Ooma Keypad Quick Start Guide

Keypad

Quick Start Guide

Contents

What’s in the Box ....................................................................... 4

Install the App ........................................................................... 6

Activate Account ........................................................................ 6

Start Pairing Process ....................................................................7

Pull Battery Tab ..........................................................................7

Manually Start Pairing Mode (Optional) .......................................... 8

Complete Pairing Process ............................................................. 9

2 3

Prepare to Mount Your Ooma Keypad ................................................. 9

Mount with Adhesive Pads (Optional) ............................................ 10

Mount with Screws (Optional) ...................................................... 11

How to Check Your Current Mode .................................................... 13

How to Switch Modes .................................................................... 13

How to Trigger a Panic Signal (Professional Monitoring users only).......14

Ooma Keypad Interaction Reference ................................................ 15

1

What’s in the Box

Quick Start Guide

Success LED

(hidde n)

Error LED

(hidde n)

4 5

Ooma Keypad

Back Cover

Back Cover Screw

Tamper Sensor Spring

Screws and Anchors

(1) CR123A

Battery

Adhesive

Pads

2

Install the App

4

Start Pairing Process

If you haven’t done so already, install the Ooma Smart
Security app on your iOS or Android device. Visit the Apple
App Store or Google Play Store and search for “Ooma Smart

Security.” Download the app and install it on your device.

3

Activate Account

Once you get to the login screen, press “Activate Account”
and follow the steps in the app to set up your account.

6 7

Once you have finished setting up your account, press the
“Add Sensor” button on the dashboard. Pick “Keypad” and
follow the steps in the app.

5

Pull Battery Tab

Stand within 10 feet of your Telo Base Station. Looking at
the back side of the Ooma Keypad, pull the clear battery tab.
Doing this will activate the battery connection and the Ooma
Keypad will automatically enter pairing mode. Watch for
the success LED on the front of the sensor to flash green 3
times, indicating the Ooma Keypad is in pairing mode.

Manually Start Pairing Mode

6

7

Complete Pairing Process

(Optiona l)

a. If pulling the battery tab does not automatically

start pairing mode, you will need to start pairing
mode manually.

b. To do this, unscrew the back cover screw.

c. Remove the CR123A battery and wait 10 seconds.

d. Then, press and hold the “Enter” key. While holding

down the Enter key, re-insert the battery.

e. Watch for the success LED on the front of the sensor

to flash green 3 times, indicating the Ooma Keypad is
in pairing mode.

8 9

Follow the steps on the mobile app to complete the
pairing process.

Prepare to Mount Your

8

Ooma Keypad

After pairing your Ooma Keypad, the next step is to mount it
near your main entryway. You will want it within easy reach
when you arrive and leave home every day.

9

Mount with Adhesive Pads (Optional)

10

Mount with Screws (Optional)

a. Use a damp cloth to clean the area where

you want your Ooma Keypad to be so that
the adhesive pads stick properly.

b. If you had to remove the Ooma Keypad’s back

cover during the pairing process, place it back
on the Ooma Keypad now and secure the screw.

c. Peel the backing off of one of the included

adhesive pads. Align it with one edge of the
Ooma Keypad back cover and press firmly.
Repeat this process with the other adhesive pad.

d. Peel off the other backing from the adhesive

pads. Firmly press the Ooma Keypad against
the desired surface for 30 seconds.

a. If you haven’t already,

unscrew the back cover
from the Ooma Keypad.

b. Using the back cover as

a stencil, mark the screw
holes on the desired
mounting surface with
a pencil. If you’re using
the optional anchors,
use a drill to bore holes
and place the anchors
in the holes.

(optional)

(optional)

1110
