Contents
5.1 Ch Home Theater Speaker Package
Getting Started .................... 2
SKS-HT235
Installing & Using ................ 6
Instruction Manual
Thank you for purchasing an Onkyo home theater
speaker package. Please read this manual thoroughly
before using your new speakers. Following the
instructions in this manual will enable you to obtain
optimum performance and listening enjoyment from
your speaker package.
Please retain this manual for future reference.
使用手冊
感謝您選購 Onkyo 家庭影院音箱系統。在使用音
箱前請仔細閱讀本手冊。按照手冊中的說明進行
操作可以發揮設備的最佳性能，並使您獲得最好
的視聽享受。
請保留本手冊以備將來查詢。
Appendix ............................ 10
目錄
卷首語 .................... 2
安裝與使用
.............................5
........................................9
附錄
En
SKS-HT235.book Page 2 Friday, June 18, 2004 9:05 AM
1.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
Important Safeguards
Read Instructions – All the safety and operating
instructions should be read before the appliance is
operated.
2. Retain Instructions – The safety and operating
instructions should be retained for future reference.
3. Heed Warnings – All warnings on the appliance and
in the operating instructions should be adhered to.
4. Follow Instructions – All operating and use
instructions should be followed.
5. Cleaning – Unplug the appliance from the wall outlet before cleaning. The appliance should be cleaned
only as recommended by the manufacturer.
6. Attachments – Do not use attachments not recommended by the appliance manufacturer as they may
cause hazards.
7. Water and Moisture – Do not use the appliance near
water –for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub; in a wet basement; or
near a swimming pool; and the like.
8. Accessories – Do not place the appliance on an
unstable cart, stand, tripod, bracket, or table. The
appliance may fall, causing serious injury to a child
or adult, and serious damage to the appliance. Use
only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the
appliance. Any mounting of the appliance should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
9. An appliance and cart combination should be moved
with care. Quick stops,
excessive force, and uneven
surfaces may cause the
appliance and cart combination to overturn.
10. Ventilation – Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation of the appliance and to protect it from overheating, and these openings must not be blocked or
covered. The openings should never be blocked by
placing the appliance on a bed, sofa, rug, or other
similar surface. The appliance should not be placed
in a built-in installation such as a bookcase or rack
unless proper ventilation is provided. There should
be free space of at least 20 cm (8 in.) and an opening behind the appliance.
En-
2
PORTABLE CART WARNING
S3125A
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
11. Power Sources – The appliance should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of
power supply to your home, consult your appliance
dealer or local power company.
12. Grounding or Polarization – The appliance may
be equipped with a polarized alternating current line
plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug.
If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
13. Power-Cord Protection – Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where
they exit from the appliance.
14. Lightning – For added protection for the appliance
during a lightning storm, or when it is left unattended and unused for long periods of time, unplug
it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the appliance due to lightning and power-line surges.
15. Overloading – Do not overload wall outlets, extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
16. Object and Liquid Entry – Never push objects of
any kind into the appliance through openings as
they may touch dangerous voltage points or shortout parts that could result in a fire or electric shock.
Never spill liquid of any kind on the appliance.
17. Servicing – Do not attempt to service the appliance
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
SKS-HT235.book Page 3 Friday, June 18, 2004 9:05 AM
Important Safeguards —Continued
18. Damage Requiring Service – Unplug the appliance from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the appliance,
C. If the appliance has been exposed to rain or
water,
D. If the appliance does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the appliance to its normal operation,
E. If the appliance has been dropped or damaged in
any way, and
F. When the appliance exhibits a distinct change in
performance – this indicates a need for service.
19. Replacement Parts – When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20. Safety Check – Upon completion of any service or
repairs to the appliance, ask the service technician to
perform safety checks to determine that the appliance
is in proper operation condition.
21. Wall or Ceiling Mounting – The appliance should
be mounted to a wall or ceiling only as recommended by the manufacturer.
22. Heat – The appliance should be situated away from
heat sources such as radiators, heat registers, stoves,
or other appliances (including amplifiers) that produce heat.
23. Liquid Hazards – The appliance should not be
exposed to dripping or splashing and no objects
filled with liquids, such as vases should be placed
on the appliance.
Precautions
1. Mounting
Mount the speakers as explained in this manual. Don’t
use the front or surround speakers without their bases as
damage or injury may result.
2. AC Fuse
The fuse is located inside the chassis and is not userserviceable. If power does not come on, contact your Onkyo
authorized service station.
3. Care
From time to time you should wipe off the front and rear
panels and the cabinet with a soft cloth. For heavier dirt,
dampen a soft cloth in a weak solution of mild detergent
and water, wring it out dry, and wipe off the dirt. Following this, dry immediately with a clean cloth. Do not use
rough material, thinners, alcohol or other chemical solvents or cloths since these may damage the finish or
remove the panel lettering.
Use a vacuum cleaner to remove dust from hard-to-reach
grilles.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION
CAREFULLY.
The voltage of the available power supply differs
according to country or region. Be sure that the power
supply voltage of the area where this unit will be used
meets the required voltage (e.g., AC 220–230 V, 50/
60 Hz) written on the rear panel.
En-
3
SKS-HT235.book Page 4 Friday, June 18, 2004 9:05 AM
Introduction
The SKS-HT235’s stylish enclosures are made of aluminum and their slim design makes them ideal for use with LCD
and plasma TVs.
SKS-HT235
The SKS-HT235 is a 5.1-channel speaker package consisting of front left and right speakers, a center speaker, surround
left and right speakers, and a powered subwoofer. Simply connect the speakers to your AV amp or receiver for superb
surround sound playback.
Speaker terminals and speaker cables are color-coded for easy identification. Simply connect each speaker cable to the
same-colored speaker terminals.
Package Contents
Make sure your box contains all of the items below. If anything is missing, contact the nearest Onkyo dealer.
• Front speakers
(SKF-404F)
• Center speaker
(SKC-404C)
• Speaker cable for front speakers
(4.5 m)
(Red) (White)
• Front speaker bases
• Speaker cable for center speaker
(3 m)
(Green)
• Spacers for wall mounting [×20]
• Front speaker base fixing screws [×8]
• Center speaker base
• Surround speakers
(SKM-230S)
* In catalogs and on packaging, the letter added to the end of the product name indicates the color of the SKS-HT235. Specifications and
operation are the same regardless of color.
En-
4
• Speaker cables for surround
speakers (9 m)
(Blue) (Gray)
• Subwoofer
(SKW-240)
• RCA cable for subwoofer
connection (3m)
■
■
SKS-HT235.book Page 5 Friday, June 18, 2004 9:05 AM
Getting to know Your Speaker Package
Subwoofer (SKW-240)
Front
1
Rear
MIN
OUTPUT
LEVEL
MAX
LINE
INPUT
POWER
ON OFF
Front, Center & Surround Speakers
(SKF-404F, SKC-404C, SKM-230S)
3
2
1
4
2 31
A
POWER switch and indicator
To turn on the SKW-240, set the POWER switch to
the ON position (the indicator lights up).
To turn off the SKW-240, set the POWER switch to
the OFF position (the indicator goes out).
Red: The unit is in standby mode
Green: The unit is in operation mode
The SKW-240 automatically turns to Standby mode
when no signal has been input for about 20 minutes.
The SKW-240 automatically turns on when an input
signal is detected in Standby mode.
B
OUTPUT LEVEL control
This control is used to adjust the output level of the
subwoofer.
C
LINE INPUT
The RCA input should be connected to the subwoofer preout on your AV receiver, amp, or other
receiver with supplied RCA cable.
Note:
The Auto Standby function turns the subwoofer on when
the input signal exceeds a certain level. If the Auto
Standby function does not work reliably, try slightly
increasing or decreasing the subwoofer output level on
your receiver or amp.
1
Speaker terminals
These push terminals are for connecting the speaker
to your amp, or other receiver with the supplied
speaker cables. The supplied speaker cables are
color-coded for easy identification. Simply connect
each cable to the same-colored positive speaker terminal.
Keyhole slots
2
These keyhole slots can be used to wall-mount the
speaker either horizontally or vertically.
Speaker mount/bracket inserts
3
These threaded inserts can be used to attach the
speaker either horizontally or vertically to a speaker
mount or bracket.
Note:
Use commercially available M5 screws to attach the
speaker to a speaker mount or bracket.
4
Base inserts (other than center speaker)
These threaded inserts can be used to mount the
speaker on the supplied base (screws included).
En-
5
SKS-HT235.book Page 6 Friday, June 18, 2004 9:05 AM
Various Mounting Methods
■
Front Speaker Bases
If you intend to stand the front speakers on the floor or
on a TV stand or AV stand, you should attach the supplied front speaker bases. To do this, align the mounting
holes in the base with base inserts on the front speaker’s
rear panel, and secure by using four of the supplied fixing screws.
Base inserts
Mounting holes
Wall Mounting
The front speakers, center speaker, and surround speakers, can easily be wall mounted by using the keyhole
slots. To prevent the speaker from vibrating against the
wall, attach four of the supplied spacers to the keyhole
fins on the rear of each speaker.
Mounting vertically
To mount the front speakers, or surround speakers, vertically, use the keyhole slot shown to hang each speaker on
a screw that’s securely screwed into the wall.
Front speaker
65 mm65 mm
125 mm
Keyhole slot for
vertical wall
mounting
Spacers
Center Speaker Base
The center speaker base is for mounting the center
speaker horizontally. If you put it on a TV stand or AV
stand, aim it toward the listening position. The center
speaker should sit securely on the base. If it’s loose, try
resetting it.
Note:
• If you put the center speaker on the floor, take it off the
base and position it so that it’s facing slightly up
toward the listener’s ears.
Base for horizontal
mounting
Spacers
Surround speaker
45 mm
Spacers
Spacers
Bottom
65 mm65 mm
Keyhole slot for
vertical wall
mounting
Bottom
En-
6
SKS-HT235.book Page 7 Friday, June 18, 2004 9:05 AM
Various Mounting Methods —Continued
■
Mounting horizontally
To mount the center speaker horizontally, use the two
keyhole slots shown to hang each speaker on two screws
that are securely screwed into the wall.
Center speaker
Keyhole slots for horizontal
Spacers Spacers
125 mm 190 mm 125 mm
wall mounting
65 mm
65 mm
Caution:
A mounting screw’s ability to support a speaker depends
on how well it’s anchored to the wall. If you have hollow
walls, screw each mounting screw into a stud. If there are
no studs, or the walls are solid, use suitable wall anchors.
Use screws with a head diameter of 9.5 mm or less and a
shank diameter of 4 mm or less. With hollow walls, use
a cable/pipe detector to check for any power cables or
water pipes before making any holes.
Leave a gap of between 7 mm and 10 mm between the
wall and the base of the screw head, as shown.
Wall
Using Speaker Mounts/Brackets
Threaded inserts for M5 screws are provided on the rear
of each speaker for wall-mounting with commercially
available speaker mounts and brackets. Refer to the manual supplied with your mounts or brackets for installation details.
Use this hole if mounting
vertically
Use this hole if mounting
horizontally
Note:
The portion of the screw that goes into the speaker’s
threaded insert should be between 5–9 mm long.
Mount or bracket
5 mm
5–9 mm
7–10 mm
(We recommend that you consult a home installation
professional.)
En-
7
SKS-HT235.book Page 8 Friday, June 18, 2004 9:05 AM
Connecting the Speakers
Read the following before connecting your speakers:
•Turn off your amp before making any connections.
• The nominal impedance of these speakers is 8 Ω . Use
only an amp that supports this impedance.
•Pay close attention to speaker wiring polarity. Connect
positive (+) terminals to only positive (+) terminals,
and negative (–) terminals to only negative (–) terminals. If the speakers are wired incorrectly, the sound
will be out of phase and will sound unnatural.
• Be careful not to short the positive and negative wires. Doing so
may damage your amp.
Connecting the Speaker Cables
Use the cables to connect each speaker’s
1
input terminals to the corresponding
speaker output terminals on your amp.
To make a connection, while
pressing the terminal lever,
insert the wire into the hole, and
then release the lever.
Make sure that the terminals are
gripping the bare wires, not the insulation.
Connecting the Subwoofer
Using the supplied RCA cable, connect
1
the subwoofer’s LINE INPUT to your amp’s
SUBWOOFER PREOUT.
Front right
speaker
Red
Surround
right speaker
ANTENNA
AM
FM
75
VIDEO
AUDIO
Gray
MON
OUT
SUB
WOOFER
PRE OUT
Center
speaker
Green
REMOTE
CONTROL
MON
2 ––VIDEO–– 1 VIDEO 2 VIDEO 1
OUT
OUT
OUT
IN
IN
OUT
IN OUT INININ
VIDEO 1 TAPE
VIDEO2
MD/HD
CDR/PC
Powered
subwoofer
DIGITAL INPUT
COMPONENT VIDEO OUTPUT
VIDEO 2 VIDEO 1
DIGITAL
OUTPUT
IN IN
OPT
S VIDEO
L
AUDIO
R
TV/LINE
OPT
FRONT SPEAKERS
L
Y
COAX
SURROUND
SPEAKERS
BA
RLR
RCA cable
LINE
INPUT
Front left
speaker
P
B
P
R
CENTER
SPEAKER
L
R
Blue
Surround
left speaker
White
En-
8
Loading...
