C-P6
CAMERA SPECIFICATION
Digital camera resolution 6.3 MP (3072 x 2048)
Signal output USB 3.0
Sensor Size 1/1.8”
Sensor technology CMOS
Sensor type SONY EXMOR CMOS
Image format 3/2
Pixel size 2.4 x 2.4 µm
Frame rate full resolution 30 fps (3072 x 2048)
Frame rate other resolutions 38 fps (1536 x 1024)
Sensitivity 425 mV at 1/30sec
Dark signal 0.15 mV at 1/30sec
ADC Conversion 8 Bit - 12 Bit
Color Depth 1 Bit; 4 Bit; 8 Bit; 24 Bit
Exposure Time 0.1 msec - 15 sec
Binning 1x1; 2x2
IR lter 380-650 nm (IR-cut lter)
Camera power PC USB
C-mount YES
EN
OPTIKA
v 2.0 2018
Model:
C-P6
Type:
CAMERA - PRO SERIES
Description:
USB 3.0 C-mount Microscope Camera
ACCESSORIES
Calibration Slide YES
Always Included 1.5 m USB cable
ENVIRONMENT SPECIFICATION
Working temperature -10 up to +50°C
Storage temperature -20 up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
Dimensions 68 x 68 x 46.4 mm
Weight 0.265 Kg
SYSTEM REQUIREMENTS
Operating System Win XP / Win Vista / Win 7 / Win 8 / Win 10 (32 o 64 bit)
OSx (Mac OSx) starting from 10.7.5
Linux
PC Requirements CPU: Equal to Intel Core2 2.8GHz or higher
RAM: 2 GB or more
USB port: USB 2.0, at least two ports
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
