ON Semiconductor ADT7476 User guide

ADT7476
Remote Thermal Controller and Voltage Monitor
The ADT7476 controller is a thermal monitor and multiple PWM fan controller for noise-sensitive or power-sensitive applications requiring active system cooling. The ADT7476 can drive a fan using either a low or high frequency drive signal and can monitor the temperature of up to two remote sensor diodes plus its own internal temperature. The part also measures and controls the speed of up to four fans, so the fans operate at the lowest possible speed for minimum acoustic noise.
The automatic fan speed control loop optimizes fan speed for a given temperature. The effectiveness of the system’s thermal solution can be monitored using the THERM also provides critical thermal protection to the system using the bidirectional THERM
pin as an output to prevent system or
component overheating.
Features
Monitors Up to Five Voltages
Controls and Monitors Up to Four Fans
High and Low Frequency Fan Drive Signal
One On-Chip and Two Remote Temperature Sensors
Extended T emperature Measurement Range Up to 191°C
Automatic Fan Speed Control Mode Controls System Cooling Based
on Measured Temperature
Enhanced Acoustic Mode Dramatically Reduces User Perception of
Changing Fan Speeds
Thermal Protection Feature via THERM Output
Monitors Performance Impact of Intel
Thermal Control Circuit via THERM Input
3-wire and 4-wire Fan Speed Measurement
Limit Comparison of All Monitored Values
Meets SMBus 2.0 Electrical Specifications
This Device is Pb-Free, Halogen Free and is RoHS Compliant
input. The ADT7476
®
Pentium®4 Processor
PIN ASSIGNMENT
SDA
SCL
GND
V
CC
VID0/GPIO0 VID1/GPIO1 VID2/GPIO2 VID3/GPIO3
TACH3 PWM2/
SMBALERT
TACH1 TACH2
*TACH4/THERM
MARKING DIAGRAMS
www.onsemi.com
QSOP−24 NB
CASE 492B
1 2 3 4 5 6
ADT7476
7
(Top View)
8
9 10 11 12
/SMBALERT/GPIO6/ADDRSELECT
ADT7476RQZ
#YYWW
xxxx
24
PWM1/XTO
23
V
CCP
+2.5VIN/THERM
22 21
+12VIN/VID5
20
+5V
IN
19
VID4/GPIO4
18
D1+
17
D1− D2+
16 15
D2−
14
*
13
PWM3/ADDREN
© Semiconductor Components Industries, LLC, 2016
February, 2016 − Rev. 10
ADT7476RQZ = Specific Device Code # = Pb-Free Package YYWW = Date Code xxxx = Assembly Lot Code
ORDERING INFORMATION
See detailed ordering and shipping information in the package dimensions section on page 67 of this data sheet.
1 Publication Order Number:
ADT7476/D
ADT7476
ADDR
ADDREN SCL SDA SMBALERT
SELECT
VID5/GPIO5 VID4/GPIO4 VID3/GPIO3 VID2/GPIO2 VID1/GPIO1 VID0/GPIO0
GPIO6 PWM1
PWM2
PWM3 TACH1 TACH2 TACH3 TACH4
THERM
V
CC
D1+ D1− D2+ D2−
+5V
+12V
+2.5V
V
CCP
ADT7476
VID/GPIO
REGISTER
SMBus
ADDRESS
SELECTION
SERIAL BUS
INTERFACE
ADDRESS
POINTER
REGISTER
PWM REGISTERS
AND CONTROLLERS
(HF AND LF)
AUTOMATIC FAN SPEED
CONTROL
PWM
CONFIGURATION
REGISTERS
FAN SPEED
COUNTER
INTERRUPT
MASKING
PERFORMANCE
MONITORING
TO ADT7476
V
CC
THERMAL
PROTECTION
ACOUSTIC
INTERRUPT
STATUS
REGISTERS
ENHANCEMENT
CONTROL
INPUT
SIGNAL
CONDITIONING
IN IN IN
AND
ANALOG
MULTIPLEXER
10-BIT
ADC
LIMIT
COMPARATORS
VALUE AND
LIMIT
REGISTERS
BAND GAP
BAND GAP
REFERENCE
TEMP. SENSOR
GND
Figure 1. Functional Block Diagram
Table 1. ABSOLUTE MAXIMUM RATINGS
Parameter Rating Unit
Positive Supply Voltage (VCC) 3.6 V Maximum Voltage on +12 VIN Pin 16 V Maximum Voltage on +5.0 VIN Pin 6.25 V Maximum Voltage on All Open-Drain Outputs 3.6 V Input Current at Any Pin ±5 mA Package Input Current ±20 mA Maximum Junction Temperature (T
) 150 °C
J MAX
Storage Temperature Range −65 to +150 °C Lead Temperature, Soldering
IR Reflow Peak Temperature Pb-Free Peak Temperature Lead Temperature (Soldering, 10 sec)
220 260 300
°C
ESD Rating 1,500 V
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.
NOTE: This device is ESD sensitive. Use standard ESD precautions when handling.
www.onsemi.com
2
ADT7476
Table 2. THERMAL CHARACTERISTICS (Note 1)
Package Type
24-lead QSOP 122 31.25 °C/W
1. qJA is specified for the worst-case conditions, that is, a device soldered in a circuit board for surface-mount packages.
Table 3. PIN ASSIGNMENT
Pin No. Mnemonic Description
1 SDA Digital I/O (Open Drain). SMBus bidirectional serial data. Requires SMBus pullup. 2 SCL Digital Input (Open Drain). SMBus serial clock input. Requires SMBus pullup. 3 GND Ground Pin. 4 V
CC
5 VID0/
GPIO0
6 VID1/
GPIO1
7 VID2/
GPIO2
8 VID3/
GPIO3
9 TACH3 Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 3.
10 PWM2/
SMBALERT
11 TACH1 Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 1. 12 TACH2 Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 2. 13 PWM3
ADDREN
14 TACH4/
THERM
SMBALERT
GPIO6/
ADDR SELECT
15 D2– Cathode Connection to Second Thermal Diode. 16 D2+ Anode Connection to Second Thermal Diode. 17 D1– Cathode Connection to First Thermal Diode. 18 D1+ Anode Connection to First Thermal Diode. 19 VID4/
GPIO4
20 +5.0 V
IN
21 +12 VIN/
VID5
22 +2.5 VIN/
THERM
23 V
CCP
24 PWM1/
XTO
Power Supply. Powered by 3.3V standby, if monitoring in low power states is required. VCC is also monitored through this pin.
Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
Digital Output (Open Drain). Requires 10 kW typical pullup. Pulse width modulated output to control Fan 2 speed. Can be configured as a high or low frequency drive. Digital Output (Open Drain). This pin can be reconfigured as an SMBALERT
interrupt output to signal out-of-limit conditions.
Digital I/O (Open Drain). Pulse width modulated output to control the speed of Fan 3 and Fan 4. Requires 10 kW typical pullup. Can be configured as a high or low frequency drive. If pulled low on powerup, the ADT7476 enters address select mode, and the state of Pin 14 (ADDR SELECT determines the ADT7476’s slave address.
Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 4. Alternatively, the pin can be reconfigured as a bidirectional THERM
/
the THERM input. For example, it can be connected to the PROCHOT output of Intel’s Pentium®4 processor or to the output of a trip point temperature sensor. Can be used as an output to signal overtemperature conditions.
Digital Output (Open Drain). This pin can be reconfigured as an SMBALERT
/
out-of-limit conditions. General-Purpose Open Drain Digital I/O. If in address select mode, the logic state of this pin defines the SMBus device address.
Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
Analog Input. Monitors 5.0 V power supply. Analog Input. Monitors 12 V power supply.
Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). Analog Input. Monitors 2.5 V supply, typically a chipset voltage.
Alternatively, this pin can be reconfigured as a bidirectional/omnidirectional THERM time and monitor assertions on the THERM
input. For example, can be connected to the PROCHOT output of Intel’s Pentium®4 processor or to the output of a trip point temperature sensor. Can be used as an output to signal overtemperature conditions.
Analog Input. Monitors processor core voltage (0 V to 3.0 V). Digital Output (Open Drain). Pulse width modulated output to control the speed of Fan 1. Requires 10 kW
typical pullup. Also functions as the output from the XOR tree in XOR test mode.
q
JA
q
JC
pin. Times and monitors assertions on
interrupt output to signal
pin. Can be used to
Unit
)
www.onsemi.com
3
ADT7476
Table 4. ELECTRICAL CHARACTERISTICS (T
Parameter
A=TMIN
to T
MAX
, VCC=V
MIN
to V
, unless otherwise noted.) (Note 1)
MAX
Conditions Min Typ Max Unit
Power Supply
Supply Voltage Supply Current, I
CC
Interface Inactive, ADC Active 1.5 3.0 mA
3.0 3.3 3.6 V
Temperature-to-Digital Converter
Local Sensor Accuracy
0°C TA 85°C
−40°C T
Resolution
Remote Diode Sensor Accuracy
0°C TA 85°C
−40°C T
Resolution
Remote Sensor Source Current Low Level
High Level
125°C
A
125°C
A
±0.5
0.25 ±0.5
0.25 11
180
±1.5 ±2.5
±1.5 ±2.5
Analog-to-Digital Converter (Including MUX and Attentuators)
Total Unadjusted Error (TUE)
For 12 V Channel For All Other Channels
±2
±1.5
Differential Non-linearity (DNL) 8 Bits ±1 LSB Power Supply Sensitivity ±0.1 %/V Conversion Time
Voltage Input Local Temperature Remote Temperature
Total Monitoring Cycle Time Averaging Enabled
Input Resistance For V
Averaging Enabled
Averaging Disabled
channel
CCP
For all other channels
70 70
11 12 38
145
19
120 114
Fan RPM-to-Digital Converter
Accuracy
0°C TA 70°C
−40°C T
+120°C
A
±6
±10
Full-Scale Count 65,535 Nominal Input RPM Fan Count = 0xBFFF
Fan Count = 0x3FFF Fan Count = 0x0438 Fan Count = 0x021C
109 329
5,000
10,000
RPM
Open-Drain Digital Outputs, PWM1 TO PWM3, XTO
Current Sink, I Output Low Voltage, V
OL
OL
High Level Output Current, I
OH
I
= −8.0 mA 0.4 V
OUT
V
= V
OUT
CC
8.0 mA
0.1 20
Open-Drain Serial Data Bus Output (SDA)
I
Output Low Voltage, V
OL
High Level Output Current, I
OH
= −4.0 mA 0.4 V
OUT
V
OUT
= V
CC
0.1 1.0
SMBus Digital Inputs (SCL, SDA) (Note 2)
Input High Voltage, V Input Low Voltage, V
IH
IL
2.0 V
0.8 V
Hysteresis 500 mV
Digital Input Logic Levels (TACH Inputs)
Input High Voltage, V Input Low Voltage, V
IH
IL
Maximum Input Voltage 2.0 3.6 V Minimum Input Voltage −0.3 0.8 V
Hysteresis 0.5 V p-p
°C
°C
mA
%
ms
ms
kW
%
mA
mA
www.onsemi.com
4
ADT7476
Table 4. ELECTRICAL CHARACTERISTICS (T
A=TMIN
to T
MAX
, VCC=V
MIN
to V
, unless otherwise noted.) (Note 1)
MAX
Parameter UnitMaxTypMinConditions
Digital Input Logic Levels (THERM) ADTL+
Input High Voltage, V Input Low Voltage, V
IH
IL
0.75 x V
CCP
0.8 V
V
Digital Input Current
Input High Current, I Input Low Current, I Input Capacitance, C
IH
IL
IN
VIN = V
CC
VIN = 0 V ±1
±1
mA mA
5.0 pF
Serial Bus Timing (See Figure 2)
Clock Frequency, f Glitch Immunity, t Bus Free Time, t SCL Low Time, t SCL High Time, t SCL, SDA Rise Time, t SCL, SDA Fall Time, t Data Setup Time, t
SCLK
SW BUF LOW
HIGH
r
f
SU;DAT
Detect Clock Low Timeout, t
TIMEOUT
Can be Optionally Disabled 15 35 ms
10 400 kHz
50 ns
4.7
4.7
4.0 50
ms ms ms
1,000 ns
300
ms
250 ns
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.
1. All voltages are measured with respect to GND, unless otherwise specified. Typical voltages are T Logic inputs accept input high voltages up to V levels of V
2. SMBus timing specifications are guaranteed by design and are not production tested.
= 0.8 V for a falling edge, and VIH= 2.0 V for a rising edge.
IL
, even when the device is operating down to V
MAX
=25°C and represent a parametric norm.
A
. Timing specifications are tested at logic
MIN
SCL
SDA
t
BUF
PS
t
LOW
t
HD; STA
t
F
t
R
t
t
HD; DAT
HIGH
t
SU; DAT
Figure 2. Serial Bus Timing Diagram
t
HD; STA
t
SU; STA
S
t
SU; STO
P
www.onsemi.com
5
ADT7476
0
M
TYPICAL PERFORMANCE CHARACTERISTICS
30
−10
−20
TEMPERATURE ERROR (°C)
−30
−40
−50
−60 0
246810
CAPACITANCE (nF)
12 14 16 18 20 22
Figure 3. Temperature Error vs. Capacitance
Between D+ and D−
30
TEMPERATURE ERROR (°C)
25
20
15
10
−5
5
0
40 mV
100M 200M 300M 400M 500M 600M
0
NOISE FREQUENCY (Hz)
100 mV
60 mV
Figure 5. Remote Temperature Error vs.
Common-Mode Noise Frequency
20
TEMPERATURE ERROR (°C)
10
0
−10
−20
−30
−40 0
D+ To GND
D+ To V
CC
20 40 60 80 100
LEAKAGE RESISTANCE (MW)
Figure 4. Remote Temperature Error vs. PCB
Resistance
70 60 50 40
TEMPERATURE ERROR (°C)
30 20 10
−10
40 mV
0
100M 200M 300M 400M 500M 600M
0
NOISE FREQUENCY (Hz)
100 mV
60 mV
Figure 6. Remote Temperature Error vs.
Differential-Mode Noise Frequency
1.20
1.18
1.16
1.14
1.12
1.10
(mA)
1.08
DD
I
1.06
1.04
1.02
1.00
0.98
3.0
Figure 7. Normal I
3.1 3.2 3.3 3.4 3.5 3.6 VDD (V)
B
vs. Power Supply Figure 8. Internal Temperature Error vs. Power
B
DD
www.onsemi.com
15
10
5
100 mV
0
250 mV
FREQUENCY (Hz)
TEMPERATURE ERROR (°C)
−5
−10
−15 100M 200M 300M 400M 500M 600
0
Supply Noise
6
ADT7476
TYPICAL PERFORMANCE CHARACTERISTICS (Cont’d)
6
TEMPERATURE ERROR (°C)
4 2 0
−2
−4
−6
−8
−10
−12
250 mV
100 mV
0
100M 200M 300M 400M 500M 600M
FREQUENCY (Hz)
Figure 9. Remote Temperature Error vs. Power
Supply Noise Frequency
3.0
2.5
2.0
1.5
1.0
0.5 0
−0.5
−1.0
TEMPERATURE ERROR (°C)
−1.5
−2.0
−40
3.0
2.5
2.0
1.5
1.0
0.5 0
−0.5
TEMPERATURE ERROR (°C)
−1.0
−1.5
−20 0 20 40 60 85 105 125
−40 OIL BATH TEMPERATURE (°C)
Figure 10. Internal Temperature Error vs. Temperature
−20 0 20 40 60 85 105 125 OIL BATH TEMPERATURE (°C)
Figure 11. Remote Temperature Error vs. Temperature
1.4
1.2
1.0
2.5 V Applied to 2.5 V Pin
0.8
0.6
TRIP POINT (V)
0.4
0.2
0
0
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 V
(V)
CCP
Figure 12. THERM Input Threshold vs. V
CCP
Voltage
www.onsemi.com
7
ADT7476
Product Description
The ADT7476 is a complete thermal monitor and multiple fan controller for any system requiring thermal monitoring and cooling. The device communicates with the system via a serial system management bus. The serial bus controller has a serial data line for reading and writing addresses and data (Pin 1), and an input line for the serial clock (Pin 2). All control and programming functions for the ADT7476 are performed over the serial bus. In addition, a pin can be reconfigured as an SMBALERT
output to signal
out-of-limit conditions.
Feature Comparisons Between ADT7476 and ADT7468
Dynamic T
, dynamic operating point, and
MIN
associated registers are no longer available in the ADT7476. The following related registers are gone:
Calibration Control 1 (0x36)Calibration Control 2 (0x37)Operating Point (0x33, 0x34, and 0x35)
Previously (in the ADT7468), T
of the automatic fan control algorithm. T
defined the slope
RANGE
RANGE
now
defines a true temperature range (in the ADT7476).
Acoustic filtering is now assigned to temperature zones,
not to fans. Available smoothing times have been increased for better acoustic performance.
Temperature measurements are now made with two
switching currents instead of three. SRC is not available in the ADT7476.
High frequency PWM can now be enabled/disabled on
each PWM output individually.
THERM can now be enabled/disabled on each
temperature channel individually.
The ADT7476 does not support full shutdown mode.
The ADT7476 offers increased temperature accuracy
on all temperature channels.
The ADT7476 defaults to twos complement
temperature measurement mode.
Some pins have swapped/added functions.
The powerup routine for the ADT7476 is simplified.
The ADT7476 has a higher maximum input voltage
TACH/PWM spec, supporting a wider range of fans.
V
CORE_LOW_ENABLE
has been reallocated to Bit 7 of
Configuration Register 1 (0x40).
Recommended Implementation
Configuring the ADT7476 as shown in Figure 13 allows
the system designer to use the following features:
Two PWM outputs for fan control of up to three fans
(the front and rear chassis fans are connected in parallel).
Three TACH fan speed measurement inputs.
V
measured internally through Pin 4.
CC
CPU temperature measured using Remote 1
temperature channel.
Remote temperature zone measured through Remote 2
temperature channel.
Local temperature zone measured through the internal
temperature channel.
Bidirectional THERM pin. This feature allows
®
Pentium®4 PROCHOT monitoring and can
Intel function as an overtemperature THERM alternatively be programmed as an SMBALERT interrupt output.
output. It can
system
FRONT
CHASSIS
FAN
REAR
CHASSIS
FAN
AMBIENT
TEMPERATURE
ADT7476
TACH2
PWM3 TACH3
D1+ D1−
V
CC
+5V +12VIN/VID5
Figure 13. ADT7476 Configuration
VID[0:4]/VID[0:5]
IN
GND
www.onsemi.com
PWM1
TACH1
D2+
D2−
THERM
SDA
SCL
SMBALERT
8
5(VRM9)/6(VRM10)
PROCHOT
ADT7476
Serial Bus Interface
Control of the ADT7476 is carried out using the serial system management bus (SMBus). The ADT7476 is connected to this bus as a slave device, under the control of a master controller. The ADT7476 has a 7-bit serial bus address. When the device is powered up with Pin 13 (PWM3/ADDREN
) high, the ADT7476 has a default SMBus address of 0101 1 10 or 0x2E. The read/write bit must be added to get the 8-bit address. If more than one ADT7476 is to be used in a system, each ADT7476 is placed in ADDR SELECT mode by strapping Pin 13 low on powerup. The logic state of Pin 14 then determines the device’s SMBus address. The logic of these pins is sampled on powerup.
The device address is sampled on powerup and latched on the first valid SMBus transaction, more precisely on the low-to-high transition at the beginning of the eighth SCL pulse, when the serial bus address byte matches the selected slave address. The selected slave address is chosen using the ADDREN
pin/ADDR SELECT pin. Any attempted
changes in the address have no effect after this.
Table 5. HARDWIRING THE ADT7476 SMBUS DEVICE ADDRESS
Pin 13 State Pin 14 State Address
0 0 1 Don’t Care 0101110 (0x2E)
Low (10 kW to GND) High (10 kW Pullup)
ADT7476
ADDR SELECT
PWM3/
ADDREN
ADDRESS = 0x2E
14
13
Figure 14. Default SMBus Address = 0x2E
ADT7476
ADDR SELECT
PWM3/
ADDREN
ADDRESS = 0x2C
14
13
Figure 15. SMBus Address = 0x2C (Pin 14 = 0)
ADT7476
ADDR SELECT
PWM3/
ADDR_EN
ADDRESS = 0x2D
14
13
Figure 16. SMBus Address = 0x2D (Pin 14 = 1)
V
V
CC
10 kW
CC
10 kW
10 kW
0101100 (0x2C) 0101101 (0x2D)
V
CC
ADT7476
ADDR SELECT
PWM3/
ADDREN
CARE SHOULD BE TAKEN TO ENSURE THAT PIN 13 (PWM3/ADDREN PIN 13 FLOATING COULD CAUSE THE ADT7476 TO POWER UP WITH AN UNEXPECTED ADDRESS.
NOTE THAT IF THE ADT7476 IS PLACED INTO ADDR SELECT MODE, PINS 13 AND 14 CANNOT BE USED AS THE ALTERNATE FUNCTIONS (PWM3, TACH4/THERM CIRCUIT IS MUXED IN AT THE CORRECT TIME OR DESIGNED TO HANDLE THESE DUAL FUNCTIONS.
) IS EITHER TIED HIGH OR LOW. LEAVING
10 kW
14
13
NC
DO NOT LEAVE ADDREN UNCONNECTED! CAN CAUSE UNPREDICTABLE ADDRESSES.
) UNLESS THE CORRECT
Figure 17. Unpredictable SMBus Address if Pin 13
is Unconnected
The ability to make hardwired changes to the SMBus slave address allows the user to avoid conflicts with other devices sharing the same serial bus, for example, if more than one ADT7476 is used in a system.
The serial bus protocol operates as follows:
1. The master initiates data transfer by establishing a start condition, which is defined as a high-to-low transition on the serial data line SDA while the serial clock line SCL remains high. This indicates that an address/data stream follows. All slave peripherals connected to the serial bus respond to the start condition and shift in the next eight bits, consisting of a 7-bit address (MSB first), plus a R/W
bit, which determine the direction of the data transfer, that is, whether data is written to or read from the slave device. The peripheral whose address corresponds to the transmitted address responds by pulling the data line low during the low period before the ninth clock pulse, known as the acknowledge bit. All other devices on the bus now remain idle while the selected device waits for data to be read from or written to it. If the R/W to the slave device. If the R/W
bit is a 0, the master writes
bit is a 1, the master
reads from the slave device.
2. Data is sent over the serial bus in sequences of nine clock pulses, eight bits of data followed by an acknowledge bit from the slave device. Transitions on the data line must occur during the low period of the clock signal and remain stable during the high period. A low-to-high transition, when the clock is high, can be interpreted as a stop signal. The number of data bytes transmitted over the serial bus in a single read or write operation is limited only by what the master and slave devices can handle.
3. When all data bytes have been read or written, stop conditions are established. In write mode, the master pulls the data line high during the 10
th
clock
www.onsemi.com
9
ADT7476
pulse to assert a stop condition. In read mode, the master device overrides the acknowledge bit by pulling the data line high during the low period before the ninth clock pulse. This is known as no acknowledge. The master then takes the data line low during the low period before the 10 pulse, and then high during the 10
th
clock
th
clock pulse to
assert a stop condition.
Any number of bytes of data can be transferred over the serial bus in one operation. However, it is not possible to mix read and write in one operation because the type of operation is determined at the beginning and cannot subsequently be changed without starting a new operation. In the ADT7476, write operations contain either one or two bytes, and read operations contain one byte.
To write data to one of the device data registers or read data from it, the address pointer register must be set so the correct data register is addressed. Then, data can be written into that register or read from it. The first byte of a write operation always contains an address stored in the address pointer register. If data is to be written to the device, then the write operation contains a second data byte that is written to the register selected by the address pointer register.
This write operation is illustrated in Figure 18. The device address is sent over the bus, and then R/W
is set to 0. This is followed by two data bytes. The first data byte is the address of the internal data register to be written to, which is stored in the address pointer register. The second data byte is the data to be written to the internal data register.
When reading d ata f rom a r egister , t here are t wo p ossibilities:
1. If the ADT7476’s address pointer register value is unknown, or not the desired value, then it must first be set to the correct value before data can be read from the desired data register. This is done by performing a write to the ADT7476 as before, but only the data byte containing the register address is sent, because no data is written to the register (see Figure 19). A read operation is then performed consisting of the serial bus address; R/W
bit set to 1, followed by the data byte read from the data register (see Figure 20.)
2. If the address pointer register is already known to be at the desired address, data can be read from the corresponding data register without first writing to the address pointer register (see Figure 20).
It is possible to read a data byte from a data register without first writing to the address pointer register, if the address pointer register is already at the correct value. However, it i s not possible to write data to a register without writing to the address pointer register, because the first data byte of a write is always written to the address pointer register.
In addition to supporting the send byte and receive byte protocols, the ADT7476 also supports t he read byte protocol. See Intel’s System Management Bus Specifications Revision 2 for more information.
If several read or write operations must be performed in succession, the master can send a repeat start condition instead of a stop condition to begin a new operation.
ACK. BY
ADT7476
9
ACK. BY
9
ACK. BY
MASTER
9
STOP BY MASTER
STOP BY MASTER
19
SCL
0
SDA
START BY MASTER
Figure 18. Writing a Register Address to the Address Pointer Register, then Writing Data to the Selected Register
1
SCL
SDA
START BY MASTER
0
10
SERIAL BUS ADDRESS BYTE
1011
SERIAL BUS ADDRESS BYTE
FRAME 1
1
1
FRAME 1
SCL (CONTINUED)
SDA (CONTINUED)
Figure 19. Writing to the Address Pointer Register Only
A1
A1
A0
A0
R/W
R/W
ACK. BY
ADT7476
ACK. BY
ADT7476
1
D7 D6 D5 D4 D3 D2 D1 D0
ADDRESS POINTER REGISTER BYTE
1
D7 D6 D5 D4 D3 D2 D1 D0
19
D6
D7
D5
ADDRESS POINTER REGISTER BYTE
FRAME 2
FRAME 3
DATA BYTE
D4
D3
FRAME 2
D2
D1
ADT7476
D0
www.onsemi.com
10
ADT7476
1
SCL
0
SDA
START BY MASTER
Write Operations
10
SERIAL BUS ADDRESS BYTE
1
1
FRAME 1
Figure 20. Reading Data from a Previously Selected Register
A1
A0
R/W
ACK. BY
ADT7476
The SMBus specification defines several protocols for different types of read and write operations. The ones used in the ADT7476 are discussed below. The following abbreviations are used in the diagrams:
S – START
P – STOP
R – READ
W– WRITE
A – ACKNOWLEDGE
A – NO ACKNOWLEDGE
The ADT7476 uses the following SMBus write protocols.
Send Byte
In this operation, the master device sends a single command byte to a slave device, as follows:
1. The master device asserts a start condition on SDA.
2. The master sends the 7-bit slave address followed by the write bit (low).
3. The addressed slave device asserts ACK on SDA.
4. The master sends a command code.
5. The slave asserts ACK on SDA.
6. The master asserts a stop condition on SDA, and the transaction ends.
For the ADT7476, the send byte protocol is used to write a register address to RAM for a subsequent single-byte read from the same address. This operation is illustrated in Figure 21.
231564
SLAVE
ADDRESS
Figure 21. Setting a Register Address for
Subsequent Read
If the master is required to read data from the register immediately after setting up the address, it can assert a repeat start condition immediately after the final ACK and carry out a single byte read without asserting an intermediate stop condition.
Write Byte
In this operation, the master device sends a command byte and one data byte to the slave device, as follows:
1. The master device asserts a start condition on SDA.
2. The master sends the 7-bit slave address followed by the write bit (low).
REGISTER
WASAP
ADDRESS
19
D7
D6
D4
D5
DATA BYTE FROM ADT7476
D3
FRAME 2
D2
D1
9
D0
NO ACK. BY
MASTER
STOP BY MASTER
3. The addressed slave device asserts ACK on SDA.
4. The master sends a command code.
5. The slave asserts ACK on SDA.
6. The master sends a data byte.
7. The slave asserts ACK on SDA.
8. The master asserts a stop condition on SDA, and the transaction ends.
This operation is illustrated in Figure 22.
23156784
SLAVE
ADDRESS
Figure 22. Single-byte Write to a Register
Read Operations
REGISTER
WA DATASAAP
ADDRESS
The ADT7476 uses the following SMBus read protocols.
Receive Byte
This operation is useful when repeatedly reading a single register. The register address is set up beforehand. In this operation, the master device receives a single byte from a slave device, as follows:
1. The master device asserts a start condition on SDA.
2. The master sends the 7-bit slave address followed by the read bit (high).
3. The addressed slave device asserts ACK on SDA.
4. The master receives a data byte.
5. The master asserts NO ACK on SDA.
6. The master asserts a stop condition on SDA, and the transaction ends.
In the ADT7476, the receive byte protocol is used to read a single byte of data from a register whose address has previously been set by a send byte or write byte operation. This operation is illustrated in Figure 23.
243156
SLAVE
ADDRESS
Figure 23. Single-byte Read from a Register
Alert Response Address
DATAARSAP
Alert response address (ARA) is a feature of SMBus devices, allowing an interrupting device to identify itself to the host when multiple devices exist on the same bus.
The SMBALERT output or an SMBALERT connected to a common SMBALERT
output can be used as either an interrupt
. One or more outputs can be
line connected to the
www.onsemi.com
11
ADT7476
master. If a device’s SMBALERT line goes low, the following procedure occurs:
1. SMBALERT
is pulled low.
2. The master initiates a read operation and sends the alert response address (ARA = 0001 100). This is a general call address that must not be used as a specific device address.
3. The device whose SMBALERT
output is low responds to the alert response address, and the master reads its device address. The address of this device is now known and can be interrogated per usual.
4. If more than one device’s SMBALERT
output is low, the one with the lowest device address has priority in accordance with normal SMBus arbitration.
5. Once the ADT7476 responds to the alert response address, the master must read the status registers, and SMBALERT
is cleared only if the error
condition goes away.
SMBus Timeout
The ADT7476 includes an SMBus timeout feature. If there is no SMBus activity for 35 ms, the ADT7476 assumes the bus is locked and releases the bus. This prevents the device from locking or holding the SMBus expecting data. Some SMBus controllers cannot handle the SMBus timeout feature, so if necessary, it can be disabled.
Table 6. CONFIGURATION REGISTER 1 (REG. 0X40)
Bit Description
[6] TODIS 0: SMBus Timeout Enabled (Default)
1: SMBus Timeout Disabled
Virus Protection
To prevent rogue programs or viruses from accessing critical ADT7476 register settings, the lock bit can be set. Setting Bit 1 of Configuration Register 1 (0x40) sets the lock bit and locks critical registers. In this mode, certain registers can no longer be written to until the ADT7476 is powered down and powered up again. For more information on which registers are locked see Table 49.
V oltage Measurement Input
The ADT7476 has four external voltage measurement channels. It can also measure its own supply voltage, V
CC
Pin 20 to Pin 23 can measure 5.0 V, 12 V, and 2.5 V supplies, and the processor core voltage V input). The V through the V
supply voltage measurement is carried out
CC
pin (Pin 4). The 2.5 V input can be used to
CC
(0 V to 3 V
CCP
monitor a chipset supply voltage in computer systems.
Analog-to-Digital Converter
All analog inputs are multiplexed into the on-chip, successive-approximation, analog-to-digital converter,
which has a resolution of 10 bits. The basic input range is 0 V to 2.25 V, but the inputs have built−in attenuators to allow measurement of 2.5 V, 3.3 V, 5.0 V, 12 V, and the processor core voltage V
without any external components. To
CCP
allow the tolerance of these supply voltages, the ADC produces an output of 3/4 full scale (768 dec or 300 hex) for the nominal input voltage, giving it adequate headroom to cope with overvoltages.
Input Circuitry
The internal structure for the analog inputs is shown in Figure 24 The input circuit consists of an input protection diode, an attenuator, plus a capacitor to form a first-order low-pass filter that gives input immunity to high frequency noise.
+12V
IN
+5V
IN
V
CC
+2.5V
IN
V
CCP
Figure 24. Structure of Analog Inputs
Table 7. VOLTAGE MEASUREMENT REGISTERS
Register Description Default
0x20 2.5 V Reading 0x00 0x21 V 0x22 VCC Reading 0x00
.
Voltage Limit Registers
0x23 5.0 V Reading 0x00 0x24 12 V Reading 0x00
183.6 kW
30 kW
93 kW
47 kW
68 kW
71 kW
45 kW
94 kW
17.5 kW
52.5 kW
Reading 0x00
CCP
30 pF
30 pF
30 pF
30 pF
35 pF
Associated with each voltage measurement channel is a high and low limit register . Exceeding the programmed high or low limit causes the appropriate status bit to be set. Exceeding either limit can also generate SMBALERT interrupts.
MUX
www.onsemi.com
12
ADT7476
Table 8. VOLTAGE LIMIT REGISTERS
Register Description Default
0x44 2.5 V Low Limit 0x00 0x45 2.5 V High Limit 0xFF 0x46 V 0x47 V 0x48 VCC Low Limit 0x00 0x49 VCC High Limit 0xFF 0x4A 5.0 V Low Limit 0x00
0x4B 5.0 V High Limit 0xFF 0x4C 12 V Low Limit 0x00 0x4D 12 V High Limit 0xFF
Low Limit 0x00
CCP
High Limit 0xFF
CCP
Table 13 shows the input ranges of the analog inputs and
output codes of the 10-bit ADC.
When the ADC is running, it samples and converts a voltage input in 0.7 ms and averages 16 conversions to reduce noise; a measurement takes nominally 11 ms.
Extended Resolution Registers
Voltage measurements can be made with higher accuracy using the extended resolution registers (0x76 and 0x77). Whenever the extended resolution registers are read, the corresponding data in the voltage measurement registers (0x20 to 0x24) is locked until their data is read. That is, if extended resolution is required, then the extended resolution register must be read first, immediately followed by the appropriate voltage measurement register.
Additional ADC Functions for Voltage Measurements
A number of other functions are available on the ADT7476 to of fer the system designer increased flexibility.
Turn-off Averaging
For each voltage/temperature measurement read from a value register, 16 readings have been made internally and the results averaged before being placed into the value register. When faster conversions are needed, setting Bit 4 of Configuration Register 2 (0x73) turns averaging off. This effectively gives a reading 16 times faster but the reading can be noisier. The default round robin cycle time takes
146.5 ms.
Bypass All Voltage Input Attenuators
Setting Bit 5 of Configuration Register 2 (0x73) removes
the attenuation circuitry from the 2.5 V, V
, VCC, 5.0 V,
CCP
and 12 V inputs. This allows the user to directly connect external sensors or rescale the analog voltage measurement inputs for other applications. The input range of the ADC without the attenuators is 0 V to 2.25 V.
Bypass Individual Voltage Input Attenuators
Bits [7:4] of Configuration Register 4 (0x7D) can be used
to bypass individual voltage channel attenuators.
Table 10. BYPASSING INDIVIDUAL VOLTAGE INPUT ATTENUATORS
Configuration Register 4 (0x7D)
Bit No. Channel Attenuated
[4] Bypass 2.5 V Attenuator [5] Bypass V [6] Bypass 5.0 V Attenuator [7] Bypass 12 V Attenuator
Table 11. CONFIGURATION REGISTER 2 (REG. 0X73)
Bit Description
[4] 1: Averaging Off [5] 1: Bypass Input Attenuators [6] 1: Single-channel Convert Mode
TACH1 Minimum High Byte (0x55)
Attenuator
CCP
[7:5] Selects ADC channel for single-channel convert m ode.
Single-channel ADC Conversion
While single-channel mode is intended as a test mode that can be used to increase sampling times for a specific channel, and therefore helps to analyze that channel’s performance in greater detail, it can also have other applications.
Setting Bit 6 of Configuration Register 2 (0x73) places the ADT7476 into single-channel ADC conversion mode. In this mode, the ADT7476 can only read a single voltage channel. The selected voltage input is read every 0.7 ms. The appropriate ADC channel is selected by writing to Bits [7:5] of the TACH1 minimum high byte register (0x55).
Table 9. CONVERSION TIME WITH AVERAGING DISABLED
Channel Measurement Time (ms)
Voltage Channels 0.7 Remote Temperature 1 7 Remote Temperature 2 7 Local Temperature 1.3
When Bit 7 of Configuration Register 6 (0x10) is set, the
default round robin cycle time increases to 240 ms.
www.onsemi.com
13
ADT7476
Table 12. PROGRAMMING SINGLE-CHANNEL ADC MODE
Bits [7:4], Register 0x55 Channel Selected (Note 1)
000 2.5 V 001 V 010 V 011 5.0 V 100 12 V 101 Remote 1 temperature 110 Local temperature 111 Remote 2 temperature
CCP CC
1. In the process of configuring single-channel ADC conversion
mode, the T ACH1 minimum high byte is also changed, possibly trading off TACH1 minimum high byte functionality with single-channel mode functionality.
www.onsemi.com
14
ADT7476
Table 13. 10-BIT ADC OUTPUT CODE VS. V
IN
Input Voltage ADC Output
12 V
IN
5.0 V
IN
VCC (3.3 VIN) 2.5 V
IN
V
CCP
VTT/I
MON
Decimal Binary (10 Bits)
<0.0156 <0.0065 <0.0042 <0.0032 <0.00293 <0.00220 0 00000000 00
0.0156 to
0.0312
0.0312 to
0.0469
0.0469 to
0.0625
0.0625 to
0.0781
0.0781 to
0.0937
0.0937 to
0.1093
0.1093 to
0.1250
0.1250 to
0.14060
0.0065 to
0.0130
0.0130 to
0.0195
0.0195 to
0.0260
0.0260 to
0.0325
0.0325 to
0.0390
0.0390 to
0.0455
0.0455 to
0.0521
0.0521 to
0.0586
0.0042 to
0.0085
0.0085 to
0.0128
0.0128 to
0.0171
0.0171 to
0.0214
0.0214 to
0.0257
0.0257 to
0.0300
0.0300 to
0.0343
0.0343 to
0.0386
0.0032 to
0.0065
0.0065 to
0.0097
0.0097 to
0.0130
0.0130 to
0.0162
0.0162 to
0.0195
0.0195 to
0.0227
0.0227 to
0.0260
0.0260 to
0.0292
0.0293 to
0.0058
0.0058 to
0.0087
0.0087 to
0.0117
0.0117 to
0.0146
0.0146 to
0.0175
0.0175 to
0.0205
0.0205 to
0.0234
0.0234 to
0.0263
0.00220 to
0.00440
0.00440 to 0,00660
0,00660 to
0.00881
0.00881 to
0.01100
0.01100 to
0.01320
0.01320 to
0.01541
0.01541 to
0.01761
0.01761 to
0.01981
1 00000000 01
2 00000000 10
3 00000000 11
4 00000001 00
5 00000001 01
6 00000001 10
7 00000001 11
8 00000010 00
4.0000 to
4.0156
1.6675 to
1.6740
1.1000 to
1.1042
0.8325 to
0.8357
0.7500 to
0.7529
0.5636 to
0.5658
256
(1/4 scale)
01000000 00
8.0000 to
8.0156
3.3300 to
3.3415
2.2000–2.204 2
1.6650 to
1.6682
1.5000 to
1.5029
1.1272 to
1.1294
512
(1/2 scale)
10000000 00
12.0000 to
12.0156
5.0025 to
5.0090
3.3000 to
3.3042
2.4975 to
2.5007
2.2500 to
2.2529
1.6809 to
1.6930
768
(3/4 scale)
11000000 00
15.8281 to
15.8437
15.8437 to
15.8593
15.8593 to
15.8750
15.8750 to
15.8906
15.8906 to
15.9062
15.9062 to
15.9218
15.9218 to
15.9375
15.9375 to
15.9531
15.9531 to
15.9687
15.9687 to
15.9843
6.5983 to
6.6048
6.6048 to
6.6113
6.6113 to
6.6178
6.6178 to
6.6244
6.6244 to
6.6309
6.6309 to
6.6374
6.6374 to
6.4390
6.6439 to
6.6504
6.6504 to
6.6569
6.6569 to
6.6634
4.3527 to
4.3570
4.3570 to
4.3613
4.3613 to
4.3656
4.3656 to
4.3699
4.3699 to
4.3742
4.3742 to
4.3785
4.3785 to
4.3828
4.3828 to
4.3871
4.3871 to
4.3914
4.3914 to
4.3957
3.2942 to
3.2974
3.2974 to
3.3007
3.3007 to
3.3039
3.3039 to
3.3072
3.3072 to
3.3104
3.3104 to
3.3137
3.3137 to
3.3169
3.3169 to
3.3202
3.3202 to
3.3234
3.3234 to
3.3267
2.9677 to
2.9707
2.9707 to
2.9736
2.9736 to
2.9765
2.9765 to
2.9794
2.9794 to
2.9824
2.9824 to
2.9853
2.9853 to
2.9882
2.9882 to
2.9912
2.9912 to
2.9941
2.9941 to
2.9970
2.2301 to
2.2323
2.2323 to
2.2346
2.2346 to
2.2368
2.2368 to
2.23899
2,23899 to
2.2412
2.2412 to
2.2434
2.2434 to
2.2456
2.2456 to
2.2478
2.2478 to
2.25
2.25 to
2.2522
1013 11111101 01
1014 11111101 10
1015 11111101 11
1016 11111110 00
1017 11111110 01
1018 11111110 10
1019 11111110 11
1020 11111111 00
1021 11111111 01
1022 11111111 10
>15.9843 >6.6634 >4.3957 >3.3267 >2.9970 >2.2522 1023 11111111 11
www.onsemi.com
15
ADT7476
VID Code Monitoring
The ADT7476 has five dedicated voltage ID (VID code) inputs. These are digital inputs that can be read back through the VID/GPIO register (0x43) to determine the processor voltage required or the system being used. Five VID code inputs support VRM9.x solutions. In addition, Pin 21 (12 V input) can be reconfigured as a sixth VID input to satisfy future VRM requirements.
VID/GPIO Register (0x43)
[0] = VID0, reflects logic state of Pin 5. [1] = VID1, reflects logic state of Pin 6. [2] = VID2, reflects logic state of Pin 7. [3] = VID3, reflects logic state of Pin 8. [4] = VID4, reflects logic state of Pin 19. [5] = VID5, reconfigurable 12 V input. This bit reads 0 when
Pin 21 is configured as the 12 V input. This bit reflects the logic state of Pin 21 when the pin is configured as VID5.
VID Code Input Threshold Voltage
The switching threshold for the VID code inputs is approximately 1.0 V. To enable future compatibility, it is possible to reduce the VID code input threshold to 0.6 V. Bit 6 (THLD) of the VID/GPIO register (0x43) controls the VID input threshold voltage.
VID/GPIO Register (0x43)
[6] THLD = 0, VID switching threshold = 1.0 V, V
< 0.8 V, VIH > 1.7 V, V
OL
MAX
= 3.3 V.
[6] THLD = 1, VID switching threshold = 0.6 V, V
< 0.4 V, VIH > 0.8 V, V
OL
Reconfiguring Pin 21 as VID5 Input
MAX
= 3.3 V.
Pin 21 can be reconfigured as a sixth VID code input (VID5) for VRM10 compatible systems. Because the pin is configured as VID5, it is not possible to monitor a 12 V supply.
Bit 7 of the VID/GPIO register (0x43) determines the function of Pin 21. System or BIOS software can read the state of Bit 7 to determine whether the system is designed to monitor 12 V or a sixth VID input.
VID/GPIO Register (0x43)
[7] VIDSEL = 0, Pin 21 functions as a 12 V measurement input. Software can read this bit to determine that there are five VID inputs being monitored. Bit 5 of VID/GPIO Register (0x43) always reads back 0. Bit 0 of Interrupt Status Register 2 (0x42) reflects 12 V out-of-limit measurements.
[7] VIDSEL = 1, Pin 21 functions as the sixth VID code input (VID5). Software can read this bit to determine that there are six VID inputs being monitored. Bit 5 of Register 0x43 reflects the logic state of Pin 21. Bit 0 of Interrupt Status Register 2 (0x42) reflects VID code changes.
VID Code Change Detect Function
The ADT7476 has a VID code change detect function. When Pin 21 is configured as the VID5 input, VID code changes are detected and reported back by the ADT7476. Bit 0 of Interrupt Status Register 2 (0x42) is the 12 V/VC bit and denotes a VID change when set. The VID code change bit is set when t he l ogic s tates o n the V ID i nputs a re d ifferent than they were 11 ms previously. The change of VID code is used to generate an SMBALERT SMBALER T
interrupt is n ot r equired, Bit 0 of Interrupt Mask
Register 2 (0x75), when set, prevents SMBALERT
interrupt. If an
s from
occurring on VID code changes.
Interrupt Status Register 2 (0x42)
[0] 12 V/VC = 0, if Pin 21 is configured as VID5, Logic 0 denotes no change in VID code within the last 11 ms.
[0] 12 V/VC = 1, if Pin 21 is configured as VID5, Logic 1 means that a change has occurred on the VID code inputs within the last 11 ms. An SMBALERT
is generated, if this
function is enabled.
Programming the GPIOs
The ADT7476 follows an upgrade path from the ADM1027 to the ADT7476. In order to maintain consistency between versions, it is necessary to omit references to GPIO5. As a result, there are six GPIOs as follows: GPIO0, GPIO1, GPIO2, GPIO3, GPIO4, and GPIO6.
Setting Bit 4 of Configuration Register 5 (0x7C) to 1 enables GPIO functionality. This turns all pins configured as VID inputs into general-purpose outputs. Writing to the corresponding VID bit in the VID/GPIO register (0x43) sets the polarity for the corresponding GPIO. GPIO6 can be programmed independently as, for example, an input or output, using Bits [3:2] of Configuration Register 5 (0x7C).
Temperature Measurement Method
Local Temperature Measurement
The ADT7476 contains an on-chip band gap temperature sensor whose output is digitized by the on-chip, 10-bit ADC. The 8-bit MSB temperature data is stored in the temperature registers (Addresses 0x25, 0x26, and 0x27). Because both positive and negative temperatures can be measured, the temperature data is stored in Offset 64 format or twos complement format, as shown in Table 14 and Table 15. Theoretically, the temperature sensor and ADC can measure temperatures from −63°C to +127°C (or −61°C to +191°C in the extended temperature range) with a resolution of 0.25°C. However, this exceeds the operating temperature range of the device, so local temperature measurements outside the ADT7476 operating temperature range are not possible.
www.onsemi.com
16
ADT7476
V
Table 14. TWOS COMPLEMENT TEMPERATURE DATA FORMA T
Temperature Digital Output (10-bit) (Note 1)
–128°C 1000 0000 00 (Diode Fault)
–50°C 1100 1110 00 –25°C 1110 0111 00 –10°C 1111 0110 00
0°C 0000 0000 00
+10.25°C 0000 1010 01
+25.5°C 0001 1001 10
+50.75°C 0011 0010 11
+75°C 0100 1011 00 +100°C 0110 0100 00 +125°C 0111 1101 00 +127°C 0111 1111 00
1. Bold numbers denote 2 LSB of measurement in the Extended Resolution Register 2 (0x77) with 0.25°C resolution.
Table 15. EXTENDED RANGE, TEMPERATURE DATA FORMAT
Temperature Digital Output (10-Bit) (Note 1)
–64°C 0000 0000 00 (Diode Fault)
–1°C 0011 1111 00
0°C 0100 0000 00
1°C 0100 0001 00 10°C 0100 1010 00 25°C 0101 1001 00 50°C 0111 0010 00 75°C 1000 1001 00
100°C 1010 0100 00 125°C 1011 1101 00 191°C 1111 1111 00
1. Bold numbers denote 2 LSB of measurement in the Extended Resolution Register 2 (0x77) with 0.25°C resolution.
Remote Temperature Measurement
The ADT7476 can measure the temperature of two remote diode sensors or diode-connected transistors connected to Pin 17 and Pin 18, or Pin 15 and Pin 16.
The forward voltage of a diode or diode-connected transistor operated at a constant current exhibits a negative temperature coefficient of about –2 mV/°C. Unfortunately, the absolute value of V
varies from device to device, and
BE
individual calibration is required to null this out. As a result, this technique is unsuitable for mass production. The technique used in the ADT7476 is to measure the change in V
when the device is operated at two different currents.
BE
This is given by:
DV
BE
+
kT
q
In(N
)
(eq. 1)
where:
k is the Boltzmann’s constant. q is the charge on the carrier. T is the absolute temperature in Kelvin. N is the ratio of the two currents.
Figure 25 shows the input signal conditioning used to measure the output of a remote temperature sensor. This figure shows the external sensor as a substrate transistor, which is provided on some microprocessors for temperature monitoring. It could also be a discrete transistor such as a 2N3904/2N3906.
If a discrete transistor is used, the collector is not grounded and is linked to the base. If a PNP transistor is used, the base is connected to the D– input and the emitter to the D+ input. If an NPN transistor is used, the emitter is connected to the D– input and the base to the D+ input. Figure 26 and Figure 27 show how to connect the ADT7476 to an NPN or PNP transistor for temperature measurement. T o prevent ground noise from interfering with the measurement, the more negative terminal of the sensor is not referenced to ground, but is biased above ground by an internal diode at the D– input.
CPU
REMOTE
SENSING
TRANSISTOR
= 65 kHz
f
C
DD
IN × I
THERMDA
THERMDC
D+
D−
BIAS
DIODE
Figure 25. Signal Conditioning for Remote Diode Temperature Sensors
I
BIAS
LOW-PASS FILTER
www.onsemi.com
17
V
OUT+
To ADC
V
OUT−
ADT7476
ADT7476
2N3904
NPN
Figure 26. Measuring Temperature by Using
an NPN Transistor
2N3906
PNP
Figure 27. Measuring Temperature by Using
a PNP Transistor
D+ D−
ADT7476
D+ D−
To measure DVBE, the sensor switches between operating currents of I and N × I. The resulting waveform passes through a 65 kHz low-pass filter to remove n oise and t hrough a chopper-stabilized amplifier. The amplifier performs the amplification and rectification of the waveform to produce a dc voltage p roportional to DV
. This v oltage i s m easured b y
BE
the ADC to give a temperature output in 10-bit, twos complement format. To further reduce the effects of noise, digital filtering is performed by averaging the results of 16 measurement cycles.
A remote temperature measurement takes nominally 38 ms. The results of remote temperature measurements are stored in 10-bit, twos complement format, as illustrated in Table10. The extra resolution for the temperature measurements is he l d i n t h e Extended Resolution Register 2 (0x77). This gives temperature readings with a resolution of
0.25°C.
Noise Filtering
For temperature sensors operating in noisy environments, previous practice placed a capacitor across the D+ pin and the D− pin to help combat the effects of noise. However, large capacitances affect the accuracy of the temperature measurement, leading to a recommended maximum capacitor value of 1,000 pF.
This capacitor reduces the noise but does not eliminate it, which makes using the sensor difficult in a very noisy environment. In most cases, a capacitor is not required because differential inputs by their very nature have a high immunity to noise.
Factors Affecting Diode Accuracy
Remote Sensing Diode
The ADT7476 is designed to work with substrate transistors built into processors or with discrete transistors. Substrate transistors are generally PNP types with the collector connected to the substrate. Discrete types can be either PNP or NPN transistors connected as a diode (base-shorted to the collector). If an NPN transistor is used, the collector and base are connected to D+ and the emitter to D−. If a PNP transistor is used, the collector and base are connected to D− and the emitter is connected to D+.
To reduce the error due to variations in both substrate and discrete transistors, a number of factors should be taken into consideration:
The ideality factor, n
, of the transistor is a measure of
f
the deviation of the thermal diode from ideal behavior. The ADT7476 is trimmed for an n
value of 1.008. Use
f
the following equation to calculate the error introduced at a temperature T (°C), when using a transistor whose
does not equal 1.008 (see the processor’s data sheet
n
f
for the n
values):
f
DT +(nf * 1.008
ǒ
)
273.15 K ) T
Ǔ
(eq. 2)
To factor this in, the user can write the DT value to the
offset register . The ADT7476 then automatically adds
it to or subtracts it from the temperature measurement.
Some CPU manufacturers specify the high and low
current levels of the substrate transistors. The high current level of the ADT7476, I the low level current, I
, is 11 mA. If the ADT7476
LOW
, is 180 mA, and
HIGH
current levels do not match the current levels specified by the CPU manufacturer, it could be necessary to remove an offset. The CPU’s data sheet advises whether this offset needs to be removed and how to calculate it. This offset can be programmed to the offset register. It is important to note that if more than one offset must be considered, then the algebraic sum of these offsets must be programmed to the offset register.
If a discrete transistor is used with the ADT7476, the best accuracy is obtained by choosing devices according to the following criteria:
Base-emitter voltage greater than 0.25 V at 11 mA, at
the highest operating temperature.
Base-emitter voltage less than 0.95 V at 180 mA,
at the lowest operating temperature.
Base resistance less than 100 W.
Small variation in the current gain, h
50 to 150) that indicates tight control of V characteristics.
Transistors, such as 2N3904, 2N3906, or equivalents in SOT−23 packages, are suitable devices to use.
Nulling Out Temperature Errors
As CPUs run faster, it is more difficult to avoid high frequency clocks when routing the D+/D– traces around a system board. Even when recommended layout guidelines are followed, some temperature errors can still be attributable to noise coupled onto the D+/D– lines. Constant high frequency noise usually attenuates, or increases, temperature measurements by a linear, constant value.
The ADT7476 has temperature offset registers (0x70 and 0x72) for the Remote 1 and Remote 2 temperature channels. By doing a one-time calibration of the system, the user can determine the offset caused by system board noise and null it out using the offset registers. The offset registers
, (approximately
FE
BE
www.onsemi.com
18
ADT7476
automatically add a twos complement 8-bit reading to every temperature measurement.
Changing Bit 1 of Configuration Register 5 (0x7C) changes the resolution and therefore, the range of the temperature of fset as either having a −63°C to +127°C range with a resolution of 1°C or having a −63°C to +64°C range with a resolution of 0.5°C. This temperature offset can be used to compensate for linear temperature errors introduced by noise.
Table 16. TEMPERATURE OFFSET REGISTERS
Register Description Default
0x70 Remote 1 Temperature Offset 0x00 (0°C) 0x71 Local Temperature Offset 0x00 (0°C) 0x72 Remote 2 Temperature Offset 0x00 (0°C)
ADT7463/ADT7476 Backwards Compatible Mode
By setting Bit 0 of Configuration Register 5 (0x7C), all temperature measurements a re s tored in t he z one t emperature reading registers ( 0x25, 0 x26, a nd 0 x27) i n t wos c omplement in the −63°C to +127°C range. The temperature limits must be reprogrammed in twos complement.
If a twos complement temperature below −63°C is entered, the temperature is clamped to −63°C. In this mode, the diode fault condition remains −128°C = 1000 0000, while in the extended temperature range ( − 6 3°C to +191°C), the fault condition is represented by −64°C = 0000 0000.
Table 17. TEMPERATURE READING REGISTERS
Register Description Default
0x25 Remote 1 Temperature − 0x26 Local Temperature − 0x27 Remote 2 Temperature − 0x77 Extended Resolution 2 0x00
Table 18. EXTENDED RESOLUTION TEMPERATURE MEASUREMENT REGISTER BITS
Bit Mnemonic Description
[7:6] TDM2 Remote2 Temperature LSBs [5:4] LTMP Local Temperature LSBs [3:2] TDM1 Remote 1 Temperature LSBs
Temperature Limit Registers
Associated with each temperature measurement channel are high and low limit registers. Exceeding the programmed high or low limit causes the appropriate status bit to be set. Exceeding either limit can also generate SMBALERT interrupts (depending on the way the interrupt mask register is programmed and assuming that SMBALERT
is set as an
output on the appropriate pin).
Table 19. TEMPERATURE LIMIT REGISTERS
Register Description Default
0x4E Remote 1 T emperature Low Limit 0x81 0x4F Remote 1 Temperature High Limit 0x7F 0x50 Local Temperature Low Limit 0x81 0x51 Local Temperature High Limit 0x7F 0x52 Remote 2 Temperature Low Limit 0x81 0x53 Remote 2 Temperature High Limit 0x7F
Reading Temperature from the ADT7476
It is important to note that temperature can be read from the ADT7476 as an 8-bit value (with 1°C resolution) or as a 10-bit value (with 0.25°C resolution). If only 1°C resolution is required, the temperature readings can be read back at any time and in no particular order.
If the 10-bit measurement is required, this involves a 2-register read for each measurement. Extended Resolution Register 2 (0x77) should be read first. This causes all temperature reading registers to be frozen until all temperature reading registers have been read from. This prevents an MSB reading from being updated while its two LSBs are being read and vice versa.
Additional ADC Functions for Temperature Measurement
A number of other functions are available on the ADT7476 to of fer the system designer increased flexibility.
Turn-off Averaging
For each temperature measurement read from a value register, 1 6readings have actually been made internally, an d the results averaged, before being placed into the value register. Sometimes it is necessary to take a very fast measurement. Setting Bit 4 of Configuration Register 2 (0x73) turns averaging off. The default round robin cycle time takes 146.5 ms.
Table 20. CONVERSION TIME WITH AVERAGING DISABLED
Channel Measurement Time (ms)
Voltage Channels 0.7 Remote Temperature 1 7 Remote Temperature 2 7 Local Temperature 1.3
When Bit 7 of Configuration Register 6 (0x10) is set, the default round robin cycle time increases to 240 ms.
Table 21. CONVERSION TIME WITH AVERAGING ENABLED
Channel Measurement Time (ms)
Voltage Channels 11 Remote Temperature 39 Local Temperature 12
www.onsemi.com
19
ADT7476
Single-channel ADC Conversions
Setting Bit 6 of Configuration Register 2 (0x73) places the ADT7476 into single-channel ADC conversion mode. In this mode, the ADT7476 can be made to read a single temperature channel only. The appropriate ADC channel is selected by writing to Bits [7:5] of the TACH1 minimum high byte register (0x55).
Table 22. PROGRAMMING SINGLE-CHANNEL ADC MODE FOR TEMPERATURES
Bits [7:5], Register 0x55 Channel Selected
101 Remote 1 Temperature 110 Local Temperature 111 Remote 2 Temperature
Table 23. CONFIGURATION REGISTER 2 (REG. 0X73)
Bit Description
[4] 1: Averaging Off [6] 1: Single-channel Convert Mode
TACH1 Minimum High Byte (0x55)
[7:5] selects ADC channel for single-channel convert mode.
Overtemperature Events
Overtemperature events on any of the temperature channels can be detected and dealt with automatically in automatic fan speed control mode. Register 0x6A to Register 0x6C are the THERM temperature exceeds its THERM
temperature limits. When a
temperature limit, all PWM outputs run at the maximum PWM duty cycle (Register 0x38, Register 0x39, and Register 0x3A). This effectively runs the fans at the fastest allowed speed.
The fans run at this speed until the temperature drops
below THERM
minus hysteresis. This can be disabled by setting Bit 2, the boost bit, in Configuration Register 3 (0x78). The hysteresis value for the THERM
temperature limit is the value programmed into the hysteresis registers (0x6D and 0x6E). The default hysteresis value is 4°C.
THERM LIMIT
TEMPERATURE
HYSTERESIS (°C)
Limits, Status Registers, and Interrupts
Limit Values
Associated with each measurement channel on the ADT7476 are high a nd l ow l imits. These c a n form t he b asis o f system status monitoring; a status bit can be set for any out-of-limit condition and is detected by polling the device. Alternatively, S MBALERT
interrupts c an b e g enerated t o f lag
out-of-limit conditions to a processor or microcontroller.
8-bit Limits
The following is a list of 8-bit limits on the ADT7476.
Table 24. VOLTAGE LIMIT REGISTERS
Register Description Default
0x44 2.5 V Low Limit 0x00 0x45 2.5 V High Limit 0xFF 0x46 V 0x47 V 0x48 VCC Low Limit 0x00 0x49 VCC High Limit 0xFF 0x4A 5.0 V Low Limit 0x00
0x4B 5.0 V High Limit 0xFF 0x4C 12 V Low Limit 0x00 0x4D 12 V High Limit 0xFF
Table 25. TEMPERATURE LIMIT REGISTERS
Register Description Default
0x4E Remote 1 T emperature Low Limit 0x81 0x4F Remote 1 Temperature High Limit 0x7F 0x6A Remote 1 THERM T emp. Limit 0x64 0x50 Local Temperature Low Limit 0x81 0x51 Local Temperature High Limit 0x7F 0x6B Local THERM Temperature Limit 0x64 0x52 Remote 2 Temperature Low Limit 0x81 0x53 Remote 2 Temperature High Limit 0x7F
0x6C Remote 2 THERM Temp. Limit 0x64
Table 26. THERM TIMER LIMIT REGISTER
Register Description Default
0x7A THERM Timer Limit 0x00
Low Limit 0x00
CCP
High Limit 0xFF
CCP
FANS
Figure 28. THERM Temperature Limit Operation
100%
THERM can be disabled on specific temperature channels using Bits [7:5] of Configuration Register 5 (0x7C). THERM
can also be disabled by:
Writing −64°C to the appropriate THERM temperature
limit in Offset 64 mode.
Writing −128°C to the appropriate THERM
temperature limit in twos complement mode.
www.onsemi.com
16-bit Limits
The fan TACH measurements are 16-bit results. The fan TACH limits are also 16 bits, consisting of a high byte and low byte. Because fans running under speed or stalled are normally the only conditions of interest, only high limits exist for fan TACHs. Because the fan TACH period is actually being measured, exceeding the limit indicates a slow or stalled fan.
20
ADT7476
Table 27. FAN LIMIT REGISTERS
Register Description Default
0x54 TACH1 Minimum Low Byte 0xFF 0x55 TACH1 Minimum High Byte 0xFF 0x56 TACH2 Minimum Low Byte 0xFF 0x57 TACH2 Minimum High Byte 0xFF 0x58 TACH3 Minimum Low Byte 0xFF 0x59 TACH3 Minimum High Byte 0xFF 0x5A TACH4 Minimum Low Byte 0xFF 0x5B TACH4 Minimum High Byte 0xFF
Out-of-Limit Comparisons
Once all limits have been programmed, the ADT7476 can be enabled for monitoring. The ADT7476 measures all voltage and temperature measurements in round robin format and sets the appropriate status bit for out-of-limit conditions. TACH measurements are not part of this round robin cycle. Comparisons are done differently depending on whether the measured value is being compared to a high or low limit.
(
5 11)) 12 )(2 39)+ 145 ms
(eq. 3)
High Limit: > Comparison Performed
Low Limit: Comparison Performed
Voltage and temperature channels use a window comparator for error detecting and, therefore, have high and low limits. Fan speed measurements use only a low limit. This fan limit is needed only in manual fan control mode.
Analog Monitoring Cycle Time
The analog monitoring cycle begins when a 1 is written to the start bit (Bit 0) of Configuration Register 1 (0x40). The ADC measures each analog input in turn, and, as each measurement is completed, the result is automatically stored in the appropriate value register. This round robin monitoring cycle continues unless disabled by writing a 0 to Bit 0 of Configuration Register 1.
As the ADC is normally left to free-run in this manner, the time taken to monitor all the analog inputs is normally not of interest, because the most recently measured value of any input can be read out at any time.
For applications where the monitoring cycle time is important, it can easily be calculated.
The total number of channels measured is:
Four Dedicated Supply Voltage Inputs
Supply Voltage (V
CC
Pin)
Local Temperature
Two Remote Temperatures
As mentioned previously, the ADC performs round robin conversions and takes 1 1 ms for each voltage measurement, 12 ms for a local temperature reading, and 39 ms for each remote temperature reading. The total monitoring cycle time for averaged voltage and temperature monitoring is, therefore, nominally:
www.onsemi.com
21
ADT7476
Fan T ACH measurements are made in parallel and are not synchronized with the analog measurements in any way.
Status Registers
The results of limit comparisons are stored in Interrupt Status Register 1 and Interrupt Status Register 2. The status register bit for each channel reflects the status of the last measurement and limit comparison on that channel. If a measurement is within limits, the corresponding s tatus register bit is cleared to 0. If the measurement is out-of-limits, the corresponding status register bit is set to 1.
The state of the various measurement channels can be polled by reading the status registers over the serial bus. In Bit 7 (OOL) of Interrupt Status Register 1 (0x41), 1 means an out-of-limit event has been flagged in Interrupt Status Register 2. This means the user also needs to read Interrupt Status Register 2. Alternatively, Pin 10 or Pin 14 can be configured as an SMBALERT
output. This hard interrupt automatically notifies the system supervisor of an out-of-limit condition. Reading the status registers clears the appropriate status bit as long as the error condition that caused the interrupt has cleared. Status register bits are sticky. Whenever a status bit is set, indicating an out-of-limit condition, it remains set even if the event that caused it has gone away (until read).
The only way to clear the status bit is to read the status register after the event has gone away. Interrupt mask registers (0x74 and 0x75) allow individual interrupt sources to be masked from causing an SMBALERT
. However, if o ne of these masked interrupt sources goes out-of-limit, its associated status bit is set in the status registers.
Table 28. INTERRUPT STATUS REGISTER 1 (0X41)
Bit Mnemonic Description
7 OOL 1 denotes a bit in Interrupt Status
6 R2T 1 indicates that the Remote 2
5 LT 1 indicates that the Local Temperature
4 R1T 1 indicates that the Remote 1
3 5.0 V 1 indicates that the 5.0 V High or Low
2 V
1 V
0 2.5 V 1 indicates that the 2.5 V High or Low
CC
CCP
Register 2 is set and Interrupt Status Register 2 should be read.
Temperature High or Low limit has been exceeded.
High or Low Limit has been exceeded.
Temperature High or Low Limit has been exceeded.
Limit has been exceeded. 1 indicates that the VCC High or Low
Limit has been exceeded. 1 indicates that the V
Limit has been exceeded.
Limit has been exceeded. If the 2.5 V input is configured as
THERM
, this bit represents the status of
THERM
.
High or Low
CCP
Table 29. INTERRUPT STATUS REGISTER 2 (0X42)
Bit Mnemonic Description
7 D2 1 indicates an open or short on
6 D1 1 indicates an open or short on
5 F4P 1 indicates Fan 4 has dropped below
4 FAN3 1 indicates that Fan 3 has dropped
3 FAN2 1 indicates that Fan 2 has dropped
2 FAN1 1 indicates that Fan 1 has dropped
1 OVT 1 indicates that a THERM
0 12 V/VC 1 indicates a 12 V high or low limit has
D2+/D2− inputs.
D1+/D1− inputs.
minimum speed. Alternatively, indicates that the THERM exceeded, if the THERM function is used. Alternatively, indicates the status of GPIO6.
below minimum speed.
below minimum speed.
below minimum speed.
overtemperature limit has been exceeded.
been exceeded. If the VID code change function is used, this bit indicates a change in VID code on the VID0 to VID4 inputs.
limit has been
SMBALERT Interrupt Behavior
The ADT7476 can be polled for status, or an SMBALERT interrupt can be generated for out-of-limit conditions. It is important to note how the SMBALERT
output and status
bits behave when writing interrupt handler software.
HIGH LIMIT
HIGH LIMIT
TEMPERATURE
TEMPERATURE
“STICKY”
“STICKY” STATUS BIT
STATUS BIT
SMBALERT
SMBALERT
TEMP BACK IN LIMIT (STATUS BIT STAYS SET)
CLEARED ON READ (TEMP BELOW LIMIT)
Figure 29. SMBALERT and Status Bit Behavior
Figure 29 shows how the SMBALERT output and sticky status bits behave. Once a limit is exceeded, the corresponding status bit is set to 1. The status bit remains set until the error condition subsides and the status register is read. The status bits are referred to as sticky because they remain set until read by software. This ensures that an out-of-limit event cannot be missed if the software is periodically polling the device.
www.onsemi.com
22
ADT7476
)
Note that:
The SMBALERT output remains low for the entire
duration that a reading is out-of-limit and until the status register has been read. This has implications on how software handles the interrupt.
THERM overtemperature events are not sticky. They
reset immediately after the overtemperature condition ceases.
Handling SMBALERT Interrupts
To prevent the system from being tied up servicing interrupts, it is recommend to handle the SMBALERT interrupt as follows:
1. Detect the SMBALERT
2. Enter the interrupt handler.
3. Read the status registers to identify the interrupt source.
4. Mask the interrupt source by setting the appropriate mask bit in the interrupt mask registers (0x74 and 0x75).
5. Take the appropriate action for a given interrupt source.
6. Exit the interrupt handler.
7. Periodically poll the status registers. If the interrupt status bit has cleared, reset the corresponding interrupt mask bit to 0. This causes
assertion.
the SMBALERT
output and status bits to behave
as shown in Figure 30.
HIGH LIMIT
TEMPERATURE
CLEARED ON READ
“STICKY” STATUS BIT
SMBALERT
TEMP BACK IN LIMIT (STATUS BIT STAYS SET)
INTERRUPT MASK BIT SET
(TEMP BELOW LIMIT
INTERRUPT MASK BIT
CLEARED
(SMBALERT
RE-ARMED)
Figure 30. How Masking the Interrupt Source Affects
SMBALERT
Output
Masking Interrupt Sources
Interrupt Mask Register 1 (0x74) and Interrupt Mask Register 2 (0x75) allow individual interrupt sources to be masked to prevent SMBALERT
NOTE: Masking an interrupt source prevents only the SMBALERT
output from being asserted; the appropriate status bit is set normally.
interrupts.
www.onsemi.com
23
ADT7476
Table 30. INTERRUPT MASK REGISTER 1 (REG. 0X74)
Bit Mnemonic Description
7 OOL 1 masks SMBALERT for any alert
6 R2T 1 masks SMBALERT for Remote 2
5 LT 1 masks SMBALERT for Local
4 R1T 1 masks SMBALERT for Remote 1
3 5.0 V 1 masks SMBALERT for the 5.0 V
2 V
1 V
0 2.5 V 1 masks SMBALERT for the
CC
CCP
condition flagged in Interrupt Status Register 2.
temperature.
temperature.
temperature.
channel. 1 masks SMBALERT for the V
channel. 1 masks SMBALERT for the V
channel.
2.5 V
/THERM channel.
IN
CC
CCP
Table 31. INTERRUPT MASK REGISTER 2 (REG. 0X75)
Bit Mnemonic Description
7 D2 1 masks SMBALERT for Diode 2 errors. 6 D1 1 masks SMBALERT for Diode 1 errors. 5 FAN4 1 masks SMBALERT for Fan 4 failure. If
4 FAN3 1 masks SMBALERT for Fan 3. 3 FAN2 1 masks SMBALERT for Fan 2. 2 FAN1 1 masks SMBALERT for Fan 1. 1 OVT 1 masks SMBALERT for
0 12 V/VC 1 masks SMBALERT for 12 V channel
the TACH4 pin is being used as the THERM
input, this bit masks SMBALERT for a THERM event. If the TACH4 pin is being used as GPIO6, setting this bit masks interrupts related to GPIO6.
overtemperature (exceeding THERM limits).
or for a VID code change, depending on the function used.
Enabling the SMBALERT Interrupt Output
The SMBALERT interrupt function is disabled by default. Pin 10 or Pin 14 can be reconfigured as an SMBALERT
output to signal out-of-limit conditions.
chooses the required functionality by setting Bit 0 and Bit 1 of Configuration Register 4 (0x7D).
If THERM
is enabled on Bit 1, Configuration Register 3
(0x78):
Pin 22 becomes THERM.
If Pin 14 is configured as THERM on Bit 0 and Bit 1 of
Configuration Register 4 (0x7D), THERM on this pin.
If THERM
is not enabled:
is enabled
Pin 22 becomes a 2.5 V measurement input.
If Pin 14 is configured as THERM, then THERM is
disabled on this pin.
Table 33. CONFIGURING PIN 14
Bit 1 Bit 0 Function
0 0 TACH4 0 1 THERM 1 0 SMBALERT 1
THERM as an Input
When THERM is configured as an input, the user can time assertions on the THERM connecting to the PROCHOT system performance.
When the THERM can also set up the ADT7476 to run the fans at 100%. The fans run at 100% for the duration of time that the THERM pin is pulled low. This is done by setting the BOOST bit (Bit 2) in Configuration Register 3 (0x78) to 1. This works only if the fan is already running, for example, in manual mode, when the current duty cycle is above 0x00, or in automatic mode when the temperature is above T
If the temperature is below T manual mode is set to 0x00, pulling the THERM externally has no effect. See Figure 31 for more information.
T
MIN
THERM
1 GPIO6
pin. This can be useful for
output of a CPU to gauge
pin is driven low externally, the user
.
MIN
or if the duty cycle in
MIN
low
Table 32. CONFIGURING PIN 10 AS SMBALERT OUTPUT
Register Bit Setting
Configuration Register 3 (0x78)
[1] Pin 10 = SMBALERT [0] Pin 10 = PWM2
Assigning THERM Functionality to a Pin
Pin 14 on the ADT7476 has four possible functions:
SMBALERT
, THERM, GPIO6, and TACH4. The user
www.onsemi.com
THERM ASSERTED TO LOW AS AN INPUT: FANS DO NOT GO TO 100% BECAUSE TEMPERATURE IS BELOW T
MIN
Figure 31. Asserting THERM Low as an Input in
Automatic Fan Speed Control Mode
24
THERM ASSERTED TO LOW AS AN INPUT: FANS GO TO 100% BECAUSE TEMPERATURE IS ABOVE T ALREADY RUNNING.
AND FANS ARE
MIN
ADT7476
THERM Timer
The ADT7476 has an internal timer to measure THERM assertion time. For example, the THERM input can be connected to the PROCHOT measure system performance. The THERM
output of a Pentium®4 CPU to
input can also
be connected to the output of a trip-point temperature sensor.
The timer is started on the assertion of the ADT7476’s THERM The timer counts THERM timer resumes counting on the next THERM THERM
input and stopped when THERM is de-asserted.
times cumulatively; that is, the
assertion. The
timer continues to accumulate THERM assertion times until the timer is read (where it is cleared), or until it reaches full scale. If the counter reaches full scale, it stops at that reading until cleared.
The 8-bit THERM so that Bit 0 is set to 1 on the first THERM the cumulative THERM
45.52 ms, Bit 1 of the THERM
timer status register (0x79) is designed
assertion. Once
assertion time has exceeded
timer is set and Bit 0 now becomes the LSB of the timer with a resolution of 22.76 ms (see Figure 32).
THERM
THERM
TIMER
(REG. 0x79)
THERM
10000000 01234567
THERM ASSERTED
22.76 ms
When using the THERM timer, be aware of the following: After a THERM
timer read (0x79)
1. The contents of the timer are cleared on read.
2. The F4P bit (Bit 5) of Interrupt Status Register 2 needs to be cleared (assuming that the THERM timer limit has been exceeded).
If the THERM
timer is read during a THERM assertion, the
following occurs:
1. The contents of the timer are cleared.
2. Bit 0 of the THERM THERM
assertion is occurring.
3. The THERM
4. If the THERM
timer is set to 1, because a
timer increments from zero.
timer limit register (0x7A) = 0x00,
the F4P bit is set.
Generating SMBALERT Interrupts from THERM Timer Events
The ADT7476 can generate SMBALERTs when a
programmable THERM
timer limit has been exceeded. This allows the system designer to ignore brief, infrequent THERM events. Register 0x7A is the THERM
assertions, while capturing longer THERM timer
timer limit register. This 8-bit register allows a limit from 0 sec (first THERM assertion) to 5.825 sec to be set before an SMBALERT is generated. The THERM contents of the THERM
timer value is compared with the
timer limit register. If the THERM timer value exceeds the THERM timer limit value, then the F4P bit (Bit 5) of Interrupt Status Register 2 is set and an SMBALERT
is generated.
ACCUMULATE THERM
ASSERTION TIMES
THERM
TIMER
(REG. 0x79)
THERM
ACCUMULATE THERM
ASSERTION TIMES
THERM
TIMER
(REG. 0x79)
Figure 32. Understanding the THERM Timer
LOW
01000000 01234567
THERM
LOW
10100000 01234567
THERM
(91.04 ms + 22.76 ms)
ASSERTED
45.52 ms
ASSERTED
113.8 ms
NOTE: Depending on which pins are configured as a THERM timer ,
setting the F4P bit (Bit 5) of Mask Register 2 (0x75) or Bit 0 of Mask Register 1 (0x74) masks out SMBALERT the F4P bit of Interrupt Status Register 2 is still set if the THERM
timer limit is exceeded.
; although
Figure 33 is a functional block diagram of the THERM timer, limit, and associated circuitry. Writing a value of 0x00 to the THERM SMBALERT A THERM SMBALERT
timer limit register (0x7A) causes an
to be generated on the first THERM assertion.
timer limit value of 0x01 generates an
once cumulative THERM assertions exceed
45.52 ms.
www.onsemi.com
25
ADT7476
2.914 s
1.457 s
THERM LIMIT
(REG. 0x7A)
Configuring the Relevant THERM Behavior
728.32 ms
364.16 ms
182.08 ms
91.04 ms
45.52 ms
22.76 ms
01234567 01234567
Figure 33. Functional Block Diagram of THERM Monitoring Circuitry
1. Configure the desired pin as the THERM timer input. Setting Bit 1 (THERM
timer enable) of Configuration Register 3 (0x78) enables the THERM
timer monitoring functionality. This is disabled on Pin 14 and Pin 22 by default. Setting Bit 0 and Bit 1 (PIN14FUNC) of Configuration Register 4 (0x7D) enables THERM timer output functionality on Pin 22 (Bit 1 of Configuration Register 3, THERM
, must also be
set). Pin 14 can also be used as TACH4.
2. Select the desired fan behavior for THERM events. Assuming the fans are running, setting Bit 2 (BOOST bit) of Configuration Register 3 (0x78) causes all fans to run at 100% duty cycle whenever THERM
is asserted. This allows fail-safe system cooling. If this bit is 0, the fans run at their current settings and are not affected by THERM the fans are not already running when THERM is asserted, then the fans do not run to full speed.
3. Select whether THERM generate SMBALERT
timer events should
interrupts. Setting Bit 5 (F4P) of Mask Register 2 (0x75) or Bit 0 of Mask Register 1 (0x74), depending on which pins are configured as a THERM timer, masks SMBALERT
s when the THERM timer limit value is exceeded. This bit should be cleared if SMBALERT
s based on THERM events are
required.
4. Select a suitable THERM
limit value.
This value determines whether an SMBALERT
COMPARATOR
timer
events. If
is
2.914 s
1.457 s
CLEARED
ON READ
OUTIN LATCH RESET
728.32 ms
364.16 ms
182.08 ms
91.04 ms
45.52 ms
22.76 ms
THERM
TIMER CLEARED ON READ
F4P BIT (BIT 5)
INTERRUPT STATUS
REGISTER 2
1 = MASK
F4P BIT (BIT 5)
MASK REGISTER 2
(REG. 0x75)
generated on the first THERM a cumulative THERM
THERM TIMER
(REG. 0x79)
THERM
SMBALERT
assertion, or if only
assertion time limit is exceeded. A value of 0x00 causes an SMBALERT to be generated on the first THERM assertion.
5. Select a THERM
monitoring time. This value specifies how often OS- or BIOS-level software checks the THERM BIOS can read the THERM determine the cumulative THERM If, for example, the total THERM
timer. For example,
timer once an hour to
assertion time.
assertion time is <22.76 ms in Hour 1, >182.08 ms in Hour 2, and >5.825 sec in Hour 3, system performance is degrading significantly because THERM asserting more frequently on an hourly basis. Alternatively, OS or BIOS level software can timestamp when the system is powered on. If an SMBALERT
is generated due to the THERM timer limit being exceeded, another timestamp can be taken. The difference in time can be calculated for a fixed THERM if it takes one week for a THERM
timer limit time. For example,
timer limit of
2.914 sec to be exceeded, and the next time it takes only 1 hour, then a serious degradation in system performance has occurred.
Configuring the THERM Pin as an Output
In addition to monitoring THERM as an input, the ADT7476 can optionally drive THERM When PROCHOT
is bidirectional, THERM can be used to
low as an output.
throttle the processor by asserting PROCHOT preprogram system-critical thermal limits. If the t emperature exceeds a t hermal limit by 0 .25°C, T HERM
asserts l ow . If t he
temperature is still above the thermal limit on the next
is
. The user can
www.onsemi.com
26
ADT7476
monitoring cycle, THERM stays low. THERM remains asserted low until the temperature is equal to or below the thermal limit. Because the temperature for that channel is measured only once for every monitoring cycle, after THERM
a sserts, i t i s g uaranteed t o remain l ow f or a t l east o ne
monitoring cycle.
The THERM Remote 1, local, or Remote 2 THERM are exceeded by 0.25°C. The THERM
pin can be configured to assert low, if the
temperature limits
temperature limit registers are at Register 0x6A, Register 0x6B, and Register 0x6C, respectively. Setting Bits [5:7] of Configuration Register 5 (0x7C) enables the THERM output feature for the Remote 1, local, and Remote 2 temperature channels, respectively. Figure 34 shows how the THERM
pin asserts
low as an output in the event of a critical overtemperature.
THERM LIMIT
0.255C
THERM
LIMIT
TEMP
THERM
MONITORING
CYCLE
Figure 34. Asserting THERM as an Output, Based on
Tripping THERM
Limits
An alternative method of disabling THERM is to program
the THERM
temperature limit to –63°C or less in Offset 64 mode, or −128°C or less in twos complement mode; that is, for THERM –128°C, respectively, THERM
Enabling and Disabling THERM on individual Channels
temperature limit values less than –63°C or
is disabled.
THERM can be enabled/disabled for individual or combinations of temperature channels using Bits [7:5] of Configuration Register 5 (0x7C).
THERM Hysteresis
Setting Bit 0 of Configuration Register 7 (0x11) disables THERM
(Bit 2 of Configuration Register 4, 0x7D), the THERM does not assert low when a THERM THERM
hysteresis.
If THERM
hysteresis is enabled and THERM is disabled
event occurs. If
hysteresis is disabled and THERM is disabled
pin
(Bit 2 of Configuration Register 4, 0x7D) and assuming the appropriate pin is configured as THERM asserts low when a THERM
If THERM THERM
and THERM hysteresis are both enabled, the
output asserts as expected.
event occurs.
), the THERM pin
Additionally, Bit 3 of Configuration Register 4 (0x7D)
can be used to select the PWM speed on a THERM
event
(100% or maximum PWM).
Bit 2 in Configuration Register 4 (0x7D) can be set to
disable THERM
Fan Drive Using PWM Control
events from affecting the fans.
The ADT7476 uses pulse-width modulation (PWM) to control fan speed. This relies on varying the duty cycle (or on/off ratio) of a square wave applied to the fan to vary the fan speed. The external circuitry required to drive a fan using PWM control is extremely simple. For 4-wire fans, the PWM drive might need only a pullup resistor. In many cases, the 4-wire fan PWM input has a built-in, pullup resistor.
The ADT7476 PWM frequency can be set to a selection of low frequencies or a single high PWM frequency. The low frequency options are used for 3-wire fans, while the high frequency option is usually used with 4-wire fans.
For 3-wire fans, a single N-channel MOSFET is the only drive device required. The specifications of the MOSFET depend on the maximum current required by the fan being driven and the input capacitance of the FET. Because a 10 kW (or greater) resistor must be used as a PWM pullup, an FET with large input capacitance can cause the PWM output to become distorted and adversely affect the fan control range. This is a requirement only when using high frequency PWM mode.
Typical notebook fans draw a nominal 170 mA, so SOT devices can be used where board space is a concern. In desktops, fans typically draw 250 mA to 300 mA each. If you drive several fans in parallel from a single PWM output or drive larger server fans, the MOSFET must handle the higher current requirements. The only other stipulation is that the MOSFET should have a gate voltage drive, V
< 3.3 V, for direct interfacing to the PWM output pin.
GS
The MOSFET should also have a low on resistance to ensure that there is not a significant voltage drop across the FET, which would reduce the voltage applied across the fan and, therefore, the maximum operating speed of the fan. Figure 35 shows how to drive a 3-wire fan using PWM control.
12 V12 V
10 kW
TACH
ADT7476
PWM
4.7 kW
10 kW
TACH
3.3 V
10 kW
12 V FAN
Q1 NDT3055L
1N4148
THERM Operation in Manual Mode
In manual mode, THERM events do not cause fans to go to full speed, unless Bit 3 of Configuration Register 6 (0x10) is set to 1.
www.onsemi.com
Figure 35. Driving a 3-wire Fan Using an N-channel
MOSFET
27
ADT7476
V
Figure 35 uses a 10 kW pullup resistor for the TACH signal. This assumes that the TACH signal is an open-collector from the fan. In all cases, the TACH signal from the fan must be kept below 5.5 V maximum to prevent damaging the ADT7476.
Figure 36 shows a fan drive circuit using an NPN transistor such as a general-purpose MMBT2222. While these devices are inexpensive, they tend to have much lower current handling capabilities and higher on resistance than MOSFETs. When choosing a transistor, care should be taken to ensure that it meets the fan’s current requirements. Ensure that the base resistor is chosen so that the transistor is saturated when the fan is powered on.
Because the fan drive circuitry in 4-wire fans is not switched on or off, as with previous PWM driven/powered fans, the internal drive circuit is always on and uses the PWM input as a signal instead of a power supply. This enables the internal fan drive circuit to perform better than 3-wire fans, especially for high frequency applications.
12 V12 V
10 kW
TACH
ADT7476
PWM
4.7 kW
10 kW
TACH
3.3 V
470 W
12 V FAN
Q1 MMBT2222
1N4148
Figure 36. Driving a 3-wire Fan Using
an NPN Transistor
Figure 37 shows a typical drive circuit for 4-wire fans.
12 V12 V
12 V , 4-WIRE FAN
V
CC
TACH PWM
TACH
ADT7476
PWM
4.7 kW
10 kW
10 kW
TACH
3.3 V
2 kW
Figure 37. Driving a 4-wire Fan
Driving Two Fans from PWM3
The ADT7476 has four TACH inputs available for fan speed measurement, but only three PWM drive outputs. If a fourth fan is being used in the system, it should be driven from the PWM3 output in parallel with the third fan. Figure 38 shows how to drive two fans in parallel using low cost NPN transistors. Figure 39 shows the equivalent circuit using a MOSFET.
Because the MOSFET can handle up to 3.5 A, users can connect another fan directly in parallel with the first. Care
should be taken in designing drive circuits with transistors and FETs to ensure that the PWM outputs are not required to source current, and that they sink less than the 5 mA maximum current specified on the data sheet.
Driving up to Three Fans from PWM3
TACH measurements for fans are synchronized to particular PWM channels; for example, TACH1 is synchronized to PWM1. TACH3 and TACH4 are both synchronized to PWM3, so PWM3 can drive two fans. Alternatively, PWM3 can be programmed to synchronize TACH2, TACH3, and TACH4 to the PWM3 output. This allows PWM3 to drive two or three fans. In this case, the drive circuitry looks the same, as shown in Figure 38 and Figure 39. The SYNC bit in Register 0x62 enables this function.
Synchronization is not required in high frequency mode when used with 4-wire fans.
T able 34. SYNC: ENHANCE ACOUSTICS REGISTER 1 (REG. 0X62)
Bit Mnemonic Description
[4] SYNC 1, Synchronizes TACH2, TACH3, and
3.3 V
ADT7476
1 kW
PWM3
2.2 kW
Figure 38. Interfacing Two Fans in Parallel to the
PWM3 Output Using Low Cost NPN Transistors
TACH4
3.3 V
ADT7476
TACH3
3.3 V
PWM3
Figure 39. Interfacing Two Fans in Parallel to the
PWM3 Output Using a Single N-channel MOSFET
3.3 V
10 kW TYP
10 kW TYP
10 kW TYP
3.3 V
TACH
TACH4 to PWM3.
TACH3
3.3 V Q1
MMBT3904
10 kW
10 kW
3.3 V
3.3 V
MMBT2222
+V
5 V or 12 V FAN
Q1 NDT3055L
1N4148
Q2 MMBT2222
Q3
1N4148
TACH
12 V
TACH4
3.3
+V
5 V or 12 V FAN
www.onsemi.com
28
ADT7476
5 V or12 V V
4)
2
PULLUP
PULLUP
Laying Out 3-wire Fans
Figure 40 shows how to lay out a common circuit
arrangement for 3-wire fans.
12 V or 5 V
R1
R2
TACH
R3
Q1 MMBT2222
Figure 40. Planning for 3-wire Fans on a PCB
TACH Inputs
Pin 9, Pin 11, Pin 12, and Pin 14 (when configured as TACH inputs) are high impedance inputs intended for fan speed measurement.
Signal conditioning in the ADT7476 accommodates the slow rise and fall times typical of fan tachometer outputs. The maximum input signal range is 0 V to 5.5 V, even though V
is 3.3 V. In the event that these inputs are
CC
supplied from fan outputs that exceed 0 V to 5.5 V, either resistive attenuation of the fan signal or diode clamping must be included to keep inputs within an acceptable range.
Figure 41 to Figure 44 show circuits for most common fan TACH outputs.
If the fan TACH output has a resistive pullup to V be connected directly to the fan input, as shown in Figure 41.
12 V
PULLUP
4.7 kW TYP
TACH OUTPUT
TACH
Figure 41. Fan with TACH Pullup to V
If the fan output has a resistive pullup to 12 V, or other voltage greater than 5.5 V, the fan output can be clamped with a Zener diode, as shown in Figure 42. The Zener diode voltage should be chosen so that it is greater than V TACH input but less than 5.5 V, allowing for the voltage tolerance of the Zener. A value between 5.0 V and 5.5 V is suitable.
1N4148
3.3 V or 5 V
R4
FAN SPEED
PWM
CC
V
CC
ADT7476
COUNTER
CC
IH
, it can
of the
12 V V
PULLUP
4.7 kW TYP
*CHOOSE ZD1 VOLTAGE APPROXIMATELY 0.8 × V
TACH OUTPUT
ZD1*
TACH
CC
ADT7476
FAN SPEED
COUNTER
CC
Figure 42. Fan with Strong TACH Pullup to > 5.5 V,
(for Example, 12 V) Clamped with Zener Diode
If the fan has a strong pullup (less than 1 kW) to 12 V or a totem-pole output, a series resistor can be added to limit the Zener current, as shown in Figure 43.
CC
FAN
R1
10 kW
PULLUP
TYP < 1 kW
OR TOTEM-POLE
*CHOOSE ZD1 VOLTAGE APPROXIMATELY 0.8 × V
TACH OUTPUT
TACH
ZD1* ZENER
Figure 43. Fan with Strong TACH. Pullup to > V
ADT7476
FAN SPEED
COUNTER
CC
CC
or Totem-Pole Output, Clamped with
Zener Diode and Resistor
Alternatively , a r e s istive attenuator can be used, as shown in Figure 44. R1 and R2 should be chosen such that:
V t V
R2ńǒR
) R1 ) R2Ǔt 5.5 V
(eq.
The fan inputs have an input resistance of nominally 160 kW to ground, which should be taken into account when calculating resistor values.
With a pullup voltage of 12 V and pullup resistor less than 1 kW, suitable values for R1 and R2 are 100 kW and 40 kW, respectively. This gives a high input voltage of 3.42 V.
12 V
< 1 kW
TACH OUTPUT
R1*
TACH
R2*
V
CC
ADT7476
FAN SPEED
COUNTER
*SEE TEXT
Figure 44. Fan with Strong TACH. Pullup to > VCC or
Totem-Pole Output, Attenuated with R1/R2
www.onsemi.com
29
ADT7476
The fan counter does not count the fan TACH output pulses directly because the fan speed could be less than 1,000 RPM, and it takes several seconds to accumulate a reasonably large and accurate count. Instead, the period of the fan revolution is measured by gating an on-chip 90 kHz oscillator into the input of a 16-bit counter for N periods of the fan TACH output (Figure 45), so the accumulated count is actually proportional to the fan tachometer period and inversely proportional to the fan speed.
N, the number of pulses counted, is determined by the settings of TACH pulses per revolution register (0x7B). This register contains two bits for each fan, allowing one, two (default), three, or four TACH pulses to be counted.
CLOCK
PWM
TACH
Fan Tachometer Reading Registers
1
2
3
4
Figure 45. Fan Speed Measurement
The fan tachometer readings are 16-bit values consisting of a 2-byte read from the ADT7476.
Table 35. FAN TACHOMETER READING REGISTERS
Register Description Default
0x28 TACH1 Low Byte 0x00
0x29 TACH1 High Byte 0x00 0x2A TACH2 Low Byte 0x00 0x2B TACH2 High Byte 0x00 0x2C TACH3 Low Byte 0x00 0x2D TACH3 High Byte 0x00 0x2E TACH4 Low Byte 0x00
0x2F TACH4 High Byte 0x00
Reading Fan Speed from the ADT7476
The measurement of fan speeds involves a 2-register read for each measurement. The low byte should be read first. This causes the high byte to be frozen until both high and low byte registers have been read, preventing erroneous TACH readings. The fan tachometer reading registers report back the number of 11.11 ms period clocks (90 kHz oscillator) gated to the fan speed counter from the rising edge of the first fan TACH pulse to the rising edge of the third fan TACH pulse (assuming two pulses per revolution are being counted).
Because the device is essentially measuring the fan TACH period, the higher the count value, the slower the fan is
actually running. A 16-bit fan tachometer reading of 0xFFFF indicates that either the fan has stalled or is running very slowly (<100 RPM).
High Limit: > Comparison Performed
Because the actual fan TACH period is being measured, falling below a fan TACH limit by 1 sets the appropriate status bit and can be used to generate an SMBALERT
.
Measuring fan TACH has the following caveat: When the ADT7476 starts up, TACH measurements are locked. In effect, an i nternal r ead of the low b yte h as b een m ade f or e ach TACH input. The net result of this is that all TACH readings are locked until the high byte is r ead f rom t he corresponding T ACH r egisters. A ll TACH r elated i nterrupts a re a lso i gnored until the appropriate high byte is read.
Once the corresponding high byte has been read, TACH measurements are unlocked and interrupts are processed as normal.
Fan TACH Limit Registers
The fan TACH limit registers are 16-bit values consisting of two bytes.
Table 36. FAN TACH LIMIT REGISTERS
Register Description Default
0x54 TACH1 Minimum Low Byte 0xFF 0x55 TACH1 Minimum High Byte 0xFF 0x56 TACH2 Minimum Low Byte 0xFF 0x57 TACH2 Minimum High Byte 0xFF 0x58 TACH3 Minimum Low Byte 0xFF
0x59 TACH3 Minimum High Byte 0xFF 0x5A TACH4 Minimum Low Byte 0xFF 0x5B TACH4 Minimum High Byte 0xFF
Fan Speed Measurement Rate
The fan TACH readings are normally updated once every
second.
When set, the FAST bit (Bit 3) of Configuration Register 3 (0x78) updates the fan TACH readings every 250 ms.
DC Bits
If any of the fans are not being driven by a PWM channel but are powered directly from 5.0 V or 12 V , their associated dc bit in Configuration Register 3 should be set. This allows TACH readings to be taken on a continuous basis for fans connected directly to a dc source. Once high frequency mode is enabled in 4-wire fans, the dc bits do not need to be set because this is automatically done internally.
Calculating Fan Speed
Assuming a fan with two pulses per revolution, and with the ADT7476 programmed to measure two pulses per revolution, fan speed is calculated by
www.onsemi.com
30
ADT7476
Fan Speed (RPM) = (90,000 × 60)/Fan TACH Reading
where Fan TACH Reading is the 16-bit fan tachometer reading.
Example:
TACH1 High Byte (0x29) = 0x17 TACH1 Low Byte (0x28) = 0xFF
What is Fan 1 speed in RPM?
Fan 1 TACH Reading = 0x17FF = 6143 (decimal) RPM = (f × 60)/Fan 1 TACH Reading RPM = (90,000 × 60)/6143 Fan Speed = 879 RPM
TACH Pulses per Revolution
Different fan models can output either one, two, three, or four TACH pulses per revolution. Once the number of fan TACH pulses has been determined, it can be programmed into the TACH Pulses per Revolution Register (0x7B) for each fan. Alternatively, this register can be used to determine the number of pulses per revolution output by a given fan. By plotting fan speed measurements at 100% speed with different pulses per revolution settings, the smoothest graph with the lowest ripple determines the correct pulses per revolution value.
Table 37. FAN PULSES/REVOLUTION REGISTER (REG. 0X7B)
Bit Mnemonic Description
[1:0] FAN1 Default 2 Pulses per Revolution [3:2] FAN2 Default 2 Pulses per Revolution [5:4] FAN3 Default 2 Pulses per Revolution [7:6] FAN4 Default 2 Pulses per Revolution
Table 38. FAN PULSES/REVOLUTION REGISTER BIT VALUES
Value Description
00 1 Pulse per Revolution 01 2 Pulses per Revolution 10 3 Pulses per Revolution 11 4 Pulses per Revolution
Fan Spin-up
The ADT7476 has a unique fan spin-up function. It spins the fan at 100% PWM duty cycle until two TACH pulses are detected on the TACH input. Once two TACH pulses have been detected, the PWM duty cycle goes to the expected running value, for example, 33%. Fans have different spin-up characteristics and take different times to overcome inertia. The advantage of the ADT7476 is that it runs the fans just fast enough to overcome inertia and is quieter on spin-up than fans that are programmed to spin up for a given time.
Fan Startup Timeout
To prevent the generation of false interrupts as a fan spins up (because it is below running speed), the ADT7476 includes a fan startup timeout function. During this time, the ADT7476 looks for two TACH pulses. If two TACH pulses are not detected, an interrupt is generated.
Fan startup timeout can be disabled by setting Bit 5 (FSPDIS) of Configuration Register 1 (0x40).
Table 39. PWM1 TO PWM3 CONFIGURATION (REG. 0X5C TO 0X5E)
Bit Mnemonic Description
[2:0] SPIN These bits control the startup
timeout for PWM1 (0x5C), PWM2 (0x5D), PWM3 (0x5E).
000 = No Startup Timeout 001 = 100 ms 010 = 250 ms (Default) 011 = 400 ms 100 = 667 ms 101 = 1 s 110 = 2 s 111 = 4 s
Disabling Fan Startup Timeout
Although fan startup makes fan spin-ups much quieter than fixed-time spin-ups, the option exists to use fixed spin-up times. Setting Bit 5 (FSPDIS) to 1 in Configuration Register 1 (0x 40 ) d i s a b l e s t h e s p i n - u p f o r t w o TACH pulses. Instead, the fan spins up for the fixed time as selected in Register 0x5C to Register 0x5E.
PWM Logic State
The PWM outputs can be programmed high for 100% duty cycle (non-inverted) or low for 100% duty cycle (inverted).
Table 40. PWM1 TO PWM3 CONFIGURATION (REG. 0X5C TO 0X5E) BITS
Bit Mnemonic Description
[4] INV 0 = logic high for 100% PWM duty cycle
1 = logic low for 100% PWM duty cycle
Low Frequency Mode PWM Drive Frequency
The PWM drive frequency can be adjusted for the application. Register 0x5F to Register 0x61 configure the PWM frequency for PWM1 to PWM3, respectively.
www.onsemi.com
31
ADT7476
Table 41. PWM FREQUENCY REGISTERS (REG. 0X5F TO 0X61)
Bit Mnemonic Description
[2:0] FREQ 000 = 11.0 Hz
High Frequency Mode PWM Drive
001 = 14.7 Hz 010 = 22.1 Hz 011 = 29.4 Hz 100 = 35.3 Hz (Default) 101 = 44.1 Hz 110 = 58.8 Hz 111 = 88.2 Hz
Setting Bit 3 of Register 0x5F, Register 0x60, and Register 0x61 enables high frequency mode for Fan 1, Fan 2, and Fan 3 respectively.
In high frequency mode, the PWM drive frequency is always 22.5 kHz. When high frequency mode is enabled, the dc bits are automatically asserted internally and do not need to be changed.
Fan Speed Control
The ADT7476 controls fan speed using automatic and manual modes:
In automatic fan speed control mode, fan speed is
automatically varied with temperature and without CPU intervention once initial parameters are set up. The advantage is that if the system hangs, the user is guaranteed that the system is protected from overheating.
In manual fan speed control mode, the ADT7476
allows the duty cycle of any PWM output to be adjusted manually. This can be useful if the user wants to change fan speed in software or adjust PWM duty cycle output for test purposes. Bits [7:5] of Register 0x5C to Register 0x5E (PWM Configuration) control the behavior of each PWM output.
Table 42. PWM CONFIGURATION (REG. 0X5C TO 0X5E) BITS
Bit Mnemonic Description
[7:5] BHVR 111 = Manual Mode
Once under manual control, each PWM output can be manually updated by writing to Register 0x30 to Register 0x32 (PWM current duty cycle registers).
Programming the PWM Current Duty Cycle Registers
The PWM current duty cycle registers are 8-bit registers that allow the PWM duty cycle for each output to be set anywhere from 0% to 100% in steps of 0.39%. The value to be programmed into the PWM
Value (decimal) = PWM
Example 1:
MIN
For a PWM duty cycle of 50%,
Value (decimal) = 50/0.39 = 128 (decimal)
register is given by:
MIN
/0.39
Value = 128 (decimal) or 0x80 (hex)
Example 2:
For a PWM duty cycle of 33%,
Value (decimal) = 33/0.39 = 85 (decimal) Value = 85 (decimal) or 0x54 (hex)
Table 43. PWM CURRENT DUTY CYCLE REGISTERS
Register Description Default
0x30 PWM1 Current Duty Cycle 0xFF (100%) 0x31 PWM2 Current Duty Cycle 0xFF (100%) 0x32 PWM3 Current Duty Cycle 0xFF (100%)
By reading the PWMx current duty cycle registers, the user can keep track of the current duty cycle on each PWM output, even when the fans are running in automatic fan speed control mode or acoustic enhancement mode.
Programming T
T
RANGE
PWM. For the ADT7467, A DT7468 a nd ADT7473, T
RANGE
defines the distance between T
and 100%
MIN
RANGE
is effectively a slope. For the ADT7475 andADT7476, T region where the PWM output l inearly ramps from P WM
is no longer a slope, but defines the temperature
RANGE
MIN
to 100% PWM.
PWM = 100%
PWM
MAX
PWM
MIN
PWM = 0%
Figure 46. T
Programming the Automatic Fan Speed Control Loop
T
RANGE
T
MIN
RANGE
To understand the automatic fan speed control loop more efficiently, it is recommended to use the ADT7476 evaluation board and software while reading this section.
This section provides the system designer with an understanding of the automatic fan control loop and provides step-by-step guidance on effectively evaluating and selecting critical system parameters. To optimize the system characteristics, the designer needs to give some thought to system configuration, including the number of fans, where they are located, and what temperatures are being measured in the particular system.
The mechanical or thermal engineer who is tasked with the system thermal characterization should also be involved at the beginning of the system development process.
www.onsemi.com
32
ADT7476
Manual Fan Control Overview
In unusual circumstances, it can be necessary to manually control the speed of the fans. Because the ADT7476 has an SMBus interface, a system can read back all necessary voltage, fan speed, and temperature information, and use this information to control the speed of the fans by writing to the PWM current duty cycle register (0x30, 0x31, and 0x32) of the appropriate fan. Bits [7:5] of the PWMx configuration registers (0x5C, 0x5D, 0x5E) are used to set fans up for manual control.
THERM Operation in Manual Mode
In manual mode, if the temperature increases above the programmed THERM
temperature limit, the fans automatically speed up to maximum PWM or 100% PWM, whichever way the appropriate fan channel is configured.
Automatic Fan Control Overview
The ADT7476 can automatically control the speed of fans based on the measured temperature. This is done independently of CPU intervention once initial parameters are set up.
The ADT7476 has a local temperature sensor and two remote temperature channels that can be connected to a CPU on-chip thermal diode (available on Intel
®
Pentium® class and other CPUs). These three temperature channels can be used as the basis for automatic fan speed control to drive fans using pulse-width modulation (PWM).
Automatic fan speed control reduces acoustic noise by
optimizing fan speed according to accurately measured
temperature. Reducing fan speed can also decrease system current consumption. The automatic fan speed control mode is very flexible due to the number of programmable parameters, including T T
values for a temperature channel and, therefore, for
RANGE
MIN
and T
RANGE
. The T
MIN
and
a given fan, are critical, because they define the thermal characteristics of the system. The thermal validation of the system is one of the most important steps in the design process, so these values should be selected carefully.
Figure 47 gives a top level overview of the automatic fan control circuitry on the ADT7476. From a systems level perspective, up to three system temperatures can be monitored and used to control three PWM outputs. The three PWM outputs can be used to control up to four fans. The ADT7476 allows the speed of four fans to be monitored. Each temperature channel has a thermal calibration block, allowing the designer to individually configure the thermal characteristics of each temperature channel. For example, designers can decide to run the CPU fan when CPU temperature increases above 60°C and a chassis fan when the local temperature increases above 45°C.
At this stage, the designer has not assigned these thermal calibration settings to a particular fan drive (PWM) channel. The right side of Figure 47 shows fan-specific controls. The designer has individual control over parameters such as minimum PWM duty cycle, fan speed failure thresholds, and even ramp control of the PWM outputs. Automatic fan control, then, ultimately allows graceful fan speed changes that are less perceptible to the system user.
www.onsemi.com
33
ADT7476
1
2
3
REMOTE1
TEMP
LOCAL
TEMP
REMOTE2
TEMP
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
T
RANGE
T
RANGE
T
RANGE
100%
0%
100%
0%
100%
0%
MUX
PWM
MIN
S
PWM
MIN
S
PWM
MIN
S
PWM
CONFIG
PWM
GENERATOR
TACHOMETER 1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER 2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER 3
AND 4
MEASUREMENT
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH
PWM2
TACH
PWM3
TACH
Figure 47. Automatic Fan Control Block Diagram
www.onsemi.com
34
ADT7476
Step 1 − Hardware Configuration
During system design, the motherboard sensing and control capabilities should be addressed early in the design stages. Decisions about how these capabilities are used should involve the system thermal/mechanical engineer. Ask the following questions:
1. What ADT7476 functionality is used?
PWM2 or SMBALERT?
TACH4 fan speed measurement or
overtemperature THERM
function?
2.5 V voltage monitoring or overtemperature
THERM
function?
12 V voltage monitoring or VID5 input?
The ADT7476 offers multifunctional pins that can be reconfigured to suit different system requirements and physical layouts. These multifunction pins are software programmable.
REMOTE1 =
AMBIENT TEMP
LOCAL =
VRM TEMP
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
T
RANGE
T
RANGE
T
RANGE
100%
0%
100%
MUX
0%
100%
0%
PWM
MIN
S
PWM
MIN
S
PWM
MIN
S
2. How many fans are supported in system, three or four? This influences the choice of whether to use the TACH4 pin or to reconfigure it for the THERM function.
3. Is the CPU fan to be controlled using the ADT7476, or will the CPU fan run at full speed 100% of the time? If run at 100%, this frees up a PWM output, but the system is louder.
4. Where will the ADT7476 be physically located in the system? This influences the assignment of the temperature measurement channels to particular system thermal zones. For example, locating the ADT7476 close to the VRM controller circuitry allows the VRM temperature to be monitored using the local temperature channel.
PWM
CONFIG
PWM
GENERATOR
TACHOMETER1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER3
AND 4
MEASUREMENT
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH1
CPU FAN SINK
PWM2
TACH2
FRONT CHASSIS
PWM3
TACH3
REMOTE2 =
CPU TEMP
Figure 48. Hardware Configuration Example
www.onsemi.com
35
REAR CHASSIS
ADT7476
Recommended Implementation 1
Configuring the ADT7476 as shown in Figure 49
provides the system designer with the following features:
Six VID inputs (VID0, VID1, VID2, VID3, VID4, and
VID6) for VRM10 support.
Two PWM outputs for fan control of up to three fans.
The front and rear chassis fans are connected in parallel.
Three TACH fan speed measurement inputs.
V
measured internally through Pin 4.
CC
CPU core voltage measurement (V
CORE
).
2.5 V measurement input used to monitor CPU current
(connected to V controller). This is used to determine CPU power consumption.
FRONT
CHASSIS
FAN
output of ADP316x VRM
COMP
TACH2
ADT7476
5.0 V measurement input.
VRM temperature using local temperature sensor.
CPU temperature measured using the Remote 1
temperature channel.
Ambient temperature measured through the Remote 2
temperature channel.
If not using VID5, it can be reconfigured as the 12 V
monitoring input.
Bidirectional THERM pin allows the monitoring of
PROCHOT example, or can be used as an overtemperature THERM output.
output from an Intel P4 processor, for
SMBALERT system interrupt output.
PWM1
TACH1
CPU FAN
REAR
CHASSIS
FAN
TEMPERATURE
AMBIENT
PWM3 TACH3
D1+ D1−
V
CC
+5V +12VIN/VID5
Figure 49. Recommended Implementation 1
VID[0:4]/VID[0:5]
THERM
SDA
SMBALERT
IN
GND
5(VRM9)/6(VRM10)
D2+
D2−
PROCHOT
SCL
CPU
ICH
www.onsemi.com
36
ADT7476
Recommended Implementation 2
Configuring the ADT7476 as shown in Figure 50
provides the system designer with the following features:
Six VID inputs (VID0, VID1, VID2, VID3, VID4, and
VID6) for VRM10 support.
Three PWM outputs for fan control of up to three fans.
All three fans can be individually controlled.
Three TACH fan speed measurement inputs.
V
measured internally through Pin 4.
CC
CPU core voltage measurement (V
CORE
).
2.5 V measurement input used to monitor CPU current
(connected to V controller). This is used to determine CPU power consumption.
FRONT
CHASSIS
FAN
REAR
CHASSIS
FAN
output of ADP316x VRM
COMP
TACH2 PWM2
PWM3 TACH3
5.0 V measurement input.
VRM temperature using local temperature sensor.
CPU temperature measured using the Remote 1
Ambient temperature measured through the Remote 2
If not using VID5, it can be reconfigured as the 12 V
Bidirectional THERM pin allows the monitoring of
ADT7476
TACH1
VID[0:4]/VID[0:5]
THERM
temperature channel.
temperature channel.
monitoring input.
PROCHOT
output/input from an Intel P4 processor, for example, or can be used as an overtemperature THERM
PWM1
output.
CPU FAN
5(VRM9)/6(VRM10)
D2+
D2−
PROCHOT
CPU
AMBIENT
TEMPERATURE
D1+ D1−
V
CC
+5V
IN
+12VIN/VID5
GND
Figure 50. Recommended Implementation 2
SDA
SCL
ICH
www.onsemi.com
37
ADT7476
Step 2 − Configuring the Mux
After the system hardware configuration is determined, the fans can be assigned to particular temperature channels. Not only can fans be assigned to individual channels, but the behavior of the fans is also configurable. For example, fans can be run under automatic fan control, manually (under software control), or at the fastest speed calculated by multiple temperature channels. The mux is the bridge between temperature measurement channels and the three PWM outputs.
Bits [7:5] (BHVR) of Register 0x5C, Register 0x5D, and Register 0x5E (PWM configuration registers) control the behavior of the fans connected to the PWM1, PWM2, and PWM3 outputs. The values selected for these bits determine how the mux connects a temperature measurement channel to a PWM output.
Automatic Fan Control Mux Options
[7:5] (BHVR), Register 0x5C, Register 0x5D, Register 0x5E.
000 = Remote 1 temperature controls PWMx 001 = Local temperature controls PWMx 010 = Remote 2 temperature controls PWMx 101 = Fastest speed calculated by local and Remote 2
temperature controls PWMx
110 = Fastest speed calculated by all three
temperature channels controls PWMx
The fastest speed calculated options pertain to controlling one PWM output based on multiple temperature channels. The thermal characteristics of the three temperature zones can be set to drive a single fan. An example would be the fan turning on when Remote 1 temperature exceeds 60°C or if the local temperature exceeds 45°C.
Other Mux Options
[7:5] (BHVR), R egister 0 x5C, R egister 0 x5D, R egister 0 x5E.
011 = PWMx runs full speed 100 = PWMx disabled (default) 111 = Manual mode. PWMx is running under
software control. In this mode, PWM current duty cycle registers (0x30 to 0x32) are writable and control the PWM outputs.
REMOTE1 =
AMBIENT TEMP
LOCAL =
VRM TEMP
REMOTE2 =
CPU TEMP
MUX
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
T
RANGE
T
RANGE
T
RANGE
100%
0%
100%
MUX
0%
100%
0%
PWM
MIN
S
PWM
MIN
S
PWM
MIN
S
PWM
CONFIG
PWM
GENERATOR
TACHOMETER1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER3
AND 4
MEASUREMENT
Figure 51. Assigning Temperature Channels to Fan Channels
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH1
CPU FAN SINK
PWM2
TACH2
FRONT CHASSIS
PWM3
TACH3
REAR CHASSIS
www.onsemi.com
38
ADT7476
Mux Configuration Example
This is an example of how to configure the mux in a system using the ADT7476 to control three fans. The CPU fan sink is controlled by PWM1, the front chassis fan is controlled by PWM2, and the rear chassis fan is controlled by PWM3. The mux is configured for the following fan control behavior:
PWM1 (CPU fan sink) is controlled by the fastest speed
calculated by the local (VRM temperature) and Remote 2 (processor) temperature. In this case, the CPU fan sink is also being used to cool the VRM.
PWM2 (front chassis fan) is controlled by the Remote 1
temperature (ambient).
PWM3 (rear chassis fan) is controlled by the Remote 1
temperature (ambient).
REMOTE2 =
CPU TEMP
LOCAL =
VRM TEMP
REMOTE1 =
AMBIENT TEMP
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
100%
0%
T
RANGE
T
RANGE
T
RANGE
MUX
100%
0%
100%
0%
Figure 52. Mux Configuration Example
Example Mux Settings
[7:5] (BHVR), PWM1 Configuration Register (0x5C).
101 = Fastest speed calculated by local and Remote 2
temperature controls PWM1
[7:5] (BHVR), PWM2 Configuration Register (0x5D).
000 = Remote 1 temperature controls PWM2
[7:5] (BHVR), PWM3 Configuration Register (0x5E).
000 = Remote 1 temperature controls PWM3
These settings configure the mux, as shown in Figure 52.
PWM
MIN
PWM
MIN
PWM
MIN
S
S
S
PWM
CONFIG
PWM
GENERATOR
TACHOMETER1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER3
AND 4
MEASUREMENT
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH1
PWM2
TACH2
PWM3
TACH3
CPU FAN SINK
FRONT CHASSIS
REAR CHASSIS
www.onsemi.com
39
ADT7476
Step 3 − T
Settings for Thermal Calibration
MIN
Channels
T
is the temperature at which the fans start to turn on
MIN
under automatic fan control. The speed at which the fan runs at T
is programmed later. The T
MIN
values chosen are
MIN
temperature channel specific, for example, 25°C for ambient channel, 30°C for VRM temperature, and 40°C for processor temperature.
T
is an 8-bit value, either twos complement or Offset
MIN
64, which can be programmed in 1°C increments. A T
MIN
register is associated with each temperature measurement channel: Remote 1, local, and Remote 2 temperature. Once the T
value is exceeded, the fan turns on and runs at the
MIN
minimum PWM duty cycle. The fan turns off once the temperature has dropped below T
MIN
− T
HYST
.
To overcome fan inertia, the fan is spun up until two valid TACH rising edges are counted. See the Fan Startup Timeout section for more details. In some cases, primarily for psycho-acoustic reasons, it is desirable that the fan never switch off below T
. Setting Bits [7:5] of Enhance
MIN
Acoustics Register 1 (0x62) keeps the fans running at the PWM minimum duty cycle if the temperature should fall below T
MIN
.
T able 44. T
REGISTERS
MIN
Register Description Default
0x67 Remote 1 Temperature T 0x68 Local Temperature T
MIN
0x69 Remote 2 Temperature T
MIN
MIN
0x5A (90°C) 0x5A (90°C) 0x5A (90°C)
Enhance Acoustics Register 1 (0x62)
Bit 7 (MIN3) = 0, PWM3 is off (0% PWM duty cycle) when temperature is below T
MIN
– T
HYST
.
Bit 7 (MIN3) = 1, PWM3 runs at PWM3 minimum duty cycle below T
MIN
– T
HYST
.
Bit 6 (MIN2) = 0, PWM2 is off (0% PWM duty cycle) when temperature is below T
MIN
– T
HYST
.
Bit 6 (MIN2) = 1, PWM2 runs at PWM2 minimum duty cycle below T
MIN
– T
HYST
.
Bit 5 (MIN1) = 0, PWM1 is off (0% PWM duty cycle) when temperature is below T
MIN
– T
HYST
.
Bit 5 (MIN1) = 1, PWM1 runs at PWM1 minimum duty cycle below T
MIN
– T
HYST
.
100%
PWM DUTY CYCLE
0%
REMOTE2 =
CPU TEMP
LOCAL =
VRM TEMP
REMOTE1 =
AMBIENT TEMP
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
T
RANGE
T
RANGE
T
RANGE
Figure 53. Understanding the T
100%
0%
100%
0%
100%
0%
MUX
PWM
MIN
S
PWM
MIN
S
PWM
MIN
S
PWM
CONFIG
PWM
GENERATOR
TACHOMETER1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER3
AND 4
MEASUREMENT
Parameter
MIN
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH1
CPU FAN SINK
PWM2
TACH2
FRONT CHASSIS
PWM3
TACH3
REAR CHASSIS
www.onsemi.com
40
ADT7476
Step 4 − PWM
PWM
MIN
for Each PWM (Fan) Output
MIN
is the minimum PWM duty cycle at which each fan in the system runs. It is also the start speed for each fan under automatic fan control once the temperature rises above T PWM fan used, the PWM
. For maximum system acoustic benefit,
MIN
should be as low as possible. Depending on the
MIN
setting is usually in the 20% to 33%
MIN
duty cycle range. This value can be found through fan validation.
100%
PWM
MIN
PWM DUTY CYCLE
0%
TEMPERATURE
Determines Minimum
Figure 54. PWM
PWM Duty Cycle
T
MIN
MIN
More than one PWM output can be controlled from a single temperature measurement channel. For example, Remote 1 temperature can control PWM1 and PWM2 outputs. If two dif ferent fans are used on PWM1 and PWM2, the fan characteristics can be set up differently. As a result, Fan 1 driven by PWM1 can have a different PWM
MIN
value than that of Fan 2 connected to PWM2. Figure 55 illustrates this as PWM1 minimum duty cycle of 20%, while PWM2
(front fan), which is turned on at a
MIN
(rear fan)
MIN
turns on at a minimum of 40% duty cycle. Note: Both fans turn on at exactly the same temperature, defined by T
100%
PWM2
PWM2
MIN
PWM1
MIN
PWM DUTY CYCLE
0%
T
MIN
Figure 55. Operating Two Different Fans from
a Single Temperature Channel
Programming the PWM Minimum Duty Cycle Registers
PWM1
TEMPERATURE
MIN
The PWM minimum duty cycle registers are 8-bit registers that allow the minimum PWM duty cycle for each output to be configured anywhere from 0% to 100%. This allows the minimum PWM duty cycle to be set in steps of
0.39%.
The value to be programmed into the PWM
register is
MIN
given by:
Value (decimal) = PWM
MIN
/0.39
Example 1:
For a minimum PWM duty cycle of 50%,
Value (decimal) = 50/0.39 = 128 (decimal) Value = 128 (decimal) or 80 (hex)
Example 2:
For a minimum PWM duty cycle of 33%,
Value (decimal) = 33/0.39 = 85 (decimal) Value = 85 (decimal) l or 54 (hex)
Table 45. PWM MINIMUM DUTY CYCLE REGISTERS
Register Description Default
0x64 PWM1 Minimum Duty Cycle 0x80 (50%) 0x65 PWM2 Minimum Duty Cycle 0x80 (50%) 0x66 PWM3 Minimum Duty Cycle 0x80 (50%)
Note on Fan Speed and PWM Duty Cycle
The PWM duty cycle does not directly correlate to fan speed in RPM. Running a fan at 33% PWM duty cycle does not equate to running the fan at 33% speed. Driving a fan at 33% PWM duty cycle actually runs the fan at closer to 50% of its full speed. This is because fan speed in %RPM generally relates to the square root of PWM duty cycle. Given a PWM square wave as the drive signal, fan speed in RPM approximates to:
% fanspeed + PWM Duty Cycle 10
Step 5 − PWM
PWM
is the maximum duty cycle that each fan in the
MAX
Ǹ
for PWM (Fan) Outputs
MAX
system runs at under the automatic fan speed control loop. For maximum system acoustic benefit, PWM as low as possible but should be capable of maintaining the
.
processor temperature limit at an acceptable level. If the THERM temperature limit is exceeded, the fans are still boosted to 100% for fail-safe cooling.
There is a PWM
limit for each fan channel. The
MAX
default value of this register is 0xFF and has no effect unless it is programmed.
100%
PWM
MAX
PWM
MIN
PWM DUTY CYCLE
0%
TEMPERATURE
Temperature Limit
Figure 56. PWM
Cycle Below the THERM
MAX
T
MIN
Determines Maximum PWM Duty
MAX
(eq. 5)
should be
www.onsemi.com
41
ADT7476
Programming the PWM Maximum Duty Cycle Registers
The PWM maximum duty cycle registers are 8-bit registers that allow the maximum PWM duty cycle for each output to be configured anywhere from 0% to 100%. This allows the maximum PWM duty cycle to be set in steps of
0.39%.
The value to be programmed into the PWM maximum duty cycle register is given by:
Value (decimal) = PWM
Example 1:
MAX
/0.39
For a maximum PWM duty cycle of 50%,
Value (decimal) – 50/0.39 = 128 (decimal) Value = 128 (decimal) or 80 (hex)
Example 2:
For a minimum PWM duty cycle of 75%,
Value (decimal) = 75/0.39 = 85 (decimal) Value = 192 (decimal) or C0 (hex)
Table 46. PWM MAXIMUM DUTY CYCLE REGISTERS
Register Description Default
0x38 PWM1 Maximum Duty Cycle 0xFF (100%) 0x39 PWM2 Maximum Duty Cycle 0xFF (100%) 0x3A PWM3 Maximum Duty Cycle 0xFF (100%)
example, 70°C is reached when the fans are running at 50% PWM duty cycle.
3. Determine the slope of the required control loop to meet these requirements.
4. Using the ADT7476 evaluation software, you can graphically program and visualize this functionality.
As PWM
is changed, the automatic fan control slope
MIN
changes.
100%
50% 33%
PWM DUTY CYCLE
0%
30°C
T
MIN
Figure 58. Adjusting PWM
Changes the Automatic
MIN
Fan Control Slope
As T
is changed, the slope changes. As T
RANGE
RANGE
gets smaller, the fans reach 100% speed with a smaller temperature change.
Step 6 − T
T
RANGE
fan control occurs once the programmed T has been e xceeded. T PWM
MIN
for Temperature Channels
RANGE
is the range of temperature over w hich a utomatic
temperature
MIN
is the t emperature range between
RANGE
and 100% PWM where the fan speed changes linearly. Otherwise stated, it is the line drawn between the T
MIN
/PWM
and the (T
MIN
MIN+TRANGE
)/PWM100%
intersection points.
T
RANGE
100%
PWM
MIN
PWM DUTY CYCLE
0%
TEMPERATURE
Figure 57. T
The T
RANGE
T
MIN
Parameter Affects Cooling Slope
RANGE
is determined by the following procedure:
1. Determine the maximum operating temperature for that channel (for example, 70°C).
2. Determine experimentally the fan speed (PWM duty cycle value) that does not exceed the temperature at the worst-case operating points. For
100%
10%
PWM DUTY CYCLE
0%
T
MIN−HYST
T
MIN
Figure 59. Increasing T
100%
MAX
PWM
10%
PWM DUTY CYCLE
0%
T
MIN−HYST
RANGE
Figure 60. Changing PWM
AFC Slope
30°C
40°C
45°C
54°C
Changes the AFC Slope
T
RANGE
Does Not Change the
MAX
www.onsemi.com
42
ADT7476
Selecting T
The T
RANGE
value can be selected for each temperature
RANGE
channel: Remote 1, local, and Remote 2 temperature. Bits [7:4] (T define the T
Table 47. SELECTING A T
1. Register 0x5F configures Remote 1 T configures local T T
RANGE
Actual Changes in PWM Output (Advanced Acoustics Settings)
RANGE
Bits [7:4] (Note 1) T
0000 2 0001 2.5 0010 3.33 0011 4 0100 5 0101 6.67 0110 8
0111 10 1000 13.33 1001 16 1010 20 1011 26.67 1100 32 (Default) 1101 40
1110 53.33
1111 80
.
) of Register 0x5F to Register 0x61
RANGE
value for each temperature channel.
VALUE
RANGE
RANGE
; Register 0x61 configures Remote 2
RANGE
RANGE
(5C)
; Register 0x60
While the automatic fan control algorithm describes the general response of the PWM output, it is also necessary to note that the enhance acoustics registers (0x62 and 0x63) can be used to set/clamp the maximum rate of change of PWM output for a given temperature zone. This means that if T
RANGE
is programmed with an AFC slope that is quite steep, a relatively small change in temperature could cause a large change in PWM output and possibly an audible change in fan speed, which can be noticeable/ bothersome to end users.
Decreasing the speed the PWM output changes by programming the smoothing on the appropriate temperature channels (Register 0x62 and Register 0x63) changes how fast the fan speed increases/decreases in the event of a temperature spike. The PWM duty cycle increases slowly
until the PWM duty cycle reaches the appropriate duty cycle as defined by the AFC curve.
Figure 61 shows PWM duty cycle vs. temperature for each T T
RANGE
setting. The lower graph shows how each
RANGE
setting affects fan speed vs. temperature. As can be
seen from the graph, the effect on fan speed is nonlinear.
100
90 80 70
60 50 40 30 20
PWM DUTY CYCLE (%)
10
0
0
20 40 60 80 100 120
TEMPERATURE ABOVE T
100
90 80 70
60 50 40 30 20
FAN SPEED (% OF MAX)
10
0
0
20 40 60 80 100 120
TEMPERATURE ABOVE T
Figure 61. T
RANGE
(Not PWM Drive) Profile
MIN
MIN
vs. Actual Fan Speed
25C
2.55C
3.335C
45C
55C
6.675C
85C
105C
13.35C
165C
205C
26.65C
325C
405C
53.35C
805C
25C
2.55C
3.335C
45C
55C
6.675C
85C
105C
13.35C
165C
205C
26.65C
325C
405C
53.35C
805C
The graphs in Figure 61 assume that the fan starts from 0% PWM duty cycle. Clearly, the minimum PWM duty cycle, PWM
, needs to be factored in to see how the loop
MIN
actually performs in the system. Figure 62 shows how T
is affected when the PWM
RANGE
value is set to 20%.
MIN
It can be seen that the fan actually runs at about 45% fan speed when the temperature exceeds T
MIN
.
www.onsemi.com
43
ADT7476
100
90 80 70
60 50 40 30 20
PWM DUTY CYCLE (%)
10
0
0
20 40 60 80 100 120
TEMPERATURE ABOVE T
100
90 80 70
60 50 40 30 20
FAN SPEED (% OF MAX)
10
0
0
20 40 60 80 100 120
TEMPERATURE ABOVE T
Figure 62. T
RANGE
PWM
MIN
MIN
and % Fan Speed Slopes with
= 20%
MIN
25C
2.55C
3.335C
45C
55C
6.675C
85C
105C
13.35C
165C
205C
26.65C
325C
405C
53.35C
805C
25C
2.55C
3.335C
45C
55C
6.675C
85C
105C
13.35C
165C
205C
26.65C
325C
405C
53.35C
805C
100
VRM TEMP.
90 80 70 60 50 40 30
PWM DUTY CYCLE (%)
20 10
0
0
10 20 30 40 50 60 70 80 90 100
CPU TEMPERATURE
AMBIENT TEMPERATURE
TEMPERATURE ABOVE T
100
VRM TEMP.
90 80 70 60 50 40 30 20
FAN SPEED (% MAX RPM)
10
0
0
10 20 30 40 50 60 70 80 90 100
CPU TEMPERATURE
AMBIENT TEMPERATURE
TEMPERATURE ABOVE T
Figure 63. T
and % Fan Speed Slopes for VRM,
RANGE
Ambient, and CPU Temperature Channels
MIN
MIN
Example: Determining T
for Each Temperature
RANGE
Channel
The following example shows how the different T T zones. In this example, the following T
settings can be applied to three different thermal
RANGE
RANGE
T T T
= 80°C for ambient temperature
RANGE
= 53.33°C for CPU temperature
RANGE
= 40°C for VRM temperature
RANGE
values apply:
MIN
and
This example uses the mux configuration described in Step 2 − Configuring the Mux with the ADT7476 connected as shown in Figure 52. Both CPU temperature and VRM temperature drive the CPU fan connected to PWM1. Ambient temperature drives the front chassis fan and rear chassis fan connected to PWM2 and PWM3. The front chassis fan is configured to run at PWM chassis fan is configured to run at PWM CPU fan is configured to run at PWM
= 20%. The rear
MIN
= 30%. The
MIN
= 10%.
MIN
Note: The control range for 4-wire fans is much wider than that of 3-wire fans. In many cases, 4-wire fans can start with a PWM drive of as little as 20% or less. In extreme cases, some 3-wire fans cannot run unless a PWM drive of 60% or more is applied.
Step 7 − T
T
THERM
for Temperature Channels
THERM
is the absolute maximum temperature allowed
on a temperature channel. Above this temperature, a component such as the CPU or VRM can operate beyond its safe operating limit. When the temperature measured exceeds T
, all fans are driven at 100% PWM duty
THERM
cycle (full speed) to provide critical system cooling.
The fans remain running at 100% until the temperature
drops below T
minus hysteresis, where hysteresis is
THERM
the number programmed into the hysteresis registers (0x6D and 0x6E). The default hysteresis value is 4°C.
The T
limit should be considered the maximum
THERM
worst-case operating temperature of the system. Because exceeding any T
limit runs all fans at 100%, it has
THERM
very negative acoustic effects. Ultimately, this limit should be set up as a fail-safe, and users should ensure that it is not exceeded under normal system operating conditions.
Note: T
limits are nonmaskable and affect the fan
THERM
speed no matter how automatic fan control settings are configured. This allows some flexibility, because a T
RANGE
value can be selected based on its slope, while a hard limit (such as 70°C), can be programmed as T
MAX
(the
www.onsemi.com
44
ADT7476
temperature at which the fan reaches full speed) by setting T
THERM Hysteresis
to that limit (for example, 70°C).
THERM
Table 48. THERM LIMIT REGISTERS
Register Description Default
0x6A Remote 1 THERM Limit 0x64 (100°C) 0x6B Local THERM Limit 0x64 (100°C) 0x6C Remote 2 THERM Limit 0x64 (100°C)
THERM hysteresis on a particular channel is configured via the hysteresis settings (Register 0x6D and Register 0x6E). For example, setting hysteresis on the Remote 1 channel also sets the hysteresis on Remote 1 THERM
.
T
RANGE
100%
PWM DUTY CYCLE
0%
Hysteresis Registers
Register 0x6D, Remote 1, Local Temperature Hysteresis
[7:4], Remote 1 temperature hysteresis (4°C default). [3:0], Local temperature hysteresis (4°C default).
Register 0x6E, Remote 2 Temperature Hysteresis
[7:4], Remote 2 temperature hysteresis (4°C default).
Because each hysteresis setting is four bits, hysteresis values are programmable from 1°C to 15°C. It is not recommended to program hysteresis values to 0°C, because this disables hysteresis. In effect, this causes the fans to cycle (during a THERM speed, or, while operating close to T
event) between normal speed and 100%
, between normal
MIN
speed and off, creating unsettling acoustic noise.
REMOTE2 =
CPU TEMP
LOCAL =
VRM TEMP
REMOTE1 =
AMBIENT TEMP
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
T
RANGE
T
RANGE
T
RANGE
Figure 64. How T
T
THERM
100%
0%
100%
0%
100%
0%
PWM
MIN
PWM
MIN
MUX
PWM
MIN
Relates to Automatic Fan Control
THERM
S
S
S
PWM
CONFIG
PWM
GENERATOR
TACHOMETER1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER3
AND 4
MEASUREMENT
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH1
CPU FAN SINK
PWM2
TACH2
FRONT CHASSIS
PWM3
TACH3
REAR CHASSIS
www.onsemi.com
45
ADT7476
Step 8 − T
T
HYST
the temperature measured has dropped back below T
for Temperature Channels
HYST
is the amount of extra cooling a fan provides after
MIN
before the fan turns off. The premise for temperature hysteresis (T
) is that without it, the fan would merely
HYST
chatter, or cycle on and off regularly, whenever the temperature hovers around the T
The T
value chosen determines the amount of time
HYST
MIN
setting.
needed for the system to cool down or heat up as the fan is turning on and of f. Values of hysteresis are programmable in the range 1°C to 15°C. Larger values of T fans from chattering on and off. The T
HYST
prevent the
HYST
default value is
set at 4°C.
The T
setting applies not only to the temperature
HYST
hysteresis for fan on/off, but the same setting is used for the
T
RANGE
100%
PWM DUTY CYCLE
0%
T
hysteresis value, described in Step 6 − T
THERM
RANGE
for Temperature Channels. Therefore, programming Register 0x6D and Register 0x6E sets the hysteresis for both fan on/off and the THERM
function.
In some applications, it is required that fans not turn off
below T
but remain running at PWM
MIN
. Bits [7:5] of
MIN
Enhance Acoustics Register 1 (0x62) allow the fans to be turned off o r t o b e kept spinning below T always on, the T temperature drops below T
THERM Hysteresis
value has no ef fect on the fan when the
HYST
.
MIN
. If the fans are
MIN
Any hysteresis programmed via Register 0x6D and Register 0x6E also applies hysteresis on the appropriate THERM
channel.
REMOTE2 =
CPU TEMP
LOCAL =
VRM TEMP
REMOTE1 =
AMBIENT TEMP
Figure 65. The T
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
THERMAL CALIBRATION
T
MIN
T
RANGE
T
RANGE
T
RANGE
Value Applies to Fan On/Off Hysteresis and THERM Hysteresis
HYST
T
THERM
100%
0%
100%
0%
100%
0%
MUX
PWM
MIN
PWM
MIN
PWM
MIN
S
S
S
PWM
CONFIG
PWM
GENERATOR
TACHOMETER1 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER2 MEASUREMENT
PWM
CONFIG
PWM
GENERATOR
TACHOMETER3
AND 4
MEASUREMENT
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
RAMP
CONTROL
(ACOUSTIC
ENHANCEMENT)
PWM1
TACH1
CPU FAN SINK
PWM2
TACH2
FRONT CHASSIS
PWM3
TACH3
REAR CHASSIS
www.onsemi.com
46
ADT7476
Enhance Acoustics Register 1 (0x62)
Bit 7 (MIN3) = 0, PWM3 is off (0% P WM duty c ycle) when temperature is below T
MIN
− T
HYST
.
Bit 7 ( MIN3) = 1, PWM3 r uns at PWM3 minimum d uty cycle below T
MIN
− T
HYST
.
Bit 6 (MIN2) = 0, PWM2 is off (0% P WM duty c ycle) when temperature is below T
MIN
− T
HYST
.
Bit 6 ( MIN2) = 1, PWM2 r uns at PWM2 minimum d uty cycle below T
MIN
− T
HYST
.
Bit 5 (MIN1) = 0, PWM1 is off (0% P WM duty c ycle) when temperature is below T
MIN
− T
HYST
.
Bit 5 ( MIN1) = 1, PWM1 r uns at PWM1 minimum d uty cycle below T
Configuration Register 6 (0x10)
MIN
− T
HYST
.
[0] SLOW = 1, slows the ramp rate for PWM changes associated with t he R emote 1 t e mperature c hannel b y a f actor of 4.
[1] SLOW = 1, slows the ramp rate for PWM changes associated with the local temperature channel by a factor of 4.
[2] SLOW = 1, slows the ramp rate for PWM changes associated with t he R emote 2 t e mperature c hannel b y a f actor of 4.
[7] ExtraSlow = 1 , s lows t he ra mp r ate f or a ll f ans b y a f actor of 39.2%.
The following sections list the ramp-up times when
enhanced acoustics is enabled for each temperature channel.
Enhance Acoustics Register 1 (0x62)
[2:0] ACOU selects the ramp rate for PWM outputs associated with the Remote Temperature 1 input.
000 = 37.5 sec 001 = 18.8 sec 010 = 12.5 sec 011 = 7.5 sec 100 = 4.7 sec 101 = 3.1 sec 110 = 1.6 sec 111 = 0.8 sec
Enhance Acoustics Register 2 (0x63)
[2:0] ACOU3 selects the ramp rate for PWM outputs associated with the local temperature channel.
000 = 37.5 sec 001 = 18.8 sec 010 = 12.5 sec 011 = 7.5 sec 100 = 4.7 sec 101 = 3.1 sec 110 = 1.6 sec 111 = 0.8 sec
[6:4] ACOU2 selects the ramp rate for PWM outputs associated with the Remote Temperature 2 input.
000 = 37.5 sec 001 = 18.8 sec 010 = 12.5 sec 011 = 7.5 sec 100 = 4.7 sec 101 = 3.1 sec 110 = 1.6 sec 111 = 0.8 sec
When Bit 7 of Configuration Register 6 (0x10) = 1, the above ramp rates change to the values below.
000 = 52.2 sec 001 = 26.1 sec 010 = 17.4 sec 011 = 10.4 sec 100 = 6.5 sec 101 = 4.4 sec 110 = 2.2 sec 111 = 1.1 sec
Setting the appropriate slow bit [2:0] of Configuration Register 6 (0x10) s lows t he r amp rate further by a f actor o f 4 .
Fan Presence Detect
This feature is used to determine if a 4-wire fan is directly connected to a PWM output. This feature does not work for 3-wire fans. To detect whether a 4-wire fan is connected directly to a PWM output, the following must be performed in this order:
1. Drive the appropriate PWM outputs to 100% duty cycle.
2. Set Bit 0 of Configuration Register 2 (0x73).
3. Wait 5 ms.
4. Program fans to run at a different speed if necessary.
5. Read the state of Bits [3:1] of Configuration Register 2 (0x73). The state of these bits reflects whether a 4-wire fan is directly connected to the PWM output.
As the detection time only takes 5 ms, programming the PWM outputs to 100% and then back to its normal speed is not noticeable in most cases.
How Fan Presence Detect Works
4-wire fans typically have an internal pull up to 4.75 V ±10%, which typically sources 5 mA. While the detection cycle is on, an internal current sink is turned on, which sinks current from the fan’ s internal pullup. By driving some of the current from the fan’s internal pullup (~100 mA) the logic buffer switches to a defined logic state. If this state is high, a fan is present; if the state is low, no fan is present.
Note: The PWM input voltage should be clamped to 3.3 V. This ensures the PWM output is not pulled to a voltage higher than the maximum allowable voltage on that pin (5.5 V).
www.onsemi.com
47
ADT7476
Fan Sync
When two ADT7476s are used in a system, it is possible to synchronize them so that one PWM channel from each device can be effectively OR’ed together to create a PWM output that reflects the maximum speed of the two OR’ed PWMs. This OR’ed PWM can in turn be used to drive a chassis fan.
Standby Mode
The ADT7476 has been specifically designed to respond to the STBY supply. In computers that support S3 and S5 states, the core voltage of the processor is lowered in these states. When monitoring THERM
, the THERM timer
should be disabled during these states.
When the V
voltage drops below the V
CCP
low limit,
CCP
the following occurs:
1. Status Bit 1 (V
) in Interrupt Status Register 1
CCP
is set.
2. SMBALERT
3. THERM
is generated, if enabled.
monitoring is disabled. The THERM timer should hold its value prior to the S3 or S5 state.
Once the core voltage, V
, goes above the V
CCP
CCP
low limit, everything is re-enabled and the system resumes normal operation.
Figure 66 shows the signals that are exercised in the
XNOR tree test mode.
VID0 VID1
VID2
VID3
VID4
TACH1
TACH2
TACH3
TACH4
PWM2
PWM3
Figure 66. XNOR Tree Test
PWM1/XTO
XNOR Tree Test Mode
The ADT7476 includes an XNOR tree test mode. This mode is useful for in-circuit test equipment at board-level testing. By applying stimulus to the pins included in the XNOR tree, it is possible to detect opens, or shorts, on the system board.
The XNOR tree test is invoked by setting Bit 0 (XEN) of the XNOR Tree Test Enable Register (0x6F).
Power-On Default
When the ADT7476 is powered up, monitoring is off by default and the PWM outputs go to 100%. All necessary registers then need to be configured via the SMBus for the appropriate functions to operate.
www.onsemi.com
48
ADT7476
Register Tables
Table 49. ADT7476 REGISTERS
Addr R/W Desc Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0x10 R/W Configuration
0x11 R/W Configuration
0x20 R 2.5 V
0x21 R V
0x22 R V
0x23 R 5.0 V
0x24 R 12 V
0x25 R Remote 1
0x26 R Local
0x27 R Remote 2
0x28 R TACH1 Low
0x29 R TACH1 High
0x2A R TACH2 Low
0x2B R TACH2 High
0x2C R TACH3 Low
0x2D R TACH3 High
0x2E R TACH4 Low
0x2F R T ACH4 High
0x30 R/W PWM1 Current
0x31 R/W PWM2 Current
0x32 R/W PWM3 Current
0x38 R/W PWM1 Max
0x39 R/W PWM2 Max
0x3A R/W PWM3 Max
0x3D R Device ID
0x3E R Company ID
0x3F R Revision ID 7 6 5 4 3 2 1 0 0x6B − 0x40 R/W Configuration
0x41 R Interrupt Status
0x42 R Interrupt Status
Register 6
Register 7
Measurement
CCP
Measurement
CC
Measurement
Measurement
Measurement
T emperature
T emperature
T emperature
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Duty Cycle
Duty Cycle
Duty Cycle
Duty Cycle
Duty Cycle
Duty Cycle
Register
Number
Register 1
Register 1
Register 2
Extra Slow
RES RES RES RES RES RES RES Dis
9 8 7 6 5 4 3 2 0x00
9 8 7 6 5 4 3 2 0x00
9 8 7 6 5 4 3 2 0x00
9 8 7 6 5 4 3 2 0x00
9 8 7 6 5 4 3 2 0x00
9 8 7 6 5 4 3 2 0x80
9 8 7 6 5 4 3 2 0x80
9 8 7 6 5 4 3 2 0x80
7 6 5 4 3 2 1 0 0x00
15 14 13 12 11 10 9 8 0x00
7 6 5 4 3 2 1 0 0x00
15 14 13 12 11 10 9 8 0x00
7 6 5 4 3 2 1 0 0x00
15 14 13 12 11 10 9 8 0x00
7 6 5 4 3 2 1 0 0x00
15 14 13 12 11 10 9 8 0x00
7 6 5 4 3 2 1 0 0xFF
7 6 5 4 3 2 1 0 0xFF
7 6 5 4 3 2 1 0 0xFF
7 6 5 4 3 2 1 0 0xFF Yes
7 6 5 4 3 2 1 0 0xFF Yes
7 6 5 4 3 2 1 0 0xFF Yes
7 6 5 4 3 2 1 0 0x76
7 6 5 4 3 2 1 0 0x41
RES TODIS FSPDIS Vx1 FSPD RDY LOCK STRT 0x04 Yes
OOL R2T LT R1T 5.0 V V
D2 D1 F4P FAN3 FAN2 FAN1 OVT 12 V/VC 0x00
V
Low
CCP
MasterEnSlaveEn THERM
in
Manual
SlowFan
Remote
1
CC
SlowFan
Local
V
CCP
SlowFan
Remote
1
THERM
Hys
2.5 V/
THERM
De-
fault
0x00 Yes
0x00 Yes
0x00
Lock-
able
www.onsemi.com
49
ADT7476
Table 49. ADT7476 REGISTERS (continued)
Addr
0x43 R/W VID/GPIO VIDSEL THLD VID 5 VID4/
0x44 R/W 2.5 V Low Limit 7 6 5 4 3 2 1 0 0x00 − 0x45 R/W 2.5 V High Limit 7 6 5 4 3 2 1 0 0xFF − 0x46 R/W V 0x47 R/W V 0x48 R/W VCC Low Limit 7 6 5 4 3 2 1 0 0x00 − 0x49 R/W VCC High Limit 7 6 5 4 3 2 1 0 0xFF − 0x4A R/W 5.0 V Lo w Limit 7 6 5 4 3 2 1 0 0x00 − 0x4B R/W 5.0 V High L imit 7 6 5 4 3 2 1 0 0xFF − 0x4C R/W 12 V Low Limit 7 6 5 4 3 2 1 0 0x00 − 0x4D R/W 12 V High Limit 7 6 5 4 3 2 1 0 0xFF − 0x4E R/W Remote 1 Temp
0x4F R/W Remote 1 Temp
0x50 R/W Local Temp Low
0x51 R/W Local Temp High
0x52 R/W Remote 2 Temp
0x53 R/W Remote 2 Temp
0x54 R/W TACH1 Min Low
0x55 R/W TACH1 Min High
0x56 R/W TACH2 Min Low
0x57 R/W TACH2 Min High
0x58 R/W TACH3 Min Low
0x59 R/W TACH3 Min High
0x5A R/W TACH4 Min Low
0x5B R/W TACH4 Min High
0x5C R/W PWM1
0x5D R/W PWM2
0x5E R/W PWM3
0x5F R/W Remote 1
0x60 R/W Local
0x61 R/W Remote 2
0x62 R/W Enhance
0x63 R/W Enhance
Low Limit 7 6 5 4 3 2 1 0 0x00
CCP
High Limit 7 6 5 4 3 2 1 0 0xFF
CCP
Low Limit
High Limit
Limit
Limit
Low Limit
High Limit
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Configuration
Configuration
Configuration
/PWM1
T
RANGE
Frequency
/PWM2
T
RANGE
Frequency
/PWM3
T
RANGE
Frequency
Acoustics
Register 1
Acoustics
Register 2
7 6 5 4 3 2 1 0 0x81
7 6 5 4 3 2 1 0 0x7F
7 6 5 4 3 2 1 0 0x81
7 6 5 4 3 2 1 0 0x7F
7 6 5 4 3 2 1 0 0x81
7 6 5 4 3 2 1 0 0x7F
7 6 5 4 3 2 1 0 0xFF
15 14 13 12 11 10 9 8 0xFF
7 6 5 4 3 2 1 0 0xFF
15 14 13 12 11 10 9 8 0xFF
7 6 5 4 3 2 1 0 0xFF
15 14 13 12 11 10 9 8 0xFF
7 6 5 4 3 2 1 0 0xFF
15 14 13 12 11 10 9 8 0xFF
BHVR BHVR BHVR INV RES SPIN SPIN SPIN 0x62 Yes
BHVR BHVR BHVR INV RES SPIN SPIN SPIN 0x62 Yes
BHVR BHVR BHVR INV RES SPIN SPIN SPIN 0x62 Yes
RANGE RANGE RANGE RANGE HF/LF FREQ FREQ FREQ 0XC4 Yes
RANGE RANGE RANGE RANGE HF/LF FREQ FREQ FREQ 0XC4 Yes
RANGE RANGE RANGE RANGE HF/LF FREQ FREQ FREQ 0XC4 Yes
MIN3 MIN2 MIN1 SYNC EN1 ACOU ACOU ACOU 0X00 Yes
EN2 ACOU2 ACOU2 ACOU2 EN3 ACOU3 ACOU3 ACOU3 0X00 Yes
GPIO4
VID3/
GPIO3
VID2/
GPIO2
VID1/
GPIO1
Bit 0Bit 1Bit 2Bit 3Bit 4Bit 5Bit 6Bit 7DescR/W
VID 0/
GPIO 0
De-
fault
0x1F
Lock-
able
www.onsemi.com
50
ADT7476
Table 49. ADT7476 REGISTERS (continued)
Addr
0x64 R/W PWM1 Min Duty
0x65 R/W PWM2 Min Duty
0x66 R/W PWM3 Min Duty
0x67 R/W Remote 1 Temp
0x68 R/W Local Temp
0x69 R/W Remote 2 Temp
0x6A R/W Remote 1
0x6B R/W Local THERM
0x6C R/W Remote 2
0x6D R/W Remote 1 and
0x6E R/W Remote 2
0x6F R/W XNOR Tree Test
0x70 R/W Remote 1 Temp
0x71 R/W Local Temp
0x72 R/W Remote 2 Temp
0x73 R/W Configuration
0x74 R/W Interrupt Mask
0x75 R/W Interrupt Mask
0x76 R/W Extended
0x77 R/W Extended
0x78 R/W Configuration
0x79 R THERM Timer
0x7A R/W THERM Timer
0x7B R/W TACH Pulses
0x7C R/W Configuration
0x7D R/W Configuration
Cycle
Cycle
Cycle
T
MIN
T
MIN
T
MIN
Limit
THERM
Limit
Limit
THERM
Local Temp/T
Hysteresis
Temp/T
MIN
Hysteresis
Enable
Offset
Offset
Offset
Register 2
Register 1
Register 2
Resolution Register 1
Resolution Register 2
Register 3
Status
Limit
per Revolution
Register 5
Register 4
7 6 5 4 3 2 1 0 0X80 Yes
7 6 5 4 3 2 1 0 0X80 Yes
7 6 5 4 3 2 1 0 0X80 Yes
7 6 5 4 3 2 1 0 0X5A Yes
7 6 5 4 3 2 1 0 0X5A Yes
7 6 5 4 3 2 1 0 0X5A Yes
7 6 5 4 3 2 1 0 0X64 Yes
7 6 5 4 3 2 1 0 0X64 Yes
7 6 5 4 3 2 1 0 0X64 Yes
HYSR1 HYSR1 HYSR1 HYSR1 HYSL HYSL HYSL HYSL 0X44 Yes
MIN
HYSR2 HYSR2 HYSR2 HYRS RES RES RES RES 0X40 Yes
RES RES RES RES RES RES RES XEN 0X00 Yes
7 6 5 4 3 2 1 0 0X00 Yes
7 6 5 4 3 2 1 0 0X00 Yes
7 6 5 4 3 2 1 0 0X00 Yes
RES CONV A TTN AVG Fan3
Detect
Fan2
Detect
Fan1
Detect
OOL R2T LT R1T 5.0 V VCC VCCP 2.5 V/
D2 D1 F4P FAN3 FAN2 FAN1 OVT 12 V/VC 0X00
5.0 V 5.0 V V
CC
V
CC
V
CCP
V
CCP
2.5 V 2.5 V 0X00
TDM2 TDM2 LTMP LTMP TDM1 TDM1 12 V 12 V 0X00
DC4 DC3 DC2 DC1 FAST BOOST THERM/
2.5 V
TMR TMR TMR TMR TMR TMR TMR ASRT/T
LIMT LIMT LIMT LIMT LIMT LIMT LIMT LIMT 0x00
FAN4 FAN4 FAN3 FAN3 FAN2 FAN2 FAN1 FAN1 0x55
R2
THERM
BpAtt
12 V
Local
THERMR1THERM
BpAtt
5.0 V
BpAtt V
CCP
VID/
GPIO BpAtt
2.5 V
GPIO6P GPIO6D Temp
Max
Speed
on
THERM
THERM
Disable
Offset
PIN14 FUNC
Bit 0Bit 1Bit 2Bit 3Bit 4Bit 5Bit 6Bit 7DescR/W
Fan
PresDT
THERM
ALERT 0x00 Yes
MRO
2sC 0x01 Yes
PIN14 FUNC
0x7E R Test 1 DO NOT WRITE TO THESE REGISTERS 0x00 Yes 0x7F R Test 2 DO NOT WRITE TO THESE REGISTERS 0x00 Yes
De-
fault
0X00 Yes
0X00
0x00
0x00 Yes
Lock-
able
www.onsemi.com
51
ADT7476
Table 50. REGISTER 0X10 − CONFIGURATION REGISTER 6 (POWER-ON DEFAULT = 0X00) (Note 1 and 2)
Bit No.
[0] SlowFan
[1] SlowFan
[2] SlowFan
[3] THERM in
[4] SlaveEn R/W Setting this bit configures the ADT7476 as a slave for use in fan sync mode. [5] MasterEn R/W Setting this bit configures the ADT7476 as a master for use in fan sync mode. [6] V
[7] ExtraSlow R/W When this bit is set, all fan smoothing times are increased by a further 39.2%
1. A THERM event always overrides any fan setting (even when fans are disabled).
2. This register becomes read-only when the Configuration Register 1 Lock bit is set to 1. Any subsequent attempts to write to this register fail.
Mnemonic R/W Description
R/W When this bit is set, Fan 1 smoothing times are multiplied x4 for Remote 1 temperature
Remote 1
channel (as defined in Register 0x62).
R/W When this bit is set, Fan 2 smoothing times are multiplied x4 for local temperature channel
Local
(as defined in Register 0x63).
R/W When this bit is set, Fan 3 smoothing times are multiplied x4 for Remote 2 temperature
Remote 2
channel (as defined in Register 0x63).
R/W When this bit is set, THERM is enabled in manual mode. (Note 1)
Manual
Low R/W VCCPLow = 1. When the power is supplied from 3.3 V STANDBY and the core voltage (VCCP)
CCP
drops below its V
CCP low limit value (Register 0x46), the following occurs:
Status Bit 1 in Interrupt Status Register 1 is set. SMBALERT
PROCHOT Everything is re-enabled once VCCP increases above the VCCP low limit.When V above the low limit:
PROCHOT
is generated, if enabled.
monitoring is disabled.
CCP
monitoring is enabled.
Fans return to their programmed state after a spin-up cycle.
increases
Table 51. REGISTER 0X11 − CONFIGURATION REGISTER 7 (POWER-ON DEFAULT = 0X00) (Note 1)
Bit No.
[0] DisTHERM
[7:1] Reserved N/A Reserved. Do not write to these bits.
1. This register becomes read-only when the Configuration Register 1 Lock bit is set to 1. Any subsequent attempts to write to this register fail.
Mnemonic R/W Description
Read/Write Setting this bit to 1 disables THERM hysteresis.
Hys
Table 52. VOLTAGE READING REGISTERS (POWER-ON DEFAULT = 0X00) (Note 1)
Register Address
0x20 Read-only Reflects the voltage measurement at the 2.5 V input on Pin 22 (8 MSBs of reading). 0x21 Read-only
0x22 Read-only 0x23 Read-only Reflects the voltage measurement at the 5.0 V input on Pin 20 (8 MSBs of reading). 0x24 Read-only Reflects the voltage measurement at the 12 V input on Pin 21 (8 MSBs of reading).
1. If the extended resolution bits of these readings are also being read, the extended resolution registers (Register 0x76, Register 0x77) must be read first. Once the extended resolution registers have been read, the associated MSB reading registers are frozen until read. Both the extended resolution registers and the MSB registers are frozen.
2. If V
3. V
Low (Bit 7 of 0x40) is set, V
CCP
(Pin 4) is the supply voltage for the ADT7476.
CC
R/W Description
Reflects the voltage measurement (Note 2) at the V Reflects the voltage measurement (Note 3) at the VCC input on Pin 4 (8 MSBs of reading).
can control the sleep state of the ADT7476.
CCP
input on Pin 23 (8 MSBs of reading).
CCP
Table 53. TEMPERATURE READING REGISTERS (POWER-ON DEFAULT = 0X80) (Note1. 2 and 3)
Register Address
0x25 Read-only Remote 1 temperature reading (Note 3 and 4) (8 MSBs of reading). 0x26 Read-only Local temperature reading (8 MSBs of reading). 0x27 Read-only Remote 2 temperature reading (Note 3 and 4) (8 MSBs of reading).
1. If the extended resolution bits of these readings are also being read, the extended resolution registers (Register 0x76, Register 0x77) must be read first. Once the extended resolution registers have been read, all associated MSB reading registers are frozen until read. Both the extended resolution registers and the MSB registers are frozen.
2. These temperature readings can be in twos complement or Offset 64 format; this interpretation is determined by Bit 0 of Configuration Register 5 (0x7C).
3. In twos complement mode, a temperature reading of −128°C (0x80) indicates a diode fault (open or short) on that channel.
4. In Offset 64 mode, a temperature reading of −64°C (0x00) indicates a diode fault (open or short) on that channel.
R/W Description
www.onsemi.com
52
ADT7476
Table 54. FAN TACHOMETER READING REGISTERS (POWER-ON DEFAULT = 0X00) (Note 1)
Register Address
0x28 Read-only T ACH1 Low Byte
0x29 Read-only T ACH1 High Byte 0x2A Read-only TACH2 Low Byte 0x2B Read-only TACH2 High Byte 0x2C Read-only TACH3 Low Byte 0x2D Read-only TACH3 High Byte 0x2E Read-only TACH4 Low Byte 0x2F Read-only TACH4 High Byte
1. These registers count the n umber of 11.11ms periods ( based o n an internal 90kHz clock) t hat o ccur b etween a n umber o f c onsecutive f an TACH pulses (default = 2). The number o f TACH pulses u sed to count can b e c hanged u sing t he TACH Pulses p er R evolution r egister ( Register0x7B). This allows t he f an s peed t o b e a ccurately m easured. B ecause a v alid f an t achometer reading r equires t hat t wo b ytes b e r ead, t h e low byte must be read first. Both the low and high bytes are then frozen until read. At power-on, these registers contain 0x0000 until the first valid fan TACH measurement is read into these registers. This prevents false interrupts from occurring while the fans are spinning up. A count of 0xFFFF indicates that a f an i s o ne o f t he f ollowing: s talled o r b locked ( object j amming t he f an), f ailed ( internal c ircuitry d estroyed), o r n ot p opulated. ( The ADT7476 expects to see a fan connected to each TACH. If a fan is not connected to t hat TACH, its T ACH m inimum h igh a nd l ow b ytes should be set to 0xFFFF.) An alternate function, for example, is T ACH4 reconfigured as the THERM
Table 55. CURRENT PWM DUTY CYCLE REGISTERS (POWER-ON DEFAULT = 0XFF) (Note 1)
Register Address
0x30 R/W PWM1 Current Duty Cycle (0% to 100% Duty Cycle = 0x00 to 0xFF) 0x31 R/W PWM2 Current Duty Cycle (0% to 100% Duty Cycle = 0x00 to 0xFF) 0x32 R/W PWM3 Current Duty Cycle (0% to 100% Duty Cycle = 0x00 to 0xFF)
1. These registers reflect the PWM duty cycle driving each fan at any given time. When in automatic fan speed control mode, the ADT7476 reports the PWM duty cycles back through these registers. The PWM duty cycle values vary according to temperature in automatic fan speed control mode. During fan startup, these registers report back 0x00. In manual mode, the PWM duty cycle outputs can be set to any duty cycle value by writing to these registers.
R/W Description
pin.
R/W Description
Table 56. PWM MAXIMUM DUTY CYCLE (POWER-ON DEFAULT = 0XFF) (Note 1 and 2)
Register Address
0x38 R/W Maximum Duty Cycle for PWM1 Output, Default = 100% (0xFF) 0x39 R/W Maximum Duty Cycle for PWM2 Output, Default = 100% (0xFF)
0x3A R/W Maximum Duty Cycle for PWM3 Output, Default = 100% (0xFF)
1. These registers set the maximum PWM duty cycle of the PWM output.
2. This register becomes read-only when the Configuration Register 1 Lock bit is set to 1. Any subsequent attempts to write to this register fail.
R/W Description
www.onsemi.com
53
ADT7476
Table 57. REGISTER 0X40 − CONFIGURATION REGISTER 1 (POWER-ON DEFAULT = 0X04)
Bit No. Mnemonic R/W Description
[0] STRT
(Notes 1, 2)
[1] LOCK Write Once Logic 1 locks all limit values to their current settings. Once this bit is set, all lockable registers
[2] RDY Read-only This bit is set to 1 by the ADT7476 to indicate that the device is fully powered-up and ready
[3] FSPD R/W When set to 1, this bit runs all fans at max speed as programmed in the max PWM current
[4] Vx1 R/W BIOS should set this bit to a 1 when the ADT7476 is configured to measure current from an
[5] FSPDIS R/W Logic 1 disables fan spin-up for two T ACH pulses. Instead, the PWM outputs go high for the
[6] TODIS R/W When this bit is set to 1, the SMBus timeout feature is disabled. This allows the ADT7476 to
[7] Reserved N/A Reserved. Do not write to this bit.
1. Bit 0 (STRT) of Configuration Register 1 (0x40) remains writable after lock bit is set.
2. When monitoring (STRT) is disabled, PWM outputs always go to 100% for thermal protection.
R/W Logic 1 enables monitoring and PWM control outputs based on the limit settings
programmed. Logic 0 disables monitoring and PWM control is based on the default powerup limit settings.
Note that the limit values programmed are preserved even if a Logic 0 is written to this bit and the default settings are enabled. This bit does not become locked once Bit 1 (LOCK bit) has been set.
become read-only and cannot be modified until the ADT7476 is powered down and powered up again. This prevents rogue programs such as viruses from modifying critical system limit settings. (Lockable.)
to begin system monitoring.
duty cycle registers (0x30 to 0x32). Power-on default = 0. This bit is not locked at any time.
®
ADOPT
VRM controller and to measure the CPU’s core voltage. This bit allows monitoring
software to display CPU watts usage. (Lockable.)
entire fan spin-up timeout selected.
be used with SMBus controllers that cannot handle SMBus timeouts. This bit is lockable.
Table 58. REGISTER 0X41 − INTERRUPT STATUS REGISTER 1 (POWER-ON DEFAULT = 0X00)
Bit No. Mnemonic R/W Description
[0] 2.5 V/
THERM
[1] V
[2] V
CCP
CC
[3] 5.0 V Read-only A 1 indicates that the 5.0 V high or low limit has been exceeded. This bit is cleared on a read
[4] R1T Read-only R1T = 1 indicates that the Remote 1 low or high temperature has been exceeded. This bit is
[5] LT Read-only LT = 1 indicates that the local low or high temperature has been exceeded. This bit is cleared
[6] R2T Read-only R2T = 1 indicates that the Remote 2 low or high temperature has been exceeded. This bit is
[7] OOL Read-only OOL = 1 indicates that an out-of-limit event has been latched in Interrupt Status Register 2.
Read-only 2.5 V = 1 indicates that the 2.5 V high or low limit has been exceeded. This bit is cleared on a
read of the status register only if the error condition has subsided. If Pin 22 is configured as THERM
, this bit is asserted when the timer limit has been exceeded.
Read-only V
= 1 indicates that the V
CCP
a read of the status register only if the error condition has subsided.
high or low limit has been exceeded. This bit is cleared on
CCP
Read-only VCC= 1 indicates that the VCC high or low limit has been exceeded. This bit is cleared on a
read of the status register only if the error condition has subsided.
of the status register only if the error condition has subsided.
cleared on a read of the status register only if the error condition has subsided.
on a read of the status register only if the error condition has subsided.
cleared on a read of the status register only if the error condition has subsided.
This bit is a logical OR of all status bits in Interrupt Status Register 2. Software can test this bit in isolation to determine whether any of the voltage, temperature, or fan speed readings represented by Interrupt Status Register 2 are out-of-limit, which eliminates the need to read Interrupt Status Register 2 during every interrupt or polling cycle.
www.onsemi.com
54
ADT7476
Table 59. REGISTER 0X42 − INTERRUPT STATUS REGISTER 2 (POWER-ON DEFAULT = 0X00)
Bit No. Mnemonic R/W Description
[0] 12 V/VC Read-only A 1 indicates that the 12 V high or low limit has been exceeded. This bit is cleared on a read
[1] OVT Read-only OVT = 1 indicates that one of the THERM overtemperature limits has been exceeded. This
[2] FAN1 Read-only FAN1 = 1 indicates that Fan 1 has dropped below minimum speed or has stalled. This bit is
[3] FAN2 Read-only FAN2 = 1 indicates that Fan 2 has dropped below minimum speed or has stalled. This bit is
[4] FAN3 Read-only FAN3 = 1 indicates that Fan 3 has dropped below minimum speed or has stalled. This bit is
[5] F4P Read-only When Pin 14 is programmed as a TACH4 input, F4P= 1 indicates that Fan 4 has dropped
R/W When Pin 14 is programmed as the GPIO6 output, writing to this bit determines the logic
Read-only If Pin 14 is configured as the THERM timer input for THERM monitoring, then this bit is set
[6] D1 Read-only D1 = 1 indicates either an open or short circuit on the Thermal Diode 1 inputs. [7] D2 Read-only D2 = 1 indicates either an open or short circuit on the Thermal Diode 2 inputs.
of the status register only if the error condition has subsided. If Pin 21 is configured as VID5, this bit is the VID change bit. This bit is set when the levels on VID0 to VID5 are different than they were 11ms previously. This pin can be used to generate an SMBALERT the VID code changes.
bit is cleared on a read of the status register when the temperature drops below THERM
not set when the PWM1 output is off.
not set when the PWM2 output is off.
not set when the PWM3 output is off.
below minimum speed or has stalled. This bit is not set when the PWM3 output is off.
output of GPIO6. When GPIO6 is programmed as an input, this bit reflects the value read by GPIO6.
when the THERM register (0x7A).
−T
.
HYST
assertion time exceeds the limit programmed in the THERM timer limit
whenever
Table 60. REGISTER 0X43 − VID/GPIO REGISTER (POWER-ON DEFAULT = 0X1F)
Bit No. Mnemonic R/W Description
[4:0] VID[4:0]/
GPIO[4:0]
[5] VID5 R/W Reads VID5 from the CPU when Bit 7 = 1. If Bit 7 = 0, the VID5 bit always reads back 0
[6] THLD R/W Selects the input switching threshold for the VID inputs.
[7] VIDSEL R/W VIDSEL = 0 configures Pin 21 as the 12 V measurement input (default).
R/W The VID[4:0] inputs from the CPU indicate the expected processor core voltage. On
powerup, these bits reflect the state of the VID pins, even if monitoring is not enabled. When Bit 4 of Configuration Register 5 (0x7C) = 1, these bits become general-purpose outputs. The state of these bits then reflects the state of the appropriate GPIO pin.
(power-on default).
THLD = 0 selects a threshold of 1 V (V THLD = 1 lowers the switching threshold to 0.6 V (VOL< 0.4 V, VIH> 0.8 V).
< 0.8 V, VIH> 1.7 V).
OL
Table 61. VOLTAGE LIMIT REGISTERS (Note 1)
Register Address
0x44 R/W 2.5 V Low Limit 0x00 0x45 R/W 2.5 V High Limit 0xFF 0x46 R/W V 0x47 R/W V 0x48 R/W VCC Low Limit 0x00
0x49 R/W VCC High Limit 0xFF 0x4A R/W 5.0 V Low Limit 0x00 0x4B R/W 5.0 V High Limit 0xFF 0x4C R/W 12 V Low Limit 0x00 0x4D R/W 12 V High Limit 0xFF
1. Setting the Configuration Register 1 Lock bit has no effect on these registers.
2. High limits: An interrupt is generated when a value exceeds its high limit (> comparison). Low limits: An interrupt is generated when a value is equal to or below its low limit (≤ comparison).
R/W Description (Note 2) Power-On Default
Low Limit 0x00
CCP
High Limit 0xFF
CCP
www.onsemi.com
55
ADT7476
Table 62. TEMPERATURE LIMIT REGISTERS (Note 1)
Register Address
0x4E R/W Remote 1 Temperature Low Limit 0x81 0x4F R/W Remote 1 Temperature High Limit 0x7F
0x50 R/W Local Temperature Low Limit 0x81 0x51 R/W Local Temperature High Limit 0x7F 0x52 R/W Remote 2 Temperature Low Limit 0x81 0x53 R/W Remote 2 Temperature High Limit 0x7F
1. Exceeding any of these temperature limits by 1°C causes the appropriate status bit to be set in the interrupt status register. Setting the Configuration Register 1 Lock bit has no effect on these registers.
2. High limits: An interrupt is generated when a value exceeds its high limit (> comparison). Low limits: An interrupt is generated when a value is equal to or below its low limit (≤ comparison).
Table 63. FAN TACH LIMIT REGISTERS (Note1)
Register Address
0x54 R/W TACH1 Minimum Low Byte 0xFF 0x55 R/W TACH1 Minimum High Byte/Single-channel ADC Channel Select 0xFF 0x56 R/W TACH2 Minimum Low Byte 0xFF 0x57 R/W TACH2 Minimum High Byte 0xFF 0x58 R/W TACH3 Minimum Low Byte 0xFF
0x59 R/W TACH3 Minimum High Byte 0xFF 0x5A R/W TACH4 Minimum Low Byte 0xFF 0x5B R/W TACH4 Minimum High Byte 0xFF
1. Exceeding any of the TACH limit registers by 1 indicates that the fan is running too slowly or has stalled. The appropriate status bit is set in Interrupt Status Register 2 to indicate the fan failure. Setting the Configuration Register 1 Lock bit has no effect on these registers.
R/W Description (Note 2) Power-On Default
R/W Description Power-On Default
Table 64. REGISTER 0X55 − TACH1 MINIMUM HIGH BYTE (POWER-ON DEFAULT = 0XFF)
Bit No. Mnemonic R/W Description
[4:0] Reserved Read-only When Bit 6 of Configuration 2 Register (0x73) is set (single-channel ADC mode), these bits
[7:5] SCADC R/W When Bit 6 of Configuration 2 Register (0x73) is set (single-channel ADC mode), these bits
are reserved. Otherwise, these bits represent Bits [4:0] of the TACH1 minimum high byte.
are used to select the only channel from which the ADC will take measurements. Otherwise, these bits represent Bits [7:5] of the TACH1 minimum high byte.
www.onsemi.com
56
ADT7476
Table 65. PWM CONFIGURATION REGISTERS (Note 1)
Register Address
0x5C R/W PWM1 Configuration 0x62 0x5D R/W PWM2 Configuration 0x62 0x5E R/W PWM3 Configuration 0x62
Bit No. Name R/W Description
[2:0] SPIN R/W These bits control the startup timeout for PWMx. The PWM output stays high until two valid
[3] RES N/A Reserved. Do not write to this bit. [4] INV R/W This bit inverts the PWM output. The default is 0, which corresponds to a logic high output for
[7:5] BHVR R/W These bits assign each fan to a particular temperature sensor for localized cooling.
1. These registers become read-only when the Configuration Register 1 Lock bit is set to 1. Any subsequent attempts to write to these registers fail.
R/W Description Power-On Default
TACH rising edges are seen from the fan. If there is not a valid TACH signal during the fan TACH measurement directly after the fan startup timeout period, the TACH measurement reads 0xFFFF and Interrupt Status Register 2 reflects the fan fault. If the TACH minimum high and low bytes contain 0xFFFF or 0x0000, the Interrupt Status Register 2 bit is not set, even if the fan has not started.
000 = No Startup Timeout 001 = 100 ms 010 = 250 ms (Default) 011 = 400 ms 100 = 667 ms 101 = 1 sec 110 = 2 sec 111 = 4 sec
100% duty cycle. Setting this bit to 1 inverts the PWM output, so 100% duty cycle corresponds to a logic low output.
000 = Remote 1 temperature controls PWMx (automatic fan control mode). 001 = Local temperature controls PWMx (automatic fan control mode). 010 = Remote 2 temperature controls PWMx (automatic fan control mode). 011 = PWMx runs full speed (default). 100 = PWMx disabled. 101 = Fastest speed calculated by local and Remote 2 temperature controls PWMx. 110 = Fastest speed calculated by all three temperature channel controls PWMx. 111 = Manual mode. PWM current duty cycle registers (0x30 to 0x32) become writable.
www.onsemi.com
57
ADT7476
T able 66. T
Register Address
0x5F R/W Remote 1 T
0x60 R/W Local T 0x61 R/W Remote 2 T
Bit No. Name R/W Description
[2:0] FREQ R/W These bits control the PWMx frequency (only apply when PWM channel is in low frequency
[3] HF/LR R/W HF/LF = 1, High frequency PWM mode is enabled for PWMx.
[7:4] RANGE R/W These bits determine the PWM duty cycle vs. the temperature range for automatic fan
1. These registers become read-only when the Configuration Register 1 Lock bit is set. Any further attempts to write to these registers have no effect.
/PWM FREQUENCY REGISTERS (Note 1)
RANGE
R/W Description Power-On Default
RANGE
mode).
000 = 11.0 Hz 001 = 14.7 Hz 010 = 22.1 Hz 011 = 29.4 Hz 100 = 35.3 Hz (Default) 101 = 44.1 Hz 110 = 58.8 Hz 111 = 88.2 Hz
HF/LF = 0, Low frequency PWM mode is enabled for PWMx.
control.
0000 = 2°C 0001 = 2.5°C 0010 = 3.33°C 0011 = 4°C 0100 = 5°C 0101 = 6.67°C 0110 = 8°C 0111 = 10°C 1000 = 13.33°C 1001 = 16°C 1010 = 20°C 1011 = 26.67°C 1100 = 32°C (Default) 1101 = 40°C 1110 = 53.33°C 1111 = 80°C
/PWM1 Frequency 0xC4
RANGE
/PWM2 Frequency 0xC4
/PWM3 Frequency 0xC4
RANGE
www.onsemi.com
58
ADT7476
Table 67. REGISTER 0X62 − ENHANCED ACOUSTICS REGISTER 1 (POWER-ON DEFAULT = 0X00) (Note 1)
Bit No.
[2:0] ACOU
[3] EN1 R/W When this bit is 1, smoothing is enabled on Remote 1 temperature channel. [4] SYNC R/W SYNC = 1 synchronizes fan speed measurements on TACH2, TACH3, and TACH4 to PWM3.
[5] MIN1 R/W When the ADT7476 is in automatic fan control mode, this bit defines whether PWM1 is off
[6] MIN2 R/W When the ADT7476 is in automatic fan speed control mode, this bit defines whether PWM2 is
[7] MIN3 R/W When the ADT7476 is in automatic fan speed control mode, this bit defines whether PWM3 is
1. This register b ecomes r ead-only w hen t he C onfiguration R egister 1 Lock b it i s s et t o 1 . A ny f urther a ttempts t o w rite t o t his r egister h ave n o e ffect.
2. Setting the relevant bit of Configuration Register 6 (0x10, [2:0]) further decreases these ramp rates by a factor of 4.
Mnemonic R/W Description
R/W Assuming that PWMx is associated with the Remote 1 temperature channel, these bits define
(Note 2)
the maximum rate of change of the PWMx output for Remote 1 temperature related changes. Instead of the fan speed jumping instantaneously to its newly determined speed, it ramps gracefully at the rate determined by these bits. This feature ultimately enhances the acoustics of the fan.
When Bit 7 of Configuration Register 6 (0x10) is 0 Time Slot Increase Time for 0% to 100%
000 = 1 37.5 sec 001 = 2 18.8 sec 010 = 3 12.5 sec 011 = 4 7.5 sec 100 = 8 4.7 sec 101 = 12 3.1 sec 110 = 24 1.6 sec 111 = 48 0.8 sec
When Bit 7 of Configuration Register 6 (0x10) is 1 Time Slot Increase Time for 0% to 100%
000 = 1 52.2 sec 001 = 2 26.1 sec 010 = 3 17.4 sec 011 = 4 10.4 sec 100 = 8 6.5 sec 101 = 12 4.4 sec 110 = 24 2.2 sec 111 = 48 1.1 sec
This allows up to three fans to be driven from PWM3 output and their speeds to be measured. SYNC = 0 synchronizes only TACH3 and TACH4 to PWM3 output.
(0% duty cycle) or at PWM1 minimum duty cycle when the controlling temperature is below its T
− hysteresis value.
MIN
0 = 0% duty cycle below T 1 = PWM1 minimum duty cycle below T
– hysteresis.
MIN
– hysteresis.
MIN
off (0% duty cycle) or at PWM2 minimum duty cycle when the controlling temperature is below its T 0 = 0% duty cycle below T 1 = PWM2 minimum duty cycle below T
− hysteresis value.
MIN
– hysteresis.
MIN
– hysteresis.
MIN
off (0% duty cycle) or at PWM3 minimum duty cycle when the controlling temperature is below its T 0 = 0% duty cycle below T 1 = PWM3 minimum duty cycle below T
– hysteresis value.
MIN
– hysteresis.
MIN
– hysteresis.
MIN
www.onsemi.com
59
ADT7476
Table 68. REGISTER 0X63 − ENHANCED ACOUSTICS REGISTER 2 (POWER-ON DEFAULT = 0X00) (Note 1)
Bit No.
[2:0] ACOU3 R/W Assuming that PWMx is associated with the local temperature channel, these bits define the
[3] EN3 R/W When this bit is 1, smoothing is enabled on the local temperature channel.
[6:4] ACOU2 R/W Assuming that PWMx is associated with the Remote 2 temperature channel, these bits define
Mnemonic R/W Description
maximum rate of change of the PWMx output for local temperature related changes. Instead of the fan speed jumping instantaneously to its newly determined speed, it ramps gracefully at the rate determined by these bits. This feature ultimately enhances the acoustics of the fan.
When Bit 7 of Configuration Register 6 (0x10) is 0 Time Slot Increase Time for 0% to 100%
000 = 1 37.5 sec 001 = 2 18.8 sec 010 = 3 12.5 sec 011 = 4 7.5 sec 100 = 8 4.7 sec 101 = 12 3.1 sec 110 = 24 1.6 sec 111 = 48 0.8 sec
When Bit 7 of Configuration Register 6 (0x10) is 1 Time Slot Increase Time for 0% to 100%
000 = 1 52.2 sec 001 = 2 26.1 sec 010 = 3 17.4 sec 011 = 4 10.4 sec 100 = 8 6.5 sec 101 = 12 4.4 sec 110 = 24 2.2 sec 111 = 48 1.1 sec
the maximum rate of change of the PWMx output for Remote 2 Temperature related changes. Instead of the fan speed jumping instantaneously to its newly determined speed, it ramps gracefully at the rate determined by these bits. This feature ultimately enhances the acoustics of the fan.
When Bit 7 of Configuration Register 6 (0x10) is 0 Time Slot Increase Time for 0% to 100%
000 = 1 37.5 sec 001 = 2 18.8 sec 010 = 3 12.5 sec 011 = 4 7.5 sec 100 = 8 4.7 sec 101 = 12 3.1 sec 110 = 24 1.6 sec 111 = 48 0.8 sec
When Bit 7 of Configuration Register 6 (0x10) is 1 Time Slot Increase Time for 0% to 100%
000 = 1 52.2 sec 001 = 2 26.1 sec 010 = 3 17.4 sec 011 = 4 10.4 sec 100 = 8 6.5 sec 101 = 12 4.4 sec 110 = 24 2.2 sec 111 = 48 1.1 sec
[7] EN2 R/W When this bit is 1, smoothing is enabled on the Remote 2 temperature channel.
1. This register b ecomes r ead-only w hen t he C onfiguration R egister 1 Lock b it i s s et t o 1 . A ny f urther a ttempts t o w rite t o t his r egister h ave n o e ffect.
www.onsemi.com
60
ADT7476
Table 69. PWM MINIMUM DUTY CYCLE REGISTERS (Note 1)
Register Address
0x64 R/W PWM1 Minimum Duty Cycle 0x80 (50% Duty Cycle) 0x65 R/W PWM2 Minimum Duty Cycle 0x80 (50% Duty Cycle) 0x66 R/W PWM3 Minimum Duty Cycle 0x80 (50% Duty Cycle)
Bit No. Name R/W Description
[7:0] PWM Duty
Cycle
1. These registers become read-only when the ADT7476 is in automatic fan control mode.
R/W Description Power-On Default
R/W These bits define the PWM
0x00 = 0% Duty Cycle (Fan Off)
duty cycle for PWMx.
MIN
0x40 = 25% Duty Cycle 0x80 = 50% Duty Cycle 0xFF = 100% Duty Cycle (Fan Full Speed)
T able 70. T
Register Address
1. These are the T minimum speed and increases with temperature according to T
2. These registers become read-only when the Configuration Register 1 Lock bit is set. Any further attempts to write to these registers have no
REGISTERS (Note 1 and 2)
MIN
0x67 0x68 0x69
registers for each temperature channel. When the temperature measured exceeds T
MIN
R/W Description Power-On Default
R/W Remote 1 Temperature T R/W Local Temperature T
MIN
R/W Remote 2 Temperature T
RANGE
MIN
MIN
.
MIN
0x5A (90°C) 0x5A (90°C) 0x5A (90°C)
, the appropriate fan runs at
effect.
Table 71. THERM LIMIT REGISTERS (Note 1 and 2)
Register Address
0x6A R/W Remote 1 THERM T emperature Limit 0x64 (100°C) 0x6B R/W Local THERM Temperature Limit 0x64 (100°C) 0x6C R/W Remote 2 THERM Temperature Limit 0x64 (100°C)
1. If any temperature measured exceeds its THERM limit, all PWM outputs drive their fans at 100% duty cycle. This is a fail-safe mechanism incorporated to cool the system in the event of a critical overtemperature. It also ensures some level of cooling in the event that software or hardware locks up. If set to 0x80, this feature is disabled. The PWM output remains at 100% until the temperature drops below THERM
limit − hysteresis. If the THERM pin is programmed as an output, exceeding these limits by 0.25°C can cause the THERM pin to
assert low as an output.
2. These registers become read-only when the Configuration Register 1 Lock bit is set to 1. Any further attempts to write to these registers have no effect.
Table 72. TEMPERATURE/T
Register Address
0x6D R/W Remote 1 and local temperature hysteresis. 0x44
[3:0] HYSL Local temperature hysteresis. 0°C to 15°C of hysteresis can be
[7:4] HYSR1 Remote 1 temperature hysteresis. 0°C to 15°C of hysteresis can
0x6E R/W Remote 2 temperature hysteresis. 0x40 0x6E HYSR2 Local temperature hysteresis. 0°C to 15°C of hysteresis can be
1. Each 4-bit value controls the amount of temperature hysteresis applied to a particular temperature channel. Once the temperature for that channel falls below its T hysteresis can be assigned to any temperature channel. The hysteresis value chosen also applies to that temperature channel if its THERM limit is exceeded. The PWM output being controlled goes to 100% if the THERM limit is exceeded and remains at 100% until the temperature drops below THERM Setting the hysteresis value lower than 4°C causes the fan to switch on and off regularly when the temperature is close to T
2. These registers become read-only when the Configuration Register 1 Lock bit is set to 1. Any further attempts to write to these registers have no effect.
R/W Description Power-On Default
HYSTERESIS REGISTERS (Note 1 and 2)
MIN
R/W Description Power-On Default
applied to the local temperature AFC control loops.
be applied to the Remote 1 temperature AFC control loops.
applied to the local temperature AFC control loops.
value, the fan remains running at PWM
MIN
duty cycle until the temperature = T
MIN
– hysteresis. Up to 15°C of
MIN
– hysteresis. For acoustic reasons, it is recommended that the hysteresis value not be programmed less than 4°C.
.
MIN
www.onsemi.com
61
ADT7476
Table 73. XNOR TREE TEST ENABLE (Note 1)
Register Address
0x6F R/W XNOR tree test enable register. 0x00
[0] XEN If the XEN bit is set to 1, the device enters the XNOR tree test mode.
[7:1] Reserved Unused. Do not write to these bits.
1. This register b ecomes read-only w hen the Configuration R egister 1 Lock b it i s set t o 1 . A ny f urther a ttempts t o w rite t o t his r egi ster h ave n o e ffect.
Table 74. REMOTE 1 TEMPERATURE OFFSET (Note 1)
Register Address
0x70 R/W Remote 1 temperature offset. 0x00
[7:0] R/W Allows a temperature offset to be automatically applied to the Remote
1. This register b ecomes r ead-only w hen t he C onfiguration R egister1 Lock bit i s s et t o 1 . A ny f urther a ttempts t o w rite t o t his r egister h ave n o e ffect.
Table 75. LOCAL TEMPERATURE OFFSET (Note 1)
Register Address
0x71 R/W Local temperature offset. 0x00
[7:0] R/W Allows a temperature offset to be automatically applied to the local
1. This register b ecomes r ead-only w hen t he Configuration R egister1 Lock b it i s set t o 1. A ny further a ttempts to w rite t o t his r egi ster h ave n o e ffect.
R/W Description Power-On Default
Clearing the bit removes the device from the XNOR tree test mode.
R/W Description Power-On Default
Temperature 1 channel measurement. Bit 1 of Configuration Register 5 (0x7C) determines the range and resolution of this register.
R/W Description Power-On Default
temperature measurement. Bit 1 of Configuration Register 5 (0x7C) determines the range and resolution of this register.
Table 76. REMOTE 2 TEMPERATURE OFFSET (Note 1)
Register Address
0x72 R/W Remote 2 temperature offset. 0x00
[7:0] R/W Allows a temperature offset to be automatically applied to the Remote
1. This register b ecomes read-only w hen t he C onfiguration R egister 1 lock b it is s et t o 1 . A ny f urther a ttempts t o w rite t o t his r egiste r h ave n o e ffect.
R/W Description Power-On Default
Temperature 2 channel measurement. Bit 1 of Configuration Register 5 (0x7C) determines the range and resolution of this register.
www.onsemi.com
62
ADT7476
Table 77. REGISTER 0X73 − CONFIGURATION REGISTER 2 (POWER-ON DEFAULT = 0X00) (Note 1)
Bit No.
[0] FanPresDT R/W When FanPresenceDT = 1, the state of Bits [3:1] of 0x73 reflects the presence of a 4-wire fan
[1] Fan1Detect Read-only Fan1Detect = 1 indicates that a 4-wire fan is connected to the TACH1 input. [2] Fan2Detect Read-only Fan2Detect = 1 indicates that a 4-wire fan is connected to the TACH2 input. [3] Fan3Detect Read-only Fan3Detect = 1 indicates that a 4-wire fan is connected to the TACH3 input. [4] AVG R/W AVG = 1 indicates that averaging on the temperature and voltage measurements is turned
[5] ATTN R/W ATTN = 1 indicates that the ADT7476 removes the attenuators from the +2.5 VIN, V
[6] CONV R/W CONV = 1 indicates that the ADT7476 is put into a single-channel ADC conversion mode. In
[7] Res This bit is reserved and should not be changed.
1. This register b ecomes r ead-only w hen t he C onfiguration R egister1 Lock bit i s s et t o 1 . A ny f urther a ttempts t o w rite t o t his r egister h ave n o e ffect.
Mnemonic R/W Description
on the appropriate TACH channel.
off. This allows measurements on each channel to be made much faster (x16).
+5.0 V
, and +12VIN inputs. These inputs can be used for other functions such as connecting
IN
up external sensors. It is also possible to remove attenuators from individual channels using Bits [7:4] of Configuration Register 4 (0x7D).
this mode, the ADT7476 can be made to read continuously from one input only, for example, Remote 1 temperature. The appropriate ADC channel is selected by writing to Bits [7:5] of TACH1 minimum high byte register (0x55).
Bits [7:5], Register 0x55
000 2.5 V 001 V 010 VCC (3.3 V)
CCP
011 5.0 V 100 12 V 101 Remote 1 Temperature 110 Local Temperature 111 Remote 2 Temperature
CCP
,
Table 78. REGISTER 0X74 − INTERRUPT MASK REGISTER 1 (POWER-ON DEFAULT [7:0] = 0X00)
Bit No. Mnemonic R/W Description
[0] 2.5 V/
THERM [1] V [2] V
CCP
CC
[3] 5.0 V R/W 5.0 V = 1 masks SMBALERT for out-of-limit conditions on the 5.0 V channel. [4] R1T R/W R1T = 1 masks SMBALERT for out-of-limit conditions on the Remote 1 temperature channel. [5] LT R/W LT = 1 masks SMBALERT for out-of-limit conditions on the local temperature channel. [6] R2T R/W R2T = 1 masks SMBALERT for out-of-limit conditions on the Remote 2 temperature channel. [7] OOL R/W OOL = 0 when one or more alerts are generated in Interrupt Status Register 2, assuming all
R/W 2.5 V/THERM = 1 masks SMBALERT for out-of-limit conditions on the 2.5 V/THERM timer
channel.
R/W V
= 1 masks SMBALERT for out-of-limit conditions on the V
CCP
CCP
channel.
R/W VCC= 1 masks SMBALERT for out-of-limit conditions on the VCC channel.
the mask bits in the Interrupt Mask Register 2 (0x75) = 1, SMBALERT
is still asserted. OOL = 1 when one or more alerts are generated in Interrupt Status Register 2, assuming all the mask bits in the Interrupt Mask Register 2 (0x75) = 1, SMBALERT is not asserted.
www.onsemi.com
63
ADT7476
Table 79. REGISTER 0X75 − INTERRUPT MASK REGISTER 2 (POWER-ON DEFAULT [7:0] = 0X00)
Bit No. Mnemonic R/W Description
[0] 12 V/VC R/W When Pin 21 is configured as a 12 V input, 12 V/VC = 1 masks SMBALERT for out-of-limit
[1] OVT R/W OVT = 1 masks SMBALERT for overtemperature THERM conditions. [2] FAN1 R/W FAN1 = 1 masks SMBALERT for a Fan 1 fault. [3] FAN2 R/W FAN2 = 1 masks SMBALERT for a Fan 2 fault. [4] FAN3 R/W FAN3 = 1 masks SMBALERT for a Fan 3 fault. [5] F4P R/W If Pin 14 is configured as TACH4, F4P = 1 masks SMBALERT for a Fan 4 fault. If Pin 14 is
[6] D1 R/W D1 = 1 masks SMBALERT for a diode open or short on a Remote 1 channel. [7] D2 R/W D2 = 1 masks SMBALERT for a diode open or short on a Remote 2 channel.
Table 80. REGISTER 0X76 − EXTENDED RESOLUTION REGISTER 1 (POWER-ON DEFAULT [7:0] = 0X00) (Note 1)
Bit No.
[1:0] 2.5 V Read-only 2.5 V LSBs. Holds the 2 LSBs of the 10-bit 2.5 V measurement. [3:2] V [5:4] V [7:6] 5.0 V Read-only 5.0 V LSBs. Holds the 2 LSBs of the 10-bit 5.0 V measurement.
1. If this register is read, this register and the registers holding the MSB of each reading are frozen until read.
Mnemonic R/W Description
CCP
CC
Read-only V Read-only VCC LSBs. Holds the 2 LSBs of the 10-bit VCC measurement.
conditions on the 12 V channel. When Pin 21 is programmed as VID5, this bit masks an SMBALERT, if the VID5 VID code bit changes.
configured as THERM is configured as GPIO, F4P = 1 masks SMBALERT when GPIO is an input and GPIO is asserted.
LSBs. Holds the 2 LSBs of the 10-bit V
CCP
, F4P = 1 masks SMBALERT for an exceeded THERM timer limit. If Pin 14
measurement.
CCP
Table 81. REGISTER 0X77 − EXTENDED RESOLUTION REGISTER 2 (POWER-ON DEFAULT [7:0] = 0X00) (Note 1)
Bit No.
[1:0] 12 V Read-only 12 V LSBs. Holds the 2 LSBs of the 10-bit 12 V measurement. [3:2] TDM1 Read-only Remote 1 temperature LSBs. Holds the 2 LSBs of the 10-bit Remote 1 temperature
[5:4] LTMP Read-only Local temperature LSBs. Holds the 2 LSBs of the 10-bit local temperature measurement. [7:6] TDM2 Read-only Remote 2 temperature LSBs. Holds the 2 LSBs of the 10-bit Remote 2 temperature
1. If this register is read, this register and the registers holding the MSB of each reading are frozen until read.
Mnemonic R/W Description
measurement.
measurement.
www.onsemi.com
64
ADT7476
Table 82. REGISTER 0X78 − CONFIGURATION REGISTER 3 (POWER-ON DEFAULT = 0X00) (Note 1)
Bit No.
[0] ALERT R/W ALERT = 1, Pin 10 (PWM2/SMBALERT) is configured as an SMBALERT interrupt output to
[1] THERM/
[2] BOOST R/W When THERM is an input and BOOST = 1, assertion of THERM causes all fans to run at the
[3] FAST R/W FAST = 1 enables fast TACH measurements on all channels. This increases the TACH
[4] DC1 R/W DC1 = 1 enables TACH measurements to be continuously made on TACH1. Fans must be
[5] DC2 R/W DC2 = 1 enables TACH measurements to be continuously made on TACH2. Fans must be
[6] DC3 R/W DC3 = 1 enables TACH measurements to be continuously made on TACH3. Fans must be
[7] DC4 R/W DC4 = 1 enables TACH measurements to be continuously made on TACH4. Fans must be
1. This register become read-only when the Configuration Register 1 Lock bit is set to 1. Any further attempts to write to to this register have no effect.
Mnemonic R/W Description
indicate out-of-limit error conditions. ALERT = 0, Pin 10 (PWM2/SMBALERT) is configured as the PWM2 output.
2.5V
R/W
THERM = 1 enables THERM functionality on Pin 22 and Pin 14, if Pin 14 is configured as THERM
, determined by Bits 0 and 1 (PIN14FUNC) of Configuration Register 4. When THERM is asserted, if the fans are running and the BOOST bit is set, then the fans run at full speed. Alternatively, THERM can be programmed so that a timer is triggered to time how long THERM has been asserted.
THERM Configuration Register 5 are set, THERM is bidirectional. If they are 0, THERM is a timer input only.
Pin 14 FUNC THERM/2.5 V Pin 22 Pin 14
00 01 10 11 00 01 10 11
maximum programmed duty cycle for fail-safe cooling.
measurement rate from once per second to once every 250 ms (4x).
driven by dc. Setting this bit prevents pulse stretching because it is not required for dc driven motors.
driven by dc. Setting this bit prevents pulse stretching because it is not required for dc driven motors.
driven by dc. Setting this bit prevents pulse stretching because it is not required for dc driven motors.
driven by dc. Setting this bit prevents pulse stretching because it is not required for dc driven motors.
= 0 enables 2.5 V measurement on Pin 22 and disables THERM. If Bits [5:7] of
0 0 0 0 1 1 1 1
+2.5 V +2.5 V +2.5 V +2.5 V THERM +2.5 V THERM THERM
IN IN IN IN
IN
TACH4 THERM SMBALERT GPIO6 TACH4 THERM SMBALERT GPIO6
T able 83. REGISTER 0X79 − THERM TIMER STATUS REGISTER (POWER-ON DEFAULT = 0X00)
Bit No. Mnemonic R/W Description
[7:1] TMR Read-only Times how long THERM input is asserted. These seven bits read 0 until the THERM
[0] ASRT/
TMR0
Read-only This bit is set high on the assertion of the THERM input and is cleared on read. If the THERM
assertion time exceeds 45.52 ms.
assertion time exceeds 45.52 ms, this bit is set and becomes the LSB of the 8-bit TMR reading. This allows THERM with a resolution of 22.76 ms.
assertion times from 45.52 ms to 5.82 sec to be reported back
T able 84. REGISTER 0X7A − THERM TIMER LIMIT REGISTER (POWER-ON DEFAULT = 0X00)
Bit No. Mnemonic R/W Description
[7:0] LIMT R/W Sets maximum THERM assertion length allowed before an interrupt is generated. This is an
8-bit limit with a resolution of 22.76 ms allowing THERM
5.82 sec to be programmed. If the THERM assertion time exceeds this limit, Bit 5 (F4P) of Interrupt Status Register 2 (0x42) is set. If the limit value is 0x00, an interrupt is generated immediately on the assertion of the THERM input.
assertion limits of 45.52 ms to
www.onsemi.com
65
ADT7476
Table 85. REGISTER 0X7B − TACH PULSES PER REVOLUTION REGISTER (POWER-ON DEFAULT = 0X55)
Bit No. Mnemonic R/W Description
[1:0] FAN1 R/W Sets number of pulses to be counted when measuring Fan 1 speed. Can be used to
[3:2] FAN2 R/W Sets number of pulses to be counted when measuring Fan 2 speed. Can be used to
[5:4] FAN3 R/W Sets number of pulses to be counted when measuring Fan 3 speed. Can be used to
[7:6] FAN4 R/W Sets number of pulses to be counted when measuring Fan 4 speed. Can be used to
determine fan pulses per revolution for unknown fan type.
Pulses Counted
00 = 1 01 = 2 (Default) 10 = 3 11 = 4
determine fan pulses per revolution for unknown fan type.
Pulses Counted
00 = 1 01 = 2 (Default) 10 = 3 11 = 4
determine fan pulses per revolution for unknown fan type.
Pulses Counted
00 = 1 01 = 2 (Default) 10 = 3 11 = 4
determine fan pulses per revolution for unknown fan type.
Pulses Counted
00 = 1 01 = 2 (Default) 10 = 3 11 = 4
Table 86. REGISTER 0X7C − CONFIGURATION REGISTER 5 (POWER-ON DEFAULT = 0X01) (Note 1)
Bit No.
[0] 2sC R/W 2sC = 1 sets the temperature range to the twos complement temperature range.
[1] Temp Offset R/W TempOffset = 0 sets offset range to −63°C to +64°C with 0.5°C resolution.
[2] GPIO6D R/W GPIO6 direction. When GPIO6 function is enabled, this determines whether GPIO6 is an
[3] GPIO6P R/W GPIO6 polarity. When the GPIO6 function is enabled and is programmed as an output, this
[4] VID/GPIO R/W VID/GPIO = 0 enables VID functionality on Pin 5, Pin 6, Pin 7, Pin 8, and Pin 19.
[5] R1 THERM R/W R1 THERM = 1 enables THERM temperature limit functionality for Remote 1 temperature
[6] Local
[7] R2 THERM R/W R2 THERM = 1 enables THERM temperature limit functionality for Remote 2 temperature
1. This register b ecomes read-only w hen the Configuration R egister 1 Lock b it i s set t o 1 . A ny f urther a ttempts t o w rite t o t his r egi ster h ave n o e ffect.
Mnemonic R/W Description
2sC = 0 changes the temperature range to the Offset 64 temperature range. When this bit is changed, the ADT7476 interprets all relevant temperature register values as defined by this bit.
TempOffset = 1 sets offset range to −63°C to +127°C with 1°C resolution. These settings apply to Remote 1, Local, and Remote2 temperature offset registers (0x70, 0x71, and 0x72).
input (0) or an output (1).
bit determines whether the GPIO6 is active low (0) or high (1).
VID/GPIO = 1 enables GPIO functionality on Pin 5, Pin 6, Pin 7, Pin 8, and Pin 19.
THERM
channel; that is, THERM R1 THERM = 0 indicates THERM is a timer input only. THERM can also be disabled on any channel by:
Writing −64°C to the appropriate THERM Writing −128°C to the appropriate THERM temperature limit in twos complement mode.
R/W Local THERM = 1 enables THERM temperature limit functionality for local temperature
channel; that is, THERM Local THERM = 0 indicates THERM is a timer input only. THERM can also be disabled on any channel by:
Writing −64°C to the appropriate THERM temperature limit in Offset 64 mode. Writing −128°C to the appropriate THERM
channel; that is, THERM R2 THERM channel by:
Writing −64°C to the appropriate THERM Writing −128°C to the appropriate THERM temperature limit in twos complement mode.
= 0 indicates THERM is a timer input only.THERM can also be disabled on any
is bidirectional.
temperature limit in Offset 64 mode.
is bidirectional.
temperature limit in twos complement mode.
is bidirectional.
temperature limit in Offset 64 mode.
www.onsemi.com
66
ADT7476
Table 87. REGISTER 0X7D − CONFIGURATION REGISTER 4 (POWER-ON DEFAULT = 0X00) (Note 1)
Bit No.
[1:0] PIN14FUNC R/W These bits set the functionality of Pin 14.
[2] THERM
[3] MaxSpeed
[4] BpAtt 2.5 V R/W Bypass 2.5 V attenuator. When set, the measurement scale for this channel changes from
[5] BpAtt V
[6] BpAtt 5.0 V R/W Bypass 5.0 V attenuator. When set, the measurement scale for this channel changes from
[7] BpAtt 12 V R/W Bypass 12 V attenuator. When set, the measurement scale for this channel changes
1. This register b ecomes r ead-only w hen t he C onfiguration R egister 1 Lock b it i s s et t o 1 . A ny f urther a ttempts t o w rite t o t his r egister h ave n o e ffect.
Mnemonic R/W Description
00 = TACH4 (Default) 01 = THERM 10 = SMBALERT 11 = GPIO
Disable
THERM
CCP
R/W THERM Disable = 0 enables THERM overtemperature output assuming THERM is correctly
R/W MaxSpeed on THERM = 0 indicates that fans go to full speed when THERM temperature
R/W Bypass V
configured (Registers 0x78, 0x7C, and 0x7D). THERM
Disable = 1 disables THERM overtemperature output on all channels. THERM
can also be disabled on any channel by:
Writing −64°C to the appropriate THERM Writing −128°C to the appropriate THERM
limit is exceeded. MaxSpeed on THERM
temperature limit is exceeded.
THERM
0 V (0x00) to 2.25 V (0xFF).
attenuator. When set, the measurement scale for this channel changes from
0 V (0x00) to 2.25 V (0xFF).
0 V (0x00) to 2.25 V (0xFF).
from 0 V (0x00) to 2.25 V (0xFF).
CCP
= 1 indicates that fans go to max speed (0x38, 0x39, 0x3A) when
temperature limit in Offset 64 mode.
temperature limit in twos complement mode.
Table 88. REGISTER 0X7E − MANUFACTURER’S TEST REGISTER 1 (POWER-ON DEFAULT = 0X00)
Bit No. Mnemonic R/W Description
[7:0] Reserved Read-only Manufacturer’s test register. These bits are reserved for manufacturer’s test purposes and
should not be written to under normal operation.
Table 89. REGISTER 0X7F − MANUFACTURER’S TEST REGISTER 2 (POWER-ON DEFAULT = 0X00)
Bit No. Mnemonic R/W Description
[7:0] Reserved Read-only Manufacturer’s test register. These bits are reserved for manufacturer’s test purposes and
should not be written to under normal operation.
Table 90. ORDERING INFORMATION
Device Order Number* Package Type Package Option Shipping
ADT7476ARQZ−REEL 24-lead QSOP RQ−24 2,500 Tape & Reel
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specifications Brochure, BRD8011/D.
*The “Z” suffix indicates Pb-Free packages.
Pentium is a registered trademark of Intel Corporation.
www.onsemi.com
67
MECHANICAL CASE OUTLINE
PACKAGE DIMENSIONS
2X
SCALE 2:1
D
24 13
A
E1
2X
0.20
C
D
112
e
24X
B
0.10 C
0.10 C
24X
SOLDERING FOOTPRINT
24X
0.42
24
0.20 C D
b
0.25 C
A1
13
D
E
M
QSOP24 NB
CASE 492B01
ISSUE A
2X 12 TIPS
C D
0.25
A-B D
A
SEATING
C
PLANE
24X
1.12
DETAIL A
H
C
L
h x 45
DETAIL A
GAUGE PLANE
_
L2
DATE 06 MAY 2008
NOTES:
1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994.
2. CONTROLLING DIMENSION: MILLIMETERS.
3. DIMENSION b DOES NOT INCLUDE DAMBAR PROTRUSION.
4. DIMENSION D DOES NOT INCLUDE MOLD FLASH, PROTRUSIONS, OR GATE BURRS. MOLD FLASH, PROTRUSIONS, OR GATE BURRS SHALL NOT EX CEED 0.15 PER SIDE. DIMENSION E1 DOES NOT INCLUDE INTERLEAD FLASH OR PROTRUSION. IN
C
TERLEAD FLASH OR PROTRUSION SHALL NOT EX CEED 0.15 PER SIDE. D AND E1 ARE DETERMINED AT DATUM H.
5. DATUMS A AND B ARE DETERMINED AT DATUM H.
MILLIMETERS
DIM MAXMIN
A 1.35 1.75
A1 0.10 0.25
b 0.20 0.30 C 0.19 0.25 D 8.65 BSC E 6.00 BSC
E1 3.90 BSC
e 0.635 BSC h 0.22 0.50 L 0.40 1.27
L2 0.25 BSC
M
M 0 8
__
GENERIC
MARKING DIAGRAM*
xxxxxxxxx AWLYWW
6.40
xxx = Specific Device Code A = Assembly Location WL = Wafer Lot Y = Year WW = Work Week
112
0.635 PITCH
DOCUMENT NUMBER:
DESCRIPTION:
ON Semiconductor and are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor reserves the right to make changes without further notice to any products herein. ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. ON Semiconductor does not convey any license under its patent rights nor the rights of others.
DIMENSIONS: MILLIMETERS
98AON04474D
QSOP24 NB
Electronic versions are uncontrolled except when accessed directly from the Document Repository. Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red.
*This information is generic. Please refer
to device data sheet for actual part marking. PbFree indicator, “G”, may or not be present.
PAGE 1 OF 1
© Semiconductor Components Industries, LLC, 2019
www.onsemi.com
ON Semiconductor and are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductor ’s product/patent coverage may be accessed at www.onsemi.com/site/pdf/PatentMarking.pdf ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. Buyer is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards, regardless of any support or applications information provided by ON Semiconductor. “Typical” parameters which may be provided in ON Semiconductor data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor was negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.
. ON Semiconductor reserves the right to make changes without further notice to any products herein.
PUBLICATION ORDERING INFORMATION
LITERATURE FULFILLMENT: Email Requests to: orderlit@onsemi.com
ON Semiconductor Website: www.onsemi.com
TECHNICAL SUPPORT North American Technical Support:
Voice Mail: 1 8002829855 Toll Free USA/Canada Phone: 011 421 33 790 2910
Europe, Middle East and Africa Technical Support:
Phone: 00421 33 790 2910 For additional information, please contact your local Sales Representative
www.onsemi.com
1
Loading...
