Onyx ONYX-1721, ONYX-1921 User Manual

Slim Medical Panel PC ONYX-1721/1921

ONYX-1721/1921

17”/19” Intel® Atom D525 Dual Core Processor

High Brightness

Slim Medical Panel PC

ONYX-1721/1921 Manual

December, 2011

Slim Medical Panel PC ONYX-1721/1921

Copyright Notice

This document is copyrighted, 2011. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor
for any infringements upon the rights of third parties, which may
result from its use.

The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, ONYX, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.

ONYX reserves the right to make changes in the product design
without notice to its users.

Slim Medical Panel PC ONYX-1721/1921

Acknowledgments

 Intel

®

, CoreTM 2 Duo / Celeron are registered trademarks of

Intel

®

Corporation.

 IBM, PC/AT, PS/2 are trademarks of International Business

Machines Corporation.

 Microsoft

®

Windows is a registered trademark of Microsoft®

Corporation.

 RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
 C&T is a trademark of Chips and Technologies, Inc.
 UMC is a trademark of United Microelectronics Corporation.
 ITE is a trademark of Integrated Technology Express, Inc.

All other product names or trademarks are properties of their
respective owners

.

Slim Medical Panel PC ONYX-1721/1921

Packing List

Before you begin installing your Slim Medical Panel PC, please
make sure that the following items have been shipped:

 ONYX-1721 or ONYX-1921 Slim Medical Panel PC
 VESA Screws (M4 x 0.7 x 12mm)
 Utility CD-ROM which contains User’s Manual (in PDF

format), Drivers and Utilities

If any of these items are missing or damaged, you should contact
your distributor or sales representative immediately.

Headquarters

Onyx Healthcare Inc.
2F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist.,
New Taipei City 231, Taiwan (R.O.C.)
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
http://www.onyx-healthcare.com

Slim Medical Panel PC ONYX-1721/1921

Worldwide Offices:
Onyx Healthcare, USA Inc.
2663 Saturn street, Brea, CA 92821, USA
Tel : [phone]
Fax: [phone]
Email: [e-mail]

Onyx Healthcare EUROPE

B.V.
Ekkersrijt 4002, 5692 DA Son, Netherlands
Tel : [phone]
Fax: [phone]
Email: [e-mail]

Onyx Health

care Technology GmbH
An der Trift65d
63303 Dreieich , Germany
TEL: [phone]
Fax: [phone]
Email: [e-mail]

Slim Medical Panel PC ONYX-1721/1921

Onyx Healthcare (Nanjing) INC.
Room 1318, Metallurgy Building , East Zhongshan Road,
Nanjing, China
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Onyx Health

care Singapore PTE LTD
57 Genting Lane, #07-00, Singapore 349564
Tel: [phone]
Fax [phone]
Email: [e-mail]

Slim Medical Panel PC ONYX-1721/1921

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning.

Do not use liquid or spray detergents for cleaning. Use a damp

cloth.

4. For pluggable equipment, the power outlet must be installed

near the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation.

Dropping it or letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect

the equipment from overheating. DO NOT COVER THE
OPENINGS.

8. Make sure the voltage of the power source is correct before

connecting the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not

place anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from

the power source to avoid damage by transient over-voltage.

12. Never pour any liquid into an opening. This could cause fire o r

electrical shock.

13. Never open the equipment. For safety reasons, only qualified

Slim Medical Panel PC ONYX-1721/1921

service personnel should open the equipment.

14. If any of the following situations arises, get the equipment

checked by service personnel:

a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The eq uipme nt does not work well, or y ou ca nnot get it

to work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvio us signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED

ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT

.

16. External equipment intended for connection to signal
input/output or other connectors, shall comply with
relevant UL / IEC standard (e.g. UL 1950 for IT equipment
and UL 60601-1 / IEC 60601 series for systems – shall
comply with the standard IEC 60601-1-1, Safe ty
requirements for medical electrical systems. Equipment
not complying with UL 60601-1 shall be kept outside the
patient environment, as defined in the standard.

Caution:

It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equival ent type
recommended by the manufacturer.

Slim Medical Panel PC ONYX-1721/1921

Classification

1. Degree of production against electric shock: Not classified.

2. Degree of protection against the ingress of water: IPX0

3. Equipment not suitable for use in the presence of a flammable

anesthetic mixture with air or with oxygen or nitrous oxide.

4. Mode of operation: Continuous

5. Type of protection against electric shock: Class I equipment

Slim Medical Panel PC ONYX-1721/1921

FCC

This device complies with Part 18 FCC
Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and (2)
this device must accept any interference
received including interference that may
cause undesired operation.

Slim Medical Panel PC ONYX-1721/1921

UL Module Description

Onyx-1721/1921 AC modules are developed
to suitable for the Classification Mark
requirement

Slim Medical Panel PC ONYX-1721/1921

Safety Symbol Description

The following safety symbols are the further explanations for your
reference.

Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1

Attention, consult ACCOMPANYING

DOCUMENTS.

Ground wire
Protective Ground wire.

Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
