www.opticavideo.com
B102
720P HD Outdoor Bullet Network Camera
Full HD 720P - Day/Night w/IR to 25m - Outdoor Ready
The B102 bullet is a professional day/night, outdoor-
ready network camera, able to deliver high quality HD
720P video at a full 30 frames per second, and see
up to 25m in complete darkness (0 lux) with on-board
IR illuminators. The IP66 rated weather-proof camera
housing is constructed with a cable management
bracket, making for an easy, secure installation.
As with all Optica cameras, the B102 bullet comes with
a limited Two Year Warranty and free OpticaCMS software,
capable of recording and viewing 64 camera channels.
Advanced camera features found in all Optica cameras
include H.264 Quad Streams, Wide Dynamic Range,
PoE/PoE+ Power, 3D Noise Cancellation, Tamper
Detection, Network Failure Detection, MicroSD on-board
recording, Vertical View mode, Privacy Masks, Digital
Zoom, and more.
Features
• HD 720P Resolution at 30 fps
• 4mm Fixed Lens
• Wide Dynamic Range
• IR Cut Filter for True Day/Night
Video
• IR illuminators with 25m range
• Weather-Proof Housing
• MicroSD On-Board Recording
• H.264 / MJPEG video compression
Page 2
OPTICA is a trademark of Pacific Products LLC. All other company names
and products are trademarks or registered trademarks of their respective
owners. Product specifications subject to change without notice.
TECHNICAL SPECIFICATIONS
Camera Mechanical
Image sensor 1/2.7" Progressive CMOS Built-in IR Illuminator Working Distance up to 25m
Effective Pixels 1920(H) x 1080(V) Wavelength 850nm
Minimum Illumination
Day / Night Yes - IR Cut Filter LED Indicator Power / Link / ACT
White Balance Manual / AWB / ATW Connectors Alarm 4 Pin Terminal Block
Shutter Speed 1 ~ 1/10000 sec Power 3 Pin Terminal Block
Lens Ethernet RJ-45
Focal Length Fixed Lens 4.0 mm Analog Video 1.0 Vp-p / 75 Ω, BNC
F Number F1.5 Audio Female Stereo Phone Jack, 3.5 mm
FOV
Operation
Multiple Languages English / French / German / Italian / Korean / Simplified Chinese / Traditional Chinese / Russian
Image Setting Backlight Compensation On / Off
White Balance Auto / Manual
Noise Reduction (3D) On / Off
Wide Dynamic Range 3 WDR Settings: Low / Medium / High
Privacy Mask On / Off
Brightness Manual
Exposure Auto / Manual
Sharpness Manual
Contrast Manual
Saturation Manual
Hue Manual
Digital Zoom Yes
Motion Detection On / Off
Privacy Mask Type Color
ICR Auto / On / Off / Smart
Tampering Alarm On / Off
Audio Two-way Audio Line out, Line in
Compression G.711 / G.726
0.2 lux (Color) / 0.02 lux (B/W) / 0 lux (w/IR)
78˚ (Wide)
Mic In / Line In Female Stereo Phone Jack, 3.5 mm
Number of LEDs 23
720P HD Outdoor Bullet Network CameraB102
Network
Interface RJ-45, 10/100 Mbps Ethernet
Video Compression H.264 / MJPEG
Video Streaming Quad Streams – H.264 + H.264 + H.264 + H.264/MJPEG
Video Resolution H.264- 1920x1080 (15FPS) / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
MJPEG- 1920x1080 (15FPS) / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
Protocol IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE,
UPnP, IGMP, SNMP, QoS
Security HTTPS / IP Filter / IEEE 802.1x
Alarm Input 1 Set - 5V 10kΩ pull up
Output 1 Set - Photo Relay Output 300V DC/AC
Event Notification HTTP / FTP / SMTP
Micro SD microSDHC 32GB support
Supported Web Browser Internet Explorer (6.0+) / Chrome / Firefox / Safari
User Account 20
Password Levels User and Administrator
General
Operating Temperature -10°C ~ 50°C (14° ~ 122° F)
Dimension Ø 84 x 180 mm (Ø 3.3 x 7.1 in.) ( w/ Sunshield ) Ø 84 x 193 mm (Ø 3.3 x 7.6 in.)
Power Consumption System: 5 W (Built-in IR Illuminator: +3 W)
Weight 940g ( 2.07 lb )
Power Source DC 12V / AC 24V / PoE
Humidity 10% ~ 90%, No Condensation
Weatherproof Standard IP66
Regulatory CE / FCC / RoHS
