This brochure covers Zafi ra Life, Club, Design, Elite,
SRi and OPC models only. Some of the models shown
include options and accessories available at extra
cost. And not all of the features described are
available on every model. So please check in the
Opel Zafi ra Price Guide for further details. From time
to time, we also offer alternative Zafi ra models such
as Special Editions, featured in separate literature or
can be found on the Opel website www.opel.ie

Exterior styling

4

Interior styling

6

Flex7® seating

8

Environmental issues

12

Panoramic roof

10

Driving dynamics

14

Safety and security

16

Interior features

18

Model line-up

20

Accessories

26

Zafira OPC

28

Technical data

32

Features explained

38

Colours and trims

30

Zafi ra shows what can be achieved
with clever thinking. All that dynamic
driving experience, interior comfort
and built-in, seven-seater fl exibility
– but with sharp styling, cool interior
fi nishes and impressive safety features.

make the world

adjust to you

T21073 Opel Zafira.indd 3T21073 Opel Zafira.indd 3 31/10/08 11:08:4931/10/08 11:08:49

Fed up with boxy looking MPVs? Here’s a
welcome change. A seven-seater compact
people carrier that’s defi nitely got the
X-factor. With its radical, tapered roofl ine,
dynamic front grille and bumper shapes,
chrome headlight surrounds and great
alloy wheel designs too, family travel has
never been so attractive.

always cruise
in style

T21073 Opel Zafira.indd 4T21073 Opel Zafira.indd 4 31/10/08 11:08:5131/10/08 11:08:51

5

T21073 Opel Zafira.indd 5T21073 Opel Zafira.indd 5 31/10/08 11:08:5631/10/08 11:08:56

Zafi ra’s design themes move effortlessly from outside to
inside with a driver-friendly facia and high quality interior
fi nishes throughout. And while it’s easy for the driver to get
comfortable, this is a car designed to make travel easy for
the whole family. So it’s light and spacious, comfortable
and clever – wherever you’re sitting.

real comfort
wherever you sit

T21073 Opel Zafira.indd 6T21073 Opel Zafira.indd 6 31/10/08 11:08:5931/10/08 11:08:59

7

T21073 Opel Zafira.indd 7T21073 Opel Zafira.indd 7 31/10/08 11:09:0331/10/08 11:09:03

This is what versatility looks like. And it’s all down to clever design –
Flex7® seating, adaptable luggage space and plenty of smart storage
ideas for all your essential travelling kit.

space for a quality lifestyle

T21073 Opel Zafira.indd 8T21073 Opel Zafira.indd 8 31/10/08 11:09:0731/10/08 11:09:07

9

T21073 Opel Zafira.indd 9T21073 Opel Zafira.indd 9 31/10/08 11:09:0931/10/08 11:09:09

Talk about personalised travel arrangements! The
optional Zafi ra panoramic roof gives you four tinted
glass roof panels – with separate, electrically-operated
sunblinds – and a fi ve-compartment, central overhead
console. So there’s always somewhere to put your
mobile phone, personal music player, sunglasses
or hand held games console.

a different look at life

T21073 Opel Zafira.indd 10T21073 Opel Zafira.indd 10 31/10/08 11:09:1131/10/08 11:09:11

11

T21073 Opel Zafira.indd 11T21073 Opel Zafira.indd 11 31/10/08 11:09:2031/10/08 11:09:20

T21073 Opel Zafira.indd 12T21073 Opel Zafira.indd 12 5/11/08 12:43:535/11/08 12:43:53

We all share a responsibility to look after our world. That’s why Opel has always been
at the forefront of green automotive initiatives. Most recently, we are looking at ways
to further reduce vehicle CO2 emissions and working on even cleaner, alternative power
sources, including zero-emission fuel cell technology.

But our commitment to preserving the environment goes even further. We have
dramatically reduced manufacturing emissions, for example, and our new vehicles
use more recycled materials and more recyclable parts than ever before. We also
offer free and easily accessible, environmentally friendly, end-of-life vehicle disposal.

That way, we reduce our environmental impact in every phase of every vehicle’s life cycle.
Because your world is our world, too.

respect
your world.

13

T21073 Opel Zafira.indd 13T21073 Opel Zafira.indd 13 5/11/08 12:43:575/11/08 12:43:57

Petrol engines. Zafira’s 115PS 1.6i 16v
and 140PS 1.8i 16v VVT engines use
Double Continuous Variable Cam
Phasing (DCVCP), to provide most
of the available torque across a wide
rev band. The result? More power and
lower fuel consumption. The 2.0i 16v
Turbo makes Zafira one of the only
compact MPVs with 200PS on tap. And
the all-aluminium, 150PS 2.2i 16v Direct
uses direct petrol injection for
outstanding fuel economy, flexibility
and refinement.

CDTi diesels. That’s ‘CD’ for common
rail diesel technology, ‘T’ for
turbocharged and ‘i’ for fuel injected.
Put them all together and you’ve got
the most up-to-date diesel technology
around. All Zafira engines are CDTi,
providing serious diesel performance
and economy and tough emissions
control. Choose from a 1.7CDTi 125PS
engine or two 1.9CDTi diesels – one
rated at 120PS, the other at 150PS.

Life is better on the move

Think Zafira. Think advanced engine and chassis technology. Four petrol engines and three common
rail turbo diesels – all brilliantly efficient with an impressive spread of power. And out on the road,
a reassuring sense of control, helping you feel relaxed and secure under any conditions.

T21073 Opel Zafira.indd 14T21073 Opel Zafira.indd 14 31/10/08 11:09:3531/10/08 11:09:35

15

Driving dynamics

Interactive Driving System (IDS-plus).

This optional system senses changes in
the vehicle dynamics and automatically
adjusts the damper rates – in real time.
The result is confident cornering and
sharper handling with reduced body
roll. Pretty smart for seven-seater
compact MPV. For further information
please see page 39.

Sport switch. Sports performance
to suit your mood. Hit the optional Sport
switch and you get a sharper throttle
and more responsive steering. With
optional IDS-plus you also get sportier
chassis dynamics with more body
control. It also controls the automatic
transmission’s Sport mode. For further
information please see page 39.

Easytronic transmission. Choose
the optional Easytronic transmission
and you’ll get a five-speed manual
gearbox with a fully automatic mode.
In manual mode, you simply push the
lever forward or back to shift gears
up or down. The facia display tells
you what gear you’re in – 1 to 5, N for
Neutral or A for Auto. Switch to fully
automatic mode and it has many of
the features of a regular automatic
including a kickdown function. There’s
no clutch pedal so you can drive it on
an automatic-only driving licence.

ESP-plus. Especially useful on
wet roundabouts and greasy roads or
whenever a slippery surface catches
you out, the optional Electronic Stability
Programme (ESP-plus), senses if the car
starts to slide on a bend and applies
corrective braking to the appropriate
wheels to help you regain control. For
further information please see page 38.

Six-speed. Zafira comes with
a six-speed manual gearbox as
standard on all 2.2i 16v, 1.7CDTi and

1.9CDTi 150PS engines. Others come
with a five-speed manual as standard,
with four- and six-speed automatic
and five-speed Easytronic transmission
options also available at extra cost.

Automatic transmission. The
electronically-controlled, six-speed
automatic has an adaptive driving
function and a Winter mode, which
selects third gear for standing starts in
slippery conditions. It’s available on both

1.9CDTi diesels. A four-speed automatic
is available on 2.2i 16v Direct models.

T21073 Opel Zafira.indd 15T21073 Opel Zafira.indd 15 31/10/08 11:09:3731/10/08 11:09:37

Adaptive Forward Lighting (AFL).

The optional lighting system swivels
the headlight beams up to 15 degrees
for improved vision as you turn a
corner. Above 105 km/h, it raises the
dipped headlight beam slightly, also
to increase safety – returning to
normal beam automatically as speed
is reduced. Turn to page 39 for more
detailed information.

Intelligent, reassuring safety and security

Zafira has a strong reputation for safety and security, and with good reason. Every model has a five star
EuroNCAP adult occupant safety rating, with six full-size airbags and a chassis that is packed with active
safety innovations that help you avoid accidents before they happen. Security features include remote
control central locking.

T21073 Opel Zafira.indd 16T21073 Opel Zafira.indd 16 31/10/08 11:09:3831/10/08 11:09:38

Adult occupant rating

17

Safety and security

Anti-lock Braking System (ABS). On its

own, ABS is a huge benefit in emergency
braking, but Zafira goes even further.
Emergency Brake Assist (EBA), Electronic
Brakeforce Distribution (EBD) and
Cornering Brake Control (CBC) all make
the car easier to control and stop under
extreme cornering and braking.

Six airbags. Zafira now protects
you and your family with six full-size
airbags as standard on every model.
Specially developed to provide
maximum protection, every model has
twin front airbags, enlarged ‘thorax­pelvis’ front seat side-impact airbags
and full-size curtain airbags too.

Remote control alarm system.

Standard on SRi and OPC, the
ultrasonic security alarm system
features forced entry detection, along
with tilt, movement and rear glass
breakage sensors, plus a power siren
complete with its own power supply.

ISOFIX Child Seat Restraint System.

The rigid ISOFIX anchoring mechanism
virtually eliminates the dangers of
incorrect child seat installation. You
simply click the accessory Opel ISOFIX
child seat into the mounting points
engineered into the Zafira outer rear
second-row seats.

T21073 Opel Zafira.indd 17T21073 Opel Zafira.indd 17 31/10/08 11:09:4131/10/08 11:09:41

Keeping everybody happy

Zafira’s Flex7® seating. It’s not just about quantity. It’s about quality too, making everyone feel comfortable
– front and rear. Wherever you’re sitting, you’ll be amazed at what Zafira has to offer, whether it’s features
like air conditioning and rear seat audio or clever storage space for all your bits and bobs.

Versatile load space.

When you’re not using Zafira’s third
row seats, there’s no need to remove
them completely. Each one folds down
separately, flush with the load floor. Add
the optional FlexOrganiser

®

Pack, and
you’ve got the smartest, most versatile
way to manage your load area ever!

T21073 Opel Zafira.indd 18T21073 Opel Zafira.indd 18 31/10/08 11:09:4331/10/08 11:09:43

19

Interior features

Multi-function trip computer. Standard

on all models (except Life), this
invaluable driver information system
provides instantaneous and average
fuel consumption, fuel consumed,
average speed, distance travelled and
range based on fuel remaining.

Cruise control. The easy-to-use,
tap-up/tap-down cruise control allows
you to maintain a steady speed without
keeping your foot on the throttle. So
it’s more comfortable on long journeys
and easier to keep to speed limits too.
Standard on Elite and optional on most
other models, cruise control is also
included in the Technical Pack.

*Please contac t your local Opel deal er for
further information.

Mobile phone system with

Bluetooth

®

*. With the optional mobile

phone system, your phone interfaces
with the audio unit, for operation via
the steering wheel controls and facia
display. Bluetooth

®

wireless technology
with voice activation is included.
Bluetooth

®

is also available as part

of the Technical Pack.

Quality sounds. Every Zafira features
a quality stereo radio/CD player, with
steering wheel mounted audio controls
on many models. Optional systems add
MP3/CD format, user-friendly satellite
navigation with colour display, and
our independent rear seat Twin Audio

®

system, where the front and two second­row rear passengers can listen to the
radio or a CD independently and at the
same time. It comes with separate
second-row rear seat audio controls –
an on/off switch, independent volume
controls for each headset, switching
between CD and radio tuner and a scan
function. And it even mutes the rear
speakers when the headphones are in
use. Accessory headphone sets and
alternative earhook headphones are
also available.

Air conditioning. It makes for a fresher
interior atmosphere all year round,
with chilled air on hot days and faster
demisting when it’s damp. Move up
to Electronic Climate Control (ECC),
standard on Elite and optional on most
other models and you can maintain
the interior temperature to within a
single degree.

Satellite navigation. You’ll never get
lost with optional satellite navigation.
It can determine your precise location
and guide you to your destination by
the best and fastest route.

T21073 Opel Zafira.indd 19T21073 Opel Zafira.indd 19 31/10/08 11:09:4531/10/08 11:09:45

20

Life

LIFE

Standard features include:

•

Anti-lock braking system

•

Power-assisted steering

•

Twin front airbags

•

Front seat side-impact airbags

•

Full-size curtain airbags

•

Driver’s seat height adjuster

•

Electric door mirrors

•

Electric front windows

•

Remote control central locking

•

Steering wheel adjustable
for reach and rake

•

Air conditioning*

•

CD player/stereo radio (CD 30)

•

12-volt auxiliary power socket
located in luggage compartment

•

Black roof rails

Engine availability

1.6i 16v VVT

1.8i 16v VVT

1.8i 16v VVT Easytronic

1.7CDTi 16v (125PS)

1.9CDTi (120PS) Automatic

*Non-air con ditioned 1.6i 16v model also avail able.

T21073 Opel Zafira.indd 20T21073 Opel Zafira.indd 20 31/10/08 11:09:4631/10/08 11:09:46

21

Club

CLUB

Standard features include:

•

Anti-lock braking system

•

Twin front airbags

•

Front seat side-impact airbags

•

Full-size curtain airbags

•

Driver’s seat height adjuster

•

Electric front windows

•

Remote control central locking

•

Steering wheel adjustable
for reach and rake

•

Air conditioning*

Additional features over and
above Life model include:

•

16-inch five-spoke Structure wheels

•

Front passenger’s seat undertray

•

Steering wheel mounted audio controls

•

Electrically adjustable/
heated door mirrors

•

Body-colour bumper inserts, door
handles and side-protection mouldings

•

Leather-covered three-spoke
steering wheel

•

Multi-function trip computer

•

CD player with MP3 format/auxiliary­in socket/stereo radio (CD 30 MP3)

•

Dark-tinted glass (excludes
windscreen and front door windows)

•

Alloy-effect roof rails

Model illustrated features two-coat metallic paint,
optional at e xtra cost.

Engine availability

1.6i 16v VVT

1.8i 16v VVT

2.2i 16v Direct Automatic

1.7CDTi 16v (125PS)

1.9CDTi (120PS) Automatic

*Non-air con ditioned 1.6i 16v model is also avai lable.

T21073 Opel Zafira.indd 21T21073 Opel Zafira.indd 21 5/11/08 12:43:595/11/08 12:43:59

22

Design

DESIGN

Standard features include:

•

Anti-lock braking system

•

Twin front airbags

•

Front seat side-impact airbags

•

Full-size curtain airbags

•

Electric front windows

•

Remote control central locking

•

Steering wheel adjustable
for reach and rake

•

Air conditioning

•

CD player/stereo radio (CD 30)

•

Dark-tinted glass (excludes
windscreen and front door windows)

•

Multi-function trip computer

•

Leather-covered three-spoke
steering wheel

Additional features over and
above Club model include:

•

Silver Alpha cloth seat trim with
Morrocana-trim side bolsters

•

16-inch seven twin-spoke alloy wheels

•

Front fog lights

•

Electric rear windows

•

Driver’s armrest

•

Driver’s seat with tilt
and lumbar adjustment

•

Rain-sensitive windscreen wipers

•

Alloy-effect roof rails

•

Automatic Lighting Control

Additional features on 2.2i 16v Direct
and 1.9CDTi 16v (150PS) models:

•

17-inch 10-spoke alloy wheels with
225/45 R 17 ultra-low profile tyres

•

Electronic Stability Programme-plus
(ESP-plus) with traction control

•

Sports suspension

•

Sport switch

Model illu strated feature s Panoramic Roof Pack (a bove),
automatic transmission (left) and two-coat metallic
paint, all opti onal at extra cost.

Engine availability

1.6i 16v VVT

1.8i 16v VVT

1.8i 16v VVT Easytronic

2.2i 16v Direct

2.2i 16v Direct Automatic

1.7CDTi 16v (125PS)

1.9CDTi (120PS) Automatic

1.9CDTi 16v (150PS)

1.9CDTi 16v (150PS) Automatic

T21073 Opel Zafira.indd 22T21073 Opel Zafira.indd 22 31/10/08 11:09:4931/10/08 11:09:49

23

Elite

ELITE

Standard features include:

•

Anti-lock braking system

•

Six airbags

•

Electric front and rear windows

•

Dark-tinted rear glass

•

Multi-function trip computer

•

Driver’s armrest

•

Leather-covered three-spoke
steering wheel

•

Rain-sensitive windscreen wipers

•

Alloy-effect roof rails

Additional features over and
above Design model include:

•

Leather seat facings

•

Electrically heated sports front seats
with tilt and lumbar adjustment

•

Electronic climate control

•

Cruise control

•

CD player with MP3 format/auxiliary-in
socket/stereo radio (CD 30 MP3)

Additional features on 2.2i 16v Direct
and 1.9CDTi 16v (150PS) models:

•

17-inch 10-spoke alloy wheels with
225/45 R 17 ultra-low profile tyres

•

Electronic Stability Programme-plus
(ESP-plus) with traction control

•

Sports suspension

•

Sport switch

2.2i 16v Direct mod el illustrated fea tures automatic
transmission (right) and two-coat metallic paint (above),
optional at e xtra cost.

Engine availability

1.6i 16v VVT

1.8i 16v VVT

1.8i 16v VVT Easytronic

2.2i 16v Direct

2.2i 16v Direct Automatic

1.7CDTi 16v (125PS)

1.9CDTi (120PS) Automatic

1.9CDTi 16v (150PS)

1.9CDTi 16v (150PS) Automatic

T21073 Opel Zafira.indd 23T21073 Opel Zafira.indd 23 31/10/08 11:09:5031/10/08 11:09:50

24

SRi

T21073 Opel Zafira.indd 24T21073 Opel Zafira.indd 24 31/10/08 11:09:5131/10/08 11:09:51

25

SRi

SRi

Standard features include:

•

Anti-lock braking system

•

Twin front airbags

•

Front seat side-impact airbags

•

Full-size curtain airbags

•

Electric front windows

•

Remote control central deadlocking

•

Steering wheel adjustable
for reach and rake

•

Air conditioning

•

Dark-tinted glass (excludes
windscreen and front door windows)

•

Multi-function trip computer

Additional features over and
above Club model include:

•

17-inch five-spoke alloy wheels

•

Remote control ultrasonic
security alarm

•

Electronic Stability Programme
(ESP-plus) with traction control

•

Sports suspension

•

Sport switch

•

Electric rear windows

•

Matt chrome-effect centre console

•

Front fog lights

•

Sports front seats with driver’s armrest

•

Driver’s seat with tilt and
lumbar adjustment

•

Leather-covered three-spoke
sports steering wheel

•

Rear roof spoiler

•

Sunglasses holder

•

Chrome exhaust tailpipe
(2.0i 16v Turbo models only)

Model illu strated (above) fe atures two-co at pearlescent
paint optio nal at extra cost.

Model illu strated (left) feat ures two-coat pe arlescent
paint, OPC Line O ne Styling Pack and 18-inc h five­spoke alloy whe els, optional at ext ra cost. (Zafira SRi

2.0i 16v Turbo model illus trated.)

Engine availability

1.8i 16v VVT

2.0i 16v Turbo

1.9CDTi 16v (150PS)

1.9CDTi 16v (150PS) Automatic

Satellite navigation system/CD
player with MP3 format/auxiliary-in
socket/stereo radio/colour graphic
information display (CD 70)*.

*Optional at e xtra cost.

Please note : Chrome exhaust tail pipe illustrated o n both
models is st andard on 2.0i 16v Turbo models only.

T21073 Opel Zafira.indd 25T21073 Opel Zafira.indd 25 31/10/08 11:09:5231/10/08 11:09:52

Opel accessories are the right choice for your Zafira. Whatever you’re into, there’s certain
to be an Opel accessory with your name on it, all fitted by trained Opel professionals.
You can also choose styling products from the OPC range as well as auto design specialist
Irmscher International. We’ve only featured a small selection of what’s available here but
just ask your Opel dealer for more details.

Inspired by Opel’s racing heritage,
Opel OPC styling products come with
all the same experience, knowledge,
and passion for style and performance.
They put the accent firmly on quality
and exclusivity, with a winning edge.
And they add flair, personality and
excitement to every Zafira model.
OPC styling products are available as
factory-fit option packs or accessories
fitted by your Opel dealer.

Styling

Accessories

OPC Line One Styling Pack.

Breathe some extra style into your Zafira
with a front lower spoiler, side sills, rear
roof spoiler* (above) and rear lower
skirt. These items are also available
separately as retailer-fit accessories.

*Standard on SRi.

26

T21073 Opel Zafira.indd 26T21073 Opel Zafira.indd 26 31/10/08 11:09:5331/10/08 11:09:53

27

Accessories

Tow bar. Both fixed (shown) and

detachable tow bars are available, with
12N electrics, or 12N/12S t win electrics
which also provide supplementary
power for use in the caravan or trailer.
Fitted by your Opel dealer, all Opel
tow bars conform to top European
regulations and standards.

**The space divi der grid can only be use d in conjunction
with the dog g uard. N.B. Dog guard r equires fittin g kit
(dealer-fit on ly) if vehicle is not equipp ed with the
optional factory-fit vertical load restraining net.

†

Only availab le if vehicle is equipp ed with an REC unit.

Please consu lt your Opel dealer for f urther informat ion.

Rear parking distance sensors.†

Activated automatically as you
select reverse, this clever system
beeps faster the closer you get to
an obstruction, changing to a
continuous tone at 300mm away.

Developed in conjunction with auto design specialists Irmscher International,
Zafira styling accessories perfectly complement the vehicle’s lines, as well
as being manufactured to the same exacting standards as the car itself.
For availability details please ask your Opel dealer.

Styling

FURTHER ACCESSORIES
AVAILABLE INCLUDE:

•

Alarm system

•

Velour floor mats

•

Cargo liner

•

Mudflaps

•

Dog guard with space divider grid**

•

Electrically-chilled 12-litre cool bag

•

Base carrier

•

Alloy ski carrier

•

Tow bar

•

Anti-slip mat

•

Portable satellite navigation system

•

Steering wheel security bar

Irmscher sports silencers.

For distinctive looks (with chrome­plated tailpipes) and a sportier exhaust
note, these split oval design tailpipes
are the perfect choice for your Zafira.

Cross hatch grille. Being different is
easy with the cross hatch front grille from
Irmscher. Featuring an aluminium upper
strip with a laser-etched ‘Irmscher’ logo
it adds style and individuality.

Irmscher alloy wheels. They’re the
perfect way to personalise your Zafira.
With a huge range to choose from
(style illustrated is Stila), and sizes from
16 to 19 inches, you’re sure to find one
to suit your style and budget. And don’t
forget to ask about our accessory wheel
locking kits too.

Child seats. Ergonomically styled for
comfort and safety, Opel’s Baby-Safe
(birth to 13kg), and Kid (15-36kg) seats
are fixed with a standard lap and
diagonal seatbelt, while the Duo ISOFIX
(9-18kg) can also be attached using the
ISOFIX child seat restraint fittings, which
are standard on the outer second-row
seats of all Zafira models.

T21073 Opel Zafira.indd 27T21073 Opel Zafira.indd 27 31/10/08 11:09:5531/10/08 11:09:55

ZAFIRA OPC

Engine

2.0i 16v ECOTEC-4 Turbo (1998cc)
Maximum power: 240PS (176kW)
@ 5600rpm
Maximum torque: 320Nm (236 lb.ft.)
@ 2400-5000rpm

Transmission

> Six-speed manual gearbox

Performance (manufacturer’s figures)
> Maximum speed: 231km/h
> Acceleration 0-100km/h: 7.8secs

Chassis, suspension and brakes

> Lowered and uprated OPC sports

suspension
> Electronic Stability Programme (ESP)
> Interactive Driving System2-plus

(IDS2-plus) with Continuous Damping

Control (CDC)
> Front ventilated disc brakes: 321mm

diameter
> Rear disc brakes: 278mm diameter
> Front and rear brake calipers in blue

Wheels and tyres

> 18-inch six-spoke alloy wheels with

225/40 R 18 ultra-low profile tyres
> 19-inch multi-spoke alloy wheels with

anthracite inner and 235/35 R 19 ultra-

low profile tyres optional at extra cost

OPC exterior features include

> OPC honeycomb spor ts front grille and

air dam/bumper
> OPC front fog lights
> OPC side sills and rear bumper
> OPC dual branch chrome trapezoidal

exhaust tailpipes – tuned for

sound optimisation
> OPC rear roof spoiler

OPC interior features include

> Recaro sports front seats with leather-

trimmed side bolsters
> Driver’s and front passenger’s front and

side-impact airbags
> Curtain airbags for front and second-

row seating
> Three-spoke leather-covered sports

steering wheel with OPC logo
> Unique OPC instrument panel

with stepper motor speedometer

and tachometer
> Unique OPC gear knob and floor mats
> Active-safety front seat head restraints
> Air conditioning
> CD player with MP3 format/auxiliary-in

socket/stereo radio (CD 30 MP3)
> OPC matt chrome-effect inserts on facia

and doors
> Trip computer
> Keyless entry and start
> OPC alloy-effect door sill covers
> Remote control ultrasonic security

alarm system

DISCOVER

7. 8 SEC

0-100KM/H

Having a family didn’t stop you having a life. You still ride, play, ski
or whatever it is that sets you free. And you still want to drive, not just
travel. What you need is a seven-seat performance car. Cue Zafira
OPC. Same compact MPV format. But a whole new shape. And a
whole new attitude. No other MPV looks this good. And no surprise,
this is one of the quickest production MPVs ever made. Enough said?

T21073 Opel Zafira.indd 28T21073 Opel Zafira.indd 28 4/11/08 13:58:384/11/08 13:58:38

Excuses. A word that doesn’t figure in the Zafira OPC vocabulary. Make no mistake, this OPC features all the innovation
you’ve come to expect from a Zafira with added attitude. Like serious style, a six-speed gearbox, 18-inch alloy wheels
and lowered sports suspension. Then there’s that 2.0i 16v turbocharged engine. The same 240PS, 320Nm unit that you’ll
find in Astra OPC, Opel’s hottest ever hot hatch. The Zafira OPC. Expect no excuses.

29

T21073 Opel Zafira.indd 29T21073 Opel Zafira.indd 29 3/11/08 13:46:133/11/08 13:46:13

Black Sapphire – pearlescent*

Metro Blue – metallic*

Power Red – solid

Panacotta – pearlescent*

Silver Lightning – metallic*

Star Silver – metallic*

Green Spirit – metallic*

Technical Grey – metallic*

Arden Blue

†

– pearlescent*

Royal Blue – solid

Ultra Blue – pearlescent*

30

Colours and trims

Zafira comes in eleven different exterior colours. And each one suits the car
beautifully. Every trim combination – cloth or leather – has been carefully
selected to complement whatever colour you choose.

Due to the lim itations of the print ing process the
colours rep roduced may vary sli ghtly from the
actual p aint colour or trim mate rial. As a result
they should b e used as a guide only.

Your Opel deale r has a comprehensive d isplay of all
our paint sam ples and trim swatche s.

*Optional at e xtra cost.
†Available on OPC mode ls only.

T21073 Opel Zafira.indd 30T21073 Opel Zafira.indd 30 31/10/08 11:10:0531/10/08 11:10:05

31

Colours and trims

Alpha cloth – Charcoal
LIFE

Tabita cloth – Charcoal
CLUB

Leather – Charcoal
ELITE / SRi*

Race cloth/Leather – Charcoal
OPC

Leather – Charcoal
OPC*

Silver Alpha cloth – Charcoal
SRi

Silver Alpha cloth/
Morrocana – Charcoal
DESIGN

T21073 Opel Zafira.indd 31T21073 Opel Zafira.indd 31 31/10/08 16:21:1231/10/08 16:21:12

Technical dataTechnical data

High-performance petrol engines.

240PS

2.0i 16v turbo –
one of the most
powerful petrol
engines in its class

Engines

1.6i 16v VVT 1.8i 16v VVT 2.2i 16v Direct 2.0i 16v Turbo
ECOTEC-4 ECOTEC-4 ECOTEC-4 aluminium (200PS) ECOTEC-4

Capacity 1598cc 1796cc 2198cc 1998cc
Maximum power* 115PS (85kW) 140PS (103kW) 150PS (110kW) 200PS (147kW)

@ 6000rpm @ 6300rpm @ 5600rpm @ 5400rpm
Maximum torque 155Nm (114 lb.ft.) 175Nm (129 lb.ft.) 215Nm (159 lb.ft.) 262Nm (193 lb.ft.)

@ 4000rpm @ 3800rpm @ 4000rpm @ 4200rpm
Confi guration 4 cylinders, 4 valves per cylinder, double overhead camshafts
Fuel/induction system

Naturally aspirated Naturally aspirated

Water-cooled

Variable Valve Variable Valve

turbocharger

Timing (VVT). Timing (VVT).

Naturally

with air-cooled

Multi-point Multi-point

aspirated.

intercooler.

sequential fuel sequential fuel

Direct fuel

Multi-point

injection injection

injection

sequential

fuel injection
Service intervals 30,000km or 1 year (whichever occurs sooner)

2.0i 16v Turbo 1.7CDTi 16v (125PS) 1.9CDTi (120PS) 1.9CDTi 16v (150PS)

(240PS) ECOTEC-4 ECOTEC-4 ECOTEC-4 ECOTEC-4
Turbo diesel Turbo diesel Turbo diesel

Capacity 1998cc 1686cc 1910cc 1910cc
Maximum power* 240PS (176kW) 125PS (92kW) 120PS (88kW) 150PS (110kW)

@ 5600rpm @ 4000rpm @ 3500rpm @ 4000rpm
Maximum torque 320Nm (236 lb.ft.) 280Nm (206 lb.ft.) 280Nm (206 lb.ft.) 320Nm (236 lb.ft.)

@ 2400-5000rpm @ 2300rpm @ 2000-2750rpm @ 2000rpm
Confi guration 4 cylinders, 4 valves 4 cylinders, 4 valves 4 cylinders, 2 valves 4 cylinders, 4 valves
per cylinder. per cylinder. per cylinder. per cylinder.
Double overhead Double overhead Single overhead Double overhead
camshafts camshaft camshafts camshafts
Fuel/induction system Uprated water-cooled Variable geometry Variable geometry Variable geometry
turbocharger with turbocharger with turbocharger with turbocharger with
air-cooled intercooler. intercooler. intercooler. intercooler.
Multi-point sequential Common rail Common rail Common rail
fuel injection fuel injection fuel injection fuel injection
Service intervals 30,000km or 1 year (whichever occurs sooner)

* = To calculate BHP divide the PS fi gure by 1.0136.

32

T21073 Opel Zafira Spec.indd 32T21073 Opel Zafira Spec.indd 32 31/10/08 10:26:3231/10/08 10:26:32

Technical dataTechnical data

Smarter driving tips

• Drive at an appropriate speed: –
Staying within the speed limit increases
driver safety, reduces CO

2

emissions
and saves fuel. At 115km/h you could
be using up to 9% more fuel than at
100km/h and up to 15% more fuel than
at 80km/h

• Drive smoothly at all times: – Anticipate
the ebb and fl ow of the traffi c to avoid
harsh acceleration and braking

• Reduce your revs: – Change gear earlier
to help reduce fuel consumption – try
2500rpm with petrol engines and
2000rpm with diesel

• Idling is wasting fuel: – If you’re likely
to be at a standstill for more than
three minutes, switch off the engine
to save fuel

• Regularly check your tyre pressures:
– Under infl ated tyres increase CO

2

emissions whilst over infl ated tyres
can be unsafe. Always check your
handbook for the correct tyre pressure.
This will also help to increase the life of
your tyres

• Remove unnecessary items from the
car: – Extra weight increases the
engine’s workload which in turn burns
more fuel and increases CO

2

emissions

Performance*, fuel economy and emissions

Performance Fuel economy litres/100km (mpg)
Maximum Acceleration Extra- CO

2

speed (secs) Urban urban Combined emissions
Model km/h (mph) 0-100km/h driving driving fi gure (g/km)

Manual 5-speed

1.6i 16v VVT 185 (115) 13.5 9.3 (30.4) 5.8 (48.7) 7.1 (39.8) 169
1

.8i 16v VVT 197 (122) 11.5 9.9 (28.5) 6.0 (47.1) 7.4 (38.2) 177

Manual 6-speed

2.2i 16v Direct 200 (124) 10.6 11.3 (25.0) 6.4 (44.1) 8.2 (34.4) 197

2.0i 1

6v Turbo (200PS) 225 (140) 9.0 13.3 (21.2) 7.3 (38.7) 9.5 (29.7) 228

2.0i 16v Turbo (240PS) 231 (144) 7.8 13.4 (21.1) 7.4 (38.2) 9.6 (29.4) 230

1.7CDTi 16v (125PS) 189 (117) 12.3 7.1 (39.8) 4.9 (57.6) 5.7 (49.6) 152

1.9CDTi 16v (150PS) 204 (127) 10.3 7.6 (37.2) 5.1 (55.4) 6.0 (47.1) 159

Easytronic 5-speed

1.8i 16v VVT 197 (122) 12.9 9.7 (29.1) 5.8 (48.7) 7.2 (39.2) 172

Automatic 4-speed

2.2i 16v Direct 190 (118) 11.6 11.6 (24.4) 6.7 (42.2) 8.5 (33.2) 204

Automatic 6-speed

1.9CDTi (120PS) 182 (113) 12.5 9.8 (28.8) 5.7 (49.6) 7.2 (39.2) 194
1

.9CDTi 16v (150PS) 198 (123) 10.7 9.8 (28.8) 5.7 (49.6) 7.2 (39.2) 194

The fuel consumption fi gures shown comply with EC directive 1999/100 to provide a realistic indication of fuel consumption by taking into account everyday driving conditions,
such as cold starts, acceleration and braking. These fi gures take account of the vehicles kerbweight, ascertained in accordance with the above regulation. Important: the results
given relate to the particular car tested. Driving style, road and traffi c conditions, vehicle mileage and standard of maintenance may also affect fuel consumption; therefore the
results do not express or imply any guarantee of fuel consumption attainable. * = Manufacturer’s fi gures.

33

T21073 Opel Zafira Spec.indd 33T21073 Opel Zafira Spec.indd 33 31/10/08 10:26:3331/10/08 10:26:33

Technical data

Six-speed automatic transmission.

MacPherson strut front suspension.

6-SPEED

Six-speed manual
and automatic
transmissions
available

Optional transmissions

Five-speed Easytronic transmission
– 1.8i VVT 16v models: Easytronic is a

fi ve-speed manual gearbox with a fully
automatic mode. In manual mode you
simply push the lever forward or back to
shift gears up or down, while the facia
display tells you what gear you’re in.
Switch to fully automatic mode and
you’ll have many of the features of a
regular automatic, including kickdown.
Since there’s no clutch pedal, Easytronic
is ideal for effortless town driving.

Four-speed automatic transmission
– 2.2i 16v Direct models: Electronically

controlled with an adaptive driving
programme, which tailors its gear
changes to match your driving
conditions. There is also a winter mode,
which selects a higher than normal gear
to reduce the possibility of wheelspin in
icy conditions.

Six-speed automatic transmission
with Active Select function – 1.9CDTi
(120/150PS) models: The electronically

controlled adaptive driving programme
can tailor gear changes to match your
driving conditions, while the winter
mode selects a higher than normal gear
to reduce the possibility of wheelspin
in icy conditions. The Active Select
manual mode allows the gear lever to
be used like a manual gearbox – you
simply push the lever forward or back to
change up or down the gears.

Anti-corrosion warranty

●

12-year body panel anti-perforation

warranty

Brakes

●

Anti-lock Braking System (ABS)

●

Dual circuit, diagonally split braking
system

1.6i 16v VVT/1.8i 16v VVT

Front ventilated discs: 280mm diameter
Rear discs: 264mm diameter

2.2i 16v Direct/ 2.0i 16v Turbo (200PS)

Front ventilated discs: 308mm diameter
Rear discs: 264mm diameter

1.7CDTi 16v (125PS)/1.9CDTi (120/150PS)

Front ventilated discs: 308mm diameter
Rear discs: 264mm diameter

2.0i 16v Turbo (240PS)

Front ventilated discs: 321mm diameter
Rear discs: 278mm diameter

Wheels and tyres

Life – 16-inch steel wheels with 205/55

R 16 tyres.
Club – 16-inch Structure wheels with
205/55 R 16 tyres.
Design/Elite – 16-inch seven twin-spoke
alloy wheels with 205/55 R 16 tyres
(1.6i 16v/1.8i 16v VVT/1.7CDTi 16v
(125PS)/1.9CDTi (120PS) models).
17-inch 10-spoke alloy wheels
with 225/45 R 17 tyres (2.2i 16v
Direct/1.9CDTi 16v (150PS) models).
SRi – 17-inch fi ve-spoke alloy wheels
with 225/45 R 17 tyres.
OPC – 18-inch six-spoke alloy wheels
with 225/40 R 18 tyres.

●

Emergency tyre infl ation kit included

in lieu of spare wheel

Fuel tank capacity

●

All models – 58 litres (12.8 gallons)

Steering

●

Electro-hydraulic power-assisted

steering

●

Turning circle (kerb-to-kerb):

All models – 11.10m (36.4ft.)

Suspension

Front: Independent. Lightweight

MacPherson struts with gas-pressure
dampers and coil springs. Anti-roll
bar. Hydro-formed subframe offers
increased lateral stiffness. Hydraulic
control arm bushing gives improved
insulation from road noise.

●

Design/Elite 2.2i 16v Direct/1.9CDTi 16v
(150PS) and all SRi models – uprated
springs and dampers

●

SRi – Interactive Driving System with
Continuous Damping Control, optional
at extra cost – see

D4

on page 39

●

OPC – Interactive Driving System2-plus
(IDS

2

-plus) with Continuous Damping

Control (CDC) – see

D4

on page 39
Rear: Lightweight torsion beam rear
axle with one-piece, hollow cast trailing
arms. Built-in anti-roll bar. Progressive­rate double conical mini-block springs
and gas-pressure dampers.

●

Design/Elite 2.2i 16v Direct/1.9CDTi 16v
(150PS) and all SRi models – uprated
springs and dampers

●

SRi – Interactive Driving System with
Continuous Damping Control, optional
at extra cost – see

D4

on page 39

●

OPC – Interactive Driving System2-plus
(IDS

2

-plus) with Continuous Damping

Control (CDC) – see

D4

on page 39

Body

●

Aerodynamic drag co-effi cient: Cd 0.31

34

T21073 Opel Zafira Spec.indd 34T21073 Opel Zafira Spec.indd 34 31/10/08 10:26:3331/10/08 10:26:33

Technical data

150 0kg

Maximum
towing weight

652kg

Maximum
carrying capacity

Weights and towing data kg

Kerbweight (Gross vehicle weight) Max. towing weights

Trailer with brakes (without brakes)

1.6i 16v VVT Life 1445 (2090) 1000 (750)

1.6i 16v VVT Club 1455 (2090) 1000 (750)

1.6i 16v VVT Design/Elite 1468 (2090) 1000 (750)

1.8i 16v VVT Life (inc. Easy tronic) 1443 (2095) 1200* (750)

1.8i 16v VVT Club 1453 (2095) 1200* (750)

1.8i 16v VVT Design/Elite (inc. Easy tronic) 1468 (2095) 1200* (750)

1.8i 16v VVT SRi 1463 (2095) 1200 (750)

2.2i 16v Direct Club automatic 1537 (2175) 1500 (750)

2.2i 16v Direct Design/Elite 1526 (2150) 1500 (750)

2.2i 16v Direct Design/Elite automatic 1551 (2175) 1500 (750)

2.0i 16v Turbo (200PS) SRi 1548 (2175) 1500 (750)

2.0i 16v Turbo (240PS) OPC 1590 (2200) 1500 (750)

1.7CDTi 16v (125PS) Life 1540 (2175) 1400 (750)

1.7CDTi 16v (125PS) Club 1545 (2175) 1400 (750)

1.7CDTi 16v (125PS) Design/Elite 1556 (2175) 1400 (750)

1.9CDTi (120PS) Life automatic 1583 (2225) 1400 (750)

1.9CDTi (120PS) Club automatic 1588 (2225) 1400 (750)

1.9CDTi (120PS) Design/Elite automatic 1599 (2225) 1400 (750)

1.9CDTi 16v (150PS) Design/Elite 1569 (2205) 1500 (750)

1.9CDTi 16v (150PS) Design/Elite automatic 1599 (2235) 1500 (750)

1.9CDTi 16v (150PS) SRi 1566 (2205) 1500 (750)

1.9CDTi 16v (150PS) SRi automatic 1596 (2235) 1500 (750)

* = On models fi tted with the optional Easytronic transmission the maximum towing weight for a trailer with brakes is 1300kg.
Gross vehicle weight is the total permissible weight of the vehicle including passengers and their luggage. To determine total carrying capacity, deduct kerbweight from gross

vehicle weight. The maximum roof rack loading should not exceed 75kg. The maximum towing weights are based on the ability of the car, with two occupants of 75kg each,
to restart on a 12% gradient, which is approximately 1 in 8.3, at sea level. At altitudes above 1500 metres, the engine output may drop with a corresponding reduction in towing
capability. Any extra weight, such as luggage or additional passengers, should be deducted from the maximum towing weight. With a trailer fully loaded, maximum noseweight
should not exceed 75kg. Always fi t Opel towing attachments and accessories available from your Opel dealer. They are designed specifi cally for Opel models and carry a 24-month
guarantee.

35

T21073 Opel Zafira Spec.indd 35T21073 Opel Zafira Spec.indd 35 31/10/08 10:26:3431/10/08 10:26:34

Technical data

1645

(64.7)
including
roof rails

1670

(65.7)

including

Panoramic

roof

844**

(33.2)

920*
(36.2)

1781 (70.1)

excluding door mirrors

2026 (79.8)

including door mirrors

2703

(106.4)
4467

†

(175.8)

1820 litres

Maximum
luggage capacity

* = OPC front overhang 945mm (37.2 inches). ** = OPC rear overhang 855mm (33.7 inches). † = OPC overall length 4503mm (177.3 inches).

Exterior dimensions millimetres (inches)

Luggage capacities (measured using the ECIE method)

litres cu.ft

Behind third-row, to glass line 140 4.9
Behind second-row, to glass line 645 22.8
Behind front seats, to glass line 1070 37.8
Behind front seats, to roof 1820 64.3

Loadspace dimensions

mm inches

Maximum fl oor length – behind front seats,
second-row seat back lowered

1809 71.2

Maximum fl oor length – behind front seats,
second-row seat folded and stowed

1525 60.0

Maximum fl oor length – behind second-row seat 1088 42.8
Maximum fl oor length – behind third-row seat 405 15.9
Maximum fl oor width 1114 43.9
Width between wheel arches 1071 42.2
Tailgate aperture height 893 35.2
Tailgate aperture width 1136 44.7

36

T21073 Opel Zafira Spec.indd 36T21073 Opel Zafira Spec.indd 36 31/10/08 10:26:3431/10/08 10:26:34

Technical data

A. Second-row seat backs can be

folded individually if required.

B. All seven seats in use.
C. Second-row seats folded and

stowed.

D. Third-row seats stow in fl oor,

creating a fl at luggage area.

D

A

C

B

Flex7® seat confi gurations

37

T21073 Opel Zafira Spec.indd 37T21073 Opel Zafira Spec.indd 37 31/10/08 10:26:3431/10/08 10:26:34

Technical data

Hill Start Assist
D1. Hill Start Assist maintains the brake pressure for up to 1.5 seconds after the

brake pedal has been released when pulling away on a gradient of 5% or more;
this helps prevent the vehicle from rolling back should the driver release the brake
pedal before fi rst applying the handbrake. The pressure is released as soon as the
driver presses the accelerator and the car begins to move forward.

Electronic Stability Programme-plus (ESP-plus)
D2. ESP-plus provides enhanced yaw compensation during understeer or oversteer.

It works by monitoring the front and rear of the car and comparing their respective
directions of travel with the input through the steering wheel. If the vehicle star ts
to slide, ESP-plus applies corrective braking to the appropriate wheel, or wheels,
compensating for the slide and helping you regain control more rapidly. ESP-plus
offers additional safety in the form of two-way traction control, which helps prevent
the driving wheels from spinning, under acceleration, on slippery surfaces.

Keyless entry and start
D3. Available as an option, the keyless entry and start system means that the driver

need never remove their key fob from their pocket. When approaching the car,
sensors in the front door handles and rear bumper

1

detect the driver’s proximity

and automatically unlock the doors or boot when the handle is pulled.

When in the car, two internal sensors

2

activate the ignition and release the
electronic steering lock, enabling the driver to start or stop the engine by pressing
the dashboard-mounted Start/Stop button. As an added safety feature, the engine
will only start if the driver presses the foot brake while pushing the Start/Stop button.

Upon leaving the vehicle, the driver can lock it by either pressing a button on the
key fob like a conventional system, or by simply touching one of the sensors on the
external handles of the front doors.

Additionally the system offers excellent theft protection by its use of sophisticated
cryptographic algorithms, while a back-up key is also included for emergency use.

D1

D3

D2

Features explained

1 2

38

T21073 Opel Zafira Spec.indd 38T21073 Opel Zafira Spec.indd 38 31/10/08 10:26:3431/10/08 10:26:34

Technical data

IDS-plus with Continuous Damping Control (CDC)
D4. The Interactive Driving System (IDS-plus) chassis – available on SRi models –

offers the Zafi ra driver an even more sporting driving experience, thanks mainly
to the electronic control of the suspension. Pressing the Sport switch activates the
CDC function – CDC monitors the roll, pitch and yaw of the car, and changes the
rate of damping on each wheel to optimise the handling, selectively stiffening the
suspension. This means the vehicle will exhibit a reduced rate of roll and pitch,
making it more responsive during direction changes and more settled during the
braking/turn-in/acceleration transition when cornering.

Zafi ra OPC models are fi tted with a revised version of IDS-plus, called IDS

2

-plus, as
standard. Specifi cally developed for OPC models, IDS2-plus offers an even greater
level of control for enthusiastic drivers by continuously adjusting the performance of
the suspension.

Sport switch
D5. The Sport switch, standard on Design/Elite 2.2i 16v Direct/1.9CDTi 16v (150PS)

and all SRi and OPC models, improves the responses of both the steering and
throttle, giving the driver sharper initial throttle response and crisper turn-in when
cornering. On vehicles fi tted with automatic transmission, the Sport switch also
controls the transmission Sport mode.

Bi-xenon Adaptive Forward Lighting (AFL)

Adaptive Forward Lighting is a sophisticated new lighting system that allows
drivers to see around corners. AFL utilises powerful bi-xenon headlights – which
offer up to three times more light output than conventional halogen headlights
– to enable the full benefi t of the system’s advantages to be appreciated. While
standard xenon headlights provide only dipped beam lighting (main beam
illumination still uses conventional halogen lights), bi-xenon units provide both
dipped and main beam from a single lighting unit. The package is completed
by high-pressure headlight washers and dynamic beam levelling.

Curve light
D6. Controlled by a combination of steering wheel movement and sensors for the

vehicle’s speed and yaw angle, the Curve light function allows the headlight beam
to move up to 15 degrees left or right of the straight ahead position. This ensures
the light is always following the trajectory plotted by the front wheels, rather than
simply pointing straight ahead.

Motorway light
D7. At speeds above 105km/h, AFL raises the dipped headlight beam to extend

the range of vision for increased safety at higher speed. The beam automatically
returns to its normal position when the car falls below that speed.

D4

D6

D7

39

T21073 Opel Zafira Spec.indd 39T21073 Opel Zafira Spec.indd 39 31/10/08 10:26:3531/10/08 10:26:35

Every effort has been made to ensure that the contents of this publication were accurate and up-to-date at the time of going to press (October 2008). Opel vehicles are equipped with components
manufactured by various General Motors operating units and outside suppliers. The Company reserves the right to change specifi cations and withdraw products from sale without notice. Any such
alterations will be notifi ed to Opel dealers at the earliest opportunity; please consult your local dealer for the latest information. The specifi cations detailed within this brochure are not necessarily
applicable to alternative models such as Special Editions. Details of any such models will be contained in specifi c literature or found on the Opel website. The colours reproduced in this brochure may
vary slightly from the actual paint colour or trim material due to the limitations of the printing process. Please note that Opel dealers are not the agents of General Motors Ireland Limited and are not
authorised to bind the Company by any specifi c or implied undertaking or representation. It is advisable to ensure that your motor insurance policy provides adequate cover for additional fi tted
options and accessories. As part of Opel’s policy of environmental care, this brochure is printed on paper manufactured using Elemental Chlorine Free pulps from specially farmed, sustainable timber
resources. All rights reserved. No part of this publication may be reproduced in any form or by any means, without the prior written permission of General Motors Ireland Limited.

Published October 2008 (BMB/Graymatter) General Motors Ireland Limited, Fern Road, Sandyford Business Estate, Dublin 18. www.opel.ie

OP0800109

T21073 Opel Zafira.indd 40T21073 Opel Zafira.indd 40 31/10/08 11:08:3731/10/08 11:08:37
