OnStar TTY Guide

Welcome to OnStar.

The safety and security of OnStar®

is available to TTY (Text Telephone) users.

16989 R8 8.25.06.indd 116989 R8 8.25.06.indd 1 8/25/06 8:59:39 AM8/25/06 8:59:39 AM

OnStar TTY Functions

Congratulations on your purchase of a GM
vehicle equipped with OnStar TTY capability.
OnStar has enhanced its TTY services and
provides access to TTY-trained Advisors 24
hours a day, 7 days a week. Now you can enjoy
the peace of mind that comes with knowing
you have access to OnStar’s safety and secu­rity features while you’re on the road.

Your OnStar TTY system comes
equipped with three components:

• OnStar TTY Interface
Module (OTIM)

• Dial Pad (for making
phone calls)

• TTY Device

OTIM

Status Light

Dial Pad

TTY Device

16989 R8 8.25.06.indd 216989 R8 8.25.06.indd 2 8/25/06 8:59:42 AM8/25/06 8:59:42 AM

Upon installation by your dealer, your OnStar TTY system is fully
functional for OnStar services.

*

Please take a moment to familiar­ize yourself with all the functions of the TTY system so that you’ll
be comfortable with them once you begin driving. Your OnStar TTY
system provides you with access to most of the features

**

described

in the OnStar Subscriber Information kit in your glove box. Be sure

to read the OnStar Owner Guide so that you understand all the
details of how the OnStar features work.

Most 2007 GM vehicles come with one year of OnStar service. Check
with your dealer or an OnStar TTY Advisor to determine what service
plan comes with your vehicle. Your TTY system is your communication
link to trained TTY Advisors at OnStar’s call centers 24/7, every day of
the year. You can press the OnStar blue button, the Emergency button,
and make phone calls using the dial pad.

OnStar TTY Guide

* OnStar services require vehicle electrical system (including battery), wireless service
and GPS satelite signals to be available and operating for features to funtion properly.
OnStar acts as a link to existing emergency service providers. Subscriptions Service
Agreement required. Call 1.877.248.2080 or visit onstar.com for OnStar’s Terms and
Conditions, Privacy Policy and systems limitations and details. Additional information
can be found in the OnStar Owner’s Guide in your glove box.

**Excludes OnStar Turn-by-Turn Navigation and Virtual Advisor.

Important Note: In order to use your OnStar TTY system your

vehicle must be stationary. If you initiate a call while stationary
and begin moving your vehicle, the call will automatically disconnect.
Your TTY device will display a “call disconnected due to vehicle
speed” message. This feature is designed to prevent you from being
distracted while driving so that you can devote your full attention to
driving safely.

16989 R8 8.25.06.indd 316989 R8 8.25.06.indd 3 8/25/06 8:59:44 AM8/25/06 8:59:44 AM

How to contact OnStar:

1. Be sure the TTY device is plugged into the right side of the OTIM
in the jack identifi ed for TTY.

2. Push the MODE button to TTY; the green status light will
illuminate. If you push the MODE button a second time, the
status light will go out. This indicates that the TTY system is
off, and the OnStar system is in Voice mode.

3. Practice making a call to OnStar by pressing the blue OnStar
button on your mirror or console. The TTY screen will
display “CONNECTING TO ONSTAR” and the green status light
will blink to indicate that a call is in progress.

4. OnStar will respond to you with a greeting and you can
now correspond with the live Advisors.

5. When you fi nish your interaction with the OnStar Advisor,
the Advisor will automatically disconnect the call for you.

16989 R8 8.25.06.indd 416989 R8 8.25.06.indd 4 8/25/06 8:59:45 AM8/25/06 8:59:45 AM

How to make Emergency calls:

1. Your vehicle should not be moving.

*

Press the red OnStar
emergency button and wait for the OnStar Emergency
Advisors to respond.

2. The Advisor will ask you to state your emergency.

3. OnStar Emergency Advisors will contact emergency service
providers and request that they respond to your location.

4. In the event that you do not respond, OnStar will contact
emergency services and automatically send them to your
location. If the red button is pressed in error, please inform the
Advisor using your TTY device.

*Note: If you must call OnStar Emergency when your vehicle is
moving, the OnStar Advisor will only respond with short text
messages. It is very important to stop the vehicle in a safe
location whenever possible.

16989 R8 8.25.06.indd 516989 R8 8.25.06.indd 5 8/25/06 8:59:48 AM8/25/06 8:59:48 AM

You’ll need to purchase minutes to make calls. The OnStar system in your
vehicle automatically keeps track of your calling minutes. You can check
the calling minutes you have remaining by pushing the OnStar blue button
and asking an Advisor. The Advisors can provide you with the vehicle phone
number and can help you purchase minutes.

How to answer incoming phone calls:

Your vehicle has a phone number so others can call you when you are
stationary. This feature will not work when your vehicle is moving. You
can identify incoming calls by viewing the TTY screen for the “INCOMING
PERSONAL CALL” message, or you can look for the green status light to blink.
You can answer an incoming call by pressing the phone button on the Dial Pad.
Incoming calls may also occur while you are driving. Callers will receive

How to make phone calls :

1. Using the Dial Pad, dial the number you wish
to call. Then push the phone button on the
Dial Pad. Always use 1 and the area code.

2. Once your call is in progress the TTY screen
will display “CALL” and the green status
light on the OTIM will blink to indicate the call is in progress.

3. When the party you called answers, you can begin your conversation by
typing into the TTY device in the usual fashion.

4. To end your call, push the phone button on the Dial Pad.

Note: While the TTY system is on, the phone button
next to the blue button is disabled. To place a call using
the voice mode, turn the TTY system off by pressing the “Mode”
button. Then press the phone button on the three-button keypad.

*OnStar Hands-Free Calling requires a Hands-Free Calling enabled vehicle, existing OnStar service
contract and prepaid calling minutes. Not available in certain markets. Calls may be made to the US
and Canada only.

*

16989 R8 8.25.06.indd 616989 R8 8.25.06.indd 6 8/25/06 8:59:52 AM8/25/06 8:59:52 AM

a “Driver Unavailable” message. If someone called you while you
were driving, you can return that call by pushing the phone button on
the Dial Pad.

Troubleshooting:

If you are experiencing problems with your OnStar TTY system,
please check the following:

1. Make sure the LED next to your three-button OnStar system, located either in
your rearview mirror or your overhead console, is green. If the LED is not
green, please turn off your vehicle’s ignition, and then turn it back on. If the
status light next to the three button system does not illuminate, this indicates
a problem with your OnStar system. Please visit your GM dealer.

2. Make the TTY device is properly plugged into the OTIM. When the TTY
device is properly plugged in, the Status LED and the Mode LED will be
illuminated green.

If these LEDs are not illuminated, please disconnect then reconnect the
TTY device into the TTY jack, and ensure the OTIM is set to TTY mode by
pressing the Mode button until the Mode LED illuminates green.
If the lights are still not illuminated, please call OnStar via the TTY toll-free
number (877.248.2080). Ask the TTY Advisor to ensure that your OnStar
account has been activated and that you are enrolled as a TTY subscriber.

3. If you are experiencing garbled text on your TTY device, make sure the
device is fully charged. If it is fully charged, there may be cellular
connectivity issues affecting your call. In this case, please
disconnect your call and try again in a few minutes.

*Note: In an emergency situation, in addition to the red emergency
button on the OnStar 3-button system you can dial 9-1-1 on the dial pad
while the vehicle is moving. However, due to the OnStar advisor’s ability
to pinpoint your location, the red emergency button is the preferred mode
of communication in an emergency.

16989 R8 8.25.06.indd 716989 R8 8.25.06.indd 7 8/25/06 8:59:55 AM8/25/06 8:59:55 AM

Contact OnStar at 1.877.248.2080 (tty)
Visit www.onstar.com/tty
or Email us at [e-mail]

Write to OnStar at:
OnStar Subscriber Services
P.O. Box 0217
Troy, MI 48099-0217

Gen. 7 TTY Guide

Warranty Information

Your TTY device is manufactured by an independent manufacturer and is covered by the
manufacturer’s warranty. It is not covered under the GM New Vehicle Limited Warranty.
All other parts (OTIM & dial pad) are covered by the standard parts & labor warranty of
your new vehicle. Please be aware that you will be responsible for proper care of your
equipment. Contact your GM Dealer to set up an appointment for service if required.
