C-P5GS
v 1.1 2019
High Performance USB 3.0 C-mount
Microscope Camera
PC Camera resolution (MP) 5
Camera resolution (n° of pixels: W x H) 2448x2048
USB Signal output USB.3.0
Color / Monochrome Color
Sensor Size 2/3"
Sensor Technology CMOS
Sensor Type SONY EXMOR
Global Shutter Yes
Image Format 5/4
Pixel Size (mm)
3.45x3.45
Frame rate full resolution (fps) 35@2448x2048
Frame rate other resolution (fps) 50@1224x1024
Dynamic range (DB) 70.60
G sensitivity 1146mV at 1/30s
Dark Signal 0.15mV at 1/30s
ADC conversion 8 Bit - 12Bit
Color Depth 1, 4, 8, 24 Bit
Exposure time 0.1 msec - 15 sec
Binning 1x1
IR filter Yes
IR filter range (nm) 380-650 (IR CUT)
Camera Power PC USB
C-Mount Yes
Dimensions (mm) 68 x 68 x 46
Weight (Kg) 0.265
Calibration slide Yes
USB cable (1.8m) Yes
Working Temperature -10°C up to +50°C
Storage Temperature -20°C up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
Environment
specifications
Camera specifications
Camera accessories
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
OS Windows 7
OS Windows 8
OS Windows 10 (32Bit)
OS Windows 10 (64Bit)
OS Osx (MAC Osx) starting from 10.7.5
OS Linux
SW PROVIEW
SW LITEVIEW
PC CPU: Intel Core2 - 2.8GZ or higher
PC RAM: 2GB or more
PC USB 3.0
Warranty
Years 2
PC requirements
Operating System
Available Software
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
