One for All SV-1500 User Manual

SV-1500

R

Wireless Phone Line Extender

2 WWW.ONEFORALL.COM

Safety precautions 2

Thank you 3

Product 3

Installation 4

Trouble-Shooting 6

Customer Service 7

Unpacking

Carefully remove units from packaging. If there is any visible damage,
DO NOT attempt to operate the equipment. Notify your dealer or shipping
carrier immediately. Keep this guide for future use.

• Do not attempt to plug in your Wireless Phone Line Extender until
you have read this owners manual.

• Read, understand and follow all instructions.

• Unplug the system from the wall outlet before cleaning. Do not use

liquied or aerosol cleaners. Use a damp cloth for cleaning.

• Do not use this system near water; for example, near a bath tub,
wachbowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.

• This system should never be placed near or over a heat radiator or
registrer.

• This system should not be placed in a built-in installation unless proper
ventilation is provided.

• This system should only be operated from the type of power source
indicated in this guide and on the system label. If you are not sure of
the type of power supplied to your home or building, consult your
local power company.

• Never spill liquid of any kind on the system.

• Do not disassemble or open the system. Service must be done by a

qualified service center of ONE FOR ALL.

• Service must be done by a qualified service center of ONE FOR ALL.

• Do not plug the Wireless Phone Line Extender into a surge protector.

• The Wireless Phone Line Extender System does not operate during a

power outage.

• The Wireless Phone Line Extender System can only be used for a single
(analog) phone line.

• Be sure to plug the BASE UNIT in first before the EXTENSION UNIT.

• If you cannot get a dial tone, unplug both units and follow the

instructions in the “Trouble Shooting” section.

• It is very important that directions are followed in order. In the event
of a problem unplug both units, remove all cords and start again.

• Choose an easily accessible socket-outlet close to the equipment you
want to use.

• Equipment connected to the base and extension must be approved for
the telephone system.

Table of Contents

Safety and operation precautions

WWW.ONEFORALL.COM 3

Thank you for purchasing the ONE FOR ALL “Wireless Phone Line
Extender”. ONE FOR ALL is continuously striving to develop, produce and
market high quality innovative products. We hope the “Wireless Phone
Line Extender” will give you the freedom of wireless control.

BASE UNIT

1 BASE UNIT with attached telephone plug.

2 Adaptor for connection between telephone cord and wall

phone socket.

3 Telephone socket for connection with existing telephone.

4 The recessed button used for setting the SECURITY FEATURE.

5 The in-use “green light” indicator used also for setting the

SECURITY FEATURE.

EXTENSION UNIT

6 EXTENSION UNIT with telephone socket for connection with

second telephone, PC, Set-Top Box or fax.

7 The recessed button used for setting the SECURITY FEATURE.

8 The in-use “green light” indicator also used for setting the

SECURITY FEATURE.

The EXTENSION UNIT can be moved from any location to any other
location within the home to create a phone socket from any electrical
power main.

Thank You

Product

5
4

1

3

8
7

6

2

4 WWW.ONEFORALL.COM

Installation

Installing the “BASE UNIT”

1

. Unplug the existing phone from the phone-line socket and connect it

to the BASE UNIT.

2. Plug the adaptor into the wall phone socket and connect the tele-

phone cord of the BASE UNIT to this adaptor.

3. Now plug the BASE UNIT into a power main.

Note: The SV-1500 should not be used in conjuction with a power surge
protector.

Installing the “EXTENSION UNIT”

4. Plug the EXTENSION UNIT into a power main where you want a new

phone socket.

Note: The SV-1500 should not be used in conjuction with a power surge
protector.

5. Connect EXTENSION UNIT with second telephone, Set-Top Box or fax

using a telephone cord. There should now be a dial tone when your
phone/fax is taken off the hook.

Once steps 1 - 5 have been completed in the installation sequence above,
you can now set the security, addressing the BASE UNIT to the EXTENSION
UNIT.

Setting the “SECURITY FEATURE”

This product comes with a SECURITY FEATURE to make sure that nobody
else owning a “Wireless Phone Line Extender” can connect his “EXTENSION
UNIT” to your “BASE UNIT”. The SECURITY FEATURE makes sure that your
“BASE-” and “EXTENSION-“ unit synchronize onto one of the possible
65,000 codes to prevent access from an unauthorized unit. Please follow
steps 6 – 8 to complete the installation.

6. Using a small pointed object, press the recessed button on the side of

the BASE UNIT. The green light on the side of the BASE UNIT will come
on. This will stay lit during the security programming sequence.

7. Now, using the same small pointed object, press the recessed button

on the side of the EXTENSION UNIT. The green light on the side of the
EXTENSION UNIT will flash once. This is your notification that the
security programming for this extension is complete.

- If the green button is flashing repeatedly,.

Push the recessed button
again. If the green button continues to flash it is telling you that the
security programming has not been completed successfully and the SV­1500 will not function. You can rectify the problem by first going back
to step 6 and retrying the sequence. It this does not work then go
back to step 1. If it still does not work then the user should go to the
trouble-shooting guide for further options.

- To program additional EXTENSION UNITS to the same BASE UNIT,
repeat step 7 with the additional EXTENSIONS. This programming
sequence allows five minutes since the last UNIT was programmed, to
program the next UNIT.

8. Once all EXTENSIONS have been coded, you will need to verify the dial

tone for each phone.

WWW.ONEFORALL.COM 5

Most difficulties associated with the Wireless Phone line Extender system
are due to improper installation.
If the steps below do not solve your problem, remove both units from the
electrical outlets, remove all cords and re-install making sure to follow the
INSTALLATION instructions carefully.

Your situation (system location, characteristics of the home/office) can, in
some instances, affect performance and occasional interference may be
experienced. Some static, buzzing or humming at certain locations within
the operating area is possible. However, if you experience unusual levels of
noise, follow the trouble shooting actions below.

You Should Know

The following list of situations is provided to inform you of things that you
may encounter when using the system. It is intended to help you get the
best performance possible.

Power Outages Only the telephone plugged into the

BASE UNIT operates during a power
outage.

Two-Line Phone Operations If two lines are being used, only one

line can operate through the
Wireless Phone Line Extender.
A single base and extension hook-up
will only operate the phone line to
which the base is connected.

Ground Fault Circuits It is recommended that the Wireless

Phone Line Extender not be set up
or operated using GFI (Ground Fault
Interrupters) mains. (e.g. bathrooms,
outdoor use, etc.)

Problem:

No dial tone

Static / Interference

Can't dial out

Does not ring

Extension beeps

Will not security program

Solution:

Check connections, check outlet for power, try
new cords, move base and/or extension. Repeat
the security programming starting with step six.

Move base and/or extension (halogen lamps,
light dimmers, touch lamps, and computer
socket strips can cause some static).

Decrease distance between units. If
problems continue call customer service.

Decrease distance between units. If
problems continue call customer service.

Repeat the security programming
starting with step one.

Try programming the unti following steps 6 and
7 with the base and extension units in close
proximity from each other. Note: The units can

be moved to
different locations without losing security
programming.

If problems continue call customer service

Trouble Shooting

6 WWW.ONEFORALL.COM

Customer Service

If you still have questions about the operation of your Wireless Phone Line
Extender and could not find the answer(s) in the trouble shooting section,
you may want to contact the customer service department for assistance or

visit our Internet-site:

www.oneforall.com

Our internet-site has many advantages:

- 24 hours access

- no waiting time

- page for Frequently Asked Questions

- info about the ONE FOR ALL product range

Before contacting us, by Fax, E-mail or Phone, make sure to have
the following information available;

1. The ONE FOR ALL SV- 1500 Wireless Phone Line Extender.

2. The date of purchase (.........../.........../...........).

3. Clear description of the problem.

In the UK:

[e-mail]
Fax : [phone]
Tel : [phone] (premium number; £ 1 per minute)

WWW.ONEFORALL.COM 7

Declaration of Conformity

Phonex Broadband Corporation declares as manufacturer, that the product
sold under One For All model SV-1500/00/002 (Phonex part PX-281)
conforms with the following directives:

89/336/EEC EMC Directive
73/23/EEC Low Voltage Directive
99/5/EC R&TTE Directive
93/68/EEC CE Marking Directive

Following the provisions of European Directive 99/5/EC.

A copy of the complete declaration can be found at

www.oneforall.com

NOTE:

This product is designed for use in the UK and must be used and installed
as instructed in the user manual. This equipment has been tested and
found to conform with the European Directives that provide protection
from electromagnetic interference. However, there is no guarantee
that interference from this equipment will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, the user will be required to correct the
interference or cease operation of the equipment.

SV-1500

702518

HdH-1102

Guarantee UK UNIVERSAL ELECTRONICS INC./ONE FOR ALL warrants to the origi­nal purchaser that this product will be free from defects in materials and workman­ship under normal and correct use for a period of one (1) year from the date of
original purchase. This product will be replaced free of charge if it has been proven
to be defective within the one (1) year warranty period. This warranty does not
cover cartons, carrying cases, batteries, broken or marred cabinets or any other item
used in connection with the product. Any further obligation than listed above is
excluded. Please notice that we need your purchase receipt so that we may estab­lish your eligibility for service.

Universal Electronics BV
Europe & International
P.O. Box 3332
7500 DH, Enschede
The Netherlands
