TB-3W
v 4.0 2020
Tablet PC with Camera for C-mount
connection
PC Camera resolution (MP) 3.1
Camera resolution (n° of pixels: W x H) 2048x1536
USB Signal output USB 2.0
Color / Monochrome Color
Sensor Size 1/2"
Sensor Technology CMOS
Sensor Type APTINA CMOS
Rolling Shutter Yes
Image Format 4/3
Pixel Size (mm)
3.2x3.2
Frame rate full resolution (fps) 12@2048x1536
Frame rate other resolution (fps) 32@1024x768; 45@680x510
Sensitivity 1 V/lux-second
Signal/Noise Ratio (DB) 43
Dynamic range (DB) 61
ADC conversion 8 Bit
Color Depth 1, 4, 8, 24 Bit
Exposure time 0.244 msec - 2 sec
Binning 1x1; 2x2; 3x3
IR filter Yes
IR filter range (nm) 380-650 (IR CUT)
Camera Power PC USB
C-Mount Yes
Dimensions (mm) 58 x 58 x 36.4
Weight (Kg) 0.18
Optical adapter (for 23mm eyepiece tube) 0.5x
Calibration slide Yes
Working Temperature -10°C up to +50°C
Storage Temperature -20°C up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
OS Windows 10 (64Bit)
SW PROVIEW
Warranty
Years 2
Operating system Windows 10 (64Bit)
CPU Intel® Atom™ Z8350, Quad core
CPU speed 1.44 GHz
Graphic card Intel® HD Graphics 400
RAM Ram 4 GB LPDDR3
Display size LED 10.1” IPS Multi Touch Screen
Display resolution 1920x1200
Storage Hdd 64 GB
Network Wireless - Bluetooth 4.0
Input ports
Micro USB (OTG) - USB Type-C - Micro SD card
reader
Output ports Microphone - Headphone - Micro HDMI
Tablet
Camera specifications
Camera accessories
Environment
specifications
Operating System
Available Software
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Battery Type Lithium-ion
Battery capacity 6500 mAh
Power consumption 15W
Power supply 5V 3A
Dimensions (mm) 261X167X9
Weight (Kg) 0.53
Language Multilanguage
OTG cable (micro USB-B to USB-A) Yes
USB cable USB-B to USB-A (0.5m) Yes
Keyboard As optional
Touch pen Yes
Tablet
Tablet accessories
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
