Route Printer™- Serial and Wireless Portable Impact Printer
™
RP
The Route Printer Series is a portable, full-page dot
matrix printer that is rugged enough to be used in
the cab of a truck or carried into a remote
receiving area. The RP 2000 accommodates
®
Symbol
handheld computers. Its intelligent cradle allows
the handheld computer to communicate with the
printer as well as charge the handheld computer
batteries.
The RP 2000 with Bluetooth
receipts and invoices wherever they are needed.
The features of this one-piece printing solution
include:
• Paper capacity of up to 200 sheets of 8.5" x 11" paper.
•
Ability to print 4-part delivery receipts and invoices.
• Unique paper feed design that literally eliminates
paper jams.
•
In-vehicle 12-volt system or internal battery pack.
Ease of Use Minimizes Training. The RP printer
automatically “wakes up” upon receipt of data and
returns to sleep mode after printing, ensuring
maximum battery life.
PDT8000, PDT8046, and MC9000-S
®
enables the printing of
Investment Protection. Printer fonts and the
operating system are stored in Flash memory, so
upgrading using the office PC is easy. The RP Series
speaks your language – any language.
cooperation with Bitstream©fonts, any
In
international character set can be added. This
ensures that RP Series printers will meet your
language needs today and tomorrow.
No Paper Jams. In the early 80’s, O’Neil created a
unique paper feed design that literally eliminates
paper jams. It allows a lot of paper to fit in a small
package. The printer can be held in any
orientation, even upside down, without jamming...
perfect for portable applications.
Rugged and Reliable. With uncompromising
standards, the RP is engineered throughout to
withstand even the most punishing portable
applications. It can take all the bumps and knocks
inherent in the mobile workplace. Its rock-solid
print mechanism is proven to provide years of
service where other printers fail. The full one year
warranty, even on the printhead, offers peace of
mind with our promise to stand behind every
product we sell.
The O’Neil printer has
“
been a workhorse for us
since the day we started
using it four years ago.
It’s tough. Ash and dust
doesn’t bother it. It
doesn’t break. We had
a truck run over one,
and all we had to do
was change the case.
”
Alejandro Amézquita
Electronics Shop S.A.
u Wireless Bluetooth
When the RP 2000 printer is configured with an
Integrated Bluetooth
realize all of the convenience, power efficiencies
and cost benefits of a wireless personal area
network. O’Neil was the first portable printer
manufacturer to incorporate the Bluetooth protocol
in Flash memory, eliminating the need for costly
software and hardware upgrades whenever the
wireless specification changes.
®
Connectivity
®
module, mobile workers can
www.oneilprinters.com
Page 2
Standard Features at a Glance
• Supports Symbol®PDT8000, PDT8046, MC9060-S, and MC9090-S hand held
computers for critical route accounting applications.
• Reports, invoices and receipts are downloaded and printed on the spot.
• Optional real-time anywhere, anytime connectivity enables data to be uploaded
or accessed without a physical network connection.
• Rugged design withstands the harshest of road conditions.
• Easy-to-load/unload paper reduces driver training and enhances reliability.
• Battery pack supplies power to print up to 201 - 11” invoices.
• Printer fonts are stored in Flash memory and are easily upgraded as new fonts
become available.
• Intelligent power management settings extend battery life.
• Unique paper feed design eliminates paper jams.
• Cords and adapters are neatly stored and ready for immediate use.
™
RP
Specification Highlights RP
Physical Characteristics RP™2000, Serial RP™2000, Bluetooth
Dimensions 14" x 17.5" x 5.125" 14" x 17.5" x 5.125"
Weight (printer only) 129.7 oz (3.677 kg) 131.5 oz (3.691 kg)
Weight (with batteries & paper) 146.1 oz (4.142 kg) 149.5 oz (4.238 kg)
Drop Specification 3 ft (0.9 m) 3 ft (0.9 m)
User Environment
Operating Temperature -4° F to 122° F (-20° C to 50° C)
Storage Temperature -40° F
Charging Temperature 41° F to 104° F (5° C to 40° C)
Relative Humidity 10% to 90% non-condensing
ESD Protection 8 kV Air, 4 kV contact
Communications
Serial
®
Bluetooth
Network Environment Ad hoc environment
Protocol v1.2 (compatible with v1.1 devices)
Cradle Standard PDT 8000, 8046, or MC9000-S interface connector
Print Technology
Printhe ad 9 pin impact
Printhead Life 100 million dots
Print Speed
Ribbon Cartridge Life
Media
Type NCR, Plain (up to 4-ply)
Width 3" minimum, 8.5"/A4 maximum
Capacity
Options / Accessories
• AC Adapter
• Cigarette Lighter Adapter
• Download Cable • Ribbon
• Extended Paper T
ray
RS-232, up to 115.2k baud
270 characters per second
2,000,000 characters
Up to 200 sheets
• Fuse Box Power Cable Kit
• Power Extension Kit
• Spare Batteries
(355.6 x 444.5 x 130.2 mm) (355.6 x 444.5 x 130.2 mm)
° F (without HHC) (-40° C to 70° C)
to 158
™
Route Printer
™
Power Source
Battery 12V NiMH, 4000 mAh
DC Input 1 (AC Adapter) 12-15V, built-in spike and surge protection
DC Input 2 (Cigarette Lighter Adapter) 12-15V, built-in spike and surge
Endurance Serial Prints approx. 245 – 8.5” x 11" invoices on a single battery
Printer Recharging 3.5-4.5 hours from AC adapter or cigarette lighter
Hand-Held Recharging Approximately 3 hours (depending on hand-held model)
Fonts & Languages
Memory Capacity Flash/RAM Memory: 1024kB/512kB
Standard Fonts 10 CPI Pica/Elite & 12 CPI Pica/Elite
International Characters
Graphics Supports storage of graphics/logos in Flash memory and
Agency Approvals
FCC B, CE, UL/cUL
Warranty
1 year (including printer case and printhead*)
protection
Bluetooth Prints approx. 188 – 8.5” x 11" invoices on a single battery
charge
charge
from AC adapter or cigarette lighter
(additional fonts available)
, Arab-S, Arab-E, Cyrillic (Cy110 & CY210),
Arab-T
Greek (GRDOS & GR
Latin & Turkish (additional international characters available)
transient “print once” graphics
Hebrew (HB110, HB210, HB310),
WIN),
* When used with approved ribbon.
RP™and Route Printer™are trademarks of O’Neil Product Development, Inc. Specifications
are subject to change without notice. All product and company names are trademarks,
service marks or registered trademarks of their respective owners.
Copyright 2007, O’Neil Product Development, Inc.
rev. 7/07 Made in the U.S.A.
