Opel 2013 Corsa Installation Manual

2013 Models Edition 1

OPEL CORSA

This brochure covers Corsa S, SC, SE and Limited Edition only. Some of the models shown include options and accessories available at extra cost. And not all of the features described are
available on every model. So please check in the separate Price and Specification Guide, available from your local Opel dealer or online at www.opel.ie, for further details. Note: some of the
vehicles illustrated may not be to final GM Ireland specification.

Corsa. Put the fun back into driving

Get yourself into a Corsa. And get a lot more fun out of life. With stunning styling, funky colours and
brilliant attention to detail, inside and out. A dynamic chassis and punchy petrol or diesel engines.
Plus, bags of clever features. It can only make life better. Wherever you go. Whatever’s in store for you.

Contents

Limited Edition 04
Linea Stripes Pack 06
ecoFLEX 08
Engines and transmissions 10
Safety and security 12

Comfort equipment 14
Model line-up 16
Colours 24
Packs 25
Trims 26

Wheels and tyres 28
OPC Styling 29
Accessories 30

Why blend in when you can stand out?

Corsa Limited Edition – you don’t look this sharp by chance. You need Corsa’s natural
style and a whole lot of attitude. Colour it all red, white, orange, black or yellow. Add black
mirrors, roof and dark style headlights. Match it with black 17-inch twin-spoke alloy wheels
and you can see the results for yourself.

4

Vehicles illustrated also include OPC Styling Pack (consisting of front lower
spoiler, side sills, rear roof spoiler and rear lower skirt), optional at extra cost.

Corsa. Get yourself noticed.

Want your Corsa SC to really stand out from the crowd? Then check out
the optional Line Pack. Unique to SC models, it also includes white 17-inch
alloy wheels and white door mirrors. Now that should get you noticed!

Corsa SC model illustrated. Line Pack and
two-coat pearlescent paint are optional at
extra cost.

7

Corsa. Fun and frugality in equal measure

Corsa’s range of ecoFLEX engines have been designed to save you money. So how
do we do it without losing Corsa’s fun, lively power delivery and driveability? Well,

the benefi t of improved fuel economy speaks for itself but lower CO

2

emissions mean

you’ll also benefi t from signifi cant tax savings.

Of course, we are always looking to further reduce vehicle CO2 emissions and we
already have some of the lowest emissions in Ireland. We’ve been researching ways

of developing new cars that are even more effi cient than ever before. The new

Opel Ampera is an Extended-Range Electric Vehicle (E-REV) that can drive up to
80 kilometres on battery power alone and over 500 kilometres utilising an on-board
electric generator system.

So there it is. You get all of Corsa’s sense of fun and our philosophy of forward
thinking – helping your money go further.

Corsa SE model illustrated features 17-inch alloy wheels, Adaptive Forward Lighting, dark-tinted rear windows and Guacamole paint which are all optional at extra cost.

9

The Corsa’s engine range is big on flexibility, economy and technology too.
Choose from our lively multi-valve petrol or our turbo diesel units and you can
be sure of great driveability and outstanding fuel economy. And if that isn’t
enough choice you could opt for Easytronic, automatic transmission or Opel’s
Start/Stop technology. Check out the model pages for individual availability.
Decisions, decisions?

Petrol engines. Corsa models are available with three, Euro 5 compliant petrol
engines – the 1.0i 12v ecoFLEX, the 1.2i 16v VVT and a 1.4i 16v VVT –
combining power and fuel efficiency with low CO

2

emissions.

ecoFLEX turbo diesels. Corsa’s Euro 5 diesel engine range features
a choice of two efficient 1.3CDTi 16v units (75PS and 95PS) that combine
performance, refinement and efficiency, offering superb environmental
credentials. Both Corsa diesel engines include diesel particulate filters.

Start/Stop technology. In addition, some of our engines benefit from
Start/Stop technology. This system switches the engine off when you stop
at the lights or in traffic, then restarts it automatically once the clutch is
depressed, saving fuel and reducing emissions even further. The AUTOSTOP
symbol housed within the rev counter indicates that the engine has stopped.
The system can be deactivated manually by simply pressing the ECO button
on the facia. Start/Stop drops the CO

2

emissions of the 1.2i 16v VVT from 129
to 119g/km, placing the vehicle inside tax band A (except if optional 17-inch
alloy wheels are added).

Easytronic. Choose Corsa’s optional
Easytronic transmission and you’ll get a
five-speed manual gearbox with a fully
automatic mode. In manual mode, you
push the lever forward or back to shift
gears up or down and by nudging the
lever to the side you switch to fully
automatic mode. There’s no clutch pedal
so you can drive it on an automatic-only
driving licence.

Transmissions. The 1.3CDTi 16v (95PS) SE comes with a six-speed manual
gearbox. The rest of the range comes with a five-speed manual as standard,
with sophisticated four-speed automatic (1.4i 16v) and five-speed Easytronic
(1.2i 16v) transmissions also available.

Shift-up indicator. Standard on every Corsa model, a
shift-up indicator on the rev counter alerts the driver
to the optimum time a gear change is required, further
enhancing fuel efficiency.

Chassis. We could just tell you that the Corsa chassis has been designed
to ensure pure driving pleasure without ever compromising ride comfort.
But wouldn’t it be better to discover how much fun it is to drive by trying one
for yourself? Then you’ll really be able to appreciate the benefits of a chassis
that features optimised spring, damper and anti-roll bar settings to combine
serious ride comfort with real agility. And an advanced Anti-lock Braking
System (ABS) that combines with other chassis safety features such as
cornering brake control and optional Electronic Stability Programme-plus to
improve stability and steering behaviour in a range of emergency situations.

Choose the Limited Edition model and you will also enjoy a lower ride height
and sportier spring and damper settings, plus progressive rate, variable ratio
power steering.

Details of engine availability and standard features can be found on the
individual model pages starting on page 17.

11

Engines and transmissions

Model illustrated features Adaptive Forward Lighting and Guacamole paint optional at extra cost.

13

Safety and security

Intelligent safety. Our safety

features are almost taken for
granted nowadays, but it doesn’t
mean we’ve stopped adding new
ones. Double front seatbelt
pretensioners and adaptive brake
lights are just two examples of
how Corsa achieves such a high
safety rating.

Static cornering light. Halogen
Adaptive Forward Lighting throws
light 90 degrees left or right for
enhanced lateral vision. The system
operates up to 40 kilometres per
hour, also while reversing.

Double pretensioners. Front seatbelt
pretensioners act on the diagonal
shoulder restraint on all models.
And on most models the lap belt
too. So in the event of a collision,
they’re ready to interact with the
front airbags and compensate for
lateral seat movement.

Daytime Running Lights. As well as
providing a striking style accent on
the Corsa the Daytime Running
Lights improve your visibility to other
road users whatever the conditions.

Dynamic curve light. Halogen
Adaptive Forward Lighting moves
the headlight beams outwards up
to 15 degrees left or right of the
straight ahead position when you
turn the steering wheel, helping
improve your vision of the
approaching bend.

Airbags. Most Corsa models feature double-action front seatbelt
pretensioners and up to six airbags, including front seat side-impact
and curtain airbags too. Press a button on the centre console to
deactivate the front passenger’s airbag and you can keep a rear-facing
child seat up front.

Security. Every Corsa features an
engine deadlock immobiliser as
standard as well as remote control
central locking. There’s also an
internal door locking switch for
added reassurance in the event
of unwanted attention from
outside the car.

Adaptive brake lights. ABS brakes
can shorten your stopping distance
in slippery road conditions, but
what about the driver behind you?
With Corsa, if the ABS is activated
at over 29 kilometres per hour, your
brake lights blink at five times a
second, warning the following driver
that you’re emergency braking.

Adaptive Forward Lighting (AFL). Night driving has always had the
potential to generate stress. Corsa’s advanced halogen AFL system
projects the headlight beams into curves and provides extra side
illumination when making extreme turns. The result: less stress, more
safety. Optional on SE models.

Easy life. Corsa is available with some pretty brilliant features so you never
have to compromise on what you really want. Like Electronic Climate Control.
Heated steering wheel. Or simply added peace of mind. So it’s easy to choose
a new Corsa that fits the way you live perfectly.

Sunroof with interior blind. Optional
at extra cost on SC and SE models, the
electrically operated glass sunroof
stretches wide across the car for
maximum fresh air and blue sky. And if
the sun’s too strong, you simply pull
out the roller blind to reduce glare.

Rain and light sensors. Standard on
SE models, automatic lighting control
can switch the car’s lights on when it
gets dark. Other sensors can switch
the wipers on and even dim the rear­view mirror – all automatically.

Winter Pack. Standard on SE and
optional on SC and Limited Edition
models, the Winter Pack provides both
driver and front passenger with heated
seats, while the heated steering wheel
is a first-in-class feature.

Air con and ECC. Air conditioning
provides chilled air on hot days, faster
demisting on damp days and a more
pleasant atmosphere throughout the
year. Move up to Electronic Climate
Control (ECC) for a more consistent
control of the interior temperature.

Cruise control. The easy-to-use, twist
up/twist down cruise control – standard
on many models and available as part
of the Technical Pack on SC – allows
you to maintain a steady speed without
keeping your foot on the accelerator. So
it’s more comfortable on long journeys
and easier to keep to speed limits too.

Driving position. You’re going to be
spending some quality time in your
Corsa. So we’ve made it easy for you
to make sure it’s exactly how you
want it. The Corsa interior is big on
ergonomic efficiency. Which means
it’s designed around real people, with
space to relax and plenty of room for
long legs and broad shoulders – front
and rear. All the controls are within
easy reach so you don’t have to take
your eyes off the road for more than a
moment to adjust the heating or the
audio, for example.

Best of all, it’s easy to find the perfect
seating position with a driver’s seat
that moves six ways – including
height adjustment – on most models.
On SC models and above (optional
on S as part of the Comfort Pack),
you’ll find fully adjustable steering
too, bringing us right back to what
we said earlier about real people and
perfect ergonomics.

Electrically operated glass sunroof optional
at extra cost on SC and SE models.

15

Comfort equipment

VX_N_COR_16073.tif

Corsa. You choose.

So here’s the question. Do you get what you want? Or make
do with what you get? We suspect the former. So it’s just
as well that Corsa comes with an excellent choice of
feature-packed models, petrol and diesel engines, and
drop-dead gorgeous colour and trim choices.

17

S

Corsa S

Standard features include:

•

CD/MP3 player, 6 speakers, aux-in
socket and stereo radio

•

Chrome-style headlights

•

Body-colour bumpers

•

Daytime Running Lights

•

Remote control central locking

•

Speed-sensitive power-assisted
steering

•

Matt chrome instrument panel

•

Electrically operated front windows

•

Electrically adjustable door mirrors

•

Driver’s and front passenger’s
dual-stage airbags

•

Driver’s seatbelt reminder

•

ISOFIX preparation on outer
rear seats

•

Anti-lock Braking System (ABS)

•

Emergency Brake Assist

•

Electronic engine deadlock
immobiliser

•

Door-to-door illumination

•

Welcome lighting

•

Map pockets on front seat backs

•

14-inch steel wheels

Engine availability

3 and 5 door

1.0i 12v ecoFLEX

1.2i 16v VVT ecoFLEX Start/Stop

1.2i 16v VVT Easytronic

1.3CDTi 16v (75PS) ecoFLEX

Model illustrated features air conditioning and
Plus Pack optional at extra cost.

Engine availability

3 and 5 door

1.2i 16v VVT ecoFLEX Start/Stop

1.2i 16v VVT Easytronic

1.4i 16v VVT

1.4i 16v VVT automatic

1.3CDTi 16v (75PS) ecoFLEX

Model illustrated features air conditioning and
two-coat metallic paint, optional at extra cost. Model illustrated features Reflection cloth trim in Charcoal.

Corsa SC

Additional features over and above
S models include:

•

15-inch five twin-spoke alloy wheels

•

Front fog lights

•

Steering wheel mounted audio
controls

•

Chrome-effect interior detailing

•

Body-colour door handles

•

Front seat side-impact and full-size
curtain airbags

•

Adjustable steering column

•

Driver’s seat height adjuster

•

Choice of Charcoal (illustrated), Blue
or Orange Reflection cloth

19

SC

Corsa SE

Additional features over and above
SC models include:

•

16-inch alloy wheels

•

Air conditioning

•

Cruise control

•

Multi-function trip computer

•

Electrically heated leather-covered
steering wheel

•

Electrically heated front seats

•

Rain-sensitive windscreen wipers

•

Automatic Lighting Control

•

Sports instruments

•

Alloy-effect front door sill covers

•

Heated door mirrors

•

60/40 split-folding rear seat back

•

Front and rear seats with Morrocana
side bolsters

•

Translucent lighting and window
controls

Engine availability

3 and 5 door

1.2i 16v VVT ecoFLEX Start/Stop

1.3CDTi 16v (95PS) ecoFLEX

Model illustrated features electronic climate control
(including graphic info display), Bluetooth® mobile
phone system and metallic paint, optional at extra cost.

21

SE

Corsa Limited Edition

Additional features over and above
S models include:

•

17-inch black twin-spoke alloy wheels

•

Carbon Flash black roof and door
mirror housings

•

Sports suspension

•

Front fog lights

•

Sports-style front seats

•

Leather-covered steering wheel

•

Steering wheel mounted
audio controls

•

Piano Black interior detailing

•

Body-colour door handles

•

Adjustable steering column

•

Driver’s seat height adjuster

•

Cruise control

•

Dark-style headlights and tail lights

•

Dark-tinted rear windows

•

Sports pedals

•

Heated door mirrors

•

Multi-function trip computer

•

Red, silver or yellow interior seat
stitching

•

Red, white, orange, matt chrome or
yellow air vent rings

•

Choice of five exterior colours –
Flame Red, Glacier White, Chilli
Orange, Carbon Flash or Flaming
Yellow

Engine availability

3 and 5 door

1.2i 16v VVT

1.3CDTi 16v (75PS) ecoFLEX

Model illustrated features air conditioning, optional
at extra cost. Charcoal/Red Twist cloth trim and red air vent rings feature with Flame Red.

23

Limited Edition

*Limited Edition models feature a Carbon Flash black roof and door mirror housings.
**Optional at extra cost.

Flame Red – Solid

Available on S/SC/SE/Limited Edition*.

Sovereign Silver – Metallic**

Available on S/SC/SE.

Lime Green – Pearlescent**

Available on S/SC/SE.

Glacier White – Brilliant**

Available on S/SC/SE/Limited Edition*.

Chilli Orange – Metallic**

Available on S/SC/SE/Limited Edition*.

Oriental Blue – Pearlescent**

Available on S/SC/SE.

Royal Blue – Solid

Available on S/SC/SE.

Silver Lake – Metallic**

Available on S/SC/SE.

Carbon Flash – Metallic**

Available on S/SC/SE/Limited Edition.

Guacamole – Brilliant**

Available on S/SC/SE.

Flaming Yellow – Brilliant**

Available on S/SC/SE/Limited Edition*.

Pepperdust – Metallic**

Available on SC/SE.

Technical Grey – Metallic**

Available on S/SC/SE.

Waterworld – Pearlescent**

Available on S/SC/SE.

Colours

25

Packs

†Optional at extra cost. Not available on models fitted
with the electrically operated sliding glass sunroof.
††Metallic or pearlescent paint cost is in addition to the
cost of the Line Pack.

Due to the limitations of the printing process, the colours
reproduced may vary slightly from the actual paint
colour. As a result, they should be used as a guide only.
Your Opel dealer has a comprehensive display of our
paint samples. Vehicle illustrated is a non-specific model.

Standing out from the crowd
couldn’t be any easier. The
new Corsa Line Switch Pack**
– consisting of twin black
stripes on the bonnet and
tailgate together with twin
body-colour stripes on the
roof – gets you noticed.

Why not express your style
with a Corsa SC Line Pack

†

consisting of white 17-inch
alloy wheels, white door
mirrors and twin white
stripes on the bonnet, roof
and tailgate. Available in
these striking combinations.

Flame Red – Solid

Available on Limited Edition.

Carbon Flash – Metallic

††

Flame Red – Solid

Glacier White – Brilliant

Available on Limited Edition.

Lime Green – Pearlescent

††

Chilli Orange – Metallic

††

Flaming Yellow – Brilliant

Available on Limited Edition.

Oriental Blue – Pearlescent

††

Technical Grey – Metallic

††

Drops cloth/Morrocana – Charcoal

Standard on SE models.

OP_N_COR_17243.tif

Reflection cloth – Charcoal

Standard on SC models.

Punch cloth – Charcoal

Standard on S models.

With funky colours you need a
matching interior. Corsa, better
looking inside and out.

Twist cloth – Charcoal/Red

Standard on Limited Edition models
(available with Flame Red exterior colour).

OP_N_COR_18489.tif

27

Trims

Reflection cloth – Orange

Optional on SC models at no cost
(available with Glacier White, Guacamole, Carbon
Flash, Sovereign Silver, Chilli Orange and Technical Grey
exterior colours).

Reflection cloth – Blue

Optional on SC models at no cost
(available with Glacier White, Waterworld, Technical Grey
and Silver Lake exterior colours).

The colours illustrated may vary slightly from the actual trim material.
As a result, they should be used as a guide only. Your Opel dealer has a
comprehensive display of our trim swatches.

Twist cloth – Charcoal/Silver

Standard on Limited Edition models
(available with Glacier White, Chilli Orange and
Carbon Flash exterior colours).

Twist cloth – Charcoal/Yellow

Standard on Limited Edition models
(available with Flaming Yellow exterior colour).

Please note: S models feature
a full size steel spare wheel.
SC, SE

†

and Limited Edition†
models feature a one size
down steel spare wheel.

Standard wheels:

Optional wheels**:

S

14-inch steel wheels with flush
covers and 185/70 R 14 tyres.

SC

15-inch alloy wheels with
185/65 R 15 tyres.

SE

17-inch alloy wheels with
215/45 R 17 tyres.

SE

16-inch alloy wheels with
195/55 R 16 tyres.

Limited Edition

17-inch alloy wheels in black
with 215/45 R 17 tyres.

Line Pack*

17-inch alloy wheels in white
with 215/45 R 17 tyres.

28

Wheels and tyres

*Available on SC models only.
**Extra-cost option.
†Models fitted with the optional OPC Styling
Pack feature a tyre inflation kit in lieu of
the spare wheel.

29

OPC Styling

Inspired by our racing heritage,
Opel OPC styling products come
with all the same experience,
knowledge, and passion for style
and performance. They put the
accent firmly on quality and
exclusivity, with a winning edge.
And they add flair, personality and
excitement to every Corsa model.

OPC Styling Pack. Optional on
SE and Limited Edition models,
this pack consists of a front lower
spoiler, side sills, rear roof spoiler
and rear skirt. In addition, SE
models include a chrome-effect
exhaust tailpipe (standard on
Limited Edition).

These items are also available
separately as dealer-fit
accessories. Vehicle illustrated
also features electric glass
sunroof, Adaptive Forward
Lighting, 17-inch alloy wheels,
dark-tinted rear windows and
two-coat metallic paint,
optional at extra cost.

Vehicle illustrated features the following accessories fitted at extra cost:
Line pack, 17-inch white alloy wheels, body side protection mouldings,
OPC styling kit and base carrier roof rack system with Thule roof box.
In addition dark-tinted rear windows and two-coat pearlescent paint,
optional at extra cost.

31

Genuine Opel Accessories

Genuine Opel accessories are the right choice for your Corsa. Whatever you’re
into, there’s certain to be an Opel accessory with your name on it, all fitted by
trained Opel professionals. We’ve only featured a small selection of what’s
available here, so please check with your Opel dealer for accessory availability
information or visit our website at www.opel-accessories.com

Economy, rubber and velour mats
(illustrated) are available for Corsa
and feature unique fixing points
which help keep them firmly in place.

Bicycle carrier. Used in conjunction
with the Opel base carrier this system,
manufactured by Thule, allows a
bicycle to be transported on the roof of
your vehicle. Designed to enable easy
installation, the bicycle is secured using
quick release straps and a lock for
security. Available in steel or aluminium.

Base carrier. The Opel roof rack
system begins with this base carrier.
It comprises of two T-track bars which
support a wide range of attachments.
Each carrier is supplied with locks for
added security.

Privacy shades. Available for the rear
side and tailgate windows, privacy
shades provide shade for rear seat
passengers and increase security.
The tailored fit still allows the rear
windows to be opened.

FURTHER ACCESSORIES INCLUDE:

•

Floor mats

•

Cargo liner

•

Mudflaps

•

Headlight protectors

•

Detachable tow bar

•

Electrically chilled 12-litre cool bag

•

Thule roof boxes

•

Anti-slip mat

•

Steering wheel security bar

•

Child seats

•

Alloy wheels

•

OPC styling accessories

OP1200188

www.opel.ie

Every effort has been made to ensure that the contents of this publication were accurate and up-to-date at the time of going to press (October 2012). Opel vehicles are

equipped with components manufactured by various General Motors operating units and outside suppliers. The Company reserves the right to change specications
and withdraw products from sale without notice. Any such alterations will be notied to Opel dealers at the earliest opportunity; please consult your local dealer for
the latest information. The specications detailed within this brochure are not necessarily applicable to alternative models such as Special Editions. Details of any such
models will be contained in specic literature or found on the Opel website. The colours reproduced in this brochure may vary slightly from the actual paint colour or

trim material due to the limitations of the printing process. Please note that Opel dealers are not the agents of General Motors Ireland Limited and are not authorised

to bind the Company by any specic or implied undertaking or representation. It is advisable to ensure that your motor insurance policy provides adequate cover for
additional tted options and accessories. As part of Opel’s policy of environmental care, this brochure is printed on paper manufactured using Elemental Chlorine Free
pulps from specially farmed, sustainable timber resources. All rights reserved. No part of this publication may be reproduced in any form or by any means, without the

prior written permission of General Motors Ireland Limited.

Published October 2012 General Motors Ireland Limited, Fern Road, Sandyford Business Estate, Dublin 18. www.opel.ie

Opel Service.

Europe-wide Customer Service.

Throughout Europe, more than 6,000 Opel repair
workshops are ready to provide professional and
punctual service. As you’d expect, they’ll repair

your vehicle to the highest standards. More

unusually, perhaps, they’ll tell you exactly what’s
been done and why, and they will show any costs

involved clearly and concisely.

New Vehicle Warranty.

2-year new vehicle warranty. This warranty
applies to any new Opel car for a period of 24

months without any mileage restrictions, as from

the day on which it was either registered for the
first time or delivered to the customer by the

dealer, depending on which date comes first.

Opel Roadside Assistance.

This free-of-charge mobility service is valid
for all new Opel vehicles during the first year
after the date on which they were first
registered or delivered to the customer by the

dealer, depending on which date comes first.
No matter where you are, the Opel Assistance

is there to help. In more than 40 European

countries – round the clock. Offering services
such as breakdown assistance, towing services,
rental car, hotel accommodation or the
organisation of onward transportation, e.g. via

rail or air (please see programme conditions).

12-year Anti-Perforation Warranty.

Opel provides you with a reliable long-term

warranty against perforation, provided you have

your vehicle serviced and all necessary inspections

performed according to the service booklet.

2-year Warranty for Opel Batteries.

With a 2-year warranty for service-installed Opel
original batteries your starting problems are
over – even in the coldest winter.

Parts and Accessories Service.

Opel parts and accessories are available at your

local Opel Shop, where you’ll find everything to
make your vehicle more comfortable or to meet
your individual needs, as well as expert advice.

Opel on the Internet.

Need instant information? At www.opel.ie you
can access a wealth of information on all Opel
cars, services, and accessories. Get online for
Opel news and product updates.

Recycling.

Information about Design for Recycling, Take­Back points for End of Life Vehicles (ELVs) and
the recycling of ELVs can be found on the Opel

website www.opel.ie

In case of any questions, please ask your
Opel dealer. More information can be found
at www.opel.ie
