IS-02
v 1.0 2019
Advanced Inspection system with
overhanging stand and HDMI autofocus
camera
Type Simple overhanging
Pillar diameter (mm) 32
Pillar height (cm) 42
Horizontal arm (cm) 55
Base (mm) 260x210x80
Tilting Yes
Swivel Yes
Total height (mm) 645
Base height (mm) 80
Base width (mm) 210
Base depth (mm) 260
Horizontal arm (mm) 330
Product Weight
(kg) 20
Display size 11.5"
Display resolution 1920x1080
Power plug type Multi-plug (EU, UK, US)
Input voltage 110/240 Vac, 50/60 Hz
Output voltage 12 Vdc 1.5 A
Input ports HDMI
Stand alone use Yes
HDMI Camera resolution (MP) 2
Camera resolution (n° of pixels: W x H) 1920x1080
HDMI Signal output Yes
Trigger Signal output Yes
Color / Monochrome Color
Sensor Size 1/2.8"
Sensor Technology CMOS
Sensor Type SONY EXMOR
Optical Zoom 1x-14x
Digital Zoom 1x-6x
Rolling Shutter Yes
Autofocus Yes
Image Format 16/9
Camera specifications
HDMI Monitor
Product Dimensions
Stand
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Pixel Size (mm) 2.9x2.9
Frame rate full resolution (fps) 60@1920x1080
G sensitivity 1300mV at 1/30sec
Dark Signal 0.34mV at 1/30sec
ADC conversion 8 Bit
Color Depth 8 Bit
Exposure time Auto
Binning 1x1
IR filter Yes
Camera Power 5V 2A
Dimensions (mm) 88 x 72 x 125
Weight (Kg) 0.57
Camera specifications
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
