Orbit Merret OM 652UC/20mm Instruction Manual

Download

OM 652UC/20mm

6 DIGIT PROGRAMMABLE

IMPULSE COUNTER/FREQUENCY METER

STOPWATCH/TIMER

GUARANTEE

YEARS

2 | INSTRUCTIONS FOR USEE OM 652UC

ORBIT MERRET, spol. s r.o.

Vodňanská 675/30 198 00 Praha 9

Tel: +420 - 281 040 200 Fax: +420 - 281 040 299 e-mail: orbit@merret.cz www.orbit.merret.cz

SAFETY INSTRUCTIONS

Please, read the enclosed safety instructions carefully and observe them! These instruments should be safeguarded by isolated or common fuses (breakers)! For safety information the EN 61 010-1 + A2 standard must be observed. This instrument is not explosion-safe!

TECHNICAL DATA

Measuring instruments of the OM 652 series conform to the European regulation 89/336/EWG and the Ordinance 168/1997 Coll.

They are up to the following European standards: EN 55 022, class B EN 61000-4-2, -4, -5, -6, -8, -9, -10, -11

The instruments are applicable for unlimited use in agricultural and industrial areas.

CONNECTION

Supply of energy from the main line has to be isolated from the measuring leads.

NNSTRUCTIONS FOR USE OM 652UC

1. Contens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

2. Instrument description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3. Instrument connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

4. Instrument setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Symbols used in the instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting the DP and the (-) sing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Control keys functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Configuration of „User“ menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

5. Setting “LIGHT” menu

5.0 Description “LIGHT” menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Access to menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting initial value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Selection of instrument measuring mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Selection of control START

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Selection of control STOP

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Selection of digital input filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Selection of type of input A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting level of input A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Selection of type of input C (Resetting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setting level of input C (Resetting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setting multiplying constant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setting dividing constant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setting offset - PRESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selection of projection format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setting limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Setting analog output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Setting color display projection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Setting the menu type (LIGHT/PROFI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Restoration of manufacture setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting new access password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Instrument identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6. Setting “PROFI” menu

6.0 Description “PROFI” menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.1 “PROFI” menu - INPUT

6.1.1 Resetting internal values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.1.2 Instrument configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.1.3 Setting external control input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

6.1.4 Setting function of the control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

6.2 “PROFI” menu - CHANNELS

6.2.1 Setting calibration constants and offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

6.2.2 Setting digital filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

6.2.3 Projection format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

6.3 “PROFI” menu - OUTPUTS

6.3.1 Configuration and setting the limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

6.3.2 Setting data output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

6.3.3 Setting analog output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

6.3.4 Setting display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

6.4 “PROFI” menu - SERVICE

6.4.1 Selection of the type of programming menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

6.4.2 Restoration of manufacture setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

6.4.3 Setting new access password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

6.4.4 Instrument identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

7. Configuration “USER” menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

8. Data protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

9. Error statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

10. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

11. Instrument dimension and installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

12. Certificate of guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

1CONTENS

4 | INSTRUCTIONS FOR USEE OM 652UC

2.1 Description

The OM 652UC model is a universal 6 digit panel programmable impulse counter/frequencymeter and stopwatch/timer. The instrument is based on an 8-bit microprocessor, which secures high accuracy, stability and easy operation of the

instrument.

Measuring modes

COUNTER Single-channel counter

FREQUENCY Frequencymeter

STOPWATCH Stopwatch

TIMER Timer

PROGRAMMABLE PROJECTION

Calibration calibration coefficient may be set in „CM“ Projection -99999...999999 with fixed or floating DP, for measuring modes STOPWATCH/TIMER with the option of setting in format 10/24/60 Time base: 0,5/1/5/10 s

DIGITAL FILTERS

Input filter the instrument enables filtering the input signal and thus suppress unwatnted interfering signals (e.g. relay backswings). The parameter set gives maximum feasible measured frequency processed by the instrument, 5/40/100/1 000 Hz Exponen.average: from 2…100 measurements

LINEARIZATION

Linearization:* by linear interpolation in 25 points (solely via OM Link)

FUCTIONS

Preset initial non-zero value, unloaded always after instrument resetting Rounding setting projection step for display Tare*: designed to reset display upon non-zero input signal

OM Link company interface for control, setting and instrument update

EXTERNAL CONTROL

Hold display/instrument blocking Lock locking the control keys for access into Configuration menu Resettting resetting/pre-setting the counter Tare* tare activation Start/Stop stopwatch/timer control

2 INSTRUMENT DESCRIPTION

NNSTRUCTIONS FOR USE OM 652UC

2.2 Operationn

The instrument is set and controlled by five control keys located on the front panel. All programmable settings of the instrument are realized in two adjusting modes:

LIGHT Simple programming menu

- contains only items necessary for instrument setting and is protected by an optional numeral code

PROFI Complete programming menu

- contains complete instrument menu and is protected by an optional numeral code

USER User programmable menu

- may contain arbitrary items selected from programmable menu (LIGHT/PROFI), which determines the authorization (see or change)

- access is without password

All programmable parameters are stored in the EEPROM memory (they hold even after the instrument is switched off).

Complete operation and setting of the instrument may be performed via communication interface OM Link, which is a standard equipment of every instrument.

The operation program is freely available (www.orbit.merret.cz) and the only requirement is the purchase of OML cable for connecting the instrument to PC. It is manufactured in version RS 232 and USB and is compatible with all ORBIT MERRET instruments.

Another option for connection is with the aid of data output RS 232 or RS 485 (without the need for OML cable). The OM LINK program version „Standard“ allows you to connect an unlimited number of instruments with the option of

visualizatiion and storage in PC.

2.3 Extension

Excitation is suitable for feeding sensors and converters. It has a galvanic isolation. Comparators are assigned to control two limit values with relay output. The limits have adjustable hysteresis as well as

selectable delay of the switch-on. Reaching the preset limits is signalled by LED and simultaneously by the switch-on of the relevant relay.

Data outputs are for their rate and accuracy suitable for transmission of measured data for further projection or directly into the control systems. We offer an isolated RS232 and RS485 with the ASCII protocol.

Analog outputs will find their place in applications where further evaluating or processing of measured data in external devices is required. We offer a universal analog output with the option of selection of output type - voltage/current. The value of analog output corresponds with the displayed data and its type and range are selectable in the programming mode.

Time backup by means of RTC circuit is designed for the „TIMER“ measuring mode and secures time measuring even if the instrument is switched-off (without display projection).

2INSTRUMENT DESCRIPTION

6 | INSTRUCTIONS FOR USEE OM 652UC

The instrument supply leads should not be in proximity of the incoming low-potential signals. Contactors, motors with larger input power should not be in proximity of the instrument. The leads into the instrument input (measured quantity) should be in sufficient distance from all power leads and appliances.

Provided this cannot be secured it is necessary to use shielded leads with connection to ground (bracket E). The instruments are tested in compliance with standards for use in industrial area, yet we recommend to abide by the above

mentioned principles.

CONNECTION

Description Connection

Input A (< 30 V)

input signal < 43 V (absolute 60 V) GND + Input A (< 30 V)

Input A (< 300 V)

input signal < 300 V GND + Input A (< 300 V)

Resetting (< 30 V)

input signal < 43 V GND + Resetting (< 30 V)

Resetting (< 300 V)

input signal < 300 V GND + Resetting (< 300 V)

Function Description Control Hold

Blocking display and instrument outputs upon contact, bracket (no. 11/12)

Lock

Control keys blocking upon contact, bracket (no. 11/12)

Tare

Tare activation upon contact, bracket (no. 11/12)

3 INSTRUMENT CONNECTION

11 12 13 14 15 16 17 18

GND

Reset (< 300 V)

INPUT A (< 300 V)

Excitation

Hold/Lock

POWER SUPPLY

123 567

8910

INPUT A (< 30 V)

232

485

GND

TxD

RxD

GND

Rx/Tx+

Rx/Tx-

GND

AO - I

AO - U

Reset (< 30 V)

Grounding on bracket „E“ has to connected at all times

NNSTRUCTIONS FOR USE OM 652UC

Table of comparation levels

Input

Type of

input

Maximum input

voltage

(Level A, C)

Maximum comparation levels

L > H H > L

Input A

Resetting

(< 30 V)

NPN, Contact xxx 0,5 V 4,5 V

PNP 9,7 V 0,5 V 4,5 V PNP 14,4 V 1,0 V 9,0 V PNP 19,2 V 1,5 V 13,3 V PNP 23,9 V 2,0 V 17,8 V PNP 28,7 V 2,5 V 22,1 V PNP 33,5 V 3,0 V 26,6 V PNP 38,3 V 3,4 V 31,0 V PNP 43,0 V 3,9 V 35,5 V

Input A

Resetting

(< 300 V)

NPN, Contact !!! prohibited !!!

PNP 84 V 4,9 V 39,8 V PNP 128 V 9,2 V 78,0 V PNP 170 V 13,6 V 117,8 V PNP 211 V 17,8 V 156,0 V PNP 253 V 22,3 V 195,8 V PNP 295 V 26,5 V 234,1 V PNP 301 V 30,9 V 273,9 V

3INSTRUMENT CONNECTION

8 | INSTRUCTIONS FOR USEE OM 652UC

For trained users•

Only items necessary for instrument•

setting

Access is password protected•

Possibility to arrange items of the•

„User“ menu

Linear menu structure•

For expert users•

Complete instrument menu•

Access is password protected•

Possibility to arrange items of the •

„User“ menu

Tree menu structure•

SETTING PROFISETTING LIGHT

For user operation•

Menu items are set by the user •

(Profi/Light) as per request

Access is not password protected •

Optional menu structure either tree •

(PROFI) or linear (LIGHT)

SETTING USER

INSTRUMENT SETTING3

NNSTRUCTIONS FOR USE OM 652UC

4.1 Setting

The instrument is set and controlled by five control keys located on the front panel. All programmable settings of the instrument are performed in three adjusting modes:

LIGHT Simple programming menu

- contains solely items necessary for instrument setting and is protected by optional number code PROFI Complete programming menu

- contains complete instrument menu and is protected by optional number code USER User programming menu

- may contain arbitrary items selected from the programming menu (LIGHT/PROFI), which determine the right (see or change)

- acces without password All programmable parameters are stored in the EEPROM memory (they hold even after the instrument is switched off).

Complete instrument operation and setting may be performed via OM Link communication interface, which is a standard equipment of all instruments.

The operation program is freely accessible (www.orbit.merret.cz) and the only requirement is the purchase of OML cable to connect the instrument to PC. It is manufactured in version RS 232 and USB and is compatible with all ORBIT MERRET instruments.

Another option for connection is with the aid of data output RS 232 or RS 485 (without the need of the OML cable).

INSTRUMENT SETTING 3

10 | INSTRUCTIONS FOR USEE OM 652UC

Setting and controlling the instrument is performed by means of 5 control keys located on the front panel. With the aid of these keys it is possble to browse through the operation menu and to select and set required values.

Symbols used in the instructions

Indicates the setting for given type of instrument

DEF

values preset from manufacture

symbol indicates a flashing light (symbol)

MI N

inverted triangle indicates the item that can be placed in USER menu

CONECT.

broken line indicates a dynamic item, i.e. it is displayed only in particular selection/version



after pressing the key the set value will not be stored



after pressing the key the set value will be stored



continues on page 30

Setting the decimal point and the minus sign

DECIMAL POINT

Its selection in the menu, upon modification of the number to be adjusted it is performed by the control key with transition beyond the highest decade, when the decimal point starts flashing . Positioning is performed by / .

THE MINUS SIGN

Setting the minus sign is performed by the key on higher decade. When editing the item substraction must be made from the current number (e.g..: 013 >

, on class 100 > -87)

85.42

1 2

Relay status (red LED)

ON the digit is lit OFF the digit is not lit OFF the digit is ﬂashing limits withrestriction

(hysteresis, delay)

Functions

M Min/max. value T Tare

Measured value

(red/green/orange LED)

(green LED)

4 INSTRUMENT SETTING

NNSTRUCTIONS FOR USE OM 652UC

Control keys functions

Setting items into „USER“ menu

• in LIGHT or PROFI menu

• no items permitted in USER menu from manufacture

• on items marked by inverted triangle

item will not be displayed in USER menu

YES

item will be displayed in USER menu with the option of setting

SHO

item will be solely displayed in USER menu

4INSTRUMENT SETTING

Key Measurement Menu Setting numbers/Selection

access into USER menu exit menu w/o saving

transition to next item w/o saving

tare value return to previous level move to higher decade

cancel Tare move to previous item move down

cancel Tare move to next item move up

Tare conﬁ rm selection setting/selection conﬁ rmation

numeric value is set to zero

access into LIGHT/PROFI menu

direct access into PROFI menu temporary (remains LIGHT)

conﬁ guration of an item for “USER” menu

determine the sequence of items in “USER - LIGHT” menu



---

NO YES SHO

---

return to item

legend is flashing - current setting is displayed

12 | INSTRUCTIONS FOR USEE OM 652UC

5.0 Setting “LIGHT”

LIGHT Simple programming menu

- contains only items necessary for instrument setting and is protected by optional numeral code

For capable users•

Only items necessary for instrument•

setting

Password protected access•

Possibility to arrange items of the •

„User“ menu

Linear menu structure•

SETTING LIGHT

5 SETTING

lightlight

Password “0” Menu LIGHT USR menu off Setting the items

DEF

Preset from manufacture

NNSTRUCTIONS FOR USE OM 652UC

142. 8

PASS.

Access code

FREQ.

MODE

OFFFI L .

5SETTING

lightlight

NPN.C.TYP.A 10LEV . A

10LEV . CNPN. C.TY P. C 1SCAL.

1DI V . 0OFFS.

SET.V.

TY . A. O . MI . A . O. MA. A .O. 1000Er 4

Option - Analog output

L. L.1 25 L. L.2 75

Option - Comparator

COL. 0 . GRn .

Basic color

d . L.1. 333 .3

First color’s limit

COL. 2. RED

Color after ﬁ rst limit

d . L.1. 666 .7

Second color’s limit

COL. 2. ORAn .

Color after second limit

MENU LI G H .

Menu type

IDEN .

Identiﬁ cation

142. 8

Return to previous measuring mode

OM 652. . . .

N. PAS. 0

New password

FI R M .

Return to manufacture setting

YES

000000FORM . A

CLR.M. STO .CONT.M.STA.

Only for Mode > TIME and RTC

Upon delay exceeding 60 s the programming mode is automatically discontinued and the instrument itself restores the measuring mode

14 | INSTRUCTIONS FOR USEE OM 652UC

142. 8

PASS. 0

Entering access password for access into the menu

PASS.

Access into instrument menu

PAS = 0

- access into menu is unrestricted, after releasing keys you automaticaly move to first item of the menu

PAS > 0

- access into menu is protected ny numeric code

Set “PASS.” = 42 Example

0 1 2 02 12

32 SET.V .

SET.V.

Setting initial value

- the function allows the user a single-time setting of initial value of display projection

- the instrument is preset from manufacture into “FREQU.” measuring mode and unless another mode is set the item remains hidden

- if you need to set initial value for another mode it is necessary to do so upon next access to programming menu > after

change of measuring mode

- setting “SET V.” is a one-time operation unlike the “OFFS.” option, i.e. after resetting the display value is “0”, provided there is no other value set in the “OFFS.” item

DEF

= 0

SET.V.

Setting initial value

The setting item „SET.V.“ does not project for measuring mode „FREQ.“

Set “S ET V.” = 233 Example

0 1 2 3 03

23 MODE233133033

5 SETTING

lightlight

NNSTRUCTIONS FOR USE OM 652UC

4. NASTAVENÍ PŘÍSTROJE - UŽIVATELSKÝ MÓD



COUN . FREQ.

MODE

Selection of instrument measuring mode

- elementary selection of instrument type

DEF

= FREQ.

MODE

Menu Instrument mode

COUN. Counter FREQ. Frequencymeter TIME Stopwatch/timer RTC Stopwatch/backup timer

Selection of “COUN.” mode Example

M. STA.FREQ .

MODE

RTCTI M E .

COU N.

M. STA.

Selection of stopwatch/ timer control

- menu for time setting is accessible only in the stopwatch/timer mode

CONT.

Stopwatch/timer is running constantly if the instrument

is turned on

CtCt .

Stopwatch/timer is running upon contact making

EDGE

Stopwatch/timer is controlled by the priming

signal edge

- time is set off by the edge (by the signal passing across the comparing level) and stopped by the next edge

R. ST. C.

Stopwatch/timer is controlled and reset by the

edge of the priming signal

- time is set off by the edge (by the signal passing across the comparing level) and stopped by the next edge

C.R. ST.

Stopwatch/timer is controlled and reset by the

edge of the priming signal

- time is set off by the edge (by the signal passing across the comparing level) and stopped by the next edge

CL. R.

Stopwatch/timer is reset and set off by the edge of

the priming signal

CL. R.R.

Stopwatch/timer is reset

and set off by the edge of the priming signal, the cycle is repeated with every other edge

RUN

Stopwatch/timer is only set

off by the edge

DEF

= COnt.

M. STA.



CONT. CTCt . EDG E R.ST.C.

C.R. ST. CL . R. CL. R.R. RU N

Selection of stopwatch control > EdGE Example

M. STO .CONT. EDG E

Only for measuring mode

TIME • RTC

5SETTING

lightlight

16 | INSTRUCTIONS FOR USEE OM 652UC

OFF 1000 100 40 5



Maximum input frequency 100 Hz > 100 Example

FI L .

Selection of digital filter

- digital filter may suppress unwanted interfering impulses (e.g. relay backswings)

on the input signal. The set parameter gives maximum possible frequency, which the instrument processes w/o limitation

DEF

= OFF

FI L .

TYP. AOFF 1000 100

When accessing upon contact and available maximum input frequency we recommend using filter

M. STO .

Selection of stopwatch resetting

- menu of the resetting option is accessible only in the stopwatch/timer regime

DEF

= CLr.

CLR.

Stopwatch/timer is reset through input „Clear“

ST. C.

Stopwatch/timer is stopped and reset through input

„Clear“

STOP

Stopwatch/timer is stopped through input „Clear“

Selection of type of stopwatch resetting > St. C. Example

CLEAR ST. CLR. FI L .

M. STO .

CLr. ST. C. STOP



Only for measuring mode

TIME • RTC

Only for measuring mode

COUN. • TIME • RTC

5 SETTING

lightlight

NNSTRUCTIONS FOR USE OM 652UC

Setting input level

LEV . A

Setting input level for Input A

- setting applies for Input A

- setting level (only for type PNP) of the input voltage, the instrument subsequently automatically selects divider and thus the comparing levels

- range of setting 0…43 V (Input < 30 V)

- range of setting 43…300 V (Input < 300 V)

- table of comparing levels is on page 7

Setting the level = 34 V Example

10 11 12 13 14

24 TYP .C

LEV . A



NPN.C. PN P

TYP.A

Selection of type of input

- setting applies for Input A

DEF

= NPN.C.

TYPE

Menu Type of input

NPN.C NPN or contact PNP PNP

Selection of type of input > NPN Example

LEV .ANPN.C.

TYP.A

Po této volbě je nutné nastavit vstupní úrovně (Level A)

5SETTING

lightlight

18 | INSTRUCTIONS FOR USEE OM 652UC



NPN.C PNP

TYP.C

Selection of type of input

- setting applies for resetting input

DEF

= NPN.C.

TYPE

Menu Type of input

NPN.C NPN or contact PNP PNP

Selection of type of input > NPN Example

LEV .CNPN.C.

TYP.C

Setting input level

LEV . C

Setting input level for resetting input

- setting the level (only for PNP type) of input voltage, the instrument subsequently automatically selects divider and thus the comparing levels

- range of setting 0…43 V (Input < 30 V)

- range of setting 43…300 V (Input < 300 V)

- table of comparing levels is on page 7

Setting levels = 34 V Example

10 11 12 13 14

24 SCAL .

LEV . C

5 SETTING

lightlight

Input levels (Level C) have to be set after this option

NNSTRUCTIONS FOR USE OM 652UC

Setting division constant

DI V .

Setting division constant

- calibration constant is for calculation of the input value to required display value

- range: -0,001...9999

DEF

= 1

Division consta nt = 22 Example

1 2 02 12 22 OFFS.

DI V .

Setting multiplyingconstant

SCAL.

Setting multiplying constant

- calibration constant serves for calculation of the input value to required display value

- by entering minus value direction of the calculation is changed, i.e. we count down

- range: -0,001...9999

DEF

= 1

Cali bration consta nt = 3,12 Example

1 2 02 12 012 112

212

DI V .

312 31 2 .

0312

31 . 2 3 .12

SCAL.

5SETTING

lightlight

20 | INSTRUCTIONS FOR USEE OM 652UC

Setting PRESET

OFFS.

Setting additive constant

- PRESET

- offset of the measuring by a set value, which shall be loaded always upon instrument resetting

- range: -99999...999999

(+ time formats)

DEF

= 0

Setting „PRESE T“ = 24 Example

0 1 2 3 4

14 FOR.A

OFFS.

FOR. A

Selection of projection format

- instrument enables classical projection of number with fixed position of decimal point as well as projection with floating allowing fo projection of number in its most precise form „FL. P.“

- for measuring modes „TIME“ and „RTC“ special time formats are preset

DEF

= 0000

DEF

= HH.MM

FOR. A

0000 000. o 00 . oo 0. ooo FL. P.



Projection of DP on display > 000.o Example

L. L. 1

* subsequent menu item depends on instrument equipment

0000 000. o

F C

99. MM MM .SS 99.SSHH. MM

5 SETTING

lightlight

NNSTRUCTIONS FOR USE OM 652UC

5SETTING

lightlight

22 | INSTRUCTIONS FOR USEE OM 652UC



L. L. 2

L. L.1

Setting the boundary for limit 1

- range of the setting is -999…9999 (+ time formats)

- presetting “Hysteresis”=0 “Delay”=0

- contingent change of hysteresis or offset of the switch-on may be performed in the PROFI menu

DEF

= 25

Setting the boundary for limit 1

L. L. 2

Setting the boundary for limit 2

- range of the setting is -999…9999 (+ time formats)

- presetting “Hysteresis”=0 “Delay”=0

- contingent change of hysteresis or offset of the switch-on may be performed in the PROFI menu

DEF

= 75

Setting the boundary for limit 2

Setting limit 2 > L 2 = 230 Example

100 100 130 130 120 110

230 MENU

* following item of the menu depends on instrument equipment, provided it has an analog output the following item is „Type“

Setting limit 1 > L 1 = 30 Example

25 26 20 29 28 27

20 30 L. L. 2

Items for “Limits” and “Analog output” are accessible only if the instrument contains them.

Only with option > Dual Comparator

5 SETTING

lightlight

NNSTRUCTIONS FOR USE OM 652UC

MA. A .O.

Assigning the display value to the end of the

AO range

- range of the setting is -999…9999

DEF

= 100

MI . A . O.

Assigning the display value to the beginning of

the AO range

- range of the setting is -999…9999

DEF

= 0

TY . A. O .

Setting the type of analog output

Menu Range Description

0-20 0…20 mA Er 4 4…20 mA with indication of error statement (<3,6 mA) 4-20 4…20 mA i0-5 0…5 mA u0-2 0…2 V u0-5 0…5 V 0-10 0…10 V

DEF

= E 4

Display value for the beginning of the AO range > MI. A.O. = 0 Example



MA. A .O.

TY .A. O.

Type of analog outpu - 0...10 V > TY. A.O.= U -10 Example

4-20 u0-2i0-5 0-10 u0 -5 MI . A . O.

0-20 ER 4 4-20 i0-5 u0-2 u0-5 0-10

Assigning the display value to the beginning of the AO range

0 MA. A . O.

100

Assigning the display value to the end of the AO range

MI . A . O.

Display value for the beginning of the AO range > MA . A.O. = 120 Example

100 100 120 110 CO L.0

Only with option > Analog output

5SETTING

lightlight

24 | INSTRUCTIONS FOR USEE OM 652UC



333 .3

Setting limit for change of display color

d . L.1.

Setting first value for change of display color

- range of setting is -999…9999 (+ time formats)

DEF

= 333.3

d . L.1.

RED . GRN. ORAN.

COL. 0 .



COL. 0 .

Selection of display color > primary setting

DEF

= green

Selection of display color - prim ary > red Example

d . L.1.GRN. RED .

RED . GRN. ORAn .

COL.1.



COL.1.

Selection of display color > after crossing d.L. 1.

- selection of display color is controlled through setting under d.L.1.

- color changes if the value on display exceeds the value set in d.L.1.

DEF

= orange

Selection of display color if the value is > d.L.1 > green Example

d . L.2.ORAN. GRN.

Display value for 1st color change > 100 Example

COL .1 .

333 .3

0 100 000 00

5 SETTING

lightlight

NNSTRUCTIONS FOR USE OM 652UC



666.7

Setting limit for change of display color

d . L. 2.

Setting second value for change of display color

- range of setting is -999…9999 (+ time formats)

DEF

= 666.7

d . L. 2.

RED . GRN. ORAN.

COL. 2.



COL. 2.

Selection of display color > after crossing d.L. 2.

- selection of display color is controlled through setting under item d.L.2.

- color changes if the value on display exceeds the value set in d.L.2.

DEF

= red

Selection of display color if the value is > COL.2 > orange Example

MENURED ORAn .

Display value is for 1st color c hange > 400 Example

666.7

0 000 0 0

COL .2.

200 300 400

5SETTING

lightlight

26 | INSTRUCTIONS FOR USEE OM 652UC

Menu LIGHT > MENU = LIGH. Example



FI R M .

Restoration of the instrument manufacture

setting

- in case of incorrect setting or calibration it

is possible to return to manufacture setting. Prior execution of the changes you will be asked to confirm your selection (YES)

- reading the manufacture calibration and original setting of items in the menu

Setting the menu type LIGHT/PROFI

LIGH. > LIGHT menu, a simple menu,

which contains only items necessary for instrument setting

> linear structure of the menu

PROF. > PROFI menu, a complete menu for

entire instrument setting

> tree structure of the menu

DEF

= LIGH.

LIGH . FI R M .

LI G H . PROF.

FI R M .

Restoration of manufacture setting > FIRM. Example

FI RM . n . PAS.

YES

Do not perform restoration of user setting (USER) prior to its saving in Profi menu

5 SETTING

lightlight

NNSTRUCTIONS FOR USE OM 652UC



Setting new access password

n . PAS .

Setting new access password

- access password for LIGHT/PROFI menu

- range of the numeral code 0…9999

- when setting password to “0000” the

access into LIGHT/PROFI menu is accessible without call for entering it

- in case of loss of password universal password “8177” may be used

DEF

= 0

IDEN .

SW version of the instrument

- the display shows the type identification of the instrument, SW number, SW version and current input setting (Mode)

- if the SW version reads a letter on the first position, then it is a customer SW

- after the identification is completed the menu automatically quits the display and measuring mode is restored

YES

OM 652 61 - 001 FREQ .

142. 8

Return to measuring mode

New password - 341 > n.PAS. = 341 Example

IDEN .

1 01 11 21 31

41 041 341 241 141

5SETTING

lightlight

setting the input typeSW number SW versionInstrument type

28 | INSTRUCTIONS FOR USEE OM 652UC

6 SETTING

proﬁ proﬁ

6.0 Setting “PROFI”

PROFI Complete programming menu

• contains complete instrument menu and is protected by optional number code

• designed for expert users

• preset from manufacture is menu LIGHT

Switching over to “PROFI” menu

• temporary switch-over to PROFI menu, which is suitable to edit a few items

• after quitting PROFI menu the instrument automatically switches to LIGHT menu

• access is password protected (if it was not set under item N. PAS. =0)

+ • access into LIGHT menu and transition to item „MNU“ with subsequent selection of „PROFI“

and confirmation

• after re-entering the menu the PROFI type is active

• access is password protected (if it was not set under item N. PAS. =0)

For expert users•

Complete instrument menu•

Access is password protected•

Possibility to arrange items of the •

„User“ menu

Tree menu structure•

SETTING PROFI

NNSTRUCTIONS FOR USE OM 652UC

6SETTING

proﬁ proﬁ

30 | INSTRUCTIONS FOR USEE OM 652UC

6.1 Setting “PROFI” - INPUT

6.1.1 Resetting internal values

INP.

SERV.

OUT.

CHAN .

CLR.

E. IN.

CONF.

KEYS

The basic instrument parameters are set in this menu

CLR.

Resetting internal values

CONF.

Primary instrument setting

E. IN.

Setting the external input function

KEYS

Setting the ENTER key function

INP.

SERV.

OUT.

CHAN .

CLR.

E. IN.

CONF.

KEYS

C. TA .

CL. C.

CLR.

Resetting internal values

CL. C.

Counter resetting

C. TA .

Tare resetting

6 SETTING

proﬁ proﬁ

NNSTRUCTIONS FOR USE OM 652UC

6.1.2 Instrument configurtion

6.1.2a Setting the initial value

M. TI M .

MODE

INP.

SER.

OUT.

CHAN .

E. IN.

CONF.

KEYS

M. STA.

M. STO .

TYP.A.

FI L .

LEV . C

TYP.C.

LEV . A

POL.

BACK.

SET.V.CLR.

CONF.

Primary instrument setting

SET. V.

Setting the initial value

MODE

Setting the instrument measuring mode

M. TI M .

Setting the time base

M. STA.

Setting the stopwatch control

M. STO .

Setting stopwatch resetting

FI L .

Setting the input filtration constant

TYP. -

Setting the type of input

LEV . .-

Setting the input level

POL.

Selection of active level/ edge

BACK.

Setting data backup/ time dat/času

INP.

SER.

OUT.

CHAN .

CLR.

E. IN.

CONF.

SET.V.

KEYS

M. TI M .

MODE

M. STO.

M. STA.

TYP.A

FI L .

LEV . C

TYP.C

LEV . A

POL.

BACK.

SET.V.

Setting initial value

- function allows the user a one-time setting of the display initial value

6SETTING

proﬁ proﬁ

32 | INSTRUCTIONS FOR USEE OM 652UC

6 SETTING

proﬁ proﬁ

142. 8

PASS. 0

INP. CHA N.

M. TI M .

CLR.

CL. C.  C. TA...

CONF.

MODE

COUN.  FREQ.  TIME  RTC

0.5  1.0  5.0  10.0

LEV .A

TYP.A

NPN.C.  PNP

FI L .

OFF  1000  100  40  5

LEV .C

TYP.C

NPN.C.  PNP

POL.

Lo \  HI /

E. IN. EX . 1

OFF  LO. k.  HOLD  TARE  CLR.  CLr.S..

KEYS ALL

NO  YES

BACK.

YES  NO

Programming schem

SET. A SCAL. 1

FOR.A

0000  000.o  00.oo  0.ooo  FL

FI L . M. F. A.

C. F.A 0

NO  EXP..  ROUN..

DI V . 1

OFFS. 0

HH.MM  99.MM  MM.SS  99.SS

SET.V.

M. STA.

CONT  CTCT.  EDGE  r.St.C.  C.r.ST.  rUN

M. STO.

CLR.  ST. C.  STOP

BACK.

NO  VAL.  TIME

CH . A.

NNSTRUCTIONS FOR USE OM 652UC

6SETTING

proﬁ proﬁ

IDEN . OM 652UC. . . .

SERv .

OUT.

LI M S . L. 1 .

DI S P.

REST .

SAVE

LIGH.  PROF.

100MA. A .O .

0MI . A .O .

A. OUT. TY . A.O .

0-20  Er 4  4-20  i0-5  u0-2  u0-5  0-10

ADR. 0

DATA BAUD

0.3  0.6  1.2  2.4  4.8  9.6  19.2  38.4  57.6 115.2  230.4

T. L.1 0

H. L.1 0

L. L.1 25

L. 2.

T. L. 2 0

H. L. 2 0

L. L.2 75

TY. L. 2

CLOSE  OPEn

USER

FI R M .

MO. L.1

HYST.  C.PLS.

TY.L.1

CLOS.  OPEN

Upon delay exceeding 60 s the programming mode is automatically discontinued and the instrument itself restores the measuring mode

BRIN .

25%  50%  75% 100%

COL . 0.

RED  GRN.  ORAn.

d . L.1.

COL .1.

d . L.2.

COL . 2.

RED  GRN..  ORAn.

RED.  GRN..  ORAn.

600

333 .3

0N. PA S.

. P.

MO. L.2

HYST.  RUN

34 | INSTRUCTIONS FOR USEE OM 652UC

6 SETTING

proﬁ proﬁ

6.1.2b Selection of measuring mode

6.1.2c Selection of measuring period/time base

CLR.INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

COUN .

FREQ.

KEYS

RTC

TI M E

DEF

M. STA.

M. STO.

M. TI M .

MODE

TYP.A

LEV . C

TYP.C

LEV . A

FI L .

BACK.

POL.

SET. v .

MODE

Selection of instrument measuring mode

COUN .

Mode „Counter“

- counts on input A

FREQ.

Mode „Frequencymeter“

- measures frequency on input A

TI M E

Mode „Stopwatch/ timer“

RTC

Mode „Stopwatch/ timer“ with RTC backup

- not in standard equipment

DEF

0.5

5. 0

1. 0

10. 0

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

M.TIM.

MODE

M. STA.

M. STO.

TYP.A

LEV . C

TYP.C

LEV . A

FI L .

BACK.

POL.

SET. v .CLR.

M. TI M .

Selection of measuring period/time base

- if you set measuring period e.g. for 1 s, the measuring runs approximtely from 1 s to 2 s (1 s + maximum one cycle of measured signal). If no signal arrives within 2 s it is taken that the signal has zero frequency

- range of setting of the time base is 0,5 s to 10 s

- in the „RTC“ regime with data projection the set time defines the cycle of switching between time/date, min. is 5 s, datue is displayed for approx. 2,5 s

NNSTRUCTIONS FOR USE OM 652UC

6SETTING

proﬁ proﬁ

Při vstupu na kontakt a známém maximálním vstupním kmitočtu doporučujeme filtr použít

6.1.2d Selection of stopwatch/timer control

CLR.

RUN

CL. R.R.

CL. R.

MODE

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

TYP.A

LEV . C

TYP.C

LEV . A

FI L .

BACK.

POL.

SET. V.

M. STA.

M. STO.

DEF

CONT.

CtCT.

EDGE

R.ST.C.

C.R. ST.

M. TI M .

M. STA.

Selection of stopwatch/ timer control

- time setting menu is accessible only in the stopwatch/timer regime

CONT.

Stopwatch/timer is running constantly if the

instrument is turned on

CT. Ct .

Stopwatch/timer is running upon contact

making

EDGE

Stopwatch/timer is controlled by the priming

signal edge

- time is set off by the edge (by the signal passing across the comparing level) and stopped by the next edge

R.ST.C.

Stopwatch/timer is controlled and reset by

the edge of the priming signal

- time is set off by the edge (by the signal passing across the comparing level) and stopped by the next edge

C.R. ST.

Stopwatch/timer is controlled and reset by

the edge of the priming signal

- time is set off by the edge (by the signal passing across the comparing level) and stopped by the next edge

CL. R.

Stopwatch/timer is reset and set off by the edge

of the priming signal

CL. R.R.

Stopwatch/timer is

reset and set off by the edge of the priming signal, the cycle is repeated with every other edge

RUN

Stopwatch/timer is only

set off by the edge

36 | INSTRUCTIONS FOR USEE OM 652UC

6 SETTING

proﬁ proﬁ

6.1.2e Selection of stopwatch/timer resetting

6.1.2f Selection of input filter parameters

MODE

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

TYP.A

LEV . C

TYP.C

LEV . A

FI L .

BACK.

POL.

SET. V.

M. STA.

M. STO.

M. TI M .

DEF

CLR.

ST. C.

STOP

CLR.

M. STO .

Selection of stopwatch resetting

- menu of the resetting option is accessible only in the stopwatch/timer regime

CLR.

Stopwatch/timer is reset through input „Clear“

ST. C.

Stopwatch/timer is stopped and reset

through input „Clear“

STOP

Stopwatch/timer is stopped through input

„Clear“

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

DEF

OFF

1000

100

MODE

TYP.A

LEV . C

TYP.C

LEV . A

M. STO .

BACK.

POL.

M. STA.

FI L .

M. TI M .

SET. v .CLR.

FI L .

Selection of digital input filter

- digital filter may suppress unwanted interfering impulses (e.g. relay backswings) on the input signal. The set parameter gives maximum possible frequency (Hz) of the instrument, which the instrument w/o limitation

When accessing upon contact and available maximum input frequency we recommend using filter

NNSTRUCTIONS FOR USE OM 652UC

6.1.2g Selection of the type of input

6.1.2h Setting input level

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

DEF

NPN.C.

PNPMODE

LEV . C

TYP.C

LEV . A

M. STO .

BACK.

POL.

M. STA.

M. TI M .

FI L .

TYP.A

SET. v .CLR.

TYP.A

Selection of type of input

- setting applies for Input A

NPN.C.

Type of input NPN and upon contact

PNP

Type of input PNP

Input levels (Level A) must be set after this selection

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

MODE

LEV . C

TYP.C

M. STO .

BACK.

POL.

M. STA.

M. TI M .

FI L .

TYP.A

LEV . A

SET. v .CLR.

LEV . A

Setting input level

- setting applies for Input A

- setting level (only for type PNP) of the input voltage, the instrument subsequently automatically selects divider and thus comparing levels

- range of setting 0…43 V

(Input A < 30 V, bracket No. 13) (Input C < 30 V, bracket No. 14)

- range of setting 43…300 V

(Input A <300 V, bracket No. 18) (Input C <300 V, bracket No. 16)

- table of comparing levels is on page 7

6SETTING

proﬁ proﬁ

Setting for input Resetting (type C) is identical with setting for Input A

38 | INSTRUCTIONS FOR USEE OM 652UC

6.1.2i Selection of active level or edge

6.1.2j Selection of display status backup

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

DEF

Lo \

Hi /MODE

TYP.C

M. STO .

LEV . C

M. STA.

M. TI M .

FI L .

TYP.A

BACK.

POL.

LEV . A

SET. v .CLR.

POL.

Selection of active level or edge

Lo \

Active upon change of declining edge Lo >Hi

- upon entering the contact > active on switch-on

Hi /

Active upon change of entering edge Hi > Lo

- upon entering the contact > active on switch-off

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

DEF

YESMODE

M. TI M .

TYP.C

LEV . C

FI L .

TYP.A

POL.

BACK.

LEV . A

SET. V.CLR.

BACK.

Selection of display status backup

- setting display value restoration after power failure or instrument switch-off

After switch-on the instrument loads the

display status from the memory

YES

Instrument resets itself after switch-on

6 SETTING

proﬁ proﬁ

NNSTRUCTIONS FOR USE OM 652UC

6.1.2k Setting the display status backup

6.1.3 External input function selection

INP.

SER.

OUT. .

CHAN .

E. IN.

CONF.

KEYS

TI M E

VAL.

DEF

MODE

TYP.C

M. STO .

LEV . C

M. STA.

M. TI M .

FI L .

TYP.A

POL.

BACK.

LEV . A

SET. V.CLR.

BACK.

Selection of display status backup

- time setting menu is accessible only in the stopwatch/timer regime

- setting display value restoration after power failure or instrument switch-off

Instrument resets itself after every switch-on

VALUE

After switch-on the instrument loads the

display status from the memory

TI M E

Instrument downloads „running“ time from RTC

- item accessible only with extension „Time backup“

INP.

SERV.

OUT.

CHAN .

CLR.

CONF.

KEYS

OFF

LO . k .

DEF

HOLD

E. IN.

EX. 1

TARE

CLR. S.

CLR.

E. IN.

External input function selection

OFF

Input is off

LO . K.

Auxiliary input governs the „LOCK“ function

- the input governs the blocking of control keys on front panel

HOLD

Auxiliary input governs the „HOLD“ function

- the input governs the HOLD function, which blocks all instrument functions

TARE

Auxiliary input governs the „TARE“ function

- the TARE function is activated through the input, only in the “Frequency” mode

CLr.

Auxiliary input governs the „Clear“ function

- stopwatch/counter is cleared (preset) through the input

CLR. S.

Auxiliary input governs the „Clear“ function

- stopwatch/counter is cleared (preset) through the input, Stopwatcg stops altogether

6SETTING

proﬁ proﬁ

40 | INSTRUCTIONS FOR USEE OM 652UC

6.1.4 Optional accessory functions of the keys

INP.

SERV.

OUT.

CHAN .

CLR.

E. IN.

CONF.

YES

DEF

KEYS

ALL

Assigning accessory functions of control keys

- owing to limited space in the instrument’s memory it is not feasible to set the keys’ functions one by one

YES

Accessory functions are on

Counter Frequency Stopwatch

- Resetting tare Resetting

- Resetting tare Display hold

- Tare projection Start

Resetting Tare Stop

Accessory functions are off

6 SETTING

proﬁ proﬁ

Control keys functions are described on page 11

NNSTRUCTIONS FOR USE OM 652UC

6SETTING

proﬁ proﬁ

42 | INSTRUCTIONS FOR USEE OM 652UC

6.2 Setting “PROFI” - CHANNEL

6.2.1a Setting multiplying constant

6.2.1b Setting division constant

INP.

SERV.

OUT.

CHAN .

SET.A

FOR.A

FIL.

CH . A

In this menu the instrument input parameters are set

SET. A

Setting calibration constant

FI L .

Setting the digital filters

FOR.A

Selection of projection format

INP.

SERV.

OUT.

CHAN .

SET. A

FOR.A

FIL.

CH . A

OFFS.

SCAL.

DI V .

SCAL.

Setting multiplying constant

- multiplying constant serves for calculation of input value to required display value

- by entering minus value the direction of calculation is changed, i.e. we count down

- range: -0,001...9999

DEF

= 1

INP.

SERV.

OUT.

CHAN .

SET. A

FOR.A

FIL.

CH . A

OFFS.

DI V .

SCAL. 1

DI V .

Setting division constant

- division constant serves for calculation of input value to required display value

- range: 0,001...9999

DEF

= 1

6 SETTING

proﬁ proﬁ

If non-zero value is set in the “TIME” or “RTC” mode in the “OFFS.” item, it applies that the multiplying constant “SCAL.” is negative

NNSTRUCTIONS FOR USE OM 652UC

6.2.1c Setting additive constant - PRESET

6.2.2 Setting the digital filters

FOR.A

SCAL.INP.

SERV.

OUT.

CHAN .

SET. A

FIL.

CH . A

OFFS.

DIV.

OFFS.

Setting PRESET constant

- offset of the measuring by a set value, which shall be loaded always upon instrument resetting

- range: -999...9999

DEF

= 0

M. F. AINP.

SERV.

OUT.

CHAN .

SET. A

FOR.A

FIL.

CH . A NO

EXP.

ROUn.

C. FA .

M. F. A

Setting the digital filters

C. FA

Setting the constant

- this menu item is always displayed after selection of a particular type of filter

DEF

= 2

OFF

Filters are switched off

EXP.

Selection of exponential filter

- calculation of value from the number of measurements selected in „C. FA.“

ROUN .

Selection of value round-up

- it is set by …arbitrary number, which determines the projection step (e.g.: “C. FA.”=2,5 > display 0, 2.5, 5,...)

6SETTING

proﬁ proﬁ

If non-zero value is set in the “TIME” or “RTC” mode in the “OFFS.” item, it applies that the multiplying constant “SCAL.” is negative

44 | INSTRUCTIONS FOR USEE OM 652UC

6 SETTING

proﬁ proﬁ

6.2.3 Selection of projection format

FOR.A

DEF

0000

000. 0

00. 00

0. 000

FL. P.

HH. MM

99. SS

MM.SS

99. MM

DEF

INP.

SERV.

OUT.

CHAN .

SET.A

FIL.

CH . A

FOR.A

Selection of projection format

- the instrument enables projection of number with decade positioning of decimal point

- for projection of time there are also other projection forms available

In mode “TIME” or “RTC” the time base is preset according to projection format:

in seconds > 0000…0.000, Fl.P., HH.MM, 99.MM

in minutes > HH.MM

in hundredths of seconds > MM.SS, 99.SS

NNSTRUCTIONS FOR USE OM 652UC

6SETTING

proﬁ proﬁ

46 | INSTRUCTIONS FOR USEE OM 652UC

6.3 Setting „PROFI“ - OUTPUTS

6.3.1a Selection of mode of output L 1

6.3.1b Selection of mode of output L 2

CHAN .

SERV.

OUT..

LI M S .

A. OUT.

DATA

DI S P .

INP.

It is possible to set the parameters of the instrument output signals in this menu

LI M S .

Setting the type and the switching of limits

DATA

Setting the type and the parameters ot data

output

A. OUT.

Setting the type and parameters of analog

output

DI S P .

Setting the display

INP.

SERV.

OUT.

CHAN .

LIMS.

A. OUT.

DATA

DI S P .

L. 1

L. 2

HYST.

C.PLS.

DEF

H. L.1

L. L.1

T. L.1

MO. L.1

TY . L.1

MO. L.1

Mode of limit 1

HYST.

Standard mode - limit, hysteresis and delay

C.PLS.

Automatic clearing of counter to preset value

Setting is available only for LIM 1

INP.

SERV.

OUT.

CHAN .

LIMS.

A. OUT.

DATA

DI S P .

L. 2

L. 1 HYST.

RUN

DEF

H. L.2

L. L.2

T. L.2

MO. L.2

TY . L.2

MO. L. 2

Mode of limit 2

HYST.

Standard mode - limit, hysteresis and delay

RUN

Relay is switched on/ off if the stopwatch is

running

Setting is available only for LIM 2

6 SETTING

proﬁ proﬁ

NNSTRUCTIONS FOR USE OM 652UC

6.3.1c Selectionof type of output

6.3.1d Setting values for limits evaluation

INP.

SERV.

OUT.

CHAN .

LIMS.

A. OUT.

DATA

DI S P .

L. 1

L. 2

CLOS.

OPEN

DEF

TY. L.1

H. L.1

L. L.1

T. L.1

MO. L.1

TY . L.1

Setting the type of relay function

CLOS.

Relay switches on when the condition is met

OPEN

Relay switches off when the condition is met

Setting is identical for LIM 1 and LIM 2

INP.

SERV.

OUT.

CHAN .

LIMS.

A. OUT.

DATA

DI S P .

L. 1

L. 2

H. L.1

L. L.1

T. L.1

MO. L.1

TY .L.1

L. L.1

Setting the boundary for relay switch-on

- within the full display range

DEF

= 25 (L 1), 75 (L 2)

H. L1

Setting hysteresis

- defines the band around the limit (on both sides, LIM. ±1/2 HYS.)

- within the full display range

DEF

= 0

T. L1

Setting the offset of the relay switch-on

- within the range 0…99,9 s

DEF

= 0

Setting is identical for LIM 1 and LIM 2

6SETTING

proﬁ proﬁ

48 | INSTRUCTIONS FOR USEE OM 652UC

6.3.2a Selection of transmission rate of data output

6.3.2b Setting the instrument address

CHAN .

SERV.

OUT..

LI M S .

A. OUT.

DATA

DI S P .

INP.

ADr.

BAUD 600

1200

2400

4800

9600

19200

38400

5760 0

11 5 2 0 0

DEF

2304 0 0

600

BAUD

Setting the data output rate

0.3

Rate - 300 Baud

0. 6

Rate - 600 Baud

1. 2

Rate - 1 200 Baud

2.4

Rate - 2 400 Baud

4. 8

Rate - 4 800 Baud

9. 6

Rate - 9 600 Baud

19. 2

Rate - 19 200 Baud

38.4

Rate - 38 400 Baud

57 . 6

Rate - 57 600 Baud

11 5 . 2

Rate - 115 200 Baud

230 .4

Rate - 230 400 Baud

CHAN .

SERV.

OUT..

LI M S .

A. OUT.

DATA

DI S P .

INP.

ADr.

BAUD 0

Adr.

Setting the instrument address

- setting within the range 0…31

DEF

= 00

6 SETTING

proﬁ proﬁ

NNSTRUCTIONS FOR USE OM 652UC

6.3.3a Selection of type of analog output

6.3.3b Selection of analog output range

DI S P .

CHAN .

SERV.

OUT..

LI M S .

A. OUT.

DATA

INP. TY . A .O.

MI . A . O.

MA. A .O.

0-20

4-20

i0-5

Er 4

DEF

u0-5

u0-2

0-10

TY . A. O .

Setting the type of analog output

0-20

Typ - 0…20 mA

Er 4

Typ - 4…20 mA

- with indication of error statement (<3,6 mA)

4-20

Typ - 4…20 mA

i0-5

Typ - 0…5 mA

u0-2

Typ - 0…2 V

u0-5

Typ - 0…5 V

0-10

Typ - 0…10 V

DI S P .

CHAN .

SERV.

OUT..

LI M S .

A. OUT.

DATA

INP. TY . A .O.

MI . A . O.

MA. A .O.

A. OUT.

Setting the analog output range

- analog output is isolated and its value corresponds with the displayed data. It is fully programmable, i.e. it allows to assign the AO limit points to any two arbitrary points of the entire measuring range

MI . A . O.

Assigning the displayed value to the beginning of

the analog output range

- range of the setting is -999…9999

DEF

= 0

MA. A .O.

Assigning the displayed value to the end of the

analog output range

- range of the setting is -999…9999

DEF

= 100

6SETTING

proﬁ proﬁ

50 | INSTRUCTIONS FOR USEE OM 652UC

6.3.4a Selection of display color

6.3.4b Selection of display color change

CHAN .

SERV.

OUT..

INP. RED

ORAN.

GRN.

LI M S .

A. OUT.

DATA

DI S P .

COL. 0

D. L.1

D. L. 2

BRIG.

COL.1

COL. 2

COL. -

Selection of display color

- color selection is controlled through setting under items “d.L.1.” and “d.L.2.”

RED

Red color

GRN.

Green color

ORAn .

Orange color

- “COL. 0.”

DEF

= Green

- “COL. 1.”

DEF

= Orange

- “COL. 2.”

DEF

= Red

333 .3

CHAN .

SERV.

OUT.

INP. LI M S .

A. OUT.

DATA

DI S P .

COL. 0

COL. 2

BRIG.

D. L.1

D. L. 2

COL.1

d . L. -

Selection of display color change

- under items “d.L. 1” and “d.L.2” is set the limit when display color shall change

- “d.L.1.”

DEF

= 333,3

- “d.L.2.”

DEF

= 666,6

6 SETTING

proﬁ proﬁ

NNSTRUCTIONS FOR USE OM 652UC

6.3.4c Selection of display brightness

CHAN .

SERV.

OUT.

INP. .

COL.1

D. L.1

D. L. 2

COL. 2

COL. 0LI M S .

A. OUT.

DATA

DI S P .

BRIG.

100%

50%

25%

75%

DEF

BRIG.

Setting the display brightness

- by selecting the display brightness we may react properly to light conditions in place of location of the instrument

25%

Display brightness - 25 %

50%

Display brightness - 50 %

75%

Display brightness - 75 %

100%

Display brightness - 100 %

6SETTING

proﬁ proﬁ

52 | INSTRUCTIONS FOR USEE OM 652UC

6.4 Setting “PROFI” - SERVICE

6.4.1 Selection of the type of programming menu

CHAN .

SERV.

OUT.

MENUINP.

N. PAS.

REST .

IDEN .

The instrument‘s service functions are set in this menu

Selection of menu type LIGHT/PROFI

REST .

Restoration of the manufacture setting and

instrument calibration

N. PAS.

Setting new access password

IDEN .

Instrument identification

CHAN .

SERV.

OUT.

REST .

INP.

N. PAS.

LI G H .

PROF.

DEF

IDEN .

Selection of menu type LiGHT/PROFI

- allows to set the menu complexity as per user needs and abilities

LI G H .

Active LIGHT menu

- simple programming menu, contains only items necessary for instrument configuraction and setting

- linear menu structure > items in succession

PROF.

Active PROFI menu

- complete programming menu for expert users

- tree menu

6 SETTING

proﬁ proﬁ

Change of setting is valid with next access into menu

NNSTRUCTIONS FOR USE OM 652UC

6.4.2 Restoration of the manufacture setting

6.4.3 Setting new access password

6.4.4 Instrument identification

CHAN .

SERV.

OUT.

REST.

INP.

N. PAS.

FI R M .

IDEN .

SAV E

USER

REST .

Restoration of the instrument manufacture

setting

FI R M .

Return to manufacture setting of the instrument

- downloading manufacture setting for currently selected type of instrument (items described DEF)

USER

Return to user setting of the instrument

- downloading user setting of the instrument, i.e. setting which was stored under item SERV./REST./SAVE

SAV E

Storing user setting of the instrument

- storing the setting enables the operator its future contingent restoration

CHAN .

SERV.

OUT.

REST .

N. PAS.

INP.

IDEN .

N. PAS.

Setting new password for access into the LIGHT

and PROFI menu

- this option allows to change the numeral code, which protects the access into the LIGHT and PROFI Menu.

- numeral code range is 0…9999

- universal password in case of loss „8177“

CHAN .

SERV.

OUT.

REST .

N. PAS.

INP.

IDEN.

IDEN .

Projection of instrument SW version

- the display shows the type identification of the instrument, SW number, SW version and current input setting (Mode)

- if the SW version reads a letter on the first position, then it is a customer SW

6SETTING

proﬁ proﬁ

After restoration of setting the instrument switches off for several seconds

54 | INSTRUCTIONS FOR USEE OM 652UC

7.0 “USER” menu configuration

• USER menu is designed for users who need to change only several items of the setting without the option to change the basic instrument setting (e.g. repeated change of limit setting)

• there are no default items from manufacture in USER menu

• menu configuration possible on items indicated by inverse triangle

L.1

• setting may be performed in LIGHT or PROFI menu, with the USER menu then overtaking the given menu structure

SETTING

item will not be displayed in USER menu

YES

item will be displayed in USER menu with the chance of editing

SHO

item will be solely displayed in USER menu

For user operation•

Menu items are set by the user •

(Profi/Light) as per request

Access is not password protected •

SETTING USER

7 SETTING

useruser



---

NO YES SHO

---

return to item

flashing sign - current setting is displayed

NNSTRUCTIONS FOR USE OM 652UC

Setting sequence of items in “USER” menu

In compiling USER menu from active LIGHT menu the items (max. 10) may be assigned a sequence, in which they will be projected in the menu

Example:

Into USER menu were selected these items: (keys

) > CL. TA., L 1, L 2, for which we have preset this sequence:

(tlačítky

CL. TA. 5 L 1 0 (sequence not determined) L 2 1

Upon entering USER menu (key

) items will be projected in the following sequence: L 2 > CL. TA. > L 1

7SETTING

useruser

---

setting projection sequence

56 | INSTRUCTIONS FOR USEE OM 652UC

The instruments communicate via serial line RS232 or RS485. For communication they use the ASCII protocol. Communication runs in the following format:

ASCII: 8 bit, no parity, one stop bit

The transfer rate is adjustable in the instrument menu and depends on the control processor used. The instrument address is set in the instrument menu in the range of 0 ÷ 31. The manufacture setting always presets the ASCII protocol, rate of 9600 Baud, address 00. The type of line used - RS232 / RS485 - is determined by an exchangeable card automatically identified by the instrument.

COMMANDS FOR INSTRUMENT OPERATION

The commands are described in specification you can find at www.orbit.merret.cz/rs. A command consists of a number and a letter. The size of the letters have a significance.

DETAILED DESCRIPTION OF COMMUNICATION VIA SERIAL LINE

Activity Data transferred

Data solicitation (PC) # A A <CR>

Data transfer (Instrument) > R <SP> D D D D D (D) (D) <CR>

Command corﬁ rmation (Instrument) - OK ! A A <CR>

Command corﬁ rmation (Instrument) - Bad ? A A <CR>

Instrument identiﬁ cation # A A 1Y <CR>

HW identiﬁ cation # A A 1Z <CR>

One-time mesasurement # A A 7X <CR>

Repeated mesasurement # A A 8X <CR>

Setting to transmit display + relay value

# A A 1X <CR>

Setting to transmit measured value

# A A 1x <CR>

Setting limit1

# A A 1L D (D) (D) (D) (D) (D) <CR>

Setting limit 2

# A A 2L D (D) (D) (D) (D) (D) <CR>

LEGENDA

#3523HBeginning of the command

A A 0…31

Two signs of the inst. address (sending in ASCII - decades and

units, ex. “01“, “99“ universal

<CR> 13 0D

Carriage return

<SP> 32 20

Space

Data - usually signs “0“…“9“, “-“, “.“; (D) - DP and (-) may prolong data

R50

…57

Relay and Tare status

!3321

Positive command corﬁ rmation (ok)

?633F

Negative command corﬁ rmation (bad)

>623E

Beginning of the transmitted data

8 DATA PROTOCOL

RELAY, TARE

Signs Relay 1 Relay 2 Tare

P000

Q10 0

R01 0 S11 0

T00 1

U10 1

V01 1

W1 1 1

NNSTRUCTIONS FOR USE OM 652UC

8DATA PROTOCOL

58 | INSTRUCTIONS FOR USEE OM 652UC

ERROR CAUSE ELIMINATION

D. Un.

Number is too small (large negative) to be displayed

change DP setting, channel constant

D. Ou.

Number is too large to be displayed change DP setting, channel constant

T. Un.

Number is outside the table range increase the table values, change input setting

(channel constant)

T. Ow.

Number is outside the table range increase the table values, change input setting

(channel constant)

I. Un.

Input quantity is smaller than permitted input quantity range

change input signal value or input (range) setting

I. OW.

Input quantity is larger than permitted input quantity range

change input signal value or input (range) setting

E. HW.

A part of the instrument does not work properly

send the instrument for repair

E. EE

Data in EEPROM corrupted perform restoration of manufacture setting, upon

repeated error statement send instrument for repair

E.. DT.

Data in EEPROM outside the range perform restoration of manufacture setting, upon

repeated error statement send instrument for repair

E. CLR

Memory was empty (presetting carried out)

upon repeated error statement send instrument for repair, possible failure in calibration

9 ERROR STATEMENTS

NNSTRUCTIONS FOR USE OM 652UC

60 | INSTRUCTIONS FOR USEE OM 652UC

INPUT Type: upon contact, TTL, NPN/PNP

Measuring: 1x counter/frequency 1x stopwatch/timer

- measuring range isadjustable

Input frequency: 0,1...50 kHz

PROJECTION

Display: 9999, intensive red/green/orange 7-segment LED, digit height 20 mm Projection: -999…9999 Decimal point: adjustable - in programming mode Brightness: adjustable - in programming mode

INSTRUMENT ACCURACY

Temperature coef.: 50 ppm/°C Accuracy: ±0,05 % of the range + 1 digit (frequency) Time base: 0,5/1/5/10 s

Multiplying constant: ±0,001....9999

Division constant: ±0,001....9999

Filtration constant: allows for setting max. valid frequency, which is processed

(OFF/5...1000 Hz) Type of ﬁ lter: digital Preset: -999...9999 Data backup: preservation of measured data even after instrument switch-

off (EEPROM) Functions: Tare - display resetting Hold - stop measuring (upon contact) Lock - control keys locking RTC: the course of time is backed up by battery upon discon-

nection from the instrument supply (may be turned off -

jumper inside the instrument) minimum lifetime 1 year Battery: Lithium cell CR 2032RV, 3V/220 mAh OM Link: Company communication interface for instrument operaion,

setting and update Watch-dog: reset after 540 ms Calibration: při 25°C a 40 % r.v.

COMPARATOR

Type: digital, adjustable in the menu, contact switch-on < 50 ms Limits: -999…9999 Hysteresis: 0…9999 Delay: 0…99,9 s Outputs: 2x relays with switch-on contact (Form A) (230 VAC/30 VDC, 3 A)* Relay: 1/8 HP 277 VAC, 1/10 HP 125 V, Pilot Duty D300

DATA OUTPUTS

Protocols: ASCII Data format: 8 bit + no parity + 1 stop bit Rate: 600…230 400 Baud RS 232: isolated, two-way communication RS 485: isolated, two-way communication, addressing (max. 31 instruments)

ANALOG OUTPUTS

Type: isolated, programmable with resolution of max. 4 000

points, analog output corresponds with the displayed data,

type and range are adjustable Non-linearity: 0,2 % of the range TC: 100 ppm/°C Rate: response to change of value < 250 ms Voltage: 0…2 V/5 V/10 V Current: 0…5/20 mA/4…20 mA

- compensation of conduct up to 450 Ohm

EXCITATION

Adjustbale: 5…24 VDC/max. 1,2 W, isolated

- cannot be combined with data/analog output

POWER SUPPLY

Options: 10…30 V AC/DC, 10 VA, isolated,

- fuse inside (T 4000 mA) 80…250 V AC/DC, 10 VA, isolated

- fuse inside (T 630 mA)

MECHANIC PROPERTIES

Material: Noryl GFN2 SE1, incombustible UL 94 V-I Dimensions: 96 x 48 x 120 mm Panel cut-out: 90,5 x 45 mm

OPERATING CONDITIONS

Connection: connector terminal board, conductor cross-section <1,5 mm

/<2,5 mm

Stabilisation period: within 15 minutes after switch-on Working temp.: 0°…60°C Storage temp.: -10°…85°C Cover: IP65 (front panel only) Construction: safety class I Overvoltage category: EN 61010-1, A2 Insulation resistance: for pollution degree II, measurement category III Instrument power supply > 670 V (PI), 300 V (DI) Input/output > 300 V (PI), 150 (DI) EMC: EN 61000-3-2+A12; EN 61000-4-2, 3, 4, 5, 8, 11; EN 550222, A1, A2

* values apply for resistance load

10 TECHNICAL DATA

NNSTRUCTIONS FOR USE OM 652UC

7. TECHNICKÁ DATA

10TECHNICAL DATA

62 | INSTRUCTIONS FOR USEE OM 652UC

Panel cut

Panel thickness: 0,5...20 mm

Side view

Front view

90,5 mm

45 mm

96 mm

48 mm

13,5 mm

119 mm

1 2

11 INSTR. DIMENSIONS AND INSTALLATION

Instrument installation

1. insert the instrument into the panel cut-out

2. fit both travellers on the box

3. press the travellers close to the panel

Instrument disassembly

1. slide a screw driver under the traveller wing

2. turn the screw driver and remove the traveller

3. take the instrument out of the panel

NNSTRUCTIONS FOR USE OM 652UC

Product OM 652UC

Type . . . . . . . . . . . . . . . . . . . .

Manufacturing No. . . . . . . . . . . . . . . . . . . . .

Date of sale . . . . . . . . . . . . . . . . . . . .

A guarantee period of 60 months from the date of sale to the user applies to this instrument. Defects occuring during this period due to manufacture error or due to material faults shall be eliminated free of charge.

For quality, function and construction of the instrument the guarantee shall apply provided that the instrument was connected and used in compliance with the instructions for use.

The guarantee shall not apply to defects caused by:

- mechanic damage

- transportation

- intervention of unqualified person incl. the user

- unavoidable event

- other unprofessional interventions

The manufacturer performs guarantee and post.guarantee repairs unless provided for otherwise.

Stamp, signature

10. ZÁRUČNÍ LIST

YEA

ARS

Stamp,

hall not apply

the user

12CERTIFICATE OF GUARANTEE

64 | INSTRUCTIONS FOR USEE OM 652UC

TECHDOK - OM 652UC_20mm - 2007 - 1v2 - en - V

DECLARATION OF CONFORMITY

Company: ORBIT MERRET, spol. s r.o. Klánova 81/141, 142 00 Prague 4, Czech Republic, IDNo: 00551309

Manufactured: ORBIT MERRET, spol. s r.o. Vodňanská 675/30, 198 00 Prague 9, Czech Republic

declares at its full responsibility that the product presented hereunder meets all technical requirements, is safe for use when utilised under the terms and conditions determined by ORBIT MERRET, spol.s r.o. and that our company has taken all measures to ensure conformity of all products of the type listed hereunder, which are being brought out to the market, with technical documentation and requirements of the appurtenant statutory orders.

Product: Programmable panel instrument

Type: OM 352/652

Version: UC

Conformity is assessed pursuant to the following standards: Electrical safety: EN 61010-1

EMC: EN 50131-1, chapter 14 and chapter 15 EN 50130-4, chapter 7 EN 61000-4-11 EN 50130-4, chapter 8 EN 61000-4-11 EN 50130-4, chapter 9 EN 61000-4-2 EN 50130-4, chapter 10 EN 61000-4-3 EN 50130-4, chapter 11 EN 61000-4-6 EN 50130-4, chapter 12 EN 61000-4-4 EN 50130-4, chapter 13 EN 61000-4-5 EN 50130-5, chapter 20 prEN 50131-2-1, par. 9.3.1 EN 61000-4-8 EN 61000-4-9 EN 61000-3-2 ed. 2:2001 EN 61000-3-3: 1997, Cor. 1:1998, Z1:2002 EN 55022, chapter 5 and chapter 6 and government ordinance:

Electrical safety: No. 168/1997 Sb. EMC: No. 169/1997 Sb.

The evidence are the protocols of authorized and accredited organization: VTÚE Praha, experimental laboratory No. 1158, accredited by ČIA

VTÚPV Vyškov, experimental laboratory No. 1103, accredited by ČIA

Place and date of issue: Prague, 18. March 2003 Miroslav Hackl Company representative

Mode of asses. of conformity: §12, par. 4 b, d of Act No. 22/1997 Sb.

Orbit Merret OM 652UC/20mm Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
