Optoma TW631 3D, TX631 3D User Guide

CONTENTS

Usage Notice .....................................................................................2

Safety Instructions ................................................................................................................. 2

Introduction .......................................................................................5

Projector Features ................................................................................................................. 5

Package Contents ................................................................................................................. 6

Projector Overview ................................................................................................................ 7

Using the Product .............................................................................9

Control Panel ......................................................................................................................... 9

Connection Ports ................................................................................................................. 10

Remote Control ................................................................................................................... 11

Installing the Batteries ......................................................................................................... 13

Remote Control Operation ................................................................................................... 14

Connection ......................................................................................15

Connecting a computer or monitor ...................................................................................... 16

Connecting Video source devices ....................................................................................... 17

Operation .........................................................................................21

Powering On/Off the Projector ............................................................................................. 21

Adjusting the Projector Height ............................................................................................. 22

Adjusting the Projector Zoom and Focus ............................................................................ 22

Adjusting Projection Image Size .......................................................................................... 23

Menu Operation ................................................................................................................... 24

Use web browser to control your projector .......................................................................... 34

Crestron RoomView Control Tool ........................................................................................ 38

Appendix ..........................................................................................41

Replacing the Lamp .............................................................................................................41

Ceiling mount installation .....................................................................................................43

Compatibility Modes ............................................................................................................44

RS232 Commands and Protocol Function List .................................................................... 47

Troubleshooting ................................................................................................................... 51

Optoma Global Offices ........................................................................................................ 53

Regulation & Safety Notices ................................................................................................ 56

Remote Control ................................................................................................................... 58

EN-1

Usage Notice

Safety Instructions

Read all of these instructions before you operate your projector and save for
future reference.

1. Read instructions
All the safety and operating instructions should be read before the
appliance is operated.

2. Notes and warnings
All notes and warnings in the operating instructions should be adhered
to.

3. Cleaning
Unplug the projector from the wall socket before cleaning. Use a damp
cloth for cleaning the projector housing. Do not use liquid or aerosol
cleaners.

4. Accessories
Do not place this product on an unstable cart, stand, or table. The product
may fall,
Keep the plastic packing materials (from the projector, accessories and
optional parts) out of the reach of children as these bags may result in
death by suffocation. Be particularly careful around the small children.

5. Ventilation
The projector is equipped with ventilation holes (intake) and ventilation holes
(exhaust).
build-up may occur,
projector.

6. Power sources
Check that the operating voltage of your unit is identical with the voltage of
your local

7. Servicing
Do not attempt to service this projector yourself. Refer all servicing to
qualified service personnel.

causing serious damage to the product.

Do not block or place anything near these slots, or internal heat

causing picture degradation or damage to the

power supply.

EN-2

8. Replacement parts
When replacement parts are required, be sure that the replacement
parts are
result in fire, electric

9. Moisture Condensation
Never operate this projector immediately after moving it from a cold
location to a warm one. When the projector is exposed to such a
change in temperature, moisture may condense on the lens and the
crucial internal parts. To prevent the unit from possible damage, do not
use the projector for at least 2 hours when there is an extreme or
sudden change in temperature.

specified by the manufacture. Unauthorized substitutions may

shock or other hazards.

EN-3

Notes on the AC Power Cord

AC Power Cord must meet the requirement of countries where you use this
projector. Please confirm your AC plug type with the graphics below and
ensure that the proper AC Power Cord is used. If the supplied AC Power
Cord does not match your AC outlet, please contact your sales dealer. This
projector is equipped with a grounding type AC line plug. Please ensure that
your outlet fits the plug. Do not defeat the safety purpose of this grounding
type plug. We highly recommend using a video source device also equipped
with a grounding type AC line plug to prevent signal interference due to
voltage fluctuations.

Ground

For Australia and
Mainland China

Ground

For Continental Europe

Ground

For the U.S.A. and Canada

Ground

For the U.K.

EN-4

Introduction

Projector Features

The projector integrates high-performance optical engine projection and a user

- friendly
The projector offers the following features:

 Single chip 0.55" Texas Instruments DLP

 Single chip 0.65" Texas Instruments DLP
 XGA (1024 x 768 pixels)
 WXGA (1280 x 800 pixels)

 Compatibility with Macintosh
 Compatibility with NTSC, PAL, SECAM and HDTV
 D-Sub 15-pin terminal for analog video connectivity
 User-friendly, multi-language on-screen display
 Advanced electronic keystone correction
 RS-232 connector for serial control
 HDMI compatibility
 Support wireless dongle via internal power of VGA 1
 Support Optoma 3D-XL
 Implemented new Quick Resume feature

 New Eco

design to deliver high reliability and ease of use.

®

technology (XGA model)

®

technology (WXGA model)

®

computers

+

mode for more economic usage

Note



The information in this manual is subject to change without notices.



The reproduction, transfer or copy of all or any part of this document is not permitted without
express written consent.

EN-5

Package Contents

When you unpack the projector, make sure you have all these components:

Projector AC Power Cord

VGA Cable (D-SUB

to D-SUB)

Carry Bag (optional

for certain models)

Remote Control (IR) &

batteries (AAA *2 PCS)

Remote Control (IR) &

batteries (AAA *2 PCS) for

China

Documentation:

5User's Manual
5Warranty Card
5Quick Start Card
5WEEE Card

(for EMEA only)

Note



For European warrant information please visit www.optomaeurope.com



Due to the difference in applications for each country, some regions may have different
accessories.



Contact you dealer immediately if any items are missing, appear damaged, or if the unit does

.

not work



Save the original shipping carton and Packing material; they will come-in handy if you ever to
ship your unit. for maximum protection, repack your unit as it was originally packed at the
factory.

EN-6

Projector Overview

Front View

9

1

78

6

5

32

4

1

Front IR remote control sen-

6

Control panel

sor

2

Elevator foot Zoom ring

3

Projection lens Focus ring

4 9

Speaker Lamp cover

5

Ventilation holes

7

8

EN-7

Rear View

1

AC power socket

2

Connection ports

23

Kensington lock

Bottom View

2

1

3

3

1

2

1

Security bar

22

Ceiling mount holes

3

Ventilation holes

Note



This projector can be used with a ceiling mount for support. The ceiling mount is not included
in the package.



Contact your dealer for information to mount the projector on a ceiling.

EN-8

Using the Product

Control Panel

4

3

2

1

6

5

7

8

4

1

Power

Turn the projector on or off.

2

SOURCE

Switch between input signals.

3

MENU/EXIT

Display or exit the on-screen display menus.

4

Keystone ( / )

Manually correct distorted images resulting from an angled projection.

5

Four directional buttons

Use four directional buttons to select items or make adjustments to your
selection.

6

Re-SYNC

Automatically synchronize the projector to the input source.

7

POWER (Power LED indicator)
Refer to “LED Indicator Messages”.

8

TEMP/LAMP (Temp/Lamp LED indicator)
Refer to “LED Indicator Messages”.

EN-9

Connection Ports

4

9 8

6

7

1

AUDIO IN

11

2

1

3 5

10

Connect an audio output from video equipment or computer to this jack.

2

HDMI

Connect HDMI output from video equipment to this jack.

3

S-VIDEO

Connect S-Video output from video equipment to this jack.

4

VGA1-IN/YPbPr/

Connect image input signal (analog RGB or component) to this jack.
Support wireless dongle via internal power of VGA 1.

5

RS-232

When operating the projector via a computer, connect this to the
controlling computer's RS-232C port.

6

Service/Mouse

This connector is for firmware update and mouse function support.

7

RJ-45

For LAN display/network control and web server.

8

VGA OUT

Connect to a computer display, etc.

9

VGA2-IN/YPbPr

Connect image input signal (analog RGB or component) to this jack.

10

VIDEO

Connect composite video output from video equipment to this jack.

11

AUDIO OUT

Connect to a speaker or other audio input equipment.

EN-10

Remote Control

1

Power

Turn the projector on or off.

Four directional buttons

2

Use four directional buttons to
select items or make adjust­ments to your selection.
"UP" key: When menu is off, up
key for emulation of USB
mouse.
"Left" key: When menu is off,
left key for emulation of USB
mouse.
"Right" key: When menu is off,
right key for emulation of USB
mouse.
"Down" key: When menu is off,
down key for emulation of USB
mouse.

3

L Button

Perform the left button of the
mouse.

4

Source

Switch between input signals.
When menu is on, left key for
OSD.

5

Switch/

Switch to mouse mode
when the on-screen menus are
close.

6

Keystone+/-

Manually correct distorted
images resulting from an
angled projection.

7

Menu

Display on-screen display
menus.

8

Brightness

Display the setting bar for
adjustment of brightness.

1
2

2
2
3
4
5

6
7

8

9
10
11

9

HDMI

Display HDMI signal.
(This function will not work if prod­uct does not have HDMI)

10

S-Video

Display S-Video signal.

11

Freeze

Freeze the projected image.

12

Enter

Confirm your item selection.

13

R Button

Perform the right button of the
mouse.

14

Page +

Perform page up function.
When menu is on, up key for OSD.

12

2

13
14
15

16
17
18
19
20

21

EN-11

15

Re-SYNC

Automatically synchronize the
projector to the input source.
When menu is on, right key for
OSD.

16

Volu me+ /-

Adjust the volume level.

17

Page -

Perform page down function.
When menu is on, down key for
OSD.

18

3D

Turn on or off 3D function.

19

AV mute

Cut off the AV Mute temporarily.
Only pressing AV Mute again
can output sound and image. If
any other buttons are pressed,
the projection image will
become abnormal and no
sound will be output.

20

Video

Display video signal.

21

VGA

Switch input source to VGA1 or
VGA2 by sequence.

Using the remote mouse
control

The capability of operating your

computer with the remote control

gives you more flexibility when

delivering presentations.

1. Connect the projector to your PC or
notebook with a USB cable prior to
using the remote control in place of
your computer’s mouse. See

“Connecting a computer” on
page 16 for details.

2. Set the input signal to

VGA2

.

3. Press

Switch

to

switch to mouse mode when the

on the remote control

on-screen menus are close.
icon appears on the screen to
indicate the activation of the mouse
mode.

4. Perform the desired mouse controls
on your remote control.

 To move the cursor on the

screen, press / / / .

 To left-click, press L.
 To right-click, press R.
 To return to the normal mode,

press Switch again.

Note



HDMI doesn’t support mouse function.

VGA1

or

An

EN-12

Installing the Batteries

1. Open the battery cover in the
direction shown.

2. Install batteries as indicated by the
diagram inside the compartment.

3. Close the battery cover into
position.

Caution

Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Make sure the plus and minus terminals are correctly aligned when

loading a battery.

Note



Keep the batteries out of the reach of children. There is a danger of death by accidentally
swallowing the batteries.



Remove batteries from remote control when not using for extended periods.



Do not dispose of the used batteries along with household waste. Dispose of used batteries
according to local regulations.



Danger of explosion may happen if batteries are incorrectly replaced. Replce all the batteries with
new ones.



Batteries should not be in or near to fire or water, keep batteries in a dark, cool and dry place.



If suspect battery leakage, wipe out the leakage and then replace new batteries. If the
leakage adheres to your body or clothes, rinse well with water immediately.

EN-13

Remote Control Operation

Point the remote control at the infrared remote sensor and press a button.

 Operating the projector

from the front

15

15

5m

8m

7m

Note

 The remote control may not operate when there is sunlight or other strong light such as a

fluorescent lamp shining on the remote sensor.

 Operate the remote control from a position where the remote sensor is visible.
 Do not drop the remote control or jolt it.
 Keep the remote control out of locations with excessively high temperature or humidity.
 Do not get water on the remote control or place wet objects on it.


Do not disassemble the remote control.

EN-14

Connection

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

2

1 1

3 4

6 7

1

5

6

8

1. ............................................................................................*Audio cable

2. ............................................................................................*HDMI cable

3. .......................................................................... *Composite Video cable

4. .........................................................................................*S-Video cable

5. .......................................................*VGA (D-Sub) to HDTV (RCA) cable

6. .................................................................. VGA cable (D-Sub to D-Sub)

7. ..............................................................................................*USB cable

8. ...............................................................................*VGA to DVI-A cable

Note



Due to the difference in applications for each country, some regions may have different
accessories.



(*) Optional Accessory

EN-15

Connecting a computer or monitor

Connecting a computer

The projector provides two VGA input sockets that allow you to connect them
to both IBM
needed if you are connecting legacy version Macintosh computers.

To connect the projector to a notebook or desktop computer:

1. Take the supplied VGA cable and connect one end to the D-Sub output

socket of the computer.

2. Connect the other end of the VGA cable to the VGA1-IN/YPbPr or

VGA2-IN/YPbPr signal input socket on the projector.

Important

 Many notebooks do not turn on their external video ports when

Connecting a monitor

If you want to view your presentation close-up on a monitor as well as on the
screen, you can connect the VGA OUT signal output socket on the projector
to an external monitor with a VGA cable following the instructions below:

To connect the projector to a monitor:

1. Connect the projector to a computer as described in “Connecting a

computer” on page 16.

2. Take a suitable VGA cable (only one supplied) and connect one end of

the cable to the D-Sub input socket of the video monitor.

Or if your monitor is equipped with a DVI input socket, take a VGA to DVI-A cable and connect
the DVI end of the cable to the DVI input socket of the video monitor.

3. Connect the other end of the cable to the VGA OUT socket on the

projector.

®

compatibles and Macintosh® computers. A Mac adapter is

connected to a projector. Usually a key combo like FN + F3 or CRT/
LCD key turns the external display on/off. Locate a function key
labeled CRT/LCD or a function key with a monitor symbol on the
notebook. Press FN and the labeled function key simultaneously.
Refer to your notebook's documentation to find your notebook's key
combination.

Important

 The VGA OUT output only works when VGA1-IN/YPbPr or VGA2-IN/

YPbPr is made to the projector.

EN-16

Connecting Video source devices

You can connect your projector to various Video source devices that provide
any one of the following output sockets:

 HDMI
 Component Video
 S-Video
 Video (composite)

You need only connect the projector to a Video source device using just one
of the above connecting methods, however each provides a different level of
video quality. The method you choose will most likely depend upon the avail­ability of matching terminals on both the projector and the Video source

device as described below:

Terminal name Terminal appearance Reference Picture quality

HDMI HDMI “Connecting an

HDMI source

device” on

page 18

Component

Video

VGA1-IN/YPbPr or

VGA2-IN/YPbPr

“Connecting a
Component Video
source device” on

page 18

S-Video S-VIDEO “Connecting an

S-Video source

device” on

page 19

Video VIDEO “Connecting a

composite Video

source device” on

page 20

Best

Better

Good

Normal

Note



Not all models have HDMI input jack, please check your projector before connecting

EN-17

Connecting an HDMI source device

Examine your Video source device to determine if it has a set of unused
HDMI output jacks available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to

the device.

To connect the projector to an HDMI source device:

1. Take an HDMI cable and connect one end to the HDMI output jack of the
HDMI source device.

2. Connect the other end of the HDMI cable to the

HDMI

jack on the

projector.

Connecting a Component Video source device

Examine your Video source device to determine if it has a set of unused
Component Video output sockets available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to

the device.

To connect the projector to a Component Video source device:

1. Take a VGA (D-Sub) to HDTV (RCA) cable and connect the end with 3
RCA type connectors to the Component Video output sockets of the
Video source device. Match the color of the plugs to the color of the
sockets; green to green, blue to blue, and red to red.

2. Connect the other end of the cable (with a D-Sub type connector) to the

VGA1-IN/YPbPr

Important

 If the selected video image is not displayed after the projector is

turned on and the correct video source has been selected, check that
the Video source device is turned on and operating correctly. Also
check that the signal cables have been connected correctly.

or

VGA2-IN/YPbPr

socket on the projector.

EN-18

Connecting an S-Video source device

Examine your Video source device to determine if it has an unused S-Video
output socket available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to

the device.

To connect the projector to an S-Video source device:

1. Take an S-Video cable and connect one end to the S-Video output socket

of the Video source device.

2. Connect the other end of the S-Video cable to the

projector.

Important

 If the selected video image is not displayed after the projector is

turned on and the correct video source has been selected, check that
the Video source device is turned on and operating correctly. Also
check that the signal cables have been connected correctly.

 If you have already made a Component Video connection between

the projector and this S-Video source device using Component Video
connections, you need not connect to this device using an S-Video
connection as this makes an unnecessary second connection of
poorer picture quality. See “Connecting Video source devices” on

page 17 for details.

S-VIDEO

socket on the

EN-19

Connecting a composite Video source device

Examine your Video source device to determine if it has a set of unused
composite Video output sockets available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to

the device.

To connect the projector to a composite Video source device:

1. Take a Video cable and connect one end to the composite Video output
socket of the

2. Connect the other end of the Video cable to the
projector.

Important

 If the selected video image is not displayed after the projector is

turned on and the correct video source has been selected, check that
the Video source device is turned on and operating correctly. Also
check that the signal cables have been connected correctly.

 You need only connect to this device using a composite Video

connection if Component Video and S-Video inputs are unavailable
for use. See “Connecting Video source devices” on page 17 for
details.

Video source device.

VIDEO

socket on the

EN-20

Operation

Powering On/Off the Projector

Powering On the Projector:

1. Complete the AC power cord and peripheral signal cable(s) connections.

2. Press to turn on the projector.

The projector takes a minute or so to warm up.

3. Turn on your source (computer, notebook, DVD, etc.). The projector

automatically detects your source.

 If you are connecting multiple sources to the projector

simultaneously, press SOURCE on the projector or Source on the
remote control to select your desired signal or press your desired
signal key on the remote control.

Warning

 Never look into the lens when the lamp is on. This can damage your

eyes.

 This focal point concentrates high temperature. Do not place any

object near it to avoid possible fire hazard.

Powering Off the Projector:

1. Press to turn off the projector lamp. You will see a message

off? Press Power again"

2. Press again to confirm.

 The cooling fans continue to operate for cooling cycle.
 When

 If you want to turn the projector back on, you must wait until the

3. Disconnect the AC power cord from the electrical outlet and the projector.

4. Do not turn on the projector right after power off.

Warning

 When Quick Resume is on, if turning off the projector accidentally

 When Quick Resume is off, if turning off the projector, users need to

the Power LED becomes steady blue, the projector has entered

stand-by mode.

projector has completed the cooling cycle and has entered stand-by
mode. Once in stand-by mode, simply press to restart the
projector.

and Quick Resume selected within a period of 100 seconds, the
projector will instantly power on again

wait until the cooling process is finished and then restart the projector.
It will take a few minutes because the fan will keep running until the
internal temperature is reduced to certain level.

appear on the screen.

.

"Power

EN-21

Adjusting the Projector Height

Elevator foot

The projector is equipped with an elevator foot to adjust the image height. To
raise or lower the image, turn the elevator foot to fine-tune the height.

Note



To avoid damaging the projector, make sure that the elevator foot is fully retracted before
placing the projector in its carrying case.

Adjusting the Projector Zoom and Focus

Zoom ring

Focus ring

1. Focus the image by rotating the focus ring. A still image is recommended for
focusing.

2. Adjust the image size by rotating the zoom ring.

EN-22

Adjusting Projection Image Size

Refer to the graphic and table below to determine the screen size and projection
distance.

Maximum zoom

Minimum zoom

Screen

Center of lens

Vertical offset

Projection distance

XGA model

Screen size

Diagonal

[inch (cm)]

30 (76) 45 (1.15) 51 (1.3) 18 (46) 2.7(7)
40 (102) 61 (1.55) 68 (1.7) 24 (61) 3.6(9)
60 (152) 92 (2.33) 102 (2.6) 36 (91) 5.4 (14)
80 (203) 123 (3.12) 137 (3.5) 48 (122) 7.2 (18)

100 (254) 154 (3.90) 171 (4.3) 60 (152) 9.0 (23)
120 (305) 185 (4.69) 205 (5.2) 72 (183) 10.8 (27)
150 (381) 231 (5.87) 257 (6.5) 90 (229) 13.5 (34)
200 (508) 308 (7.83) 343 (8.7) 120 (305) 18.0 (46)
250 (635) 386 (9.80) 427 (10.9) 150 (381) 22.5 (57)
300 (762) 463 (11.77) 515 (13.1) 180 (457) 27.0 (69)

Projection distance [inch (m)]

(min. zoom) (max. zoom)

4 : 3 Screen

Image height

[inch (cm)]

WXGA model

Screen size

Diagonal

[inch (cm)]

30 (76) 37 (0.9) 46 (1.16) 16 (40) 2.4(6)
40 (102) 49 (1.3) 61 (1.55) 21 (54) 3.2(8)
60 (152) 74 (1.9) 92 (2.33) 32 (81) 4.8 (12)
80 (203) 100 (2.5) 123 (3.12) 42 (108) 6.4 (16)

100 (254) 125 (3.2) 154 (3.90) 53 (135) 7.9 (20)
120 (305) 150 (3.8) 185 (4.69) 64 (162) 9.5 (24)
150 (381) 187 (4.8) 231 (5.86) 79 (202) 11.9 (30)
200 (508) 250 (6.4) 308 (7.83) 106 (269) 15.9 (40)
250 (635) 313 (8.0) 385 (9.79) 132 (336) 19.9 (50)
300 (762) 376 (9.5) 463 (11.75) 159 (404) 23.8 (61)

Projection distance [inch (m)]

(min. zoom) (max. zoom)

4 : 3 Screen

Image height

[inch (cm)]

Vertical offset

[inch (cm)]

Vertical offset

[inch (cm)]

Note



Position the projector in a horizontal position; other positions can cause heat build-up and
damage to the projector.



Keep a space of 30 cm or more between the sides of the projector.



Do not use the projector in a smoky environment. Smoke residue may build-up on critical
parts and damage the projector or its performance



Consult with your dealer for special installation such as suspending from a ceiling.

.

EN-23

Menu Operation

The projector has multilingual on-screen display menus that allow you to
make image adjustments and change a variety of settings.

How to operate

1. Press MENU on the projector or Menu on the remote control to open the
OSD menu.

2. When OSD is displayed, use / to select any feature in the main
menu.

3. After selecting the desired main menu item, press to enter sub-menu
for feature setting.

4. Use / to select the desired item and adjust the settings with / .

5. Press MENU on the projector or Menu on the remote control, the screen
will return to the main menu.

6. To exit OSD, Press MENU on the projector or Menu on the remote
control again. The OSD menu will close and the projector will
automatically save the new settings.

EN-24

Brilliant Color

Phase

Internal Speaker

−40−+40

XGA: 4:3,16: 9-I, 16: 9-II, Native, Auto
WXGA: 4:3, 16: 9/6:10, LBX,
Native, Auto

Presentation, Bright, Movie,
sRGB, User, Black Board,

TM

Classroom

Screen Type

Security

Quick Resume

Brightness Mode

Closed Captioning

Projector ID

Network

Wireless

3D Sync Invert

XGA: 16:9
WXGA: 16 :10, 16 : 9

YUV

Security Settings

Active mode,Eco mode

Bright, Eco, Eco

0~99

Network State

DHCP

IP Address

Subnet mask

Gateway

DNS

Apply

Off, On

Off, On

+

Disconnect, Connect

EN-25


Brightness

Brighten or darken the image.

Contrast

Set the difference between light and dark areas.

Color Settings

Adjust the color temperature. At higher temperature the screen looks colder;
at lower temperature, the screen looks warmer. If you select “User”, then you
can change the intensity of each of 3 color (Red, Green, Blue) to customize
user color temperature.

Keystone

Manually correct distorted images resulting from an angled projection.

Zoom

Zoom in and out the images.

Aspect Ratio

Use this function to choose your desired aspect ratio.

For XGA models:

Source 480i/p 576i/p 1080i/p 720p

4:3 1024x768 center
16:9-I 1024x576 center
16: 9-II 1024x614 center(show 1024x768).
Native Displays the original image without any scaling.
Auto(Default) Automatically selects the appropriate display format.

PC

EN-26

For WXGA models:

16:9 or 16:10 depend on “Screen Type” setting.
16:10 Screen

16 : 10
screen

4:3

480i/p 576i/p 1080i/p 720p PC

1066 x800 center

16:10 1280x800 center
LBX 1280x960 center, then get the central 1280x800 image to display.

Displays the original image without any scaling.

Native

1:1 mapping centered

1:1 mapping
display 1280 x 800

1280x720
Centered

1:1 mapping

centred

Auto (Default) Automatically selects the appropriate display format.

16:9 Screen

16 : 9

screen

480i/p 576i/p 1080i/p 720p PC

4:3 960x720 center
16:9 1280x720 center
LBX 1280x960 center, then get the central 1280x720 image to display.

Displays the original image without any scaling.

Native

1:1 mapping centered

1:1 mapping
display 1280 x 720

1280x720
Centered

1:1 mapping

centred

Auto (Default) Automatically selects the appropriate display format.


There are many factory presets optimized for various types of images.

 Presentation: For computer or notebook.
 Bright: For bright environment.
 Movie: For home theater.
 sRGB: For PC standard color.
 User: Memorize user’s settings.
 Black Board: For black projection screen type.
 Classroom: For projection in the classroom.

BrilliantColor™

Adjusts the BrilliantColor™ value to extend the exposure range and sharp­ens detail for grain free images.

Gamma

Effect the represent of dark scenery. With greater gamma value, dark scenery will
look brighter.

Note



When Economic Standby (<1W), VGA and audio loop through will not work in standby mode.

EN-27

Signal

Frequency

Adjust the timing of the projector relative to the computer.

Phase

Adjust the phase of the projector relative to the computer.

H Position (Horizontal Position)

Adjust the image left or right within the projection area.

V Position (Vertical Position)

Adjust the image up or down within the projection area.

EN-28

Video Image

Color

Adjust a video image from black and white to fully saturated color.

Sharpness

Sharpen or soften the image.

Tint

Shift colors toward red or green.

Sound

Volume

Adjust the volume level.

Mute

Cut off the sound temporarily.

Internal Speaker

Use the internal speaker of projector.

EN-29

Setting

Menu Position

Choose the menu location on the display screen.

Projection

Adjust the picture to match the orientation of the projector: upright or upside­down, in front of or behind the screen. Invert or reverse the image accord­ingly.

Screen Type (for WXGA model only)

Choose the screen type from16:10 or 16:9.

Color Space

Select an appropriate color matrix type from RGB,YUV.

Lamp Time

Display the lamp’s elapsed operating time (in hours).

Lamp Time Reset

Reset the lamp Hour to 0 hours.

Security

Turn on the projector with or without password verification. When the pass­word function is added, image projection will require to input the preset pass­word when turning on the projector. Pass-code default value is "Right-Left-

Down-Up" (first time).

EN-30

Power mode (standby)

Set whether the VGA OUT function works when the projector is in standby
(powered off but connected to AC power).

 Eco mode: The VGA OUT function will not work when the projector is in

standby.

 Active mode: The VGA OUT and AUDIO OUT functions will work when

the projector is in standby.

Auto Power Off

Set the countdown timer interval. The countdown timer will start, when there
is no signal being sent to the projector. Then projector will automatically
power off when the countdown has finished (in minutes).

Quick Resume

If the projector is accidentally turned off, this feature allows the projector to
be instantly powered on again within 100 seconds of power down.

Source Lock

 On: The projector will search specified connection port.
 Off: The projector will search for other signals if the current input signal is

lost.

Brightness Mode

 Bright: Choose “Bright” to increase the brightness.
 Eco: Choose “Eco” to dim the projector lamp which will lower power

consumption and extend the lamp life by up to 120%.

 Eco

+

: Choose “Eco+” to dim the projector lamp which will automatically
detect the brightness level of the content and reduce lamp power
consumption (up to 70 percent) during periods of inactivity.

High Altitude

Use this function to allow the fans operates at full speed continuously to
achieve proper high altitude cooling of the projector.

OSD Timeout

Duration of OSD menu display countly starts (at idle state by second).

Closed Captioning

Enable or disable closed captioning by selecting CC1,CC2 or Off.

Projector ID

ID definition can be set up by menu (range 0~99), and allow user control an
individual projector by RS232.

Network

Allow you to configure the LAN settings.

 Network State:Display the network connection status.
 DHCP: This protocol automatically assign IP Address to networked

EN-31

devices.

 On: Assign an IP address to the projector from an external DHCP

server automatically.

 Off: Assign an IP address manually.
 IP Address: Select an IP address.
 Subent mask: Select subnet mask number.
 Gateway: Select the default gateway of the network connected to the

projector.

 DNS: Select DNS number.

 Apply: Press " " and then choose "Yes" to apply the selection.

Wireless

This setting is only for wireless module use.
Wireless is only functional with VGA 1 connector.

3D Mode

 On: Enable 3D Mode function.
 Off: Disable 3D Mode function.

When 3D Sync is set to "On", the settings for input source or broadcast
device are required as below:

1. For S-VIDEO and VIDEO input source, signal type should be NTSC (60).

2. For computer input source, the hardware and software requirements

should be Windows 7 operating system, 3D videos and professional 3D

video player softwares. Computer's output frequency should be 120Hz

and display card should be higher than NVIDIA 9800.

3D Sync Invert

 On: Invert left and right frame contents.
 Off: Default frame contents.

EN-32

Language

Select the language used by the on-screen menu.

Factory Default

Restore settings to factory default .

EN-33

Use web browser to control your projector

1. Turn on DHCP to allow the DHCP server to automatically assign an IP,

or manually enter the required network information.

2. Then choose apply and press " " button to complete the configuration

process.

3. Open your web browser and type in the projector's IP address from the

OSD LAN screen. The following web page will display as below:

• When you used the projector IP address, you will can not link to your service

server.

EN-34

4. The crestron control settings can be found in the [tools] tab.(see picture)

Please note, each field can only contain a limited number of characters,
as shown in the table below. (spaces and the other punctuation
included):

Category Item Input-Length (characters)

IP Address 15

Crestron Control

Projector

Network

Configuration

User Password

Admin Password

IP ID 2

Port 5

Projector Name 10

Location 9

Assigned To 9

DHCP (Enabled) (N/A)

IP Address 15

Subnet Mask 15

Default Gateway 15

DNS Server 15

Enabled (N/A)

New Password 15

Confirm 15

Enabled (N/A)

New Password 15

Confirm 15

EN-35

Connect you computer to the projector

1. Find an IP Address (10.0.50.100) from LAN function of projector.

2. Select "Apply" and press "Enter" button to submit function or press

"MENU" key to exit.

3. To open Network Connections, click Start, click Control Panel, click

Network and Internet Connections, and then click Network
Connections. Click the connection you want to configure, and then,

under Network Tasks , click Change settings of this connection.

4. On the General tab, under This connection uses the following items,

click Internet Protocol (TCP/IP), and then click "Properties".

EN-36

5. Click Use the following IP address, and type in as below:.

 IP address:10.0.50.101
 Subnet mask:255.0.0.0
 Default gateway:10.0.50.254

6. To open Internet Options, click IE web browser, click Internet Options,

click the Connections tab and click "LAN Settings...".

EN-37

7. The Local Area Network (LAN) Setting dialog box appears, In the Proxy

Server area, cancel the Use a proxy server for your LAN check box.,
then click "OK" button twice.

8. Open your IE and type in the IP address of 10.0.50.100 in the URL then

press "Enter" key.

Crestron RoomView Control Tool

Crestron RoomViewTM provides a central monitoring station for 250+ control
systems on a single Ethernet network (more are possible. the number
depends on the combination of IP ID and IP address). Crestron RoomView
monitors each projector, including projector's online status, system power,
lamp life, network setting and hardware faults, plus any custom attribute as
defined by the Administrator. The Administrator can add, delete, or edit room

information, contact information and events, which are logged automatically
by the software for all users.(Operation UI as following image)

1. Main Screen

 Crestron RoomView function support is dependent on models.

EN-38

2. Edit Room

3. Edit Attribute

EN-39

4. Edit Event

 For more information, please visit http://www.crestron.com &

www.crestron.com/getrommview.

EN-40

Appendix

Replacing the Lamp

As the projector operates over time, the brightness of the projector lamp
gradually decreases and the lamp becomes more susceptible to breakage.
We recommend replacing the lamp if a warning message is displayed. Do
not attempt to replace the lamp yourself. Contact the qualified service
personnel for replacement.

Note



The lamp is extremely hot right after turning off the projector. If you touch the lamp, you may
scald your finger. When you replace the lamp, wait for at least 45 minutes for the lamp to cool
down.



Do not touch the lamp glass at any time. The lamp may explode due to improper handling,
including the touching of the lamp glass.



Lamp lifetime may differ from lamp to lamp and according to the environment of use. There is
no guarantee of the same lifetime for each lamp. Some lamps may fail or terminate their
lifetime in a shorter period of time than other similar lamps.



A lamp may explode as a result of vibration, shock or degradation as a result of hours of use
as its lifetime draws to an end. Risk of explosion may differ according to the environment or
conditions in which the projector and lamp are being used.



Wear protective gloves and eyeglasses when fixing or detaching the lamp.



Faster on-off-cycles will damage the lamp and reduce lamp life. Wait at least for 5 minutes to
turn off the projector after powering on.



Do not operate the lamp in proximity to paper, cloth, or other combustible material nor cover it
with such materials.



Do not operate the lamp in an atmosphere containing an inflammable substance, such as
thinner.



Thoroughly ventilate the area or the room when operating the lamp in an oxygen atmosphere
(in the air). If ozone is inhaled, it could cause headaches, nausea, dizziness, and other
symptoms.



The inorganic mercury is involved in the lamp. If the lamp bursts, the mercury inside the lamp
will be exposed. Leave the area immediately if the lamp shatters while being operated and
ventilate the area for at least 30 minutes in order to avoid the inhalation of mercury fumes.
Otherwise it could be harmful to user’s health.

EN-41

1. Turn off the projector.

1

2

3

4

2. If the projector is installed in a ceiling mount, remove it

3. Unplug the power cord.

4. Remove the screw in the side of the lamp cover. 1

5. Remove the cover. 2

6. Loosen the screws from the lamp module. 3

7. Raise the handle, and lift out the module. 4

8. Insert the new lamp module into the projector and tighten the screws.

9. Replace the lamp cover and tighten the screw.

10. Turn on the projector. If the lamp does not turn on after the warm-up

period, try reinstalling the lamp.

11. Reset the lamp hour. Refer to the “

1

2

Setting > Lamp Time Reset

3

4

” menu.

Note



Dispose the used lamp according to local regulations.



Ensure that screws are tightened properly. Screws not tightened fully may result in injury or
accidents.



Since the lamp is made of glass, do not drop the unit and do not scratch the glass.



Do not reuse the old lamp. This could cause the lamp to explode.



Be sure to turn off the projector and unplug the AC power cord before replacing the lamp.



Do not use the projector with the lamp cover removed.

EN-42

Ceiling mount installation

1. To prevent damage to your projector, please use the Optoma ceiling

mount.

2. If you wish to use a third party ceiling mount kit, please ensure the screws

used to attach a mount to the projector meet the following specifications:

 Screw type: M4*3
 Maximum screw length: 8mm
 Minimum screw length: 6mm

120.0073.00

57.94

61.70

278.32

210.70

29.70

12.70

139.00 38.50

54.00

231.50

Lens

Unit: mm

Note



Please note that damage resulting from incorrect installation will void the warranty.

Warning

1.If you buy a ceiling mount from another company, please be sure to
use the correct screw size. Screw size will vary depending on the
thickness of the mounting plate.

2.Be sure to keep at least 10 cm gap between the ceiling and the
bottom of the projector.

3.Avoid installing the projector near a heat source.

EN-43

Compatibility Modes

Computer:

Mode Resolution H-Sync [KHz] V-Sync [Hz]

640 x 350 31.5 70
640 x 350 37.9 85
720 x 350 31.5 70
640 x 400 31.5 70
640 x 400 37.9 85.1
720 x 400 31.5 70
720 x 400 37.9 85
720 x 576 - 50
720 x 576 - 60

31.5 60

-67

VGA 640 x 480

SVGA 800 x 600

832 x 624 - 72

832 x 624 - 75
1024 x 576 - 50
1024 x 576 - 60

XGA 1024 x 768

1152 x 864

1152 x 870 - 75

HD720 1280 x 720 - 50

37.9 72.8

37.5 75

43.3 85

35.2 56.3

37.9 60.3

46.9 75

48.1 72.2

-80

53.7 85.1

48.4 60

56.5 70.1

57.7 72
60 75

68.7 85

-60

-70

-75

-85

EN-44

HD720 1280 x 720 - 60
HD720 1280 x 720 - 75
HD720 1280 x 720 - 85

47.4 60

WXGA 1280 x 768

WXGA-800 1280 x 800 - 60

SXGA 1280 x 960 - 60

SXGA 1280 x 1024

1366 x 768 - 60
1440 x 900 55.935 60

SXGA+ 1400 x 1050 - 60

UXGA 1600 x 1200 75 60
HDTV 1920 x 1080 33.8 30

1920 x 1080 28.1 25
1920 x 1080i - 50
1920 x 1080i - 60

1920 x 1080p - 24
1920 x 1080p - 25
1920 x 1080p - 30
1920 x 1080p - 50
1920 x 1080p - 60

1280 x 720 45 60
1280 x 720p - 50
1280 x 720p - 60

SDTV 720 x 576 31.3 50

720 x 576i - 50

720 x 576p - 50

720 x 480 31.5 60

720 x 480i - 60

720 x 480p - 60

-75

-85

64 60
80 75

91.1 85

EN-45

Video:

NTSC NTSC M/J, 3.58MHz, 4.43MHz

PAL PAL B/D/G/H/I/M/N, 4.43MHz

SECAM SECAM B/D/G/K/K1/L, 4.25/4.4 MHz

Component

SDTV 480i/p, 576i/p
HDTV 720p(50/60Hz), 1080i(50/60Hz), 1080P(24/25/30/50/60Hz)

480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz)

1080P(24/25/30/50/60Hz)

EN-46

RS232 Commands and Protocol Function
List

RS232 Pin Assignments

D-Sub 9 pin

11 CD
2RXD
3TXD
4DTR
5GND
6DSR
7RTS
8CTS
9RI

Wire List

C1 COLOR C2

1 Black 1
2Brown2
3Red3
4Orange4
5 Yellow 5
6 Green 6
7Blue7
8 Purple 8
9White9

SHELL DW SHELL

EN-47

RS232 Protocol Function List

Baud Rate : 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F

Note



There is a <CR> after all ASCII commands.



0D is the HEX code for <CR> in ASCII code.

SEND to projector

232 ASCII Code HEX Code Function Description

~XX00 1 7E 30 30 30 30 20 31 0D Power ON

~XX00 0 7E 30 30 30 30 20 30 0D Power OFF (0/2 for backward compatible)

~XX00 1 ~abcd 7E 30 30 30 30 20 31 20 a 0D Power ON with Password a, b, c, and d belong to{1,2,3,4}

~XX01 1 7E 30 30 30 31 20 31 0D Resync

~XX02 1 7E 30 30 30 32 20 31 0D AV Mute On

~XX02 0 7E 30 30 30 32 20 30 0D Off (0/2 for backward compatible)

~XX03 1 7E 30 30 30 33 20 31 0D Mute On

~XX03 0 7E 30 30 30 33 20 30 0D Off (0/2 for backward compatible)

~XX04 1 7E 30 30 30 34 20 31 0D Freeze

~XX04 0 7E 30 30 30 34 20 30 0D Unfreeze (0/2 for backward compatible)

~XX05 1 7E 30 30 30 35 20 31 0D Zoom Plus

~XX06 1 7E 30 30 30 36 20 31 0D Zoom Minus

~XX12 1 7E 30 30 31 32 20 35 0D Direct Source Commands HDMI

~XX12 5 7E 30 30 31 32 20 35 0D VGA 1

~XX12 6 7E 30 30 31 32 20 35 0D VGA 2

~XX12 8 7E 30 30 31 32 20 38 0D VGA 1 Component

~XX12 9 7E 30 30 31 32 20 39 0D S-Video

~XX12 10 7E 30 30 31 32 20 31 30 0D Video

~XX12 13 7E 30 30 31 32 20 31 33 0D VGA 2 Component

~XX20 0 7E 30 30 32 30 20 30 0D Display Mode None

~XX20 1 7E 30 30 32 30 20 31 0D Presentation

~XX20 2 7E 30 30 32 30 20 32 0D Bright

~XX20 3 7E 30 30 32 30 20 33 0D Movie

~XX20 4 7E 30 30 32 30 20 34 0D sRGB

~XX20 5 7E 30 30 32 30 20 35 0D User

~XX20 7 7E 30 30 32 30 20 37 0D Blackboard

~XX20 8 7E 30 30 32 30 20 38 0D Classroom

~XX21 n 7E 30 30 32 31 20 a 0D Brightness n = 0 (a=30) ~ 100 (a=31 30 30)

~XX22 n 7E 30 30 32 32 20 a 0D Contrast n = 0 (a=30) ~ 100 (a=31 30 30)

~XX23 n 7E 30 30 32 33 20 a 0D Sharpness n = 0 (a=30) ~ 31 (a=33 31)

~XX24 n 7E 30 30 32 34 20 a 0D Color Settings Red Gain n = 0 (a=2D 35 30) ~ 100 (a=35 30)

~XX25 n 7E 30 30 32 35 20 a 0D Green Gain n = 0 (a=2D 35 30) ~ 100 (a=35 30)

~XX26 n 7E 30 30 32 36 20 a 0D Blue Gain n = 0 (a=2D 35 30) ~ 100 (a=35 30)

~XX34 n 7E 30 30 33 34 20 a 0D BrilliantColor™ n = 0 (a=30) ~ 10 (a=31 30)

~XX35 1 7E 30 30 33 35 20 31 0D Gamma 0

~XX35 2 7E 30 30 33 35 20 32 0D 1

~XX35 3 7E 30 30 33 35 20 33 0D 2

~XX35 4 7E 30 30 33 35 20 34 0D 3

~XX36 1 7E 30 30 33 36 20 31 0D Color Temp. Warm

~XX36 2 7E 30 30 33 36 20 32 0D Medium

~XX36 3 7E 30 30 33 36 20 33 0D Cold

~XX37 2 7E 30 30 33 37 20 32 0D Color Space RGB

~XX37 3 7E 30 30 33 37 20 33 0D YUV

~XX45 n 7E 30 30 34 34 20 a 0D Color (Satu ration) n = 0 (a=30) ~ 100 (a=31 30 30 )

~XX44 n 7E 30 30 34 35 20 a 0D Tint n = 0 (a=30) ~ 100 (a=31 30 30)

~XX60 1 7E 30 30 36 30 20 31 0D Aspect Ratio 4:3

~XX60 2 7E 30 30 36 30 20 32 0D 16:9-l(XGA)

(Password only support Up/Down/Left/Right)

XX=01-99, projector's ID,
XX=00 is for all projectors

EN-48

~XX60 3 7E 30 30 36 30 20 33 0D 16:9-ll (XGA)/16:9 or 16:10 ( WXGA)

~XX60 5 7E 30 30 36 30 20 35 0D LBX (WXGA)

~XX60 6 7E 30 30 36 30 20 36 0D Native

~XX60 7 7E 30 30 36 30 20 37 0D Auto

~XX62 n 7E 30 30 36 32 20 a 0D Zoom n = -5 (a=2D 35) ~ 5 (a=35)

~XX66 n 7E 30 30 36 36 20 a 0D V Keystone n = -40 (a=2D 33 30) ~ 40 (a=34 30)

~XX230 1 7E 30 30 32 33 30 20 31 0D 3D Mode DLP-Link

~XX230 0 7E 30 30 32 33 30 20 30 0D 3D Mode Off

~XX231 1 7E 30 30 32 33 31 20 31 0D 3D Sync Invert On

~XX231 0 7E 30 30 32 33 31 20 30 0D 3D Sync Invert Off

~XX70 1 7E 30 30 37 30 20 31 0D Language English

~XX70 2 7E 30 30 37 30 20 32 0D German

~XX70 3 7E 30 30 37 30 20 33 0D French

~XX70 4 7E 30 30 37 30 20 34 0D Italian

~XX70 5 7E 30 30 37 30 20 35 0D Spanish

~XX70 6 7E 30 30 37 30 20 36 0D Portuguese

~XX70 7 7E 30 30 37 30 20 37 0D Polish

~XX70 8 7E 30 30 37 30 20 38 0D Dutch

~XX70 9 7E 30 30 37 30 20 39 0D Swedish

~XX70 10 7E 30 30 37 30 20 31 30 0D Norwegian/Danish

~XX70 11 7E 30 30 37 30 20 31 31 0D Finnish

~XX70 12 7E 30 30 37 30 20 31 32 0D Greek

~XX70 13 7E 30 30 37 30 20 31 33 0D Traditional Chinese

~XX70 14 7E 30 30 37 30 20 31 34 0D Simplified Chinese

~XX70 15 7E 30 30 37 30 20 31 35 0D Japanese

~XX70 16 7E 30 30 37 30 20 31 36 0D Korean

~XX70 17 7E 30 30 37 30 20 31 37 0D Russian

~XX70 18 7E 30 30 37 30 20 31 38 0D Hungarian

~XX70 19 7E 30 30 37 30 20 31 39 0D Czech

~XX70 20 7E 30 30 37 30 20 32 30 0D Arabic

~XX70 21 7E 30 30 37 30 20 32 31 0D Thai

~XX70 22 7E 30 30 37 30 20 32 32 0D Turkish

~XX70 23 7E 30 30 37 30 20 32 33 0D Farsi

~XX70 25 7E 30 30 37 30 20 32 35 0D Vietnamese

~XX70 26 7E 30 30 37 30 20 32 36 0D Indonesian

~XX70 27 7E 30 30 37 30 20 32 37 0D Romanian

~XX71 1 7E 30 30 37 31 20 31 0D Projection Front-Desktop

~XX71 2 7E 30 30 37 31 20 32 0D Rear-Desktop

~XX71 3 7E 30 30 37 31 20 33 0D Front-Ceiling

~XX71 4 7E 30 30 37 31 20 34 0D Rear-Ceiling

~XX72 1 7E 30 30 37 32 20 31 0D Menu Location Top Left

~XX72 2 7E 30 30 37 32 20 32 0D Top Right

~XX72 3 7E 30 30 37 32 20 33 0D Centre

~XX72 4 7E 30 30 37 32 20 34 0D Bottom Left

~XX72 5 7E 30 30 37 32 20 35 0D Bottom Right

~XX90 1 7E 30 30 39 31 20 31 0D Screen Type (WXGA only) 16:10

~ X X 9 0 0 7 E 3 0 3 0 3 9 3 1 2 0 3 0 0 D 1 6 : 9

~XX73 n 7E 30 30 37 33 20 a 0D Signal Frequency n = -5 (a=2D 35 30) ~ 5 (a=35 30) By signal

~XX74 n 7E 30 30 37 34 20 a 0D Phase n = 0 (a=30) ~ 31 (a=33 31) By signal

~XX75 n 7E 30 30 37 35 20 a 0D H. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing

~XX76 n 7E 30 30 37 36 20 a 0D V. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing

~XX78 1 7E 30 30 37 38 20 31 0D Security Settings Enable

~XX78 0 7E 30 30 37 38 20 32 0D Disable(0/2 for backward compatible)

~XX80 1 7E 30 30 38 30 20 31 0D Mute On

~XX80 0 7E 30 30 38 30 20 30 0D Off (0/2 for backward compatible)

~XX81 n 7E 30 30 38 31 20 a 0D Volume n = 0 (a=30) ~ 10 (a=32 30)

~XX88 0 7E 30 30 38 38 20 30 0D Closed Captioning Off

~XX88 1 7E 30 30 38 38 20 31 0D cc1

~XX88 2 7E 30 30 38 38 20 32 0D cc2

~XX100 1 7E 30 30 31 30 30 20 31 0D Source Lock On

~XX100 0 7E 30 30 31 30 30 20 30 0D Off (0/2 for backward compatible)

~XX100 3 7E 30 30 31 30 30 20 33 0D Next Source

~XX101 1 7E 30 30 31 30 31 20 31 0D High Altitude On

~XX101 0 7E 30 30 31 30 31 20 30 0D Off (0/2 for backward compatible)

~XX106 n 7E 30 30 31 30 36 20 a 0D Auto Power Off (min) n = 0 (a=30) ~ 180 (a=31 38 30)

~XX114 1 7E 30 30 31 31 34 20 31 0D Power mode (Standby) Active

~XX114 0 7E 30 30 31 31 34 20 30 0D

~XX115 1 7E 30 30 31 31 35 20 31 0D Quick Resume On

~XX115 0 7E 30 30 31 31 35 20 31 0D Quick Resume Off(0/2 for backward compatible)

Power mode (Standby) Eco (0/2 for backward
compatible)

EN-49

~XX110 1 7E 30 30 31 31 30 20 31 0D Brightness Mode Bright

~XX110 0 7E 30 30 31 31 30 20 30 0D Eco (0/2 for backward compatible)

~XX110 3 7E 30 30 31 31 30 20 33 0D Eco

~XX111 1 7E 30 30 31 31 31 20 31 0D Lamp Reset Yes

~XX111 0 7E 30 30 31 31 31 20 30 0D No (0/2 for backward compatible)

~XX112 1 7E 30 30 31 31 32 20 31 0D Reset Yes

~XX99 1 7E 30 30 39 39 20 31 0D RS232 Alert Reset Reset System Alert

SEND to emulate Remote

~XX140 1 7E 30 30 31 34 30 20 31 0D Power

~XX140 3 7E 30 30 31 34 30 20 33 0D Remote Mouse Up

~XX140 4 7E 30 30 31 34 30 20 34 0D Remote Mouse Left

~XX140 5 7E 30 30 31 34 30 20 35 0D Remote Mouse Enter

~XX140 6 7E 30 30 31 34 30 20 36 0D Remote Mouse Right

~XX140 7 7E 30 30 31 34 30 20 37 0D Remote Mouse Down

~XX140 8 7E 30 30 31 34 30 20 38 0D Mouse Left Click

~XX140 9 7E 30 30 31 34 30 20 39 0D Mouse Right Click

~XX140 10 7E 30 30 31 34 30 20 31 30 0D Up/Page +

~XX140 11 7E 30 30 31 34 30 20 31 31 0D Left/Source

~XX140 12 7E 30 30 31 34 30 20 31 32 0D Enter (for projection MENU)

~XX140 13 7E 30 30 31 34 30 20 31 33 0D Right/Re-SYNC

~XX140 14 7E 30 30 31 34 30 20 31 34 0D Down/Page -

~XX140 15 7E 30 30 31 34 30 20 31 35 0D Keystone +

~XX140 16 7E 30 30 31 34 30 20 31 36 0D Keystone -

~XX140 17 7E 30 30 31 34 30 20 31 37 0D Volume -

~XX140 18 7E 30 30 31 34 30 20 31 38 0D Volume +

~XX140 19 7E 30 30 31 34 30 20 31 39 0D Brightness (1)

~XX140 20 7E 30 30 31 34 30 20 32 30 0D Menu (2)

~XX140 21 7E 30 30 31 34 30 20 32 31 0D 3D (3)

~XX140 22 7E 30 30 31 34 30 20 32 32 0D HDMI (4)

~XX140 23 7E 30 30 31 34 30 20 32 33 0D Freeze (5)

~XX140 24 7E 30 30 31 34 30 20 32 34 0D AV Mute (6)

~XX140 25 7E 30 30 31 34 30 20 32 35 0D S-Video (7)

~XX140 26 7E 30 30 31 34 30 20 32 36 0D VGA1/2 toggle (8)

~XX140 27 7E 30 30 31 34 30 20 32 37 0D Video (9)

~XX140 28 7E 30 30 31 34 30 20 32 38 0D Switch to USB mouse

SEND from projector automatically

232 ASCII Code HEX Code Function Projector Return Description

when Standby/Warming/Cooling/Out of Range/Lamp fail/ INFOn

Fan Lock/Over Temperature/Lamp Hours Running Out/Cover Open

READ from projector

232 ASCII Code HEX Code Function Projector Return Description

~XX121 1 7E 30 30 31 32 31 20 31 0D Input Source Commands OKn

~XX122 1 7E 30 30 31 32 32 20 31 0D Sofware Version OKdddd dddd: FW version

~XX123 1 7E 30 30 31 32 33 20 31 0D Display Mode OKn

~XX124 1 7E 30 30 31 32 34 20 31 0D Power State OKn n : 0/1 = Off/On

~XX125 1 7E 30 30 31 32 35 20 31 0D Brightness OKn

~XX126 1 7E 30 30 31 32 36 20 31 0D Contrast OKn

~XX127 1 7E 30 30 31 32 37 20 31 0D Aspect Ratio OKn

~XX128 1 7E 30 30 31 32 38 20 31 0D Color Temperature OKn n: 0/1/2=Warm/Medium/Cold

~XX129 1 7E 30 30 31 32 39 20 31 0D Projection Mode OKn

~XX150 1 7E 30 30 31 35 30 20 31 0D Information OKabbbbccdddde

~XX151 1 7E 30 30 31 35 31 20 31 0D Model name OKn n:17/18 =XGA model/WXGA model

~XX108 1 7E 30 30 31 30 38 20 31 0D Lamp Hours OKbbbb bbbb: LampHour

~XX108 2 7E 30 30 31 30 38 20 31 0D Cumulative Lamp Hours OKbbbbb bbbbb: (5 digits) Total Lamp Hours

+

n : 0/1/2/3/4/6/7/8/ 9 = Standby/Warming/
Cooling/Out of Range/Lamp fail/

Fan Lock/Over Temperature/Lamp Hours
Running Out/Cover Open

n : 0/1/2/3/4/5 = None/VGA1 /VGA2/S-Video/
Video/HDMI

n : 0/1/2/3/4/5/7/8/ 9/None/Presentation/Bright/
Movie/sRGB/User/Blackbo ard/Classroom/3D

(XGA) n: 0/1/2/3/4 = 4:3/16:9-I/16:9-II/Native/AUTO
(WXGA) n: 0/1/2/3/4 = 4:3/16:9 or 16:10 */LBX/
Native/AUTO
*16:9 or 16:10 depend on Screen Type setting

n : 0/1/2/3 = Front-Deskt op/ Rear-Desktop/
Front-Ceiling/ Rear-Ceiling

a : 0/1 = Off/On

bbbb: LampHour

c: source 00/01/02/03/ 04/05 = None/VGA1/
VGA2/S-Video/Video/HDMI

dddd: FW version

e : Display mode 0/1/2/3/4/5/7/8/9

None/Presentation/Bright/Movie/sRGB/User/
Blackboard/Classroom/3D

EN-50

Troubleshooting

Refer to the symptoms and measures listed below before sending the pro­jector for repairs. If the problem persists, contact your local reseller or service
center. Please refer to "LED Indicator Messages" as well.

Start-up problems

If no lights turn on:



Be sure that the power cord is securely connected to the projector and the
other end

 Press the power button again.



Unplug the power cord and wait for a short while, then plug it in and press
the power

Image problems

If the searching source is displayed:



Press
an active input source.

 Be sure the external source is turned on and connected.



For a computer connection, ensure your notebook computer’s external
video port is

If the image is out of focus:



While displaying the on-screen menu, adjust the focus ring. (The image
size should
focus.)

 Check the projection lens to see if it needs cleaning.

If the image is flickering or unstable for a computer connection:

 Press

and adjust Frequency or Tracking.

Remote control problems

If the remote control does not operate:

 Be sure nothing is blocking the remote control receiver on the front of the

projector. Use the remote control within the effective range.

 Aim the remote control at the screen or at the front of the projector.



Move the remote control so it is more directly in front of the projector and
not as far to the side.

is plugged into an outlet with power.

button again.

SOURCE

on the projector or

Source

on the remote control

turned on. Refer to the computer manual.

not change; if it does, you are adjusting the zoom, not the

MENU

on the projector or

Menu

on the remote control

, go to Signal

to select

EN-51

LED Indicator Messages

Projector Status POWER TEMP LAMP

Standby (Eco mode) Blue solid Off Off
Standby (Active mode) Blue flashing Off Off

Flashing 30
seconds after

Normal running mode

Normal cooling Blue solid Blue solid Red solid
Lamp ignition failed Blue solid Off Red flashing
Lamp life end Blue solid Off Red solid
Temp error Blue solid Blue flashing Off
Fan error Blue solid Blue solid Off
Color wheel or DMD

error

Quick resume

+

Eco

powering on and
then become
solid blue

Blue flashing Blue flashing Red flashing

Blue flashing
(0.25 sec off then

0.25 sec on for
100 sec.)

Blue flashing Blue flashing Off

Off Off

Off Off

EN-52

Optoma Global Offices

For service or support please contact your local office.

USA

3178 Laurelview Ct.
Fremont, CA 94538, USA 888-289-6786
www.optomausa.com [e-mail]

Canada

5630 Kennedy Road, Mississauga, 905-361-2582
ON, L4Z 2A9, Canada 905-361-2581
www.optoma.ca [e-mail]

Europe

42 Caxton Way, The Watford Business
Park

Watford, Hertfordshire,
WD18 8QZ, UK [phone]
www.optoma.eu [phone]
Service Tel : [phone] [e-mail]

France

Batiment E [phone]
81-83 avenue Edouard Vaillant [phone]
92100 Boulogne Billancourt, France [e-mail]

Spain

C/ Jose Hierro,36 Of. 1C [phone]
28522 Rivas VaciaMadrid, [phone]
Spain

Deutschland

Wiesenstrasse 21 W [phone]
D40549 Dusseldorf, [phone]
Germany [e-mail]

EN-53

Scandinavia

Lerpeveien 25 [phone]
3040 Drammen [phone]
Norway [e-mail]
PO.BOX 9515
3038 Drammen
Norway

Latin America

3178 Laurelview Ct.
Fremont, CA 94538, USA 888-289-6786
www.optoma.com.br www.optoma.com.mx

Korea

WOOMI TECH.CO.,LTD.
4F,Minu Bldg.33-14, Kangnam-Ku, +82+2+34430004
seoul,135-815, KOREA +82+2+34430005

Japan

東京都足立区綾瀬 3-25-18
株式会社オーエス
コンタクトセンター：0120-380-495

[e-mail]

www.os-worldwide.com

Taiw an

5F., No. 108, Minchiuan Rd. [phone]
Shindian City, [phone]
Taipei Taiwan 231, R.O.C. [e-mail]
www.optoma.com.tw asia.optoma.com

Hong Kong

Unit A, 27/F Dragon Centre,
79 Wing Hong Street, [phone]
Cheung Sha Wan, [phone]
Kowloon, Hong Kong www.optoma.com.hk

EN-54

中国
上海市长宁区
凯旋路 1205 号 5 楼

琉璃奥图码

[phone]
[phone]

www.optoma.com.cn

EN-55

Regulation & Safety Notices

This appendix lists the general notices of your projector.

FCC Notice

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
residential installation. This equipment generates, uses and can radiate radio
frequency energy and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, detectable by turning the equipment in question off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:

 Reorient or relocate the receiving antenna

 Increase the distance between the equipment and the receiver



Connect the equipment to an outlet on a different circuit than that which
the receiver is connected to

 Or consult the dealer or an experienced radio/TV technician for help.

Notice: Shielded cables

All connections to other computing devices must be made using shielded
cables to maintain compliance with FCC regulations.

Caution

Changes or modifications not expressly approved by the manufacturer could
void the user’s authority, which is granted by the Federal Communications
Commission, to operate this projector.

EN-56

Operation conditions

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:

1. This device may not cause harmful interference and

2. This device must accept any interference received, including interference
that may cause undesired operation.

Notice: Canadian users

This Class B digital apparatus complies with Canadian ICES-003.
Remarque a l°¶intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du
Canada.

Declaration of Conformity for EU countries

 EMC Directive 2004/108/EC (including amendments)
 Low Voltage Directive 2006/95/EC
 R & TTE Directive 1999/5/EC (if product has RF function)

Disposal instructions

Do not throw this electronic device
into the trash when discarding. To
minimize pollution and ensure
utmost protection of the global
environment, please recycle it.

EN-57

Remote Control

1

Switch

Switch to mouse mode when
the on-screen menus are close.

2

Source

Switch between input signals.

3

Four directional buttons

Use four directional buttons to
select items or make adjust­ments to your selection.

4

Left mouse

Perform the left button of the
mouse when mouse mode is
activated.

5

Keystone ( / )
Manually correct distorted
images resulting from an
angled projection.

6

Brightness

Display the setting bar for
adjustment of brightness.

7

Freeze

Freeze the projected image.

8

HDMI

Display HDMI signal.
(This function will not work if
product does not have HDMI)

9

S-Video

Display S-Video signal.

1

2

3

4

5

6

7
8
9

10
11

10

Page+

Perform page up function when
mouse mode is activated.

11

3D

Turn on or off 3D function.

12

Power

Turn the projector on or off.

13

Re-SYNC

Automatically synchronize the pro­jector to the input source.

12

13

14
15

16

17
18
19
20

21
22

EN-58

14

Enter

Confirmed selections.

15

Right mouse

Perform the right button of the
mouse when mouse mode is
activated.

16

Volume ( / )

Adjust the volume level.

17

Menu

Display on-screen display
menus.

18

ZOOM

Magnifies or reduces the pro­jected picture size.

19

AV mute

Cut off the AV Mute temporarily.
Only pressing AV Mute again
can output sound and image. If
any other buttons are pressed,
the projection image will
become abnormal and no
sound will be output.

20

Video

Display video signal.

21

VGA

Switch input source to VGA1 or
VGA2 by sequence.

22

Page-

Perform page down function
when mouse mode is activated.

EN-59
