B-153
v 1.0 2019
Monocular microscope, 600x,
HC objectives
Brightfield Yes
Simple polarized light As optional
Type Upright
Construction material Aluminum die-cast
Type Monocular
Inclination 30°
360° rotating Yes
Fixing screw for eyepieces Yes
Tube inner diameter (mm) 23
Field number (mm) 18
Magnification 10x
Pointer As optional
Micrometric scale As optional
Diameter of micrometer glass (mm) 20
Positions Quadruple
Bi-directional Yes
Rotation on ball bearings Yes
Objective thread RMS
Optical system 160
Anti-fungus treatment Yes
Parfocal distance (mm) 45
Standard magnifications 40x-600x
Type HC
Objectives included
4x/0.10, W.D. 18 mm
10x/0.25, W.D. 7 mm
40x/0.65, W.D. 0.53 mm
60x/0.85, W.D. 0.45 mm
Type Double layer
Dimensions (mm) 125x116
Moving mechanism Rack and pinion
Moving range (mm) 70x30
Material Anti-scratch painting
Specimen holder Yes
Slide number 1
X-Y Vernier scale Yes
Vernier scale accuracy (mm) 0.1
Type Abbe
Numerical aperture (N.A.) 1.25
Diaphragms Iris
Centrable Pre-centered
Focusable By rotation
Objectives
Stage
Condenser - Single
Position
Eyepieces
Nosepiece
Observation Method Transmitted Light
Main Body
Head
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Type Coaxial coarse & fine
Coarse total travel (mm) 16
Fine total travel (per single rotation) (mm) 0.4
Fine graduations 100
Fine resolution (µm) 4
Upper stop to prevent contact Yes
Adjustable tension Yes
Type X-LED
X-LED type X-LED1
Light source power (W) 1
Brightness control Manual
Lifetime (hours) > 65,000
Temperature (K) 6,300
Max. required power (W) 1.5
Type External
Microscope connector Jack, 2.1 mm
Power plug type Multi-plug (EU, UK, US)
Input voltage 100/240 Vac, 50/60 Hz
Output voltage 5 Vdc 500 mA
Dust cover Yes
Tension adjustment tool Yes
User Manual Digital version (downloadable)
Additional Information
Mirror for transmitted light (as optional)
Height (mm) 350
Width (mm) 170
Depth (mm) 320
Product Weight
(kg) 4
Focusing System
Transmitted
Illumination
Power Supply for
Transmitted
Illumination
Accessories Included
Product Dimensions
