W319USTie
Ultra Short Throw Interactive
Projection
TouchBeam finger touch interactive
WXGA, super bright 3500 lumens
Large shadow-free images from a short distance, powerful 16W built-in speaker
Multiple connections including two HDMI inputs, RJ45 control and monitoring
W319USTie
The W319USTie, is perfect for businesses, schools and colleges. It is bright (3500 lumens) and uses a new generation of TouchBeam finger-touch
interactive technology, enabling several people to work simultaneously on the screen without using a pen. The throw ratio of 0.33:1 means that it can
project a 100” image from less than 0.5m away. And having the projector installed so close to the screen avoids any shadows being cast across the
screen from the presenter(s).
It provides a complete package for engaging learning with many new features, including two HDMI inputs, powered USB port, powerful 16W built-in
speaker, improved lamp life, compact chassis and a completely new mounting system for a fast and simple set-up.
Ultra short throw
With an ultra-short throw lens, you can project
an impressive image greater than 100” from
just 55cm away. This allows you to place the
projector closer to the wall, reducing shadows
so you can present with ease; perfect for
interactive applications.
TouchBeam interactive technology
Optoma’s TouchBeam finger-touch interactive technology enables
several people to work simultaneously on the screen without using a
pen. It is easy to draw, annotate*, zoom and rotate images on the
projected screen. You can even open documents or browse the web
without touching your computer. Designed for businesses, schools and
colleges, multiple touch points allow for a more natural and intuitive way
of interacting with digital content. *Interactive software required
High Contrast
Add more depth to your image with a high contrast projector; with
brighter whites and ultra-rich blacks, images come alive and text
appears crisp and clear - ideal for business and education applications.
Full 3D
Optoma projectors can display true 3D content from almost any 3D
source, including 3D Blu-ray players, 3D broadcasting and the latest
generation games consoles.
Integrated Speaker
The built-in speaker offers excellent audio support. Easy to set up
without the need for costly external speakers
Eco+
Eco+ technology brings together high
contrast, improved lamp life and energy saving
features that are easy to use while reducing
power consumption.
Energy Saving
Using the specially designed lamp modes, you can reduce the power
consumption by up to 70%. Each mode also has a positive effect on the
lamp life, while lowering the total cost of ownership and reducing
maintenance.
Quick Resume
This feature allows the projector to be instantly powered on again, if it is
accidentally switched off.
Auto power off
There may be instances when the projector is left running when not in
use. To help save energy if the projector is left running and no source is
detected, the “Auto power off” feature automatically turns off the
projector after a set period of time.
Eco AV Mute
Stay in control of your presentation with Eco AV mute. Direct your
audience's attention away from the screen by blanking the image when
no longer needed. This also reduces the power consumption by up to
70%, further prolonging the life of your lamp.
Long Lamp Life
Reduce the number of lamp changes with lamp life of up to 6500 hours.
EPSON® replacement adapter
Update your EPSON® ultra short throw projector with an Optoma UST
projector without changing your existing mount or white board.
Remote Mouse
Keep your audience’s attention focussed on the right things using the
simple, yet powerful remote with USB mouse control.
Networking and Control
Featuring a wide range of options you can remotely control and
monitor the projector.
RS232 - Optoma projector’s come with an extensive set of
RS232 commands making it simple and easy to manage using
any control system.
AMX Compatibility - Dynamic discovery protocol is incorporated
into the projector allowing for easy installation with AMX control
systems.
LAN Control - Using the compatible RoomView® software you
can power on/off, monitor, manage and control up to 250
projectors at the same time from any computer.
Schedule the projectors to power on/off.
Control and alter the projector settings using the
simple web browser.
Emergency text broadcast capabilities for urgent or
important announcements.
Automatically receive email updates for lamp
maintenance.
Colour Guarantee
We are so confident that the image colour quality will remain as good as
the day you bought it that Optoma will guarantee it for five years.
Amazing Colour
Give powerful presentations and educational lessons with stunning
colours. Optoma projectors provide you with reliable colour
performance suitable for any content and environment. From accurate
sRGB colours for true life like images to vibrant punchy presentations.
We have a display mode to specific meet your needs.
Wireless Presenting (optional extra)
Making presentations couldn't be easier using the optional wireless
features of the WPS Wireless Adapter (sold separately) - you can
connect and display presentations wirelessly from a laptop, PC or
mobile device.
USB Power
Use the USB-Power to power an HDMI dongle, such as Google
Chromecast or the Optoma WHD200 wireless HDMI device.
Specification
Display Technology Single 0.65” WXGA DC3 DMD chip DLP® Technology by Texas Instruments
Resolution WXGA 1280 x 800
Brightness1 (Bright Mode)
3500 ANSI Lumens
Contrast 18,000:1
Typical lamp life
2
Eco+/Dynamic/Eco/Bright/Education cycle
7000/6500/6000/4500/10000 (hrs)
Throw Ratio 0.27:1
Zoom Type Fixed
I/O Connectors 2 x HDMI (1.4a 3D support), 2 x VGA (YPbPr/RGB), Composite, 2 x Audio In 3.5mm, Audio Out 3.5mm, VGA Out (Shared
with VGA2), RJ45, RS232, USB remote mouse/service, 12V trigger, Mic In, USB-A Power, 3D-Sync
Speaker 16
Keystone Correction ± 15° Vertical
Weight (kg) 4.63
Dimensions (W x D x H) (mm) 385 x 310 x 120
Aspect Ratio 16:10 Native, 16:9/4:3 Compatible
Offset 115%
Projection Screen Size 2.16 – 2.92m (85” – 115”) Diagonal 16:10
Projection Distance 0.49 - 0.66m
Projection Lens F/2.4; f=3.72mm, Fixed Zoom
Uniformity 85%
Computer Compatibility UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
Video Compatibility PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p)
3D Support Full 3D - The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include
use with 3D educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK),
Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a
specification.
3D Compatibility Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60
Horizontal Scan Rate 15.3 - 91.1kHz
Vertical Scan Rate 24 - 85Hz (120Hz for 3D)
Displayable Colours 1.07 Billion
Noise Level (Eco mode) 26dB
Power Supply 100-240V, 50-60Hz
Power Consumption 235W Bright mode / 200W Eco mode (< 0.5W Standby)
Lamp Type 190W
Operating Conditions 5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m
Security Security bar, Kensington lock, password protection
On Screen Display 25 Languages: English, German, French, Italian, Spanish, Portuguese, Swedish, Dutch, Norwegian/Danish, Polish,
Russian, Finnish, Greek, Hungarian, Czech, Arabic, Traditional Chinese, Simplified Chinese, Japanese, Korean, Thai,
Turkish, Farsi, Romanian, Slovenian
Standard Accessories AC power cord, USB cable, remote control, batteries, quick start card, CD user manual, TouchBeam interactive module, 2
x passive pens
Optional Accessories 3D glasses, wireless, wall mount
Optional Wireless Yes
Warranty 3 Years
RoHS Compliant
Optoma Europe Ltd.
1 Bourne End Mills, Hemel Hempstead, Hertfordshire HP1 2UJ, UK
www.optoma.co.uk
1
Brightness and lifetime dependent on settings and environmental conditions
2
Typical lamp life achieved through testing. Will vary according to operational use and environmental conditions
