QUALITY YOU CAN TRUST

USER MANUAL

9400 SECOND GENERATION

HIGH-SPEED BLENDER

CONTENTS

SAFETY FIRST 1

GETTING TO KNOW YOUR OPTIMUM 9400 SECOND GENERATION 3

CONTROL PANEL 4

OPERATING INSTRUCTIONS 5

BLENDER CLEANING AND MAINTENANCE 6

TROUBLESHOOTING 7

PRODUCT SPECIFICATIONS 7

BLADE ASSEMBLY 8

WARRANTY TERMS & CONDITIONS (INTERNATIONAL) 9

SAFETY FIRST

WHEN USING ELECTRICAL APPLIANCES, YOU SHOULD ALWAYS BE AWARE OF AND FOLLOW BASIC SAFETY PRECAUTIONS INCLUDING:

1. Read and follow all instructions and warnings in this manual carefully.

2. Unplug the power cord from the power outlet before assembling, disassembling, cleaning or putting

your hands near any moving parts of the appliance to avoid injury.

3. To protect against the risk of injury due to electric shock, do not immerse the base of the Optimum 9400 Second Generation in water or any other liquid.

4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they are supervised or have been given instruction concerning the use of the appliance by a person responsible for their safety.

5. Do not blend carbonated liquids.

6. Do not pour boiling water into the blending jug.

7. Do not blend liquids for more than 7 minutes.

8. Do not operate the blender if the power cord or plug are damaged, or if it malfunctions or is

damaged in any way. Return the appliance to the nearest authorised service facility for inspection or repair. Do not attempt to repair the appliance yourself to avoid the risk of injury.

9. The use of attachments, including canning jars, is not recommended by the manufacturer and presents a risk of injury.

10. Do not use the blender outdoors.

11. Place the appliance on a ﬂat, stable and level surface, away from any water or heat sources and

avoid hanging the cord over the edge. Do not use the appliance on carpets, towels, plastic, paper, or ﬂammable surfaces.

12. Never use your hands or utensils while blending to prevent the risk of injury and damage to the appliance. You can use a plastic scraper but only after the blender has come to a full stop.

13. Exercise extra care when handling the blades, which are very sharp.

14. Never operate the blender without its lid ﬁrmly in place.

15. Use water to clean the appliance and all detachable parts, which come into direct contact with the

ingredients, after every use. Do not use abrasive materials, harsh cleansers or corrosive liquids (e.g. acids, acetone, etc.) to clean the appliance.

16. Never operate the blender without the cushion pad. Replace it if it becomes worn.

17. Do not ﬁll the blender above the MAX FILL LINE.

18. If the jar overﬂows during blending. Stop, remove any liquid/ingredients above the MAX FILL LINE,

and resume blending. Do not operate if overﬂowing.

19. Do not operate the blender in an appliance garage to prevent the risk of injury or ﬁre. When storing in an appliance garage, always unplug the unit from the electrical outlet.

20. The use of ear protection is recommended during extended operating periods.

21. Ensure the jar and motor couplers are aligned and locked before operating. If unable to lock, remove

the container and shake the contents before trying again.

22. Do not touch the coupling seal after blending as it may be hot.

OPTIMUM 9400 SECOND GENERATION // 1

TO RESET THE UNIT

The 9400 Second Generation blender is equipped with an intelligent protection chip to protect the motor. If the motor shuts down, unplug the blender and let it rest for approximately 15 minutes. Then, plug the blender again and resume blending. If your blender still doesn’t work properly, following this procedure, stop using it and contact the distributor.

FAILURE TO FOLLOW SAFETY INSTRUCTIONS AND WARNINGS COULD RESULT IN

SERIOUS INJURY. MISUSE OF YOUR BLENDER MAY DAMAGE YOUR APPLIANCE AND

VOID YOUR WARRANTY.

2 // OPTIMUM 9400 SECOND GENERATION

GETTING TO KNOW YOUR OPTIMUM 9400 SECOND GENERATION

1. Small lid and 130ml measuring cup.

2. Tight-seal blending jug lid.

3. Blending Jug: 2 litre BPA free jug made by Eastman Tritan. Includes Imperial and Metric graduation.

4. Removable cushion pad.

5. Motor base, which houses the high performance motor.

6. Tamper: using the tamper maintains circulation by preventing air pockets from forming during

blending.

OPTIMUM 9400 SECOND GENERATION // 3

CONTROL PANEL

PRESET PROGRAMS

OPERATING INSTRUCTIONS

1. Place the blender base on a clean, dry, ﬂat, and sturdy surface.

2. Place the blending jug on the motor base.

3. Place all the ingredients in the jug and cover the jug with the lid. Secure the measuring cup to the

lid by turning it counter-clockwise. You can add soft ingredients during the blend cycle by removing the measuring cup and dropping ingredients through the ﬁll area but always close the lid with the measuring cup after adding any ingredient. Do not add ice or hard ingredients while the blender is running.

4. Plug the power cord into an electrical outlet. Do not put your hands in jar when the blender is

plugged in.

5. Make sure the dial in in the OFF position. Then, turn the dial to select the preferred manual mode or

preset program.

6. Start blending.

SPEED

CONTROL

MANUAL MODES

SPEED Simply turn the dial clockwise to activate and increase the speed of the blender and counter-

clockwise to decrease and stop blending.

TIME Turn the dial clockwise and allow the blender to run for the desired amount of time, turn the dial

counter-clockwise when the operation is completed.

Important: Do not blend liquids for more than 7 minutes.

4 // OPTIMUM 9400 SECOND GENERATION

OPERATING INSTRUCTIONS

PRESET PROGRAMS

The Optimum 9400 Second Generation blender comes with six (5) preset functions (Ice and Cleaning, Juice, Milkshake, Nuts and Hot Soup) for quick results.

To use one of the preset functions, simply turn the dial to the corresponding icon. The blender will stop automatically when the operation is completed. See below for each function's running time.

ICON FUNCTION DURATION

Ice and Cleaning 45 seconds

Juice 60 seconds

Milkshake 80 seconds

Nuts 70 seconds

Hot Soup

(Be sure not to exceed the MAX FILL LINE)

Seven minutes

OPTIMUM 9400 SECOND GENERATION // 5

BLENDER CLEANING AND MAINTENANCE

Always clean your Optimum 9400 Second Generation after each use for hygiene purposes and to ensure its longevity. Leaving food in the blender is a health risk as bacteria can grow. It can also cause the blending jug to stain. Bacteria and residual food acids can also damage the seals and shaft of the blades.

TO CLEAN THE BASE:

1. Switch o and unplug the blender from the power outlet.

2. Using a soft, damp cloth, wipe the surface of the blender's base. You can use a mild detergent to

remove dried food if required. Never immerse the motor base in water or other liquids.

3. Use a dry soft cloth to thoroughly dry the blender.

TO CLEAN THE BLENDING JUG:

1. After each use, rinse the blending jug thoroughly with warm soapy water (not hot).

2. Place one or two drops of dish soap in the jug and ﬁll it halfway with warm water.

3. Secure the lid and mount on the base.

4. Start the blender at LOW and slowly increase to level 5 speed.

5. Run on level 5 for 10-60 seconds (depending on what was blended; thick contents take longer

toclean).

6. Pour the contents out and rinse thoroughly.

7. Turn the blending jug upside down and let air dry.

Remember: The blending jug, blade assembly and lid assembly are all dishwasher safe (place on the top

shelf of the dishwasher only).

FOR A DEEP CLEAN, PERFORM THE FOLLOWING STEPS MONTHLY OR AS NEEDED:

Place 2 cups of cool water and 2 cups of white vinegar into the blending jug and let them soak for between 12 and 24 hours. Pour the contents out and rinse thoroughly. Then follow the appropriate cleaning instructions above.

6 // OPTIMUM 9400 SECOND GENERATION

TROUBLESHOOTING

PROBLEM SOLUTION

It’s not working!

My blender stopped working half way through blending...

During blending, the contents do not appear to be moving.

Why is my jar cloudy or stained? How can I clean it?

My blender is emitting a strong electrical smell.

Check that the blender is plugged into the outlet and that the power is on.

Your blender may have overheated. When blending thick ingredients (dates, nut butters, etc.) the appliance must be used at the highest speed. Allow the machine to cool down for 30-45 minutes before turning it back on.

The blending jar may be overloaded or there may be a trapped air bubble. You can carefully remove the lid and try adding more liquid or reducing the quantity of ingredients in the jar.

The minerals from fruits and vegetables, such as leafy greens, can cause a ﬁlm to build up on the inside of the blending jar. Follow the instructions for cleaning.

The smell will dissipate after a few uses and the lubricants will wear o after 20-50 cycles.

PRODUCT SPECIFICATIONS

Product Optimum 9400 Second Generation

Model 9400A

Rated voltage 220-240V

Rated frequency 50-60Hz

Rated power 1500W

Max motor power 2400W

Weight 5.3kg

Dimensions 191×191×456mm

Only for EU countries. Do not dispose of electric appliances with household waste material!

As stipulated by European Directive 2002/96/EC on waste electrical and electronic equipment and in accordance with national laws, electric appliances that have reached the end of their life cycle must be collected separately and returned to an environmentally compatible recycling facility.

OPTIMUM 9400 SECOND GENERATION // 7

BLADE ASSEMBLY

DOES MY BLADE ASSEMBLY NEED REPLACING?

Even the toughest blade assemblies eventually wear out and need replacing. Replacement frequency is based on use. We recommend that you inspect your blade assembly once a week, following the instructions below. If the inspection shows you need a replacement blade assembly contact us at www. internationalwarrantysupport.com.

⊲ If any of the following are present, your assembly needs replacing: nicks, cracks or gouges in the

outer surface.

⊲ Inspect the gears of the blade assembly; the teeth that mesh with the motor unit should be deep and

have continuous edges.

⊲ Inspect the seal, on the bottom of the blade assembly below the gear; if it is missing, lifting or torn,

replace the assembly.

⊲ With the blade assembly in your hand, rotate the blade, checking that it moves smoothly with a

constant and slight resistance.

⊲ Check the blade assembly for vertical movement: holding the assembly in one hand, use the other to

push up and down on the gears. If you feel any vertical movement, it’s time to replace the blade.

As a general rule, the blade assembly should be replaced when:

⊲ The seal is damaged and missing or bearings are visible ⊲ The blades move vertically ⊲ The blades move side-to-side ⊲ There are noises from the blade assembly ⊲ The blade spins without any resistance when testing by hand ⊲ The blade is either dicult to spin or will not spin at all, when testing by hand

CAUSES FOR BLADE ASSEMBLY WEAR

While many factors can cause the blade assembly to wear out, the following are often to blame:

⊲ Washing incorrectly, either in a dishwasher or by using a bleach sanitizer stronger than 100 ppm ⊲ Blending abrasive products (sand, etc.) ⊲ Using parts not approved by Optimum ⊲ Operating the blender with foreign objects in the container ⊲ Incorrect operation of the blender, including: removing or placing the container on the drive socket

while it is spinning, forgoing the use of the centering pad, rocking or tilting the blender while in operation

⊲ Worn drive sockets can also cause damage to the blade assembly

8 // OPTIMUM 9400 SECOND GENERATION

WARRANTY TERMS & CONDITIONS (INTERNATIONAL)

This warranty as outlined below solely covers distributors of the Optimum range of products. Please contact your distributor for full product warranty.

Eective as of 1st January 2014

1. Optimum® warranties this product against defects in materials and workmanship for a period of 2 years from the

original date of purchase when used in accordance with the accompanying instruction manual.

2. Any warranties exceeding this standard period are oered as extended terms by the selling distributor and

claimable only though that provider.

3. Defects that occur within this manufacturer’s warranty period, under normal use and care will be repaired or

replaced at our discretion only if the selling distributor is unable to do so. This is done solely at our option with no charge for parts. This warranty does not extend to accessories included or purchased separately. Replacements can be oered for major faults as determined by your distributor and at their own discretion.

4. In the event that the goods requiring repair are under warranty, and this distributor is unable to provide the repairs;

the customer is responsible for any freight charges to or from Optimum® (or their approved service provider).

5. Whilst in transit the goods are at the owner’s risk and any further damage during this transportation is not covered

under warranty.

6. Customers should ensure that the product being returned is properly packaged so as to ensure that no damage

occurs to the product during transit. To be able to process the warranty claim ensure you have included an explanation of any problem, Optimum® will not fault-ﬁnd and will only repair described faults as covered under warranty.

7. This full warranty is void if this product has been subject to abuse, negligence, accident, alteration, failure to follow

operating instructions, or the product has been exposed to abnormal or extreme conditions.

8. Cosmetic changes that do not aect performance, such as discolouration of parts of the product in the hands of

the user or the eects of the use of abrasive cleaners will not be warranted or considered defects. The cleaning or removal of food products along with any damage caused by allowing them to build up is not covered by this full warranty.

9. This warranty does not cover normal wear and tear of the product or parts.

10. This warranty does not cover any defect caused by an accident, misuse, abuse, improper installation or operation,

lack of reasonable care, unauthorized medication, loss of parts, tampering or attempted repair by a person not authorized by Optimum®.

11. The warranty will not apply if damage, malfunction or failure resulting from alterations, accident, misuse, abuse,

ﬁre, liquid spillage, maladjustment of customer controls, use on an incorrect voltage, power surges and dips, thunderstorm activity, acts of God, voltage supply problems, tampering or unauthorized repairs by any persons, use of defective or incompatible accessories, exposure to abnormally corrosive conditions or entry by any insect, vermin or foreign object in the product.

12. This warranty does not cover damage resulting from the use of an alternate power source (e.g. solar, inverter,

generator) and the use of these devices to power your appliance is not recommended.

13. You must keep your purchase receipt as proof of purchase and as proof of the date on which the purchase was

made. The purchase receipt must be presented when making a claim under this warranty.

14. In the event the receipt of purchase is not presented, then this warranty is invalid. Consumer Law allows us to

request reasonable proof of purchase to service a warranty claim.

15. This warranty does not imply, intend to or detract from any consumer rights listed in and able to be enforced from

Regulated Consumer Law, any condition which is found to be in breach of the consumer law, the single condition shall be void only and all other conditions remain in place.

OPTIMUM 9400 SECOND GENERATION // 9
