Auto Zooming Tracking
Dome Cameras
User Manual
Auto Zooming Tracking Dome Camera User Manual
1
Contents
Section1 Instruction ..................................................................... 3
1.1 Production Introducing ................................................... 3
1.2 Character ....................................................................... 3
1.3 Function Description ...................................................... 4
1.4 Specification Comparison Chart .................................... 9
Section 2 Normal Operation ...................................................... 12
Section 3 Menu Configuration ................................................... 13
3.1 Main Menu ................................................................... 15
3.2 Select Language .......................................................... 15
3.3 System Information ...................................................... 16
3.4 Display Setup ............................................................... 17
3.4.1 Display Setup ........................................................... 17
3.4.2 Label Position .......................................................... 18
3.5 Dome Settings 1........................................................... 19
3.5.1 Dome Settings 1 ...................................................... 19
3.5.2 Camera Settings ..................................................... 19
3.5.3 Motion Setting .......................................................... 26
3.5.4 Power Up ........................................................... 29
3.5.5 Presets Setting .................................................. 30
3.5.6 Patterns Setting ................................................. 32
3.5.7 Zone Setting ...................................................... 33
3.5.8 Clears Setting .................................................... 35
3.5.9 Presets Number ................................................. 36
3.6 Dome Settings 2 Menu ................................................ 36
3.6.1 Alarms ................................................................ 37
3.6.2 Alarms Setting .................................................... 38
3.6.3 Aux Setting ......................................................... 40
Auto Zooming Tracking Dome Camera User Manual
2
3.6.4 Password Setting ............................................... 41
3.6.5 Windows Blanking ............................................. 43
3.6.6 Set Windows ...................................................... 44
3.6.7 Edit Windows Location ...................................... 45
3.6.8 Edit Windows Zoom ........................................... 46
3.6.9 Heater Setting .................................................... 47
3.6.10 Cruise Setting .................................................. 48
3.6.11 Tracking Setting ............................................... 49
3.6.12 Tracking Boundary ........................................... 51
3.7 Dome Label .................................................................. 52
3.8 Other Functions............................................................ 52
Auto Zooming Tracking Dome Camera User Manual
3
Section1 Instruction
1.1 Production Introducing
The dome cameras feature high position resolution, high
speed, low price and selectable communication protocols;
Widely used in surveillance system.
1.2 Character
Built-in English OSD Menu, by which you can change
dome parameter, set or call preset, and achieve auto tour,
pattern, auto scan etc.
The feature will define the activity when the dome
parks.
Integrated design making it high reliability.
Auto panning function with 256 preset positions.
RS-485 data communication.
Low noise design.
With its full 360º horizontal rotation, 180º vertical auto-flip
to follow object and surveillance of any subject is constant and
continuous.
The speed can be adjusted automatically according to
the zooming times.
Auto focus, Auto white balance.
Auto focus lens and auto white balance.
BLC Function.
Multi protocols (Pelco-P, Pelco-D, Kalate, etc).
Baud rate is changeable.
Alarm input, Alarm output, Alarm action.
Auto Zooming Tracking Dome Camera User Manual
4
The features password protection to prevent
unauthorized changes to the dome setting.
A set window can be reversed so that it is the only visible
tilt area of the scene. ll other parts of the tilt area of the scene will
be blanked.
Revolutionary motion tracking technology make it realize
intelligent surveillance easily with the help of alarming function
1.3 Function Description
(1) Setting the dome ID, Baud-rate and Protocol
Every controlling command has a target camera Address,
Baud-rate and Protocol, the camera only reacts the controlling
command in accordance with its own Address, Baud-rate and
Protocol.
(2) Object tracking
The dome can be manually controlled from the control system
by using the joystick on the controller to move the camera up and
down, right and left to follow objects under observation.
In default status AUTO IRIS and AUTO FOCUS control of
the lens will automatically adjust the picture image on alteration
of the background illumination to get a best view.
(3) Proportional Pan
Proportional pan automatically reduces or increases the pan
and tilt speeds in proportion to the zooming times. At telephoto
zoom settings, the pan and tilt speeds will be slower for a given
amount of joystick deflection then at wide zoom settings. This
keeps the image from moving too fast on the monitor when there
Auto Zooming Tracking Dome Camera User Manual
5
is a large amount of zoom.
(4) Auto Flip
When the dome camera tilts downward and goes just
beyond the vertical, the dome camera rotates 180 degrees
automatically. Afterwards, the dome camera starts moving
upward even you still hold joystick in the down position. Once
you let go of the joystick after the dome rotates, joystick control
returns to normal operation. The auto-flip feature is useful for
following a person who passes directly beneath the dome.
(5) Setup and call Preset
Preset function is that dome saves current horizontal angle
and title angle of pan/tilt, zoom and position parameters into the
memory. When necessary, dome calls up these parameters and
adjusts Pan/Tilt/Zoom accordingly so that the camera goes to
that position again. Operator can save and call up presets easily
and promptly by using keyboard controller or infrared controller.
This dome supports up to 256 presets.
(6) Lens Control
a. Zoom control
User can adjust camera‟s zoom wide or near by using
controller and get desired image.
b. Focus control
System defaults Auto Focus mode, in which the lens and
camera will automatically adjust the focus to give the best image.
Focus can also be controlled manually from the
controller if required.
Press FOCUS NEAR or FOCUS FAR key to manually
focus.
Auto Zooming Tracking Dome Camera User Manual
6
Focus can be manually controlled via keyboard or
matrix, please refer to control keyboard or matrix operation
manual for detailed operation.
When on manual focus status, operations such as
adjusting positions or preset setting will resume the camera to
auto focus status.
The camera will not auto focus in the following status.
Target is not in the center of image.
Targets are in near and far at the same time.
Target is of strong light object. Such as spotlight etc.
Target is behind the glass with water drop or dust.
Target moves too fast.
Target is too big, such as wall.
Target is too dark or vague.
c. Iris control
System defaults AUTO IRIS. Camera can adjust immediately
according to the alteration of back ground illumination to get a
steady image.
Users may adjust Iris manually by using a controller to get
required image quality.
Users can call back AUTO IRIS by moving the joystick.
(7) Auto Back-light Compensation
Lens has been divided to six areas for back light
compensation. In a strong light background, camera will auto
compensate the darker object and adjust light input from the
lighter area to avoid a mass image that usually presents a sharp
contrast of brightness and darkness.
(8) Auto White Balance
Auto Zooming Tracking Dome Camera User Manual
7
Camera can automatically adjust white balance according to
the alteration of background lightness to give a true color image.
(9) Backlight Compensation (BLC)
If a bright backlight presents, the subjects in the picture may
appear dark or as a silhouette. Backlight compensation
enhances objects in the center of the picture. The dome uses the
center of the picture to adjust the iris. If there is a bright light
source outside this area, it will change to white. The camera will
adjust the iris so that the object in the sensitive area is properly
exposed.
(10) Day and Night Function
The IR cut filter of camera module inside the dome can be
removed by sending special command, so that the camera can
change from color to mono. The picture is clear even if the
illumination is as low as 0.01Lux.
(11) Auto Cruise
The preset positions are programmed for recalled in
sequence. This feature is called auto cruise. Up 30 presets can
be set in each cruise tour.
(12) Patterns
A pattern is a saved moving course, the camera will repeat
its pan, tilt, zoom and preset functions that can be recalled with a
command from a controller or automatically by a programmed
function (alarm, park or power-up).
(13) Auto Scan
Make the dome scan 360º range in the current position.
(14) Random Scan
Auto Zooming Tracking Dome Camera User Manual
8
Make the dome random scan 360º range in the current
position.
(15) Frame Scan
This feature freezes the scene on the monitor when going to
a preset. This allows for smooth transition from one preset scene
to another.
(16) Zones Setting
A zone is a pan area, defined by a left and right limit, on the
360-degree pan plane. The spectra dome system is capable of
eight zones, each with a 6-character label.
(17) Alarms
Alarms input:
The dome has four alarm inputs, which can be programmed
as high, medium or low priority. When an alarm is received, an
input signal to the dome triggers the user-defined action (go to
preset, run pattern, etc.) programmed for the alarm.
Auxiliary output:
An auxiliary output is a programmable signal from the dome
back box that can trigger another device to operate. An auxiliary
output is programmable to trigger from an alarm or from a
controller.
(18) Password protection
The dome features password protection to prevent
unauthorized changes to the dome settings. You can open the
System Information and Display Setup screens, but cannot
access any of the Dome Settings menus.
(19) Windows blank
Auto Zooming Tracking Dome Camera User Manual
9
A set window can be reversed so that it is the only visible tilt
area of the scene. All other parts of the tilt area of the scene will
be blanked.
NOTE: Be the same with only the model of TRKPTZ-18NX,
TRKPTZ -26NX, TRKPTZ -18NX, TRKPTZ-26NX.
(20) Auto tracking
Revolutionary motion tracking technology making it realize
intelligent surveillance easily with the help of alarming function
1.4 Specification Comparison Chart
Auto Zooming Tracking Dome Camera User Manual
10
Model
TRKPTZ-
1801
TRKPTZ-
1802
TRKPTZ-
1803
TRKP
TZ-22
00PT
TRKPTZ-
22X
TRKPTZ-
23X
Signal Format
PAL/NTSC
Image Sensor
¼ inch color CCD
Horizontal Resolution
480 TVL
Video Out
1.0±0.2V
P-P
P/T Speed
Pan:0.05º～240º/sec;Tilt:0.03º～160º/sec
S/N Ratio
≥50DB
Sensitivity
1Lux
0.1Lux
0.01Lux
1Lux
0.1Lux
0.01Lux
IR cut Filter
No
Yes
No
Yes
AGC
Auto/Manual
BLC
Auto/Manual
Lens
F1.4-F3.0 f=4.1-73.8mm
/ F1.6-F3.8 f=3.5-91mm
F1.6-F3.8
f=4-88mm
F1.6-F3.7
f=3.6-82.8mm
Auto Zooming Tracking Dome Camera User Manual
11
Optical Zoom
18X
22X
23X
Digital Zoom
12X
8X
Panning
Range
Pan: 360ºContinuous;Tilt:-5º～ 92º
Preset
Number
256
Auto Cruise
Auto switch from 1 to 30 preset position sequentially
Patterns
4
Zone
8
Alarm input
4
Alarm output
2
Windows
blanking
8
Interface
RS-485
Baud Rate
1200bps , 2400bps, 4800bps, 9600bps , 19200bps
Address
0～255
Input voltage
24VAC
Input power
20W（Without Heater）/50W（With Heater）
Operating
Temperature
-25℃～ 70℃（ Without Heater） /-50℃～70℃（ With
Heater）
Dome Size
6 inch
Auto Zooming Tracking Dome Camera User Manual
12
Section 2 Normal Operation
These operating instructions cover the basic operation of the
dome and its features. When the dome is used with other
manufacturers‟ control system, please refer to the system
controller‟s instructions. In the event of special requirements
outside the scope of this document it is prefer to contact your
local distributor.
Below instructions are based on using control keyboard as
controlling device.
(1) Dome Self-testing after Powered up
After powered up, the dome will conduct reset procedure. In
this procedure, the dome firstly pans to the default horizontal
origin point, and finally tilts to the vertical 45° position to
complete the self-testing. After the dome stops, it means the
camera has completed the self-testing and is ready to receive
control commands.
(2) Pan and tilt: Move joystick up, down, right, left.
(3) Set up preset
Move to next position. Then press PRESET + NUM （preset
NO.）+ ENTER and the dome will save current horizontal angle
and title angle of pan / tilt / zoom and position parameters into
memory.
(4) Call preset
Press PRESET + NUM（Preset NO.）+ ENTER , and the
Auto Zooming Tracking Dome Camera User Manual
13
Presets 1
Function
Presets 2
80
Auto tracking
37
82
Auto switch sequentially among preset
positions
19
83
Clear all presets positions
20
95
Select main programming menu
28
97
Random scanning
30
98
Frame scanning
31
99
Start auto scanning
32
dome will calls these parameters saved in memoriy and adjust
Pan/Tilt/Zoom of the camera to that position.
Extended Presets
Note: For others dynamics controllers with only 64 or 40
presets. On the menu of PRESETS NUMBER, set it as 64 or 40.
Then you can use presets listed in „Presets 2‟ in stead.
(5) Zoom: You can press IN or OUT key continuously or
revolve the joystick to get desired zooming times.
(6) Focus: press FAR or NEAR key.
(7) Iris: Press OPEN or CLOSE key.
Section 3 Menu Configuration
You need to install the dome system before using this
Auto Zooming Tracking Dome Camera User Manual
14
manual. Please refer to the installation packet supplied with the
back box for installation instructions.
After installed properly, power up the camera. It will start a
configuration sequence. After the configuration is done, the
monitor will display as below.
PTOL：PELCO-D
COMM：2400,N,8,1
ADDR：0
This information will remain on the monitor until dome
operation begins.
Please refer to the following pages for more about how to
operate and program the camera.
Access main menu (preset 95): Please refer to the
Accessing Main Menu (Preset 95) section.
(1) Move joystick to position the cursor beside menu
selection.
(2) Move the joystick up or down to submenu/cursor
selections.
(3) Press iris Open to confirm selection.
(4) Press iris Close to cancel selection.
(5) Below instructions are based on using control keyboard
as control device.
Auto Zooming Tracking Dome Camera User Manual
15
MAIN MENU
< SYSTEM INFORMATION >
< DISPLAY SETUP >
< DOME SETTINGS 1>
< DOME SETTINGS 2>
<DOME LABLE>
RESET CAMERA
REBOOT SYSTEM
LANGUAGE ENGLISH
EXIT
3.1 Main Menu
Set 95# preset to access main menu.
Figure 3.1 MAIN MENU
Access other OSD menus:
(1) Move the joystick up or down to position the cursor
beside others OSD menus.
(2) Press iris Open to confirm selection.
3.2 Select Language
The language for the on-screen menus is selectable.
Available languages include English and Chinese. The factory
default language is English.
Changing the display language:
(1) In main menu move the joystick to position the cursor
beside LANGUAGE.
(2) Press iris Open. The cursor moves to the right, beside
the currently selected language.
Auto Zooming Tracking Dome Camera User Manual
16
SYSTEM INFORMATION
COMM 9600，N，8，1
ADDRESS 255
PROTOCOL PELCO-P
PRESETS NUMBER 256
LANGUAGE ENGLISH
TEMPERATURE 36°C
BACK
EXIT
(3) Move the joystick up or down to view selections. Press
iris Open to confirm selection. All on-screen menus are changed
into the selected language.
3.3 System Information
Move joystick to select <system information>, press Open to
confirm the system information menu shown as Fig 3.2.
Figure 3.2 SYSTEM INFORMATION
The system information screen shows dome language,
protocol, and other configuration information.
System information settings shown are not changeable in
this interface. It is for reference only.
Follow the following steps to display the system information
screen:
(1) Move the joystick to position the cursor beside SYSTEM
INFORMATION.
17
(2) Press iris Open.
DISPLAY SETUP
PRESET LABEL ON
ZONE LABEL ON
ZOOM ON
AZIMUTH/ELEVATION ON
CAMERA LABEL ON
<LABEL POSITION>
BACK
EXIT
3.4 Display Setup
3.4.1 Display Setup
Move joystick to select <DISPLAY SETUP>, press Open to
enter the display setup menu shown as Fig3.3.
Display setup enables you to program how labels are
displayed on the monitor. The following labels are available:
PRESET LABEL: Identifying preset.
ZONE LABEL: Identifying zone.
ZOOM: Identifying zooming times.
AZIMUTH/ELEVATION: Amount of pan from 0°and the
amount of tilt from 0°horizontal.
CAMERA LABEL: Identifying dome.
A preset label is displayed when a preset is called. A zone
label is displayed when the system moves into a zone. The zoom
Auto Zooming Tracking Dome Camera User Manual
Figure 3.3 DISPLAY SETUP
Auto Zooming Tracking Dome Camera User Manual
18
ZONE CAMERA PRESET
SAVE
RESET
AZIMUTH
ZOOM
ratio label is displayed when zoom is activated.
Azimuth/elevation and direction labels are displayed when
pan/tilt is activated. The dome label is displayed when the dome
label is activated.
The following settings are available foe each label:
OFF: The label is not displayed when activated.
ON: The label shows when activated.
3.4.2 Label Position
Labels can be placed anywhere on the monitor. This feature
enables you to customize the place of labels on monitor screen.
To set a label position:
(1) Move joystick to position the cursor beside a label.
(2) Press iris Open.
(3) Move joystick to move the label up, down, left, or right.
(4) Press iris Open.
(5) Repeat steps 1 through 4 to position other labels.
(6) Move the cursor to Save and press iris Open to save
settings and return to display setup menu.
Figure 3.4 Label Position
Auto Zooming Tracking Dome Camera User Manual
19
DOME SETTINGS1
<CAMERA>
<MOTION>
<POWER UP>
<PRESETS>
<PATTERNS>
<ZONES>
<CLEAR>
PRESET NUMBER 256
BACK
EXIT
3.5 Dome Settings 1
3.5.1 Dome Settings 1
Move joystick to select <DOME SETTING 1>, press Open to
enter the dome setting1 menu shown as Fig3.5.
Figure 3.5 Dome settings 1
3.5.2 Camera Settings
Move joystick to select <CAMERA>, press Open to enter
the camera menu shown as Fig3.6.
Auto Zooming Tracking Dome Camera User Manual
20
CAMERA
ZOME LIMIT X46
BACKLIGHT COMP ON/OFF
<PROGRAM AE MODE>
<OTHERS>
BACK
EXIT
Figure 3.6 CAMERA
ZOOM LIMIT:
Zoom limit enables you to define a limitation on zooming
times.
BACKLIGHT COMPENSATION (BLC):
If a bright backlight presents, the subjects in the picture may
appear dark or as a silhouette. Backlight compensation
enhances objects in the center of the picture. The dome uses the
center of the picture to adjust the iris. If there is a bright light
source outside this area, it will change to white. The camera will
adjust the iris so that the object in the sensitive area is properly
exposed.
There are two backlight compensation settings:
ON: Backlight compensation is activated.
OFF (default): Backlight compensation is not activated.
3.5.2.1 Program AE Mode
Move joystick to select < PROGRAM AE CORTROL >, press
Open to enter the PROGRAM AE CORTROL menu shown as
Fig3.7
Auto Zooming Tracking Dome Camera User Manual
21
PROGRAM AE CORTROL
AE MODE AUTO
LOW LIGHT MODE AUTO
LOW LIGHT LIMIT 1/50
IRIS LEVEL F2.0
AGC LEVEL 0dB
BIRGHT LEVEL 0dB/F2.0
BACK
EXIT
PROGRAM AE COORTROL
PROGRAM AE MODE AUTO
IR CUT FILTER INISERT/REMOVE
BACK
EXIT
Figure 3.7A PROGRAM AE CORTROL
Figure 3.7 B PROGRAM AE CORTROL
Note: Figure 1.7A shows program AE mode, it is only for
models names TRKPTZ18XX and TRKPTZ26XX. Figure 1.7B
shows program AE mode, it is only for models named
TRKPTZ22XX and TRKPTZ23XXPNT.
(Ⅰ) Figure 3.7A PROGRAM AE MODE setting for models
named TRKPTZ18XX and TRKPTZ26XX.
AE MODE:
Settings include: AUTO, MANUAL , SHUTTER, IRIS, and
BRIGHT.
LOW LIGHT MODE:
Settings include: AUTO and MANUAL.
Auto Zooming Tracking Dome Camera User Manual
22
LOW LIGHT LIMIT
Low light limit is the maximum duration, it is in fractions of a
second, that electronic shutter will remain open in low light
conditions. The default setting is 1/50.
Settings include:1/2, 1/3, 1/6, 1/12, 1/25, 1/50, 1/75, 1/100,
1/120, 1/150, 1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750,
1/2500, 1/3500, 1/6500, 1/10000.
IRIS LEVEL
Iris level is the lens function that automatically opens and
closes the iris in response to changing light conditions. The
default setting is F2.0.
Settings include: F2.0, F1.6 , F1.4, Close, F22, F19, F16,
F14, F11, F 9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4.
AGC LEVEL
AGC(Automatic Gain Control) automatically adjusts the
amount of video amplification to maintain a Full 1-volt
peak-to-peak video signal output. The default setting is 0 dB.
Settings include: 0dB, 2 dB, 4 dB, 6dB, 8 dB, 10 dB, 12 dB,
14 dB, 16 dB, 18 dB, 20 dB, 22 dB, 24 dB, 26 dB, 28 dB.
BRIGHT LEVEL
The default setting is 0 dB /F2.0.
Settings include: 0 dB /F2.0, 0 dB /F1.6, 0 dB /F1.4, 2 dB /
F1.4, 4 dB / F1.4, 6 dB / F1.4, 8 dB / F1.4, 10 dB/ F1.4, 12 dB/
F1.4, 14 dB/ F1.4, 16 dB/ F1.4, 18 dB/ F1.4, 20 dB/ F1.4, 22 dB/
F1.4, 24 dB/ F1.4, 26 dB/ F1.4, 28 dB/ F1.4, Close, 0 dB /F22, 0
dB /F19, 0 dB /F16, 0 dB /F14, 0 dB /F11, 0 dB /F9.0, 0 dB /F 8.0,
0 dB /F6.8, 0 dB /F5.6, 0 dB /F4.8, 0 dB /F4.0, 0 dB /F3.4, 0 dB
/F2.8, 0 dB /F2.4.
NOTE: LOW LIGHT LIMIT, IRIS LEVEL, AGC LEVEL
BRIGHT LEVEL can set only when AE MODE and LOW LIGHT
MODE are set as Manual.
(Ⅱ) Figure 3.7B PROGRAM AE MODE settings are for
MODEL TRKPTZ18XX and TRKPTZ26XX.
AE MODE
Settings include: AUTO, AU+IR1, AU+IR2, AU+DSS,
Auto Zooming Tracking Dome Camera User Manual
23
AU+DSS+IR1, AU+DSS+IR2, AU+DSS+IR3, SHUTTER PR,
IRIS PRIO, and AGC PRIORI.
IR CUT FILTER
Settings include: IN and OUT.
LOW LIGHT LIMIT
Settings include: 1/1.5, 1/3, 1/6, 1/12, 1/25, 1/50.
SHUTTER
Settings include: 1/30000, 1/10000, 1/4000, 1/2000, 1/1000,
1/500, 1/250, 1/150, 1/100, 1/50, 1/25, 1/12, 1/6, 1/3, 1/1.5.
IRIS LEVEL
Iris level is the lens function that automatically opens and
closes the iris in response to changing light conditions. The
default setting is F1.6.
Settings include: F1.6, F2.2, F3.2, F4.4, F6.4, F8.8, F12, F17,
F24, F34.
AGC LEVEL
AGC(Automatic Gain Control) automatically adjusts the
amount of video amplification to maintain a Full 1-volt
peak-to-peak video signal output. The default setting is 0 dB.
Settings include: 0dB, 6dB, 12dB, 18dB, 24dB, and 30dB
3.5.2.2 Other Menu
Move joystick to select < others >, press Open to enter the
others menu shown as Fig3.8.
Auto Zooming Tracking Dome Camera User Manual
24
OTHERS
IR CUT FILTER AUTO
IR CUT FILTER COLOUR
AUTO IRIS ON
SHARPNESS ON
SHARPNESS LEVEL 5
AUTO WHITE BALANCE ON/OFF
R GAIN 214
B GAIN 164
BACK
EXIT
OTHERS
AUTO IRIS ON
AUTO IRIS LEVEL 91
AUTO IRIS PEAK 16
SHARPNESS ON
SHARPNESS LEVEL 39
AUTO WHITE BALANCE ON
R GAIN 652
B GAIN 427
BACK
EXIT
Figure 3.8A OTHER MENU
Note: Figure 3.8A shows Other Menu only for models named
TRKPTZ18XX and TRKPTZ26XX. Figure 3.8B shows Other
Menu only for the models named TRKPTZ22XX and
TRKPTZ23XX.
AUTO IRIS:
Auto iris is the lens function that automatically opens and
Figure 3.8B OTHER MENU
Auto Zooming Tracking Dome Camera User Manual
25
closes the iris in response to changing light conditions.
Program the auto iris to operate automatically or at a
user-defined level.
OFF: Auto iris is disabled, and for manually control only.
AUTO: The iris is adjusted automatically to produce a
constant video output as determined by the Auto Iris level setting.
NOTE: If auto iris is in auto mode, it will remain that status
until the iris is manually opened or closed. The dome will return
to auto mode when it pans or tilts more than 15 degrees.
AUTO SHARPNESS:
Auto sharpness enhances picture details by increasing the
aperture gain of the camera and sharpening the edges in the
picture.
There are two settings:
ON (default): The camera automatically keeps at a normal
sharpness mode.
OFF: The sharpness of the picture is set manually by
programming the sharpness level.
AUTO WHITE BALANCE:
This feature automatically processes the viewed image to
retain color balance over a color temperature range. The default
setting for auto white balance is ON.
R GAN: Adjusts the picture output in the red range. As you
change the value, the color changes on your monitor.
B GAN: Adjusts the picture output in the blue range. As you
Auto Zooming Tracking Dome Camera User Manual
26
MOTION
AUTO FLIP ON/OFF
PROPORTIONAL PAN ON/OFF
PARK TIME（MINUTES） 0
PARK ACTION NONE
SCAN SPEED（DEG/S） 1
< SET SCAN>
< MANUAL LIMIT>
< SET AZIMUTH ZERO>
< CLEAR AZIMUTH ZERO>
BACK
EXIT
change the value, the color changes on your monitor.
3.5.3 Motion Setting
Move joystick to select <MOTION >, press Open to enter the
motion menu shown as Fig3.9.
AUTO FILP:
When the dome camera tilts downward and goes just
beyond the vertical, the dome camera rotates 180 degrees
automatically. Afterwards, the dome camera starts moving
upward even you still hold joystick in the down position. Once
you let go of the joystick after the dome rotates, joystick control
returns to normal operation. The auto-flip feature is useful for
following a person who passes directly beneath the dome.
There are two auto flip modes:
ON (default): Auto flip mode enabled.
OFF: Auto flip mode disabled.
FIGURE 3.9 MOTION MENU
Auto Zooming Tracking Dome Camera User Manual
27
PROPORTIONAL PAN:
Proportional pan automatically reduces or increases the pan
and tilt speeds in proportion to the zooming times. At telephoto
zoom settings, the pan and tilt speeds will be slower for a given
amount of joystick deflection then at wide zoom settings. This
keeps the image from moving too fast on the monitor when there
is a large amount of zoom.
There are two proportional pan modes:
ON (default): Enables the proportional pan mode.
OFF: Disables proportional pan mode. The pan speed will
not depend on the zooming times.
PARK TIME:
This feature enables the dome to operate a specified activity
(scan, preset, or pattern) after a programmed time of idleness.
Park time can be programmed from 1 minute to 720
minutes (12 hours), or set to zero, which disables this feature.
The default setting is zero.
PARK ACTION:
This feature will define the activity when the dome parks.
The following settings are available:
NONE (default): No action.
AUTO SCAN: Dome starts auto scan operation.
RANDOM SCAN: Dome starts frame scan operation.
FRAME SCAN: Dome starts frame scan operation.
PRESET 1: Dome goes to preset 1.
PRESET 8: Dome goes to preset 8.
PANTTERN 1: Dome runs pattern1.
PANTTERN 2: Dome runs pattern2.
Auto Zooming Tracking Dome Camera User Manual
28
PANTTERN 3: Dome runs pattern3.
PANTTERN4: Dome runs pattern4.
SCAN SPEED:
Scan speed is that the dome will pan when in a FRAME
SCAN mode. Scan speed is adjustable from 1 to 32 via the
programming menu.
SET SCAN STOPS:
Set Scan Stops are programmable stops that limit the pan
range of the dome. There must be two limits, a left and a right, to
define an area. The dome reverses direction frame scanning
when a limit stop is reached.
To set scan stops:
(1) Move joystick to position the cursor beside set scan
stops.
(2) Press iris Open.
(3) Follow the directions displayed on the monitor.
CLEAR SCAN STOPS:
To clear scan stops:
(1) Move joystick to position the cursor beside clear scan
stops.
(2) Press iris Open.
(3) Follow the directions displayed on the monitor.
SET MANUAL LIMIT:
<Set manual limit > is to set the P/T/Z‟s moving range.
To set manual limit:
(1) Move joystick to position the cursor beside set manual
limit.
(2) Press iris Open.
Auto Zooming Tracking Dome Camera User Manual
29
POWER UP
POWER UP ACTION NONE
BACK
EXIT
(3) Follow the directions displayed on the monitor.
SET AZIMUTH ZERO:
Azimuth is the pan angle from 0°to 359°.Azimuth zero is
the pan position you specify to be the 0°point. Azimuth zero is
normally set to magnetic north. Once set, azimuth and compass
readings are based on the set Azimuth Zero point.
To program azimuth zero:
(1) Move joystick to position the cursor beside set azimuth
zero.
(2) Press iris Open.
(3) Follow the directions displayed on the monitor.
CLEAR AZIMUTH ZERO:
(1) Move joystick to position the cursor beside CLEAR
AZIMUTH ZERO.
(2) Press iris Open
(3) Follow the directions displayed on the monitor.
3.5.4 Power Up
Move joystick to select <power up>, press Open to enter the
power up menu shown as Fig3.10.
POWER UP ACTION:
Figure 3.10 POWER UP
Auto Zooming Tracking Dome Camera User Manual
30
PRESETS
PRESET NUMBER 1
…PRESET NOT DEFINEO…
< EDIT PRESET LABEL >
< EDIT PRESET SCAENE >
< CLEAR PRESET >
BACK
EXIT
This setting defines a specific activity (scan, preset, pattern)
to be performed after the dome is powered up.
Following settings are available:
NONE (default): No action.
AUTO SCAN: Dome starts auto scan operation.
RANDOM SCAN: Dome starts random scan operation.
FRAME SCAN: Dome starts frame scan operation.
PRESET 1: Dome goes to preset 1.
PRESET 8: Dome goes to preset 8.
PATTERN 1:Dome runs pattern 1.
PATTERN 2:Dome runs pattern 2.
PATTERN 3:Dome runs pattern 3.
PATTERN 4:Dome runs pattern 4.
3.5.5 Presets Setting
Move joystick to select <PRESETS>, press Open to enter
the presets menu shown as Fig3.11.
The dome camera has 64 programmable preset positions.
Follow below steps to program a preset.
Figure 3.11 PRESET
Auto Zooming Tracking Dome Camera User Manual
31
PRESET NUMBER 1
PRESET LABLE 1 - - - - -
0 1 2 3 4 5 6 7 8 9 Y Z y z
A B C D E F G H I J K L M N O P Q R S T U V W X
a b c d e f g h I j k l m n o p q r s t u v w x
INPUT MODE CHARACTER
OK CN SP BP
(1) Select preset number:
a. Move joystick to position the cursor beside PRESET
NUMMBER, press iris Open.
b. Move the joystick up or down to view selections. Press
iris Open to confirm selection.
(2) Edit preset label.
a. Move joystick to position the cursor beside EDIT Preset
label.
b. Press iris Open. It will show:
Figure 3.12 CHARACTER INPUT
c. Move joystick to position the cursor beside a character.
Press iris Open to confirm selection. To clear a character,
position the cursor beside BPE, and then press iris Open.
press iris Open to save and return to the Preset menu.
press iris Open to cancel and return to the Preset menu.
d. After the label is inputted, move the cursor to Ok, then
e. After the label is inputted, move the cursor to CE, then
Auto Zooming Tracking Dome Camera User Manual
32
PATTERNS
PATTERN NUMBER 1
<PROZGRSM PATTERN>
<CLEARE PATTERN>
BACK
EDIT
(3) Edit preset scene:
a. Move joystick to position the cursor beside EDIT
PRESET SCENE.
b. Press iris Open.
c. Follow the direction displayed on the monitor.
(4) Clear a preset:
a. Move joystick to position the cursor beside CLEAR
PRESET.
b. Press iris Open.
c. Follow the direction displayed on the monitor.
3.5.6 Patterns Setting
Use stick to select <patterns> Open to enter the patterns
menu shown as Fig3.13.
PROGRAME PATTERN:
A pattern is function that the camera can save its moving
course, and will repeat that course when demanded.
To program a pattern:
(1) Move joystick to position the cursor beside PATTERN
NUMBER, and then press iris Open.
Figure 3.13 PATTERNS
Auto Zooming Tracking Dome Camera User Manual
33
ZONES
ZONE NUMBER 1
…ZONE NOT DEFINEO…
<EDIT ZONE LABEL>
<EDIT ZONE>
ZONE ENABLED ON
<CLEAR ZONE >
BACK
EXIT
(2) Move the joystick up or down to view selections. Press
iris Open to confirm selection.
(3) Move joystick to position the cursor beside PROGRAM
PATTERN.
(4) Press iris Open.
(5) Follow the directions displayed on the monitor.
After a pattern is programmed, the remaining storage
percentage will be displayed on the screen. This is the amount of
memory available to program the remaining patterns.
CLEAR PATTERN:
(1) Move joystick to position the cursor beside CLEAR
PATTERN.
(2). Press iris Open.
(3) F0llow the directions displayed on the monitor.
3.5.7 Zone Setting
Move joystick to select <ZONES>, then press Open to enter
the zones menu shown as Fig 3.14.
Figure 3.14 ZONES SETTING
Auto Zooming Tracking Dome Camera User Manual
34
ZONE NUMBER 1
ZONE LABLE 1 - - - - -
0 1 2 3 4 5 6 7 8 9 Y Z y z
A B C D E F G H I J K L M N O P Q R S T U V W X
a b c d e f g h I j k l m n o p q r s t u v w x
INPUT MODE CHARACTER
OK CN SP BP
A zone is pan area, defined by a left and right limit on the
360-degree pan plane. There are altogether eight zones, each
can be with a 6-character label.
TO program a zone:
(1) Move joystick to position the cursor beside ZONE
NUMBER. Press iris Open.
(2) Move the joystick up or down to view selections. Press
iris Open to confirm selection.
(3) Move joystick to position the cursor beside EDIT ZONE.
(4) Press iris Open. The Zone programming window will
show on the monitor.
(5) Follow the directions displayed on the monitor. After the
left stops and right limit stops are set, the Zones menu reappears
with the ZONE ENABLED option set to be ON.
To edit a zone label:
(1) Move joystick to position the cursor beside EDIT ZONE
LABEL.
(2) Press iris Open. It will show as follows:
Figure 3.15 ZONE SETTING
Auto Zooming Tracking Dome Camera User Manual
35
CLEARS
CLEAR ZONES
CLEAR PARESETS
CLEAR PATTERNS
RESTORE FACTORY DEFAULTS
BACK
EXIT
(3) Move joystick to position the cursor beside a character.
Press iris Open to confirm selection. To clear a character,
position the cursor beside BP, and then press iris Open.
(4) When a label is inputted, move the cursor to Ok, then
press iris Open to save and return to the Preset menu.
(5) When a label is inputted, move the cursor to CN, then
press iris Open to cancel and return to the Preset menu.
To clear a zone:
(1) Move joystick to position the cursor beside CLEAR
ZONE.
(2) Press iris Open. Follow the instructions on the screen.
Note: The ZONE NUMBER 9 is the dome‟s label.
3.5.8 Clears Setting
Move joystick to select <CLEARS>, then press Open to
enter the clears menu shown as Fig 3.16.
CLEAR ZONES:
Figure 3.16 CLEARS SET
Clear all zones. To clear a specific zone, please refer to
Auto Zooming Tracking Dome Camera User Manual
36
DOME SETTINGS 2
<ALARMS>
<AUX>
<PASSWORD>
<WINDOWS BLANKING>
<HEATER SETTING>
CRUISE SETTING
TRACKING SETTING
BACK
EXIT
ZONES section.
CLEAR PRESETS:
Clear all presets. To clear a specific preset, please refer to
the PRESETS section.
CLEAR PATTERNS:
Clear all patterns. To clear a specific pattern, please refer to
the PATTERNS section.
RESTORE FACTORY DEFAULTS:
This is to restore leaving-factory‟s default settings.
3.5.9 Presets Number
This is to set the dome‟s preset number.
3.6 Dome Settings 2 Menu
Move joystick to select <DOME SETTINGS 2>, then press
Open to enter the dome settings 2 menu shown as Fig 3.17.
Auto Zooming Tracking Dome Camera User Manual
37
ALARMS
ALARM NUMBER 1
SEQUENCE(SECS) 1
< ALARM SETTINGS >
<CLEAR SET>
BACK
EXIT
3.6.1 Alarms
Move joystick to select <ALARMS>, then press Open to
enter the alarms menu shown as Fig 3.18.
The dome has seven alarm inputs, which can be
programmed as high, medium or low priority. When an alarm is
received, the inputted signal to the dome triggers the
user–defined action (go to preset, run pattern, etc.) programmed
for the alarm.
There are three alarm settings:
ALARM NUMBER:
Use this to select alarms number.
SEQUENCE<SECS>:
This is the time the dome will perform an alarm activity when
more than one alarm of the same priority occurs at the same
time.
RESET DELAY<SECS>:
Figure 3.17 DOME SETTINGS
Figure 3.18 ALARMS
Auto Zooming Tracking Dome Camera User Manual
38
ALARM NUMBER 1
ALARM PRIORITY LOW
ALARM ACTION NONE
ACTIVATE AUX OPEN
ALARM CONTACT OPEN
BACK
EXIT
This is the length of time the dome considers the alarm to be
active after it has physically cleared.
3.6.2 Alarms Setting
Move joystick to select <ALARM NUMBER>, then press
Open to enter the alarm number menu shown as Fig 3.19.
Figure 3.19 ALARM SETTINGS
Follow below steps to program alarm settings.
Select alarm number:
(1) a. Move joystick to position the cursor the cursor beside
ALARM NUMBER.
b. Press iris Open.
c. Move the joystick up or down to view selections. Press iris
Open to confirm selection.
(2) Move the joystick to position the cursor beside Alarm
Settings. Press iris Open.
Select alarm priority:
(1) Move joystick to position the cursor beside Alarm Priority.
Auto Zooming Tracking Dome Camera User Manual
39
(2) Press iris Open.
(3) Move the joystick up or down to view the available
selections. Available settings include HIGH, MEDIUM, and LOW
(default). If multiple alarms with different priorities are active at
the same time, the dome will only go to the alarms with the
highest priority.
(4) Press iris Open to confirm selection.
Set alarm action:
(1) Move joystick to position the cursor beside Alarm action.
(2) Press iris Open.
(3) Move the joystick up or down to view the available
selections. Below are the settings for alarm action:
NONE: No action when alarm is triggered.
PRESET: Dome goes to the preset that is the same as the
alarm number. E.g. preset 1 will go to Alarm 1.
PATTERN 1: Dome runs pattern 1 when alarm is triggered.
PATTERN 2: Dome runs pattern 2 when alarm is triggered.
PATTERN 3: Dome runs pattern 3 when alarm is triggered.
PATTERN 4: Dome runs pattern 4 when alarm is triggered.
AUTO SCAN: Dome starts auto scan operation when alarm
is triggered.
RANDOM SCAN: Dome starts RANDOM scan operation
when alarm is triggered.
FRAME SCAN: Dome starts FRAME scan operation when
alarm is triggered.
TRACKING: Dome calls preset and start auto tracking.
Tracking function only available with the models named
TRKPTZ18XXPT, TRKPTZ22XXPT, TRKPTZ23XXPNT and
TRKPTZ26XXPNT.
(4) Press iris Open to confirm selection.
Auto Zooming Tracking Dome Camera User Manual
40
Set auxiliary to activate:
(1) Move joystick to position the cursor beside ACTIVATE
AUX.
(2) Press iris Open.
(3) Move the joystick up or down to view the following
available selections.
OFF (default): Not activated.
1:An alarm action will close AUX 1.
2: AN alarm action will close AUX 2.
(4) Press iris Open to confirm selection.
Set alarm contact:
(1) Move joystick to position the cursor beside ALARM
CONTACT.
(2) Press iris Open.
(3) Move the joystick up or down to view the following
available selections.
OFF (default): close
ON: open.
(4) Press iris Open to confirm selection.
3.6.3 Aux Setting
Move joystick to select <AUX>, then press Open to enter the
aux menu shown as Fig 3.20.
Auto Zooming Tracking Dome Camera User Manual
41
AUX
DWELL TIME<SECS> 1 0
DWELL TIME<SECS> 2 0
BACK
EXIT
Figure 3.20 AUX
An auxiliary output is a programmable signal from the dome
back box that can trigger another device to operate. An auxiliary
out put is programmable to trigger from an alarm or from a
controller.
An AUX 1 command from the controller will place a ground
at the output of AUX 2 to operate the device that is connected to
it.
Setting include: 0~30secs.
An AUX 2 command from the controller will place a ground
at the output of AUX 2 to operate the device that is connected to
it.
Setting include: 0~30secs.
3.6.4 Password Setting
Move joystick to select <PASSWORD>, then press Open to
enter the password menu shown as Fig 3.21.
Auto Zooming Tracking Dome Camera User Manual
42
PASSWORED
EBABLE PASSWORD OFF
<EDIT PASSWORD>
BACK
EXIT
PLEASE INPUT OLD PASSWORED
PASSWORD
1 2 3 4 5 6 7 8 9 0
CLEAR
ENTER
EXIT
Figure 3.21 PASSWORED
This setting protects it from unauthorized changes to the
dome settings.
ENABLE PASSWORD:
Open or close the password features.
EDIT PASSWORD (Four Numbers):
(1) Move joystick to position the cursor beside a number.
Press iris Open to confirm selection.
(2) When password is inputted, move the cursor to ENTER
and press iris Open comes to the PLEASE INPUT NEW
PASSWORED.
(3) Input four new passwords, move the cursor to ENTER
then press iris Open and comes to PLEASE INPUT NEW
PASSWORED. Input four new passwords.
Figure 3.22 EDIT PASSWORD
Auto Zooming Tracking Dome Camera User Manual
43
WINDOWS BLANKING
STYLE GRAY
BLANK ALL ABOVE OFF
BALANK ALL BELOW OFF
<SET WINDOWS>
BACK
EXIT
3.6.5 Windows Blanking
Move joystick to select <WINDOWS BLANKING>, then
press Open to enter the windows blanking menu shown as Fig
3.23.
Figure 3.22 WINDOWS BLANKING
Window blanking enables you to program up to eight,
four-sided, user-defined areas that cannot be viewed by the
operator of the dome system. A blanked area will move with pan
and tilt functions and automatically adjust in size according to
zoom times.
Style:
The dome has two styles for window blanking, GRAY and
SMEAR. If style is set to gray, the blanked area is covered with a
solid gray window. If smear is selected images behind the
window will be noticeable but not distinguishable.
BLANK ALL ABOVE/BLANK ALL BELOW:
The dome camera has two style modes for window blanking,
GRAY and SMEAR. If style is set to gray, the blanked area is
covered with a solid gray window. If smear is selected images
behind the window will be noticeable but not distinguishable.
Auto Zooming Tracking Dome Camera User Manual
44
BLANK ALL ABOVE
BLANK ALL BELOW
OFF
No Blanking
OFF
No Blanking
0
-5º~10º
0
5º~92º
10
-5º~25º
10
-5º~92º
20
-5º~35º
20
5º~92º
30
-5º~45º
30
15º~92º
40
-5º~55º
40
25º~92º
50
-5º~65º
50
35º~92º
60
-5º~75º
60
45º~92º
70
-5º~85º
70
55º~92º
80
-5º~95º
80
70º~92º
SET WINDOWS
WINDOWS NUMBER 1
<EDIT WINDOWS LOCATION>
<EDIT WINDOW ZOOM >
ENABLE WINDOWS OFF
CLEAR WINDOWS
BACK
EXIT
Blanking Parameters:
3.6.6 Set Windows
Move joystick to select <SET WINDOWS>, then press Open
to enter the set windows menu shown as Fig 3.24.
Windows Number: 1 ~ 8.
<Edit windows location>: Edit the location of windows
Figure 3.24 SET WINDOWS MENU
Auto Zooming Tracking Dome Camera User Manual
45
EDIT WINDOWS LOCATION
IRIS OPEN TO CONTINUE
IRIS CLOSE TO CANCEL
blanking
<Edit window zoom>: set the zoom of the blanking. The
blanking will take effect when the video is zoomed to this time or
above.
Enable Windows: Enable or disable the current blanking
Clear windows: clear the current windows blanking
Operation:
1. Move joystick to select a item
2. Press iris Open
3. Move joystick to select parameters
4. Press Open
3.6.7 Edit Windows Location
Move joystick and move cursor to < EDIT WINDOWS
LOCATION >, then press open to enter the menu as Fig 3.25.
Operation：
1. From Fig 3.25, move cursor to make sure it is at the
center points of blanking and coordinate.
Figure 3.25 EDIT WINDOWS MENU
Auto Zooming Tracking Dome Camera User Manual
46
EDIT WINDOW LOCATION
EDIT WINDOWS
IRIS OPEN TO CONTINUE
IRIS CLOSE TO CANCEL
2. From the menu of Fig. 3.25, press Close to return to the
menu of Fig 3.24
3. From the menu of Fig. 3.25, press Open to enter menu of
Fig 3.26 to edit the windows location.
Figure 3.26 EDIT WINDOW LOCATION
4. From the EDIT WINDOW LOCATION menu shown in Fig
3.26：
Move joystick left; zoom in (left/right) from the zone center.
Move stick right; zoom in (left/right) from the zone center.
Move stick up; zoom in (up/down) from the zone center.
Move stick down; zoom in (up/down) from the zone center.
5. After the zone is set, press Open to save the settings and
return to menu of Figure3.24.
3.6.8 Edit Windows Zoom
From the menu of Figure 3.24, move stick and move cursor
to <Edit Window Zoom>, press Open to enter below menu:
Pan the joystick to adjust the zoom times.
Figure 3.27 EDIT WINDOWS
Auto Zooming Tracking Dome Camera User Manual
47
HEATER SETTING
HEATER DISPLAY ON
HEATER MODE AUTO
TEMPERATUEE SET 33℃
BACK
EXIT
Press Close to discard the setting and return to Fig 3.24
Press Open to save the setting and return to Fig 3.24.
3.6.9 Heater Setting
From the dome setting 2 menu shown in Fig3.17, move
joystick and move cursor to HEATER SETTING, press Open to
enter the following menu (Figure 3.28).
HEATER DISPLAY:
Heater display shows heater state.
ON: Screen will display heater state.
OFF: Screen will not display heater state.
HEATER MODE:
Heater mode is to set the heater‟s startup mode.
AUTO: Heater starts when temperature is lower than lower
temperature.
OFF: Heater is closed.
ON: Heater is open.
TEMPERATURE SET:
Figure 3.28 HEATER SETTING
Auto Zooming Tracking Dome Camera User Manual
48
CRUISE
DWELL TIME<SECS> 7
PRESET LIST 1
1 ON 0 OFF
1 2 3 4 5 6 7 8 9 0
0 1 1 0 0 1 0 1 1 1
BACK
EXIT
Temperature set is to set the heater‟s startup temperature.
Operations:
1. Move joystick to select an item.
2. Press Open.
3. Move the stick to select a parameter.
4. Press Open.
3.6.10 Cruise Setting
From the menu shown in Fig3.17, move joystick to select
<CRUISE SETTING>, press Open to enter the following menu.
Dwell Time: the lasting time of preset, from 5~250 seconds
Preset List: parameter 1, 2, 3
Operations:
1. In the menu, move the joystick to select a specific item.
2. Press Open.
3. Select the parameter with the joystick.
4. Press Open
Fig 3.29 CRUISE
Auto Zooming Tracking Dome Camera User Manual
49
TRACKING SETTING
DEFAULT SETTING
SIZE SNS MIDIUM
GRAY SNS MIDIUM
LOST ACT TO HOME & TRACKING
AUTO ZOOMING ON
WAIT TINE<S> 40
<TRACKING BOUNDARY>
BACK
EXIT
1 ON 0 OFF: Note, they are not changeable,
1234567890: display info, not changeable. When the preset
list is 1, “1, 2, 3, 4, 5, 6, 7, 8, 9, 0” indicates presets from 1 ~ 10.
When it is 2, it indicates presets from 11 ~ 20. When it is 3, it
indicates presets from 21 ~ 30.
0 0 0 0 0 1 0 1 0 1: select the cruising presets. 1 for cruising,
0 for not cruising.
Operations:
1.From the menu in Fig3.21, select relative item of
“1234567890” with the joystick.
2. Press Open and select a specific parameter.
Select options with joystick.
3.6.11 Tracking Setting
Move joystick to select <TRACKING SETTING>, press
Open to enter the tracking menu shown as Fig 3.30.
Default Setting: tracking setting to default.
Figure 3.30 TRACKING SETTING
Auto Zooming Tracking Dome Camera User Manual
50
Size SNS: the size of the target in the screen, Medium,
Large, Small are selectable
GRAY SNS: the sensitivity of the moving object, Medium,
High and Low are selectable
LOST AC: the action when the moving object is lost.
Parameters include: return home and tracking, keep tracking,
stop tracking
AUTO ZOOMING: The dome will auto zoom in / out
according to the size and distance of the object. Parameters can
be ON/OFF.
WAIT TIME <S>: When the tracking object is lost, the
interval of time for the dome to wait before Lost Action.
Parameters can be 5, 10, 15, 20, 25, 30, 35, 40 seconds.
<TRACKING BOUNDARY>: to set the valid area of tracking
function (UP/DOWN/LEFT/RIGHT).
Operations:
1. In the menu of Fig 3.30, move joystick to a specific item
2. Press Open
3. Move joystick to select desired parameter
4. Press Open
Auto Zooming Tracking Dome Camera User Manual
51
TRACKING BOUNDARY
BOUNDARY LIMIT OFF
CLEAR BOUNDARY
LEFT LIMIT OFF
RIGHT LIMIT OFF
UP LIMIT OFF
DOWN LIMIT OFF
BACK
EXIT
3.6.12 Tracking Boundary
From the menu in Fig3.30, move the cursor to < TRACKING
BOUNDRAY >, press Open to enter the following menu (Figure
3.31)
Figure 3.31 TRACKING BOUNDARY
BOUNDAR LIMIT: enable / disable the boundary
CLEAR BOUNDARY: clear setting of the current boundary
LEFT LIMT: set the left tracking boundary
RIGHT LIMT: set the right tracking boundary
UP LIMT: set the up tracking boundary
DOWN LIMT: set the down tracking boundary
Operations:
1. Move the cursor to a specific function item
2. Press Open
3. Move the joystick to select parameter or operate as per
screen instructions
3. Press Open
Auto Zooming Tracking Dome Camera User Manual
52
DOME LABLE
<EDIT DOME LABEL>
<CLEAR DOME LABEL>
BACK
EXIT
3.7 Dome Label
From the menu shown in Fig3.1, move the cursor to
<DOME LABEL>, press Open to enter the following menu
(Figure .32)
Figure 3.32 DOME LABLE
<EDIT DOME LABEL>: To edit the dome description and
information. Please refer to 3.5.4 Edit Preset Label”.
<CLEAR DOME LABLE>: Clear current dome label. Press
Open to enter the menu and then operate with instructions.
3.8 Other Functions
RESET CAMERA:
If the camera does not operate or if you close camera‟s
control, cycle camera power. Cycling camera power resets the
camera but does not change any saved camera settings.
REBOOT SYSTEM:
Reboot the system if it does not operate or if there is no
control. Rebooting the system will cycle dome and camera power
without changing programmed dome settings. Ω
Loading...
