Optoma W415 Product Sheet

MULTIMEDIA PROJECTOR

W415

CRYSTAL CLEAR DIGITAL CONNECTIVITY

WXGA resolution with DisplayPort and HDMI 1.4a connectivity

4500 lumens bright image with 15,000:1 contrast ratio makes it ideal for large screen applications

Lens shift for installation exibility

Full 3D compatibility for audience captivating immersive presentations

1.5x zoom ratio for greater installation placement exibility

The Optoma W415 is the perfect projector solution for medium to large size conference rooms, training rooms, higher education and houses of worship.

With a powerful 4500 lumens and a stunning 15,000:1 contrast ratio the W415 delivers bright large-screen presentations with fantastic image clarity, outstanding color accuracy and incredibly sharp image detail.

Designed for today’s digital world, the W415 provides HDMI v1.4a, DisplayPort connectivity, vertical lens shift for installation

exibility and RJ45 for LAN command

and control. Up to 7000 hours of lamp life

and lter-free design minimize the cost

of operation. It's compelling feature set include: Full 3D display compatibility, DICOM

Simulation and sRGB display modes.

Closed captioning, logo capture, Crestron

RoomView® for remote monitoring and

control, powerful 10-Watt speaker and more.

CONNECTIVITY (May require optional accessories)

3D BLU-RAY/DVD PLAYERS

COMPUTERS

SMART

PHONES

TABLETS

SET TOP BOXES

CAMCORDERS

GAME

CONSOLES

DIGITAL

CAMERAS

Roku

Apple TV®Chromcast™

MULTIMEDIA PROJECTOR — W415

1 6

2 3 4 5

OPTICAL/TECHNICAL SPECIFICATIONS

Display Technology Single 0.65” DC3 DMD

DLP® Technology by Texas Instruments

Native Resolution WXGA (1280 x 800)

Maximum Resolution HD 1080p (1920 x 1080)

Brightness (Typical) 4500 lumens

Contrast Ratio 15,000:1 (full on/full off)

Displayable Colors 1.07 Billion

Lamp Life* and Type 7000/4000/3000 Hours (ECO+/ECO/normal)

Projection Method Front, rear, ceiling mount, table top

Keystone Correction ±40° Vertical

Uniformity >80%

Aspect Ratio 16:10 native, 16:9 and 4:3 compatible

Throw Ratio 1.46 ~ 2.2 (distance/width)

Projection Distance 3.9'– 32.8' (1.2– 10 m)

Image Size (Diagonal) 25.3" – 318" (0.65 – 8.0 m)

Projection Lens F=2.42– 2.97, f=20.7– 31.05 mm

1.5x manual zoom and focus

Lens Shift Offset Vertical: 107% ~ 119%

Digital Zoom 0.8 ~ 2.0

Typical Offset 112%

Audio 10-Watt speaker

Noise Level 35dB min.

Remote Control IR remote mouse with laser

Operating Conditions 41–113°F (5–45°C), 85% max humidity

Power Supply AC Input 100–240V, 50– 60Hz, auto-switching

Power Consumption Max 290W (Normal), Min 230W (Eco+),

<0.5W (standby-ECO)

™

COMPATIBILITY SPECIFICATIONS

Computer Compatibility HD, UXGA, SXGA+, WXGA+, WXGA, SXGA,

Video Compatibility NTSC, PAL, SECAM, SDTV (480i), EDTV (480p),

3D Compatibility† Supports all HDMI 1.4a mandatory 3D formats

Vertical Scan Rate 24– 85Hz, 120Hz

Horizontal Scan Rate 15.375–91.146KHz

User Controls Complete on-screen menu adjustments in 27

I/O Connection Ports HDMI v1.4a, DisplayPort, two VGA-in, VGA-out,

XGA, SVGA, VGA

HDTV (720p, 1080i/p)

(Frame pack, side-by-side, top-bottom) and up

converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz (i.e 60 or 72 frames per eye). 3D glasses are needed and are sold separately. Refer to user

manual for details.

languages

composite video, S-Video, audio-in, RCA audio-in, audio-out, 12V trigger, RS-232C, RJ45 & USB-B

PHYSICAL SPECIFICATIONS

Security Kensington® lock port, security bar and keypad

Weight 5.95 lb (2.7 kg)

Dimensions (W x H x D) 11.26" x 4.88" x 10.43" (286 x 124 x 265 mm)

lock

7 8 9

1. VGA2-In

2. VG A1- In

3. VGA-Out

4. Display Port

5. HDMI

6. RJ45

10.4 3"

4.88"

Warranty

3-Year Optoma Express Service, 1-Year on Lamp

What's In the Box

W415 projector, AC power cord, VGA to VGA cable, remote control, batteries for remote, carrying case, lens cap, CD-ROM user’s manual, quick start card

and warranty card

Optional Accessories

Wireless VGA dongle, universal ceiling mount, Optoma screens, DLP®Link™ 3D glasses, wireless HDMI system and Cat6 HDBaseT

Accessory Part Numbers

Lamp: 5811118924-SOT Wireless VGA dongle: BI-EXTBG03 Remote: BR-3070L DLP® Link™ 3D glasses: BG-ZD301

Wireless HDMI system: WHD200 Single-Cat6 HDBaseT kit: EVBMN-M110 Universal ceiling mount: BM-5001U Universal ceiling mount: OCM818W-RU Universal ceiling mount (with extensional pole): OCM815W

UPC 796435 41 900 4

7. RS-232C

8. S-Video

9. Video

10. Kensington® lock port

11. Power

12. 12 V Out

13. Audio -Out

14. A udio1- In

15. RCA Audio -In

16. Security bar

11. 26 "

*Lamp -life is dependent on many fac tors, including lamp mode, display m ode, usage,

environmental c onditi ons and more. Lamp brightne ss can dec rease over time.

†3D content can be v iewed with either RF or DLP Link active shut ter glas ses when projecto r is

used wit h a compat ible 3D pl ayer. RF 3D glasses require the us e of an RF 3D emitter and a

projector with a 3 D VESA Sync po rt. Plea se visit w ww.OptomaUSA.co m for more information.

www.OptomaUSA.com

Copyright © 2014 Optoma Technology, Inc. DLP® and the DLP logo are registered trademarks of Texas Instruments™. All other trademarks are the property of their respective owners. All specications subject to change at any time. The Optoma Express Program is only valid in the U.S.
