SLX-5
v 1.0 2019
Trinocular stereozoom microscope,
7x...45x, simple overhanging stand
Brightfield Yes
Simple polarized light As optional
Type Trinocular
Construction material Aluminum & Plastic molds / Aluminum gears
Split ratio Fixed. 50 (eyepiece) / 50 (photo)
Inclination 45°
360° rotating Yes
Interpupillary distance (mm) 51-75
Dioptric adjustment On both tubes
Head holder internal diameter (mm) 76
Tube inner diameter (mm) 30
Field number (mm) 21
Magnification 10x
Micrometric scale As optional
Diameter of micrometer glass (mm) 23
High eyepoint (for glass wearers) Yes
Rubber cup Yes
Retractable protections Yes
Optical system Greenough
Anti-fungus treatment Yes
Objective Type Achromatic
Zoom type Parfocal achromatic
Working distance (mm) 100
Standard magnifications 7x-45x
Zoom ratio 6.43
Type Coarse
Coarse total travel (mm) 110
Adjustable tension Yes
Head holder internal diameter (mm) 76
Type Simple overhanging
Pillar diameter (mm) 32
Dust cover Yes
User Manual Digital version (downloadable)
Accessories Included
Observation Method Incident Light
Head
Eyepieces
Objective
Focusing System
Stand
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Additional Information
Maximum sample height (mm): 400 (from bench)
Total height (mm) 435
Base height (mm) 48
Base width (mm) 230
Base depth (mm) 230
Horizontal arm (mm) 415 (overall)
Product Weight
(kg) 17.6
Product Dimensions
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
