Optex OA-AXIS T, i-two, OP-08CW, OP-08CBL, i-one Original Instructions Manual

45(1 3/4")

63(2 1/2")

267(10 1/2")

125(4 15/16")

36(1 7/16") 43(1 11/16")

7(1/4")

MANUFACTURER'S STATEMENT

DETECTION AREA

OUTER DIMENSIONS AND PART NAMES

ENGLISH

5921880 JUN 2014

NM-0035-1

(1) Connector
(2) Mounting holes
(3) Operation indicator
(4) Depth angle adjustment screw
(5) Width adjustment screws
(6) Function switch
(7) Dipswitches
(8) Detection window
(9) Area adjustment tool

Test conditions required by EN 16005

Model
Cover color
Mounting height
Detection area
Detection method
Depth angle
adjustment
Power supply (*2 )

Power consumption
Operation indicator
Safety input

Activation output

: OA-AXIS T
: Silver / Black
: 2.0 (6'7") to 3.0m (9'10")
: See DETECTION AREA
: Active infrared reflection (*1 )
: 1st to 3rd rows / -6 to +6°
4th and 5th rows / +26 to +44°
: 12 to 24VAC ±10% (50 / 60 Hz)
12 to 30VDC ±10%
: < 2.5W (< 4VA at AC)
: See chart below
: Opto coupler
Voltage / 5 to 30VDC
Current / 6mA Max. (30VDC)

: When 3rd, 4th or 5th row detects.
Form A relay
50V 0.3A Max. (Resistance load)

Safety output

Output hold time
Response time

Operating temperature
Operating humidity

IP rate
Category

Weight
Accessories

Performance level

: When 1st or 2nd row detects.
Opto coupler (NPN)
Voltage / 5 to 50VDC
Current / 100mA Max.
Dark current / 600nA Max.
(Resistance load)

: <0.5 sec.
: <0.3 sec.

: -20 to +55°C (-4 to 131°F)
: <80%

: IP54
: 2 (EN ISO 13849-1 : 2008)
: d (EN ISO 13849-1 : 2008)

: 320g (11.2oz )
: 1 Operation manual
2 Mounting screws
1 Mounting template
1 Area adjustment tool
1 Cable 3m (9'10")
(8 × 0.22mm² AWG24 ) (*3 )

The specifications herein are subject to change without prior notice due to improvements.

NOTE

*1 : The 1st and 2nd rows have presence detection function.
*2 : When using this sensor, the sensor has to be connected to a door system which has the SELV circuit.
*3 : Overcurrent protection with less than 2A.

It is required to check the operation manual if this symbol is shown on the product.

MANUFACTURER'S STATEMENT

WARNING

Do not wash, disassemble, rebuild or repair the sensor, otherwise
it may cause electric shock or breakdown of the equipment.

Danger of electric shock.

WARNING

CAUTION

NOTE

Disregard of warning may cause the improper operation causing death or serious injury of
a person.

Special attention is required to the section of this symbol.

Disregard of caution may cause the improper operation causing injury of a person or damage to
objects.

NOTE

Read this operation manual carefully before use to ensure proper operation of this product.
Failure to read this operation manual may cause improper operation and may result in serious injury or
death of a person.The meanings of the symbols are as follows.

1. This product is a non-contact switch intended for header mount or wall mount for use on an automatic sliding door.
Do not use for any other applications.

2. When setting the sensor's detection area, make sure that there is no traffic around the installation site.

3. Before turning the power ON, check the wiring to prevent damage or malfunction of equipment connected to
the product.

4. Only use the product as specified in the operation manual provided.

5. Be sure to install and adjust the sensor in accordance with the local laws and standards of the country in which
the product is installed.

6. Before leaving the installation site make sure that the product is operating properly and instruct the building
owner/operator on proper operation of the door and the product.

7.The product settings can only be changed by an installer or service engineer. When changed, the
changed settings and the date shall be registered in the maintenance logbook accompanying the door.

The actual detection area may become smaller depending on the ambient light, the color / material of
the object or the floor as well as the entry speed of the object.
The sensor may not be activated when the entering speed of the object or a person is slower than
50mm / sec. or faster than 1500mm / sec.

NOTE

[mm (inch)]

Operation indicator

The values above are those of the Detection area when tested referring to the test conditions of EN 16005.
(The emitting area is as shown in Emitting area above.)
*: When installed at higher than 2.35m(7'9"), EN 16005 requirements are fulfilled only within the area width "I"
of 3m(9'10").

To comply with EN 16005, make sure that the detection area is within the values in the chart below.

1

3

2

CAUTION

Risk of getting caught.

Make sure to affix the mounting template as described in the above chart ,
otherwise it can be dangerous since there may be no detection area around
the threshold. Install the sensor as low as possible on the header.

WARNING

Danger of electric shock.

Do not use the sensor without the cover.
When using the cable knockout, install the sensor indoors or use the rain-cover
(Separately available) otherwise electric shock or breakdown of
the sensor may occur.

Before starting the procedure, make sure that the power is turned OFF.
When passing the cable through the hole, do not tear the shield.
otherwise it may cause electric shock or breakdown of the sensor.

To the connector
of the sensor

4

Power supply

12 to 24VAC±10% /12 to 30VDC±10%

1.Plug the connector of the sensor.

2.Supply power to the sensor. Adjust the detection area and set the dipswitches. (See ADJUSTMENTS)

Place the housing cover.
If wiring is to be exposed, break the knockout.

}

H : Height from the floor to the bottom of the header

Y : Distance between the bottom of the header and the sensor
X : Distance between the door and the mounting surface

(The mounting height is "H + Y".)

WARNING

Danger of electric shock.

NOTE

Make sure to connect the cable correctly to the door controller before turning the power ON.
When turning the power ON or after adjusting the settings, do not enter the detection area for more
than 10 seconds in order to enable the presence detection.
Do not touch the dipswitches before turning the power ON, otherwise an error occurs.
When changing the settings of dipswitch, see ADJUSTMENTS 3 Dipswitch settings.

1.White

2.Brown

3.Green

4.Yellow

5.Pink (+)

6.Blue (-)

7.Red (+)

8.Black (-)

Safety output

Opto coupler(NPN) / Voltage: 5 to 50VDC

Activation output

Form A relay 50V 0.3A Max.

Safety input

Opto coupler / Voltage: 5 to 30VDC

INSTALLATION

The following conditions are not suitable for sensor installation.

-Fog or exhaust emission around the door.

-Wet floor.

-Vibrating header or mounting surface.

-Moving objects or objects that emit light near the detection area.

-Highly reflecting floor or highly reflecting objects around the door.

NOTE

Detection area

1sec. 1sec.

1st row
2nd row
3rd row
4th row
5th row

: Emitting spots

: Detection Area

A

B

C

D

E

F

G G

H

I

Motion / Presence

detection

Motion detection

: Emitting spots
(Can be eliminated)

Charts show the values in the following
depth angle adjustment settings ;

1st to 3rd rows : +6°
4th and 5th rows : +44°

[m(feet,inch)]

Emitting area

A
B
C
D
E
F
G
H
I (*)
X

1.35 (4'5")

2.20 (7'3")

0.14 (6")

0.42 (1'5")

0.82 (2'8")

1.90 (6'3")

1.33 (4'4")

2.05 (6'9")

2.78 (9'1")

2.70 (8'10")

0.18 (7")

0.52 (1'8")

1.00 (3'3")

1.66 (5'5")

2.34 (7'8")

3.00 (9'10")

0.20 (8")

0.58 (1'11")

1.10 (3'7")

1.85 (6'1")

2.60 (8'6")

1.63 (5'4")

2.51 (8'3")

1.81 (5'11")

2.79 (9'2")

3.40 (11'2") 3.79 (12'5")

2.50 (8'2")

0.16 (6")

0.48 (1'7")

0.93 (3'1")

1.54 (5'1")

2.17 (7'1")

1.51 (4'11")

2.32 (7'7")

3.15 (10'4")

1.23 (4')

2.00 (6'7")

0.13 (5")

0.38 (1'3")

0.74 (2'5")

1.74 (5'9")

1.06 (3'6")

1.86 (6'1")

2.52 (8'3")

0.21 (8") 0.26 (10") 0.28 (11")0.24 (9")0.19 (7")

X is the distance between the 1st row and the mounting surface.

A
C
G

I

2.20 (7'3")2.00 (6'7")

0.24 (9")

1.10 (3'7")

2.54 (8'4")

0.23 (9")

1.02 (3'4")

2.41 (7'11")

Maximum mounting distance (Y)

X

H

Y

Sensor

Door

Header

Floor

X

2.00 (6'7")

2.30 (7'7") 2.50 (8'2")

2.80 (9'2")

0

No limit

0.05 (2")

0.20 (8") 0.20 (8")

0.20 (8")

0.10 (4") 0.20 (8")

0.20 (8") 0.20 (8")

0.20 (8")

0.15 (6") 0.13 (5”)

0.15 (6”) 0.19 (7")

0.20 (8")

0.20 (8")

-

0.12 (5”) 0.14 (6”)

0.15 (6”)

0.25 (10")

0.12 (5”)

0.30 (12") -

-

H

0.20 (8")

-

- -

- 0.11 (4")

[m (feet,inch)]

SPECIFICATIONS

(9)

(1)

(5)

(4)

(7)(6) (8)

(3)

(2)

Noise level : <70dBA

3.00 (9'10")

0
0
0
0
0

-

1. Affix the mounting template at the desired mounting position.

2. Drill two mounting holes of ø3.4mm (ø1/8”).

3. To pass the cable through the header, drill a wiring hole of ø8mm (ø5/16”).

4. Remove the mounting template.

5. Remove the housing cover. Fix the sensor to the mounting surface with the two mounting screws.

(When setting the detection area close to the door, mount the sensor according to the chart below.)

OA-AXIS T

ESPE : Type2

EN 12978:2003 +A1:2009
EN ISO 13849-1:2008 EN ISO 13849-2:2012

Machinery Directive 2006/42/EC

Notified Body 0044 : TÜV NORD CERT GmbH Langemarckstr. 20 45141 Essen Germany
EC-type examination certificate No. 44 205 13 099205

EN 16005:2012 Chapter 4.6.8 and Annex C
EMC Directive 2004/108/EC
EN 61496-3:2001 clause 4. 3. 5 and 5. 4. 7. 3

COMPLIED STANDARDS
AND EXTRACT FROM EC DECLARATION OF CONFORMITY

EN 61000-6-2:2005 EN 61000-6-3:2007 +A1:2011

Function
switch

Technical documentation see manufacture address

A. Maekawa
General Manager
OPTEX CO., LTD.
Quality Control Dept.

Original instructions

Function switch

After changing the dipswitches
settings,make sure to push the
function switch for 2 seconds.

1st to 3rd rows

4th and 5th rows

Narrow

Shallow Deep

Low
Middle
High
S-High

Sensitivity

30sec.
60sec.

180sec.

Safety / Test
timer

Setting 2
Setting 3
Setting 4

Setting 1

Frequency

Row
adjustment

5 rows
4 rows
3 rows
2 rows

Width

RL

Width

RL

Not

applicable

0

°
35

°

-3°3

°
40°30

°

5730870

1 2 3 4 6 7 8 9101112 141516135

Wide

Narrow

Wide

1,2 3,4 5,6

7,8

Depth

-6

°

6

°

Depth

26

°

44

°

Self
monitoring

Immunity

ON

OFF

Disable
Enable

9 10

Safety / Test
output

Low
High

11

Test input

Low
High

12

N.O.

N.C.

14

Activation
output

20msec.
10msec.

13

Test input

delay

Installation
mode

16

ON
OFF

6°-6

°

26

°

44

°

600sec.

NOTE

Make sure not to mount the sensor lower than the bottom of header.

Floor :Grey paper
Detection object : EN 16005 CA reference body
Sensitivity : Middle
Speed of detection object : 50mm / sec.

Status

Stand-by (Installation mode)

Operation

indicator

color

Stand-by (Operation mode)

Yellow
Green

1st row detection

2nd row detection

3rd, 4th or 5th row detection

Setting error

Signal saturation

Sensor failure

Blinking Red

Red

Orange

Red & Green Blinking

Slow Green Blinking
Fast Green Blinking

18730 S. Wilmington Ave. Suite 100 Rancho Dominguez,
CA 90220 U.S.A.
TOLL-FREE: 800 877 6656 FAX.: [phone]
WEBSITE: www.optextechnologies.com

Mounting height [ m (feet,inch) ]

2.0 (6'7") 2.2 (7'3") 2.5 (8'2") 3.0 (9'10")

Contact your installer or service engineer.

Sensor failure.

2

1

ADJUSTMENTS

Wrong wiring or connection failure. Check the wires and connector.

Wrong wiring or connection failure.

Check the wires and connector.

Door operation

Operation

indicator

Possible cause

Possible countermeasures

None Wrong power supply voltage. Set to the stated voltage.

Wrong wiring or connection failure.

Fast

Green

Blinking

Signal saturation. (1st or 2nd row)

Dirty detection window. Wipe the detection window with a damp cloth.

Do not use any cleaner or solvent.

Sensitivity is too low.

Set the sensitivity higher.(*)

The detection area overlaps with
the door/header.

Adjust the detection area to "Deep" (Outside).

Door opens
when no one
is in the
detection area.
(Ghosting)

Unstable

Door remains
open

Sudden change in the detection area.

Check ADJUSTMENTS 3-1, 3-2.(*)
If the problem still persists, hard-reset the
sensor.(Turn the power OFF and ON again.)

Slow

Green

Blinking

Check the wires and connector.

Remove highly reflecting objects from the
detection area. Or lower the sensitivity.(*)
Or change the area depth angle for 1st to 3rd rows.

Setting error.

Red &
Green

Blinking

Door does not
open when a
person enters
the detection
area.

Unstable

Wrong detection area positioning.

Check ADJUSTMENTS 1, 2, 3.(*)

Sensitivity is too low.

Set the sensitivity higher.(*)

Short presence timer. Set the presence timer longer.(*)

Proper

Proper

Wrong setting of dipswitches. Check

ADJUSTMENTS 3-7, 3-8, 3-10.(*)

Dirty detection window. Wipe the detection window with a damp cloth.

Do not use any cleaner or solvent.

When using more than two sensors close to each other, set the different
frequency for each sensor by dipswitches 5 and 6.

3-3.Setting the frequency

3-5.Setting the immunity

Red

4th and 5th rows

Area depth angle adjustment

1st to 3rd rows

C

Area adjustment tool

A

B

Area width adjustment

Blue

Use the area adjustment tool (B) as shown above to
change the area depth angle for the 4th and 5th rows.

Depth angle adjustment screw
for the 1st to 3rd rows

Depth angle adjustment screw
for the 4th and 5th rows

Use the area adjustment tool (A) as shown above to
change the area depth angle for the 1st to 3rd rows.

1-2.Simultaneous adjustment

1-1.Independent adjustment

For the simultaneous adjustment of the 1st to 5th rows, use the adjustment tool (C).

When adjusting the width adjustment screws, make sure to turn until it clicks otherwise the proper operation may not
be obtained.
cannot be eliminated separately, neither can .

Depth angle
adjustment screw

Shallow

Deep

4th and 5th rows 1st to 3rd rows

Width adjustment
screws (Right)

Width adjustment
screws (Left)

Check the operation in the operation mode according to the chart below.

Dipswitch settings

Refer to the chart below for the suitable sensitivity to your installation environment.

3-1.Setting the sensitivity

3-2.Setting the presence timer

The 1st and 2nd rows have the presence detection function.

To enable the presence detection, do not enter the detection area for 10 seconds after setting the timer.

When adjusting the 1st row close to the door,
see 3-11 Installation mode for the easier adjustment.

Special attention to the setting is required when the door is used often by the elderly or children.
Please adjust the sensitivity and the presence detection timer according to your risk assessment.

For example

Floor condition

Low reflection Middle Middle High S-High

-Carpet

-Dark color floor

Middle reflection Low Middle Middle

-Concrete

High reflection Low Low Middle High

-Tile

-Marble

S-High

1. Always keep the detection window clean. If dirty, wipe the window with a damp cloth.(Do not use any cleaner / solvent.)

2. Do not wash the sensor with water.

3. Do not disassemble, rebuild or repair the sensor yourself, otherwise electric shock may occur.

4. When the operation indicator blinks Green, contact your installer or service engineer.

5. Always contact your installer or service engineer when changing the settings.

6. Do not paint the detection window.

WARNING

1. When turning the power ON, always walk-test the detection area to ensure the proper operation.

2. Do not place any objects that move or emit light in the detection area. (e.g. Plant, illumination, etc.)

Set the depth rows with dipswitches 7 and 8.

3-4.Setting the row adjustment

When "2rows" are selected, the activation output
is disabled.

Make sure that the detection area does not overlap with the door/header, and there is no highly reflecting

object near the detection area otherwise ghosting/signal saturation may occur.

NOTE

NOTE

NOTE

NOTE

NOTE

NOTE

INFRARED FINDER

Detection area

Detection area

1. Turn the depth angle adjustment screw to the right (Deep) to place the detection area most away from the door.

2. Set INFRARED FINDER sensitivity to "H" (High) and place it on the floor as shown below.

Area depth adjustment with INFRARED FINDER (Separately available)

REFERENCE

3. Turn the depth angle adjustment screw to the left (Shallow) until the emitting area is placed at the position where
INFRARED FINDER is in the low detection status (Slow Red Blinking).

Set dipswitch 9 to "ON" when the sensor operates by itself (Ghosting).

3

9

9

ONOFF

65

Setting165Setting265Setting365Setting4

21

Low21Middle21High21S-High

43

30sec.4360sec.43180sec.

43

600sec.

87

5rows874rows873rows872rows

CHECKING

INFORM BUILDING OWNER / OPERATOR OF THE FOLLOWING ITEMS

TROUBLESHOOTING

NOTE

When dipswitch 9 is set to "ON", the actual detection area may become smaller.

Proper
operation

Others Set dipswitch 9 to "ON".(*)

Adjust the detection area to "Deep" (Outside).

Waterdrops on the detection window.

Or install in a place keeping the waterdrops off.

The detection area overlaps
with that of another sensor.

Check ADJUSTMENTS 3-3.(*)

Objects that move or
emit light in the detection area.

Remove the objects.

Sensitivity is too high. Set the sensitivity lower.(*)

Installation mode is set to "ON". Set dipswitch 16 to "OFF".(*)

Yellow

* After changing the dipswitch settings, make sure to push the function switch for 2 seconds.

Remove highly reflecting objects from the
detection area. Or lower the sensitivity.(*)
Or change the area depth angle.

Signal saturation. (3rd, 4th or 5th row)Slow

Green

Blinking

Shallow

Deep

ShallowDeep

ShallowDeep

0

Status

Green

Motion

detection active

Red

Blinking Red

Entry

Outside of

detection

area

Outside of

detection

area

Entry into

3rd to 5th row

Entry into

2nd row

Entry into

1st row

Orange

Stand-by

Green

Stand-by

Operation indicator

Motion / Presence

detection active

Power OFF

-

None

Activation

output

Safety
output

ON OFF ONOFF

OFF ON OFFOFF

High

11

Low

11

N.O.

14

N.C.

14

Front view

0

Narrow

Wide

Eliminated

Eliminated

Eliminated

Eliminated

Narrow

Wide

Eliminated

Eliminated

Eliminated

Eliminated

3-6.Setting the self monitoring

10

10

Disable Enable

When the door remains open and the LED indicator shows fast or slow green
blinking, please refer to the TROUBLESHOOTING.
If the door still remains open, set dipswitch 10 to "Disable".

To comply with EN 16005, dipswitch 10 must be set to "Enable".

NOTE

3-7.Setting the Safety output (to door controller)

3-8.Setting the Safety input (from door controller)

3-11.Installation mode

3-10.Setting the Activation output

14

14

N.C.N.O.

13

13

UniBi

16

16

ONOFF

11

11

Low

High

12

12

Low

High

3-9.Settings the direction recognition

When Dipswitch13 is set to "Uni", uni-directional function is activated.
This function enables the door to close faster if a person walks away from the door.

Uni-directional function is disabled in case the detection at 1st and/or 2nd row continues
for more than 5sec..

NOTE

NOTE

The delay time between Safety input and Safety output is 10msec..

Dipswitch11 is for the Safety output (to door controller).

Dipswitch12 is for the Safety input (from door controller).

OPTEX Technologies Inc.

Corporate Headquarters

North and South American Subsidiary

East Coast Office

OPTEX Co.,LTD. OPTEX Technologies B.V.

Manufacturer European Subsidiary

5-8-12 Ogoto Otsu 520-0101, Japan
TEL.: [phone] FAX.: [phone]
WEBSITE: www.optex.co.jp/as/eng/index.html

8510 McAlpines Park Drive, Suite 108 Charlotte,
NC 28211 U.S.A.
TOLL-FREE: 800 877 6656 FAX.: [phone]
WEBSITE: www.optextechnologies.com

After changing the dipswitch settings, make sure to push the function
switch for 2 seconds.

push 2 seconds

[m(feet,inch)]

1 2 3

10 11 12

4 5 6 7 8 9

0

2.0

(6′7")

2.0

(6′7")

1.0

(3′3")

1.0

(3′3")

3.0

(9′10")

2.0

(6′7")

1 2 3

10 11 12

1 2 3

10 11 12

10 11 121 2 3

2.0 (6′7")

3.0 (9′10")

[m(feet,inch)]

3.0

(9′10")

2.0

(6′7")

1.0

(3′3")

0

2.0 (6′7")

3.0 (9′10")

02.0

(6′7")

1.0

(3′3")

2.0

(6′7")

Set dipswitch 16 to "ON" to adjust the 1st row.
During the Installation mode only the 1st row remains active and the operation indicator shows yellow.
After setting the row set dipswitch 16

"

OFF".

[m(feet,inch)]

1.0

(3′3")

-1.0

(3′3")

0

3.0

(9′10")

2.0

(6′7")

1.0

(3′3")

-1.0

(3′3")

After changing the dipswitch settings, make
sure to push the function switch for 2 seconds.

Or wipe the detection window with a damp cloth.

Use the rain-cover. (Separately available)

Dipswitch14 is for the Activation output to door controller.

Do not use any cleaner or solvent.

Proper

The detection area overlaps with
the door/header.

Henricuskade 17, 2497 NB The Hague,The Netherlands
TEL.: [phone] FAX.: [phone]
E-MAIL: [e-mail] WEBSITE: www.optex.eu
