Medical Station ONYX-1722/1922
ONYX-1722/1922
17”/19” Intel
®
CoreTM 2 Duo
Processor
High Brightness
Slim Medical Panel PC
ONYX-1722/ 1922 Manual 1
January 2010
st
Ed
Medical Station ONYX-1722/1922
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties, which may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i
Medical Station ONYX-1722/1922
Acknowledgments
Intel
®
, CoreTM 2 Duo are registered trademarks of Intel®
Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft
®
Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
All other product names or trademarks are properties of their
respective owners.
ii
Medical Station ONYX-1722/1922
Packing List
Before you begin installing your Medical Station, please make
sure that the following items have been shipped:
ONYX-1722 or ONYX-1922 Medical Station
HDD screws
Utility CD-ROM
Contains User’s Manual (in PDF format), Drivers and
Utilities
If any of these items are missing or damaged, you should cont act y our
distributor or sales representative immediately.
iii
Medical Station ONYX-1722/1922
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cl oth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
iv
Medical Station ONYX-1722/1922
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or yo u cannot get it to
work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT
16. External equipment intended for connection to signal
input/output or other connectors, shall comply with relevant
UL / IEC standard (e.g. UL 1950 for IT equipment and
UL 60601-1 / IEC 60601 series for systems – shall comply with
the standard IEC 60601-1-1, Safety requirements for medical
electrical systems. Equipment not complying with
UL 60601-1 shall be kept outside the patient environment, as
defined in the standard.
.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.
v
Medical Station ONYX-1722/1922
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IPX0
3. Equipment not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment
vi
FCC
Medical Station ONYX-1722/1922
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received
including interference that may cause
undesired operation.
vii
Medical Station ONYX-1722/1922
UL Module Description
Onyx-1722/1922 AC modules are developed
to suitable for the Classification Mark
requirement
viii
Medical Station ONYX-1722/1922
Safety Symbol Description
The following safety symbols are the further explanations for your
reference.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
Attention, consult ACCOMPANYING
DOCUMENTS.
Ground wire
Protective Ground wire.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
ix
Medical Station ONYX-1722/1922
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
有毒有害物质或元素
部件名称
印刷电路板
及其电子组件
外部信号
连接器及线材
外壳 × ○ ○ ○ ○ ○
中央处理器
与内存
硬盘 × ○ ○ ○ ○ ○
液晶模块 × ○ ○ ○ ○ ○
光驱 × ○ ○ ○ ○ ○
触控模块 × ○ ○ ○ ○ ○
电源 × ○ ○ ○ ○ ○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。
铅
(Pb)汞 (Hg)镉 (Cd)
× ○ ○ ○ ○ ○
× ○ ○ ○ ○ ○
× ○ ○ ○ ○ ○
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
x
Medical Station ONYX-1722/1922
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features....................................................................1-3
1.3 Specification..............................................................1-4
1.4 Dimension ................................................................. 1-8
Chapter 2 Hardware Installation
2.1 Safety Precautions....................................................2-2
2.2 A Quick Tour of the ONYX-1722/1922...................... 2-3
2.3 Removing the rear maintenance cover.....................2-5
2.4 2.5” Hard Disk Drive (HDD) Installation .................... 2-5
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization . ................................. 3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3
Appendix A Programming the Watchdog Timer
A.1 Programming .........................................................A-2
A.2 ITE8712 Watchdog Timer Initial Program..............A-5
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
xi
Medical Station ONYX-1722/1922
B.2 Memory Address Map............................................B-2
B.3 IRQ Mapping Chart ..............................................B-3
B.4 DMA Channel Assignments...................................B-3
Appendix C Miscellanea
C.1 General Cleaning Tips.......................................... C-2
C.2 Cleaning Tools...................................................... C-3
C.3 Scrap Computer Recycling ................................. C-5
xii
Medical Station ONYX-1722/1922
Chapter
1
General
Information
Chapter 1 General Information 1-1
Medical Station ONYX-1722/1922
1.1 Introduction
The ONYX-1722/1922 is a Slim Medical Panel PC with Intel®
TM
Core
2 Duo ULV processor-based computer that is designed to
serve as a point of care station. It is a PC-based system with
17"/19” true color TFT LCD display, Zero Noise solution, integrated
multimedia functions make them the perfect platforms to build
comprehensive lifestyle computing applications.
The ONYX-1722/1922 includes all the features of a powerful
computer into a slim and attractive chassis. Both of the ONYX-1722
has 380 nits and ONYX-1922 has 300 nits TFT displays with 1280 x
1024 resolution, and with 17” and 19” LCD respectively. Integrating
with high brightness LCD is easier to analyze DICOM images.
These two models support 2.5” Hard Disk Drive storage function
and one Mini-PCI for WLAN expansion. Moreover, they feature
flexible I/O ports, such as two USB2.0, one RS-232, one
RS-232/422/485, two 10/100Base-TX, one PS/2 keyboard/ mouse,
and two speakers.
Convenient operation, Silent, compact, mobility and highly
integrated multimedia system let you to focus on healthcare utility,
interactive information displays, automation control systems,
general desktop usage, multimedia recreation, and other medical
requirements.
Chapter 1 General Information 1-2
Medical Station ONYX-1722/1922
1.2 Features
17”/19” SXGA Color TFT LCD Display
Easy To Use, Compact, Simple Design
Fanless, Zero Noise
1000 : 1 Contrast Wide View Angle For X-Ray Film
(ONYX-1722)
2000 : 1 Contrast Wide View Angle For X-Ray Film
(ONYX-1922)
380 Nits High Brightness For X-Ray Film (ONYX-1722)
300 Nits High Brightness For X-Ray Film (ONYX-1922)
Intel
USB & COM Port Isolation (Optional)
Resistive Touchscreen (Optional)
802.11a/b/g/n Wireless Antenna (Optional)
®
Core™ 2 Duo ULV Processor
Weight: 5.6 Kg, Thickness: 69 mm (ONYX-1722)
Weight: 6.0 Kg, Thickness: 69.5 mm (ONYX-1922)
Chapter 1 General Information 1-3
Medical Station ONYX-1722/1922
1.3 Specification
Hardware Specifications
Display
System
Memory
CPU Board
ONYX-1722: 17” SXGA color TFT LCD
ONYX-1922: 19” SXGA color TFT LCD
200-pin DDRII SODIMM x 1, Max. 2GB
®
Intel
CoreTM 2 Duo ® U series Processor
Drive Bay
Expansion
Button
I/O
2.5” Hard Disk Drive (SATA)
Mini-PCI x 1
Brightness: “+” / ”-“; Sound: “+” / ”-“; Power SW
RS-232 x 1, RS-232/422/485 x 1
USB 2.0 x 2
10/100/1000 Base-TX x 1
PS/2 keyboard/ mouse x 1
Speaker x 2 (2W)
LCD Specifications
Model Name ONYX-1722 series ONYX-1922 series
Display Type
Max. Resolution
Max. Colors
Dot Size (mm)
Luminance (cd/m2)
Viewing Angle
17” color TFT LCD 19” color TFT LCD
1280 x 1024 1280 x 1024
16.7M 16.7M
0.297 x 0.297 0.294 x 0.294
380 (TYP) 300 (TYP)
170°(H) 178°(H)
170°(V) 178°(V)
Chapter 1 General Information 1-4
Medical Station ONYX-1722/1922
Contrast Ratio
1000 : 1 2000 : 1
Brightness Control
Back Light MTBF
Yes Yes
50,000 Hrs 50,000 Hrs
Note: All AAEON's LCD products are manufactured with High precision
technology. However, there are a small number of defective pixels in all
LCD panels that are not able to change color. This is a normal occurrence
for all LCD displays from all manufacturers and should not be noticeable or
objectionable under normal operation. AAEON LCD panels are qualified for
industry standard conditions in the following: total 7 dead pixels on a
screen or if there are 3 within 1 inch square area of each other on the
display.
Mechanical Specifications
Architecture
Front Bezel
Color
Mounting / Holder
Construction
Dimension
(W x H x D)
Carton Dimension
Net Weight
Gross Weight
Packing Filler
Close-frame
Plastic bezel with resistive touch screen
White
VESA 75/100mm
3mm ABS + PC TYPE Plastic housing
ONYX-1722: 15.1” x 13.3” x 2.8”
(383mm x 338mm x 70mm)
ONYX-1922: 17.4” x 14.9” x 2.8”
(442mm x 379mm x 70mm)
23.8” x 9.1” x 24” (605mm x 230mm x 610mm)
ONYX-1722: 12.32 lb (5.6 kg)
ONYX-1922: 14.3 lb (6.5 kg)
ONYX-1722: 15.62 lb (7.1 kg)
ONYX-1922: 18.4 lb (8.2 kg)
PE
Chapter 1 General Information 1-5
Medical Station ONYX-1722/1922
Power Supply Specifications
Power Requirement
Input Voltage
Output Voltages
MTBF
DC 9~30V
100 ~ 240V AC @ 47~ 63Hz, 1.4 ~0.6A
24V, 5A, 120W Max.
100,000 hrs operation at 25˚C
Environmental Specifications
Operating Temperature
Storage Temperature
Storage Humidity
Vibration
Shock
Drop
EMI / Safety
IP
Noise
Input Power Rating
0˚C to 40˚C (32˚F ~104˚F)
-20˚C to 60˚C (-4˚F ~140˚F)
5% to 95%@ 40˚C, non-condensing
0.5G / 5 ~ 500Hz (Random) / operation
15G peak acceleration (11 msec. duration) /
operation
76cm (1 Corner, 3 Edge, 6 Surface)
CE / FCC Class B/ UL 60601-1/ EN 60601-1
Front bezel, IP-65 compliant
Zero noise
100~240V/47~63Hz, 1.4~0.6A
TouchScreen (Optional)
Type
5-wire, Analog Resistive
Interface
Resolution
Light Transmission
Life Time
Chapter 1 General Information 1-6
USB Interface
2048 x 2048
> 80% ± 2%
36 million times
Medical Station ONYX-1722/1922
1.4 Dimension
Unit: mm
ONYX-1722
Unit: mm
ONYX-1922
Chapter 1 General Information 1-7
Medical Station ONYX-1722/1922
Chapter
2
Hardware
Installation
Chapter 2 Hardware Installation 2-1
Medical Station ONYX-1722/1922
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis
Chapter 2 Hardware Installation 2-2
Medical Station ONYX-1722/1922
2.2 A Quick Tour of the ONYX-1722/1922
Before you start to set up the ONYX-1722/1922, take a moment to
become familiar with the locations and purposes of the controls,
drives, connections and ports, which are illustrated in the figures
below.
When you place the ONYX-1722/1922 upright on the desktop, its
front panel appears as shown in Picture 2-1.
Picture 2-1: Front View of the Medical Station
When you turn the Medical Station around and look at its rear cover,
the sunken I/O section is at the bottom of the station, as shown in
Picture 2-2. (The I/O section includes various I/O ports, including
DC-in, Serial ports, VGA, PS2, Ethernet, USB.) Only assemble with
the Mini PCI capture card; the S-Video in function will work. The
medical Station integrates with WLAN function by using Mini PCI.
Chapter 2 Hardware Installation 2-3
Medical Station ONYX-1722/1922
Figure 2.2: Rear view of the Medical Station
Chapter 2 Hardware Installation 2-4
Medical Station ONYX-1722/1922
2.3 Removing the rear maintenance cover
Pull USB cover; Unscrew the attachment screws used to hold the
rear maintenance cover and remove rear cover.
2.4 2.5” Hard Disk Drive (HDD) Installation
1. Unscrew the rear cover screws.
2. Remove rear cover and unscrew the disk module screws.
Chapter 2 Hardware Installation 2-5
Medical Station ONYX-1722/1922
3. Assemble 2.5”HDD into disk module.
4. Connect HDD cable to 2.5” HDD connector
Chapter 2 Hardware Installation 2-6
Medical Station ONYX-1722/1922
Chapter
3
Award
BIOS Setup
Chapter 3 Award BIOS Setup 3-1
Medical Station ONYX-1722/1922
3.1 System Test and Initialization
These routines test and initialize board hardware. If the routines
encounter an error during the tests, you will either hear a few short
beeps or see an error message on the screen. There are two kinds
of errors: fatal and non-fatal. The system can usually continue the
boot up sequence with non-fatal errors. Non-fatal error messages
usually appear on the screen along with the following instructions:
Press <F1> to RESUME
Write down the message and press the F1 key to continue
the boot up sequence.
System configuration verification
These routines check the current system configuration against the
values stored in the CMOS memory. If they do not match, the
program outputs an error message. You will then need to run the
BIOS setup program to set the configuration information in memory.
There are three situations in which you will need to change the
CMOS settings:
1. You are starting your system for the first time
2. You have changed the hardware attached to your system
3. The CMOS memory has lost power and the configuration
information has been erased.
The ONYX-1722/1922 CMOS memory has an integral lithium
battery backup for data retention. However, you will need to replace
the complete unit when it finally runs down.
Chapter 3 Award BIOS Setup 3-2
Medical Station ONYX-1722/1922
3.2 Award BIOS Setup
Awards BIOS ROM has a built-in Setup program that allows users
to modify the basic system configuration. This type of information is
stored in battery-backed CMOS RAM so that it retains the Setup
information when the power is turned off.
Entering setup
Power on the computer and press <Del> immediately. This will
allow you to enter Setup.
Standard CMOS Features
Use this menu for basic system configuration. (Date, t ime, IDE,
etc.)
Advanced BIOS Features
Use this menu to set the advanced features available on your
system.
Advanced Chipset Features
Use this menu to change the values in the chipset registers and
optimize your system performance.
Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
(Primary slave, secondary slave, keyboard, mouse etc.)
Power Management Setup
Use this menu to specify your settings for power management.
(HDD power down, power on by ring etc.)
PnP/PCI Configurations
This entry appears if your system supports PnP/PCI.
Chapter 3 Award BIOS Setup 3-3
Medical Station ONYX-1722/1922
PC Health Status
This menu shows you the status of PC.
Frequency/Voltage Control
This menu shows you the display of frequency/Voltage Control.
Load Fail-Safe Defaults
Use this menu to load the BIOS default values for the minimal/
stable performance for your system to operate.
Load Optimized Defaults
Use this menu to load the BIOS default values that are factory
settings for optimal performance system operations. While AWARD
has designated the custom BIOS to maximize performance, the
factory has the right to change these defaults to meet their needs.
Set Supervisor/User Password
Use this menu to set Supervisor/User Passwords.
Save and Exit Setup
Save CMOS value changes to CMOS and exit setup.
Exit Without Saving
Abandon all CMOS value changes and exit setup.
For more detailed information, you can refer to the "AAEON
BIOS Item Description.pdf" file in the CD for the meaning of
each setting in this chapter.
Chapter 3 Award BIOS Setup 3-4
Medical Station ONYX-1722/1922
Chapter
4
Driver
Installation
Chapter 4 Driver Installation 4-1
Medical Station ONYX-1722/1922
The ONYX-1722/1922 comes with an AutoRun CD-ROM that
contains all drivers and utilities that can help you to install the driver
automatically.
Insert the driver CD, the driver CD-title will auto start and show the
installation guide. If not, please follow the sequence below to install
the drivers.
Follow the sequence below to install the drivers:
Step 1 – Install Intel® INF Driver
Step 2 – Install Intel® VGA Driver
Step 3 – Install Intel
Step 4 – Install Realtek Audio Driver
Step 5 – Install Touch Driver
®
LAN Driver
USB 2.0 Drivers are available for download using Windows
Update for both Windows
information regarding USB 2.0 support in Windows
®
Windows
2000, please visit www.microsoft.com/hwdev/usb/.
®
XP and Windows® 2000. For additional
®
XP and
®
Please read instructions below for further detailed installations.
Chapter 4 Driver Installation 4-2
Medical Station ONYX-1722/1922
4.1 Installation:
Insert the ONYX-1722/1922 CD-ROM into the CD-ROM drive. And
install the drivers from Step 1 to Step 5 in order.
®
Step 1 – Install Intel
INF Driver
1. Click on the Step 1 – Intel Inf Driver folder and double
click on the Setup.exe
2. Follow the instructions that the window shows
3. The system will help you install the driver automatically
Step 2 – Install Intel
®
VGA Driver
1. Click on the Step 2 –Intel VGA Driver folder and double
click on the win2k_xp14311.exe
2. Follow the instructions that the window shows
3. The system will help you install the driver automatically
Step 3 – Install Intel
®
LAN Driver
1. Click on the Step 3 – Intel LAN Driver folder and double
click on the PRO2KXP.exe
2. Follow the instructions that the window shows
3. The system will help you install the driver automatically
Step 4 –Install Realtek Audio Driver
1. Click on the Step 4 –Realtek Audio Driver folder and
Chapter 4 Driver Installation 4-3
Medical Station ONYX-1722/1922
double click on the setup.exe
2. Follow the instructions that the window shows
3. The system will help you install the driver automatically
Step 5 – Install Touch Panel Driver
1. Click on the Touch folder and double click on the
setup.exe
2. Follow the instructions that the window shows
3. The system will help you install the driver automatically
Chapter 4 Driver Installation 4-4
Medical Station ONYX-1722/1922
A
Appendix
Programming the
Watchdog Timer
Appendix A Programming the Watchdog Timer A-1
Medical Station ONYX-1722/1922
A.1 Programming
ONYX-1722/1922 utilizes ITE 8712 chipset as its watchdog timer
controller. Below are the procedures to complete its configuration
and the AAEON intial watchdog timer program is also attached
based on which you can develop customized program to fit your
application.
Configuring Sequence Description
After the hardware reset or power-on reset, the ITE 8712 enters the
normal mode with all logical devices disabled except KBC. The
initial state (enable bit ) of this logical device (KBC) is determined
by the state of pin 121 (DTR1#) at the falling edge of the system
reset during power-on reset.
There are three steps to complete the configuration setup: (1) Enter
the MB PnP Mode; (2) Modify the data of configuration registers; (3)
Exit the MB PnP Mode. Undesired result may occur if the MB PnP
Mode is not exited normally.
Appendix A Programming the Watchdog Timer A-2
Medical Station ONYX-1722/1922
(1) Enter the MB PnP Mode
To enter the MB PnP Mode, four special I/O write operations are to
be performed during Wait for Key state. To ensure the initial state of
the key-check logic, it is necessary to perform four write opera -tions
to the Special Address port (2EH). Two different enter keys are
provided to select configuration ports (2Eh/2Fh) of the next
step
(2) Modify the Data of the Registers
All configuration registers can be accessed after entering the MB
PnP Mode. Before accessing a selected register, the content of
Index 07h must be changed to the LDN to which the register
belongs, except some Global registers.
(3) Exit the MB PnP Mode
Set bit 1 of the configure control register (Index=02h) to 1 to exit the
MB PnP Mode.
WatchDog Timer Configuration Registers
Configure Control (Index=02h)
This register is write only. Its values are not sticky; that is to say, a
hardware reset will automatically clear the bits, and does not
require the software to clear them.
Appendix A Programming the Watchdog Timer A-3
Medical Station ONYX-1722/1922
WatchDog Timer Control Register (Index=71h, Default=00h)
WatchDog Timer Configuration Register (Index=72h, Default=0
WatchDog Timer Time-out Value Register (Index=73h, Default=00h)
Appendix A Programming the Watchdog Timer A-4
Medical Station ONYX-1722/1922
A.2 ITE8712 Watchdog Timer Initial Program
.MODEL SMALL
.CODE
Main:
CALL Enter_Configuration_mode
CALL Check_Chip
mov cl, 7
call Set_Logic_Device
;time setting
mov cl, 10 ; 10 Sec
dec al
Watch_Dog_Setting:
;Timer setting
mov al, cl
mov cl, 73h
call Superio_Set_Reg
;Clear by keyboard or mouse interrupt
mov al, 0f0h
mov cl, 71h
call Superio_Set_Reg
;unit is second.
mov al, 0C0H
mov cl, 72h
call Superio_Set_Reg
Appendix A Programming the Watchdog Timer A-5
Medical Station ONYX-1722/1922
; game port enable
mov cl, 9
call Set_Logic_Device
Initial_OK:
CALL Exit_Configuration_mode
MOV AH,4Ch
INT 21h
Enter_Configuration_Mode PROC NEAR
MOV SI,WORD PTR CS:[Offset Cfg_Port]
MOV DX,02Eh
MOV CX,04h
Init_1:
MOV AL,BYTE PTR CS:[SI]
OUT DX,AL
INC SI
LOOP Init_1
RET
Enter_Configuration_Mode ENDP
Exit_Configuration_Mode PROC NEAR
MOV AX,0202h
CALL Write_Configuration_Data
Appendix A Programming the Watchdog Timer A-6
Medical Station ONYX-1722/1922
RET
Exit_Configuration_Mode ENDP
Check_Chip PROC NEAR
MOV AL,20h
CALL Read_Configuration_Data
CMP AL,87h
JNE Not_Initial
MOV AL,21h
CALL Read_Configuration_Data
CMP AL,12h
JNE Not_Initial
Need_Initial:
STC
RET
Not_Initial:
CLC
RET
Check_Chip ENDP
Read_Configuration_Data PROC NEAR
MOV DX,WORD PTR CS:[Cfg_Port+04h]
OUT DX,AL
Appendix A Programming the Watchdog Timer A-7
Medical Station ONYX-1722/1922
MOV DX,WORD PTR CS:[Cfg_Port+06h]
IN AL,DX
RET
Read_Configuration_Data ENDP
Write_Configuration_Data PROC NEAR
MOV DX,WORD PTR CS:[Cfg_Port+04h]
OUT DX,AL
XCHG AL,AH
MOV DX,WORD PTR CS:[Cfg_Port+06h]
OUT DX,AL
RET
Write_Configuration_Data ENDP
Superio_Set_Reg proc near
push ax
MOV DX,WORD PTR CS:[Cfg_Port+04h]
mov al,cl
out dx,al
pop ax
inc dx
out dx,al
ret
Superio_Set_Reg endp.Set_Logic_Device proc near
Appendix A Programming the Watchdog Timer A-8
Medical Station ONYX-1722/1922
Set_Logic_Device proc near
push ax
push cx
xchg al,cl
mov cl,07h
call Superio_Set_Reg
pop cx
pop ax
ret
Set_Logic_Device endp
;Select 02Eh->Index Port, 02Fh->Data Port
Cfg_Port DB 087h,001h,055h,055h
DW 02Eh,02Fh
END Main
Note: Interrupt level mapping
0Fh-Dh: not valid
0Ch: IRQ12
.
.
03h: IRQ3
02h: not valid
01h: IRQ1
00h: no interrupt selected
Appendix A Programming the Watchdog Timer A-9
Medical Station ONYX-1722/1922
Appendix
B
I/O Information
Appendix B I/O Information B-1
Medical Station ONYX-1722/1922
B.1 I/O Address Map
Address Description User Address
000-01F DMA Controller #1 000-000F
020-03F Interrupt Controller #1, Master 020-021
040-05F System Time 040-043
060-06F 8042 (Keyboard Controller) 060-064
070-07F
080-09F DMA Page Register 080-08F
0A0-0BF Interrupt Controller #2 0A0-0A1
0C0-0DF DMA Controller #2 0C0-0DF
0F0-0FF Math Coprpcessor 0F0-0FF
170-177 Secondary IDE Channel 170-177
1F0-1F7 Primary IDE Channel 1F0-1F7
2F8-2FF Serial Port 2 2F8-2FF
378-37F Parallel Printer Port 1 378-37F
3B0-3DF EGA / VGA card 3B0-3DF
3F8-3FF Serial Port 1 3F8-3FF
Real time Clock, NMI (non-maskable
Interrupt) Mask
070-073
B.2 Memory Address Map
Memory Address Description
00000-9FFFF System memory
A0000-BFFFF VGA buffer
C0000-CFFFF VGA BIOS
E0000-FFFFF System BIOS
Appendix B I/O Information B-2
Medical Station ONYX-1722/1922
B.3 IRQ Mapping Chart
IRQ0 System Timer IRQ8 System CMOS /
Real time clock
IRQ1 Keyboard IRQ9 Microsoft ACPI –
Compliant system
IRQ2 Cascade to IRQ
Controller
IRQ3 COM2 IRQ11 Unused
IRQ4 COM1 IRQ12 PS/2 mouse
IRQ5 Unused IRQ13 FPU
IRQ6 Unused IRQ14 Primary IDE
IRQ7 Printer IRQ15 Secondary IDE
IRQ10 Unused
B.4 DMA Channel Assignments
DMA Channel Function
0 Available
1 Available
2 Unused
3 Available
4 Direct Memory Access Controller
5 Available
6 Available
7 Available
Appendix B I/O Information B-3
Medical Station ONYX-1722/1922
A
ppendix
C
Miscellanea
Appendix C Miscellanea C-1
Medical Station ONYX-1722/1922
C.1 General Cleaning Tips
You may need the following precautions before you begin to clean
the computer. When you clean any single part or component for the
computer, please read and understand the details below fully.
1. Never spray or squirt the liquids directly onto any computer
component. If you need to clean the device, please rub it
with a piece of dry cloth.
2. Be cautious of the tiny removable components when you
use a vacuum cleaner to absorb the dirt on the floor.
3. Turn the system off before you start to clean up the
component or computer.
4. Never drop the components inside the computer or get
circuit board damp or wet.
5. Be cautious of all kinds of cleaning solvents or chemicals
when you use it for the sake of cleaning. Some individuals
may be allergic to the ingredients.
6. Try not to put any food, drink or cigarette around the
computer.
Appendix C Miscellanea C-2
Medical Station ONYX-1722/1922
C.2 Cleaning tools
Although many companies have created products to help improve
the process of cleaning your computer and peripherals users can
also use household items to clean their computers and peripherals.
Below is a listing of items you may need or want to use while
cleaning your computer or computer peripherals.
Keep in mind that some components in your computer may only be
able to be cleaned using a product designed for cleaning that
component, if this is the case it will be mentioned in the cleaning
tips.
• Cloth - A piece of cloth is the best tool to use when rubbing
up a component. Although paper towels or tissues can be
used on most hardware as well, we still recommend you to
rub it with a piece of cloth.
• Water or rubbing alcohol – You may moisten a piece of
cloth a bit with some water or rubbing alcohol and rub it on
the computer. Unknown solvents may be harmful to the
plastics parts.
• Vacuum cleaner - Absorb the dust, dirt, hair, cigarette
particles, and other particles out of a computer can be one
of the best methods of cleaning a computer. Over time
these items can restrict the airflow in a computer and cause
circuitry to corrode.
Appendix C Miscellanea C-3
Medical Station ONYX-1722/1922
• Cotton swabs - Cotton swaps moistened with rubbing
alcohol or water are excellent tools for wiping hard to reach
areas in your keyboard, mouse, and other locations.
• Foam swabs - Whenever possible it is better to use lint
free swabs such as foam swabs.
Note:
We strongly recommended that you should shut down the
system before you start to clean any single components.
Please follow the steps below.
1. Close all application programs
2. Close operating software
3. Turn off power switch
4. Remove all device
5. Pull out power cable
Appendix C Miscellanea C-4
Medical Station ONYX-1722/1922
C.3 Scrap Computer Recycling
If the computer equipments need the maintenance or are beyond
repair, we strongly recommended that you should inform us as
soon as possible for the suitable solution. For the computers that
are no longer useful or work well, please contact with worldwide
distributors for recycling.
The worldwide distributors show on the following website:
http://www.aaeon.com/?TabIndex=Contact&TabID=Distributors
Note:
Follow the national requirements to dispose unit
Appendix C Miscellanea C-5
Loading...
