ET766XE − Home Theater Projector
Portable Home Theater Projector
Breathtaking and powerful, the Optoma ET766XE home theater projector takes
high-definition, big-screen viewing to the next level. Portable at 5.1 lbs, the
ET766XE is capable of displaying a screen size of up to 300” for large group
viewing. With 2300 lumens, 3000:1 contrast ratio and 1080p compatibility, the
ET766XE unleashes power and performance to deliver pure viewing delight!
* 3D content can be viewed with DLP®Link™ 3D glasses when the projector is
connected to a computer with a compatible 3D graphics card. Please visit
www.optoma.com for more information.
Features
DLP® by Texas Instruments with BrilliantColor™ Technology
Bright images and high contrast ratio – 2300 ANSI lumens and
3000:1 contrast ratio (full on/full off)
Rapid power-on and shutdown – saving you time and money
Produces stunning images for high intensity gaming
Longer lamp life – up to 4000 hrs
Specifications
Display Type
Single 0.65” DMD DLP Technology by
Texas Instruments
Resolution
HD (1280x720)
Maximum Resolution
UXGA (1600 x 1200)
Brightness (Typical)
2300 ANSI Lumens
Contrast Ratio
3000:1 (Full On/Full Off)
Lamp Life and Type
4000/3000 Hours (STD/Bright)
185W P-VIP
Throw Ratio
1.55 to 1.7 (Distance/Width)
Projection Distance
3.28’ to 32.8’ (1.0 to 10m)
Image Size (Diagonal)
27.2” to 301” (0.69 to 7.65m)
Offset
112%
Displayable Colors
1.07 Billion
Uniformity
85%
Audio
2-Watt Speaker
Remote Control
IR Remote
User Controls
Complete On-Screen Menu
Adjustments in 23 Languages
Computer Compatibility
UXGA, WXGA, SXGA+, SXGA, XGA,
SVGA, VGA Resized, VESA, PC and
Macintosh Compatible
Video Compatibility
NTSC, PAL, SECAM, SDTV (480i),
EDTV (480p), HDTV (720p, 1080i/p)
3D Compatibility
120Hz frame sequential 3D for
resolutions up to 720p, 60Hz field
sequential 3D for resolutions up to
480i
Projection Lens
F=2.41-2.55, f=21.8-24mm, 1.1x
Manual Zoom and Focus
I/O Connectors
HDMI, VGA-In, S-Video, Composite
Video, Stereo Audio-In and RS-232
Security
Kensington® Lock Port, Security Bar
and Keypad Lock
Projection Method
Front, Rear, Ceiling Mount, Table Top
Weight
5.1 lbs (2.31kg)
Dimensions (W x H x D)
11.28” x 3.98” x 7.6”
(287 x 101 x 193 mm)
Noise Level (STD/BRIGHT)
28dB/30dB
Keystone Correction
±40° Vertical
Datasheet – ET766XE
NO FILTER
REQUIRED
Horizontal Scan Rate
15.3 - 91.1 KHz
Vertical Refresh Rate
24 - 120 Hz
Operating Temperature
41 to 104°F (5 to 40°C), 85% Max
Humidity
Power Supply
AC Input 100-240V, 50-60Hz,
Auto-Switching
Power Consumption
255 Watts (Bright), 207 Watts
(STD), <1 Watt (Standby)
Standard Accessories
AC Power Cord, Composite
Cable, VGA to Component
Cable, Remote Control, Batteries
for Remote, Lens Cap,
Multilingual CD-ROM User’s
Manual, Quick Start Card and
Warranty Card
Optional Accessories
HDMI cable, Ceiling Mount,
S-Video Cable, Composite Video
Cable, RS-232 Cable and
Panoview™ Series Screens
Warranty
1 Year Limited Parts and Labor,
90 Days on Lamp
UPC
796435 81 123 5
Accessory Part Numbers
Lamp: BL-FU185A
Remote: BR-3048N
Mount: BM-5001U
Case: BK-4006
© Copyright 2010 Optoma Technology, Inc. DLP® and the DLP logo are registered trademarks of Texas Instruments. All other trademarks are the property of their
respective owners. All specifications subject to change at any time.
