Opticom OPERA BROCHURE

OPERA

YOUR DIGITAL EAR!

Voice/Audio Quality Analyzer

The Objective Perceptual Signal Quality Analyzer setting the Standards

Comprehensive, end-to-end
quality analysis based on
perceptual measurement

The OPERA™Voice/Audio Quality
Analyzer represents the latest
developments to objectively eva­luate and assure the quality of
compressed voice and wide-band
audio signals, based on modeling
the human ear
can achieve a comprehensive ana­lysis of the end-to-end quality of
today's and next generation net
works, such as 3G V
VoATM, ISDN, GSM, POTS, from
the caller to the callee. Also, you
can test the audio quality of com
pression formats such as MP3,

. With OPERA you

oDSL,

, V

oIP

-

AAC, AC3, Microsoft Windows
Media, from the studio source to
the receiver, or from the server to
the client.
For the test engineer, one of the
issues is how to apply a computer
model of the human ear to a test
circuit, or to a live network envi­ronment. For this reason, OPTICOM
developed OPERA as an open, easy
to configure hardware platform
that can process perceptual
models, which are implemented

-

just by software. The basis of the
OPERA system is a portable 'lunch

box' type of PC host system. Four
slots can take various kinds of
interfaces. Alternatively, OPERA is
now also available in a rack-moun­table form factor. For R&D and lab
applications, a cost effective soft­ware-only version with reduced
functionality is offered, as well.
Supported Operating Systems

™

Microsoft Windows NT

are
Windows™2000, Windows™XP
Windows™2003.

,

,

Key Functionality at a Glance

Voice Quality
Measurement

• PESQ, the new state-of-the-art

perceptual evaluation of speech
quality according to ITU-T rec.
P.862 [2001], combines PSQM

AMS, optimized for VoIP

with P
and hybrid end-to-end applica­tions, MOS and MOS-LQ calcu­lations. PESQ wideband func­tionality (PESQ-WB) is also
included.

•

PSQM/IP, perceptual speech
quality measure according to
ITU-T rec. P.861 [1996], incl.
advanced delay compensation
for end-to-end measurements,
developed by OPTICOM

• PSQM+, advanced perceptual

speech quality measure accord­ing to ITU-T COM 12-20 [1998]

• Echo measurement based on

real speech, Echo Return Loss
ERLpeak, ERL vs. delay

• Transmission Rating Factor R

according to ITU-T G. 107 (E­Model), available with PESQ only

• One way delay measure-
with PESQ also delay

ment,
jitter vs. time

distribution
Measurement under

•

talk conditions

• One way and two way

measurements

• Bulk call generation

H.323 interface functionality

•

using Windows NetMeeting
and audio interfaces

VAD analysis, Front-end

•

clipping FEC, hold-over time
HOT and dropout measurement

• Background noise

measurement

• Signal-to-noise

ment of speech and silent parts
of a test signal

and delay

double

™

SNR measure-

Audio Quality
Measurement

• PEAQ, perceptual evaluation

of audio quality according to
ITU-R rec. BS.1387 [1999],
Basic and Advanced Model

• 48 kHz and 44.1 kHz sampling

rates supported

• Result logging functionality,
including user definable log
intervals and quality score
threshold

• Trigger functionality for
targeted analysis of on-line
or long duration test signals

Common Functionality

• Advanced delay compensation
for end-to-end measurements,
suitable for constant and vari­able delays (VoIP), developed by
OPTICOM

• Delay measurement with real
speech/music. Results in sam­ples as well as ms

• Attenuation measured in dB

• On-line real time acquisition
and analysis capability

• Comprehensive scripting inter­face

Remote Control over IP

•

• DDLC™improved timing
accuracy (Dynamic Driver
Latency Compensation)

• Play and record functionality
for wide band audio as well
as voice signals

• Easy-to-use graphical user
interface

Extensive scripting and

•
command line options

OPERA™Control Center:
Easy Scheduling and
Remote Control
Functionality

• User friendly graphical interface
for setting up a schedule of test
calls between OPERA™systems

Automated remote control

•
of a single or various OPERA
systems via IP connection

• More than 3.000 measurements
per day, more than 20.000
BHCA (call attempts per hour)

• Automatic synchronisation and
allocation of the resources

Commands may be automatically

•
repeated and rescheduled after
a certain time (e.g. every
Monday)

• Applicable to telecom and wide
band audio applications

• All result values as in the voice
and audio quality measurement
functionality are available
(except for graphical diagrams),
like PESQ, PSQM/IP, PSQM+,
PEAQ, Echo scores etc.

• PDD measurements (Post dial
delay)

• Total call duration measure­ments

• Termination cause indicator

• All measurement results avail­able at a glance

• Result view filtering by connec­tions and/or QoS results (e.g.
only connections with poor
listening quality are shown)

• Measurement results may be
exported to any spread sheet,
data base program or network
management system for further
analysis

• Statistics and charts

™

Graphical Displays

• Time signal displays, zoomable
FFT Spectra, zoomable

•

• Excitation and various psycho­acoustic parameters, like NMR,
Masked Threshold and
Loudness

• Audible distortion measurement

• Result summary display with
MOV, PSQM MOS, PESQ MOS
and PEAQ ODG numerical
scores and bar graphs

• Delay Jitter vs. Time min/max
scores and graph (PESQ)

• Echo Return Loss vs. Delay
and many other features (list

•
not comprehensive).

Interfaces

• Four port analog POTS inter­faces

• Dual- or quad-port E1/T1 trunk
interfaces, fully software con­figurable for a variety of proto­cols: ISDN PRI, E1 MFC-R2 CAS,
E1 CAS-R2, T1 CAS/Robbed Bit,
both, FXO and FXS types. 120
Ohm RJ48C, optional adapter
kit for 75 Ohm Coax

Professional stereo 24 bit ana

•
log/digital audio interfaces, XLR
balanced, AES/EBU. With
optional multimedia adapter kit

also applicable to VoIP ter­minal and IP phone testing

• Interfaces can be freely
combined in a system

-

User definable state machines

•
supported for E1 MFC-R2,
E1 CAS-R2, T1 CAS

Applications and Features Why

ariety

est

™

Windows

ool

A Flexible and Reliable T
to Assess a Large V
of Systems Under T

• End-to-end voice quality testing
of 3G, VoIP, VoDSL, VoATM,
ISDN, GSM, POTS, based on
real world speech signals

• Measure VAD behaviour, echo
cancellers and signal enhancers
with any speech signal

• End-to-end wide band audio
quality testing of MP3, AAC,
AC3 and Microsoft

™

Media

• Interactive or automated
unattended measurements

• Immediate overview of the QoS
of your network based on stan­dardized metrics

Stress your network in order

•
to observe the effects on the
transmission quality (bulk call
generation)

• Monitor the QoS of any corpo­rate, public or long distance
network

• Remote control a single or
numerous OPERA
an IP connection.
Share a pool of OPERA
systems in your test lab with

™

analyzers via

™

other developers. Conveniently
control the pool from your
office PC

• Freely combine various inter­face types in every measure­ment (e.g. V
to a VoIP terminal)

• Include the acoustical path in
the measurement using a head
and torso simulator (HATS)

• Monitor broadcast networks
on-line

oIP calls from POTS

OPERA
sets the
Standards:

• Objective perceptual
evaluation of compressed
voice/audio signals modelling
recognized listening test
procedures, based on natural
speech/music

• Original reference imple­mentations from the co­developers and originators
of the ITU standards,

• Plenty of detailed views and
graphs provided for further fault
analysis, incl. voice or wide
band audio quality, echo, delay,
jitter, VAD behaviour and call
timing

incl. KPN, BT, OPTICOM

• Direct relation of measured
QoS to customer’s satisfaction

• Efficient diagnostic tool
for next generations hard­ware/networks design

Configurations and Ordering Information

OPTICOM GmbH

Nägelsbachstraße 38
91052 Erlangen, GERMANY
Phone: +49 9131 / 5 30 20-0
Fax: +49 9131 / 5 30 20 - 20
EMail:
Website: www.opticom.de

Further information also available
from www.pesq.org, www.peaq.org.

[email protected]

North America

Acterna U.S.
One Milestone Center Court
Germantown, MD 20876-7100, USA

oll Free: 1 866 ACTERNA

T
Toll Free: 1 866 228 3762
Phone [phone] x 2850
Fax:

[phone]

Western Europe

Acterna Germany GmbH
Mühleweg 5
72800 Eningen u.A., Germany
Phone: [phone]
Fax:

[phone]

Latin America

Acterna do Brasil Ltda.
Av.Eng.Luis Carlos Berrini
936/8 °e 9 ° andares
04571-000 São Paulo
SP-Brazil
Phone: [phone]
Fax: [phone]

Eastern Europe,
Middle East & Africa

Acterna Austria GmbH
Aredstr.16-18
2544 Leobersdorf, Austria
Phone: [phone]
Fax: [phone]

Asia Pacific

Acterna Hong Kong Ltd.
Room 902,9th Floor
Bank of East Asia
Harbour V
56 Gloucester Road
W
Phone: [phone]
Fax:

CIS Countries

Acterna Moscow
Prospect Mira,26
stroenie 5
RF 129090 Moscow, Russia
Phone:
Fax:

Through our distributor network,
we are represented in more than
80 countries.
To find your local sales office,
please contact [email protected]

This information may be subject to change.
All brand and product names are trademarks
and/or registered trademarks of their respective
owners. All rights reserved. Copyright © 2005
OPTICOM GmbH – www.opticom.de

iew Centre

anchai, Hong Kong

[phone]

[phone]
[phone]

Common System
Specifications:

OPR-1XX-XXX-P
Objective Perceptual Analyzer,
OPERA™

Basic portable framework system, incl.

• Dual Pentium IV Architecture

• 15" XGA TFT Display, 1024x768

• German, US or International
keyboard

• Integrated Trackpad

• Power Supply Unit 240/120 V

• Microsoft
OPERA Framework Software v3.5

•

• Control Center Light

• OPERA User's Manual

• Trolley Soft Case
1 year extended maintenance

•
and support

•

Alternatively available as
rackmounted version

™

Windows 2000

Voice Testing Configurations:

OPR-101-ESQ-P

™

OPERA

voice quality tester,

incl.

• PESQ/P.862/P.862.1

• PSQM/P.861, PSQM+, PSQM/IP

• Echo return loss and delay
(w/ real speech)

• Four port analog POTS interface

• OPTICALL
Software

™

Signal Acquisition

OPR-111-ESQ-P
same as OPR-101-ESQ-P, add.
incl.

• 2x 24 bit analog/digital audio I/O
interface option for multimedia
terminal testing (e.g. PC-to-phone)

OPR-121-ESQ-P
same as OPR-101-ESQ-P, add.
incl.

•

2 x Stereo 24bit analog/digital
audio I/O interface option for
multimedia terminal testing
(e. g. PC-to-phone)

OPR-101-SQM-P
OPERA™voice quality tester

,

incl.

• PSQM/P.861, PSQM+ , PSQM/IP

• Echo return loss and delay
(w/ real speech)

• Four port analog POTS interface

• OPTICALL
Software

™

Signal Acquisition

OPR-111-SQM-P
same as OPR-101-SQM-P, add.
incl.

• 2x 24 bit analog/digital audio I/O
interface option for multimedia
terminal testing (e.g. PC-to-phone)

Options for Voice Testing
Configuration

OPR-002-E1T

-P
E1/T1 Option for OPERA
Voice Testing Configuration

• Dual Port E1/T1 Interface,

software configurable

• 120 Ohm RJ48C

OPR-000-EAQ-P
PEAQ s/w option for OPERA

oice Testing Configuration

V

wide band audio testing algorithm
(software only)

PEAQ/BS.1387 Advanced

•

• PEAQ/BS.1387 Basic Model

OPERA™Control Center server
software for automated use
incl.

Remote control OPERA systems over
TCP/IP

OPR-003-CTR-X

• 3-User license

OPR-010-CTR-X

• each user license from 4 up

to 10 users (others on request)

Audio Testing Configurations

OPR-120-EAQ-P
OPERA™audio quality tester,
incl.

• PEAQ/BS.1387 Advanced Model

• PEAQ/BS.1387 Basic Model

• 2x Stereo 24bit analog/digital audio

interface option, sym. XLR, AES/EBU

Combined Voice+Audio Testing
Configurations

OPR-121-ASE-P

™

OPERA

voice+audio quality

tester, incl.

• PESQ/P.862/P.862.1

•

PSQM/P.861, PSQM+ , PSQM/IP

• Echo return loss and delay

(w/ real speech)

• Four port analog POTS interface

•

OPTICALL
Software

• PEAQ/BS.1387 Advanced Model

• PEAQ/BS.1387 Basic Model

2x Stereo 24bit analog/digital audio

•

interface option, sym. XLR, AES/EBU

™

Signal Acquisition

OPR-121-ASQ-P
OPERA™voice+
audio quality tester, incl.

• PSQM/P.861, PSQM+ , PSQM/IP

Echo return loss and delay

•

(w/ real speech)
Four port analog POTS interface

•

• OPTICALL

Software

• PEAQ/BS.1387 Advanced Model

PEAQ/BS.1387 Basic Model

•

• 2x Stereo 24bit analog/digital

audio interface option, sym. XLR,
AES/EBU

™

Signal Acquisition

Other Options for Voice and
Audio Testing Configuration

OPR-991-SUP-X

1 year extended maintenance and sup­port, available to all OPR-xxx products

OPR-810-XXX-X

™

OPERA

multimedia adapter

set, 1 set

(e.g. for PC-to-phone, multimedia termi­nal testing)

• incl. stereo XLR(m)-to-jack(3,5mm),
stereo XLR(f)-to-jack(3,5mm)

• incl. 2x XLR(m)-to-Cinch,
2x XLR(f)-to-Cinch

[Note: one set required, except for
OPR-x2x-xxx-x two sets required]

OPR-820-FMA-X
OPERA™fixed and mobile
phone adapter box

the OPERA audio interface to hand­sets, headsets, IP phones, etc.)
[Note: OPR-x1x-x or OPR-x2x-x required]

(for connecting

Software-only configurations

Common S/W Specifications

OPERA software suite v3.5, restricted
functionality (.wav) file-based only, no
real time/on line streaming, basic
framework system, incl.:

• installation guide

• OPERA User's Manual

• 1 year support

Hardware Requirements for
OPERA software suite:

• Pentium III PC, 500MHz or above

• min. 128MB RAM,
256MB recommended

• OpenGL capable graphics adapter,
min. 8 MB required, nVIDIA RIVA,
TNT2 or similar;

optionally available with:
OPR-000-ESQ-S

.862.1, includes also

• PESQ/P

.862/P

• PSQM/P.861, PSQM+, PSQM/IP

or OPR-000-EAQ-S

• PEAQ/BS.1387
Advanced Model

• PEAQ/BS.1387 Basic Model

or OPR-000-ASQ-S

• PSQM/P.861, PSQM+, PSQM/IP,

includes also

• PEAQ/BS.1387 Advanced Model

• PEAQ/BS.1387 Basic Model

or OPR-000-ASE-S

• PESQ/P.862/P.862.1, includes also

.861, PSQM+, PSQM/IP

PSQM/P

•

• PEAQ/BS.1387 Advanced Model
PEAQ/BS.1387 Basic Model

•

DEMO FOR EVALUATION

OPR-000-DEM-S

OPERA software suite v3.5,

limited trial demo version

• functionality as OPR-000-ASE-S

• limited number of trials
