opticis BR-500 User Manual

WWW.OPTICIS.COM

19” 1RU Power Supply Frame

For DisplayPort 1.2 Modules

User’s Manual

(BR-500)

- 1 -

Contents

Welcome! .............................................................................. - 3 -

Product Description ............................................................... - 3 -

Shipping group ...................................................................... - 3 -

WebGUI Control .................................................................... - 4 -

Installation ............................................................................. - 4 -

- 2 -

Welcome!

Congratulations on your purchase of the 19” 1RU Power Supply Frame for DisplayPort 1.2
Modules, BR-500. This manual contains information that will assist you in installing and operating the

product.

Product Description

OPTICIS BR-500, 19” 1RU multi-mounting rack is a modular rack and systematic fiber-optic solution
providing flexibility to install Opticis DisplayPort 1.2 modules up to 8 units. DPFX-200-Tx or DPFX­300-Tx is required in use.

Each power line of mounting unit is connected to the central bus power of +12VDC at 4.2A. BR-500
can be fit with the dual power supplies for load-sharing and redundant backup. BR-500 adopts two (2)
LEDs in the front panel for power supply failure to run the stable system without any disruption or
disconnection from the power failure.

BR-500 has one separate RJ45 Port which allows the connection through LAN cable. This connection
to GUI enables the access to the current power status of individual module and also allows to turn
on/off the power of the device.

By using premium graded DisplayPort 1.2 copper cables, BR-500 can extend up to 3m (9.84ft)
distance from the sources.

*Note: The DisplayPort modules and DisplayPort copper cables are separately sold.
BR-500 is applicable to use with Opticis DisplayPort 1.2 fiber-optic transmitters ONLY.

Shipping group

 BR-500: One (1) unit
 Module bracket: Eight (8) units
 Module Slot: Eight (8) units
 Heat Sink: Sixteen (16) units
 Screw: Thirty-two (32) units
 User manual: One (1) unit
 Options

1) BI050S12F02: Power supply for BR-500 (100-240VAC, 50-60Hz)

2) BM050S12F02: Medical certified power supply for BR-500 (100-240VAC, 50-60Hz)
