Onkyo X9 User Manual

X9

USER

MANUAL

1EN

Contents

1 Important 2

Hearing safety 2

2 Your Onkyo X9 speaker 3

Introduction 3

What's in the box 3

Overview of the speaker 4

3 Get started 5

Power supply 5

Switch on or go to standby mode 5

4 Use Bluetooth devices 7

Connect a Bluetooth-enabled device 7

Play from a Bluetooth-enabled device 9

Control your phone call 9

5 Other features 10

Listen to an external device 10

Play through USB 10

Adjust volume 11

Listen through a headphone 11

6 Product information 12

Specifications 12

7 Troubleshooting 13

General 13

8 Notice 14

2 EN

1 Important

Warning

•

Never remove the casing of this speaker.

• Never lubricate any part of this speaker.

• Never place this speaker on other electrical

equipment.

• Keep this speaker away from direct sunlight, naked

flames or heat.

• Make sure that there is enough free
space around the device for ventilation.

• Use only power supplies listed in the
user manual.

• Only use attachments or accessories
specified by the manufacturer.

• The battery shall not be exposed to
excessive heat such as sunshine, fire or
the like.

• The device shall not be exposed to
dripping or splashing.

• Do not place any sources of danger
on the device (e.g. liquid filled objects,
lighted candles).

• Where the plug of the Direct Plug-in
Adapter is used as the disconnect
device, the disconnect device shall
remain readily operable.

Hearing safety

Caution

•

To avoid hearing damage, limit the time you use the
headphones at high volume and set the volume to a
safe level. The louder the volume, the shorter is the
safe listening time.

Be sure to observe the following guidelines
when using your headphones.

• Listen at reasonable volumes for
reasonable periods of time.

• Be careful not to adjust the volume as
your hearing adapts.

• Do not turn up the volume so high that
you can't hear what's around you.

• You should use caution or temporarily
discontinue use in potentially
hazardous situations.

• Excessive sound pressure from
earphones and headphones can cause
hearing loss.

Note

•

The type plate is located on the bottom of the
product.

About operating temperatures and humidity

• Operate in a place where temperature
is between 0

o

C (32oF) and 40oC (104oF)

(up to 80% relative humidity)

• Battery life may be shorter in high or
low temperature conditions

3EN

2 Your Onkyo X9

speaker

Thank you for purchasing an Onkyo product.
Please read this manual carefully before
making any connections or using this
product. By following these instructions,
you’ll get the best audio performance and
the most listening pleasure from your
Onkyo product. Keep this manual for future
reference.

Introduction

With this speaker, you can

• enjoy audio from your Bluetooth­enabled devices, or other external audio
devices;

• enjoy the best possible listening
experience with High Resolution Audio
from your PC; and

• control the incoming phone call through
Bluetooth connection.

What's in the box

Check and identify the contents of your
package:

• Main unit

• Power adaptor

• 3.5mm audio cable

• USB cable

• Printed materials

4 EN

Overview of the speaker

a button/indicator

• Press briefly to switch on or go to

standby mode.

• In standby mode, press and hold to

switch o.

• Indicate the power status.

b

• Start, pause, or resume play.

• Press to answer an incoming call.

• During a call, press to end the

current call.

c -/+

• Adjust volume.

d

button/indicator

• Press and hold for 2 seconds to

enter pairing mode manually.

• Press and hold for 7 seconds to

clear pairing information.

• Indicate the Bluetooth connection

status.

e NFC

• Touch with an NFC compatible

device to set up Bluetooth
connection automatically.

ab cd

fg

hi

e

f DC IN socket

• Connect the power adaptor.

• Charge the built-in battery of the
speaker.

g AUDIO IN

socket

• Play music from your PC/Mac
through USB.

h AUX IN socket

• Connect an external audio device.

i

• Connect a headphone.
