OpenVox FA100 User Manual

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

1

OpenVox FA100 User Manual

OpenVox Communication Co. Ltd.

Address: F/2, Building No.14,Shangsha Science & Technology Park,

No.9283,BinheRoad, Futian District, ShenZhen ,Guangdong

518048,China
Tel: [phone],
Fax: [phone]

Email for Sales: [e-mail]
Email for Technical Support: [e-mail]
Business Hours: 9:00AM-18:00PM from Monday-Friday

Thank You for Choosing OpenVox Products!

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

2

Table of Contents

FA100 Description ................................................................................ 3

FA100 Features ..................................................................................... 4

FA100 Installation Guide ...................................................................... 5

Hardware Connection 5

Device Driver Detection 6

FA100 Operating Instruction 7

FA100 Software Installation ............................................................... 10

Software Download 10

Software Installation 10

Explanation of Configuration Files 11

Steps to Use 12

Technical Support ............................................................................... 14

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

3

FA100 Description

Most of the time, users need to reconnect PSTN line to analog

telephone to make it work when the PBX Sever faces a power failure. It

may cause only a little extra work for people who use simple and small

PBX servers. But for those who run complex PBXs in server rooms, it

becomes real problems.

How to eliminate this problem? The release of OpenVox FA100

failover box solves it. The FA100 can automatically switch the PSTN line

to analog telephone when the power of the PBX server has been cut off

and will automatically switch back to normal when the power is on again.

In this way, you will no more need to worry whether the power is cut off.

FA100 is controlled through an Asterisk loadable module

res_failover.so. This module keeps sending “running” signal to FA100

when Asterisk is running. Once Asterisk is down or system power is cut

off, the module will not be able to send out the “running” signal, thus

FA100 will automatically switch to the standby telephone.

FA100 provides a reliable and flexible solution to Asterisk PBX.

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

4

FA100 Features

 Easy installation: Connected to computer or server by USB port. In

order to provide more stable power supply, the number of USB port

connected to hosts is two.

 Industry standard USB type B connector.
 Support USB 2.0 and 1.1.
 Support all compatible analog cards and E1/T1/BRI cards.
 Two indicator lights: red and green. Two light, Asterisk and FA100

work normal. Only green lights, Asterisk hangs and FA100 switches

PSTN line to the backup phone.

 Support up to 8 standby Analog ports and 2 E1/T1/BRI/Ethernet

Ports.

 Supports multiple FA100 devices in one system.
 Two network ports. Each network interface is divided into four ports,

A, B, C, D respectively, the port A and B are interconnected. The NET

port of Digital cards can be connected to port A or B. And the other

one port can be connected to our TAP cards to record, so as to meet

your requirement of functional diversification. C and D are connected

to CPE port of Digital cards, D is the port of the primary server, and C

is the standby server. For cable connection, LAN line is connected to

port A or B, D is connected to the main server and C is connected to

backup server.

 Supports software watchdog.

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

5

FA100 Installation Guide

Hardware Connection

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

6

Device Driver Detection

Usually under Linux, you do not need to install driver program.

Generally system already comes with a USB - to - Serial Drivers support.

Users can run the following command to see if the FA100 has been

recognized or detected by the system.

# dmesg | grep FTDI

Users can also run “lsusb” command to check if the FA100 device is

connected.

# lsusb

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

7

FA100 Operating Instruction

The following picture shows how the FA100 works when the PBX Server

and Asterisk work. The PSTN signal goes from:

1->(blue)2->(red)3->(green)4->(purple)

When dial out from internal, the PSTN signal goes inversely.

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

8

If the PBX Server stops working (power off) or Asterisk works abnormally,

FA100 will launch automatic switching function, and the PSTN signal goes

as follows:

1->(blue)2->(purple)

When dial out from internal, the PSTN signal goes inversely.

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

9

The picture below shows FA100 network ports connection, such as the

connection between Network cable, PRI, BRI and port A or B.

When Asterisk normally works, the PSTN signal goes:

1->LAN (red) 2->main network (green)

When Asterisk works abnormally，the PSTN signal goes:

1->LAN (red) 2-> Redundant network (purple)

If FA100 doesn’t receive the "running" signal from the Main Server, then

the internal circuits will be switched to Redundant Server automatically.

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

10

FA100 Software Installation

Before installation, make sure whether the host system (LINUX) is

running well, whether the DAHDI and Asterisk have been installed well,

whether boards (Analog cards) drivers have been loaded into the system.

If you have bought our cards, but don’t know how to install them, you

can go to our official website to download user manuals. After

everything prepared well, follow next steps.

Software Download

#wget

www.openvox.cn/download/drivers/failover/failover-1.0.1.tar.gz

Software Installation

1) Unzip the file

#tar –xvzf failover-1.0.1.tar.gz

#cd failover

2) Copy the file to res directory under asterisk

# cp res_failover.c /usr/src/asterisk-**/res/

3) Copy the configuration file to /etc/asterisk directory

# cp failover.conf /etc/asterisk/

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

11

4)Compile and install

#cd /usr/src/asterisk-**/

#make

#make install

5)Reboot asterisk

#reboot

Explanation of Configuration Files

[openvox_failover_1]
device=/dev/ttyUSB0
; Kick the soft watchdog every 4000ms
; default value: 4000
; Between 100ms and 9000ms
;kick_time_interval=4000
;event_cmd=no
;event_cmd=logger
; default value: yes

autorun=yes

;[openvox_failover_2]
;device=/dev/ttyUSB1
;kick_time_interval=500
;event_cmd=logger
;autorun=yes

 [openvox_failover_1]：Name of FA100 Device, to distinguish from

different devices, Must Be Configurable:

 device=/dev/ttyUSB0：Name of USB device that FA100 uses, Must Be

Configurable;

 kick_time_interval：the time interval of software watch dog; the

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

12

default time is 4000ms, users can customize the time with 100ms for

Minimum and 9000ms for Maximum;

 event_cmd：event command, default is logger, it will record the

FA100 status in system log;

 autorun：it decides whether FA100 starts when asterisk boots;

default is yes which means FA100 starts when asterisk boots; if no,

the FA100 will not start when asterisk boots and users will need

manually boot the device by running failover start command.

Steps to Use

1)Start asterisk

# asterisk –vvvgc

2)Start FA100 device

*CLI> failover start

3)Stop FA100 device

*CLI> failover stop

4)Show FA100 device information

*CLI> failover show

5)Reload FA100 device configuration file

*CLI> failover stop Before reloading configuration file, must

stop all FA100 devices

*CLI> failover reload Reload configuration file

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

13

6) Check connection

*CLI>pri show spans

7)Reboot DAHDI

*CLI>dahdi restart

FA100 User Manual

OpenVox Communication Co. Ltd | www.openvox.c

14

Technical Support

If you meet any technical problems when using OpenVox products, you

can check our Forum for help or contact us directly be the following

ways:

i. BBS feedback problems

Input issues to our BBS when you encounter technical problems, we

will solve the problem you mentioned as soon as possible.

http://bbs.openvox.cn/

ii. Email Support

You can email to the following email address:

[e-mail]

Unless it is an emergency, this is always the most efficient way to get

support.

OpenVox is a trademark of OpenVox Communication Co. Ltd

All other trademarks are of their respective owners.
