B-510DK
v 1.1 2019
Trinocular darkfield microscope, 1000x,
IOS W-PLAN objectives,
for live blood analysis
Brightfield Yes
Phase contrast (Positive type) As optional
Darkfield Yes
Simple polarized light As optional
Type Upright
Construction material Aluminum die-cast
Trasportation handle Yes
Type Trinocular (Siedentopf)
Split ratio 50/50
Inclination 30°
360° rotating Yes
Interpupillary distance (mm) 50-75
Dioptric adjustement On left tube
Tube inner diameter (mm) 30
Field number (mm) 22
Magnification 10x
Planar type Yes
Micrometric scale As optional
Diameter of micrometer glass (mm) 26
High eyepoint (for glass wearers) Yes
Rubber cup Yes
Retractable protections Yes
Positions Quintuple
Reversed Yes
Bi-directional Yes
Rotation on ball bearings Yes
Objective thread RMS
Optical system ∞
Anti-fungus treatment Yes
Parfocal distance (mm) 45
Standard magnifications 40x-1000x
Type IOS W-PLAN
4x/0.10, W.D. 17.3 mm
10x/0.25, W.D. 10 mm
40x/0.65, W.D. 0.54 mm
100x/0.36-1.25 with iris (Oil),
W.D. 0.18 mm
Type Double layer
Dimensions (mm) 233x147
Moving mechanism Rackless
Moving range (mm) 78x54
Material Anti-scratch painting
Specimen holder Yes
Slide number 2
X-Y Vernier scale Yes
Vernier scale accuracy (mm) 0.1
Nosepiece
Observation Method Transmitted Light
Main Body
Head
Eyepieces
Objectives
Objectives included
Stage
OPTIKA MICROSCOPES ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com
Type Swing-out
Removable Yes
Numerical aperture (N.A.) 0.2 / 0.9
Numerical aperture scale Yes
Diaphragms Iris
Centrable Yes
Focusable By rack and pinion
Type Darkfield (oil) with built-in X-LED
Removable Yes
Numerical aperture (N.A.) 1.36
Centrable Yes
Focusable By rack and pinion
Type Coaxial coarse & fine
Coarse total travel (mm) 25
Fine total travel (per single rotation) (mm) 0.2
Fine graduations 100
Fine resolution (µm) 2
Upper stop to prevent contact Yes
Adjustable tension Yes
Flat knob for ergonomy Yes
Kohler illumination Full
Type X-LED
X-LED type X-LED3
Light source power (W) 3.6
Brightness control Manual
Lifetime (hours) > 65,000
Temperature (K) 6,300
Max. required power (W) 6
Type External
Microscope connector Jack, 2.1 mm
Power plug type Multi-plug (EU, UK, US)
Input voltage 100/240 Vac, 50/60 Hz
Output voltage 6 Vdc 2.5 A
Dust cover Yes
Immersion oil (10ml) Yes
Tension adjustment tool Yes
Allen wrench Yes
Centering telescope Yes
Green filter No
User Manual Digital version (downloadable)
Additional Information
Heating stage (as optional).
External rechargeable battery pack (as optional).
Height (mm) 420
Width (mm) 270
Depth (mm) 390
Product Weight
(kg) 9.2
Product Dimensions
Condenser - Single
Position
Condenser - Immersion
Darkfield
Focusing System
Transmitted
Illumination
Power Supply for
Transmitted
Illumination
Accessories Included
