Optika SZO-4 Data sheet [EN]

SZO-4
v 1.1 2019
Trinocular stereozoom microscope,
6.7x...45x, pillar stand, transmitted & incident light
Brightfield Yes
Brightfield Yes
Type Trinocular
Construction material Plastic mold / Aluminum gears
Split ratio Fixed. 70 (eyepiece) / 30 (photo)
Inclination 45°
360° rotating Yes
Interpupillary distance (mm) 51-75
Fixing screw for eyepieces Yes
Head holder internal diameter (mm) 76
Tube inner diameter (mm) 30
Field number (mm) 23
Magnification 10x
Planar type Yes
Diameter of micrometer glass (mm) 26
High eyepoint (for glass wearers) Yes
Dioptric adjustment Yes
Rubber cup Yes
Retractable protections Yes
Optical system Greenough
Anti-fungus treatment Yes
Zoom type Parfocal achromatic
Working distance (mm) 110
Standard magnifications 6.7x-45x
Zoom ratio 6.72
Zoom click stops
At 0.67x, 0.8x, 1x, 1.2x, 1.5x, 2x, 2.5x, 3x, 3.5x, 4x,
4.5x
Type Coarse
Coarse total travel (mm) 50
Adjustable tension Yes
Head holder internal diameter (mm) 76
Type Pillar
Pillar diameter (mm) 32
White diffusion plate for transmitted ill. Yes, diameter 100 mm
Black/white contrast plate for incident ill. Yes, diameter 100 mm
Specimen clips Yes
Focusing System Observation Method -
Transmitted Light
Observation Method ­Incident Light
Head
Eyepieces Objective
Stand
Stage
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Type X-LED
X-LED type X-LEDT3
Light source power (W) 4
Illuminance (lux) 8,000
Brightness control Manual
Lifetime (hours) > 65,000
Temperature (K) 6,300
Max. required power (W) 5
Type X-LED
X-LED type X-LED3
Light source power (W) 3.6
Illuminance (lux) 60,000
Brightness control Manual
Lifetime (hours) > 65,000
Temperature (K) 6,300
Max. required power (W) 6
Type External
Microscope connector Jack, 2.1 mm
Power plug type Multi-plug (EU, UK, US)
Input voltage 100/240 Vac, 50/60 Hz
Output voltage 12 Vdc 1.5 A
Dust cover Yes
User Manual Digital version (downloadable)
Additional Information
Maximum sample height (mm): 110
Total height (mm) 315
Head height (mm) 240
Head width (mm) 167
Head depth (mm) 200
Base height (mm) 30
Base width (mm) 210
Base depth (mm) 270
Product Weight
(kg) 4.2
Product Dimensions
Transmitted Illumination
Incident Illumination
Power Supply for Illumination
Accessories Included
