MOUNTING RACKS
CLASSIC
QUAD PAK
DA TA SHEET
Form 994-091019
Description
The PB32HQ I/O mounting rack is
designed to mate with the PAMUX 32
channel Brain Board (P/N B4). The PB32HQ
I/O mounting rack accommodates up to
eight Quad Pak I/O modules for a total of
32 channels of power I/O. The B4 Brain
Board plugs into a box connector on the
I/O mounting rack and is secured by
vertical card guides.
Specifications
Operating Temperature 0° to 70°
95% relative humidity, non-condensing
page 1/4
Part
Number
PB32HQ Quad 8-Module Rack with Header Connector for B4 Brain
Description
Interface Connectors:
Field
Logic
Host
System
Schematic
6-32 screw terminals for wires connecting the rack to field devices
70-pin box connector for brain
50-pin header connector for ribbon cable to host
50-pin header connector for ribbon cable to next rack or for termination
card on last rack
MOUNTING RACKS
CLASSIC
QUAD PAK
DA TA SHEET
Form 994-091019
Schematic (Continued)
page 2/4
MOUNTING RACKS
CLASSIC
QUAD PAK
DA TA SHEET
Form 994-091019
Dimensions
page 3/4
Fuses
The board contains the following fuses:
One 2 amp fuse for 5 volt power on rack (replacement part number FUSE02)
Two 5 amp fuses per module (replacement part number FUSE05)
© 1997–2009 Opto 22. All rights reserved. All trademarks, trade names, logos, and service marks referenced herein belong to their respective companies.
More About Opto 22
