User Manual (English)
14T, 18T & 23T
®
2
Thank you for your choice of Opranic!
With the purchase of your new product, you have chosen a modern, high-quality appliance.
This manual has been designed for our Opranic NOVA & LAVA 14T,18T and 23T. You have
purchased a high quality, ecient and original Opranic-IR Infrared Heater. Please read this
manual thoroughly in order to attain a sustainable satisfaction with your heater. Ensure you
read ‘Safety Instructions” in advance and use the product correctly.
Please keep this manual in a safe place for future reference and urgent needs.
Opranic is a registered trademark by Idero AB Sweden
For information please contact your country dealer or importer on www.opranic.com
Contact:
Webb www.opranic.com
E - mail: info@opranic.com
Made in Turkey
Ver. 1.2
© Opranic 2015
3
TABLE OF CONTENTS
1. SAFETY ....................................................................................................... pag 4
1.1 Safety Instruction ......................................................................................... pag 4
1.2 Specications ......................................................................................................... pag 4
1.3 Safe distances required for installation, high temperature and re protection .... pag 5
1.4 Maintenance and cleaning Instructions ......................................................... pag 5
1.5 Warranty .................................................................................................... pag 6
1.6 Repair and Service .................................................................................... pag 6
2. IP PROTECTION ....................................................................................... pag 6
3. INSTALLATION .......................................................................................... pag 7
3.1 Installation Instructions ........................................................................... pag 7
3.2 Installation Instructions Position + Distance ........................................... pag 8
3.3 Installation Instructions with right and wrong positions ....................... pag 8
4. OPERATING INSTRUCTIONS ................................................................. pag 9
5. TERMS OF WARRANTY .......................................................................... pag 10
4
1. SAFETY
1.1 Safety Instruction
Read these instructions carefully before installation and use. Keep this manual for
future reference
Check whether your appliance and power cord are damaged before operating your appliance. Check whether there is any crack, disjoint or scratch on the lament (heating tube). If any,
contact with your authorized technical service. If your appliance or power cord is damaged,
do not operate your appliance and return it to your technical service. Make sure that the
main electricity circuit is 220-240V and 50-60Hz and the connection is fused.
Check the safety of the network. The fuse must be minimum depending on model;
• Nova / Lava 1400W - 10A
• Nova / Lava 1800W - 10A
• Nova / Lava 2300W - 10A
Do not use your Opranic heater together with another appliance plugged to the same multiple sockets or connected to the same fuse.
• Use your appliance with a properly earthed plug.
• The earthed plug must fall outside heating eld and hot surface.
• The device shall not be used below the power socket.
• The power cord must not be left on or around the frame of your Opranic appliance.
• Unplug your appliance when you won’t operate it for a long term or will conduct cleaning
or maintenance.
• If the device is assembled to spaces such as bathroom, care should be taken to assemble
the device so that people having shower cannot contact with the device and control buttons.
• The unit must only be used by people older than 8 years .
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
1.2 Specications
model NOVA14T LAVA14T NOVA18T NOVA23T LAVA18T LAVA23T
power 1400W 1400W 1800W 2300W 1800W 2300W
volt 230-240V 230-240V 230-240V 230-240V 230-240V 230-240V
dimensions
14,5 x 80,5 x 23,0 cm
5,7 x 31,7 x 9,1 inch
14,5 x 92,5 x 23,0 cm
5,7 x 36,5 x 9,1 inch
5
The Opranic Nova series has a lifetime of approx. 6000 hours on the heating element.
The Opranic Lava series has a life time of approx. 8000 hours on the heating element.
Weight 3,0Kg for 14T and 3,5Kg for 18/23T. Cable length 1,9 meter (for ALL models)
1.3 Safe distances required for installation, high temperature and re protection
• Never install your appliance on a combustible surface (plastics, nylon, carton etc.)
• During operation the surfaces of the unit are hot!
• The unit must not be fully or partially covered with inammable materials, as overheating
can result in a re risk!
• This product is not designed to be used by children or persons with reduced physical or
mental ability or a lack of experience and knowledge, unless instruction regarding the product's use has been given by a person with responsibility for their safety or that this person
supervises operation. Children must be kept under supervision to ensure they do not play
with the product.
• The heater is equipped with a protective grill to prevent contact or to prevent large objects
from touching the hot lamp. The unit must not be used without this protective grill.
• Ensure that there are no inammable materials gathered on or close to the heater.
• The free space to the inammable material in the direction of radiation must be at least 1
meter.
• Do not place the heater directly under the electrical socket.
• The cable and plug must not be placed inside the hot radiant area.
• Do not stick anything into the protective grid.
• Do not make use of your heater to light up cigarette or similar materials.
WARNING – TO REDUCE THE RISK OF FIRE
1. Do not place any objects such as furniture, papers, cloths, and curtains closer than 1m (3
feet) to the front of the heater and keep them away from the sides and rear when the heater
is plugged in.
2. Do not place the heater near a bed because objects such as pillows or blankets can fall o
the bed and be ignited by the heater.
3. Always unplug the heater if it is not being used.
4. Avoid the use of an extension cord because the extension cord may overheat and cause
a risk of re. However, if you have to use an extension cord, the cord shall be 2mm (14 AWG)
minimum size and rated not less than 10A.
5. Do not operate within 7.6m (25 feet) of ammable material (gasoline, alcohol etc.)
6. Never block the front grill of the heater.
7. Never attempt to service the heater without disconnecting its power source.
1.4 Maintenance and cleaning Instructions
• Unplug your heater rst. Never pull your power cable to unplug your heater.
• Never pull your power cable to unplug your heater
• Unplug power cable
6
When the unit is used for the rst time or after a long period of disuse, smoke or odour may
result from dust or dirt that has collected on the element. This is completely normal and
disappears after a short time. The power supply to the unit must be disconnected during
all service, repair and maintenance work. The unit has no moving parts so the maintenance
requirement is small, but it must be kept clean and free from dust and dirt. If the reector
is not clean the thermal radiation from the unit will decrease and the heater will become
hotter. A large amount of dirt can cause overheating. The surface of the reector is sensitive
and must be cleaned with care. If the reector is dirty it must be cleaned or replaced by a
specialist.
1.5 Warranty
The warranty for Opranic Nova and Lava series is 2 years. Please read the warranty section for
terms for the warranty.
1.6 Repair and Service
Attention! Only technical services and persons authorized by Opranic may serve, repair and
replace the parts of this heater.
2. IP PROTECTION
IP (Ingress Protection) code in a product is a coding system dened for indicating protecting
levels provided by a case against access to dangerous section, entry of foreign materials
and water and for providing additional information about such protection. Protection class
number, the IP, is referred using a two digit number (IP XY). First digit (X) indicates protection
against gross particles (and of course against people) and second digit refers to protection
against uids. In general, the higher the digit is, the more protection provided to the product.
Nova series has IP34 protection
IP34 - Splash-proof , providing protection against large objects ( hand tools )
with a diameter of 2.5 mm and against
water spills from all directions.
Electrical components in Opranic
Nova heaters are manufactured in
accordance with IP34 protection class
and is isolated .
Opranic Nova series can safely be used
in outdoor environments.
Lava Series has IPX5 protection
IPX5 - protection against water jets,
provides protection against large
objects ( tools ) with a diameter of 2.5
mm and spolsäkerts against water
from all directions.
Electrical components in Opranic
Lava heaters are manufactured according to IPX5 protection class and is
isolated .
Opranic Lava series, safely be used in
outdoor environments
7
3. INSTALLATION
3.1 Installation Instructions
Attention! The appliance must be installed on the solid surfaces like concrete, wood or metal etc.
Never install on ammable surfaces! (Plastics, nylon vinyl etc.)
• Drill four holes on the wall to the place where the unit will be installed, with the distances.
• Insert the wall plugs (if needed), supplied with the unit, into the holes.
• Mount two of the L shaped legs on the wall using the screws supplied with the unit.
• Mount the other L legs on the unit using the four screws and the small wrench as shown in
(corresponding nuts are already built in on the body of the unit)
• Mount and x the L shape legs on the wall and on the unit respectively, using the bolts and
nuts and the washers and tighten.
• Depending on the area to be heated the angle of the unit can be adjusted between 0-45
degrees by the help of M8 Bakelite head bolt and nut xture.
• The heater can be mounted on the ceiling.
Warning! In case of an installation on the ceiling the heater may discolour the surface
depending on the surface material.
• Before operating the unit joints should be checked once again.
8
20
mounting
bracket (1)
A
B
35
min 45º
50
3.2 Installation Instructions Position + Distance
For minimum safety distances in case of horizontal installations. For minimum distances
from coverage area and other objects please see gure.
Minimum
distance
(cm)
Flammable material (2) A 100
Floor (3) B 180
(1) (2) (3)
SE: Takfäste SE: Brännbart material SE: Golv
GB: Ceiling bracket GB: Flammable material GB: Floor
DE: Decken-halterung DE: Entammbares Material DE: Boden
TU: Tavan TU: Yanıcı madde TU: Zemin
ES: Soporte de techo ES: Material inamable ES: Suelo
FR: Console de montage au plafond FR: Matériau inammable FR: Sol
FI: Seinäkiinnikkeen FI: Tulenarka materiaali FI: Lattia
NO: Takfeste NO: Brennbart materiale NO: Gulv
9
3.3 Installation Instructions with right and wrong positions
DIRECT YOUR HEATER TOWARDS THE MOST APPROPRIATE ANGLE
Do not let the light out through window, glasses etc. as the heater primarily heats the locations onto which its light falls
NOTE: Opranic Nova and Lava series can only be used horizontally!
Maximum tilt / angle is 5 degrees.
If more than 5 degrees is used the heater will be damaged in a short time.
4. OPERATING INSTRUCTIONS
Thermostatic version (Nova and Lava 14T/18T/23T, the “T” stand
for thermostatic controlled)
You can adjust then thermostat level according to your
comfort.
The heater operates constantly when the thermostat is at
the highest level.
You may reduce the energy consumption by adjusting
the thermostat according to your comfort
Switching OFF
When the appliance is not operated for long a term,
cleaning or maintenance is conducted or when the location of the heater is changed, the electricity connection
is turned o unplugging the power cord and adjusting the
thermostat in “0” mode.
on 1
2
3
4
5
max 6
o
10
5. TERMS OF WARRANTY
Warranty by Opranic does not cover the defects arising out of the improper use the appliance. The warranty does not cover the situations below:
1. The damages and defects arising out of improper use.
2. The damages and defects having occurred during the transportation after the delivery of
the product to the customer by the company.
3. The damages and defects arising out of low or excessive voltage, ungrounded plug usage,
faulty electricity systems, operating the appliance in dierent voltage values other than
specied in the instructions.
4. The damages and defects arising out of re and lightening.
5. The damages and defects arising out of repairs and maintenance by persons other than
Authorized Services.
6. The defects arising out of the breach of the instructions in the manual.
7. The damages and defects arising out of the transportation of the product instead of repair.
Attention! Faulty maintenance and cleaning are not covered by the warranty.
1. The dust and polluters in the environment.
2. Damage in the reector or lament due to faulty cleaning.
3. Faulty installation or dismantlement.
4. Operating with damaged lament, frame or power cord.
Above mentioned defects and services are not covered by the warranty.
Should this product be proven defective in workmanship or material, the consumer's sole
remedies shall be such repair or replacement as provided by the terms of this warranty.
Under no circumstances shall Opranic be liable for any loss or damage, direct, consequential,
or incidental, arising out of the use of or inability to use this product.
This warranty will be voided if the certicate of warranty lacks the stamp and signature of the
supplier as well as the date of purchase.
This warranty will become void if the serial number (if applicable), model number identication, or brand have been wholly or partially removed or erased.
All Opranic brand products have CE certicate
This symbol on the product or its packaging indicates that the appliance cannot be treated
as normal domestic trash, but must be handed in at a collection point for recycling electric
and electronic appliances.
Your contribution to the correct disposal of this product protects the environment and the
health of your fellow men. Health and the environment are endangered by incorrect disposal. Further information about recycling of this product can be obtained from your local town
hall, your refuse collection service, or in the store at which you bought the product.
11
®
www.opranic.com
Loading...
