2U Expansion Platform
OSS-PCIe-2U-ENCL-EXP-4-1
OSS-PCIe-2U-ENCL-EXP-4-2
OSS-PCIe-2U-ENCL-EXP-8-2
One Stop Systems 2U Expansion Platform - 2 Rev x2
Table of Contents
1 Overview
1.a Introduction..................................................................................................................................... 3
1.b Description ..................................................................................................................................... 4
1.c Unpacking instructions ................................................................................................................... 4
2 Component Identification
2.a Front panel .....................................................................................................................................5
2.b LED panel identification..................................................................................................................5
2.c Rear panel ...................................................................................................................................... 5
2.d Internal ........................................................................................................................................... 6
2.e Base board ..................................................................................................................................... 6
2.f Riser card ........................................................................................................................................ 7
2.g System monitor .............................................................................................................................. 8
3 Install and Remove I/O Boards
3.a Removing top panel ....................................................................................................................... 9
3.b Removing connector cables ...........................................................................................................9
3.c Removing tray for I/O board installation .........................................................................................10
3.d Installing I/O boards ....................................................................................................................... 11
4 Servicing the Enclosure
4.a Removing a fan module ................................................................................................................. 20
4.b Installing a fan module ...................................................................................................................20
4.c Removing the power supply ...........................................................................................................20
4.d Installing the power supply............................................................................................................. 21
4.e Cleaning the air filter ......................................................................................................................21
4.f Installing rack slides .......................................................................................................................21
5 Specifications
5.a System monitor ..............................................................................................................................22
5.b Power supply..................................................................................................................................24
5.c Base board .....................................................................................................................................26
5.d Riser boards ................................................................................................................................... 27
Appendix A
A.1 System monitor GUI.......................................................................................................................A-1
A.2 Installing the system monitor GUI .................................................................................................. A-1
A.3 Using the system monitor GUI ....................................................................................................... A-1
A.4 Configuring sensor parameters...................................................................................................... A-2
A.5 Troubleshooting .............................................................................................................................A-3
Appendix B
B.1 System Monitor Command Protocol .............................................................................................. B-1
One Stop Systems 2U Expansion Platform - 3 Rev x2
1 Overview
1.a Introduction
The information contained in this manual may be subject to technical alteration as a result of constant upgrading by
One Stop Systems products. The attached documentation does not entail any guarantee on the part of One Stop
Systems with respect to technical processes described in the manual or any product characteristics set out in the
manual.
One Stop Systems does not accept any liability for any printing errors or other inaccuracies in the manual unless it can
be proven that One Stop Systems is aware of such errors or inaccuracies or that One Stop Systems is unaware of
these as a result of gross negligence and One Stop Systems has failed to eliminate these errors or inaccuracies for this
reason. One Stop Systems expressly informs the user that this manual only contains a general description of technical
processes and instructions, which may not be applicable in every individual case. In cases of doubt, please contact
One Stop Systems.
Note on the Guarantee: Due to their limited service life, parts which by their nature are subject to a particularly high
degree of wear (wearing parts) are excluded from the guarantee beyond that provided by law. This applies, for
example, to batteries.
Exemption from the Guarantee Obligation: One Stop Systems shall be exempted from its guarantee obligations if the
user fails to observe the safety instructions. One Stop Systems can only guarantee the safety, reliability and
performance of the device if all of the safety instructions are observed.
Exclusion of Accident Liability Obligation: One Stop Systems shall be exempted from the statutory accident liability
obligation if the user fails to observe the safety instructions.
Liability Limitation: In the event of damage to the device caused by failure to observe the safety regulations, One Stop
Systems shall not be required to honor the guarantee even during the guarantee period and shall be exempted from
the statutory accident liability obligation.
Safety Instructions
Please read this section carefully and observe the instructions for your own safety and correct use of the device.
Observe the warnings and instructions on the device and in the manual.
One Stop Systems products leave the factory in a perfectly safe condition. In order to maintain this condition and
ensure safe operation, the user must observe the instructions and warnings contained in this manual.
• The device must be used in accordance with the instructions for use.
• The equipment must be installed in accordance with the National Standards and/or Electrical Codes of the
country in question.
• The electrical installations in the room must correspond to the requirements of the respective regulations.
• Take care that there are no cables, particularly mains cables, in areas where persons can trip over them.
• Use only the cable supplied by One Stop Systems.
• Do not set up the device where it is exposed to direct sunlight, in the proximity of heat sources or in a damp
location. Make sure the device has adequate ventilation.
• Only devices and components may be connected to the interfaces of the system, which fulfill the requirements
of a SELV circuit (Safety extra Low Voltage) in accordance with EN60950.
• It must be assumed that safe operation is no longer possible:
o If the device has visible damage.
o If the device no longer functions.
• In these cases the device must be shut down and secured against unintentional operation.
• If extensions are made to the device the legal stipulations and the device specifications must be observed.
• Assembly, extensions, new settings, alterations or repairs may be carried out only as authorized by One Stop
Systems.
• Adjustment, maintenance or repair on the open device may be carried out only as authorized by One Stop
Systems.
• Only original accessories approved by One Stop Systems may be used.
• The inside of the enclosure is considered a “Service Access Area.”
Warning! Hazardous voltages exist.
One Stop Systems 2U Expansion Platform - 4 Rev x2
1.b Description
The Direct Attached 2U expansion platform provides four or eight PCIe x16 Gen2 slots, two PCIe x16 cable interfaces,
ample cooling, and an 850 watt power supply to support up to four GPU boards or other high speed I/O cards, and a
two PCIe x16 Gen 2 host cable adapters and two PCIe x16 one-meter cable.
Three versions available:
• Version 1 provides 2-slot wide PCIe x16 slots – P/N: OSS-PCIe-2U-ENCL-EXP-4-1
• Version 2 provides 4-slot wide PCIe x16 slots – P/N: OSS-PCIe-2U-ENCL-EXP-4-2
• Version 3 provides 4-slot wide PCIe x16 slots – P/N: OSS-PCIe-2U-ENCL-EXP-8-2
2U Accelerator Enclosure Specifications
Enclosure
• Dimensions: 17”W x 3.5” H x 21”D
• Removable front bezel with air filter
• Front panel LEDs
• One or two rear panel PCIe Gen 2 x16 interface(s)
• 4 individually removable fans
PCIe backplane
• Supports up to 8 full length, full height PCIe x16 boards
• Single x16 input to rear of enclosure
Power
• Dual 850W 1U removable power supplies
• V1: +12V @ 70A each
• V2: +5Vsb @ 3A each
System
monitoring/alarming
• Monitors up to 8 temperature sensors
• Monitors up to 4 fan tachometers
• Monitors up to 3 voltages including standard +12V, +3.3V, +5Vsb
Air filter
• 30 ppi open cell polyfoam
Operating environment
• Temperature range:
o Operating: 0°—50°C
o Storage: -40°—85°C
• Humidity range:
o Operating: 10% to 90% relative (non-condensing)
o Non-operating: 5% to 95% relative (non-condensing)
• Altitude range:
o Operating: 0 to 10,000 ft
o Storage: 0 to 50,000 ft
Agency compliance
• FCC Class A
• CE Mark
• UL
1.c Unpacking Instructions
1. If the carton is damaged when you receive it, request that the carrier's agent be present when you unpack and
inspect the equipment.
2. After unpacking, verify that all items listed in the packing list are present.
3. Observe all proper ESD safety procedures.
4. Inspect the equipment for shipping damage.
5. Save all packing material for storage or return shipment of the equipment.
6. For repairs or replacement of equipment damaged during shipment, contact One Stop Systems, Inc. to obtain
a Return Materials Authorization (RMA) number and further shipping instructions.
One Stop Systems 2U Expansion Platform - 5 Rev x2
2 Component Identification
2.a Front panel components
2.b LED panel components
Power LED behavior
Amber – Standby power
Green – On
Fault LED behavior
Off – No fault occurring
Solid red – Fault occurring (all fans will run at full speed)
1. Temperatures out of limits
2. Voltages incorrect
3. Fan failure or missing fan(s)
4. Missing riser board
5. Switch chip failure
Link and Slot LED behavior
Off – No link
On – All 16 lanes are active at 5 Gb/s
Blinking short on, short off – some lanes are reduced to 2.5 Gb/s
Blinking long on, short off – all lanes are active at 2.5 Gb/s
Blinking short on, long off – some lanes are reduced to 2.5 Gb/s and some lanes are inactive
NOTE: Version 1 will ONLY illuminate slot 1 and slot 2 LEDs.
2.c Rear panel components
PCIe x16 cable
connector
AC power supply
External system
monitor Ethernet
Removable filter bracket
Ground banana
jack
Thumb screw
LED panel
Thumb screw
Thumb screw
Power LED
Fault LED
Link LED
Slot LEDs
Thumb screw
AC power cord
connector
Removal
handle
One Stop Systems 2U Expansion Platform - 6 Rev x2
2.d Internal components
Version 1 - OSS-PCIe-2U-ENCL-EXP-4-1
Version 2 – OSS-PCIe-2U-ENCL-EXP-4-2
Version 3 – OSS-PCIe-2U-ENCL-EXP-8-2
Riser boards
Dual 850-watt
power supplies
System monitor
PCIe x16 cable
connector
Individually removable
fan modules
Power supply
backplane
Base board
Temperature
sensors
Temperature
sensors
External temperature
sensor headers x4
Riser boards
Base boards
Removable trays
Removable tray
Divider tray
thumb screws
One Stop Systems 2U Expansion Platform - 7 Rev x2
System monitor
data connector
DIP Switch 1
(SW1)
DIP Switch 2
(SW2)
2.e Base board components
2.f Riser card components
Version 1 – OSS-PCIe-2U-ENCL-EXP-4-1
Version 2 – OSS-PCIe-2U-ENCL-EXP-4-2
Version 3 – OSS-PCIe-2U-ENCL-EXP-8-2
PCIe x16 cable
connector
External temperature
sensor headers x4
LED/Fan board
data connector
External System
Monitor Ethernet
connector
Riser board
connector
Internal system
monitor Ethernet
connector
Power
connector
PCIe x16 edge
connector
PCIe x16 edge
connector
PCIe x16 slot
connector
PCIe x16 slot
connector
Switch
PCIe x16 edge
connector
Switch
PCIe x16 slot
connector
One Stop Systems 2U Expansion Platform - 8 Rev x2
Base board data
connector
System monitor
Ethernet connector
Programming
header
(factory use only)
Programming
power header
(factory use only)
2.g System monitor components
One Stop Systems 2U Expansion Platform - 9 Rev x2
3 Install and Remove I/O Boards
NOTE: The following instructions are for Version 1 only, see page 13 for Versions 2 & 3.
3.a Removing top panel
1. If the unit is operational, power it down and unplug the power cord.
2. Remove the unit from the rack.
3. Remove the top cover by unscrewing the thumb screw on the rear of the unit. A screwdriver may be used if
the screw is too tight. Slide the top cover toward the back and gently lift it from the chassis.
3.b Removing connector cables
4. Remove the power connector from the base board by releasing the clip on connector’s edge.
5. Remove the internal Ethernet connector from the base board.
One Stop Systems 2U Expansion Platform - 10 Rev x2
6. Remove the LED/fan board connector from the base board by pushing out on the ejector handles.
7. Remove the system monitor connector from the base board by pushing out on the ejector handles.
3.c Removing tray for I/O board installation
8. Remove two screws from the outer edge of the chassis, two screws from the bottom of the chassis and two
screws from the back of the chassis.
4 screws on
back of chassis
2 screws on
bottom of chassis
4 screws on
edge of chassis
One Stop Systems 2U Expansion Platform - 11 Rev x2
9. Gently slide the tray out of the chassis being sure to keep all cables clear of the tray.
10. Loosen the six base board screws to release the board from the tray.
3.d Installing I/O boards
11. Install the I/O board by carefully aligning connectors and pushing the board firmly into place.
NOTE: When installing boards into your system that the standard board brackets will not fit. One Stop can
provide new custom slot covers upon request and after receiving a drawing of the bracket. Contact the Sales
Department, sales@onestopsystems.com.
2 screws
2 screws
2 screws
One Stop Systems 2U Expansion Platform - 12 Rev x2
12. Tighten the six base board screws.
13. Reinsert the tray into the chassis lining up tabs on bottom of tray to the corresponding lances on the chassis
ensuring all the cables are out of the way.
14. Tighten the six chassis screws.
15. Plug the power connector into the I/O board.
16. Plug the system monitor cable into the base
board connector.
17. Plug the LED/fan board cable into the base
board connector.
18. Plug the internal system monitor Ethernet
cable into the base board connector.
19. Plug the power cable into the base board
connector.
20. Replace the top cover by aligning it with the coordinating notches on the chassis. Slide the top cover into
place. Tighten the thumb screw on the rear panel.
One Stop Systems 2U Expansion Platform - 13 Rev x2
NOTE: The following instructions are for Version 2 & 3 only, please see page 9 for Version 1.
3.a Removing top panel
1. If the unit is operational, power down and unplug the power cord.
2. Remove the unit from rack.
3. Remove the top cover by unscrewing the thumb screw on rear of unit. A screwdriver may be used if the
screw is too tight. Slide the top cover toward back and gently lift it from the chassis.
3.b Removing connector cables
4. From the top tray remove the power connector from the base board by releasing the clip on the connector’s
edge.
5. Remove the base board to base board connector.
One Stop Systems 2U Expansion Platform - 14 Rev x2
6. Remove two screws from the outer edge the chassis and two screws from the back of the chassis.
7. Gently slide the upper tray out of the chassis being sure to keep all the cables clear of the tray.
8. Remove the tray divider by lifting from the front edge toward the rear of the chassis. Remove the tray divider
by loosening the two thumb screws. Lift from the front edge toward the rear of the chassis and remove the
tray divider.
2 screws on
back of chassis
2 screws on
edge of chassis
One Stop Systems 2U Expansion Platform - 15 Rev x2
9. Remove the power connector from the base board by releasing the clip on the connector’s edge.
10. Remove the internal Ethernet connector from the base board.
11. Remove the base board to base board connector.
One Stop Systems 2U Expansion Platform - 16 Rev x2
12. Remove the LED/fan board connector from base board by pushing out on the ejector handles.
13. Remove the system monitor connector from the base board by pushing out on the ejector handles.
3.c Removing tray for I/O board installation
14. Remove two screws from the outer edge of the chassis, two screws from the bottom of the chassis and two
screws from the back of the chassis.
2 screws on
back of chassis
2 screws on
edge of chassis
2 screws on
bottom of chassis
One Stop Systems 2U Expansion Platform - 17 Rev x2
15. Gently slide the bottom tray out of chassis being sure to keep all the cables clear of the tray.
16. Loosen the six base board screws to release the board from the tray.
3.d Installing I/O boards
17. Install the I/O board by carefully aligning connectors and pushing the board firmly into place.
NOTE: When installing boards into your system that the standard board brackets will not fit. One Stop can
provide new custom slot covers upon request and after receiving a drawing of the bracket. Contact the Sales
Department, sales@onestopsystems.com.
2 screws
2 screws
2 screws
One Stop Systems 2U Expansion Platform - 18 Rev x2
18. Tighten the six base board screws.
19. Reinsert the bottom tray into the chassis lining up tabs on bottom of tray to corresponding lances on the
chassis ensuring all the cables are out of the way.
20. Tighten the six chassis screws.
21. Plug the power connector into the I/O board.
22. Plug the system monitor cable into the base
board connector.
23. Plug the LED/fan board cable into the base
board connector.
24. Plug the base board to base board connector
into the lower base board.
25. Plug the internal system monitor Ethernet cable
into the base board connector.
26. Plug the power cable into the base board
connector.
27. Replace the tray divider.
28. Reinsert the top tray into the chassis lining up tabs on bottom of tray to the corresponding lances on the
chassis ensuring all the cables are out of the way.
One Stop Systems 2U Expansion Platform - 19 Rev x2
29. Tighten the four remaining chassis screws.
30. Plug the base board to base board connector into the upper tray.
31. Plug the power connector into the upper tray.
32. Plug the power connectors into the upper tray I/O boards.
33. Replace the top cover by aligning it with the coordinating notches on the chassis. Slide the top panel into
place. Tighten the thumb screw on the rear panel.
2 screws on
back of chassis
2 screws on
edge of chassis
One Stop Systems 2U Expansion Platform - 20 Rev x2
4 Servicing the Enclosure
4.a Removing a fan module
1. With the unit powered down and the chassis top removed, locate the fan modules at the front of the unit.
2. Gently lift one fan module by the edges until the unit comes free.
4.b Installing a fan module
1. Tilt connector end of fan module into chassis.
2. Match bracket end of fan module with notches in chassis.
3. Snap into place.
4.c Removing the power supply
1. Power down the unit and unplug the power connector from the rear of the unit.
NOTE: You may perform this operation with the chassis lid on or off the unit.
2. Straighten power supply removal handle.
3. Loosen thumb screw. Screwdriver may be used if too tight.
One Stop Systems 2U Expansion Platform - 21 Rev x2
4. Using power supply removal handle, gently pull power supply out of chassis.
4.d Installing the power supply
NOTE: You may perform this operation with the chassis lid on or off the unit.
1. Insert new power supply into opening.
2. Tighten power supply thumb screw.
3. Fold power supply removal handle in toward unit.
4.e Cleaning the air filter
NOTE: It is necessary to clean the air filter frequently to ensure proper cooling and optimum system performance.
1. Loosen two thumb screws on front panel of unit.
2. Remove filter bracket.
3. Remove filter.
NOTE: Replace with new filter or clean filter thoroughly with clear water and allow to dry completely.
4. Fit filter to unit.
5. Replace filter bracket.
6. Tighten thumb screws.
4.f Installing rack slides
Attach the slides to
unit with five screws
on each side.
Extender
Install the slides into
the rack using an
extender if necessary.
Slide unit into rack.
One Stop Systems 2U Expansion Platform - 22 Rev x2
5 Specifications
5.a System monitor
The system monitor is designed to monitor the health and status of the chassis system. It communicates to a host via a
100Base-T Ethernet connection. It monitors 4 fan tachs, 8 temperature sensors and 3 voltages. All configuration
parameters are stored in non-volatile FLASH. All control and monitoring signals are routed via a single 40 pin connector to
the backplane where the I/O signals are efficiently routed to their corresponding functions. The ethernet signals are
connected through a RJ-45 connector. Refer to Appendix A: System Monitor GUI for a complete software interface.
The system monitor is tested for compatibility with:
o Monitors 8 temperatures
o Monitors 4 fan tachometers
o Monitors 3 voltages
• Communications to a host via an Ethernet
(TCP/IP, TelNet, and UDP) or I
2
C connection.
• Configuration parameters stored in non-volatile
FLASH
Specifications
Control and monitoring
features
• Monitors temperature sensors 1-8
• Monitors fan tachometers 2, 4, 6, 8
• Monitors voltages +12V, +5Vsb, +3.3V
• Monitors up to 8 general purpose inputs (may be used for DC power signals, etc.)
• Controls up to 8 general purpose outputs (may be used for LEDs, etc.)
Network configuration
• Stored in non-volatile memory and retained without power
Power consumption
• 237mA at 5V = 1.2 watts (the board runs on 5V only)
• Can be quickly and easily changed
• Dip switch settings allow network configuration to restore to default settings
Mechanical
• 4” (9cm)L x 3” (7.6cm)W
• 0.76” (1.9cm) stack height with passive heat sink
Operating environment
• Temperature range:
o Operating: 40°—85°C
o Storage: -40°—85°C
• Humidity range:
o Operating: 10% to 90% relative (non-condensing)
o Non-operating: 5% to 95% relative (non-condensing)
+5V (AUX) is automatically enabled after AC power is applied and is used to power all circuitry on the system monitor.
System monitor power-on sequence less than 1 second.
The system monitor will then monitor all 8 temperature sensors.
Network configuration
You must configure the system monitor so that it can communicate on a network. The unit’s configuration is stored in
nonvolatile memory and is retained without power. The network configuration can be changed at any time. The
Ethernet Controller performs a reset after you change and store the configuration.
DHCP
The unit ships with a default IP address of 192.168.1.99, which automatically enables DHCP. If a DHCP server exists
on the network, it will provide the unit with an IP address, gateway address, and subnet mask when the unit boots up.
IP address
The IP address must be set to a unique value in your network.
Set gateway IP address
The gateway address, or router, allows communication to other LAN segments. The gateway address should be the IP
address of the router connected to the same LAN segment as the unit. The gateway address must be within the local
network. The default is the gateway address has not been set.
SW1-4
SW1-3
SW1-2
SW1-1
Network Configuration
0 0 0
0
Normal use; retains network configuration as set up by the
user or previous default configuration.
0 0 0
1
Reserved
0 0 1
0
Reserved
0 0 1
1
Reserved
0 1 0
0
Reserved
0 1 0
1
Reserved
0 1 1
0
Reserved
0 1 1
1
Reserved
One Stop Systems 2U Expansion Platform - 23 Rev x2
Netmask: number of bits for host part
A netmask defines the number of bits taken from the IP address that are assigned for the host section.
NOTE: Class A: 24 bits; Class B: 16 bits; Class C: 8 bits.
Port number
The setting represents the source port number in TCP connections. It is the number that identifies the channel for
remote initiating connections. The default setting for Port 1 is 10001. The range is 1-65535, except for the following
reserved port numbers:
The port number functions as the TCP/UDP source port number for outgoing packets. Packets sent to the unit with this
port number are received to this channel. The port number selected is the Incoming TCP/UDP port and Outgoing
TCP/UDP source port. Use Port 0 when you want the outgoing source port to change with each connection. If the port
number is 0, the initial value of 5000 actively establishes a connection. Each subsequent connection increments the
number by 1. When the port number reaches 7999, it wraps around to 5000. Only use the automatic port increment
feature to initiate a connection using TCP. Set the port to a non-zero value when the unit is in a passive mode or when
you are using UDP instead of TCP. Although the System Monitor allows multiple clients to access the System Monitor
with the auto-incrementing Port number feature, undetermined results may occur if more than one user issues
commands or data simultaneously. Therefore, single client connection is recommended unless all clients can
guarantee completion of the current command and data transfer
before issuing another command.
Recovery mode
The system monitor provides a dip switch setting that allows the
Network configuration parameters to restore to their default settings.
This guarantees that communication with the System Monitor can be
reestablished in the event that the network settings are forgotten or
somehow set to unknown values as the result of communication or
software error. The Dip Switch is read only at power-up.
Network Class
Host Bits
Netmask
A
24
255.0.0.0
B
16
255.255.0.0
C
8
255.255.255.0
Port Numbers
Reserved for
1 – 1024
Reserved (well known ports)
9999
Telnet setup
14000-14009
Reserved for Redirector
30704
Reserved (77F0h)
30718
Reserved (77FEh)
ON
One Stop Systems 2U Expansion Platform - 24 Rev x2
5.b Power supply specifications
850-Watt Max
AC input
The table below lists AC input voltage and frequency range for continuous operation. The power supply is capable of
supplying full-rated output power over the input voltage ranges specified.
Parameter
Min
Nominal Input
Max
Unit
Vin Voltage
90
100-240
264
Vrms
Vin Frequency
47
50/60
63
Hz
Vin Current
12.0
A
The inrush current is less than 60A under the conditions of 240Vrms input and 25oC ambient cold start.
The leakage current is less than 2.0mA.
The repetitive ON/OFF cycling of AC input voltage will not damage the power supply.
The power supply can automatically recover from AC power loss.
The power supply is equipped with primary fuse for input over-current protection, and meet product safety requirement.
Power factor corrected AC input with PFC 0.95 min., and meet EN61000-3-2 Class D (2006)
DC output
DC output voltage regulations
The DC output voltages remain within the regulation ranges shown in Table 2 when measured at the load end of the
output connectors under all AC line, O/P loads, and environmental conditions. The voltage regulation will be maintained
under continuous operation for a period of time equal to the MTBF specified in section 5.2 at any steady state
temperature and operating conditions specified in section 3.
Output
Range Min Nom
Max
Unit
V1
+12V
±3% +11.64 +12.00
+12.36
Volt
V2
+5Vsb
±5% +4.75 +5.00
+5.25
Volt
DC output efficiency
The power supply efficiency is 85% min. under maximum rated load and 200 Vac line input.
DC output ripple and noise
The output ripple & noise specifications listed in Table 4 will be met throughout the load ranges as specified in section
2.2.2 and the nominal line input voltage conditions as specified in section 2.1. Ripple & noise is defined as periodic of
random signals over a frequency band of 10Hz to 20MHz. Measurements should be made with an oscilloscope with
20MHz bandwidth. Add a 10uF electrolytic capacitor and a 0.1uF ceramic capacitor across output terminal during ripple
& noise measurement.
Output
Max. Ripple (mV P-P)
Max Ripple & Noise (mV P-P)
+12V
120
120
+5Vsb
50
50
Over voltage protection
The power supply can provide latch-mode over voltage protection as defined in the table below.
Output
Min.
Nom.
Max.
Unit
+12VDC
13.8
12
15.6
Volts
Environmental
The following subsections define recommended environmental specifications and test parameters. Based on the typical
conditions to which an ATX power supply may be subjected during operation or shipment.
Temperature
Operating +0° C to +50° C
Non-operating -40° C to +85° C
One Stop Systems 2U Expansion Platform - 25 Rev x2
Humidity
Operating 10% to 90% relative humidity (non-condensing)
Non-operating 5% to 95% relative humidity (non-condensing)
Altitude
Operating 0 to 10,000 feet
Storage 0 to 50,000 feet
RoHS compliance
The power supply meets the requirement of RoHS Compliance with necessary exemption allowed.
Electromagnetic compatibility
The following subsections outline applicable product regulatory specifications for this power supply.
Emissions
The power supply can comply with FCC Part 15, EN55022: 2006, CISPR: 2006 meeting Class B for both conducted
and radiated emissions with a 3 db margin.
Immunity
The power supply can comply with EN 55024:1998 + A1 (2001) + A2 (2003).
Reliability component de-rating
The derating process promotes quality and high reliability. All electronic components are designed with conservative
derating for use in commercial and industrial environments.
Mean time between failures (MTBF)
100K hours minimum at full load 25° C per MIL HDBK217F calculated
One Stop Systems 2U Expansion Platform - 26 Rev x2
5.c Base board specifications
Temperature Sensors
• Temp sensor placed near rear of chassis
• Temp sensor placed near front of chassis
SYSMON Connector
• Takes all temperature sensors to System Monitor
• Takes all fan tachometer signals from LED/FAN board
• Provides all voltages to the System Monitor
• Receives fault signals from System Monitor
Fan/LED Board Connector
• Provides signals from base board to fan/led board
• Fan tachometer from each fan
• Fan control for each bank of fans
• Four fans per bank
• Front panel LEDs
Fault Detection
• Combines monitored fault signals and drives the front panel LED
Configuration DIP switch
function
• Force Power On
• Force fans full speed
• Selectx8/x16 modes for riser cards
SEE SW1 AND SW2 CHARTS BELOW
Fan Control
• PWM Fan speed controller
• Temperatures to be determined by riser card temp sensor
• Force fans to run at full speed if a fault is detected
• Force fans to run at full speed if riser temp control is not detected
Power Regulation
• +12V to +1V
• +12V to +3.3V
• +5Vaux to +3.3V aux
• +3.3V to +2.5V
DIP switch – SW1
DIP switch – SW2
Pin #
Name OFF
Name ON
1
Default
Force Power On
2
Max Fan Control
Default
3
Max Fan Control
Default
4
PCIe x8 Links
Default
Pin #
Name OFF
Name ON
1
Bottom Board Enable
Default
2
Passive Enable (-2)
Default
3
Default
Top Temperature
4
External Temperature
Default
One Stop Systems 2U Expansion Platform - 27 Rev x2
5.d Riser card specifications
Version 1
Version 2
Card edge connectors for
connecting to base board
• Non-standard pinouts for x1 and x16 PCIe card edge connectors
• Two x16PCIe slots
Power (per slot)
• +3.3V @ 3A
• +12V @ 5.5A
• +3.3Vaux @ 375mA
Fan controllers
• Two controllers. One for each side of the chassis
• Temperature variable speed control
• PWM control to each bank of four fans
• Two banks of four fans
• System faults will cause fans to run at full speed
• Missing riser card will cause fan bank to run at full speed
Card edge connectors for
connecting to base board
• Non-standard pinouts for x1 and x16 PCIe card edge connectors
• Two x16PCIe slots
Power (per slot)
• +3.3V @ 3A
• +12V @ 5.5A
• +3.3Vaux @ 375mA
PCIe Gen 2 switch
• PLX PEX8648
Fan controllers
• Two controllers. One for each side of the chassis
• Temperature variable speed control
• PWM control to each bank of four fans
• Two banks of four fans
• System faults will cause fans to run at full speed
• Missing riser card will cause fan bank to run at full speed
One Stop Systems 2U Expansion Platform - 28 Rev x2
Appendix A: System Monitor GUI
A.1 System monitor graphical user interface (GUI)
The Myclient.exe file monitors the sensors and status of your enclosure unit. It can be configured to monitor different
temperatures, voltages and fan speeds. The GUI is compatible with Windows 95, 98, NT, 2000 and XP.
A.2 Installing the system monitor GUI
1. Copy the Myclient folder on to compatible host PC.
2. Run Myclient.exe.
A.3 Using the system monitor GUI
1. In the TCP/IP portion of the GUI, click the IP dropdown menu to select the default IP address of 192.168.1.99,
indicated with a red 1 in the image below.
2. Click the Connect button.
3. Click the Refresh Status button.
4. Click the Automatic Monitor button to begin monitoring the system.
Item 1
Item 2
Item 3
Item 4
One Stop Systems 2U Expansion Platform - 29 Rev x2
A.4 Configure parameters
1. Click Stop button.
2. From the dropdown menu, select which parameter to configure.
3. Click Configure Sensor.
4. Select to enable or disable the selected
gauge with the Gauge Enabled
dropdown menu.
5. Select to enable an alarm with the
Alarm Enabled dropdown menu.
6. Select the type of alarm with the Alarm
Type menu.
7. Adjust the threshold levels for the
sensor.
8. Click Save and Exit to save changes.
9. Click Automatic Monitor to begin
monitoring the system with the new
sensor parameters.
Item 1
Item 3
Item 2
One Stop Systems 2U Expansion Platform - 30 Rev x2
A.4 Troubleshooting
The Myclient.exe visual basic program requires the MSWINSCK.OCX file. If your computer does not have this file or
the program does not work correctly, then follow the tasks listed below:
1. Back up your current copy of MSWINSCK.OCX if there is one present. Copy the new version to the same
location. See below for correct directory:
• For Windows 95, 98, or Me, the MSWINSCK.OCX file should be located in the WINDOWS\SYSTEM directory
on your C: drive (for Windows NT and 2000: \WINNT\system32).
• For Windows XP, NT or 2000, the MSWINSCK.OCX file should be located in the WINDOWS\SYSTEM32
directory on your C: drive
2. Using your mouse, click on the "Start" button and then click on "Run".
3. According to your Operating System, type the following command to register this library file:
• Windows 95, 98, or Me: regsvr32 \windows\system\MSWINSCK.OCX
• Windows NT or 2000: regsvr32 \WINNT\system32\MSWINSCK.OCX
• Windows XP: regsvr32 \windows\system32\MSWINSCK.OCX
4. You should see a message saying "DllRegisterServer ... succeeded"
One Stop Systems 2U Expansion Platform - 31 Rev x2
Appendix B: System Monitor Command
Protocol
The following section describes the basic command protocol to communicate with the System Monitor to retrieve
sensor data, configure, and control various I/O. All commands are sent via Ethernet through TCP/IP or Telnet
protocols. All commands sent to the System Monitor will be acknowledged by System Monitor returning the value
0xAC. Some commands require the System Monitor to update internal Flash that can take up to 20msec, therefore,
the application should not send additional commands until it has received the ACK (0xAC) from the System Monitor.
Any user timeout functionality should delay for 250msec worst case before retrying to communicate with the System
Monitor.
The sensors monitored are +12Volt, +5Volt, +3.3Volt, -12Volt, 8 Fan Tachs, 6 Temperature sensors, and 4 digital
Inputs. All sensors are configurable to enable sensor, enable alarm condition, and set type of alarm condition to Minor,
Major, or Critical. The Voltages, Temperature sensors, and Fan tach are configurable for a high and low threshold to
indicate an alarm condition. The Digital Inputs polarity are configurable to indicate an alarm condition for a high input
or low input.
Value
Command Description
0x30
GET_SYSMON_STATUS
0x31
GET_ALL_SENSOR_STATUS
0x32
GET_ALL_SENSOR_DATA
0x33
GET_SENSOR_DATA
0x34
CONFIGURE_SENSOR
0x35
WRITE_OUTPUT_REGISTER
0x36
READ_OUTPUT_REGISTER
0x37
SET_IP_ADDRESS
0x38
SET_IP_SUBNETMASK
0x39
SET_GATEWAY_IP_ADDRESS
0x3A
SET_PORT_NUMBER
Table 5: Command Protocol
The GET_SYSMON_STATUS command provides a global status of all alarm conditions with a single byte of data.
The GET_ALL_SENSOR_STATUS command allows all sensors to be monitored for alarm conditions with 4 bytes of
data.
The GET_ALL_SENSOR_DATA command provides all sensor data including alarm condition and type of alarm.
The GET_SENSOR_DATA command allows the user to monitor specific sensors.
The CONFIGURE_SENSOR command sets configurable sensor parameters such as enabling the sensor, enabling
alarm, setting the type of alarm (minor, major, or critical), setting the high and low thresholds for alarm conditions,
setting the polarity for the GP_Inputs, and setting the Fan Tach/Revolution divisor.
The WRITE_OUTPUT_REGISTER command allows the user to set General Purpose outputs to a TTL high or low
level.
The READ_OUTPUT_REGISTER command reads the value written to the WRITE_OUTPUT_REGISTER.
The SET_IP_ADDRESS command sets the IP Address of the SYSMON. Setting the IP Address to 0.0.0.0 will enable
DHCP.
The SET_IP_SUBNETMASK command sets the SUB NETMASK of the IP Address.
The SET_GATEWAY_IP_ADDRESS command sets the Gateway IP address.
The SET_PORT_NUMBER command sets the Port number.
0x30 GET_System Monitor_STATUS
App Sends Packet(0x30) to System Monitor
System Monitor Returns Packet(0xAC, Byte1) Byte 1 representing System Monitor status
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Byte 1
Reserved
Reserved
Reserved
Reserved
Factory
Defaults;
1=Default
0=User
Defined
Global
Minor
Alarm;
1=Alarm
0=Okay
Global
Major
Alarm;
1=Alarm
0=Okay
Global
Critical
Alarm;
1=Alarm
0=Okay
Table 6: GET_System Monitor_STATUS
One Stop Systems 2U Expansion Platform - 32 Rev x2
0x31 GET_ALL_SENSOR_STATUS
App Sends Packet(0x31) to System Monitor
System Monitor Returns Packet(0xAC, Byte 1, Byte 2, Byte 3, Byte 4) Bytes 1-4 representing status of each sensor
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Byte
1
+12 Volt
Supply
Status
+5 Volt
Supply
Status
+3.3 Volt
Supply
Status
-12 Volt
Supply
Status
+5V(AUX)
Supply
Status
Reserved
Reserved
Reserved
Byte
2
Fan 8
Status
Fan 7
Status
Fan 6
Status
Fan 5
Status
Fan 4
Status
Fan 3
Status
Fan 2
Status
Fan 1
Status
Byte
3
Reserved
Reserved
Temp 6
Status
Temp 5
Status
Temp 4
Status
Temp 3
Status
Temp 2
Status
Temp 1
Status
Byte
4
GP_Input
8 Status
GP_Input
7 Status
GP_Input
6 Status
GP_Input
5 Status
GP_Input
4 Status
GP_Input
3 Status
GP_Input
2 Status
GP_Input
1 Status
Notes: Sensor Alarm Status; 1=Alarm, 0=Okay
Table 7: GET_ALL_SENSOR_STATUS
0x32 GET_ALL_SENSOR_DATA
App Sends Packet(0x32) to System Monitor
System Monitor Returns Packet(0xAC, Bytes 1 – 64) Bytes 1 – 64 represent data for each sensor
Sensor
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
+12Volt
Byte 1
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Data Bit 11
Data Bit 10
Data Bit 9
Data Bit 8
+12Volt
Byte 2
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
+5Volt
Byte 3
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Data Bit 11
Data Bit 10
Data Bit 9
Data Bit 8
+5Volt
Byte 4
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
+3.3Volt
Byte 5
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Data Bit 11
Data Bit 10
Data Bit 9
Data Bit 8
+3.3Volt
Byte 6
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
-12Volt
Byte 7
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Data Bit 11
Data Bit 10
Data Bit 9
Data Bit 8
-12Volt
Byte 8
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
+5Volt
(AUX)
Byte 3
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Data Bit 11
Data Bit 10
Data Bit 9
Data Bit 8
+5Volt
(AUX)
Byte 4
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Reserved
Byte 11
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 12
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 13
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 14
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 15
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 16
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Fan 8
Byte 17
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 8
Byte 18
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 7
Byte 19
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 7
Byte 20
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 6
Byte 21
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 6
Byte 22
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 5
Byte 23
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
One Stop Systems 2U Expansion Platform - 33 Rev x2
Fan 5
Byte 24
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 4
Byte 25
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 4
Byte 26
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 3
Byte 27
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 3
Byte 28
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 2
Byte 29
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 2
Byte 30
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Fan 1
Byte 31
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Tach/Rev
Divisor
Fan 1
Byte 32
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Reserved
Byte 33
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 34
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 35
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Reserved
Byte 36
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
Reserved
Temp 6
Sensor
Byte 37
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Reserved
Temp 6
Sensor
Byte 38
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Temp 5
Sensor
Byte 39
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Reserved
Temp 5
Sensor
Byte 40
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Temp 4
Sensor
Byte 41
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Reserved
Temp 4
Sensor
Byte 42
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Temp 3
Sensor
Byte 43
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Reserved
Temp 3
Sensor
Byte 44
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Temp 2
Sensor
Byte 45
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Reserved
Temp 2
Sensor
Byte 46
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Temp 1
Sensor
Byte 47
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Reserved
Reserved
Reserved
Reserved
Temp 1
Sensor
Byte 48
Data Bit 7
Data Bit
6
Data Bit
5
Data Bit
4
Data Bit 3
Data Bit 2
Data Bit 1
Data Bit 0
Input 8
Sensor
Byte 49
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 8
Sensor
Byte 50
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 8
Input 7
Sensor
Byte 51
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 7
Sensor
Byte 52
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 7
Input 6
Sensor
Byte 53
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 6
Sensor
Byte 54
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 6
Input 5
Sensor
Byte 55
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 5
Sensor
Byte 56
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 5
Input 4
Byte 57
Sensor
Alarm
Alarm
Alarm
Polarity
Reserved
Reserved
Reserved
One Stop Systems 2U Expansion Platform - 34 Rev x2
Sensor
Enable
Enable
Bit 1
Bit 0
0=Alarm if low
1=Alarm if
high
Input 4
Sensor
Byte 58
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 4
Input 3
Sensor
Byte 59
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 3
Sensor
Byte 60
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 3
Input 2
Sensor
Byte 61
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 2
Sensor
Byte 62
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 2
Input 1
Sensor
Byte 63
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Polarity
0=Alarm if low
1=Alarm if
high
Reserved
Reserved
Reserved
Input 1
Sensor
Byte 64
Reserved
Reserve
d
Reserve
d
Reserve
d
Reserved
Reserved
Reserved
GP_Input 1
Table 8: GET_ALL_SENSOR_DATA
Notes common to all sensors:
Sensor Enable; 1=Disabled, 0=Enabled
Sensor Alarm Enable; 1=Disabled 0=Enabled
Alarm (bit 1=0 AND bit 0=0) = No Alarm
Alarm (bit 1=0 AND bit 0=1) = Minor Alarm
Alarm (bit 1=1 AND bit 0=0) = Major Alarm
Alarm (bit 1=1 AND bit 0=1) = Critical Alarm
Sensor Specific Notes:
+12Volt = 12bits, LSB=0.00330V
+5Volt = 12bits, LSB=0.00135V
+3.3Volt = 12bits, LSB=0.000085V
-12Volt = 12bits, LSB= -0.01769V
Fan = 8bits; Data value = Revolutions / Second
Tachs/Rev Divisor; 0= 1 Tach/Revolution, 1= 2
Tachs/Revolution
Temperature Sensor = 8 bits; Data Value = 2’s
Compliment Temperature in degrees Celsius
GP_Input Value = Data Bit 0
GP_Input Data Bit 11 is the Alarm polarity bit;
0=Alarm on low input, 1=Alarm on high input
GP_Input Data Bits 10-1 are reserved
0x33 GET_SENSOR_DATA
App Sends Packet(0x33, 0xYY) to System Monitor
(YY represents the sensor to read)
System Monitor Returns Packet(0xAC, Byte 1, Byte
2) Bytes 1 – 2 represent the data for the sensor; each
sensor is made up of 2 data bytes
Sensor
Index
Sensor
YY=0x01
+12Volt Supply
YY=0x02
+5Volt Supply
YY=0x03
+3.3Volt Supply
YY=0x04
-12Volt Supply
YY=0x05
+5Volt (AUX) Supply
YY=0x06
Reserved
YY=0x07
Reserved
YY=0x08
Reserved
YY=0x09
FAN 8
YY=0x0A
FAN 7
YY=0x0B
FAN 6
YY=0x0C
FAN 5
YY=0x0D
FAN 4
YY=0x0E
FAN 3
YY=0x0F
FAN 2
YY=0x10
FAN 1
YY=0x11
Reserved
YY=0x12
Reserved
YY=0x13
Temperature 6
YY=0x14
Temperature 5
YY=0x15
Temperature 4
YY=0x16
Temperature 3
YY=0x17
Temperature 2
YY=0x18
Temperature 1
YY=0x19
GP_Input 8
YY=0x1A
GP_Input 7
YY=0x1B
GP_Input 6
YY=0x1C
GP_Input 5
YY=0x1D
GP_Input 4
YY=0x1E
GP_Input 3
YY=0x1F
GP_Input 2
YY=0x20
GP_Input 1
Table 9: SENSOR INDEX = YY
One Stop Systems 2U Expansion Platform - 35 Rev x2
Sensor
Index
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
YY
Byte 1
Sensor
Enable
Alarm
Enable
Alarm
Bit 1
Alarm
Bit 0
Data
Bit 11
Data
Bit 10
Data
Bit 9
Data
Bit 8
YY
Byte 2
Data Bit
7
Data
Bit 6
Data
Bit 5
Data
Bit 4
Data
Bit 3
Data
Bit 2
Data
Bit 1
Data
Bit 0
Table 10: GET_SENSOR _DATA – Ox33
Notes common to all sensors:
Sensor Enable; 1=Disabled, 0=Enabled
Sensor Alarm Enable; 1=Disabled 0=Enabled
Alarm (bit 1=0 AND bit 0=0) = No Alarm
Alarm (bit 1=0 AND bit 0=1) = Minor Alarm
Alarm (bit 1=1 AND bit 0=0) = Major Alarm
Alarm (bit 1=1 AND bit 0=1) = Critical Alarm
Sensor Specific Notes:
+12Volt = 12bits, LSB=0.00330V
+5Volt = 12bits, LSB=0.00135V
+3.3Volt = 12bits, LSB=0.000085V
-12Volt = 12bits, LSB= -0.01769V
Fan = 8bits; Byte 2 = Revolutions / Second
Tachs/Rev Divisor = Data Bit 8; 0= 1 Tach/Revolution, 1= 2 Tachs/Revolution
Fan Sensor Data Bits 11-9 are reserved
Temperature Sensor = 8 bits; Byte 2 = 2’s Compliment Temperature in degrees Celsius
Temperature Sensor Data Bit 11-8 are reserved
Input Value = Data Bit 0
Input Value Data Bit 11 is the Alarm polarity bit; 0=Alarm on low input, 1=Alarm on high input
Input Register Data Bits 10-1 are reserved
Customer Definitions
GP Input 1 = +12V Power Good
GP Input 2 = +5V Power Good
GP Input 3 = +3.3V Power Good
GP Input 4 = -12V Power Good
GP Input 5 = Reserved
GP Input 6 = Reserved
GP Input 7 = Reserved
GP Input 8 = Reserved
0x34 CONFIGURE_SENSOR
App Sends Packet(0x34, 0xYY, Byte 1, Byte 2, Byte 3, Byte 4) to System Monitor (YY represents the sensor to
configure)
System Monitor Returns Packet(0xAC)
Sensor
Index
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
YY
Byte
1
Enable
Sensor
0 =
Enabled
1 =
Disabled
Enable
Alarm
0 =
Enabled
1 =
Disabled
Alarm
Bit 1
Alarm
Bit 0
High
Threshold
Data Bit
11
High
Threshold
Data Bit
10
High
Threshold
Data Bit 9
High
Threshold
Data Bit 8
YY
Byte
2
High
Threshold
Data Bit 7
High
Threshold
Data Bit 6
High
Threshold
Data Bit 5
High
Threshold
Data Bit 4
High
Threshold
Data Bit 3
High
Threshold
Data Bit 2
High
Threshold
Data Bit 1
High
Threshold
Data Bit 0
YY
Byte
3
Reserved
Reserved
Reserved
Reserved
Low
Threshold
Data Bit
11
Low
Threshold
Data Bit
10
Low
Threshold
Data Bit 9
Low
Threshold
Data Bit 8
YY
Byte
4
Low
Threshold
Data Bit 7
Low
Threshold
Data Bit 6
Low
Threshold
Data Bit 5
Low
Threshold
Data Bit 4
Low
Threshold
Data Bit 3
Low
Threshold
Data Bit 2
Low
Threshold
Data Bit 1
Low
Threshold
Data Bit 0
Table 11: CONFIGURE_SENSOR – Ox34
One Stop Systems 2U Expansion Platform - 36 Rev x2
Notes common to all sensors:
Alarm (bit 1=0 AND bit 0=0) = No Alarm
Alarm (bit 1=0 AND bit 0=1) = Minor Alarm
Alarm (bit 1=1 AND bit 0=0) = Major Alarm
Alarm (bit 1=1 AND bit 0=1) = Critical Alarm
Sensor Specific Notes:
+12Volt Threshold = 12bits, LSB=0.00330V
+5Volt Threshold = 12bits, LSB=0.00135V
+3.3Volt Threshold = 12bits, LSB=0.000085V
-12Volt Threshold = 12bits, LSB= -0.01769V
Fan Thresholds use only the lower 8bits to determine Revolutions / second; bits 11-9 are ignored
Fan Tachs/Rev Divisor = Data Bit 8; 0= 1 Tach/Revolution, 1= 2 Tachs/Revolution
Temperature Sensor = 8 bits; Byte 2 = 2’s Compliment Temperature in degrees Celsius
Temperature Sensor Threshold Data Bits 11-8 are ignored
GP_Input Polarity bit = High Threshold Data bit 11; All other Threshold Data bits are ignored.
Customer Definitions
GP Input 1 = +12V Power Good
GP Input 2 = +5V Power Good
GP Input 3 = +3.3V Power Good
GP Input 4 = -12V Power Good
GP Input 5 = Reserved
GP Input 6 = Reserved
GP Input 7 = Reserved
GP Input 8 = Reserved
0x35 WRITE_OUTPUT_REGISTER
App Sends Packet(0x35, Byte 1) to System Monitor (Byte 1, bits 7-0 represents data written to OUTPUT)
System Monitor Returns Packet(0xAC)
Customer Definitions
Bit 0 = LED #1 Sysmon Good – Masked from Host
Bit 1 = LED #2 – GREEN; Temperature Good – Masked from Host
Bit 2 = LED #2 – RED; Temperature Good – Masked from Host
Bit 3 = LED #3 Power Good – Masked from Host
Bit 4 = LED #4 System UP – Masked from Sysmon; Default “OFF”
Bit 5 = LED #5 Minor Fault – Masked from Sysmon; Default “OFF”
Bit 6 = LED #6 Major Fault – Masked from Sysmon; Default “OFF”
Bit 7 = Enable ALL DC Power Outputs
0x36 READ_OUTPUT_REGISTER
App Sends Packet(0x36) to System Monitor
System Monitor Returns Packet(0xAC, Byte 1) Byte 1, bits 7-0 represents data read from the OUTPUT register
0x37 SET_IP_ADDRESS
App Sends Packet(0x37, Byte 1, Byte 2, Byte 3, Byte 4) to System Monitor
For IP ADDRESS: www.xxx.yyy.zzz
; Byte 1 = www, Byte 2 = xxx, Byte 3 = yyy, Byte 4 = zzz
System Monitor Returns Packet(0xAC)
0x38 SET_IP_SUBNETMASK
App Sends Packet(0x38, Byte 1, Byte 2, Byte 3, Byte 4) to System Monitor
For SUB NETMASK www.xxx.yyy.zzz
; Byte 1 = www, Byte 2 = xxx, Byte 3 = yyy, Byte 4 = zzz
System Monitor Returns Packet(0xAC)
0x39 SET_GATEWAY_IP_ADDRESS
App Sends Packet(0x39, Byte 1, Byte 2, Byte 3, Byte 4) to System Monitor
For GATEWAY IP ADDRESS: www.xxx.yyy.zzz
; Byte 1 = www, Byte 2 = xxx, Byte 3 = yyy, Byte 4 = zzz
System Monitor Returns Packet(0xAC)
0x3A SET_PORT_NUMBER
App Sends Packet(0x3A, Byte 1, Byte 2) to System Monitor
For PORT NUMBER: www.xxx.
; Byte 1 = www, Byte 2 = xxx,
System Monitor Returns Packet(0xAC)
Loading...
