User’s Guide
DS-I
Durable Series
1-3KVA
Contents
警告
危险
警告
危险
Important Safety Instructions
Save these instructions
This manual contains important safety instructions. Read all safety and operating instructions
before operating the uninterruptible power systems (UPS). Adhere to all warnings on the unit
and in this manual. Follow all operating and user instructions. This equipment can be operated
by individuals without previous training.
Maximum load must not exceed that shown on the UPS rating label. The UPS is designed for
data processing equipment. If uncertain, consult your dealer or local representative.
The 1-3kVA@200/208/220/230/240VAC is designed for use with a three-wire input (L,N,G).
WARNING
The battery can present a risk of electrical shock and high
short circuit current. Following precautions should be
observed before replacing the battery.
Wear rubber gloves and boots.
Remove rings, watches and other metal objects.
Use tools with insulated handles.
Do not lay tools or other metal objects on the batteries.
If the battery is damaged in any way or shows signs of leakage, contact your local
representative immediately.
Do not dispose of batteries in a fire. The batteries may explode.
Handle, transport and recycle batteries in accordance with local representative.
WARNING
Although the UPS has been designed and manufactured to
ensure personal safety, improper use can result in electrical
shock or fire. To ensure safety, observe the following
precautions:
Turn off and unplug the UPS before cleaning it.
Clean the UPS with a dry cloth. Do not use liquid or aerosol cleaners.
Never block or insert any objects into the ventilation holes or other openings of the UPS.
Do not place the UPS power cord where it might be damaged.
Contents
CONTENTS
1.Electromagnetic Compatibility ............................................................................................... 1
2. Introduction .......................................................................................................................... 2
3. System Description .............................................................................................................. 5
3.1 Transient Voltage Surge Suppression (TVSS) and EMI/FRI Filters ............................... 5
3.2 Rectifier/Power Factor Correction (PFC) Circuit............................................................ 5
3.3 Inverter ......................................................................................................................... 5
3.4 Battery Charger ................................................................ ............................................ 5
3.5 DC-to-DC Converter ..................................................................................................... 6
3.6 Battery .......................................................................................................................... 6
3.7 Dynamic Bypass ........................................................................................................... 6
4. Product Specification and performance ................................................................................ 7
4.1 Model Description ......................................................................................................... 7
4.2 Product Specification and Performance ........................................................................ 7
5. Installation ................................ ........................................................................................... 9
5.1 Unpacking and Inspection ................................................................ ............................ 9
5.2 Connect Input/Output Power ........................................................................................ 9
5.3 Operating procedure for connecting the long backup time model UPS with the external
battery .............................................................................................................................. 10
6. Controls and Indicators ...................................................................................................... 12
7. Operation........................................................................................................................... 16
7.1 Operation Mode.......................................................................................................... 16
8. Battery maintenance .......................................................................................................... 17
9. Notes for battery disposal and replacement procedures .................................................... 18
9.1 Battery Disposal ......................................................................................................... 18
DS-I 1-3k UPS User Manual
Contents
9.2 Battery Replacement Procedures ............................................................................... 18
10. Trouble shooting ................................ ................................................................ .............. 19
10.1 Checking UPS status ................................................................................................ 19
10.2 Adjust the factors caused the problem ...................................................................... 19
Annex A. Intelligent Slot ......................................................................................................... 23
Annex B. EPO / External Battery Pack................................................................................... 24
Annex C. Rated Parameters Setting ...................................................................................... 25
Electromagnetic Compatibility
* Safety
IEC/EN 62040-1-1
* EMI
Conducted Emission.........IEC/EN 62040-2
Class A
Radiated Emission............IEC/EN 62040-2
Class A
*EMS
ESD..................................IEC/EN 61000-4-2
Level 4
RS....................................IEC/EN 61000-4-3
Level 3
EFT..................................IEC/EN 61000-4-4
Level 4
SURGE............................IEC/EN 61000-4-5
Level 4
Low Frequency Signals..............:IEC/EN 61000-2-2
Warning: This is a product for commercial and industrial application in the second
environment-installation restrictions or additional measures may be needed to
prevent disturbances.
1. Electromagnetic Compatibility
NOTICE：
This is a product for restricted sales distribution to informed partners. Installation restrictions or
additional measures may be needed to prevent radio interference.
Operated the UPS in an indoor enviroment only in an ambient temperature range of
0-40C(32-104F). Install it in a clean environment, free from moisture, flammable liquids,
gases and corrosive substance.
This UPS contains no user-serviceable parts except the internal battery pack. The UPS on/off
push buttons do not electrically isolate internal parts. Under no circumstance attempt to gain
access internally, due to the risk of electric shock or burn.
Do not continue to use the UPS if the panel indications are not in accordance with these
operating instructions or the UPS performance alters in use. Refer all fault to your dealer.
Servicing of batteries should be performed or supervised by personnel knowledgeable of
batteries and the precautions. Keep unauthorized personnel away from the batteries. Proper
disposal of batteries is required. Refer to your local laws and regulations for disposal
requirement.
DO NOT CONNECT equipment that could overload the UPS or demand DC current from the
UPS, for example: electric drills, vacuum cleaners, laser printers, hair dryer or any appliance
using half-wave rectification.
Storing magnetic media on top of the UPS may result in data loss or corruption.
Turn off and isolate the UPS before cleaning it. Use only a soft cloth, never liquid or aerosol
cleaners.
DS-I 1-3k UPS User Manual
Introduction
1 32
4 7
5
8
9
6
10
2. Introduction
Congratulations on your choice of the uninterruptible power system (UPS), the UPS comes in
nominal power ratings of 1000VA, 2000VA and 3000VA. It is designed to provide conditioned
power to microcomputers and other sensitive electronic equipment.
When it is generated, alternating current is clean and stable. However, during transmission and
distribution it may be subject to voltage sags, spikes and complete power failure that may
interrupt computer operations, cause data loss and even damage equipment. The UPS
protects equipment from these disturbances.
The UPS is a compact, on-line UPS. An on-line UPS continuously conditions and regulates its
output voltage, whether utility power is present or not. It supplies connected equipment with
clean sine-wave power. Sensitive electronic equipment operates best from sine-wave power.
For ease of use, the UPS features a LCD display to indicate all information for UPS, and
provide kinds of function buttons.
Fig 1.
2 DS-I 1-3k UPS User Manual
1KVA / Rear View
220/230/240V DS1000I 110/120V DS1000I
Introduction
1 2 3
4
7
8
5
6
9
10
1 2 3
4
5
6
7
8
11
10
9
220/230/240V DS2000I
220/230/240V DS3000I
110/120V DS2000/3000I
Fig 2. Rear View
DS-I 1-3k UPS User Manual
Introduction
1
RS-232 communication port. DB9 type.
2
EPO. Short to activate.
3
Intelligent slot
4
USB port
5
Input surge protection slot.
6
Input socket. 2x0V 1KVA: IEC C14, 2K/3K: IEC C20
1x0V DS1000I: IEC C14; DS1500/2000I : NEMA 6-20P
7
Network surge protection.
8
Output Socket.2x0V DS1000 / 2000I: IEC320*4; DS3000I: IEC320*4 + Terminal
1x0V DS1000I: 4*NEMA; DS2000/3000I: 8*NEMA
9
External battery port. Optional for Long Back-up model.
10
Battery ground
11
Output terminal
4 DS-I 1-3k UPS User Manual
System Description
TVSS & EMI/RFI
Filters
Rectifier/PFC Inverter
Bypass
DC/DC Converter
Battery Charger
Battery
I/P
O/P
Input Output
3. System Description
3.1 Transient Voltage Surge Suppression (TVSS) and EMI/FRI Filters
These UPS components provide surge protection and filter both electromagnetic interference
(EMI) and radio frequency interference (RFI). They minimize any surge or interference present
in the utility line and keep the sensitive equipment protected.
3.2 Rectifier/Power Factor Correction (PFC) Circuit
In normal operation, the rectifier/power factor correction (PFC) circuit converts utility AC power
to regulated DC power for use by the inverter while ensuring that the waveform of the input
current used by the UPS is near ideal. Extracting this sine-wave input current achieves two
objects:
The utility power is used as efficiency as possible by the UPS.
The amount of distortion reflected on the utility is reduced.
This results in cleaner power being available to other devices in the building not being
protected by the UPS.
3.3 Inverter
In normal operation, the inverter utilize the DC output of the power factor correction circuit and
inverters it into precise, regulated sine-wave AC power. Upon a utility power failure, the inverter
receives its required energy from the battery through the DC-to-DC converter. In both modes of
operation, the UPS inverter is on-line and continuously generating clean, precise, regulated AC
output power.
3.4 Battery Charger
The battery charger utilizes energy from the utility power and precisely regulates it to
continuously float charge the batteries. The batteries are being charged whenever the UPS is
DS-I 1-3k UPS User Manual
System Description
connected to utility power.
3.5 DC-to-DC Converter
The DC-to-DC converter utilizes energy from the battery system and raises the DC voltage to
the optimum operating voltage for the inverter. The converter includes boost circuit which is
also used as PFC.
3.6 Battery
The standard model includes value-regulated, non-spillage, lead acid batteries inside. To
maintain battery design life, operate the UPS in an ambient temperature of 15-25C.
3.7 Dynamic Bypass
The UPS provides an alternate path for utility power to the connected load in the unlikely event
of a UPS malfunction. Should the UPS have an overload, over temperature or any other failure
condition, the UPS automatically transfers the connected load to bypass. Bypass operation is
indicated by an audible alarm and illuminated amber Bypass LED.
NOTICE：The bypass power path does NOT protect the connected equipment from
disturbances in the utility supply.
6 DS-I 1-3k UPS User Manual
Production Specification and Performance
Model
DS1000I
DS2000I
DS3000I
Power Rating
1KVA/0.9KW
2KVA/1.8KW
3KVA/2.7KW
Frequency (Hz)
50/60
50/60
50/60
Input
Voltage
176Vac~288Vac
Current
5.5A max.
11A max
16A max
Battery
Voltage
36VDC
72VDC
96VDC
Current
35A max
35A max
37A max
Output
Voltage
200V/208V/220V/230V/240V
Current
5/4.8/4.5/4.3/4.2A
10/9.6/9/8.6/8.4A
15/14.4/13.5/12.9/12.6A
Dimension
(W*D*H) mm
144*353*222
190*374*336
190*426*336
Weight (kg)
12
21
26
Model
DS1000I
DS2000I
DS3000I
Power Rating
800VA/720W
1.5KVA/1.35KW
2KVA/1.8KW
Frequency (Hz)
50/60
50/60
50/60
Input
Voltage
96Vac~155Vac
Current
8.5A max.
15.5A max
20.7A max
Model No.
Type
DS1000I
Standard model
Long backup model
DS2000I
Standard model
Long backup model
DS3000I
Standard model
Long backup model
4. Product Specification and performance
4.1 Model Description
This manual is applicable to the following models:
4.2 Product Specification and Performance
1. General Specification 2X0V
General Specification 1X0V
DS-I 1-3k UPS User Manual
Product Specification and performance
Battery
Voltage
36VDC
72VDC
72VDC
Current
31A max
30A max
35A max
Output
Voltage
110V/115V/120V/127Vac（120V Default）
Current
6
.
7A
12
.
5A
16
.
7A
Dimension
(W*D*H) mm
144*353*222
190*374*336
190*374*336
Weight (kg)
12
22
22
Input
Model
Voltage
Frequency
Power Factor
DS1000/2000/3000I
Single-phase
40-70Hz
>0.98(Full load)
Temperature
Humidity
Altitude
Storage temperature
0C-40C
<95%
<1000m
-20C-70C
Altitude (M)
1000
1500
2000
2500
3000
3500
4000
4500
5000
De-rating Power
100%
95%
91%
86%
82%
78%
74%
70%
67%
Output
Voltage
Regulation
Power
Factor
Frequency
tolerance.
Distortion
Overload capacity
Crest ratio
1%
0.9 lag
0.5% of
normal
THD<1%@Fu
ll Linear Load
THD<6%@Fu
ll nonlinear
load
130% load: transfers to
Bypass mode after 1
minutes
150% load: transfers to
Bypass mode after 0.5
minute
3:1
maximum
2. Electrical Performance
3. Operating Environment
NOTICE：If the UPS is installed or used in a place where the altitude is above than 1000m,
the output power must be de-rated in use, please refer to the following:
8 DS-I 1-3k UPS User Manual
Installation
5. Installation
NOTICE：UPS operation in sustained temperature outside the range of 15-25C (59-77F)
reduces battery life.
5.1 Unpacking and Inspection
1) Unpack the packaging and check the package contents. The shipping package contains:
● 1 UPS
● 1 user manual
● 1 Communication cable
2) Inspect the appearance of the UPS to see if there is any damage during transportation.
Do not turn on the unit and notify the carrier and dealer immediately if there is any
damage or lacking of some parts.
5.2 Connect Input/Output Power
5.2.1 Notes for installation
1) The UPS must be installed in a location with good ventilation, far away from water,
inflammable gas and corrosive agents.
2) Ensure the air vents on the front and rear of the UPS are not blocked so as to
ensure good ventilation.
3) Condensation to water drops may occur if the UPS is unpacked in a very low
temperature environment. In this case it is necessary to wait until the UPS is fully
dried inside out before proceeding installation and use. Otherwise there are hazards
of electric shock.
5.2.2 Installation
5.2.2.1 Connecting Input and Output Cables
1. Input cable connection
The UPS is connected via the power plug, please use a proper socket with protection
against electric current, and pay attention to the capacity of the socket:
2x0V over 10A for DS1000I, over 16A for DS2000I and DS3000I.
1x0V over 10A for DS1000I, over 20A for DS2000I and over 25A for DS3000I.
2. Output cable connection
The total output power shall not exceed General Specification. Simply plug the load
power cable to the output socket of UPS to complete connection.
*Except from using socket as output, 3KVA has output terminal as well for load whose current
is over 10A.
DS-I 1-3k UPS User Manual
Installation
(a) (b)
Fig.3 Output terminal of 3KVA
1). Remove the cover of output terminal
2). Use AWG14 wires for terminal wiring configuration as fig.3 (a)
3). Please check if the wires are securely affixed
4). Put back the cover to the rear panel as fig.3 (b).
5.3 Operating procedure for connecting the long backup time model UPS with
the external battery
1. The nominal DC voltage of external battery pack please refer to General
Specification. Connect in series the batteries of the pack to ensure proper battery
voltage. To achieve longer backup time, it is possible to connect multi-battery packs,
but the principle of “same voltage, same type” should be strictly followed.
Fig.4 Battery terminal connection
10 DS-I 1-3k UPS User Manual
Installation
2. Take out battery cable delivered with the UPS. One end of battery cable is a plug and
the other end has 2 open wires.
3. Connect the RED wire to the “+” terminal of the battery. Connect the BLACK wire to
the “-“terminal of the battery.
Notice: DO NOT connect the battery plug to the battery socket of UPS first, otherwise, it
may cause electric shock.
4. Connect the external battery plug to the battery socket on the rear panel.
DS-I 1-3k UPS User Manual
Controls and Indicators
1
2
3
4 5 6 7
Controls
Description
6
ON/OFF
1.Press ON/OFF to start UPS when utility is normal
NOTE
It only bases on default setting(manual start)
2.Press ON/OFF to start from battery directly when there is no
main input, press again to start UPS upon buzzer alarms
3. Press ON/OFF to shutdown inverter when UPS is in normal
mode.
4.Press ON/OFF to shutdown UPS completely when UPS is in
battery mode
5.Press ON/OFF to ensure the rated parameter setting
7
FUNC
1.Press FUNC button to transfer in different menus
2.Press FUNC button for 3 seconds to mute off
3.Press FUNC and ON/OFF together for 2.5 seconds to set rated
parameters when only power supply is on
Indicators
Description
6. Controls and Indicators
Description of Panel
Fig.5 Display Panel
12 DS-I 1-3k UPS User Manual
Controls and Indicators
3
REC
Rectifier indicator:
green--rectifier is normal,
green flicker--rectifier is starting,
dark—rectifier is not working
5
Inv
Inv indicator:
green--inverter is normal
green flicker--inverter is starting or tracking with bypass(ECO)
dark—inverter is not working
2
BYP
Bypass indicator:
yellow—bypass is normal
dark—bypass is not working
4
BAT
Battery indicator:
yellow—battery discharge or charged
yellow flicker—battery is not connected, battery is low or charger is
failure
dark—battery is connected
1
2
3
4
5
Fig 6. LCD Main Menu
DS-I 1-3k UPS User Manual
Controls and Indicators
Display
Function
Submenu
1
Input information
Input voltage(VAC),
Input frequency(Hz),
Input current(A)
2
Warn information
Fault code(FAULT),
Warn code(WARN),
Working mode (First number:
n-normal mode, E-ECO
mode. Second number: rated
voltage and frequency
2x0V
0-200V/50Hz, 1-200V/60Hz,
2-208V/50Hz, 3-208V/60Hz,
4-220V/50Hz, 5-220V/60Hz,
6-230V/50Hz, 7-230V/60Hz,
8-240V/50Hz, 9-240V/60Hz)
1x0V
A-110V/50Hz, B-110V/60Hz
C-115V/50Hz, D-115V/60Hz
E-120V/50Hz, F-120V/60Hz
H-127V/50Hz, L-127V/60Hz
Mute on( ), mute
off( )
3
Battery information
Battery voltage(VDC),
Capacity(%) if needed,
Firmware version,
Battery low warn(LOW)
Description of Main Menu
14 DS-I 1-3k UPS User Manual
Controls and Indicators
4
Load information
Load percent (%)
Active load(kW)
Apparent load(kVA)
Protocol code in setting
mode
5
Output information
Output voltage(VAC)
Output frequency(Hz)
Output current(A)
Note: Press “FUNC” button to see different information.
DS-I 1-3k UPS User Manual
Operation
7. Operation
7.1 Operation Mode
1. Turn on the UPS in normal mode
1) After you make sure that the power supply connection is correct, and then close the
battery breaker (this step only for long backup time model), after that turn on the
utility power. At this time the fans rotate, and LCD is on
2) Press ON/OFF for about 2.5 seconds, REC LED will green flicker. Inverter will start
and the INV green led flickers when REC led is green
NOTE
Only be suitable for default setting mode.
3) About several seconds, the UPS turn into normal Line mode. If the utility power is
abnormal, the UPS will transfer to Battery mode without output interruption of the
UPS.
2. Turn on the UPS from battery without utility power
1) After you make sure that the breaker of the battery pack is in the “ON” position (this
step only for long backup time model), press the ON/OFF button once to power on
the LCD, then press ON/OFF button again for 2.5 seconds when the buzzer alarms
2) A few seconds later, the UPS turns into Battery mode, and inverter feeds the load.
3. Turn off the UPS in normal mode
1) Press ON/OFF for 2.5 seconds button in condition of normal mode
2) Turn off utility power
3) If it’s a long backup model, open the battery breaker to turn off UPS completely. If it’s
an internal battery model, wait for 30 seconds and then UPS will shutdown
completely.
4. Turn off the UPS in battery mode
1) To power off the UPS by pressing the ON/OFF button continuously for more than 2.5
seconds.
2) When being powered off, the UPS will turn into No Output mode. Finally not any
display is shown on the display panel and no voltage is available from the UPS
output.
NOTICE：Please turn off the connected loads before turning on the UPS and turn on the loads
one by one after the UPS is working in INVERTER mode. Turn off all of the connected loads
before turning off the UPS. The operation above is only suitable for default setting mode.
16 DS-I 1-3k UPS User Manual
Battery Maintenance
8. Battery maintenance
1-3KVA UPS only requires minimal maintenance. The batteries used for standard models are
value regulated, sealed lead-acid, maintenance free battery. When it being connected to the
utility power, whether the UPS is turned on or not, the UPS keeps charging the batteries and
also offers the protective function of overcharging and over-discharging.
The UPS should be charged once every 4 to 6 months if it has not been used for a long
time.
In the regions of hot climates, the battery should be charged and discharged every 2
months. The standard charging time should be at least 12 hours.
Under normal conditions, the battery life lasts 3 to 5 years. In case if the battery is found
in bad condition, earlier replacement should be made.
Battery replacement should be performed by qualified personnel.
Replace batteries with the same number and same type of batteries.
Do not replace the battery individually. All the batteries should be replaced at the same
time following the instructions of the battery supplier.
DS-I 1-3k UPS User Manual
Notes for battery disposal and replacement procedures
9. Notes for battery disposal and replacement procedures
9.1 Battery Disposal
1) Before disposing of batteries, remove jewelry, watches and other metal objects.
2) Use rubber gloves and boots, use tools with insulated handles.
3) If it is necessary to replace any connection cables, please purchase the original
materials from the authorized distributors or service centers, so as to avoid overheat
or spark resulting in fire due to insufficient capacity.
4) Do not dispose of batteries or battery packs in a fire. The batteries may explode.
5) Do not open or mutilate batteries, released electrolyte is highly poisonous and
harmful to the skin and eyes.
6) Do not short the positive and negative of the battery electrode, otherwise, it may
result in electric shock or fire.
7) Make sure that there is no voltage before touching the batteries. The battery circuit is
not isolated from the input potential circuit. There may be hazardous voltage
between the battery terminals and the ground.
8) Even though the input breaker is disconnected, the components inside the UPS are
still connected with the batteries, and there are potential hazardous voltages.
Therefore, before any maintenance and repairs work is carried out, switch off the
breaker of the battery pack or disconnect the jumper wire of connecting between the
batteries.
9) Batteries contain hazardous voltage and current. Battery maintenance such as the
battery replacement must be carried out by qualified personnel who are
knowledgeable about batteries. No other persons should handle the batteries
9.2 Battery Replacement Procedures
1) Turn off UPS completely.
2) Remove covers from the UPS.
3) Disconnect the battery wires one by one.
4) Remove metal bars which are used to fasten batteries.
5) Replace batteries one by one.
6) Screw metal bars back to UPS.
7) Connect the battery wires one by one. Take care of electrical shock while
connecting the last wire.
18 DS-I 1-3k UPS User Manual
Trouble Shooting
Code
Event
Possible cause
Solution
7
Battery not
connected
Battery not connected
Check if battery switch is off or
battery cables are disconnected
10
EPO
Emergency power off
Short the EPO terminal 1&2 to
activate EPO
12
Inverter capacity
not enough
16
Warn: Input
voltage abnormal
Utility is failure
/
Input surge protector
opens
If utility is normal but rectifier is not
working, reset input surge protector
18
Warn: Line neutral
wires reversed/PE
not grounded
Input Line and neutral
is reversed
Check the polarity of line wire and
neutral wire
PE wire is not
connected correctly in
UPS
Check if PE on input plug is shorted
with UPS rear panel. If not, contact
with distributer or service center. If
yes, please check PE wire in input
power socket
10. Trouble shooting
This section describes checking the UPS’ status. This section also indicates various UPS
symptoms a user may encounter and provides a troubleshooting guide in the event the UPS
develops a problem. Use the following information to determine whether external factors
caused the problem and how to remedy the situation.
10.1 Checking UPS status
It recommended that checking the UPS operation status every six months.
Check whether the UPS is faulty: Is the Fault Indicator on? Is the UPS sounding an
alarm?
Check whether the UPS is operating in Bypass mode. Normally, the UPS operates
in Normal Mode. If it is operating in Bypass Mode, stop and contact your local
representative, or Channel Support.
Check whether the battery is discharging. When the utility input is normal, the
battery should not discharge. If the UPS is operating in Battery Mode, stop and
contact your local representative, or Channel Support.
10.2 Adjust the factors caused the problem
When the fault indicator is on, press FUNC button to see the fault code and warn code. Fault
and warn codes are listed as following:
DS-I 1-3k UPS User Manual
Trouble Shooting
20
Warn: Bypass
voltage abnormal
Bypass voltage is out
of bypass range or is
off
Check if utility power is indeed out of
range.
24
Warn: Bypass over
load
Load is on bypass and
is overload
Remove some loads to ensure that
total loads is less than 95% of rated
capacity
26
Warn: Bypass
overload timeout
Load is on bypass and
overload. Overload
time is longer than the
overload capacity of
bypass. UPS will
shutdown output and
loads will loss power.
Remove some loads and restart
UPS again. When UPS is working
normally, turn on loads one by one.
30
Warn: Transfer
times over limit in
1 hour
Transfer times
between inverter and
bypass is over 5 in
recent 1 hour. UPS
works in bypass mode.
Check if output is overload or some
loads are shorted. Remove the
failure loads and restart the UPS or
wait for starting inverter
automatically.
32
Warn: output
shorted
Something shorted
Please remove all loads from UPS
output. Check if UPS output is
shorted. If not, please check all
loads.
34
Warn: End of
discharge
UPS works in battery
mode for long time
after utility failure. UPS
output will be off until
utility power is on.
Please save your data when UPS
alarm “utility fail”
38
Warn: Battery test
failure
Battery capacity is low
or load is low.
Please ensure that battery voltage is
higher than 36VDC and the load is
more than 30%.
47
Fault: Rectifier
fault
Bus over voltage, bus
unbalance, rectifier
starting failure, bus
under voltage, input
fuse is off
Please contact with distributer or
service center.
20 DS-I 1-3k UPS User Manual
Trouble Shooting
49
Fault: Inverter fault
Inverter over voltage,
inverter under voltage,
Please contact with distributer or
service center.
51
Fault: UPS over
temperature
Environment
temperature is higher
than permitted point,
ventilation is blocked
Please ensure that nothing blocks
ventilation and environmental temp
must be 0~40C
53
Fault: Fan failure
One or more fans are
failure, fan wires are
loosen
Please contact with distributer or
service center
55
Fault: Inverter
overload
Loads are on inverter
and over the capacity
of the UPS
Remove some loads to ensure that
total loads is under the capacity of
the UPS
57
Fault: Inverter
overload timeout
Load is over the
capacity of the UPS
and timeout, UPS will
transfer to bypass
mode if bypass is
available
Remove some loads to under 95%,
UPS will transfer to inverter
automatically
65
Fault: Battery low
UPS works in battery
and battery voltage is
low
Recover input power or save data
upon “battery low”
71
Fault: Charger
fault
There is no charger
output.
Please contact with distributer or
service center
72
Warn: input over
current
Abnormal large current
enter in rectifier.
Please contact with distributer or
service center
74
Warn: Manual
shutdown
UPS will shutdown
output or transfer to
bypass mode
/
/
Battery discharge
time diminishes
The battery has not
been fully charged
Charge the battery for more than 10
hours
UPS is overload
Check the loads and remove some
devices
Battery aged
Replace the batteries. Please
contact with distributer or service
center to obtain replacement
DS-I 1-3k UPS User Manual
Trouble Shooting
components for batteries.
82
Output CT fault
Output CT assembled
mistakenly
Check if the output CT has been
assembled mistakenly. Assemble the
output CT as the device package on
PCB.
NOTICE
Please provide the following information when reporting fault UPS:
1) The UPS model and serial NO.
2) The warn and fault code happened
3) Detail of fault, include LED indicates, buzzer beeps, power condition, load capacity
and configuration of battery(long backup time model)
22 DS-I 1-3k UPS User Manual
Intelligent Slot
12~24VDC
Bypass mode
1
6
2
3
4
5
9
8
7
Battery low
UPS is on
Utility fail
UPS fail
General alarm
Remote
shutdown
GND
VCC
Function
Description
UPS fail
Low voltage if something is failure in UPS. If not, high voltage
General alarm
Low voltage if something is abnormal. If not, high voltage
GND
Common connection
Remote shutdown
UPS shutdowns rectifier and inverter if utility is normal. UPS
shutdowns completely if in battery mode. Close switch to activate.
Power supply
12VDC~24VDC, external power supply
Bypass mode
High voltage if UPS works in bypass mode. If not, low voltage
Battery low
Low voltage if battery voltage is low. If not, high voltage
Normal mode
High voltage if UPS works in normal mode. If not, low voltage
Utility fail
Low voltage if utility is failure. If not, high voltage.
Annex A. Intelligent Slot
There are two types of intelligent slot for option: DB9, phoenix terminator.
Max output current for intelligent slot is 1A.
The functions of intelligent slot are listed as fig.7:
(a)DB9 (b) Phoenix port
Fig.7 User wiring diagram of intelligent slot
Description of intelligent slot:
DS-I 1-3k UPS User Manual
Rated Parameters Setting
Position
Name
Purpose
P1 ＋24V
+24V, internal power supply
P2
EPO_NO
EPO is activated when shorting with +24V
Model
BP-1000
BP-2000
BP-3000
DC
36V
72V
2x0Vac 96V,
1x0Vac 72V
Battery type
12V7Ah 3pcs 2set
12V7Ah 6pcs 1set
12V7Ah 8pcs 2set
12V7Ah 6pcs 1set
12V9Ah 3pcs 2set
12V9Ah 6pcs 1set
12V9Ah 8pcs 2set
12V9Ah 6pcs 1set
Dimension
(W*D*H)
144×353×222mm
1x0Vac : DC72V 14x353x222mm
2x0Vac : DC96V 190×502×335mm
Weight (kg)
16kg
20kg
DC96V 47kg, DC72V 20kg
Annex B. EPO / External Battery Pack
EPO
EPO (emergency power off) is function to shutdown UPS completely at emergency condition.
This function can be activated through a remote contact provided by the user. It requires
opening NO and +24V at normal operation. EPO is activated when shorting NO and +24V.
Description of Input Port for Remote EPO
EXTERNAL BATTERY PACK
Notice: 1. Please re-start the UPS after finish the parallel connection.
2. please finish the battery charging (8~16 hrs) before using.
SPEC of Battery pack
24 DS-I 1-3k UPS User Manual
Rated Parameters Settingot
VAC
INPUT
VAC
OUTPUT
CONVERTER
BYPASS
LOAD
Current Rated
Voltage
INPUT
OUTPUT
LOAD
CONVERTER
BYPASS
Current Rated
Frequency
Hz
Hz
Annex C. Rated Parameters Setting
Rated parameters of DS-I (L) 1-3K UPS can be set from panel. Please set rated parameters in
according to the following procedures:
1) Start UPS power supply and ensure that rectifier, inverter, bypass and discharge are not
working.
2) Press ON/OFF and FUNC together for 2.5 seconds to enter in setting mode, all LEDs
flicker.
3) Voltage setting: press FUNC to change rated voltage. Shown as following:
4) Frequency setting: Press ON/OFF to choose voltage and enter in frequency setting. Press
FUNC to change rated frequency. Shown as following:
5) Mode setting: press ON/OFF to choose frequency and enter in mode setting, press FUNC
to change mode. First code: n-normal mode, E-ECO mode. Second code indicated
current voltage/frequency are listed in description of main menu in section 6.
DS-I 1-3k UPS User Manual
Rated Parameters Setting
INPUT
OUTPUT
LOAD
MODE
CONVERTER
BYPASS
Current
mode
Current
votlage/frequency
INPUT
OUTPUT
LOAD
CONVERTER
BYPASS
Protocol
Current
setting
VAC
INPUT
OUTPUT
LOAD
MODE
CONVERTER
BYPASS
Hz
Current voltage Current frequency
Current mode
Current protocol
6) Protocol setting: press ON/OFF to choose mode and enter in protocol setting. Codes are
shown in LOAD, press FUNC to change protocol. First code: 0-Modbus, 1-SNT,
“CC”-current protocol.
7) Press ON/OFF to choose protocol and display current setting.
8) Press ON/OFF to save current setting and exit. If want to change, press FUNC and repeat
the procedures above.
9) If you want to exit from setting mode and give up saving, press ON/OFF and FUNC
10) Restart and check if the setting is right.
26 DS-I 1-3k UPS User Manual
together for 2.5 seconds when in setting mode.
Loading...
