DVRJ4
4-ch Standalone Network DVR
User’s Manual
Rel.061207
1. Product introduction
1.1. System specification
2. Product operation
2.1. Various split screen
2.2. 1 channel audio recording & playback
2.3. USB backup
2.4. System upgrade through USB stick
2.5. Network client program with various
functions
2.6. Front panel and buttons
2.7. Back panel connection
2.8. Remote controller
3. Various display mode
3.1. QUAD mode
3.2. PIP mode
3.3. FULL screen mode
3.4. AUTO rotation mode
3.5. TRIPLEX mode
4. DVR installation and operation
4.1. Recording
4.2. Playback
4.3. Searching
4.4. Zooming
4.5. Freezing
4.6. USB backup
4.7. System information
5. Menu
5.1. Setup menu
5.2. System menu
5.3. Video menu
5.4. Recording menu
5.5. Network menu
5.6. Sensor / Motion menu
5.7. Backup menu
5.8. Schedule recording menu
6. Network client software
6.1. Program installation and
operation
7. Router
7.1. Virtual server
7.2. Router IP check
7.3. Access
App. A. Troubleshooting
App. B. Product specification
DVRJ4
User’s manual
Before operating
This User‟s manual is explanation of DVRJ4 installation and operation. If you are not familiar with DVR, please
contact professional technicians for installation and operation. Please read thoroughly before you operate the unit
for your safety.
Be careful!
Do not install the unit where vibration and shock can be made. This can cause trouble.
Turn the unit off when you do cleaning and make sure to use dry towel.
Do not expose the unit to water or moisture.
Install the unit on even place and maintain the proper temperature.
Do not put heavy things on the unit.
DVRJ4
1. Product Introduction
DVRJ4 supports full triplex (recording / playback / backup) and GUI for setup.
1.1. System Specification
Up to 500GB
Storage
Compression M-JPEG (Modified JPEG)
Video input 4 (NTSC/PAL) channel
Recording resolution 704 x 240(288), 352 x 240(288)
Recording speed 1fps ~ 120fps totally @ CIF
Recording mode
(supporting 24 Bit, 48 Bit)
Two (2) hard drives
Manual recording
Event recording
- Motion, Alarm detected.
Remote recording through network
User’s manual
Playback mode FF : 2X ~ 32X, REW : 2X~16X,
Display 120fps
Display mode - QUAD, MUX, PIP, Automated rotation
Multi Task Triplex (recording, playback, backup at the same time)
Motion detection 5 levels, 16 x 12 grids area
Audio
Input 1 port
Output 1 port
DVRJ4
Firmware update via USB stick
Network viewer Setup, Search, Backup
Backup
User’s manual
Backup through network
AVI file backup
Watermark
USB memory stick, USB 2.0
Can be viewed by WINDOWS
DVRJ4
User’s manual
2. Product operation
2.1. Various split screen
Processes 4channel video input by real time, and provides various split screen (QUAD, FULL, PIP, AUTO,
FREEZE).
2.2. 1 channel audio recording and playback
2.3. Backup to USB Thumb drive
Supports USB thumb drive backup and USB 2.0. You can play back the data via remote client program.
2.4. Firmware upgrade via USB stick
When you try to update the system through USB stick, save the firmware after you change the name to
„update.bin‟. And put it in the DVR USB port, and get in „USB SETUP MENU‟ of the DVR menu to select
“FIRMWARE UPDATE‟. Then it automatically begins updating. It takes about 4 ~ 5 minutes. After that, it will reset
itself.
2.5. Various function of network client software
- It supports various display (1channel/4 channel/PIP/AUTO rotation/Triplex).
- You can save the data that are being viewed on network viewer now on your PC.
- You can convert the data saved on your PC into AVI file.
- You can search the recorded data.
DVRJ4
User’s manual
2.6. Front panel and buttons
① ② ③
NO Items Details
Status LED
①
④
- POWER : DVR is on, then LED is on.
- HDD : It lights when HDD‟s are read or recorded.
- REC : It gets on when images are recorded.
- PLAY BACK : It lights when recorded data are played back.
- NETWORK : DVR is accessed by client program, then it gets on.
- BACKUP : If backup is being done, it gets on.
⑨ ⑩ ⑪ ⑫
⑤ ⑥ ⑦ ⑧
⑬ ⑭
⑮
②
③
④
⑤
⑥
QUAD
PIP
TRIPLEX
AUTO
CH1, CH2, CH3,
CH4
- You can use this when you want to view 4 cameras at the same time.
- You can view a few smaller screen in a main screen.
- It shows live images, playback images on one screen.
- It shows one channel by one channel from #1 channel through #4 channel. It rotates
automatically.
- You can view one channel in a full screen.
DVRJ4
NO Items Details
User’s manual
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
ZOOM
FREEZE
SEARCH
PLAY-BACK
REC
SET/EXIT
BACKUP
ARROW KEYS
- You can zoom the current screen by 2x2.
- You can view the paused screen.
- RECORD START-STOP search
You can start or stop the recorded data.
- EVENT search
You can search the Event data which is motion and/or sensor(alarm).
- TIME search
You can designate your target time.
- You can view the recorded data from the hard drive of the DVR. If you press this button
without any other action, the latest recorded data will be played back.
- You can record images manually with this button. If you press it one more time, recording
will stop.
- For Setting of DVR
- To move upper menu or main menu
- This is for USB thumb drive backup.
- For menu setting or moving to other setting.
⑮
USB PORT
- USB thumb drive
DVRJ4
2.7. Back panel connection
CH1 CH2 CH3 CH4
User’s manual
AUDIO IN
MON
① ② ③ ④ ⑤ ⑥
NO Items Details
①
②
③
④
VIDEO INPUT
(1~4 CHANNEL)
MONITOR
AUDIO INPUT /
OUTPUT
ETHERNET
4 composite video inputs with BNC jack.
For monitor, CCTV monitor
Supports line level audio in/out which uses RCA mono type connector. You need external
amplifier to connect to mic.
RJ-45, 10/100Mbps
AUDIO OUT
ETHERNET
AL IN AL OUT PAN/TILT
DC 12V
DVRJ4
NO Items Details
User’s manual
⑤
⑥
ALARM/PTZ
POWER
- Alarm input (AL IN)
Supports 4 alarm inputs.
- Alarm output (AL OUT)
Supports 1 output and out internal buzzer. If alarm goes off, you can press „ENTER‟
on the front panel to reset the alarm status. Maximum volt is +5V.
External DC power supply (12V/5A)
DVRJ4
User’s manual
2.8. Remote controller
Backup button
Full screen button
4channel split button
Zoom button
Menu button
Auto rotation button
USB
QUAD
ZOOM
SET
LOCK
FULL PIP
REC
FREEZE
SEARCH
TRIAUTO
PB
Button lock key
Recording
button
PIP button
Pause button
Search button
Triplex mode button
Direction
button
Setting button
+ -
SEL
PTZ
Digital Video Recorder
Playback
button
PTZ setting button
DVRJ4
3. Various display mod
3.1. QUAD mode
User’s manual
2006/1/1 12:12:23 MON
CAMERA 1 CAMERA 2
CAMERA 3 CAMERA 4
3.2. PIP mode
2006/1/1 12:12:23 MON
Current time
Camera names
2006/1/1 12:12:23 MON
2006/1/1 12:12:23 MON
CAMERA 1
PIP mode 1
CAMERA 2
CAMERA 2
CAMERA 1
PIP mode 2
CAMERA 3
CAMERA 2
CAMERA 3 CAMERA 4
CAMERA 1
PIP mode 3
DVRJ4
3.3. FULL mode
User’s manual
2006/1/1 12:12:23 MON
CAMERA 1
3.4. AUTO mode
2006/1/1 12:12:23 MON
2006/1/1 12:12:23 MON
2006/1/1 12:12:23 MON
2006/1/1 12:12:23 MON
If you press FULL mode for the proper channel, you
can view it on a full screen. It does not affect
recording.
If you press AUTO button, the channels rotate
channel by channel as a full screen. It does not
affect recording.
CAMERA 1
CAMERA 1
CAMERA 1
CAMERA 4
DVRJ4
3.5. TRIPLEX mode
2006/1/1 12:12:23 MON
CAMERA 1
CAMERA 2
PB CAMERA 3
User’s manual
Live and playback images are displayed together on
a screen.
CAMERA 3 CAMERA 4
PB CAMERA 1 PB CAMERA 2
PB CAMERA 4
4. DVR installation and operation
Installation process
1. Open the package and check the items and take the DVR out.
2. Connect the camera cables to the ports on the back panel.
3. Connect the monitor cable to the proper port on the back panel.
4. Connect other devices such as network, PTZ, audio etc.
5. Connect the supplied DC 12V power adapter (※ Make sure to use the supplied power
adapter.)
6. Power is automatically provided, and DVR system gets defaulted and it turns into live
mode in a couple of seconds.
DVRJ4
System beginning
1. Images are being displayed and the system is being defaulted. During this process
graph is being displayed.
2. During default process, DVR checks the system and the hard drive, and gets
defaulted.
3. System default takes about 10 seconds.
4. You can change the setting if you want even during system operation or recording.
4.1. Recording
2006/1/1 12:12:23 MON
User’s manual
In recording, this time is recorded together, so you need to
set the time as precise as possible. (※ During recording, if
M
you change the time, the data may not be searched.)
CAMERA 1
M
CAMERA 3
M
CAMERA 2
M
CAMERA 4
M
Camera names
Red icon means “being recorded now.”
When is recording done?
1. When you press REC button, recording begins. When you press one more time, it
stops.
2. When Motion recording is set „ON‟ and there is motion detected.
3. When alarm is input.
4. When recording is triggered by Network client software.
DVRJ4
4.2. Playback
User’s manual
Playback speed
X16
▶
PB CAMERA 1
PB CAMERA 3
During playback, you can view various modes of FULL/QUAD/PIP etc.
4.3. Searching
Manual recording
searching
SEARCH MODE
RECORD START/STOP SEARCH
EVENT LIST SEARCH
2006/1/1 12:12:23
PB CAMERA 2
PB CAMERA 4
Playback time
Playback icon
Playback camera names
RECORD SEARCH MASTER PAGE:0001/0003
START TIME END TIME
2006/1/1 06:32:12
2006/1/11 13:31:00
2006/1/21 16:12:22
2006/1/9 17:15:12
2006/1/17 06:32:17
2006/1/21 22:12:17
The total number
of list
Selected number
TIME/DATE SEARCH
Recording ended time
Recording started time
DVRJ4
Event recording
searching
User’s manual
Search by motion/alarm/network
SEARCH MODE
RECORD START/STOP SEARCH
EVENT LIST SEARCH
TIME/DATE SEARCH
Time/date
searching
SEARCH MODE
RECORD START/STOP SEARCH
EVENT LIST SEARCH
TIME/DATE SEARCH
EVENT SEARCH MASTER PAGE:0001/1000
START TIME EVENT
2006/1/1 06:32:12
2006/1/11 13:31:00
2006/1/21 16:12:22
Recording started time by event
Search by time / date you want.
TIME SEARCH HDD : MASTER
START :
END : 2006/1/22 16:22:12
2006/1/24 11:12:12
2006/1/1 06:32:12
MOTION
MOTION
ALARM ALL
CH
CH1
CH1+CH2
The total number
of list
Selected number
The channel of event
happened
Kind of event
Recording started
and ended time
This is the place where you can designate the time you want.
After designating it, you need to press “enter” (※ You are
supposed to designate the time between START-END time to
fulfill search properly.)
DVRJ4
4.4. Zooming
User’s manual
CAMERA 1
CAMERA 3
4.5. Freezing
CAMERA 1
CAMERA 3
2006/1/1 12:12:23
CAMERA 2
CAMERA 4
2006/1/1 12:12:23
CAMERA 2
F
CAMERA 4
It means the current status is
Z
“zoom”.
This is zoom window. You can press
top/bottom/left/right to move to where you want to
zoom.
F
It means the current status is “freezing”.
It shows it is paused now. Press this one more time, then
it is released (※ even though you freeze the images,
recording is done without any problems.)
DVRJ4
4.6. USB backup
USB backup can be done only during playback. During playback, find the target images and
press BACKUP button. Then DVR saves that data to USB devices. In addition, if you press the
button very quickly, DVR will save that frame. If you press the button for 3 seconds, DVR will
save the images. You can press the button one more time to quit. During this process, USB
icon is shown on the screen.
User’s manual
Means currently still frame is being
saved via USB port.
Means currently motion images are
2006/1/1 12:12:23
S
A
being saved via USB port.
PB CAMERA 1
PB CAMERA 3
PB CAMERA 2
PB CAMERA 4
※ During backup process, if you pull the thumb
drive out, system error may be raised.
4.7. System information
Every information of DVR system is shown on screen to understand it at a glance.
Hard drive size, model, recording and playback position, network setting, recording setting,
software version etc.
DVRJ4
5. Menu
5.1. Setup menu
On live monitoring mode, if you press MENU/EXIT button,
you can see the main menu on the left.
User’s manual
For basic setting of DVR
For display setting
For recording setting
For network setting
For scheduling recording
For motion and alarm
※ Under the main menu, if you press MENU/EXIT button,
you can get out to SETUP menu.
For PTZ setting
For USB information and firmware update
DVRJ4
5.2. System menu
Time/date, hard drive formatting, auto rotation, system default, video signal selection,
buzzer setting, password setting, language setting.
Time/date
SYSTEM SETUP
User’s manual
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
TIME/DATE SETUP
O DATE : 2006/08/12
O TIME : 14:21:11
O FORMAT : YYYY/MM/DD
O DISPLAY : ON
O LOCAL : TOP
To set the current date and time. Use
the buttons of top, bottom, left, and
right.
Format of date and time. „YYY/MM/DD‟,
„MM/DD/YYY‟, or „DD/MM/YYYY‟
You can turn the time on or off.
The position of display.
„TOP‟, or „BOTTOM‟
DVRJ4
Hard drive
User’s manual
format
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
Factory default
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
DO YOU WANT ERASE THE HDD?
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
[ATTENTION]
YES NO
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
[ATTENTION]
ARE YOU SURE?
YES NO
This is to erase all the data recorded
on hard drive.
This is to have the DVR factory
defaulted.
DVRJ4
Auto rotation
User’s manual
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
AUTO SETUP
CHANNEL1 : 1 SEC
CHANNEL2 : 1 SEC
CHANNEL3 : 1 SEC
CHANNEL4 : 1 SEC
Video signal Buzzer
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
Assign the proper time each to the
channel. Each channel will be shown
on screen for that time.
DVRJ4
User’s manual
Password setting
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
Password inserting
You can use top / bottom button to select the
numbers.
Language
selection
ENGLISH/KOREAN
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
Playback repeat
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
SYSTEM SETUP
O TIME/DATE SET [ ]
O HDD FORMAT SET [ ]
O FACTORY RESET [ ]
O AUTO SEQUENCE SET [ ]
O PLAY REPEAT : YES
O VIDEO SOURCE : NTSC
O BUZZER SOUND : OFF
O PASSWORD ENA : ON
O SELECT LANG : ENGLISH
O NEW PASSWORD : 0000
DVRJ4
5.3. Video menu
This is to set the basic environmental of live monitoring mode such as channel names,
brightness, contrast etc. In addition, boarder lines of channels, color of no video channel is
set. If you select VIDEO SETUP, you can see the menu on the right side.
Channel names
VIDEO SETUP
O NAME SET [ ]
O BRI/CON SET [ ]
O BOUNDARY : WHITE
O BACK GROUND : BLUE
NAME SETUP
O CH1 : CANNEL 1
O CH2 : CHANNEL 2
O CH3 : CHANNEL 3
O CH4 : CHANNEL 4
O DISPLAY : ON
Abcdefghijklmnopqrstuvwxyz
ABCDEFGHIJKLMNOPQRSTUVWX
YZ #$%&*!1234567890
User’s manual
You can name the channel here by
using arrow buttons and press
ENTER. Maximum characters are 8,
(right).
DVRJ4
Brightness/Contrast
O NAME SET [ ]
O BRI/CON SET [ ]
O BOUNDARY : WHITE
O BACK GROUND : BLUE
Color of boarder lines (boundary) and back ground
VIDEO SETUP
BRIGHTNESS & CONTRAST SETUP
BRI [ ■ ]
CON[ ■ ]
BRI [ ■ ]
CON[ ■ ]
BRI [ ■ ]
CON[ ■ ]
BRI [ ■ ]
CON[ ■ ]
User’s manual
You can use arrow buttons to adjust
brightness and contrast.
VIDEO SETUP
O NAME SET [ ]
O BRI/CON SET [ ]
O BOUNDARY : WHITE
O BACK GROUND : BLUE
You can choose one color among white, gray, and black.
Use the arrow keys.
You can choose one color between blue and black. This
color will appear when there is no video input on the proper
channel.
BOUNDARY
DVRJ4
5.4. Recording menu
Recording setup
You can use arrow keys to adjust the setting.
RECORD SETUP
O OVER WRITE : YES
O REC SPEED : 60Fld/1SEC
O REC QUALITY : VERY HIGH
O REC SOURCE : MULTIPLEX
O PB SPEED : NO USE
O AUDIO ENABLE : OFF
User’s manual
If you press yes, DVR will over write
the data on hard drive. The oldest
data will be erased first.
Normally „15Fld/1SEC‟ lasts about
one week with 80GB.
To control playback speed
regardless of the speed of
recorded data.
This DVR records 1 channel
audio input.
Resolution selection. It supports
„MULTIPLEX‟, „CIF‟. If you want „REC
SPEED‟ double time, then set as „CIF,‟ if
you want „REC SPEED‟ as it is, then set
as „MULTIPLEX‟. In other words, if you
want to record 120ips, then set as „CIF „.
Recorded data quality selection such
as „VERY LOW‟, LOW‟, „HIGH‟, and
„VERY HIGH‟. „VERY HIGH‟ is the best
quality, but consumes the hard drive
most. Normally people set as „HIGH‟.
If you want more duration of
recording, then set as „LOW‟ or „VERY
LOW‟.
DVRJ4
5.5. Network menu
This is menu to set network environmental. You need to set the network environment. first if
you need to control various function of the DVR and do remote monitoring and remote
management.
Network setting
You can use arrow buttons to adjust.
This DVR supports DHCP and DDNS. When you use static
IP, you need to set as „Disable‟ and when you use
dynamic IP, you need to set as „Enable‟. When you use
DHCP/DDNS, every environment is set automatically. In
NETWORK SETUP
O DHCP SET : Enable
O SUB NET : 255.255.255.000
O GATEWAY : 192.168.001.001
O IP ADDR : 192.168.001.123
O NETWORK STATE : INTERIOR
O NET CMD PORT : 5001
O NET DATA PORT : 5000
This DVR uses the port of 5000 and 5001.
addition, in case of DHCP set, when you access remotely,
even though the IP is changed, you can always acess to
the DVR automatically through DDNS server.
User’s manual
DVRJ4
5.6. Sensor / Motion menu
This is to set sensor input, alarm, and motion setting. This DVR supports 4channel sensor
inputs, 1 channel alarm output (relay output). And it can set motion recording on each
channel. You can record the images as it is set.
Sensor / motion setting
You can use arrow buttons to adjust.
Channel selection for setting
User’s manual
SENSOR SETUP
O CHANNEL SELECT:CAM 1
O ALARM ENABLE : OFF
O MOTION ENABLE : OFF
O MOTION LEVEL : VERY HIGH
O COMPARE FRAME : 02
O EVENT REC TIME : 01 MIN
O BUZZER SOUND : NO USE
O AREA SET [ ]
Motion detection area
The part filled with yellow
color is the area that
detects motion.
Alarm input type selection (NO, NC, OFF)
Motion detection set
Motion detection sensitivity.
VERY HIGH is the most
sensitive.
In motion detected, how
many images you will
record? Normally people
set two frames.
In motion detected, beep
goes off and you assign
that sound duration. If you
set „NO USE‟, there is no
beep.
In motion recording, how
long will you record the
data?
DVRJ4
5.7. Backup menu
This is for USB backup. This DVR supports a variety of USB thumb drives. You can also use
USB drive for firmware upgrade.
USB backup setting
You can use arrow buttons to adjust.
It shows the total capacity of the USB thumb drive
hooked in.
USB BACKUP SETUP
O USB TOTAL SIZE : 256 BYTE
O USEFUL SIZE : 256 BYTE
O FIRMWARE UPDATE
It shows available space.
User’s manual
You can use this function when you try to update the
firmware. After update, you need to turn the system off
and turn it on.
DVRJ4
5.8. Schedule recording menu
You can schedule the recording for a week.
Schedule recording setting
You can use arrow buttons to select day / time and press
„ENTER‟ to finish. After that, you can do other days.
SCHEDULE SETUP
User’s manual
O MON : OFF --:-- ~ --:--
START STOP
O TUE : OFF --:-- ~ --:-O WED : OFF --:-- ~ --:-O THU : OFF --:-- ~ --:-O FRI : OFF --:-- ~ --:--
O SAT : OFF --:-- ~ --:--
O SUN : OFF --:-- ~ --:-O SCHEDULE ENABLE : OFF
If you use this function, you have to turn it „ON‟ for
„SCHEDULE ENABLE‟.
DVRJ4
6. Network client software
6.1. How to install and use
1> You can save the software provided on the enveloped CD on your computer or just
execute it.
Live remote monitoring
Access
button
User’s manual
The channel name
The current mode.
Live mode
Search mode: You can search the data
from the DVR.
Display mode button
You can save the currently displayed
images into M-JPEG stream.
You can save the currently displayed
images into AVI file.
Environment
setting button
You can print the currently displayed
images.
You can view the data on the hard
drive out of the DVR.
Backup playback.
Program-off button
Pan/tilt button
DVRJ4
System setting
User’s manual
① Press this button.
② Insert the IP when you use
static IP.
This is the route where you save
M-JPEG stream or AVI file.
④ DVR‟s unique MAC address. It‟s
shown on the manual.
③ Click this when you use dynamic IP
(ADSL, VDSL etc.)
DVRJ4
Access
User’s manual
Insert the password to try to access.
Default is 0000.
You can start recording of the DVR or stop
with using this button.
DVRJ4
Remote search / playback
Remote search / playback is the function that search and playback the data
recorded on the DVR remotely via client software.
User’s manual
① Select the hard drive.
② Press „REC‟ or „EVENT‟ button to find the list you want
and double-click it to play back.
If you select the list you want and doubleclick it, that recorded data will be played
back.
You can categorize the list between
„RECORD‟ and „EVENT‟.
You can select which hard drive you want
to search. This DVR supports two hard
drives, Master and Slave.
DVRJ4
HDD scan playback
You can connect the hard drive out of the DVR system to your computer
directly to play back the recorded data.
User’s manual
Hard disk selection
Playback
button
Stop
Move to end.
Move to
beginning
Audio ON/OFF
Playback speed
control
DVRJ4
Backup playback
Backup playback is the function that plays back on your PC the backup data
on USB device and other storage device. You can connect the backup
device to the PC to play back.
User’s manual
Playback
Stop
Move to end
Move to
beginning
Pull the image data of
backup data.
Playback speed control
DVRJ4
7. Router
7.1. Virtual server
Router may be various from one to one by various manufacturers. On this
manual, the target model is Linksys WRT54G.
User’s manual
On router‟s virtual server item, assign TCP 5000 and TCP 5001 as DVR IP.
( ※ Some routers use the terms of „Port Forwarding‟ instead of Virtual server.)
DVRJ4
7.2. Router IP check
User’s manual
Router‟s IP address is the internet IP. The above
example shows it 192.168.1.1
Note: The vendor of this DVR can only provide
guidance on how to configure your router. Always
call your ISP or the router‟s technical support for
complete information how to setup your local
network or Internet service.
DVRJ4
7.3. Access
User’s manual
In case of DDNS use,
insert the DVR set‟s
MAC address to
secure the IP
address. And then
you can use that IP
address.
Insert the router‟s IP address and press OK.
DVRJ4
App. A. Troubleshooting
Symptom Checks
The system does not get on. - Please check the external power adapter status.
Can not view the live images. - Please check the connection of camera video cable.
- Please check the connection of monitor video cable.
- Please check the camera power.
Live images are too bright. - Please check the input camera status.
- Please check the camera‟s brightness.
DVR stops working during recording. - If the hard drives are full, please set the recording as overwriting.
App. B. Product specification
Video
User’s manual
Video signal NTSC/PAL
Video input Composite : 4 channels, 1 Vp-p, 75 Ohms
Video output Composite : 1 channel, 1 Vp-p 75 Ohms
Resolution 704 x 240(NTSC), 704 x 288(PAL)
Playback / recording speed 120ips(NTSC)
DVRJ4
Audio input / output
Audio input 1 Line Input
Audio output 1 Line Output
Connector
Video input Composite : 4 BNC
Video output Composite : 2 BNC
Audio input 1 RCA connector
Audio output 1 RCA connector
Storage
Main storage Hard drives x 2pcs(Master & slave)
User’s manual
Backup Via USB port
DVRJ4
Generals
Unit dimension (W x D x H) 280mm x 250mm x 45mm
Unit weight 2.5Kg
Packing weight 3.0Kg
Packing dimension (W x D x H) 340mm x 260mm x 70mm
User’s manual
Operation temperature
Operation humidity 0% ~ 90%
Power DC 12V/5A Adaptor
The specification may be changed without any prior notice for better quality.
5℃ ~ 40℃
DVRJ4
User’s manual
Product Warranty
Product 4 channel DVR
Model DVRJ4
Purchase Invoice #/Date
Warranty period One year after purchase
Names E-MAIL
Customer
Vendor
1. This product has been qualified by severe quality control and process.
2. Defective units with normal operation will be replaced with brand new unit or will be repaired for free
at the discretion of the DVR vendor during the warranty period.
3. You need to get a RMA number from Optiview Technical Support Group for free warranty repair works.
4. Some charges will be applied for the cases below even though it‟s within warranty period.
- defective due to users‟ fault
- defective due to fire, natural forces like earthquake, flood, thunderbolt, etc.
- if you don‟t have this paper work (Product warranty).
- After warranty period.
Address
Contact
Name
Installer
Contact
Loading...
