M-1144
v 2.0 2020
Heating mechanical stage, temperature
controller
Type Double layer
Dimensions (mm) 175 x 145
Moving mechanism Rack and pinion
Moving range (mm) 76 x 51
Material Anti-scratch painting
Specimen holder Yes
Slide number 2
X-Y Vernier scale Yes
Vernier scale accuracy (mm) 0.1
Type External
Instrument connector Jack, 2.1 mm
Power plug type EU Plug
Input voltage 100/240 Vac, 50/60 Hz
Output voltage 6 Vdc 5 A
Control range from 20°C to 50°C
Setting resolution 0.5°C
Measurement resolution 0.1°C
Average error between actual stage temperature
and displayed temperature
± 1°C
Diplay Characters 16, back illuminated
Rotating knob for temperature adjusting Yes
ON/OFF switch Yes
Temperature Control
External Controller
Stage
Power Supply
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
