INSTRUCTION MANUAL
Model Number: ASET-036
Stereo Turntable with AM/FM Radio
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
2
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
Contents
Warranty 3
Welcome 3
General Safety Instructions 4
Parts List 6
Instructions 7
FAQs 9
Other Useful Information 10
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
3
Congratulations on choosing to buy a ONIX product. All products brought to
you by VIVID® are manufactured to the highest standards of performance and
safety and, as part of our philosophy of customer service and satisfaction, are
backed by our comprehensive 1 Year Warranty. We hope you will enjoy using
your purchase for many years to come.
Welcome
4
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place for
future reference, along with the completed warranty card, purchase receipt
and carton. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to.
Follow all instructions and take notice of all warnings to reduce the risk
of fire or electric shock.
Danger! Caution! This symbol alerts you that there is
dangerous voltage inside. To prevent electric shock, do not
open the enclosure.
Important! This symbol alerts you to read and observe
important warnings and instructions on the unit or in this
manual.
Electrical safety and cord handling
• To prevent contact with high voltage components
inside, do not attempt to open the equipment.
• Before installing this equipment, make sure your
outlet voltage corresponds to the voltage stated
on the appliance rating label.
• When connecting the equipment, align the plug
properly and insert it fully to prevent electric
shock.
• Only use this equipment with the cord and plug supplied, and do not
overload the power outlet.
• If the power cord is damaged, do not use the equipment. The cord must
be replaced by the manufacturer or similarly qualified personnel in order to
avoid a hazard. Contact the after sales support line for advice.
• CAUTION: To reduce the risk of fire or electric shock, do not expose this
equipment, the power supply cord and plug to rain or moisture; do not
use it anywhere near water or where water splashes or drips; do not touch
the power plug with wet hands. In the event that water or other liquids
enter the device, unplug the unit immediately and clean and dry it as best
as possible. Then have it checked for damage by a qualified technician.
Contact the after sales support line.
• Do not repair the unit yourself. Only have it serviced by qualified personnel.
Contact the after sales support line for advice.
• Unplug the unit from the power outlet after use to avoid possible damage
during electrical storms, or when the equipment will be unattended or
unused for a long period of time.
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
5
• Do not let the cord hang over the edge of a table or counter, or touch any
hot surface. Do not allow anything to rest on or roll over the power cord,
and run any cords so that no one steps on or trips over them.
• Do not run the cord near heat-producing appliances such as radiators,
stoves or irons. The excessive heat could melt the insulation and expose
live wires.
• Always grasp the plug, not the cord, when disconnecting the unit. Pulling
the cord can damage the internal wires and may cause a fire.
Installation
• When installing the unit, make sure to place it:
• Away from heat sources, radiators or other products that produce heat.
• Away from areas with high temperatures, high humidity or direct sunlight.
• Away from excess dirt and dust.
• Away from open windows and any place where water may get into the
unit and damage it.
• Make sure there is free circulation of air around the unit. Do not place it on a
thick carpet, bed or any place where ventilation holes are obstructed. Leave
at least 10cm clearance around the unit.
• Make sure the mains socket is readily accessible at all times.
Usage conditions and restrictions
• Openings on the cabinet are provided for ventilation and to protect the
unit from overheating. To ensure proper operation, do not cover them with
things such as newspapers, tablecloths, curtains etc.
• Do not place heavy objects on top of the equipment or step on it.
• Do not place objects filled with water (such as vases) or any naked flame
sources (such as lit candles, incense sticks or cigarettes) on top of the unit.
• The equipment is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Young children should be supervised to ensure they do not play with the
equipment. Close supervision is always necessary when an appliance is
used by or near children.
• Unplug the unit from the power outlet before cleaning.
• Clean the unit only with a dry, clean cloth. Do not use liquid or aerosol
cleaners.
• We assume no liability for any damage caused by non-compliance
with these instructions or any other improper use or mishandling of the
equipment.
General Safety Instructions (Cont.)
6
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
Parts List
1 Lift lever
2 Auto stop switch
3 Tone arm lock
4 Speed switch
5 Tone arm
6 Dust cover
7 45 RPM adaptor
8 Stylus guard
9 Power on/off & volume control knob
10 LED power indicator
11 Band selection knob
12 Function switch
13 Stereo speakers
14 Turntable
15 Antenna
16 RCA output
17 AC power cord and plug
18 Cartridge with stylus
1
6
7
8
9
1011
12
13
13
2
3
4
5
15 16 17
18
14
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
7
Instructions
Listening to a record
1. Raise the dust cover.
2. Connect the AC power cord to an electrical outlet.
3. Turn the power on/off knob in a clockwise direction: the indicator light will
illuminate.
4. Adjust the volume to your desired level.
5. Turn the function switch in a clockwise direction to PHONO.
6. Place a record on the turntable.
7. Use the speed switch to select the appropriate player speed (33/45/78
rpm) according to your record.
NOTE: If required, use the 45 rpm adaptor for playing 45 rpm records.
The stylus can be used for all three speeds.
8. Set the auto stop control to ON if you want the turntable to stop turning
when it has reached the end of the record. If the switch is set to OFF, the
turntable will continue turning at the end of the record.
9. Remove the stylus guard.
10. If the tone arm lock is engaged, open it so the tone arm can move freely.
Remove the tone arm from the rest, push the lift lever backward to raise
it and then gently move the tone arm to the desired position over the
record. The turntable will begin turning when the arm is moved toward
the record.
11. Push the lift lever forward to lower the tone arm slowly onto the desired
position on the record and begin playing the record.
12. At the end of playing the record, push the lift lever backward to raise the
tone arm and gently move it back to its rest.
13. When you have finished playing records, engage the tone arm lock to
protect it from accidental movement. Insert the stylus guard. Turn the
power on/off knob in a counterclockwise direction to switch the unit off.
Unplug it from the power supply if you are not going to use it for a while.
IMPORTANT: To avoid stylus damage,
make certain the included stylus guard
is in place whenever the turntable is
being installed, moved or cleaned.
8
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
Instructions (Cont.)
Listening to radio
1. Connect the AC power cord to an electrical outlet.
2. Turn the power on/off knob in a clockwise direction: the indicator light will
illuminate.
3. Adjust the volume to your desired level.
4. Extend the antenna to obtain the best reception.
5. Turn the function switch to either AM or FM.
6. Turn the band selection knob to your desired radio station.
7. When you have finished listening to radio, turn the power on/off knob
in a counterclockwise direction to switch the unit off. Unplug it from the
power supply if you are not going to use it for a while.
Connecting the turntable to an external amplifier
To connect the unit to an external amplifier, use an RCA cord, making sure to
connect the red jack to the red socket and the white jack to the white socket.
R
L
MIC
COMPUTER
Recording a record (or radio audio) onto computer
1. To connect the unit to a computer, plug the red and white jacks of an
RCA cord into the L/R LINE OUT sockets at the back of the turntable and
plug the 3.5mm jack to the microphone socket on your computer.
2. Download and install the appropriate software from http://audacity.
sourceforge.net/.
3. Double-click the Audacity icon and follow the prompts for recording.
R
L
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
9
FAQs
If you are experiencing problems with your Stereo Turntable with Radio,
check in the section below whether there are any quick and easy checks you
can do that may help you solve the problem. If you cannot solve the problem
by yourself, contact our after sales support line for advice. Do not attempt to
open, repair or modify the equipment yourself.
Problems with sound
• Clockwise rotate the power/volume knob to increase the volume.
• Make sure the unit's power cord is connected to an appropriate electrical outlet
and the wall socket is switched on.
• Make sure the function switch is set to your desired function: AM, FM or
PHONO.
• When playing records, make sure you have selected the correct speed (33, 45
or 78 rpm).
Problems with radio reception
• Make sure you are in an area that can receive signals for your selected
radio station.
• Try adjusting the aerial for maximum signal strength and improved
reception.
• Try moving your radio to an alternative location to see if the reception
improves.
• Check that you do not have other electrical equipment too close to your
radio, which may cause interference.
10
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
Responsible disposal
At the end of its working life, do not throw this appliance out with your
household rubbish. Electrical and electronic products contain substances
that can have a detrimental effect on the environment and human health if
disposed of inappropriately. Observe any local regulations regarding the
disposal of electrical consumer goods and dispose of it appropriately for
recycling. Contact your local authorities for advice on recycling facilities in
your area.
Other Useful Information
Technical specifications
Dimensions Stand unit
323 (W) x 288 (D) x 130mm (H)
320 mm turntable clearance
height
Vinyl Records
Speed
Supports playback speeds
33.33 / 45 / 78 rpm
Record size support
7" (17.7cm)
10" (25.5cm) SP
12" (30cm) LP
Frequency
Range
FM 88 – 108 MHz
AM 540 – 1600 kHz
Speaker
2 x 3W 4ohms
Audio Output
L/R Line Out
Power Input
240V AC 50 Hz
1300 886 649 Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
AUS
11
This page has been left blank intentionally.
Model: ASET-036 Product Code: 36996 08/2014
www.tempo.org
1300 886 649
AUS
Warranty returns
Should you for any reason need to return this product
for a warranty claim, make sure to include all accessories
with the product.
Product does not work?
If you encounter problems with this product, or if it fails
to perform to your expectations, make sure to contact
our After Sales Support Centre on 1300 886 649 before
returning it to the store for a refund.
Loading...
