C-B18+
v 1.1 2019
USB 3.0 C-mount and Eyepiece
Microscope Camera
PC Camera resolution (MP) 18
Camera resolution (n° of pixels: W x H) 4912x3684
USB Signal output USB.3.0
Color / Monochrome Color
Sensor Size 1/2.3"
Sensor Technology CMOS
Sensor Type APTINA CMOS
Rolling Shutter Yes
Image Format 4/3
Pixel Size (mm)
1.25x1.25
Frame rate full resolution (fps) 5.6@4912x3684
Frame rate other resolution (fps) 18.1@2456x1842; 32.2@1228x922
Sensitivity 0.62V/lux-second
Signal/Noise Ratio (DB) 36.3
Dynamic range (DB) 65.8
ADC conversion 8 Bit - 12Bit
Color Depth 1, 4, 8, 24 Bit
Exposure time 0.1 msec - 2 sec
Binning 1x1; 2x2; 4x4
IR filter Yes
IR filter range (nm) 380-650 (IR CUT)
Camera Power PC USB
C-Mount Yes
Dimensions (mm) 68 x 68 x 46
Weight (Kg) 0.28
Optical adapter (for 23mm eyepiece tube) 0.5x
Adapter ring Yes
Diameter of adapter ring (mm) 30
Diameter of adapter ring (mm) 30.5
Calibration slide Yes
USB cable (1.8m) Yes
Working Temperature -10°C up to +50°C
Storage Temperature -20°C up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
Camera specifications
Camera accessories
Environment
specifications
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
OS Windows 7
OS Windows 8
OS Windows 10 (32Bit)
OS Windows 10 (64Bit)
OS Osx (MAC Osx) starting from 10.7.5
OS Linux
SW PROVIEW
SW LITEVIEW
PC CPU: Intel Core2 - 2.8GZ or higher
PC RAM: 2GB or more
PC USB 3.0
Warranty
Years 2
PC requirements
Operating System
Available Software
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
