one URC-6210, URC-6211 User Manual

Instruction manual . . . . .P. 2

English

Bedienungsanleitung . .s. 10

Deutsch

Mode d’emploi . . . . . . .P. 18

Français

Guía del usario . . . . . . .P. 26

Español

Manual de instruções . .P. 34

Português

Istruzioni per l’uso . . . .P. 42

Italiano

Gebruiksaanwijzing . . .P. 50

Nederlands

Magyar

Polski

Česky

Használati útmutató

Instrukcja obsługi

Návod k použití

.P. 58

. . . . .P. 66

. . . . . . .P. 74

URC-6210/6211

Universal remote

Universal Fernbedienung

Télécommande universelle

Mando a Distancia Universal

Telecomando Universal

Telecomando Universale

Universele Afstandsbediening

Univerzális távvezérlő

Uniwersalny pilot zdalnego sterowania

Univerzální dálkové ovládání

English

Table of Contents

INSTALLING THE BATTERIES 3

FEATURES AND FUNCTIONS 3

SET UP

(To set up the ZAPPER for your Television)

Direct code set up 4
Search Method 6
Code Blink Out 7

SET-UP CODES

Television 82

TROUBLESHOOTING

Helpful Hints 8

2 WWW .ONEFORAL L.COM

Installing the batteries

The ZAPPER needs 2 new “AAAA” alkaline batteries.

1 Remove the battery cover from the back of the ZAPPER by pressing down on

the tab.

2 Match the batteries to the +/- marks inside the battery case, then insert the

batteries.

3 Press the battery cover back into place.

Important notes:

- In order to avoid having to reprogram your ZAPPER after you
remove the batteries, you will need to insert new batteries within
5 minutes. Also, it is best that you do not use rechargeable batteries.

Features and Functions

1 POWER (red LED – Light Emitting Diode)

The POWER key operates the same function it did on your original remote
control. The LED underneath the POWER key will light up red whenever a
key is pressed.

2 CHANNEL +/-, VOLUME+/- and MUTE

The CH+/- and VOL+/- keys operate just as those on your original remote
control. These keys are also used to set up your ZAPPER.

3 MAGIC

The MAGIC key (= setup key) is used to set up your ZAPPER.

WWW .ONEFORAL L.COM 3

Direct code set up

To set up the ZAPPER for your Television follow the instructions below.

1 Find your Television code in the Set-Up Code section (page 82-101). Codes

are listed by brand name. The most popular codes are listed first.

2 Make sure your TV is switched on (not on standby).

3 Press and hold the MAGIC key until the LED blinks twice (The LED

underneath the POWER key will blink once then twice).

4 Enter your 5-digit code according to the chart below.

The LED underneath the POWER key will blink twice.

CHANNEL + = 3

VOLUME - = 2

CHANNEL - = 4

5 Now, aim the ZAPPER at your Television and press POWER. If your

Television switches OFF, your ZAPPER should be ready to operate your
device.

VOLUME + = 1

MUTE = 5

4 WWW .ONEFORAL L.COM

6 Turn your device back on and try all the remote’s functions to ensure they

are working properly. If the functions do not work properly, repeat steps
1-5 using another code listed under your brand.

For example: To enter a Sony TV code 33121, you would press CHANNEL +,

CHANNEL +, VOLUME +, VOLUME -, VOLUME +.

If your television does not respond to the ZAPPER after you have
tried all the codes listed for your brand, try the Search Method
described on page 6.

Make sure you write your correct 5 digit code in
the boxes provided on this page.

Important notes:

- Some codes are quite similar. If your television does not respond or
is not functioning properly with one of the codes, follow steps 1-5
with each code listed for your brand.

- If none of the codes listed for your brand operate your television,
follow the Search Method described in the next section. The Search
Method can be used even if your brand is not listed at all.

- Write the code for your TV in the boxes provided below for easy
future reference.

TV Code

WWW .ONEFORAL L.COM 5

■■■■■■ ■■ ■

■

Search Method

If your Television does not respond to the ZAPPER after trying all the codes
listed for your brand, try searching for your code. To search for your TV code:

1 Turn on your TV.

2 Press and hold the MAGIC key until the LED blinks twice

(The LED underneath the POWER key will blink once then twice).

3 Next, press the MUTE, CHANNEL -, CHANNEL -.

4 Point the ZAPPER at your television. Next, alternate between POWER and

CHANNEL - until your Television turns off. You may have to press these

keys many times (up to 150!), so please be patient. Remember, you must
aim the ZAPPER at your device the entire time you are searching for your
code.

5 When your device turns off, press and release MAGIC to store the code.

The ZAPPER should now be ready to operate your Television. Turn your
device back on and try all the remote’s functions to ensure they are
working properly. If some of the ZAPPER’S commands are not operating
correctly, try the search method again, you may be using the wrong code.

6 WWW .ONEFORAL L.COM

Code Blink Out

After you have used the Search Method, you can find out which code
the ZAPPER responded to by blinking back the code. It’s handy to know
your Television code for future reference. Remember, you can only
blink back your code after the ZAPPER is operating your device.
To blink out your TV code:

1 Press and hold the MAGIC key until the red LED blinks twice (the LED

underneath the POWER key will blink once then twice).

2 Next, press MUTE, CHANNEL -, CHANNEL +.

3 For the first digit of your 5-digit code, press VOLUME + and count the

red blinks.

4 For the second digit, press VOLUME - and count the red blinks.

5 For the third digit, press CHANNEL + and count the red blinks.

6 For the fourth digit, press CHANNEL - and count the red blinks.

7 For the fifth digit, press MUTE and count the red blinks.

Write the code for your TV in the boxes provided on page 5.

WWW .ONEFORAL L.COM 7

Problem:

Your brand is not listed in
the ONE FOR ALL code section?

The ONE FOR ALL does not
operate your television?

The ONE FOR ALL is not
performing commands
properly?

You cannot reach channel 10
and above on your TV.

The ONE FOR ALL does not
respond after pressing a key?

LED does not blink when you
press a key?

Solution:

Try the search method.

A) Try all the codes listed for your

brand.

B) Try the search method.

You may be using the wrong code.
Try Direct Set-Up again trying each
code listed under your brand or
start the search method over again
to locate the proper code.

If your original remote did not
have CHANNEL +/- keys, the ZAPPER
may not operate this function.

Make sure you are using new
batteries and are aiming the ONE
FOR ALL at your device.

Replace batteries with 2 new
“AAAA” alkaline batteries.

8 WWW .ONEFORAL L.COM

Customer Service

In the UK

E-mail : [e-mail] (*)
Fax : [phone]
Tel. : [phone] (£ 0,50 per minute)

In Ireland In Australia

E-mail : [e-mail] (*) E-mail : [e-mail] (*)
Fax : [phone] Fax : [phone]
Tel. : [phone] Tel. : [phone]

In South Africa In New Zealand

E-mail : [e-mail] E-mail : [e-mail] (*)
Fax : [phone] Fax : [phone]
Tel. : [phone] Tel. : 0508 ONE 4 ALL (663 4 255)
Tel. : [phone]

(*) Just send a blank message, you’ll get auto-reply.

WWW .ONEFORAL L.COM 9
