SLX-2
v 1.0 2019
Binocular stereozoom microscope,
7x…45x
Brightfield Yes
Brightfield Yes
Type Binocular
Construction material Aluminum & Plastic molds / Aluminum gears
Inclination 45°
360° rotating Yes
Interpupillary distance (mm) 51-75
Dioptric adjustment On both tubes
Head holder internal diameter (mm) 76
Tube inner diameter (mm) 30
Field number (mm) 21
Magnification 10x
Micrometric scale As optional
Diameter of micrometer glass (mm) 23
High eyepoint (for glass wearers) Yes
Rubber cup Yes
Retractable protections Yes
Optical system Greenough
Anti-fungus treatment Yes
Objective Type Achromatic
Zoom type Parfocal achromatic
Working distance (mm) 100
Standard magnifications 7x-45x
Zoom ratio 6.43
Type Coarse
Coarse total travel (mm) 110
Adjustable tension Yes
Head holder internal diameter (mm) 76
Type Fixed arm
Handle Yes
White diffusion plate for transmitted ill. Yes, diameter 100 mm
Black/white contrast plate for incident ill. As optional
Specimen clips Yes
Type EcoLED
Brightness control Manual
Lifetime (hours) > 65,000
Temperature (K) 6,300
Transmitted
Illumination
Focusing System
Stand
Stage
Observation Method -
Transmitted Light
Observation Method Incident Light
Head
Eyepieces
Objective
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Type EcoLED
Brightness control Manual
Lifetime (hours) > 65,000
Temperature (K) 6,300
Type External
Microscope connector Jack, 2.1 mm
Power plug type Multi-plug (EU, UK, US)
Input voltage 100/240 Vac, 50/60 Hz
Output voltage 5 Vdc 500 mA
LED indicator Yes
Rechargeable batteries Yes
Battery type Ni-MH (3x, AA size)
Working time of batteries (hours) 12
Charging time of batteries (hours) 8
Dust cover Yes
User Manual Digital version (downloadable)
Additional Information
Maximum sample height (mm): 100
Total height (mm) 365
Head height (mm) 230
Head width (mm) 140
Head depth (mm) 150
Base height (mm) 30
Base width (mm) 205
Base depth (mm) 280
Product Weight
(kg) 3.5
Incident Illumination
Power Supply for
Illumination
Accessories Included
Product Dimensions
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
