Page 1
Thank you for purchasing FTHS
Optical 4K HDM I extender, FTHS extends HDMI2.0 signal up to 200M using a single strand of multi-mode optical
fiber.
www.ophit.com
User’s Guide
4K HDMI Optical Extender
FTHS
Page 2
NOTE: Package content may differ if you have placed a special order or
placed order from anywhere other than OPHIT CO., LTD.
OPHIT CO., LTD. reserves the right to make changes without further
notice to a product described herein to improve reliability, design,
packaging or function.
User’s Guide
Check the package and make sure you have everything:
Contents
(1) FTHS Transmitter & Receiver
(2) +5V DC Power supply x 2pcs
(3) User’s Guide
If any of these items are missing in your package, contact OPHIT or
your supplier for support.
Check your package
Installation
Installation Steps:
1. Connect the Transmitter module to the source device using
HDMI short copper cable. (HDMI cable is not Included)
2. Connect the Receiver module to the display device using
HDMI short copper cable. (HDMI cable is not Included)
3. Connect a single strand of OM3 multi-mode SC terminated fiber
optic cable(50/125㎛) from the Transmitter to the Receiver module.
4. Connect the included +5V DC power supply into Transmitter and
Receiver module.
5. Active LED indicator on the modules will be light up after
all connections are completed.
*Recommend to use the HDMI2.0 standard cable for proper working
Page 3
We, OPHIT hereby warrant the final purchase of our product as follows.
In the case of troubles on our products, please contact the shop purchased.
One year limited warranty
Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased.
Out of warranty services
When you request services (in the case of non manufacturing defects but the troubles by misusage), may served with charge as follows.
- Defects of products caused by accident, disaster.
- Damages of products caused by the customer’s carelessness or mistaken application.
- Damages of products caused by the application of the parts or products not supplied or sold by our company.
- Damages of products and related defects caused by not our staff or the men or group not nominated by us for services.
The interchanged parts and products for maintenance services shall be replaced as new parts and products operating
normally, and the inter-changed parts and products shall be subjected to our company.
Warranty
www.ophit.com
Page 4
Technical and Sales Support
REV. 1.0
KOREA HQ
OPHIT CO., LTD.
3F Suntechnovil, 5-27 Mangpo-Dong, Youngtong-Gu, Suwon-City,
Kyunggi-Do, Korea (16681 )
Tel: + 82 (0)31 695 5543
Fax: + 82 (0)31 695 5545
E-Mail
www.ophit.com
© 2016 OPHIT CO., LTD. All rights reserved.
Printed and designed in Korea
