Optika C-HAF Data sheet [EN]

C-HAF
EN
OPTIKA
Model:
C-HAF
Type:
1080P HDMI AUTOFOCUS CAMERA
Description:
CAMERA SPECIFICATION
Digital camera resolution 2 MP (Full HD 1920 x 1080)
Signal output HDMI
Sensor size 1/2.8”
Sensor technology CMOS (progressive scanning)
Sensor type SONY Exmor
Initialization time 15 sec, LED turns ON
Image format 16/9
Pixel size 2.9 x 2.9 μm
Frame rate 60 fps (1920 x 1080) HDMI mode
Sensitivity 1300 mV at 1/30sec
Dark signal 0.34mV at 1/30sec
Binnig 1x1
Exposure time Auto
Exposure mode Auto
White balance Manual / Auto
Image ip Yes
Image mirror Yes
Image capture 1920 x 1080, JPG format
Video capture 1920 x 1080, h264 format, 60 Fps
Image browse No
Control panel features (on screen) Manual focus, brightness, gain, color adjustment, zoom, capture, ip, mirror, HDR
Toolbar Zoom bar
Cross & grid Vertical lines & horizontal lines
Calibration & measurements No
Autofocus function Yes
Stand alone use Yes
Working distance 55mm – innity (low zoom)
90mm – innity (max zoom)
Optical magnication 1x – 14x
Digital magnication 1x – 6x
Remote control port Yes
USB control port Yes, for mouse
For microscope use No
C-mount connection No
CS-mount connection No
Camera power DC 5V 500mA
v 2.0 2018
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
C-HAF
ACCESSORIES
Calibration slide No
Cables HDMI
Memory card microSD 16GB
Mouse Yes, wireless
ENVIRONMENT SPECIFICATION
Working temperature -10 up to +50°C
Storage temperature -20 up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
Dimensions 90 x 72 x 130 mm
Weight 0.6 Kg
SYSTEM REQUIREMENTS
PC requirements None
Screen requirements HDMI port, Full HD 1080p
