops. when dust particles build up in the Truman

“Check Odor Absorber” • Odor Absorber • Hold down the Night Light button until the light has turned red. light blinks three times to reset the Check

Does not remove odor. • Odor Absorber • Vacuum odor absorber with a soft brush

Unit still does not • Check all the • Contact Oreck for service. operate properly. above points.

into place.

™

• Wash Truman Cell™. Make sure it is

• Hold down the Air Revitalizer button until the light blinks three times to reset the timer after cleaning.

™

• Truman Cell™may need cleaning.

™

• Truman Cell

may not be completely dry.

Allow it to air dry longer.

™

• Truman Cell

may be damaged.

Contact Oreck for service.

™

• Wash Truman Cell™. Make sure it is

™

• Sparking or popping noise (arcing) can occur Cell™. Gently wipe the cell wires with a dry

cotton swab, or clean the entire cell with Assail-a-Cell or soapy water.

• If excessive arcing continues after proper cleaning, the cell may be damaged or wet. If damaged contact Oreck for service.

Odor Absorber timer after replacing.

• Replace odor absorber if desired.

• If the odor absorber is not replaced, remove old odor absorber to turn off “Check Odor Absorber” light.

attachment if dirty. Do not use any liquids to clean the odor absorber.

• Replace odor absorber if desired.

+ 25 hidden pages
