C-WH5
v 2.0 2021
1080p Full HD+WiFi C-mount Microscope
Camera
General specifications
Sensor
SD Card Still image capture Yes
SD Card Video recording Yes
HDMI output Yes
WiFi output Yes
C-Mount Yes
Dimensions (mm) 65 x 78 x 88
Weight (kg) 0.5
Camera resolution (n° of pixels: W x H) 2592x1944
Color / Monochrome Color
Sensor Size 1/1.8"
Sensor Technology CMOS
Sensor Type SONY
Image Format 16/9
Pixel Size (mm)
Acquisition technology Rolling shutter
G sensitivity 1120mV at 1/30s
Dark Signal 0.15mV at 1/30s
ADC conversion 8 Bit - 12Bit
Color Depth 1, 4, 8, 24 Bit
Exposure time 0.03 msec - 918 msec
Binning 1x1
IR filter Yes
IR filter range (nm) 380-650 (IR CUT)
2.4x2.4
HDMI
WiFi
HDMI resolution (MP) 2
Live HDMI measurement Yes
Exposure Auto / Manual
White Balance Auto / Manual / ROI
WiFi resolution (MP) 5
WiFi Frame rate full resolution (fps)
WiFi Speed 802.11n 150Mbps
WiFi Signal From the camera
WiFi Signal ready About 10 seconds after turning on
25@1920x1080 (WiFi)
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Camera Power Supply
Type External
Connector Jack, 2.1 mm
Power plug type Multiplug (EU, UK, US)
Input voltage 100/240 Vac, 50/60Hz
Output voltage 12 Vdc, 1000 mA
LED indicator Yes
Camera accessories
Environment
Operating System
Available Software
PC requirements
Calibration slide Yes
HDMI cable (1.5m) Yes
Wireless Mouse Yes
16GB SD card Yes
WiFi Adapter Yes
Working Temperature -10°C up to +50°C
Storage Temperature -20°C up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
OS Windows 7
OS Windows 8
OS Windows 10 (32Bit)
OS Windows 10 (64Bit)
PC SW PROVIEW
Camera SW HDMILITE (built-in)
PC CPU: Intel Core2 - 2.8GHz or higher
PC RAM: 2GB or more
PC USB 2.0
General
Image Acquisition
HDMILITE SW Specifications
Archiving Yes
Multi-language menu Yes
Available languages
Chinese Yes
English Yes
French Yes
German Yes
Italian Yes
Japanese Yes
Korean Yes
Thai Yes
Still image mutliple format saving Yes
Video recordiing mutliple format saving Yes
Continuous automatic exposure Yes
Manual exposure Yes
Color acquisition Yes
Numerical Focus Indicator Yes
White Balance Manual
Image enhancement Yes
Zoom in Yes
Zoom out Yes
Image Comparison Yes
Browse of Images and Video Yes
Freeze image Yes
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Horizontal Flip Yes
Verical Flip Yes
Image Processing
Measurements
HDR (High Dynamic Range) Yes
Ruler Overlay Yes
Arrow Overlay Yes
Measurement Overlay Yes
Grids Yes
Live measurement Yes
Still image measurement Yes
Select measurement unit Yes
Available measurements
Line Yes
Angle Yes
Parallel lines Yes
Rectangle Yes
Ellipse Yes
Circle Yes
Annulus Yes
Curve Yes
Arc Yes
Polygon Yes
Export to Excel Yes
