Onix AP4-014 Instruction Manual

4” Dual SIM Smartphone
1300 886 649 Model: AP4-014 Product Code: 47281 12/2014
www.tempo.org
AFTER SALES SUPPORT
AUS
Model Number: AP4-014
2
Contents
General Safety Instructions 3
Product Overview 5
Getting Started
• Before first use, Micro SD Card, SIM Card, Inserting the SIM card(s) and battery 7
• Charging, Power Button, Volume, Linking with your Google account 8
• SIM management 9
Operation
• Entering your PIN, Screen operation 11
• Phone calls 13
• Contacts 18
• Messaging 19
• Applications and widgets, Add and manage desktop icons 20
• Changing the wallpaper 22
• Connect with computer 23
• Browsing the internet, Screen compatibility, Background applications 24
• Download and install applications from Play Store, Uninstall applications 25
Settings
• Wireless and networks 26
• Bluetooth Wireless Technology
28
• Device 29
• Personalisation 30
• System, Camera, Downloaded files management 34
Specifications 35
3
Read this manual thoroughly before first use and keep it in a safe place for future reference, along with the completed warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
Handling and maintenance
• Water: Ensure that this product does not get wet, protect it from water splashes, rain, excessive humidity and sweat. Contact with water will cause the phone to short-circuit, corrode or cause electric shock. Do not use it where it can fall into water (such as near a pool, pond, bath etc.). Do not use it with wet hands. Do not immerse it in water. Do not turn it on if it is wet. Do not try to dry it in a microwave oven.
• Handling: To avoid damaging the phone, battery or charger, do not drop it or shake it vigorously as this may cause device or battery failure, fire or explosion.
• Repair: This device is a high precision electronic product. It contains no user- serviceable parts inside. Do not try to dismantle, modify or repair the device or charger yourself. Any modifications could void your warranty.
Usage environment
• Environment: Do not use this product where it is excessively hot, cold, dusty or humid, or where it is exposed to strong magnetic fields or long periods of sunshine. Exposure to very low or very high temperatures may cause device or battery failure, fire or explosion.
• Heat sources: Do not leave the product near any heat sources, stoves, ovens or other appliances (including amplifiers) that produce heat.
• Interference: Do not use the phone near other electronic devices that use radio frequency signals. Avoid using it within a 15cm range of a pacemaker (if you have a pacemaker, do not carry the phone in a breast pocket).
Safety
• Road safety: Obey all local laws and regulations on the use of mobile devices in the area where you drive. Give full attention to driving and the road. Keep your hands free to operate the vehicle at all times; use hands-free operation or an earpiece if phone usage is required.
• Health facilities: Observe relevant rules or regulations regarding mobile phone use in health facilities. Turn off the phone in the vicinity of medical devices and wherever directed to do so by posted signs. Mobile phone radiation may interfere with pacemakers, hearing aids and other medical equipment.
• Aircraft: Turn off the smartphone when boarding an airplane in order to avoid interference with aircraft radio signals.
• Magnetic equipment: Stay away from magnetic equipment to avoid the risk of interfering with or erasing the information stored on the device.
• Volume: Always select the appropriate volume when using the music or video function. The volume should not be too loud when using earphones.
• Explosive environments: Turn off the phone in blasting areas and in any potentially explosive environment (such as at a petrol station or other refuelling points).
• Back-up: To avoid loss of data, we recommend always backing up any important infor- mation, especially before upgrading the hardware. We assume no liability for any damage and/or data loss due to lack of back-up.
• Flashlight: Do not use the flashlight close to the eyes of people or pets.
Accessories
• Accessories: Only use the device with the Micro USB cable and battery charger supplied. Use of other accessories not recommended in this manual may cause damage to the unit and void your warranty.
• Battery charger: Only use the charger provided. Do not use the phone while it is charg- ing. Do not drop or cause an impact to the charger.
• Battery handling: Do not expose the battery to high temperatures. Take care when handling a charged battery, particularly when placing it inside your pocket, purse or other container with metal objects.
• Damage: Do not use the charger if the cable or plug are damaged. In case of damage, contact the after sales support line for advice.
General Safety Instructions
4
General Safety Instructions (Cont.)
• Disconnect: Grip the plug when disconnecting the charger; do not pull on the cord.
• Memory card: Always handle the phone’s memory card(s) with care. Protect the card(s)
from static electricity and strong shocks.
Usage conditions and restrictions
• Packaging: Plastic packaging materials can present a suffocation hazard for young
children and babies. Keep all packaging materials out of children’s reach to ensure they do not play with these.
• Personal usage: Do not use this product for anything other than its intended purpose,
and only use it as described in this manual.
• Restricted usage: The equipment is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the equipment by a person responsible for their safety.
• Children: This phone is not a toy. Keep the phone, battery and charger away from young
children. Supervise young children when the phone is going to be used by or near young children.
• Cleaning: Clean the housing of the device lightly with a dry cotton cloth. Do not use
alcohol, thinners, benzene or any other chemical cleaning solutions.
• Lost phone: We recommend you inform your telecommunications service provider to
block your SIM card(s) when your phone is lost. You may also want to ask them to block the phone’s IMEI number(s), these are printed on a label inside the phone underneath the battery. (Alternatively, the number(s) will be included on a label with the packaging.) Please note down these numbers so you have them handy in case your phone is lost.
• Disposal: When discarding this device, observe local regulations and dispose of it
appropriately for recycling. Never dispose of the battery in a fire. Contact your local authorities for advice on facilities.
• Noncompliance: We accept no liability for any damage caused by noncompliance with
these instructions or any other improper use or mishandling.
5
Product Overview
1 Headphone Jack
2 Front Camera
3 Earpiece
4 Micro USB Socket
5 PowerOn/O
6 Volume Up/Down
7 Options Menu
8 Home Button
9 Back / Return
10 Microphone
11 NoticationsBar
11
10
7 8 9
Home Screen
1
2
4 5
6
3
6
Product Overview (Cont.)
12
14 151716
13
12 Rear Camera
13 Speaker
14 SIM Card Slot 1
15 SIM Card Slot 2
16 Micro SD Card Slot
17 Battery Bay
7
Beforerstuse
• Unpack the product but keep all packaging materials until you have made sure
your new Dual SIM Smartphone is undamaged and in good working order. Plastic wrapping can be a suffocation hazard for babies and young children, so ensure all packaging materials are out of their reach.
• Unwind the USB cable and inspect it for damage. Do not use the cables or the
charger if any part is damaged. In case of damage, contact our after sales support line for advice on examination, repair or return of the damaged product.
• Read this manual to familiarise yourself with all the features and operating
principles of your new 4” Dual SIM Smartphone. Pay particular attention to the safety instructions on the previous pages.
Micro SD Card
• Place you finger in the small recess in the corner of the mobile phone and with you
fingernail, carefully prise it open and lift off the back cover.
• Your Bauhn 4” Dual SIM Smartphone is compatible with Class 10 Micro SD cards,
up to 32GB in capacity.
• Power off your phone, then insert your Micro SD card into the SD slot on the rear of
the Phone, making sure the gold contacts are facing to the front of the Phone.
• To remove the SD card, power off the Phone and remove the battery, then gently
pull the SD card out.
SIM Card (2G/3G)
• Your new Bauhn 4” Dual SIM Smartphone is compatible with two ‘Mini’ sized SIM
cards.
Note: SIM card size adaptors should not be used as they may cause damage or
become stuck.
Inserting the SIM card(s) and battery
• If the battery is in place, remove it.
• Insert your SIM card(s) into the dedicated bays. Bay number (1) supports Mini
SIM Cards for 3G and 2G; bay number (2) supports Mini SIM Cards for 2G only. If required, insert a micro SD card into its dedicated space.
• Once the SIM and SD cards are securely in place, insert the battery (supplied) into
the phone, making sure to align the pins with the contacts.
• Reinstall the back cover. It will lock into place.
NOTE: Some SIM cards require a PIN number to be entered before use. This PIN may
be printed on the SIM card packaging, or you may have to contact your service provider for the number.
Getting Started
Micro SIM
Mini SIM
Normal SIM
8
Getting Started (Cont.)
Charging
The battery has been partially charged at the factory. To perform all functions, we recommend you fully recharge it as follows:
• To charge the device with the battery charger, plug the large end of the USB cable
into the charging adaptor and the smaller end into the micro USB port on the 3G Smartphone. Plug the charger into your mains power supply.
• To charge the device using the USB cable and computer, plug the large end of
the USB cable into a USB port on your computer and the smaller end into the micro USB port on the 3G Smartphone. Ensure your computer is turned on.
• When the phone indicates a full charge (the battery status icon is located in the top
right corner of the display), disconnect the charger or USB cable.
• Follow one of these charging procedures whenever your 3G Smartphone indicates
a low battery charge.
Power button
Switchingon/o
• In power-off state, press and hold the power button until the screen turns on and
the device will start up.
• In power-on state, long press to display the power off menu. Then choose to switch
off the device.
NOTE: If phone becomes unresponsive, remove and reinsert the battery.
Turningthescreenon/o
• In power-on state, press the power button to turn the screen on or off.
• After a period of inactivity the screen will automatically turn off to save battery
power. This can be set using the “Sleep” setting from the display menu in the device settings menu.
• If after a long time in sleep state the screen does not turn on, remove then reinsert
the battery. Then press the power button to turn on again.
Volume
• To adjust the ringer volume, press the Volume Up or Volume Down buttons on the
right side of the 3G Smartphone to the desired level. While adjusting the ringer volume, a window will appear on the screen displaying the volume levels.
Linking with your Google account
When you turn on the phone for the first time, you can sign in to your Google account so you can synchronise Gmail, Calendar and Contacts between your phone and your Google account. A Google account is also required to use Play Store.
• On your phone go to “Settings” and tap “Add Account” > “Google” > “Existing”.
• Tap “Sign in”, enter your user name and password and then tap “Sign in”. After signing in, all emails, contacts, and calendar events on your Google account will automatically synchronise with your phone.
NOTE: Tap “Create” if you do not have a Google account yet.
Google account password
If you cannot remember your Google account password, follow the steps below to retrieve it:
• On your computer, open your browser and go to http://google.com/accounts.
• On the bottom of the page, tap “Need help?”.
• In the “Having trouble signing in?” section, select “I don’t know my password”.
• Insert your email address in the space provided and tap “Continue”.
• Follow the preocedure until the reset password link is sent to your recovery email.
9
Getting Started (Cont.)
SIM management
This 3G Smartphone can be used with two SIM cards. When you have two SIM cards inserted, you can choose to use either SIM1 or SIM2, or both of them. Unless you have determined use of one particular SIM card as your default card in the settings, you will be prompted to choose an appropriate SIM card every time you want to make a call or send a message.
NOTE: Only SIM card bay number 1 supports 3G data connection.
SIM Information
Tap the check box to choose enable or disable a SIM card, or tap a SIM card to change its information.
Default SIM
You could choose the default SIM card for your voice calls, video calls, messages or connection.
General settings
You could change roaming settings or associate contacts with a specific SIM.
10
Operation
Entering your PIN
If you want to use a SIM card that is preset with a PIN (personal identification number), you will have to enter the PIN to proceed. Just follow the prompts to enter the SIM PIN and then tap “OK”.
Screen operation
Click / Short Press
When using the on-screen keyboard, click or short press to open applications or select items.
Long Press
Press and hold for several seconds on an item (such as a text box or web page link) to display the action or submenu for an item, if available.
Slide or Rapid Slide
Sliding or fast sliding means vertical or horizontal drag action.
Drag
When dragging, you must hold the icon with your finger and keep pressure until it reaches destination.
Display Rotation
For most of the screens, the content will change between landscape and portrait mode, according to the device orientation.
Unlocking the main screen
• Drag the lock to the right side to unlock the screen.
• After unlocking the screen, you will see the last item you had open or the main screen, which has five windows or pages. You can view the pages by dragging your finger left and right across the screen.
• To return quickly to the main screen, press the Home button.
11
Operation (Cont.)
From left to right: Bluetooth Staus indicator, Wi-Fi Signal Status, 3G Status, Battery Status, Current time (depends on current applications)
Click to search
for a file or
application
on the 3G
Smartphone, or
to search the
internet.
User
configurable
Apps
Click to display a list of all applications and widgets.
Contacts
Messaging
Call
Internet
Notifications
Favourite
Apps tray
