Onyx MD70-Pro User Manual

M D 70 - P r o

1

MD70-Pro

NVIDIA® TEGRA™ 2 1.0GHz Dual Core Processor

Battery stand for 6 hours

PCT Multi-Touch Screen

Gorilla Glass

OS: Android 4.0

IP54 for easy cleaning

M D 7 0 - P r o

2

Copyright Notice

This document is copyrighted, 2013. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor
for any infringements upon the rights of third parties, which may
result from its use.

The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, ONYX Healthcare Inc., assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein

ONYX Healthcare Inc. reserves the right to make changes in the
product design without notice to its users

M D 7 0 - P r o

3

Acknowledgments

 Tegra2 is a trademark of Nvidia Co., Ltd.
 Gorilla is a trademark of Corning Incorporated.

 Android is a trademark of Google Corporation

All other product names or trademarks are properties of their r
espective owners.

M D 7 0 - P r o

4

Packing List

Before you begin installing your Medical Station, please make sure
that the following items have been shipped:

 MD70-Pro Med-tablet
 Adapter * 1

If any of these items are missing or damaged, you should contact
your distributor or sales representative immediately.

Headquarters
Onyx Healthcare Inc.
2F, No.135, Lane 235, Pao-Chiao Rd.,
Hsin-Tien City, Taipei 231, Taiwan, R.O.C.
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
http://www.onyx-healthcare.com

M D 7 0 - P r o

5

Worldwide Offices:
Onyx Healthcare, USA Inc.
2663 Saturn street, Brea, CA 92821, USA
Tel : [phone]
Fax: [phone]
Email: [e-mail]

Onyx Healthcare EUROPE B.V.
Ekkersrijt 4002, 5692 DA Son, The Netherlands
Tel : [phone]
Fax: [phone]
Email: [e-mail]

Onyx Healthcare Technology GmbH
An der Trift65d
63303 Dreieich , Germany
TEL: [phone]
Fax: [phone]
Email: [e-mail]

M D 7 0 - P r o

6

Onyx Healthcare (SU ZHOU) INC.
Room 12, 2F, Building B, No.5 Xing Han Street, Suzhou Industrial
Park, Jiang Su Province, China
Tel: [phone]
Fax: [phone]

Email: [e-mail]

Onyx Healthcare Singapore PTE LTD
57 Genting Lane, #07-00, Singapore 349564
Tel: [phone]
Fax [phone]
Email: [e-mail]

M D 7 0 - P r o

7

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning.
Do not use liquid or spray detergents for cleaning. Use a damp
cloth.

4. For pluggable equipment, the power outlet must be installed

near the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation.

Dropping it or letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect
the equipment from overheating. DO NOT COVER THE
OPENINGS.

8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.

9. WARNING: To avoid risk of electric shock, this equipment
must only be connected to a supply mains with protective
earth

10. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.

11. All cautions and warnings on the equipment should be noted.

12. If the equipment is not used for a long time, disconnect it from
the power source to avoid damage by transient over-voltage.

M D 7 0 - P r o

8

13. Never pour any liquid into an opening. This could cause fire or
electrical shock.

14. Never open the equipment. For safety reasons, only qualified

service personnel should open the equipment.

15. Warning: Do not modify this equipment without

authorization of the manufacturer

16. If any of the following situations arises, get the equipment

checked by service personnel:

a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it

to work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.

17. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT.

18. External equipment intended for connection to signal
input/output or other connectors, shall comply with
relevant UL / IEC standard (e.g. UL 1950 for IT equipment
and ANSI/AAMI ES 60601-1: 2005 AND CAN/CSA-C22.2 No.
60601-1:08 / IEC 60601 series for systems – shall comply

M D 7 0 - P r o

9

with the standard IEC 60601-1-1, Safety requirements for
medical electrical systems. Equipment not complying
with UL 60601-1 shall be kept outside the patient
environment, as defined in the standard.

Caution:

It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.

Classification

1. Degree of production against electric shock: not classified

2. Degree of protection against the ingress of water: IPX0

3. Mode of operation: Continuous

4. Type of protection against electric shock: Class I equipment

5. No Applied Part, No AP/APG

FCC

This device complies with Part 18 FCC
Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and (2)
this device must accept any interference
received including interference that may
cause undesired operation.

M D 7 0 - P r o

10

Safety Symbol Description

The following safety symbols are the further explanations for your
reference.

Attention, consult ACCOMPANYING
DOCUMENTS.

Ground wire
Protective Ground wire.

M D 7 0 - P r o

11

Contents

Chapter 1 General Information

1.1 Introduction................................................................... 14

1.2 Feature .......................................................................... 15

1.3 Specification ................................................................. 16

1.4 Dimension ..................................................................... 19

Chapter 2 Hardware Installation

2.1 Safety Precautions ....................................................... 21

2.2 A Quick Tour of the MD70-Pro ..................................... 21

2.3 Charging the battery………………….

................................................................ …………………….24

2.4 Turn on / off the
device……………………………………..24

2.5 Connect MD70-Pro to a
computer………………………...25

2.6 Installing the Sim card and Micro-SD
card………………26

Chapter 3 Settings

3.1 Unlocking the
MD70-Pro…………….…………………..…28

3.2
Desktop…………………………………………………….….28

3.3 Touch Panel

M D 7 0 - P r o

12

control ………………………………………..29

3.4
Settings………….……………………………………………..31

Appendix A Miscellanea

A.1 General Cleaning Tips ................................................... 47

A.2 Cleaning Tools .............................................................. 48

A.3 Scrap Computer Recycling ......................................... 51

M D 7 0 - P r o

13

General

Information

Chapter

1

M D 7 0 - P r o

14

1.1 Introduction

The MD70-Pro is based on Navidia Tegra2 Dual Core processor,
which delivers a performance improvement of more than 100
percent compared to systems running traditional single-core
processors. With two cores, MD70-Pro can simultaneously execute
two computing tasks. It accommodates one 16GB EMMC flash and
1G DDR2 SDRAM.

MD70-Pro is a designed specifically device for hospital environment.
ONYX integrated bar code decoder, RFID and hotkey buttons into
MD70-pro. Medical staffs can easily use the MD70-Pro to complete
their jobs and achieve goals, high efficiency and paperless quality
services.

MD70-Pro is a designed specifically device for hospital environment.
ONYX integrated bar code decoder, RFID and hotkey buttons into
MD70-pro. Medical staffs can easily use the MD70-Pro to complete
their jobs and achieve goals, high efficiency and paperless quality
services.

M D 7 0 - P r o

15

1.2 Feature

 NVIDIA® TEGRA™ 2 1.0GHz Dual Core Processor
 Battery stand for 6 hours
 PCT Multi-Touch Screen
 Gorilla Glass
 OS: Android 4.0
 IP54 for easy cleaning
 EN 60601-1 / UL 60601-1

About Android™

Android™ for Developers offers an online orientation for Android

™ developers to answer any questions. Find it in:

http://developer.android.com/sdk/index.html

M D 7 0 - P r o

16

1.3 Specification

Hardware Specifications

Processor

NVIDIA® TEGRA™2, 1.0GHz Dual Core Processor

System Memory

DDR2 1GB SDRAM

System Storage

16GB EMMC Flash

Battery
Capacity

Li-Polymer high capacity battery (27Whr), 6 Hrs Battery
Life

RFID

13.56 MHz

Light sensor

Auto dimming form dark to bright

Navigation

GPS, E-Compass (optional)

Barcode Reader

2D/1D (optional)

Mic

Yes

M D 7 0 - P r o

17

Display Specifications

Size

7” Wide Screen Display

Panel Vendor

CMI

Resolution

1280x 800

Max Colors

262K

Luminance

400 nits

View Angle

178/178 (Typical)

Touch

PCT Multi-Touch Screen
Gorilla Glass

Back Light Life Time
(Hrs)

12000 hrs

Power Supply Specifications

Input Voltage

100-240V AC, 2.0-1.0A @ 50-60 Hz

Output Voltage

2V/2.5A

M D 7 0 - P r o

18

IO port

I/O

1 x DC-In
1 x Micro SD (SD/SDIO 2.1)
1 x Micro USB ( USB2.0)
1 x Stereo Headphone
1 x SIM card

Wireless

WLAN 802.11 b/g/n

(1T1R, 2R2R)

Camera

Front: 1.2M Pixel camera (optional)
Rear: 5M AF camera (optional)

Speaker

0.5W x 1

2 Control key

1 for barcode, 1 option

Environmental Specifications

Operating
temperature

0℃to 40℃(32℉~104℉)

Storage temperature

-20℃to 60℃(-4℉~140℉)

Storage humidity

5 to 95%@ 40℃, non-condensing

Drop

1M Drop

EMI / Safety

CE/FCC Class B, UL 60601-1, EN60601-1

M D 7 0 - P r o

19

1.4 Dimension (mount kit is optional)

M D 7 0 - P r o

20

Hardware

Introduction

Chapter

2

M D 7 0 - P r o

21

2.1 Safety Precautions

Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.

Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

2.2 A Quick Tour of the MD70-Pro

Before you start to set up the MD70-Pro, take a moment to become
familiar with the locations and purposes of the device, which are
illustrated in the figures below.

M D 7 0 - P r o

22

When you place the MD70-Pro upright on the desktop, its front side
appears as shown in Picture 2-1.

Picture 2.1: Front View of the MD70-Pro

When you turn the MD70-Pro around and look at its rear side, as
shown in Picture 2-2.

M D 7 0 - P r o

23

Picture 2.2: Rear view of the Zeus Series

M D 7 0 - P r o

24

2.3 Charging the battery

Use only the power adapter that comes with your device.
Using a different power adapter may damage your device.

1. Plug the AC charger into a wall outlet.

2. Connect the DC end of the adapter to the MD70-Pro HDMI-B

type connector.

Note: The battery is not fully charged. Allow your battery to fully charge
before using it (i.e., before disconnecting AC power). Calibrating the battery
before use is also highly recommended.

The power button turns your device on and off. Hold the button for two
seconds to power on. To start or wake it up from sleep mode, hold the
power button for 0.5 seconds to display the shutdown confirmation. If the
system is unresponsive, hold the power button to power off. A forced power
off may result in data loss. It is strongly recommended that important data
is backed up on a regular basis.

2.4 Turn on / off the device

1. Turn on : Press the Power button on the top of the device. Wait

for the boot screen to display.

2.Turn off : Press and hold the Power button on the top of the

DC in

M D 7 0 - P r o

25

device. Choice “Yes” on the screen to turn off the device.

2.5 Connect MD70-Pro to a computer

Use the USB/Micro-USB cable to connect the device and PC.
Connect the Micro-USB port to MD70-Pro and connect the USB
port to the PC.
Note: The connect status is only for data transference, and you
couldn’t use the USB port to charge the battery.

Micro USB

M D 7 0 - P r o

26

2.6 Installing the Sim card and Micro-SD card

Insert the Sim card (3G version device only) and Micro-SD card
into the socket.

Sim card socket

Micro SD socket

M D 7 0 - P r o

27

Settings

Chapter

3

M D 7 0 - P r o

28

3.1 Unlocking the MD70-Pro

To unlock this tablet, tap and drag the lock out of the circle

3.2 Desktop

M D 7 0 - P r o

29

3.3 Touch Panel Control

Single taps

Single taps on the touch panel screen lets the user select a certain
item or activate an application.

Double taps

Double taps on the File Manager lets the user open a selected file.

M D 7 0 - P r o

30

Longer press taps

Long-pressing an application allows you to drag and drop the
application or the application shortcut to another desktop.
Long-pressing a desired file in the File Manager allows you to copy,
cut, rename or delete the selected file.
You can use the pencil tool on the top right corner to copy, cut, or
delete multiple files at one time.

Input, insert, select or copy texts

The keyboard appears when you use word processor to edit
documents or enter the web address on the web browser address
bar.

M D 7 0 - P r o

31

3.4 Settings

The settings screen allows you to configure some settings of your
MD70-Pro, which includes:

 Wireless & Network
 3G ( optional )
 Sound
 Screen
 Location & Security
 Applications
 Account & Sync
 Privacy
 Storage
 Language & Input
 Accessibility
 Date & time

M D 7 0 - P r o

32

Configuration

Click the tabs on the left to switch screens and access the related
configurations.

There are two ways to enter the Settings screen:

1) Desktop:

 Tap the notification area on the bottom right corner.
 Tap and extend the quick configuration area.
 Tap Settings to open the Settings screen.

2) Apps Menu:

 Tap Apps menu on the top right corner.
 Tap Settings.

M D 7 0 - P r o

33

1. Wireless & Network

Select Wireless & networks for Wi-Fi settings, Bluetooth® settings,
VPN settings and Mobile network settings.

Select the name of your network.

M D 7 0 - P r o

34

Type in your password.

The system will confirm that you are connected to the internet.

M D 7 0 - P r o

35

M D 7 0 - P r o

36

2. 3G (optional)

For 3G functions, insert the SIM card and type in your PIN Number.

The MD70-Pro will confirm the 3G connection.

M D 7 0 - P r o

37

3. Sound

Select Sound to configure volume settings for audio broadcasts.

M D 7 0 - P r o

38

4. Screen

Select Screen to adjust the brightness of the RTC-700A.

M D 7 0 - P r o

39

5. Location & Security

Select Location & Security to secure this tablet computer. This can
also be used to determine positioning for Google Maps and other
GPS related functions.

M D 7 0 - P r o

40

6. Applications

Select Applications to manage applications, observe services,
storage use and battery use, as well as to locate options in terms of
application development.

M D 7 0 - P r o

41

7. Account & Sync

Select Accounts & sync to decide which applications to receive and
sync data.

M D 7 0 - P r o

42

8. Privacy

Select Privacy to back up important files.

M D 7 0 - P r o

43

9. Storage

Select Storage to view how much storage space is filled up, and to
view the available storage space.

M D 7 0 - P r o

44

10. Language & Input

Select Language & input to choose the correct language.

M D 7 0 - P r o

45

11. Date & time

Select Date & time appropriate for your time zone.

The system will confirm the date.

M D 7 0 - P r o

46

M D 7 0 - P r o

47

Miscellanea

Appendix

A

M D 7 0 - P r o

48

A.1 General Cleaning Tips

You may need the following precautions before you begin to clean
the computer. When you clean any single part or component for the
computer, please read and understand the details below fully.

1. Never spray or squirt the liquids directly onto any computer

component. If you need to clean the device, please rub it
with a piece of dry cloth.

2. Be cautious of the tiny removable components when you

use a vacuum cleaner to absorb the dirt on the floor.

3. Turn the system off before you start to clean up the

component or computer.

4. Never drop the components inside the computer or get

circuit board damp or wet.

5. Be cautious of all kinds of cleaning solvents or chemicals

when you use it for the sake of cleaning. Some individuals
may be allergic to the ingredients.

6. Try not to put any food, drink or cigarette around the

computer.

7. ONYX Healthcare Inc. has tested and verified these

cleaning disinfectants, CIDEX, Viraguard, Control III
Disinfectant Germicide, Caviwipes, Dispatch Disinfectant
Cleaner CLH69101, Puregreen 24 Disinfectant, can be
used with the MD70-Pro. Use of any other disinfectants will

M D 7 0 - P r o

49

void the warranty.

A.2 Cleaning tools

Although many companies have created products to help improve
the process of cleaning your computer and peripherals users can
also use household items to clean their computers and peripherals.
Below is a listing of items you may need or want to use while
cleaning your computer or computer peripherals.

Keep in mind that some components in your computer may only be
able to be cleaned using a product designed for cleaning that
component, if this is the case it will be mentioned in the cleaning
tips.

 Cloth - A piece of cloth is the best tool to use when rubbing

up a component. Although paper towels or tissues can be
used on most hardware as well, we still recommend you to
rub it with a piece of cloth.

 Water or rubbing alcohol – You may moisten a piece of

cloth a bit with some water or rubbing alcohol and rub it on
the computer. Unknown solvents may be harmful to the
plastics parts.

 Vacuum cleaner - Absorb the dust, dirt, hair, cigarette

particles, and other particles out of a computer can be one
of the best methods of cleaning a computer. Over time

M D 7 0 - P r o

50

these items can restrict the airflow in a computer and cause
circuitry to corrode.

 Cotton swabs - Cotton swaps moistened with rubbing

alcohol or water are excellent tools for wiping hard to reach
areas in your keyboard, mouse, and other locations.

 Foam swabs - Whenever possible it is better to use lint

free swabs such as foam swabs.

Please follow the steps below.

1. Close all application programs.

2. Close operating software.

3. Turn off power switch

4. Remove all device

5. Pull out power cable

Note:

We strongly recommended that you should shut down the

system before you start to clean any single components.

M D 7 0 - P r o

51

A.3 Scrap Computer Recycling

If the computer equipments need the maintenance or are beyond
repair, we strongly recommended that you should inform us as
soon as possible for the suitable solution. For the computers that
are no longer useful or work well, please contact with worldwide
distributors for recycling.

The worldwide distributors show on the following website:

http://www.onyx-healthcare.com.tw/Contact.php

Note:

Follow the national requirement to dispose unit
