STEAM
MOP
Simple and easy to use
for cleaning hard floors &
carpeted surfaces.
1
9
2
3
10
4
5
11
6
7
8
2.
O2800 Steam Mop
Congratulations on the purchase of your new Optim Steam Mop. There
are many useful features built into your steam mop. We recommend that
yo u caref u lly re a d this instru c t ion manu a l for th e best res ults.
Features:
1. Handle
2. Cable Hook
3. Cord Storage Hook
4. Hight Adjustment Button
5. Rod
Accessory:
9. Carpet Glider
10. Refill Cup
11. Mop Pads (2pcs)
Specifications:
Wattage: 1600W
Water Tank Capacity: 25 0 m l
Cord Length: 4 . 8m
6. Power Cord
7. Water Tank
8. Mop Head
Please contact Godfreys Customer Care 1800 815 270, to find your local
spare parts provider.
3.
Before You Begin
PLEASE READ THIS MANUAL BEFORE OPERATING CLEANER
This will ensure you obtain full benefit from your new steam mop. Keep this
Instruction Manual in a handy place for future reference.
IMPORTANT
Always ensure that the cleaner is in the fixed upright position and that the power
plug is removed from the power supply before cleaning your appliance, when
not in use, or attempting any maintenance task. This cleaner should only be used
for its intended purpose as described in these instructions.
PRECAUTIONARY MEASURES:
1. Do not operate the steam mop too close to heaters, radiators or
other hot surfaces.
2. Before inserting the power plug into the power supply, make sure
your hands are dry.
3. When unplugging the power plug from the power supply, do not
us e the power cabl e , gentl y pull th e powe r plug fr o m the power
supply.
BEFORE YOU CLEAN, TEST FIRST
You r steam mo p is des i gned to clean ha rd floori n g such as
ceramic tiles, vinyl, laminate, marble, stone and sealed hard wood
floors. Use of your steam mop on waxed or some unwaxed floors
may result in a diminished gloss.
Th e steam mo p is not for use on unseale d wood floo r s . For the
best results test in an inconspicuous area and check the care
instructions from your flooring manufacturer.
4.
WARNING! To reduce the risk of fire, electric shock or injury when using
an electrical appliance, basic precautions should always be followed,
including the following:
1. This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use
of the appliance by a person
responsible for their safety.
2. Always check the power cord
before use. The power cord and
the power plug should be in a
good condition and must not be
damaged. If the power cord is
damaged or defective, it must be
replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
3. Do not leave the appliance
unattended when plugged into
the power supply. Unplug the
power plug from the power
supply when not in use and before
conducting maintenance, cleaning
or troubleshooting.
4. To prevent electric shock, do not
use the appliance outdoors. The
steam cleaner is intended for
household use only.
5. Children must be supervised to
ensure that they do not play with
the appliance.
6. Do not operate the appliance in a
stationary position for an extended
period of time. Keep the appliance
moving while in operation.
7. Use only the manufacturer’s
recommended attachments.
8. Do not pull or carry the appliance
by the power cord, do not use the
power cord as a handle, do not
close a door on the power cord or
pull the power cord around sharp
edges or corners.
9. Keep the power cord away from
heated surfaces.
10. Do not run the steam cleaner over
the power cord.
11. Do not unplug by pulling on the
power cord. To unplug, grasp the
power plug not the power cord
and gently pull the power plug
from the power socket.
12. Do not use an extension cord.
13. Do not handle the power plug or
appliance with wet hands.
14. Do not use steam cleaner if it has
been dropped, damaged, left
outdoors or immersed into water.
Return it to the nearest service
centre.
15. Ensure that the cleaner is fixed
in the upright position before
unplugging the power plug from
the power supply. Remove the
power plug from the power supply
and handle the cleaner with care
when filling the water tank with
water.
16. Do not over fill the water tank.
17. Do not use the cleaner without
the water tank cap in place.
Check that the water tank cap is
completely closed before use.
18. Do not operate the cleaner
without water in the water tank.
Before You Begin
5.
19. Do not fill the water tank with
anything other than water. Never
put additives (such as perfume
disinfectant, eucalyptus oil, stain
remover or products containing
alcohol) in the water tank as damage
to the cleaner may result or make the
cleaner dangerous to use.
20. Empty the water tank after each use.
21. Do not touch any hot areas on the
steam cleaner. It is normal for the
steam cleaner to heat up during
operation.
22. The force and heat of the steam
may have an adverse effect on some
materials. Always test the cleaner on a
small concealed area to determine if it
is suitable for treatment.
23. Accessories become hot during use.
Allow them to cool down before
handling them.
24. Use only the manufacturer’s
recommended attachments. Use of
WARNING: Danger of scalding. Please use the steam mop with
caution. The steam emitted from the steam mop is very hot.
CAUTION: Recently cleaned surfaces may be hot, please avoid
contact.
attachments that are not provided or
sold by the manufacturer may cause
fire, electric shock or injury.
25. Never point or aim the steam cleaner
at people, animals or plants.
26. Do not aim the steam cleaner at
electrical systems or wires.
27. Connecting the steam cleaner to
improper voltage may result in
damage to the steam cleaner and
possible injury.
28. Do not use steam cleaner if there
are visible signs of damage or if it is
leaking.
29. Do not use the cleaner on leather, wax
polished furniture or floors, synthetic
fabrics, velvet or other delicate, steam
sensitive materials.
30. Never put descaling, aromatic,
alcoholic or detergent products into
the water tank, as this may damage
the cleaner or make it unsafe for use.
6.
Assembling
IMPORTANT! The appliance should be disconnected from the power
supply before you start to assemble.
1. Insert the handle into the main body
until it locks into position.
2. Insert the main body into the mop head
ensuring that it clicks into place.
3. Secure the mop head to the main body
with the screw provided, as shown.
4. Attach the mop pad onto the base of
th e mop head.
Before You Begin
7.
Instruction for Use
Attention: DO NOT refill the tank when the mop is connected to mains power
supply. Only refill the water tank with cold tap water.
Before You Begin Cleaning
1. Unscrew the water tank cap and fill the water
tank with cool tap water by using the refill cup
provided.
2. Ensure that the cleaner is standing vertically
and in the fixed position. With your foot placed
on to the mop head pu s h the han d l e forwa rd to
place the cleaner into the fixed position.
3. Adjust the height of the rod by pressing the
Hei g ht Adj ustment Button . Ensure the power
cab l e is secu red into the ca b le hook.
IMPORTANT: Do not operate the cleaner over the
power cable.
4. Plug the power plug into the power supply. The
LE D light on the mai n body wi ll ill u minate when
th e cleaner is ready for clea n ing.
Note: Upon initial use, please allow the water to
flow through the system for approximately 30
seconds to prime the unit.
8.
Steam Cleaning Hard Floors
NOTE: Before using the steam mop, sweep or vacuum the floor to
remove any loose dirt or debris.
IMPORTANT: Do not use the cleaner without a mop pad attached to the
mop head.
WARNING: Hard floor wax may be removed by the heat and steam
action. Do not use the cleaner on unsealed wood floors or operate the
cleaner in a stationary position for an extended period of time.
release steam
stop steam
1. With your foot placed onto the mop
head, pull the handle backwards to
unlock the cleaner. The cleaner will
emit steam in the unlocked position.
When steam is emitting from the
cleaner slowly pass over the surface to
be cleaned.
2. With your foot placed onto the mop
head push the handle forward to place
the cleaner in the fixed position. The
cleaner will stop emitting steam in the
fixed position.
Instruction for Use
9.
Steam Cleaning Carpets
NOTE: Before using the steam mop, vacuum the floor to remove any loose dirt or
debris.
IMPORTANT: Do not use the cleaner without a mop pad and carpet glider
attached to the mop head.
1. Place the cleaner onto the carpet glider.
2. Plug the cleaner into the power supply.
3. With your foot placed onto the floor head, pull
th e handle ba c k wards to unlo c k the cl e aner.
The cleaner will emit steam in the unlocked
position.
4. Move the cleaner slowly backwards and
fo r wards payin g par ticu l a r atte ntion to hig h
traffic areas.
stop steam
10.
5. With your foot placed onto the floor head push
th e handle fo r ward to lock the clea n e r. The
cleaner will stop emitting steam in the locked
position.
Maintenance
WARNING! The appliance should be in the fixed position and disconnected from
the power supply before performing any maintenance tasks.
IMPORTANT: Always ensure that cleaner has cooled before performing any
maintenance tasks.
Emptying the Water Tank
1. Remove the water tank cap.
2. Empty any excess water from the water
tank.
Note: the water tank should be emptied after
each use.
3. Replace the water tank cap.
Instruction for Use
11.
Removing and Cleaning The Mop Pad
1. Wash the mop pad in a washing
machine with a mild detergent at a
max temperature of 40°C.
IMPORTANT: Do not use bleach or fabric
softener when washing the mop pad.
12.
Troubleshooting
Problems and Solutions
If you come across a problem, please use this checklist before
contacting Godfreys Customer Care 1800 815 270.
Fault Solutions
The cleaner will
not produce
steam.
The cleaner
leaves too
much water on
the floor.
1. Ensure that the cleaner is plugged into the power
supply and that the cleaner is in the unlocked
position.
2. Ensure that the water tank is filled with cold water.
3. Remove the water tank cap and reinstall the water
tank cap securely.
1. Replace with a dry mop pad.
13.
Maintenance
Spare Parts
Part Part Number
Steam Mop Pads 2pk 31400144
14.
Troubleshooting
15.
STEAM
MOP
Conditions of warranty
Your OPTIM Steam Mop, in the case of
domestic use, has a 3 month parts and labour
warranty against product defects and failures
when the product is used in accordance with
the terms and conditions of this warranty
statement.
This warranty commences from the original
date of purchase and is not transferable;
please retain your original proof of purchase
for any warranty claims. This warranty is
valid only in the country where the cleaner
is purchased.
The cleaner must be operated in accordance
with these instructions and used only for
domestic household cleaning to remove
DRY dirt and dust from household carpets,
flooring and fabrics. This cleaner is not fit
to be used as an industrial cleaner, and is
not designed for the collection of vitreous
building material including particle board,
construction products and similar products
such as wood/fibres, cement, fillers, fibre
glass etc. or excessive or frequent sand.
The infrequent pick-up of these materials in
these circumstances may be harmful to your
cleaner and may void the manufacturer’s
warranty.
Accessories and consumables including
dust bags and filters, unless defective in
manufacture, are not subject to this warranty.
In order to prolong the life of accessories and
consumables, regular care and maintenance
is recommended.
When properly used and cared for, your
cleaner will render excellent service; refer to
the instruction manual for further details, as
misuse or failure to follow the instructions
makes this warranty void.
In the event of service or advice being
needed, please contact Electrical Home-Aids
Pty Ltd, Ground Level, Building 3, Brandon
Business Park, 530 Springvale Road, Glen
Waverley Victoria 3150, or on 1300 360 845,
Monday-Friday 9am-5pm EST. The decision
to repair or replace the cleaner is at the
sole discretion of Godfreys Customer Care.
If Godfreys Customer Care decide to repair
or replace the cleaner, it will do so at its own
cost.
Optim Floorcare is unable to accept
responsibility under this warranty for any
repair work not carried out by an authorised
Optim Service Agent or from the use of
non-genuine parts. If any part is no longer
available or manufactured, Godfreys
Customer Care will replace it with a genuine
functional replacement part. This warranty
does not apply to the cost of replacing any
parts of the product due to normal wear
and tear, alterations, improper installation,
physical abuse, misuse or accidental damage.
Any transportation costs involved in the
repair of defective parts shall be borne by
the claimant.
If proof of purchase cannot be provided at
the time of a warranty claim or service, any
work carried out on the cleaner is chargeable.
The repair or replacement of the cleaner
under this warranty does not extend the
original period of warranty.
The benefits conferred by this warranty are
in addition to all other rights and remedies in
respect of the product as outlined under the
Competition and Consumer Act and other
State and Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund
for a major failure and for compensation for
any other reasonably foreseeable loss or
damage. You are also entitled to have the
goods repaired or replaced if the goods fail
.”to be of acceptable quality and the failure
does not amount to a major failure.”
V1 0 6/17
Loading...
