Isolation Shield

ASMS4730 | 12815

Vented aluminum surrounds
panel with a metal frame.

FEATURES AND BENEFITS

Turn your microphone stand setup into a recording environment!
The ASMS4730 Isolation Shield is a lightweight and portable shield
that mounts onto most standard microphone stands, creating a mini
recording studio. Constructed from a vented aluminum surround
panel, metal frame and 2" acoustic foam, the ASMS4730 blocks out
unwanted background noise and improves the direct sound output
when recording. Included mounting brackets attach the shield easily to
most standard mic stands, and an included microphone mounting bar
can position your mic as close as 2" from the screen, and as far as 7"
away from the screen. Entire screen adjusts vertically up to 5-1/2".

Microphone can be mounted
and positioned up to 5.5"
above the bracket level.

2" Acoustic foam blocks out
unwanted background noise.

Bracket also features an independent horizontal slide
allowing you to position your mic as close as 2" from
the screen, and as far as 7" away from the screen.

Call The Music People today to place your order

Lightweight and portable Isolation Shield turns your microphone stand
into a recording studio!

PRODUCT SPECIFICATIONS

Dimensions 18.5" x 12"
Height Adjustment 5.5" up from level
Depth Adjustment Mic adjusts between 2-7" from screen
Total Weight 4.5 lbs.
Screen Weight 2.75 lbs.
Construction Vented aluminum surround panel with metal

frame and 2" acoustic foam

PRICING

Model #ASMS4730 Inventory #12815
List Price: $163.99 MAP Price: $99.95
